Isolated Signal Converter
LSP-IVC and LSP-IAC

PREFACE..................................................................................................................... 3
Document Revisions .....................................................................................................4
Approvals......................................................................................................................4
1. INTRODUCTION.......................................................................................................5
1.1. General Information .................................................................................... 5
1.2. Support and Services...................................................................................5
1.3. Disposal Remarks........................................................................................5
2. SAFETY INSTRUCTIONS.........................................................................................6
2.1.Symbols....................................................................................................... 6
2.2. Receipt and unpacking.................................................................................6
2.3. Environment................................................................................................ 6
2.4. Mounting......................................................................................................6
2.5. Cleaning ......................................................................................................7
3. DESCRIPTION..........................................................................................................8
4. FEATURES ...............................................................................................................8
5. INSTALLATION AND WIRING ...................................................................................9
5.1. Installation on TS-35 DIN Rail.......................................................................9
5.2. Connections with Screw Terminals...............................................................9
6. SPECIFICATIONS .................................................................................................. 10
7. CONFIGURATION TYPE AND ORDER CODE........................................................ 11
8. DIMENSIONS......................................................................................................... .11
9. TERMINAL DESIGNATION..................................................................................... 12
10. ELECTRICAL DIAGRAMS.....................................................................................13
11. APPLICATIONS..................................................................................................... 15
12. OPERATION AND MAINTENANCE......................................................................16
12.1. Operation................................................................................................. 16
12.2. Maintenance ............................................................................................16
13. WARRANTY DISCLAIMER .................................................................................. 16
14. CONTACT INFORMATION ....................................................................................17
Table of Contents

3
PREFACE
Thank you for selecting our product!
This User Manual contains information needed for proper installation, operation, and
maintenance of your product. A thorough understanding of these simple instructions will
help you get the most of your product.
This document should be read thoroughly, and the safety instructions described in this
manual should be followed carefully. If you have questions or concerns about the
operation and maintenance of this product, please contact our customer support.
If a problem arise with the product, check if you followed the installation steps
correctly. If the problem persists, contact an authorized Levtech dealer or our customer
support.
All information in this User Manual is based on the latest product information available at
the time of printing approval. Levtech reserves the right to make changes at any time
without notice and without incurring any obligation.
Please always keep this manual together with the isolator as a reference to everyone
who uses this product.

4
Approvals
This document requires following approvals:
Date Version Number Document Changes
11-03-2021 1.0 Initial draft
13-04-2021 2.0 Overall improvements
15-04-2021 3.0 Application examples added
Name Title
Levi Mihaly General Manager
Document Revisions
13-05-2021 4.0 Wiring diagram added

5
1.1.
General Information
1.2. Support and Services
1.3. Disposal Remarks
Lueta Nr. 319, Romania
[phone]
offi[email protected]o
www.levtech.ro
1.
INTRODUCTION
This manual is the designated User Manual for the installation, safe operation, and
maintenance of your product. It is divided into nine chapters covering general
information, safety instructions, how to safely install and operate the product,
maintenance, warranty, and contact information.
All personnel involved in the installation, operation, and maintenance of this equipment
should read and understand this manual, particularly its safety instructions. Substandard
performance and longevity, property damage, and personal injury may result from not
knowing and following these instructions.
In order to ensure long product life, Levtech recommends that you utilize the product and
perform maintenance by correctly following the instructions described in this guide. The
manufacturer’s warranty does not cover any damage resulting from the neglect of these
instructions.
Levtech assumes no liability for damage caused by operation contrary to what is
specified in this operating manual.
For information about further questions that are not answer in this manual, additional
materials, and support, please contact:
DO NOT dispose of the product with domestic waste!
Electronic devices have to be disposed of according to the regional directives on
electronic and electric waste disposal. In case of further questions, please consult your
supplier. The supplier may take care of proper disposal.

6
2.2. Receipt and unpacking
2.3. Environment
2.4. Mounting
2.
2.1. Symbols
WARNING
CAUTION
NOTICE
This symbol indicates information that, if ignored, could result possibly in
personal injury or even death due to incorrect handling.
This symbol indicates information that, if ignored, could possibly result in
personal injury or physical damage due to incorrect handling.
Indicates information considered important, but not hazard-related.
Unpack the device without damaging it and check whether the device type corresponds
to the one ordered. The packing should always follow the device until this has been
permanently mounted.
Avoid direct sunlight, dust, high temperatures, mechanical vibrations and shock, and rain
and heavy moisture.
Only technicians who are familiar with the technical terms, warnings, and
instructions in the manual and who are able to follow these should connect the
device.
Mounting and connection of the device should comply with national legislation for
mounting of electric materials, i.e. wire cross section, protective fuse, and location.
Descriptions of input / output and supply connections are shown in this installation
guide and on the side label.
Use this device only in accordance with this instruction manual, as well as all
applicable local and national laws and regulations. Only allow this device to be
installed, operated, maintained, repaired, etc. by others who have also read and
understood the user manual.
Do not allow minors, untrained personnel, or personnel suffering from physical or
mental impairment that would affect their ability to follow this manual to install,
operate, maintain, or repair this device.
Any untrained personnel who might be near the device while it is in operation
MUST be informed that it is dangerous and fully instructed on how to avoid injury
during its use.
SAFETY INSTRUCTIONS

7
WARNING
CAUTION
2.5. Cleaning
WARNING
To avoid the risk of electric shock and fire, the safety instructions of this guide
must be observed and the guidelines followed.
When disconnected, the device may be cleaned with a cloth moistened with distilled
water.
The specifications must not be exceeded, and the device must only be applied
as described in the following.
Do not use the device near water or moisture.
Do not install near any heat sources such as radiators, stoves or other heaters
that produce heat.
To prevent ignition of the explosive atmospheres, disconnect power before
servicing and do not separate connectors when energized and an explosive
gas mixture is present.
Do not mount or remove devices from the power rail when an explosive gas
mixture is present.
Before the commissioning of the device, this installation guide must be
examined carefully, and only qualified personnel (technicians) should install
this device.
If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
To avoid the risk of explosion due to electrostatic charging of the enclosure, do
not handle the units unless the area is known to be safe, or appropriate safety
measures are taken to avoid electrostatic discharge.

8
The signal converter is used in cases where the measurement device or transmitter
analog signal type is not corresponding to the input of the processing unit. For example,
you have a conductivity transmitter with 4-20mA output, but you have a PLC with only
analog 0-10V signal input. Using this converter the 4-20mA signal is converted to 0-10V
analog signal and it is cheaper then buying an analog input module for the PLC. Plus it is
a 3 point galvanic isolator itself, which makes 3500VDC isolation between the input,
output and power supply. The models can have voltage input and current output or
current input and voltage output each type has a specific order code.
Three way isolated
3500VDC isolation
TS-35 DIN rail mounting
+/-0.1% accuracy
Ip40 case
Screw terminals
Power LED
Supply voltage 24VDC
Made in EU
3. DESCRIPTION
4. FEATURES

5.2. Connections with Screw Terminals
5.1. Installation on TS-35 DIN Rail
Inserting the Module in the Rail:
Removing the Module in the Rail:
5. INSTALLATION AND WIRING
The module is designed to be installed, in a vertical position, on TS-35 DIN rail. For the
best module performance and duration, avoid placing objects that could obstruct the
ventilation. Never install the modules near heat sources.
1) Attach the module in the lower part of the rail, as shown in the left figure below.
2) Press the module upwards.
1) Apply leverage using a screwdriver, as shown in the right figure below.
2) Press the module downwards.
9
The module has been designed for screw-type terminal electrical connections. Proceed
as follows to make the connections:
1) Strip the cables by 8mm.
2) Insert a screwdriver in hole, unscrewing the screw.
3) Insert the cable in the round hole.
4) Again, use the screwdriver to tight the screw.
5) Remove the screwdriver and make sure that the cable is tightly fastened in the
terminal.
0,2...2,5 mm²
8 mm

10
6. SPECIFICATIONS
Voltage Input
Input Signal Direct Voltage
Input Range 0-10V or 0-5V
Input Resistance 10KΩ
Current Output
Output Signal Direct Current
Output Range 0(4)-20mA on current loop
Output Resistance <500 Ω
Power Supply
Supply Voltage 16 ~ 30VDC
Power Consumption <58mA
Reverse-Polarity Protection Yes
Enclosure
IP Rating IP40
Dimensions (L x D x H) 114 x 99 x 12.5 mm
Weight 82g (approx.)
Mounting TS-35 DIN
Maximum Cable Cross-Section 2.5mm2 (max.)
Enviromental Conditions
Ambient Temperature Range - 10 ~ +60ºC
Storage Temperature Range - 30 ~ +80ºC
Humidity Level 0 ~ 95% RH at 40ºC, no condensation
Current Input
Input Signal Direct Current
Input Range 0(4)-20mA
Input Resistance 500Ω
Voltage Output
Output Signal Direct Voltage
Output Range
>1K Ω
Output Resistance
Number of outputs
Number of inputs 1
1
General
Output accuracy 0.10%
Limit frequency Voltage type 100Hz
Response time 0.8ms
Isolation Voltage
3500VPEAK
Linearity error 0.10%
Number of outputs
Number of inputs 1
1
400 VRMS
Working isolation voltage
Limit frequency Current type 1kHz
0-10V or 0-5V

11
Order Code Input Output
Among the models available for this product, Levtech offers options that feature voltage
input and current output or current input and voltage output. The voltages range from 0-
5V and 0-10V, while the current options are 0-20mA and 4-20mA models. The LSP- IAC
models have current input and the LSP-IVC have voltage input. The following table
shows the ordering codes for each model.
7. CONFIGURATION TYPE AND ORDER CODE
99.0 mm
114.0 mm
12
34
56
78
12.5
mm
8. DIMENSIONS
LSP-IVC-1020
LSP-IVC-1042
LSP-IVC-0520
LSP-IVC-0542
LSP-IAC-2010
LSP-IAC-2005
LSP-IAC-4210
LSP-IAC-4205
LSP-IAC-4202
LSP-IAC-0242
0-10V
0-10V
0-5V
0-5V
0-20mA
0-20mA
4-20mA
4-20mA
4-20mA
0-20mA
0-20mA
4-20mA
0-20mA
4-20mA
0-10V
0-5V
0-10V
0-5V
0-20mA
4-20mA

12
9. TERMINAL DESIGNATION
1. Negative Signal Input;
2. Positive Signal Input;
3. Negative Input of the Power Supply;
4. Positive Input of the Power Supply;
5. Negative Signal Output1;
6. Positive Signal Output1;
7. Negative Signal Output2;
8. Positive Signal Output2.
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
0-10 V mA
4-20mA
7
8
+24VDC
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
0-5 V mA
4-20mA
7
8
+24VDC
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
0-10 V mA
0-20mA
7
8
+24VDC
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
0-5 V mA
0-20mA
7
8
+24VDC
LSP-IVC-1020
LSP-IVC-1042
LSP-IVC-0520
LSP-IVC-0542
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
V
0-10 V
7
8
0-20mA
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
V
0-5 V
7
8
0-20mA
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
V
0-10 V
7
8
4-20mA
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
V
0-5 V
7
8
4-20mA
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
4-20mA mA
0-20mA
7
8
+24VDC
IN OUT
34
24VDC
+
-
+
-
+
-
1
2
PS
0-20mA mA
4-20mA
7
8
+24VDC
LSP-IAC-2010
LSP-IAC-2005
LSP-IAC-4210
LSP-IAC-4205
LSP-IVC-4202 LSP-IVC-0242

13
This model features a current input and a voltage output. The input signal will be
converted into voltage, which are isolated from each other and from the input signal.
Check section 6 (“Configuration Type and Order Code“) to see the available options.
This models features a voltage input and a current output. The input signal will be
converted into current, which are isolated from each other and from the input signal.
Check section 6 (“Configuration Type and Order Code“) to see the available options.
Z
Min 1K
0.20mA
24V
Rs
Isolation
15-30V
0-20mA
Rs = 500 oHm
18V
5V
0-10V
U48-1
LSP_20mA/10V
8
+OUT2
7
-OUT 2
1
- IN
2
+ IN
3
-U
4
+U
Rs
Isolation 2
Rs = 10k
0-10V
0-20mA
2
+ IN
6
+OUT2
4
+U
1
- IN
5
-OUT 2
3
-U
0-10V Z2
0 - 500 oHm
24V
24V
15-30V
18V
5V
LSP-IVC
LSP-IAC
10. ELECTRICAL DIAGRAMS

14
The figure below shown an example of a connection of our isolated converter with a 0-
20mA input and 0-10V output connected to PLC. The connected sensor is loop powered.
-
+
RUN/STOP
U39
LOGO_AM2
L+
M
L+
M
I1 M1 U1 I2 M2 U2
12
3 4
56
78
+U 0 +U 1
GND0 GND1
0-20mA (4-20mA)
0-10 V
GND1
LSP-IAC-2010 Wiring Example:
LSP-IAC-2010
-
+
12
3 4
56
78
RUN/STOP
U31
LOGO_AM2
L+
M
L+
M
I1 M1 U1 I2 M2 U2
+U 0 +U 1
GND0 GND1
0 - 10V
4-20mA
Field device
with active 0-
10V output
The figure below shown an example of a connection of our isolated converter with a 0-
10V input and 4-20mA output on current loop connected to PLC.
LSP-IVC-1042 Wiring Example:
Loop powered field
device with 0-20mA or
4-20mA output

15
Example 1:
This device can be used for several applications on industrial automation. It is ideal for
removing errors caused by noise and signal interference, protecting sensitive equipment
such as a PLC from potential hazards, and converting analog signals.The models can
have voltage input and current output or current input and voltage output.
Suppose that you have a temperature sensor that operate in a 4-20mA current loop and
you need to record the temperature in a PLC that allows input voltages from 0-10V.
Therefore, you could use one of this isolated converter splitter to isolate the input signal
and provide two isolated output signals.
11. APPLICATIONS

16
13. WARRANTY DISCLAIMER
12. OPERATION AND MAINTENANCE
12.1. Operation
12.2. Maintenance
This isolator requires no user adjustments during commissioning. It comes with
factory calibration ready for use.
If the isolator fails to operate, check for bad connections. In the unlikely event of the
isolator not working, it should be returned to the supplier for repair or replacement.
Levtech suggests a quick check for terminal tightness and general unit condition. Always
adhere to any site requirements for programmed maintenance.
Levtech warrants this product to be free from significant deviations in material and
workmanship for a period of 3 year from date of purchase. If repair or adjustment is
necessary and has not been the result of abuse or misuse, within the 3 year period,
please return-freight-prepaid and the correction of the defect will be made free of
charge. If you purchased the item from our distributors and it is under warranty,
please contact them to notify us of the situation. Levtech Service Department will
determine if the product problem is due to deviations or customer misuse.
Out-of-warranty products will be repaired on a charge basis.
Authorization must be obtained from one of our representatives before returning items
for any reason. When applying for authorization, have the model and serial number
handy, including data regarding the reason for return. For your protection, items must
be carefully packed to prevent damage in shipment and insured against possible
damage or loss.
Levtech will not be responsible for damage resulting from careless or insufficient
packing. A fee will be charged on all authorized returns.
Levtech reserves the right to make improvements in design, construction and
appearance of our products without notice on which the buyer could reasonably have
discovered the alleged defect or breach.
13.1. Return of items

17
WEBSITE
https://www.levtech.ro/
SOCIAL MEDIA
Levtech
COMPANY DATA
@levtech_s_p
@levtechsp
14. CONTACT INFORMATION
ADDRESS
Lueta Nr. 319
Post Code 537140
Harghita
Romania
LEVTECH SERVICE & PRODUCTION SRL
Fiscal code (CIF): RO35733217
Trade Register: RC J19/134/2016
IBAN: RO39RNCB0152150349440001
BCR BANK
