Levana Clara KBHP5 User manual

1
ClaraTM
Product Manual
High Resolution Video Baby Monitor
KBHP5
CAUTION: Keep small parts away from children.
Proudly Designed in Canada

1
Your feedback is essential to helping us make our products the
best they can be for all parents.
Please share your Levana story with us!
www.mylevana.com
Thank You
For bringing Levana home!
/mylevana @mylevana blog.mylevana.com

2
SAFETY INSTRUCTIONS & DISCLAIMERS
Safety Instructions
Caution: This product contains small parts. Exercise care when unpacking and assembling the product and accessories. Failure
to do so can result in choking or death.
Caution: This product is not a toy and should be kept out of children’s reach.
Caution: This is not a medical product. If there is a problem with your child, call 911 immediately.
Strangulation Hazard: Children can become entangled in cords. Power cords should be kept at least 3 ft away from the crib and
baby’s reach at all times. Failure to do so could be fatal. Baby monitors and cameras with power cords should never be hung on
or near the crib.
Supervision: This product does not replace responsible adult supervision. Check on your child at regular intervals and make
sure your monitor is always adequately charged. Failure to do so can be fatal.
Power Source: LEVANA® highly recommends the use of an Uninterruptible Power Supply (UPS) with surge protection when
plugging in the camera and monitor. This product should only be used with the AC power adapters included.
Water and Moisture: Product intended for indoor use only. The unit should not be exposed to rain, moisture, dripping or
splashing, and should not be used near water.
Keep Away from Heat Sources: This product should not be exposed to direct heat sources such as a candle, replace, radiator,
heat register, stove or other appliances that emit heat. The product should not be left in direct sunlight.
Non-Use Periods: Always unplug the AC adapters from the wall outlet during long periods of non-use.
Damage Requiring Service: This product should be serviced by qualied personnel only, when:
A. Product has fallen or liquid has spilled into the unit.
B. Product has been exposed to liquids or moisture.
C. Product does not appear to operate normally or exhibits a distinct change in performance.
D. Product has been dropped or the casing has been damaged.
• Please note that the above mentioned are not covered under the product warranty.

3
SAFETY INSTRUCTIONS & DISCLAIMERS
Disclaimers
• We reserve the right to change models, conguration or specications without notice or liability. Product may not be
exactly as shown.
• Optimum range is 150 ft when signal is passing through walls or oors. Microwave ovens (when in use) may cause signal
disruption at close range. Buildings with metal frames may also cause signal disruption. Maximum transmission range is
900 ft in an open area.
• Night Vision range is up to 12 ft under ideal conditions. Objects at or beyond this range may be partially or completely
obscured, depending on the camera application.
• Battery life of 8 hours based on Power Save mode. Battery lasts an average of 4 hours with continuous audio/video usage.
© 2018 LEVANA®. All rights reserved LEVANA® logo, Clara™ and other LEVANA® marks may be registered. All other Trademarks
are the property of their respective owners.

4
COMPLIANCE STATEMENTS
FCC Caution
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IC Warning
This device complies with CNR Industry Canada license-exempt devices. Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of
the device.
This device is compliant with RF exposure guidelines, users can obtain Canadian information on RF exposure and compliance.
The minimum distance from body to use of the device is 20 cm.

5
SUPPORT
We take quality very seriously. This is why all of our products come with a one-year warranty from the original purchase
date against defects in workmanship and materials. If you have warranty or support issues, please contact us at:
Web: www.mylevana.com Support: www.mylevana.com/Support_Center.eng.html
Levana Canada Levana USA
4080 Montrose Road 840 Aero Drive
Niagara Falls, ON Cheektowaga, NY
Canada, L2H 1J9 USA 14225
Product Manual Feedback
At Levana, we’re always looking to improve your experience. Please share any suggestions for this product
manual to help us continue on this journey. CLICK HERE FOR FEEDBACK SURVEY LINK
Help Videos
Click to access our Support Center or visit our website at www.mylevana.com and open Resources on the
product page. These videos provide a visual guide for setting up and using your monitor.
www.mylevana.com/videos

6
WARRANTY TERMS
• LEVANA® products are guaranteed for a period of one year from the date of purchase against defects in workmanship and
materials. This warranty is limited to the repair, replacement or refund of the purchase price at LEVANA®’s options.
• This warranty becomes void if the product shows evidence of having been misused, mishandled or tampered with contrary
to the applicable instruction manual.
• Routine cleaning, normal cosmetic and mechanical wear and tear are not covered under the terms of this warranty.
• The warranty expressly provided for herein is the sole warranty provided in connection with the product itself and no other
warranty, expressed or implied is provided. LEVANA® assumes no responsibilities for any other claims not specically men-
tioned in this warranty.
• This warranty does not cover the shipping cost, insurance or any other incidental charges.
• You MUST contact LEVANA® at www.mylevana.com/Contact before sending any product back for repair. You will be sent
a Return Authorization form with return instructions. When returning the product for warranty service, please pack it
carefully in the original box with all supplied accessories, and enclose your original receipt or copy, and a brief explanation of
the problem, and include the RA number.
• This warranty is valid in Canada and the contiguous US.
• This warranty cannot be re-issued.
• Please visit our website at www.mylevana.com/store-policies for additional information about your product warranty.

7
TABLE OF CONTENTS
Thank You ...................................................................................................... 1
Safety Instructions & Disclaimers
Safety Instructions ................................................................................. 2
Disclaimers.............................................................................................. 3
Compliance Statements .............................................................................. 4
Support ........................................................................................................... 5
Warranty Terms ............................................................................................ 6
What’s Included............................................................................................. 8
Buttons & Features....................................................................................... 9
Getting Started.............................................................................................. 10
Connecting Power To The Monitor ...................................................... 10
Charging The Battery............................................................................. 10
Getting The Most Out Of Your Rechargeable Battery ....................... 10
Connecting Power ToThe Camera ....................................................... 10
Introduction Screens ............................................................................. 11
Status Bar................................................................................................ 12
Setup
Monitor Placement ................................................................................ 13
Camera Placement................................................................................. 13
Features
Pan/Tilt/Zoom......................................................................................... 15
Volume Controls..................................................................................... 16
Talk To Babytm......................................................................................... 17
Accessing The Menu .............................................................................. 17
Menu Functions
Power Save.............................................................................................. 18
Lullabies .................................................................................................. 19
Feeding Timer......................................................................................... 19
Camera select (Single View-Active Camera)........................................ 20
Split Screen ............................................................................................. 21
Quad Screen ........................................................................................... 21
Sequence Screen.................................................................................... 21
Camera pairing
Pairing...................................................................................................... 22
Un-Pairing ............................................................................................... 22
Night Vision............................................................................................. 23
Settings
Language................................................................................................. 24
Brightness ............................................................................................... 24
Time Set................................................................................................... 25
Factory Reset .......................................................................................... 25
Temperature........................................................................................... 26
Auto Motion Tracking ............................................................................ 27
Support.................................................................................................... 28
Battery Installation....................................................................................... 29
Maintenance.................................................................................................. 29
Troubleshooting............................................................................................ 30
Frequently Asked Questions....................................................................... 32
Specications................................................................................................. 33

8
WHAT’S INCLUDED
• 5” High Resolution Baby Video Monitor
• 2 Rechargeable Battery Packs (Installed)
• Pan/Tilt/Zoom Night Vision Camera
• 2 Power Adapters (Monitor and Camera)
• Camera Mounting Hardware
• Quick Start Guide
• 1 Year Warranty
• Lifetime Customer Support
Adding Cameras
Your Clara monitor is expandable up to 4 cameras and is compatible with Clara PTZ cameras.
• Visit www.mylevana.com to nd product details. Clara Additional Camera
KBHP5C ONLY

9
BUTTONS & FEATURES
1. Power ON/OFF (Top)
2. Exit/Back
3. Volume-/+ (Side)
4. Navigation Arrows
5. Menu/OK
6. Talk to BabyTM
7. Microphone
8. Stand (Back)
9. Power Input (Side)
10. Speakers
1. Night Vision Sensor
2. Microphone
3. Power LED (Side)
4. Power ON/OFF (Side)
5. Power Input (Side)
6. Temperature Sensor (Back)
7. Antenna (Back)
8. Pairing Button (Bottom)
10 1
2
3
4
5
6
78
9
1
2
4
5
6
7
8
3
