LevelOne GSW-0509 User manual


5-Port Gigabit Switch
w/ Internal Power GSW-0509
Gigabit Speeds, the next generation
GSW-0509 is the newest addition to the
LevelOne series of Gigabit switches for the
home and ofce. It transfers all of your les at
blazing fast speeds! This is a great solution for
users that want to maximize bandwidth-hungry
applications with no lag or delay.
Maximize all the triple play service to your
home or ofce and take advantage of fast
broadband access, Internet data, and VoIP to
each connected computer.
All 5-ports follow the IEEE standards of auto-
negotiation and can transmit trafc in half and
full duplex modes.
Internal Power
With a built-in power supply, GSW-0509 is
simple to install and use. No bulky adapters will
hang on the wall and get in the way of your
other electronic devices. Keep your desktop and
computer area free from the clutter of cords!
Save Power with LevelOne Green Technology
Active Link Detection: A LevelOne Green device
can tell if there is activity on each individual
LAN port. If an 8-port switch only has 6 active
devices connected to it, power is saved because
no trafc is routed to the 2 inactive ports.
Cable Length Detection: The switch is able to
detect the distance of the connected device and
adjusts its power accordingly. For example, if
you have a LevelOne Green switch a computer
connected to a 10-meter cable will consume
less power than a computer connected to a
100-meter cable.
Sleep Mode: The device will enter sleep/standby
mode when the connected devices are powered
down and no active links are detected. This
helps save energy consumption during extended
periods of network inactivity, such as nights,
weekends and holidays.
Key Features
- Plug-and-Play no conguration required
- Internal power supply
- Easy installation and maintenance
- Slim and compact design to save space
- Save up to 79% power compare to non Green
Switch with similiar functions
GNC-0105T
Gigabit Ethernet PCI Card
Works well with
1. LEDs
2. 10/100/1000 Mbps
3. Internel power socket
H/W Version: 1
1
USB-0201
USB 2.0 to Gigabit Ethernet
Adapter
2 3

www.level1.com
I
one world_one brand_one level_ Ethernet Switches

Operating Temperature
0°C- 40°C (32°F – 104°F)
Operating Humidity
10% ~ 90% (non-condensing)
Dimensions (L x W x H)
150 x 85 x 25 mm
Power Supply
Internal Power 100-240V AC, 5V/2A
Certication
FCC Class B, CE VCCI
Green Power Consumption
Power Consumption with 5 x 100 meters Cable Connected
3.15W
Power Consumption with 5 x 10 meters Cable Connected
2.5W
GSW-0509 Base Power Consumption
(No Cables are Connected)
0.65W
Non Green Switch Base Power Consumption
(No Cables are Connected)
3.15W
Technical Specications
Standard Compliance
Compliant
IEEE 802.3 , IEEE 802.3u, IEEE 802.3ab and IEEE802.3X
Network Interface
Ports
5 x 10/100/1000 Mbps NWay RJ-45 ports
NWay Protocol Support
10 Mbps: Full/Half duplex
100 Mbps: Full/Half duplex
1000 Mbps: Full duplex only
Buffer Memory
104 Kbytes
MAC Address Database
1,000
Backplane
10 Gbps
Filtering/Forwarding Rate
10 Mbps: 14,880 packets / sec
100 Mbps: 148,800 packets / sec
1000 Mbps: 1488,000 packets / sec
Physical Specications
LED Indicators
System: Power
Port: Link/Act
Product Diagram
Order Information GSW-0509: 5-Port Gigabit Switch w/ Internal Power
Package Contents GSW-0509, Power Cord, User’s Manual
All mentioned brand names are registered trademarks and property of their owners. Technical specications are subject to change without notice.
© Copyright 2009 Digital Data Communications GmbH. All Rights Reserved. V1.0
GSW-0509
Broadband Router Internet
NB PC Print server Printer
Power Saving by
Active
Power Consumption
Power Consumption Inactive
PWR
Active Link Detection
PWR
Cable Length Detection Active
Active
Power Consumption
Power Consumption
20m 40m
20m 40m
60m 80m 100m
PWR
Sleep Mode
Inactive
Inactive
Power Consumption
