LevelOne WPS-0100 User manual

L
Le ev ve el lO On ne e
WPS-0100
WPS-0100USB
W
Wi ir re el le es ss s P Pr ri in nt te er r S Se er rv ve er r
U
Us se er r G Gu ui id de e

Table of Contents
Chapter 1 Introduction 1
Features........................................................................................................................................1
Safety Instructions.....................................................................................................................2
Package Contents.......................................................................................................................3
Models .........................................................................................................................................3
LED Indicators...........................................................................................................................6
Diagnostic Push Button............................................................................................................6
Chapter 2 LAN Installation 8
Procedure.....................................................................................................................................8
Chapter 3 LevelOne Printer Server Configuration 10
Overview...................................................................................................................................10
Using the WindowsWizard ...................................................................................................10
Alternatives to the Windows Wizard ...................................................................................11
Advanced Configuration and Management.........................................................................12
Chapter 4 Client PC Configuration 13
Overview...................................................................................................................................13
Wireless Settings for client PCs ............................................................................................13
Printing Methods......................................................................................................................14
Windows Peer-to-peer Print Driver......................................................................................16
Windows SMB Printing..........................................................................................................20
Windows with Server-based Print Queues..........................................................................21
Windows using NDPS............................................................................................................22
Macintosh (AppleTalk)...........................................................................................................23
Chapter 5 BiAdmin Management Utility 26
Requirements............................................................................................................................26
Installation.................................................................................................................................26
Operation...................................................................................................................................27
Chapter 6 Web Interface Setup 33
Overview...................................................................................................................................33
Preparation................................................................................................................................33
Connecting to the LevelOne Printer Server........................................................................34
Configuration Screens.............................................................................................................34
Chapter 7 Special Features 44
Overview...................................................................................................................................44
Internet Printing Protocol (IPP).............................................................................................44

Page ii
Internet Mail Printing..............................................................................................................49
Printing through the Internet..................................................................................................53
SNMP.........................................................................................................................................54
Wireless Configuration...........................................................................................................55
Chapter 8 Troubleshooting 60
Overview...................................................................................................................................60
Hardware & LAN Problems ..................................................................................................60
AppleTalk (Macintosh)...........................................................................................................61
Novell NetWare .......................................................................................................................63
Windows Printing Problems ..................................................................................................64
Appendix A Specifications 68
General Specifications............................................................................................................68
Protocol Support ......................................................................................................................70
Feature Support........................................................................................................................70
Regulatory Approvals .............................................................................................................71
Appendix B Network Server Configuration 71
Windows NT Server................................................................................................................71
Windows 2000 Server.............................................................................................................73
Novell NetWare .......................................................................................................................73
Unix Systems ............................................................................................................................78

Page 1
Chapter 1
Introduction
This chapter provides an overview of your LevelOne Printer Server's features.
Features
Congratulations on the purchase of your new LevelOne Printer Server. This device was
designed to provide a simple and efficient network printing solution. It is packed with features,
including:
ØVersatility. The LevelOne Printer Server supports up to five protocols: NetWare, TCP/IP,
SMB (Service Message Block), AppleTalk (EtherTalk), and NetBEUI. It features one or
two Ethernet interface ports and operating system support includes Unix, Novell, and
Microsoft Windows.
ØEasy Installation. The LevelOne Printer Server makes adding printers or plotters to
your network simple. Depending on your model, it will support 10BaseT only, 10Base2
and 10BaseT, or 10BaseT and 100BaseT. The auto-sensing feature on the LAN interface
means that there is no need to set jumpers or perform software configuration to select the
network interface used.
ØEasy Setup. A number of utility programs are supplied to simplify setup. For Windows
95/98/NT/2000/XP users, the BiAdmin program makes it easy to configure the LevelOne
Printer Server for a variety of network and server configurations.
ØWeb-based Interface. On 100BaseT models, the Web-based interface provides an easy
method of configuration in TCP/IP networks.
ØCompact Size. This allows the LevelOne Printer Server to be used even where space is
limited.
ØRemote Management Tools. A variety of software tools are provided. In most
environments, both the LevelOne Printer Server and attached bi-directional printers can be
configured remotely.
ØSNMP Support. The LevelOne Printer Server can act as a SNMP agent, with it own
MIB. This allows TCP/IP users to monitor, configure and troubleshoot the LevelOne
Printer Server using their existing SNMP management tools.
ØJetAdmin Support. 100BaseT models support the HP JetAdmin program. If you are
already using JetAdmin, you can also use this program to manage your LevelOne Printer
Server.
ØInternet Printing Protocol (IPP) Support. Some LevelOne Printer Server models can
act an IPP (Internet Printing Protocol) Server, allowing clients, suppliers, colleagues and
others to print to your printer from anywhere on the Internet. Windows IPP Client software
is also supplied.
See the "Protocol Support" and "Feature Support"
tables in Appendix A for details of which models
support the different features.
1

Page 2
Safety Instructions
For your own safety, and to protect your LevelOne Printer Server, please observe the following
safety advice.
1. Unplug this device from its power source before cleaning. Use only a slightly dampened
cloth for cleaning. Do not use liquid or aerosol cleaners.
2. Avoid using this product near water. Exposure to water poses an electric-shock hazard.
3. Do not place the LevelOne Printer Server on an unstable surface. The device may fall
causing serious damage to the device.
4. This device should only be used with the power supply type specified on the marking label.
If you are not sure of type of your local power supply, consult your dealer or the local
power company.
5. Do not pinch, crimp or otherwise damage the power cord. If exposed to foot traffic,
ensures that the cable is properly shielded and does not pose a tripping hazard.
6. If using an extension cord, makes sure the total ampere rating of the products using the
cord does not exceed the extension cord's ampere rating.
7. Do not attempt to service this device, as opening or removing casing may expose you to
dangerous voltage points or other risks. Refer all servicing to qualified service personnel.
8. The LevelOne Printer Server should be serviced by qualified service personnelunder the
following conditions:
•The power cord is damaged or frayed.
•Liquid has been spilled onto the product.
•The product has been exposed to rain or water.
•The product does not operate normally in accordance with the operating instructions.
•The device has been dropped or the casing has been damaged.

Page 3
Package Contents
You should find the following items packaged with your LevelOne Printer Server. If any items
are missing, contact your dealer immediately.
•The LevelOne Printer Server
•Power Adapter
•One CD-ROM containing all support programs and this manual
•Quick Install Guide
•Wireless PCMCIA Card (for WPS-0100 and WPS-0100USB)
Models
This manual covers the following LevelOne Printer Server models. Details of the LEDs and
DIP Switches are in this Chapter. Further details of each model are contained inAppendix A -
Specifications.

Page 4
WPS-0100
41 Parallel Printer Port
4IEEE 802.11b Wireless Station
410/100BaseT
10/100
BaseT
Port
Parallel
Port
Diagnostic
Button
12V
Power
PCMCIA
Wireless
Card LAN
LED
WLAN
LEDACT
LED
Error
LED

Page 5
WPS-0100USB
41 USB Printer Port
4IEEE 802.11b Wireless Station
410/100BaseT
USB
Port
10/100
BaseT
Port
Diagnostic
Button
PCMCIA
Wireless
Card
12V Power
Error
LED
ACT
LED
LAN
LED
WLAN
LED

Page 6
LED Indicators
All models have two LED indicators on the top. The Status/Error LED is orange or red. The
Power/Link indicator LED is green. The LED indicator modes are described in the following
table.
Green LED Red/Orange LED Status Description
Off Off No power.
On On Hardware error.
Flashing Flashing Firmware upgrade in progress.
On Flashing (USB only) No printer connected to the USB port.
On Off Normal operation -idle.
Flashing Off Normal operation -transmitting or
receiving packets from the network.
LEDs -WPS-0100 and WPS-0100USB
The WPS-0100 and WPS-0100USB have 2 additional LED indicators as follows:
LED Description
WLAN ACT Off -Idle
Flashing -Transmitting or receiving data through the Wireless
LAN.
LAN ACT Off -Idle
Flashing -Transmitting or receiving data through the LAN.
Diagnostic Push Button
LevelOne Printer Server models WPS-0100 and WPS-0100USB are fitted with a Diagnostic
Push Button. The button is recessed; a pin or paper clip can be used to press it. This button has
2 functions:
•Restore the factory default settings
•Print a test page containing all current settings.
To restore the factory default settings:
1. Turn the LevelOne Printer Server OFF.
2. Press and hold the diagnostic button. While pressing the button, switch the LevelOne
Printer Server ON.
3. If you continue pressing the button for 10 seconds, a diagnostic page will be printed,
showing the new (default) settings.
To generate a Diagnostic print out
1. Ensure that both the LevelOne Printer Server and the printer attached to port 1 are ON.
2. Press the diagnostic button, and hold it in for 2 seconds.

Page 7
3. The test page, containing the current settings, will be printed.
Note:
PostScript printers are unable to print this page. If you have a PostScript printer on Port 1,
the test page will not be printed.

Page 8
Chapter 2
LAN Installation
This chapter describes how to install the LevelOne Printer Server in your Local Area
Network.
Procedure
1. Preparation
•Ensure the power is OFF. Do not connect the LevelOne Printer Server while power is On.
•For the PS 7100 and WPS-0100USB only, the PCMCIA wireless card must be inserted
into the PCMCIA slot on the rear.
With the LEDs on the PCMCIA card facing UP, slide the card into the PCMCIA slot until
it encounters some resistance. Push firmly and it will click into position.
•Find the Default Server Name for your LevelOne Printer Server.
The Default Server Name is shown on a sticker on the base of the device. It consists of 8
letters and/or digits. Record this name; it may be needed during configuration.
2. Connect the Printer or Printers
Connect the printer or plotter to the LevelOne Printer Server's printer port(s), as appropriate:
•USB Ports -Use the USB cable supplied with your printer to connect the printer to the
LevelOne Printer Server's USB port
•Parallel Ports -Use standard Parallel port cables to connect the printer to the parallel port
on the LevelOne Printer Server. Parallel printer cables should be less than 3 meters long.
•Serial Port-Use a standard Serial port cable to connect the printer to the serial port on the
LevelOne Printer Server.
3. Connect the Network Cable
•Connect the network cable to the proper connector on the LevelOne Printer Server. The
LevelOne Printer Server will automatically recognize whichever connector is used.
•Note that if your LevelOne Printer Server has both BNC and UTP (10BaseT or
10/100BaseT) connectors, only ONE (1) connection can be used.
On the WPS-0100 and WPS-0100USB, connecting the LAN cable will
disable the Wireless interface, because the default "Infrastructure
mode" wireless setting can NOT be used with the LAN interface.
To use both the LAN and Wireless interfaces, the Wireless mode
must be set to "Ad-hoc".
After configuration, the LAN interface can be disconnected if not
required.
4. Power Up
Plug in the power adapter cable and power up. Start-up will take only a few seconds.
Use only the Power Supply unit provided with the device. Power
Supply units for different models are not interchangeable.
2

LAN Installation
Page 9
5. Check the LEDs
•The Red Error LED should flash, then turn Off. When the Red LED goes off and the
Green LED remains lit or flashes, the LevelOne Printer Server is ready.
•For models with USB ports, the Red Error LED will remain flashing if the LevelOne
Printer Server can't connect to the printer.
•If your model supports 10BaseT and 100BaseT, check the 10/100BaseT link LED or
LEDs next to the LAN connection. If the auto negotiationFails, the LED (or both LEDs, if
there are 2) will be Off. In this case, set the DIP switches to suit your LAN, as described in
the DIP Switch Table in Chapter 1.

Page 10
Chapter 3
LevelOne Printer Server
Configuration
This chapter provides an overview of the configuration process.
Overview
The LevelOne Printer Server is designed to support many different platforms, and the
configuration required would depend upon the environment in which it is installed.
•The LevelOne Printer Server usually requires configuration. A Windows-based setup
Wizard is provided on the CD-ROM to simplify this task.
•PCs wishing to use the printer attached to the LevelOne Printer Serveralways require
configuration. See Chapter 4-Client Configuration for details.
•If using a NetWare Server (V3, 4, or 5 in "compatibility" mode), the supplied Setup
Wizard can also configure the NetWare Server for basic operation.
•For advanced configuration and management, the BiAdmin program (detailed in
Chapter 6 -BiAdmin Management Utility) is recommended.
•If using NDPS, refer toAppendix B -Network Server Configuration.
•If you wish to use a queue-based printing system usingWindows NT Server/Windows
2000, the Network Server must be configured as detailed inAppendix B -Network Server
Configuration. However, it is not necessary to use a Network Server-based queue; client
PCs can print directly to the LevelOne Printer Server using the Peer-to-peer Print Driver
installed by the User setup option on the CD-ROM.
Using the Windows Wizard
The Windows-based Wizard runs on Windows 95, 98, NT4.0, Windows 2000 and XP.
It will configure the LevelOne Printer Server for your Network environment.
If using NetWare, the Wizard can also configure the NetWare Server, provided:
•You are logged into the required NetWare server with ADMIN rights.
•NetWare Client32 is installed on the PC you are using for configuration.
Procedure
1. Insert the supplied CD-ROM into your drive. If the setup program does not start
automatically, run SETUP in the root folder.
2. Select the Administratorinstallation option. This will install both the Wizard and the
BiAdmin management program. (See Chapter 5 for details on using BiAdmin.)
3. Follow the prompts to complete the installation.
4. Run the Setup Wizard, either by using this option on the final installation screen, or by
selecting it from the menu created by the installation.
5. Within the Setup Wizard, select the LevelOne Printer Server you wish to configure, click
Configure, and step through the Wizard.
3

Page 11
If the desired LevelOne Printer Server is not listed:
•Check all cables to the LevelOne Printer Server.
•Check the LevelOne Printer Server's LEDs:
•The Red LED should be OFF and the Green LED should be ON or flashing.
•If your model supports 10BaseT and 100BaseT, check the 10/100BaseT link LED
next to the LAN connection. If the auto negotiation fails, the 10/100BaseT Link LED
will not light when the device is powered up. (If there are 2 LEDs, neither will light.)
•Check that your PC has either the TCP/IP or NetBEUI network protocols installed.
See Checking yourNetwork Protocols for details.
•If you PC can't configure the LevelOne Printer Server correctly (in Infrastructure mode),
then try to connect to LAN and disable the Wireless.
Wireless Configuration
For the WPS-0100 and WPS-0100USB, which include Wireless Stations, the Wizard will
display a "Wireless" configuration screen.
For further details about the WPS-0100 and WPS-0100USBs' Wireless Station feature, refer to
Wireless Configuration in Chapter 7 -Special Features.
The WPS-0100 and WPS-0100USBdo NOT allow both a LAN
connection and "Infrastructure" mode.
To use "Infrastructure" mode, you must DISCONNECT theLAN
cable after configuration.
If using "Ad-hoc" mode, the LAN cable can be left connected,
and both the LAN and Wireless interfaces are available.
Alternatives to the Windows Wizard
If you do not have a Windows 32 platform available, use one of the following methods to
configure the LevelOne Printer Server.
Web Browser Only available on 100BaseT models. See Chapter 6 -Web Interface
Setup for details.
FTP Using this method, the configuration file is downloaded from the
LevelOne Printer Server, edited, then sent back. No software needs to be
installed.
See the UNIX manual for details. The Unix manual is on the CD-ROM,
in the Manual\Unix folder
WPConfig This program requires Windows 3.1, and the IPX/SPX protocol.
This program is on the CD-ROM, in the Utilities\WPConfig
folder. Instructions for using the program are in a sub-folder of the
Manual folder on the CD-ROM.
PSConfig Menu-based DOS program, intended only to configure the LevelOne
Printer Server for use with NetWare V2, 3 and 4.
This program is on the CD-ROM, in the Utilities\DOS folder.
Instructions for using the program are in a sub-folder of the Manual
folder on the CD-ROM.

Page 12
Quickset Command-line DOS program, intended only to configure the LevelOne
Printer Server for use with NetWare V2, 3 and 4. This program also has
a limited ability to configure the NetWare Server itself.
This program is on the CD-ROM, in the Utilities\DOS folder.
Instructions for using the program are in a sub-folder of the Manual
folder on the CD-ROM.
Advanced Configuration and Management
The BiAdmin management utility is provided for advanced configuration and management.
This program is installed by default when the Administratorinstall option is chosen.
•See Chapter 5 for details on using BiAdmin.
•For instructions on using BiAdmin for NetWare configuration, see the NetWare manual on
the CD-ROM. It is located in the Manual/Netware folder.

Page 13
Chapter 4
Client PC Configuration
The chapter details the client configuration required on LAN clients to use the printer
or printers attached to the LevelOne Printer Server.
Overview
Before performing client configuration, the following conditions must be met:
•LevelOne Printer Server must be installed on your LAN
•LevelOne Printer Server must be configured (refer to Chapter 3).
•Both the LevelOne Printer Server and the attached printer must be powered ON.
•If the client PC uses a Wireless connection to communicate with the LevelOne Printer
Server, the PC's wireless settings must be correct, as described below.
Wireless Settings for client PCs
The WPS-0100 and WPS-0100USB incorporate Wireless Stations for IEEE 802.11b devices.
This section is only relevant to users of the WPS-0100 and WPS-0100USB.
To print to the WPS-0100 and WPS-0100USB, Wireless stations must ensure that the
following Wireless Settings are correct.
Ad-hoc Mode Infrastructure Mode
SSID Must match the other Wireless stations,
(WPS-0100 or WPS-0100USB) unless
the SSID isnull or "any".
If its SSID isnull or "any", a Wireless
station can join any Ad-hoc group.
Must match the Access Point.
Channel Should match the other Wireless
stations (WPS-0100 or WPS-
0100USB).
However, when joining an existing ad-
hoc group, a Wireless station must use
the Channel in use, rather than its own
Channel.
Access Point sets the Channel
used.
Wireless stations
automatically locate the
correct channel.
WEP Settings Must match the other Wireless stations.
(WPS-0100 or WPS-0100USB) Must match the Access Point.
To change these settings on your PC, use the software provided with your Wirelesscard.
If your PC's wireless settings are not correct, you will not be able to print to the WPS-0100 or
WPS-0100USB via a Wireless connection.
4

Page 14
Printing Methods
The LevelOne Printer Server supports a number of printing methods:
•Peer-to-peer Print Driver is used by the User installation on the CD-ROM. The print jobs
are stored (queued) on your PC, and sent to the LevelOne Printer Server when it is
available.
•Server-based Print Queue means that the all print jobs are stored (queued) on the Network
Server (e.g.NetWare, Windows NT/2000) and then sent to the LevelOne Printer Server.
This allows the Network Administrator to modify the Print Queue. For example, an
important job can be moved to the head of the queue.
•Windows SMB printing is a Microsoft standard for using a "Network Printer". No
additional software needs to be installed on your Windows PC, and printing from MS-
DOS programs is supported. However, because the LevelOne Printer Server can not store
files, large print jobs may cause problems.
•AppleTalk is also supported, and normally no configuration of the LevelOne Printer
Server is required. See the Macintosh section of this chapter for details of client
configuration.
Which printing method should I use?
•If using Windows 95, 98, NT, XP, or 2000, the easiest method is to install the Peer-to-peer
Print Driver on the CD-ROM, by selecting the User installation.
•If using Windows, and you need to print from MS-DOS programs, or you don't wish to
install additional software, use SMB.
However, SMB is not suitable for large, complex documents, so if you need this as well as
MS-DOS printing, you should install BOTH the Peer-to-peer Print Driver and SMB
printing. MS-DOS programs can use the SMB printer, Windows programs should use the
Peer-to-peer Print Driver.
•If yourLAN has Network Servers (e.g. Windows NT, Windows 2000 Server, NetWare)
use the method advised by your Network Administrator. The LevelOne Printer Server can
print via a queue located on a Network server, if desired.
•Unix users -refer to the Unix Manual on the CD-ROM, in the Manual/Unix directory.
•Macintosh users -refer to the Macintosh section of this chapter.
Checking your Network Protocols (Windows)
Your PC must have EITHER the TCP/IP or NetBEUI protocols installed.
•If using the Peer-to-peer Print Driver, the installation program will check this for you.
•If using Windows SMB Printing, you must check manually, as described below.
(This is for Windows 95 only. All later versions of Windows have TCP/IP installed by
default.)
1. Select the Settings -Control Panel -Network option on the Start Menu. You should see a
screen like the one following:

Page 15
Figure 1: Network Configuration
•The top line in the list (NetBEUI -> PCI Fast Ethernet Adapter) indicates that the
NetBEUI protocol is installed on this PC. Your PC will show the name of the your
Network card rather than "PCI Fast Ethernet Adapter".
•The highlighted line (TCP/IP -> PCI Fast Ethernet Adapter) indicates that TCP/IP is
installed. Your PC will show the name of the your Network card rather than "PCI Fast
Ethernet Adapter".
2. If neither line is present:
•Install the NetBEUI protocol by selecting Add -Protocol -Microsoft -NetBEUI -OK.
You may be prompted for your Windows CD-ROM.
•If required, you can also install TCP/IP. However, depending on your LAN
environment, TCP/IP may require further configuration.
3. If either protocol is already installed, proceed with installation.

Page 16
Windows Peer-to-peer Print Driver
With this printing method, print jobs are stored (queued) on your PC, and then sent to the
LevelOne Printer Server when it is available.
Setup
Before performing the following procedure, the LevelOne Printer Server must be installed on
your LAN, and configured as described in Chapter 3. Both the LevelOne Printer Server and the
attached printer should be powered ON.
1. Insert the supplied CD-ROM into your drive. If the setup program does not start
automatically, run SETUP in the root folder.
2. Select the Installationicon, then choose the User option in the "Setup Type" screen. This
will install the Peer-to-peer Print Driver.
3. Follow the prompts to complete the installation. (Refer to the Windows section of Chapter
8 -Troubleshooting if there is a problem with the installation.)
4. The Print Driver Setup will then run.
5. The LAN will be searched for LevelOne Printer Servers, and a screen like the following
will be displayed.
•If desired, change the Workgroup name and click Refresh.
•Select List all LevelOne Printer Servers to list all LevelOne Printer Servers,
regardless of Workgroup.
•The name of the attached printer will be displayed if possible. If "No printer" is
displayed, check that the printer is properly connected and powered on.
Figure 2: Printer Port Setup (Peer-to-peer Print Driver)

Page 17
If your LevelOne Printer Server is not listed:
•Select "List all LevelOne Printer Servers", and click the "Refresh" button.
•Check that both the LevelOne Printer Server and the printer are properly
connected, and powered on.
•Check that the LevelOne Printer Server has been configured. (Use the Setup
Wizard on the CD-ROM.)
•If using TCP/IP, try installing the NetBEUI protocol. See the earlier section
Checking your Network Protocols for details. Then uninstall and re-install
the Peer-to-peer Print Driver.
6. Select the desired printer port, and then click the "Next" button. A pop-up message will
inform you if the port has been created successfully.
If you see the following error message, either install Internet
Explorer 4 or later, or follow the procedure in the "Trouble
Shooting -Windows" section of Chapter 8.
7. Then a screen like the following will be displayed:
Figure 3: Configure Printer Port
8. Select the correct Windows printer in the Existing Printers list, and click the "Connect"
button.
If the correct printer type is not listed, click "Add New Printer" to run the WindowsAdd
Printer wizard. Step through the Wizard and install the required printer:
•Select the correct Printer Manufacturer and Model, or use the "Have Disk" option if
appropriate.
