Lexicon LFI-10 User manual

User Guide
,
LFI- 10
Digital Audio Format Interface
lexiCOn

Unpacking and Inspection
After unpacking the LFI-1 0, save all packing materials in case you ever need to ship the unit. Thoroughly inspect
the unit and packing materials for signs of damage. Report any shipment damage to the carrier at once; report
equipment malfunction to your dealer.
Precautions
Save these instructions for later use.
Follow all instructions and warnings marked
on the unit.
Always
use with the correct line voltage. Refer to the manufacturer's operating instructions for power requirements. Be advised that different
operating voltages may require the use of a different line cord and/or attachment plug.
Do not install the unit
in an unventilated rack, or directly above heat producing equipment such as power amplifiers. Observe the maximum
ambient operating temperature listed
in the product specification.
S/ols and openings on the case are provided for ventilation; to ensure reliable operation and prevent it from overheating, these openings must
not
be blocked or covered. Never push objects of any kind through any of the ventilation slots. Never spill a liquid of any kind on the unit.
This product is equipped with a 3-wire grounding type plug. This is a safety feature and should not
be defeated.
Never attach audio power amplifier outputs directly to any of the unit's connectors.
To prevent shock or fire hazard, do not expose the unit to rain or moisture, or operate it where it will be exposed to water.
Do notattempt
to operatethe unit ifithasbeen dropped, damaged, exposed to liquids, orif it exhibits adistinctchange in performanceindicating
the need for service.
This unit should only be opened by qualified service personnel. Removing covers will expose you to hazardous voltages.
This triangle, which appearson your CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Thistriangle, which appears on your
component, alerts you to the pres- component, alerts you to important
ence of unlnsulated. dangerousvolt- operatingand maintenance instruc-
age inside the enclosure
... vOltage tions in this accompanying litera-
that may be sufficient to constitute a ture.
risk of shock.
Notice
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the
manufacturer's instructions, may cause interference to radio and television reception. It has been type tested and found
to comply with the
limitsforaClass Acomputing devicein accordancewith the specifications
in SubpartJof Part15of FCC Rules, which aredesignated to provide
reasonable protection against such interference in a residential installation. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment does cause interference to radio or television reception, which can be determined by turning the
equipment OFF and ON, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient the receiving antenna
Relocate the computer with respect
to the receiver
Move the computer away from the receiver
Plug the computer into a different outlet so that the computer and receiver are
on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user may find
t~~ following booklet prepared by the Federal Communications Commission helpful:
1 "How to identify and Resolve RadiofTV Interference Problems."
f
hllib -60klet is available from the U.S. Govemment Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4.
I
4e "p"reserit appareil numerique n'emet pas de bruits radioelectriques depassant les limites applicables aux appareils numeriques de la class
~ ~r~scrites dans Ie Reglement sur Ie brouillage radioelectrique edicte par Ie ministere des Communications du Canada.
i .
I
dopyrrgtit © 1992, 1994
Lexicon Inc.
100 Beaver Street
Waltham MA 02154 USA
617-736-0300
Fax: [phone]
I
All ~ights Reserved
;,; :
I .
This publication is protected by copyright and all rights are reserved. No part of it
may be reproduced or transmitted by any
TT\eans or in any form, without express prior consent in writing from Lexicon.
I " .
Lexicon Part # 070-08618 Rev 1
Printed in the United States of America
