Specifications 3880-DIN
Advanced Home Telephone and Video Panel
Advanced Home Telephone and Video Panel
Part Number
2222–222ndSt.SE • Bothell, WA98021 USA•Tel:[phone] • Fax:[phone]•Int'lFax: 1-425-485-9170 • GSA#GS-35F-4785G
For Applications Engineering Support – Call 1-425-485-4288; in USA call 1-800-824-3005
Spec sheets and updates are also available at www.levitonvoicedata.com.
See ELECTRONIC FILES for CAD files (.DXF, .DWG, MS-DOS.EPS) on disk
47606-AHT
APPLICATION
Leviton’s Advanced Home Telephone and Video Panel combines a
Telephone Line Distribution Module, Category 5e Voice and Data
Board, and a 6-way 2 GHz Video Splitter in a dedicated plastic
bracket for multi-line systems with video distribution. Provides two to
four lines of service to up to 19 connections. Distribute “Line 1”
service to up to 12 different connections; distribute four-line service
to up to eight different connections. Route voice and data services to
up to 6 remote locations via Category 5e Voice & Data modules. Link
with other distribution panels or modules to expand the system.
STANDARDS COMPLIANCE
Meets all applicable standards: cULus Listed; TIA/EIA-568A and FCC
Part 68 compliant.
PHYSICAL SPECIFICATIONS
Materials: Bracket:
ABS plastic, white.
Telephone Line Distribution Module:
Printed circuit board with 19 8P8C jacks for 2- or
4-line distribution, one test port, one auxiliary
disconnect port, one 110-IDC, and an optional
security system punchdown.
Category 5e Voice and Data Board:
Printed circuit board with six Category 5e ports
and six 110-IDCs.
6-way 2 GHz Video Splitter:
Die-cast housing and printed circuit board
construction.
Dimensions: Bracket:
6.13”H x 13.30”W x 2.28”D
Telephone Line Distribution Module:
5.8”H x 3.5”W x .063”D
Category 5e Voice and Data Board:
2.24”H x 6.57”W x 1.96”D
6-way 2 GHz Video Splitter:
3.0”H x 6.58”W x 1.4”D
Insertion Loss: 11.0 dB -14 dB
Return Loss: 11.5 dB - 23.5 dB
Isolation: 35.0 dB - 39.5 dB
WARRANTY INFORMATION
• Two-year limited product warranty.
For ELECTRONIC Typical Specs see (.TXT) file on disk.
DESIGN CONSIDERATIONS
• Fits easily into anyLeviton Structured Media™ enclosure, or
used as a stand-alone unit.
• Determine outlet locations and carefully plan cable routing to
ensure the selected unit satisfies requirements. Additional
modules available separately.
• Isolated RJ-45 jack and punchdown security interface.
• Modular RJ-45 jacks and 4-pair 110-type IDC punchdowns.
• Use provided 8P8C patch cord to link the Telephone Line
Distribution Module to media modules. Use high-speed UTP
cable to route data, phone, fax or modem signals.
For ELECTRONIC Typical Specs see (.TXT) file on disk.
TYPICAL SPECIFICATION
The Advanced Home Telephone and Video Panel shall meet all
applicable standards: cULus Listed; TIA/EIA-568A and FCC Part
68 compliant. The unit shall include a plastic mounting bracket,
Telephone Line Distribution Module, Category 5e Voice and Data
Board, and 6-way 2 GHz Video Splitter. It shall fit into any Leviton
Structured Media enclosure, or be used as a stand-alone unit.
The panel shall feature an RJ-45 port on the Telephone
Distribution Board providing isolated circuitry for a security
system. A two-year limited product warranty shall be provided by
the manufacturer.

G-6057/C1-5M/jc H/2 #889
© 2002 Leviton Manufacturing Co., Inc. All Rights Reserved
Advanced Home Telephone
and Video Panel Part Number
47606-AHT
2222–222ndSt.SE • Bothell, WA98021USA • Tel:[phone]•Fax: [phone]•Int'lFax:1-425-485-9170•GSA# GS-35F-4785G
For Applications Engineering Support – Call 1-425-485-4288; in USA call 1-800-824-3005.
Spec sheets and updates are also available at www.levitonvoicedata.com.
DIMENSIONAL LINE ART
See ELECTRONIC FILES for CAD images
(.DXF, .DWG, MS-DOS.EPS)
PART NUMBERS
12.653 2.010
2.909
6.132 4.000
Description Part No.
Advanced Home Telephone and Video Panel 47603-AHT
Front View Side View
13.30”
4.0”
6.13”
2.28”
2.0”
