Level 1 Lasers AUTO1 User manual

Model: AUTO1
Auto Levelling Rotang Laser
and Electronic Receiver

CONTENTS
User Safety and Contents 2
AUTO1™ Diagram 3
Operating Instructions 4
Batteries & Power 4
Rotation Speed & Side Mount 5
 VerticalOperation&Specications  6
LR700 Receiver 7
Warranty 8
User Safety
• Laseroutputsignliesneartheoutputaperture.
• Donotstaredirectlyintolaserbeam.
• Donotdisassembletheinstrumentorattemptto
 performanyinternalservicing.Repairsandservice
 shouldbeperformedonlyauthorisedservice
 centresofRedbackLasers.
• Thisinstrumentcomplieswiththesafety
 Classicationstandardsoflaserradiation.
2
CAUTION: Class II laser <1mW at 635nm.
Do NOT stare into laser beam or aim at
another person.
Follow relevant Australian Standards
AUTO1™ Included Accessories
• AUTO1™LaserUnit
• ProtectiveCarryCase
• Standard“AA”Batteries
• LR700ElectronicReceiver
• ReceiverStaffClamp
• SideMountBracket(wallmount)
• InstructionManual
Copyright©CMILasersTMRedBacklasersTMandLevel1LasersTM.AllrightsreservedCMIIndustriesPtyLtd2012
NoartworkorphotographsproducedbyCMIIndustriesPtyLtdmaybeusedcopiedorreproducedwithoutthewrittenconsent
fromCMIIndustriesPtyLtd

3
AUTO1TM INTRODUCTION
www.level1lasers.com.au
1
3
5
7
1.ControlPanel
2.DotLaserOutput
3.RotatingLaserOutput
4.PendulumLock
5.VialforVerticalRotationMode
6.DCInput(optionalPowerSupply)
7.BatteryCompartment6x“AA”
8.Tripod5/8”-11tpiMount
2
4
AdjustmentPin
AttachmentLever
8
Side Plate
5/8”–11tpiScrew
AUTO1TM Laser Unit
6

4
AUTO1TM OPERATING INSTRUCTIONS
Battery Instructions
PlacelaseronTripod or on a stable surface,rotatethependulumlocking
knob to the un-locked position (marked as “ON”) then press the power
buttononthecontrolpanel.Thelaserwillautolevel,thelaserheadwill
rotateandemitalaserbeam.
The AUTO1 operates on 6 x standard Alkaline “AA” batteries, simply un-
screwthebatterycompartmentwhereindicatedandinsertbatteriesinthe
directionshown.
Turning Laser On For Levelling (Horizontal Operation)
PowerButton RotationSpeedSelection
www.level1lasers.com.au

5
www.level1lasers.com.au
Turning Laser On For Levelling (Horizontal Operation)
AUTO1TM OPERATING INSTRUCTIONS
Rotation Speed
The AUTO1TM has three rotation speeds (Low, Medium and High), under
normal conditions high speed is recommended when using the LR700
electronicreceiver.Ifyouareusingthelaserindoorsvisiblyaslowerrotation
speedmayincreasethevisibilityofthelineproduced.
Rotationspeedischangedbypressingthespeedbuttononthecontrolpanel
anLEDlightwillindicatetheselectedspeed,furtherpressesofthisbutton
wiltogglebetweenthethreeavailablespeeds.
TheSidePlatecanbeusedintwoways;rstlyasawallmountinhorizontal
levellingmodeandsecondlyasasidemountforverticalrotationmode.
TheplateclipsontothebaratthebackoftheAUTO1laserandisremoved
bypressingtheattachmentlevel.
Side Mount Plate

6
Vertical Rotation Mode (Manual Levelling)
TheAUTO1TMcanbeplacedonitssidewiththesidemountplateattached
and used for vertical rotation, this can be handy for any indoor vertical
alignmentofftherotatingbeam.
TooperatetheAUTO1inverticalrotationmodeDONOTunlockthependulum,
leaveitinthe“OFF”position,usetheadjustmentscrewonthesidemountto
leveloffthebubblevialontheAUTO1.Oncethebubbleiscentralinthevial
pressthepowerbuttononthelaserandthelaserheadwillbegintorotate,
therotatingbeambeingaverticallineandthedotbeambeinglevel.
Anotherapplicationwheretheverticalmodecanbeusefullissitesquaring
byaligningthedotlaserbeamalongoneaxisofthe90degreesquareand
thenusingthereceivertopickuptherotatingbeamwhichisat90degrees
tothedotlaserbeam.
LaserWavelength 635nm<1mW
LaserClass II
RangewithLR700Receiver 240mdiameter
Accuracy ±4mm/20m
SelfLevellingRange ±3o
IPDustWaterResistance IP54
WorkinTemperature -10oCto+40oC(inshade)
Power 6x“AA”Alkaline
LowPower PowerLEDFlash
Size 132x120x160mm
Weight 1.5Kg
AUTO1TM OPERATING INSTRUCTIONS

7
www.level1lasers.com.au
AUTO1TM OPERATING INSTRUCTIONS
TheLR700isan electronic laser receiver/detectorandcomes withastaff
clampbracketwhichallowsyoutoattachthereceivertoameasuringstaff.
BubbleVial
LaserReception
Window
Speaker
Power
LEDindicators
Powerupbypressingthepowerbutton,holdthereceiversothereception
window is facing the rotating laser (upright for horizontal and on its side
forverticalrotation).Whenthereceptionwindowislevelwiththerotating
beam the LED indication lights and Sound will alert you, When the laser
beamisabsolutelylevelwiththereceiverthecentralgreenLEDisilluminated
theredLED’saboveandbelowindicatewhenthelaserbeamisjustaboveor
belowthecentrallineonthereceiver.
TheBubblevialwillhelpyouholdthereceiverandstaffverticalwhentaking
readings.Thelineonthestaffclamplinesupwiththelevelmarkonthe
receiver.Notethatthereceiveronlyworksontherotatingbeamandnotthe
dot,andthathighspeedrotationtendstoworkbetterthanmediumorslow.
LR700 Receiver operation

12 Month WARRANTY - LEVEL 1 LASERS
Level1LasersTMdistributedbyCMIIndustriesPtyLtd
P.O.Box7324-GeelongWest-Victoria-3218-Australia
Ph:(03)52280796email:[email protected]
CMIIndustriesPtyLtdprovidesconsumerswithawarrantytoourproducts,thisisinadditionto
requirementsofanyrelevantlegislationsuchastheCompetitionandConsumerAct2010.Denitions:
“CMI”,“We”or“Our”“Level1Lases”referstoCMIIndustriesPtyLtd(ABN29102713922)of8Autumn
St,GeelongWest,Victoria3218ph(03)52280777
“You”or“Consumer”referstotheinitialpurchaseroftheproduct.
“Product”referstogoodsmanufacturedbyorforCMIIndustriesPtyLtdunderthebrandof
Level1Lasers.
“Material”referstomaterialorcomponentusedintheconstructionandmanufactureoftheproduct.
“Workmanship”referstohandling,assemblyandmanufacturingprocessesdonebyorforCMI
IndustriesPtyLtdinordertomanufacturetheproducts.
“WarrantyPeriod”ForLevel1LaserProductsis12 Months.Warrantyperiodisfromoriginalpurchase
date,noextensionismadeintheeventofwarrantyreplacementproductssuppliedortimespentbeing
repaired.
OurgoodscomewithguaranteesthatcannotbeexcludedundertheAustralianConsumerLaw.Youare
entitledtoareplacementorrefundforamajorfailureandforcompensationforanyotherreasonably
foreseeablelossordamage.Youarealsoentitledtohavethegoodsrepairedorreplacedifthegoods
failtobeofacceptablequalityandthefailuredoesnotamounttoamajorfailure.
CMIwarrantsthatourproductswillbefreefromdefectsinmaterialandworkmanshipforthewarranty
period.
CMIpromisestorepairorreplace,freeofcharge,theproductorpartofproductiffoundtobefaulty
duetodefectiveworkmanshipormaterialswithinthedurationofthewarrantyaslongasthefollowing
termsandconditionsaremet;
•Productmustnothavebeenmisusedorabused,mustnothaveincurredaccidentaldamageorhad
un-authorisedrepairortamperingthathascausedorcontributedtoitsfaultorfailure.
•YoumustcontactCMIbyphone,mailoremailimmediatelywhenafaultordefecthasbecome
apparentandwithinthewarrantyperiod.
•ProductmustbereturnedtostoreofpurchaseordirectlytoCMI,wewillcovercostofpostageonly
whensentbyourreplypaidAustraliaPostservice(AustralianMainlandandTasmaniaonly)detailswill
beprovideduponphone,postoremailcommunicationswithus.
•CMIwillcovercostoffreightbackofrepairedorreplacedproducttooriginalpurchasestoreoryou
directly(dependingonhowitwassentAustralianMainLandandTasmaniaonly).
•CMIwilldeterminewhethertorepairorreplacetheproductorpartofproductonacasebycase
basis.
•Furtherexclusionsinthiswarrantyincludedamageordefectcausedbyuseofnon-original
accessoriesorparts,damageintransportation,normalwearandtear,damagethroughmoisture,
damageduetoelectricsurge,failureduetoneglectordamagedcausedbyadjustmentsnotoutlinedin
CMI’sinstructions.
SubjecttotherequirementsofallapplicableAustralianActsorlegislationandtotheextentpermitted
bylaw,CMIacceptsnoliability(whetherexpressedorimplied)ofanynaturewhatsoeverforanyloss
ofearnings,hiringofreplacementequipment,Inaccurateworkcarriedoutbytheconsumeroragent,
damageorinjuryarisingasaresultofanyfaultintheproduct.Itistheconsumersresponsibilityto
maintaingoodworkingpracticesandregularlytesttheirtoolsforaccuracyandserviceability.
Calibrationoftheproductisnotcoveredbywarrantysubjecttotherequirementofallapplicable
AustralianActsorlegislationandtotheextentpermittedbylaw,
ACMIproductreturnedthatfailstofallwithinthetermsandconditionsofthiswarrantywillbequoted
forrepair.
