Lewmar Axis 2022108804 Installation instructions

Table of Contents
Introduction ������������������������������������������ 2
Safety ������������������������������������������������� 2
Parts List ���������������������������������������������� 3
Resources Required ��������������������������������� 3
Installation �������������������������������������������� 3
Determine Transom Mounting Location ������������� 3
Mounting the Anchor �������������������������������� 4
Optional Anchor Mounting ��������������������������� 4
Mounting the RF Module ���������������������������� 5
Programming the RF Module ������������������������ 5
Operation ��������������������������������������������� 6
Troubleshooting �������������������������������������� 7
Maintenance ������������������������������������������ 8
Manual Override ������������������������������������� 9
Warranty Coverage - Components ���������������� 10
RF Module Mounting Template ��������������������� 11
Lewmar Axis Shallow Water Anchor KitsLewmar Axis Shallow Water Anchor Kits
Part #Part # DescriptionDescription
2022108804 Lewmar Axis Shallow Water Anchor - White
2022108805 Lewmar Axis Shallow Water Anchor - Black
Lewmar® Axis
(Shallow Water
Anchor)
Installation and
Owner’s Manual
(For Aftermarket Applications)
™

2
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
Introduction
Thank you for choosing Lewmar®� Lewmar products are
world renowned for their quality, technical innovation and
proven performance� With a Lewmar product you will be
provided with many years of outstanding service�
Operating your new Lewmar Axis™Shallow Water Anchor
is as simple as pushing a button on the remote control or
the switch on the RF module�
Additional information about this product can be obtained
from lci1�com/support or by using the LippertNOW app�
Replacement kits can be ordered from https://store�lci1�
com/ or by using the LippertNOW app�
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™
for Android™users�
App Store®and iPad®are registered trademarks of
Apple Inc�
Google Play™and Android™are trademarks of
Google Inc�
Safety
Read and fully understand all instructions before
installing or operating this product� Adhere to all safety
labels�
This manual provides general instructions� Many
variables can change the circumstances of the
instructions, i�e�, the degree of difficulty, operation and
ability of the individual performing the instructions� This
manual cannot begin to plot out instructions for every
possibility, but provides the general instructions, as
necessary, for effectively interfacing with the device,
product or system� Failure to correctly follow the provided
instructions may result in death, serious personal injury,
severe product and/or property damage, including
voiding of the Lippert limited warranty�
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
AN INSTALLATION PROCEDURE HAS A SAFETY
RISK INVOLVED AND MAY CAUSE DEATH,
SERIOUS PERSONAL INJURY, SEVERE PRODUCT
AND/OR PROPERTY DAMAGE, INCLUDING
VOIDING OF THE COMPONENT WARRANTY, IF
NOT PERFORMED SAFELY AND WITHIN THE
PARAMETERS SET FORTH IN THIS MANUAL.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A PROCEDURE HAS A SAFETY RISK INVOLVED
AND MAY CAUSE PERSONAL INJURY, PRODUCT
AND/OR PROPERTY DAMAGE IF NOT PERFORMED
SAFELY AND WITHIN THE PARAMETERS SET
FORTH IN THIS MANUAL.
• DO NOT ALLOW CHILDREN TO OPERATE OR
TAMPER WITH THE AXIS SHALLOW WATER
ANCHOR UNSUPERVISED.
• KEEP HANDS AWAY FROM MOVING ANCHOR
PARTS.
• ALWAYS MAINTAIN A SAFE DISTANCE BETWEEN
THE ANCHOR AND YOUR EXTREMITIES. AVOID
WEARING LOOSE CLOTHING WITHIN CLOSE
PROXIMITY OF THE ANCHOR; FAILURE TO DO SO
MAY RESULT IN BODILY INJURY.
• ALWAYS DISCONNECT THE 12 VOLT POWER
SOURCE FROM THE ANCHOR BEFORE SERVICING.
• KEEP CLEAR OF ANCHOR WHILE EXTENDING AND
RETRACTING.
• KEEP ANCHOR CLEAR OF OBSTRUCTIONS.
• DO NOT PERFORM INSTALLATION WHILE BOAT IS
IN WATER.
• DO NOT OPERATE BOAT (PUT UNDERWAY) UNTIL
THE ANCHOR IS FULLY RETRACTED.
• DO NOT USE YOUR AXIS SHALLOW WATER
ANCHOR AS A FORM OF ASSISTANCE FOR
ENTERING OR EXITING THE VESSEL.
ALWAYS WEAR APPROPRIATE PERSONAL
PROTECTION EQUIPMENT (PPE) WHEN
PERFORMING SERVICE, MAINTENANCE OR
INSTALLATION PROCEDURES.
MOVING PARTS CAN PINCH, CUT OR CRUSH.
KEEP CLEAR AND USE CAUTION.

3
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
LetterLetter PNPN DescriptionDescription QtyQty
A2022108804 Lewmar Axis Anchor - White 1
2022108805 Lewmar Axis Anchor - Black 1
B N/A Washer, 3/8” x 1 1/2” O�D�, SS 4
C N/A Washer, 3/8” x 1” O�D�, SS 4
D N/A Nut, 3/8”, Locking, Brass 4
E N/A Screw, 3/8” x 3”, Hex HD, SS 4
F N/A Screw, #6 x 3/4”, SLFTP, SS 4
G N/A Hex wrench, 7/32” 2
Parts List
NOTE: Part numbers are shown for identification
purposes only� Not all parts are available for individual
sale� All parts with a link to the Lippert Store can
be purchased�
Resources Required
• 1-2 people, depending
on task
• ⁄” wrench
• ⁄” socket with ratchet
• #2 Phillips drive bit or
screwdriver
• Flat head screwdriver
• Cordless or electric drill or
screw gun
• ⁄”, ⁄” and ½” drill bits
• Wire cutter/stripper/crimper
• Heat shrink connectors
• Tape measure
• 4-ft straight edge
• Utility knife
• Heat gun
• Marine grade sealant
(3M 5200 or similar)
• Non-permanent marker
Installation
NOTE: Lippert recommends the installers be able to
lift 35-50 lbs and have an intermediate skill level of
mechanical and electrical aptitudes�
Determine Transom Mounting Location
1. Cover the intended mounting area with masking tape
to prevent scratches and gel-coat chipping when drilling
the mounting holes later�
2. The lowest point of the anchor must be mounted
above the water line to prevent adverse handling of the
vessel (Fig.1)�
NOTE: If the vessel has trim tabs, make sure there is
no interference between the tabs and the anchor before
continuing with installation�
Fig.1
3. With the anchor placed in its desired location, operate
the outboard motor through the entirety of its turning and
trim range to conrm there is no interference with it and
the anchor�
4. If there is no interference with any of the vessel’s
exterior components, make sure there is enough room
within the vessel’s interior location around the transom to
accommodate tightening of the mounting hardware�
A
D
B
C
F
G
E
water line

4
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
Mounting the Anchor
1. With the help of another person, place the Axis
Shallow Water Anchor stern mounting bracket against
the transom and mark the location of the four mounting
holes (Fig.2A) with a non-permanent marker�
2. Use an ⁄” drill bit to drill four pilot through-holes where
previously marked (step 1) (Fig.2A) on the transom�
3. Set the Axis Shallow Water Anchor aside�
4. Use a ⁄” drill bit to drill through the four previously
drilled pilot holes (step 2) to open them up�
PARTIAL OR SURFACE-MOUNTING OF THE AXIS
SHALLOW WATER ANCHOR CAN COME LOOSE OR
BREAK FREE FROM THE TRANSOM, RESULTING
IN POSSIBLE SEVERE PRODUCT AND/OR
PROPERTY DAMAGE, INCLUDING VOIDING OF THE
COMPONENT WARRANTY, SERIOUS PERSONAL
INJURY OR DEATH. THE AXIS SHALLOW WATER
ANCHOR MUST BE SECURELY BOLTED THROUGH
THE TRANSOM.
5. Apply a generous amount of marine grade sealant
(3M 5200 or similar):
A. On the mating surfaces of the stern mounting bracket
and hull�
Fig.2
B. All around the ⁄” stern bracket’s mounting holes�
Make sure to seal the drilled holes toward the inside of
the vessel�
6. With the help of another person, retrieve the Axis
Shallow Water Anchor and align it’s stern bracket holes
with the transom holes�
A. Install one ⁄” x 1” O�D� washer (Fig.3A) onto each of
the four ⁄”-16 x 3” hex head screws (Fig.3B) then insert
from the outside of the vessel the assembled hardware
through the previously (step 4) drilled holes in the
transom and through the anchor’s mounting bracket�
NOTE: Proper mounting bracket installation will have
each screw hex head facing outside the vessel and
the lock nuts facing inward from the inside surface of
the transom�
B. Install one ⁄” x 1 ½” O�D� washer (Fig.3C) over each
of the four screws (Fig.3B) followed by threading on a ⁄”-
16 brass lock nut (Fig.3D)� Hand-tighten the nuts to hold
the Axis Shallow Water Anchor in-place�
Fig.3
A A
C. For each installed screw (Fig.3B), hold in-place with
a ⁄” wrench to keep it from turning, while tightening
the lock nut (Fig.3D) with a ⁄” socket and ratcheting
wrench� Holding the hex head screw and tightening the
lock nut onto it prevents damage to the powder coat of
the Axis system�
Optional Anchor Mounting
In addition to transom mounting, Lippert offers several
optional mounts, such as jack plate, engine, dovetail,
pontoon and universal mounts�
D
C
A B

5
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
If installed, the optional quick-detach dovetail bracket is
mounted in the same way as the standard stern mounting
bracket procedure with the only exception being the
bolts� The quick-detach dovetail bracket uses four ⁄”-16
x 3 ½” flat head countersunk bolts instead of the hex
head style�
NOTE: The quick-detach bracket mounting hole locations
are identical to the standard stern mounting bracket hole
locations, so no new holes are required when upgrading�
Mounting the RF Module
1. Place the RF (radio frequency) module box (Fig.4) in
close proximity to the vessel’s power source�
2. Hold the RF module in-place and, using a non-
permanent marker, draw an outline of the box�
3. Using the provided mounting template, it is
recommended to pre-drill the four holes for the #6
mounting screws�
A. Cut out the provided RF module mounting
template (Fig.10)�
B. Place the template over the previously marked RF
module box outline (step 2) and secure it in-place; e�g�,
tape, tacks�
C. Using a drill with an ⁄” drill bit, drill four holes (Fig.10)
where indicated on the template�
4. Secure the RF module box in-place with the four
provided #6 x ¾” screws�
Fig.4
A
B
C
5. Using the appropriate heat shrink connectors (NOT
supplied), connect the short black lead (Fig.4A) to -12V
source and the short red lead (Fig.4B) to +12V source�
NOTE: Lippert recommends that the two power leads be
connected to a battery switch since the RF module will
draw a small amount of power when not in use�
6. Plug the longer black lead (Fig.4C), congured with a
quick connect Deutsch Plug, into the receiving plug on
the Axis Shallow Water Anchor�
Programming the RF Module
Determine if momentary or latching functionality
is preferred�
NOTE: The transmitter and receiver can be configured
for momentary or latching operation�
For momentary functionality:
• Receiver output remains active as long as the
transmitter switch is depressed�
• Receiver output turns off when the transmitter switch
is released�
For latching functionality:
• Receiver output becomes active as soon as the
transmitter switch is depressed and released�
• Receiver output turns off when the transmitter switch is
depressed and released again�
Turn on power to the RF module�
1. Remove the four screws (Fig.4A) from the RF Module�
2. Set screws aside for later use�
3. Remove the RF Module lid�
4. Locate the PROGRAM pushbutton switch (Fig.5A) on
the receiver�
ALL ELECTRICAL WIRING HARNESSES SHALL BE
LOOMED AND SECURED TO PREVENT POSSIBLE
DAMAGE AND INSTALLED IN ACCORDANCE
WITH THE LATEST ABYC (AMERICAN BOAT AND
YACHT COUNCIL) ELECTRICAL STANDARDS,
E11 A ND S31.

6
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
Operation
Operation of the Axis Shallow Water Anchor can
be by the remote control or the RF module’s hard
mounted switch�
IF THE AXIS SHALLOW WATER ANCHOR IS NOT
FULLY RETRACTED AND PROPERLY STOWED
BEFORE PUTTING UNDERWAY, TRAILERING
OR TRAVELING, PRODUCT AND/OR PROPERTY
DAMAGE MAY OCCUR. MAKE SURE THE AXIS
SHALLOW WATER ANCHOR IS IN THE STOWED
(FULLY UPRIGHT) POSITION BEFORE PUTTING
UNDERWAY, TRAILERING OR TRAVELING.
LEAVING THE BOAT UNATTENDED WHILE ONLY
SECURED BY THE AXIS SHALLOW WATER
ANCHOR MAY RESULT IN PRODUCT AND/OR
PROPERTY DAMAGE. NEVER LEAVE THE BOAT
UNATTENDED WITH THE AXIS SHALLOW WATER
ANCHOR AS THE PRIMARY ANCHORAGE.
To extend and lower the anchor:
1. If in momentary mode, depress the “down” switch
until the anchor spike makes su󰀩cient contact with the
waterway’s bed�
2. If in latching mode, press the button and the anchor
will deploy until the system senses su󰀩cient spike
engagement with the waterway’s bed�
To raise and retract the anchor:
1. If in momentary mode, depress the “up” switch until
the anchor spike is raised from the waterway’s bed and is
fully retracted�
2. If in latching mode, press the same button as before
and the anchor will automatically raise up from the
waterway’s bed and fully retract�
Fig.5
B
A
long-range
antenna jack
auxiliary
switch
leads
5. Press and hold the PROGRAM switch until the red
LED (Fig.5B) illuminates (approximately three seconds)�
The receiver is now in the transmitter program mode�
WHEN USING IN LATCHING MODE, THE
ANCHOR AUTOMATICALLY SENSES WHEN IT
REACHES SUFFICIENT CONTACT WITH THE
SEAFLOOR OR REACHES FULL EXTRACTION.
THIS SENSING MOMENTARILY CUTS POWER
TO THE MOTOR TO PREVENT DAMAGE. THERE
WILL APPROXIMATELY BE A 5-SECONND DELAY
BEFORE THE SYSTEM WILL RESPOND TO
ANOTHER INPUT FROM THE REMOTE.
6. Release the PROGRAM switch�
At this point, all previously programmed transmitter
addresses are erased from the receiver’s memory�
Programming for Momentary Functionality
1. Press and release a switch on the transmitter�
2. The red program LED on the receiver will blink once�
Programming for Latching Functionality
1. Press and release the same switch a second time�
2. The program LED will ash on and o󰀨.
3. Repeat previous step 1 for additional transmitters that
the receiver needs to respond to�
NOTE: The receiver will return to normal mode if no
transmitter switches are pressed for five seconds�
4. The red LED on the receiver will ash and then
turn o󰀨.
5. Reinstall the previously removed (steps 1-3 in the
Programming the RF Module section) lid�
RF Module programing is now complete and the receiver
is now in normal mode of operation� The receiver
will retain all of its programming even when power
is removed�

7
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
Troubleshooting
What is happening?What is happening? Why?Why? What should be done?What should be done?
Anchor does not
extend/lower�
Bad electrical
connection�
Make sure the Deutsch plug from the RF Module is fully
engaged and secured at the anchor’s plug�
Check for loose electrical connections at the power source
and at all heat shrink and switch connections� Tighten all loose
connections and/or repair connections as necessary�
No power�
Make sure the Deutsch plug from the RF Module is fully
engaged and secured at the anchor’s plug�
Check for disconnected and/or cut wires� Reconnect and/or
repair/replace wires as necessary�
Check electrical connections to the vessel’s power source� Make
sure power and ground connections to the power source are
installed correctly and made secure�
Check the vessel’s power source for voltage level� Fully charge
or replace power source as necessary�
Replace battery in RF remote control�
Dry pivot bushings� Lubricate all pivot bushings with spray Lithium grease�
Debris caught
around the anchor�
Disconnect the 12 Volt power source� Remove all debris�
Reconnect power source�
Electronic motor
failure�
Replace electronic motor� Call Lippert Customer Care Center�
DEBRIS CAUGHT AROUND THE AXIS SHALLOW
WATER ANCHOR CAN AFFECT PROPER PRODUCT
OPERATION. DO NOT CLEAR DEBRIS FROM
THE AXIS SHALLOW WATER ANCHOR WITHOUT
DISCONNECTING THE 12 VOLT POWER SOURCE
OR PERSONAL INJURY MAY OCCUR. DISCONNECT
THE 12 VOLT POWER SOURCE PRIOR TO
REMOVING ANY OBSTRUCTIONS FROM THE AXIS
SHALLOW WATER ANCHOR.

8
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
• Inspect all electrical connections to ensure that
they are secure and free of corrosion every three
months�
• Inspect all fasteners for proper tightness after
every 100 cycles to ensure that the anchor is in
safe working condition� Tighten loose fasteners
as necessary� Replace damaged fasteners and/or
bushings immediately�
Maintenance
USE OF NON-GENUINE AXIS SHALLOW
WATER ANCHOR ACCESSORIES MAY RESULT
IN PRODUCT AND/OR PROPERTY DAMAGE,
INCLUDING VOIDING OF THE COMPONENT
WARRANTY. ONLY USE GENUINE AXIS SHALLOW
WATER ANCHOR ACCESSORIES.
Fig.6
• Thoroughly rinse all moving parts with fresh water
after each use�
• Lubricate the bushings at both the mounting
bracket and knuckle hinge points (Fig.6A) every six
months with spray lithium grease�
• Check battery power level before boating� Battery
should be maintained at maximum level� The Axis
Shallow Water Anchor draws power from the vessel’s
power source during operation� The average life of a 12
Volt battery with 55 cold cranking amps is 400 cycles
per charge� Charge or replace battery as necessary�
• Although the amperage draw on the vessel’s battery is
negligible, power-off the RF Module via a battery switch
when the vessel is stored�
A

9
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
Manual Override
In the event there is a loss of power to the anchor
preventing it from extending or retracting, do as follows:
1. Disconnect the axis anchor Deutsch Plug from the
boat’s mating connector�
2. Locate the actuator dowel found at the actuator
linkage point (Fig.7A)�
3. Using the two provided ⁄” hex wrenches (Fig.8A),
remove the two ⁄” button head screws (Fig.8B) securing
the actuator dowel�
NOTE: Depending on the extension state of the system,
the same steps may be required for the upper actuator
dowel as well�
4. Manually retract the anchor�
IF THE AXIS SHALLOW WATER ANCHOR IS NOT
FULLY RETRACTED AND PROPERLY STOWED
BEFORE PUTTING UNDERWAY, TRAILERING
OR TRAVELING, PRODUCT AND/OR PROPERTY
DAMAGE MAY OCCUR. MAKE SURE THE AXIS
SHALLOW WATER ANCHOR IS IN THE STOWED
(FULLY UPRIGHT) POSITION BEFORE PUTTING
UNDERWAY, TRAILERING OR TRAVELING.
Fig.7
Fig.8
5. Using straps or some other type of cordage, rmly
secure the anchor in its upright, stored position (Fig.9)
before going underway�
Fig.9
A
retracted
anchor
B
A

10
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
Warranty Coverage - Components
The following table lists component-specific warranty information�
All listed component warranty coverage times are from date of the item’s purchase�
Component WarrantyComponent Warranty Coverage
ComponentComponent Coverage and Period
Spike Lifetime warranty
Powder Coat Six months against cracking, chipping and fading�
Linkage Arms, Mounting
Bracket and Knuckle
60 months
Spike Holder and Bushing
Hardware
12 months
Remote and RF Module 12 months
IMPORTANT NOTE:
Please retain this label.
There is another matching label on the anchor itself.
The serial number on the label will be required for all warranty claims.

11
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
Lewmar®Axis™
(Shallow Water
Anchor)
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006345
RF Module Mounting Template

2.35”
4.05”
0.25” dia.
4X



Fig.10
NOTE: Template outline and mounting holes are to scale
when the page is printed full scale (A4)� Dimensions are for
reference only�

12
lippert�com 432-LIPPERT (432-547-7378) Rev: 06�06�23
CCD-0006345
Lewmar®is a wholly owned subsidiary of Lippert Components, Inc� (Lippert)
Havant Plant No. 404
• Lewmar, Southmoor Lane, Havant, P09 1JJ, United Kingdom
• T: [phone]
• Email: techsupport@lewmar�com
For Patent Info: www�Lippert�com/patents
Lewmar�com
The contents of this manual are proprietary and copyright protected by Lippert� Lippert prohibits the copying or
dissemination of portions of this manual unless prior written consent from an authorized Lippert representative has
been provided� Any unauthorized use shall void any applicable warranty� The information contained in this manual is
subject to change without notice and at the sole discretion of Lippert� Revised editions are available for free download
from lippert�com�
Please recycle all obsolete materials�
For all concerns or questions, please contact Lippert�
Ph: 432-LIPPERT (432-547-7378) | Web: lippert�com | Email: customerservice@lci1�com
