Datasheet_GSW-1290
one world_one brand_one level_one world_one brand_one level_
4-port 1000T/mini GBIC + 2 expandable slots L2 SNMP Gigabit Switch
LevelOne’s GSW-1290 is a high-capacity Master stackable SNMP
Layer 2 switch that provides reliable and expandible solutions for
large workgroups or backbones. When combined with MDU-1290M
and MDU-1290T modules for the two expansion slots, this device
acts as a stand alone switch with 12 Gigabit Ethernet ports,
supporting both copper and fibre connections. In addition, with 2
MDU-1290S 4-port stacking modules, this device performs as a
stacking master switch, and up to 12 GSW-2492 switches can be
stacked together in star architecture, providing 9.6Gbps of available
bandwidth and managed using a single IP address as a single
device. The entire switch stack is monitored through network or
console port on the GSW-1290.
The GSW-1290 supports a variety of network management features
including: Console, CLI, Telnet, Web, SNMP v1/v3, RMON, TFTP,
Port Mirroring and DHCP as well as advanced traffic management
options including: 802.1x, bandwidth control and support for IGMP
v1/v2 Snooping. In order to increase network reliablity, the switch
also supports 802.3ad, 802.1d and 802.1w standards.
With its 1U height rack-mountable size, the switch can be easily
managed in a computer lab or a server room. The clearly visible
status LEDs provide easy monitoring of port link activity, speed, and
collision, so that you are never in the dark when it comes to the
status of your data transmissions.
GSW-1290
Key Features
 Back plane up to 24 Gbps
 Master stacking with 12 GSW-2492 switches
in star topology to provide 288 10/100 Mbps
ports
 12-port Gigabit Switch. With 4 built-in
10/100/1000Base-T ports (combo with 4 mini-
GBIC) and 2 expansion slots
 Supports 802.1Q VLAN, GARP/GVRP, and
Asymmetric VLAN.
 Supports Jumbo Frame (Up to 9216 bytes)
 802.1D compatible, 802.1w, 802.1s Spanning
Tree for redundant backup bridge paths
 Supports SNMP management/ MIB
 Supports 802.3ad LACP port trunks
 Supports SNMP v.1, v.3 network management,
4 groups of RMON
 802.1 port-based, MAC-based port access
control
 Web-based management Interface

Datasheet_GSW-1290
one world_one brand_one level_
Technical Specification
 Standards Compliance
IEEE 802.3/ IEEE 802.3u/ IEEE 802.3ab
IEEE 802.3x Flow Control
 Ports
4 x 10/100/1000 Base-T
4 x combo mini GBIC
1 x RS-232 console port
2 x Expansion Slots
 Forwarding Rate
17.8Mpps (max.)
 MAC Address Table
Standalone mode: 16K entries
Stackable mode: 8K entries
 RAM Buffer
1MB
 Jumbo Frame support
9K (Standalone mode)
 VLAN
IEEE 802.1Q Tagged VLAN
Port-based VLAN
GARP/GVRP
 Port Trunk
Trunking mode: static
Operation mode: load sharing
802.3ad LACP support
 Spanning Tree
802.1D/w Spanning Tree Protocol/Rapid spanning Tree
 Management
SNMP v.1, v.3, Web-based Management
MIB II
RMON Group 1,2,3,9
Console Port: DB-9 RS-232 DCE
 LEDs
Per Device: Power, Console, RPS
Per RJ-45 port: Speed, Link/Act
Per SFP port: Link/Act
 Power Input
100~240VAC, 50/60Hz Internal universal power supply
 Power Consumption
30 Watts (max)
 Ventilation
60 x 60 mm DC fans x 1
 Temperature
Operating: 0℃~40℃
Storage: -25℃~55℃
 Humidity
Operating: 0% ~ 95%
 Dimension
440mm(W) * 309mm(D) * 44mm(H)
 EMI and Safety
FCC, CE
Product Diagram
GSW-1290 in Stacking Mode GSW-1290 in Standalone Mode
Ordering Information
 GSW-1290: 4-port 1000T/mini GBIC +2 expandable slots L2 SNMP Master Switch
 GSW-2492: 24-port 10/100TX stacking SNMP Switch
 MDU-1290S: 4-port stacking module for GSW-1290
 MDU-1290M: 4-port mini GBIC module for GSW-1290
 MDU-1290T: 4-port 1000T module for GSW-1290
 GVT-3000: 1000BASE-SX SFP Transceiver
 GVT-3001: 1000BASE-LX SFP Transceiver
 GVT-3002: 1000BASE-ZX SFP Transceiver
