Lex System 2I640DW User manual

2I640DW
Intel Elkhart Lake ATOM® x6413E / J6412 SoC CPU,
DDR4 SODIMM,
3 x LAN / HDMI / USB / COM / M.2
All-In-One
Intel Elkhart Lake ATOM® x6413E / J6412 SoC CPU
2 x HDMI, eDP, 2 x M.2, 3 x LAN, 1 x Nano SIM
USB, COM, Wide Range DC-IN 9~24V
NO. 2I640DW
Release date: JUNE. 10. 2022
RISK OF EXPLOSION IF BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS
CAUTION

i
2I640DW
Warning!...........................................................................................................................
Hardware Notice Guide .............................................................................................
CHAPTER 1 GENERAL INFORMATION ........................................................................
1-1 MAJOR FEATURE........................................................................................................
1-2 SPECIFICATION ..........................................................................................................
1-3 INSTALLING THE SO-DIMM ........................................................................................
1-3-1 REMOVING THE SO-DIMM ......................................................................................
1-4 DIRECTIONS FOR INSTALLING THE M.2 B KEY MINI CARD ...................................
CHAPTER 2 HARDWARE INSTALLATION ....................................................................
2-1 DIMENSION-2I640DW ................................................................................................
2-2 LAYOUT-2I640DW-CONNECTOR AND JUMPER .......................................................
2-2-1 LAYOUT-2I640DW-CONNECTOR AND JUMPER BOT ............................................
2-3 LAYOUT-2I640DW-FUNCTION MAP TOP ...................................................................
2-3-1 LAYOUT-2I640DW-FUNCTION MAP BOT ...............................................................
2-4 DIAGRAM-2I640DW TOP ............................................................................................
2-4-1 DIAGRAM-2I640DW BOT .........................................................................................
2-5 FUNCTION MAP-2I640DW TOP ..................................................................................
2-5 FUNCTION MAP-2I640DW BOT ..................................................................................
2-6 LIST OF JUMPERS ......................................................................................................
2-7 JUMPER SETTING DESCRIPTION ............................................................................
2-8 JSB1: CMOS DATA CLEAR .........................................................................................
2-9 JAT1: POWER IN ALWAYS ON FUNCTION ...............................................................
2-10 JVL1: eDP PANEL POWER SELECT ........................................................................
CHAPTER 3 CONNECTION ..........................................................................................
3-1 LIST OF CONNECTORS..............................................................................................
3-2 CMOS BATTERY CONNECTOR .................................................................................
3-3 USB INTERFACE .........................................................................................................
3-4 LAN INTERFACE .........................................................................................................
3-5 COM INTERFACE ........................................................................................................
3-6 FRONT PANEL PIN HEADER ......................................................................................
3-7 DIO INTERFACE ..........................................................................................................
3-7-1 IO DEVICE: F75111 CIO UTILITY .............................................................................
3-7-2 IO DEVICE: F75111 CIO UTILITY CIO116 ................................................................
3-8 CO1: I2C 1x4 PIN (1.25mm) WAFER ...........................................................................
3-9 CPI1: DC POWER INPUT 1x4 PIN (2.0mm) WAFER (RED) .......................................
3-10 DISPLAY INTERFACE ...............................................................................................
3-11 SIM1: NANO SIM CARD PUSH-PUSH ......................................................................
3-12 NGFF1: PCI EXPRESS M.2 B KEY 2242 H=8.5 SOCKETS 75PIN ..........................
Contents
1
2
4
5
6
7
9
10
11
11
12
13
14
15
16
17
18
19
20
20
21
22
22
23
23
24
25
26
27
28
29
30
37
42
42
43
46
47

ii
49
50
51
51
52
53
53
54
55
56
57
58
59
61
62
64
65
66
67
71
75
76
77
78
81
82
83
84
85
3-13 NGFF2: PCI EXPRESS M.2 B KEY 2242 / 3042 H=8.5 SOCKETS 75PIN ...............
3-14 CRFP1: ANTENNA CONTROL 1x4 PIN (1.25mm) WAFER (OEM) ....................................
CHAPTER 4 INTRODUCTION OF BIOS ........................................................................
4-1 ENTER SETUP ............................................................................................................
4-2 BIOS MENU SCREEN & FUNCTION KEYS ................................................................
4-3 GETTING HELP ...........................................................................................................
4-4 MENU BARS ................................................................................................................
4-5 MAIN ............................................................................................................................
4-6 ADVANCED ..................................................................................................................
4-6-1 BOOT CONFIGURATION .........................................................................................
4-6-2 SOC CONFIG CONFIGURATION .............................................................................
4-6-2-1 ACPI SETTINGS ....................................................................................................
4-6-2-2 SYSTEM AGENT (SA) CONFIGURATION ............................................................
4-6-2-3 PCH-IO CONFIGURATION ...................................................................................
4-6-2-3-1 PCI EXPRESS CONFIGURATION .....................................................................
4-6-2-3-2 SATA CONFIGURATION ....................................................................................
4-6-2-4 PCH-FW CONFIGURATION .................................................................................
4-6-3 SIO F81804 ...............................................................................................................
4-6-3-1 UART PORT 1 CONFIGURATION .........................................................................
4-6-3-2 UART PORT 2 CONFIGURATION .........................................................................
4-6-3-3 HARWARE MONITOR ...........................................................................................
4-6-3-4 RESTORE ON POWER LOSS ..............................................................................
4-6-4 NVM EXPRESS INFORMATION ..............................................................................
4-7 SECURITY ...................................................................................................................
4-8 POWER .......................................................................................................................
4-9 BOOT ...........................................................................................................................
4-10 SAVE & EXIT .............................................................................................................
4-11 HOW TO UPDATE INSYDE BIOS ..............................................................................
APPENDIX B: RESOLUTION LIST ....................................................................................

Copyright
This manual is copyrighted and all rights are reserved. It does not allow any non
authorization in copied, photocopied, translated or reproduced to any electronic or machine
readable form in whole or in part without prior written consent from the manufacturer.
In general, the manufacturer will not be liable for any direct, indirect, special, incidental
or consequential damages arising from the use of inability to use the product or
documentation, even if advised of the possibility of such damages.
The manufacturer keeps the rights in the subject to change the contents of this manual
without prior notices in order to improve the function design, performance, quality, and
reliability. The author assumes no responsibility for any errors or omissions, which may
appear in this manual, nor does it make a commitment to update the information contained
herein.
Trademarks
Intel is a registered trademark of Intel Corporation.
Insyde is a registered trademark of Insyde Software, Inc.
All other trademarks, products and or product's name mentioned here are for
identifi cation purposes only, and may be trademarks and / or registered trademarks
of their respective companies or owners.
© Copyright 2022
All Rights Reserved.
User Manual edition 0.1, JUNE. 2022

1
Warning !
1. Battery
Batteries on board are consumables.
The life time of them are not guaranteed.
2. Fanless solution with HDD
The specifi cation & limitation of HDD should be considered carefully when
the fanless solution is implemented.
3. We will not give further notifi cation in case of changes of
product information and manual.
4. SATA interface does not support Hot SWAP function.
5. There might be a 20% inaccuracy of WDT at room temperature.
6. Please make sure the voltage specifi cation meets the requirement
of equipment before plugging in.
8. Caution! Please notice that the heat dissipation problem could cause the MB
system unstable. Please deal with heat dissipation properly when
buying single MB set.
9. Please avoid approaching the heat sink area to prevent users from
being scalded with fanless products.
12. It is important to install a system fan toward the CPU to decrease
the possibility of overheating / system hanging up issues,
or customer is suggested to have a fi ne cooling system to dissipate heat
from CPU.
11. DO NOT apply any other material which may reduce cooling
performance onto the thermal pad.
10. If users repair, modify or destroy any component of product unauthorizedly,
We will not take responsibility or provide warranty anymore.
7. There are two types of SSD, commercial grade and industrial grade, which
provide diff erent read/write speed performance, operation temperature and
life cycle. Please contact sales for further information before making orders.

2
Hardware Notice Guide
1. Before linking power supply with the motherboard, please attach DC-in adapter to
the motherboard fi rst. Then plug the adapter power to AC outlet.
Always shut down the computer normally before you move the system unit or
remove the power supply from the motherboard. Please unplug the DC-in adapter fi rst
and then unplug the adapter from the AC outlet.
Please refer photo 1 as standard procedures.
2. In case of using DIRECT DC-in (without adapter), please check the allowed range
for voltage & current of cables. And make sure you have the safety protection for
outer issues such as short / broken circuit, overvoltage, surge, lightning strike.
3. In case of using DC-out to an external device, please make sure its voltage and
current comply with the motherboard specifi cation.
4. The total power consumption is determined by various conditions
(CPU / motherboard type, device, application, etc.). Be cautious to the power cable
you use for the system, one with UL standard will be highly recommended.
5. It’s highly possible to burn out the CPU if you change / modify any parts of
the CPU cooler.
6. Please wear wrist strap and attach it to a metal part of the system unit
before handling a component. You can also touch an object which is
ground connected or attached with metal surface if you don't have wrist strap.
7. Please be careful to handle & don't touch the sharp-pointed components on
the bottom of PCBA.
8. Remove or change any components form the motherboard will VOID the warranty of
the motherboard.
9. Before you install / remove any components or even make any jumper setting
on the motherboard, please make sure to disconnect the power supply fi rst.
(follow the aforementioned instruction guide)
10. "POWERON after PWR-Fail" function must be used carefully as below:
When the DC power adaptor runs out of power, unplug it from the DC current;
Once power returns, plug it back after 5 seconds.
If there is a power outage, unplug it from the AC current, once power returns,
plug it back after 30 seconds. Otherwise it will cause system locked or made
a severe damage.
Remark 1:
Always insert / unplug the DC-in horizontally & directly to / from the motherboard.
DO NOT twist, it is designed to fi t snugly.
Moreover, erratic pull / push action might cause an unpredictable damage to the
component & system unit.
*

3
2
1
3
1
2
3
Photo 1 Insert
Unplug

4
Chapter-1
General Information
The 2I640DW is a 2.5" (110 x 98 mm) motherboard powered with Intel Atom® x6000E
series and Celeron® J (formerly Elkhart Lake) processor & off ered the ideal platform for
high performance applications. The ultra compact (110 x 98 mm) motherboard with wide
range 9~24V DC power input & embeds multiple Intel GbE LAN, USBs, COM Ports and
HDMI display interface that off er the ideal platforms for high performance applications in
Networking, Smart Automation, Machine Vision, In-vehicle, Industry 4.0 and any compact
high-performance Internet of Things (IoT) applications.
The 2I640DW supports high-speed data transfer interfaces such as PCIe gen3, USB 3.0,
and SATA 6 Gb/s (SATA III) for SATA-SSD interface M.2 B-Key device, with one-channel
DDR4 3200 MHz memory up to 32GB SODIMM slot and supports two serial ports RS232 /
RS485 / RS422 jumper free auto switch by BIOS. It supports 2 ports of USB 3.0, 3 ports of
USB 2.0. The expandable interfaces include 1 M.2 B-Key for PCIe x 2 or SATA-SSD (auto-
detection) and USB interface, and 1 M.2 B-Key PCIe x 2 and USB 3.0 / 2.0 interface.
The embedded motherboard 2I640DW is specially designed with Wide-Range Voltage DC
in (9~24V) for widely varying input voltage requirement. All wafer IO design off ers superb
performance and PC specifi cation in the industry using the specifi c housing. It supports
with three 10 / 100 / 1000 Mbps Ethernet for seamless broadband connectivity. With
Wake-On LAN function and the PXE function in BIOS, these are perfect control boards for
networking devices.

5
1. Intel® Atom x6413E Processor 1.5GHz / 2.7GHz (Quad Core),
Intel® Celeron Processor J6412 2.0GHz / 2.6GHz (Quad Core)
2. Intel® UHD Graphics for 10th Gen Intel® Atom x6413E 500MHz /
750MHz, Intel® Celeron J6412 400MHz / 800MHz
3. DDR4 SODIMM slot x 1, up to 32GB
4. Support 3 x 10 / 100 / 1000 Mbps Intel LAN ports.
5. Support 2 x RS232 selectable to RS485 / RS422 by BIOS
6. 2 x USB 3.0 and 3 x USB 2.0
7. Support extended 1 x M.2 B-Key for PCIe x 2 / SATA-SSD (auto-detect) and USB
interface, 1 x M.2 B-Key for PCI2 x 2 and USB 3.0 / 2.0 interface with Nano SIM.
8. Hardware digital Input & Output, 4 x DI / 4 x DO, Hardware Watch Dog Timer,
0~255 sec programmable
9. Wide Range DC IN +9V~24V
1-1 Major Feature

6
1. SOC: Intel® Atom x6413E Processor 1.5GHz / 2.7GHz (Quad Core),
Intel® Celeron Processor J6412 2.0GHz / 2.6GHz (Quad Core)
2. Memory: DDR4 SODIMM slot x 1, up to 32GB
3. Graphics: Intel® UHD Graphics for 10th Gen Intel® Atom x6413E 500MHz / 750MHz,
Intel® Celeron J6412 400MHz / 800MHz
4. LAN: 3 Intel I211-IT LAN chipset with 10 / 100 / 1000 Mbps for PCIe x 1 V2.1
5. l/O Chip: Switch chipset for 2 ports RS232 / RS422 / RS485 selected by BIOS
6. USB: 2 type A USB 3.0, 3 USB 2.0
7. WDT / DIO: Hardware digital Input & Output, 4 x DI / 4 x DO (Option) /
Hardware Watch Dog Timer, 0~255 sec programmable
8. Expansion interface: one M.2 B-Key for PCIe x 2 / SATA-SSD (auto-detect) and
USB interface, one M.2 B-key for PCIe x 2 and USB 3.0 / 2.0 interface with Nano SIM
9. BIOS: Insyde UEFI BIOS
10. Dimension: 110 x 98 mm
11. Power: On board DC +9~24V
1-2 Specifi cation

7
1-3 Installing the SO-DIMM
1. Align the SO-DIMM with the connector at a 45 degree angle.
2. Press the SO-DIMM into the connector until you hear a click.

8
Notices:
1. The connectors are designed to ensure the correct insertion. If you feel resistance,
check t h e connectors & golden fi nger direction, and realign the card.
2. Make sure the retaining clips (on two sides of the slot) lock onto the notches of
the card fi rmly.

9
1-3-1-1 Removing the SO-DIMM
1. Release the SO-DIMM by pulling outward the two retaining clips and
the SO-DIMM pops up slightly.
2. Lift the SO-DIMM out of its connector carefully.

10
1-4 Directions for installing the M.2 B Key Mini Card
1. Unscrew the screw on the board
3. Gently push down the Mini Card and screw the screw back.
2. Plug in the Mini Card in a 45 angle

11
2-1 Dimension-2I640DW
Chapter-2

12
2-2 Layout-2I640DW-Connector and Jumper
TOP
CO1
CPI1
SODIM1
CIO1
CFP1
CC2
CC1
CBT1
CU6
CU8
JAT1
JSB1
NGFF1
NGFF2
CL1
CL2
CL3
HDMI1
HDMI2
eDP
JVL1
DP1
DP2
CU7

13
2-2-1 Layout-2I640DW-Connector and Jumper Bottom
BOT
CU2
CU1
SIM1

14
2-3 Layout-2I640DW-Function MAP
TOP
SMBus
DC-IN +9V~+24V
DDR4
SODIMM
4DI/4DO
Front Panel
COM2
COM1
Battery Wafer
USB 2.0
USB 2.0
Power IN Always ON
CMOS Data Clear
M.2 B Key 2242
PCIe x2 - based SSD
USB 2.0
SATA-based SSD
M.2 B Key 2242/3042
PCIe x2 - based SSD
USB 2.0/3.0
LAN1
LAN2
LAN3
HDMI1
HDMI2
eDP
eDP Panel Power Select
Display1
Display2

15
2-3-1 Layout-2I640DW-Function MAP
BOT
USB 2.0 / 3.0
Nano SIM
USB 2.0 / 3.0

16
2-4 Diagram- 2I640DW
TOP
CO1
CPI1
SODIM1
CIO1
CFP1
CC2
CC1
CBT1
CU6
CU8
JAT1
JSB1
NGFF1
NGFF2
CL1
CL2
CL3
HDMI1
HDMI2
eDP
JVL1
DP1
DP2
CU7
