BLUETOOTH TRANSMITTER AND
RECEIVER ALL IN ONE
Operating Instructions

2
Controls and Displays
1. Switch for Bluetooth®transmitter/receiver mode
2. Multifunction button
3. Status LED
4. 3.5 mm audio connection (AUX)
5. Micro-USB connection
Thank you for choosing aHama product.
Take your time and read the following instructions and information completely.Please keep these
instructions in asafe place for futurereference. If you sell the device, please pass these operating
instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic hazards
and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
•Bluetooth®transmitter/receiver,2-in-1adapter
•3.5 mm jack cable
•Micro-USB charging/connecting cable
3. Safety Notes
•The product is intended for private, non-commercial use only.
•Protect the product from dirt, moistureand overheating, and only use it in adry environment.
•Donot use the product in the immediate vicinity of heaters or other heat sources or in direct
sunlight.
•Donot allow yourself to be distracted by the product, for example when driving avehicle or
operating sports equipment. Always pay attention to the surrounding trac and your environment.
•Donot drop the product and do not expose it to any major shocks.
•Donot operate the product outside the power limits given in the specications.
•Donot open the device or continue to operate it if it becomes damaged.
•Since the battery is integrated and cannot be removed, you will need to dispose of the product as
awhole. Do this in compliance with the legal requirements.
•Dispose of packaging material immediately according to locally applicable regulations.
•Donot modify the product in any way.Doing so voids the warranty.
G

3
Warning –Rechargeable battery
•Only use suitable charging devices or USB connections for charging.
•Asarule, do not use charging devices or USB connections that aredefective and do not try to
repair them yourself.
•Donot overcharge the product or allow the battery to completely discharge.
•Avoid storing, charging or using batteries in extreme temperatures.
•When stored over along period of time, batteries should be charged regularly (at least every
three months).
4. Getting Started
•The adapter is equipped with arechargeable battery.The battery must be fully charged before
using the device for the rst time.
•Begin charging by connecting the included Micro-USB charging/connecting cable to the adapter’s
Micro-USB connection (5) and to asuitable USB charger.Please refer to the operating instructions
for the USB charger used.
•The adapter’sstatus LED (3) emits aconstant redlight during charging.
•Itcan take up to 2hours to fully charge the battery.
•Charging begins and ends automatically.
5. Operation
5.1. Switching the adapter on/off
•Switching on:
With the device off,press and hold the multifunction button (2) for 3seconds. The status LED (3)
lights up in blue.
•Switching off:
With the device on, press and hold the multifunction button (2) for 3seconds. The status LED (3)
emits two redashes beforethe device turns off.
The rst time the device is turned on, pairing is automatically started –see 5.2 Bluetooth®pairing
in receiver (RX) mode.
5.2. Bluetooth®pairing in receiver (RX) mode
Note –Pairing
•Make surethat your Bluetooth®-capable terminal device is on and Bluetooth®is activated.
•For moreinformation, please refer to the operating instructions of your terminal device.
•Connect your terminal device to the adapter using the included 3.5 mm jack cable and the audio
connection (AUX) (4).
•Select the adapter’sRXmode by moving the switch (1) to the right.
•The adapter and the terminal device should be no further than 1metreapart. The shorter the
distance, the better.
•With the adapter on, press the multifunction button (2) twice. After approximately 3seconds, the
status LED (3) will emit ashes of alternating blue and redlight to indicate the device is in pairing
mode.
•Open the Bluetooth®settings on your terminal device and wait until BTI-020V appears in the list
of Bluetooth®devices found.

4
•Select BTI-020V and wait until the adapter is listed as connected in the Bluetooth®settings on
your terminal device.
Note –Bluetooth®password
Some terminal devices requireapasswordinorder to connect to another Bluetooth®device.
•Ifyour terminal device requests apasswordtoestablish the connection, enter 0000,1234,
1111 or 8888.
Note
•Ifpairing was successful, the status LED (3) lights up in blue.
•You can now use the adapter.
5.3. Bluetooth®pairing in transmitter (TX) mode
Note –Pairing
•Make surethat your Bluetooth®-capable terminal device is on and Bluetooth®is activated.
•For moreinformation, please refer to the operating instructions of your terminal device.
•Connect your terminal device to the adapter using the included 3.5 mm jack cable and the audio
connection (AUX) (4).
•Select the adapter’sTXmode by moving the switch (1) to the left.
•Turn on Bluetooth®on your Bluetooth®headphones/speaker.
•For moreinformation, please refer to the operating instructions of your terminal device.
•The adapter and the Bluetooth®headphones/speaker should be no further than 1metreapart. The
shorter the distance, the better.
•With the adapter on, press the multifunction button (2) twice. After approximately 3seconds, the
status LED (3) will emit ashes of blue light to indicate the device is in pairing mode.
•The connection is now established automatically.
5.4. Automatic Bluetooth®connection (after successful pairing)
Note –Pairing
•Make surethat your Bluetooth®-capable terminal device is on and Bluetooth®is activated.
•For moreinformation, please refer to the operating instructions of your terminal device.
•Make surethat the adapter is on.
•After the devices have been paired once, the connection is then established automatically.
•You can now use the adapter.

5
Note
•Ifpairing was successful, the status LED (3) will be lit blue.
•Itmay be necessary to make settings on your terminal device to enable automatic connection
to the paired adapter.
Note –Connection impaired
After the devices have been paired once, the connection is then established automatically.Ifthe
Bluetooth®connection is not established automatically,check the following:
•Check the Bluetooth®settings of your terminal device to see whether BTI-020V is connected.
•Ifnot, repeat the steps listed in 5.2 Bluetooth®pairing.
•Check whether obstacles areimpairing the range. If so, move the devices closer together.
•The performance can also be affected by aweak battery.
5.5. Pairing in transmitter (TX) mode with two devices at the same time
•Switch on the adapter and your two Bluetooth®-capable audio devices (BT headphones/speaker)
as described in 5.2 Bluetooth®pairing.
•The adapter automatically names the two terminal devices Aand B, and establishes aconnection.
5.6. Deleting the pairing list
•Switch off the adapter in the current mode (TX or RX). After approximately 3seconds, move the
switch (1) to the other mode and switch the adapter on again; this will delete all paired devices
from the list.
5.7. Battery capacity
•The status LED (3) begins ashing redwhen the battery charge is low.
•Charge the adapter as described in 4. Getting started.
6. Care and Maintenance
Only clean this product with aslightly damp, lint-free cloth and do not use aggressive cleaning
agents.

6
9. Technical Data
Bluetooth®version 4.1
Prole A2DP
Range <10m
Battery type Lithium polymer rechargeable battery
Input 240 mA
Charging time Approx. 2h
Battery life of Bluetooth®transmitter Approx. 13 h
Battery life of Bluetooth®receiver Approx. 12 h
