Advaning FS SERIES User manual

For safety reasons, please read the instructions and warnings
in this manual carefully before installing the awning.
FS SERIES
Free Standing Awning
Owner’s Manual

The awning arms contain tensioned
cables. Always use caution, securely tie
the awnings arms to the awning when
performing installation, adjustments, or
repairs. Sudden movement of tension
arms can result in serious personal injury,
product and/or property damage.
CAUTION
1
In order to avoid
accidental injury or
product damage,
DO NOT remove
the safety restraints
from the awning’s
lateral arms until
instructed to do so.
Safety instructions and warnings........................................... 2
Package contents and parts .............................................. 3
Tool requirements ...................................................... 4
Product features ....................................................... 4
Assembly
Determine where to place your awning ............................... 6
Assemble the awning support structure ............................... 6
Secure the awning to support structure ............................... 7
Secure awning to ground........................................... 8
Operation
Ready your awning ............................................... 9
Operate your awning ............................................. 9
Accessories..................................................... 10
Maintenance.......................................................... 11
Warranty............................................................. 12
!
!
TABLE OF CONTENTS
SAFETY INSTRUCTIONS
Fig.1
www.advaning.com Toll Free (US): [phone]
!
!
!
!

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
2
A B C
For safety reasons we
strongly recommend
the following during
installation:
A: Minimum 2 people
B: Work gloves
C: Safty goggles
SAFETY INSTRUCTIONS AND WARNINGS
• Pay close attention during assembly to ensure that the Advaning awning is assembled properly.
• Perform the assembly in dry and optimal conditions. Always wear protective gear and gloves when handling
sharp metal parts. If you do not feel that you can properly assemble the awning, please seek professional
help.
• The Advaning awning should only be operated by an adult that understands all the functions and operations
of the awning. Please keep unsupervised children away from playing with the awning or its parts.
• The product should be used only as described in this Advaning Owner’s manual. Do not carry out any
maintenance other than what is shown in this manual. For any issues that are not covered in this manual,
please seek support from Advaning Customer Service.
• Only use Advaning recommended accessories and original replacement parts.
• Donotplaceanyheatsourceoropenameunderorneartheawning.
• Do not place, hang, or stand persons on the awning itself, doing so can damage the awning or cause
severe personal injury and in extreme cases death.
• Donotplace,hang,orstandobjectsnotspeciedbyAdvaningorweightsmorethan18lbs,ontheawning.
Doing so can damage the awning or cause severe personal injury and in extreme cases death.
DO NOT keep the
awning open during:
D: RAIN
E: SNOW
F: STRONG WIND
G: AWAY FROM HOUSE
D E F G
Fig.3
Fig.2
Toll Free (US): [phone] www.advaning.com

3
PACKAGE CONTENTS AND PARTS
Before installation, make
certain that the package
contains all parts as listed
on this page.
Fig.4
www.advaning.com Toll Free (US): [phone]
Awning Module (1)
Hand Crank (1)
Upright Leg Cover (2)
Upright Leg (2)
Lower Leg Top
Cover (2)
Lower Leg Bottom
Cover (2)
Lower Leg (2)
Supporting Brace (2)
Short Base (2)
Long Base (2)
M8x90 Upright Leg
Bolt Set (4)
Lower Leg Screw and
Washer Set (8)
M6x16 Supporting
Brace Screw and
Washer Set (8)
13
12
11
10
13
12
11
10
1
1
5
9
6
3
3
4
5
6
7
7
2
2
4
8
8
9

4
TOOL REQUIREMENTS
PRODUCT FEATURES
Fig.6
Fig.5
Arm shoulder
Awning module
Crank loop
Awning fabric
Front bar
Retractable arms
Supporting brace
Upright leg
Lower leg
Long base
Short base
Toll Free (US): [phone] www.advaning.com
SUGGESTED TOOLS
OPTIONAL TOOLS
Measuring tape
Socket wrench/wrench
Ladders (2)
Drill bit
Masonry drill bit
Drill with bits
Minimum 2 people to
install
1 3
4
4
2
2
5
5
6
6
6
11
11
10
10
1
3
6
7
7
7
8
8
9
9
2
4
5
1
4
5
2
3
6
1
1
1
3
3

5
ASSEMBLY
For 11 x 10 foot model
Locate a clear area, on
level ground / surface,
that is at least 10 feet
wide by 11 feet length by
8 feet height.
For 14 x 10 foot model
Locate a clear area, on
level ground / surface,
that is at least 10 feet
wide by 14 feet length by
8 feet height.
DETERMINE
WHERE TO PLACE
YOUR AWNING
www.advaning.com Toll Free (US): [phone]
Fig 8
Fig 7
132”
175”
124”
167”
57”
57”
99”
99”
120”
120”

6
ASSEMBLY
Fig 11 Fig 12
Fig 9
Fig 10
ASSEMBLE THE
AWNING SUPPORT
STRUCTURE
Slot 1 short base and
1 long base together
to create a cross base.
Attach the lower leg
to the cross base with
4 lower leg screws
and washer sets.
Insert the upright leg
cover into the top of
the upright leg.
Insert the lower leg
bottom cover then
the top lower leg
cover into the lower
leg.
Insert upright leg into
the assembled leg
base.
Repeat step 1-3 to
assemble the second
leg base.
NOTE: Make sure the
screw holes on the
upright leg are facing
the short segment of the
assembled cross base.
Toll Free (US): [phone] www.advaning.com
1
2
2
5
4
3
1
3
4
5
6

7
ASSEMBLY
Fig 13
Fig 14
SECURE THE
AWNING TO
THE SUPPORT
STRUCTURE
Place the assembled
legs so the short
segments of the cross
base face each other.
Insert the awning
module into the slots
on the top of the
assembled legs.
Adjust the awning
and the legs to align
the screw holes.
Attach the awning
to the legs using 2
upright leg bolt sets
on each leg.
www.advaning.com Toll Free (US): [phone]
5
5
6
6
6
7
8
8
short segments
face each other

8
Fig 15
Fig 16
Toll Free (US): [phone] www.advaning.com
ASSEMBLY
Place the supporting
brace at the upper
corners of the awning
assembly.
Align the screw
holes and attach the
supporting brace to
the awning assembly
with 2 support brace
screw and washer
sets for each side.
Option A
Use screws / bolts /
stakes, appropriate to the
ground type, to secure
the awning cross base
onto the ground (earth,
concrete, brick, deck).
Note: Screws / bolts
/ stakes not included
in package. Please
consult with your home
improvement store for
appropriate equipments.
Option B
Place concrete pavers
onto the awning cross
base for security.
SECURING THE
AWNING TO THE
GROUND
CAUTION: Make sure
the FS Series awning is
placed on level ground.
Uneven ground will cause
the awning to tilt.
9
9
10
10
Option A
Option B

9
OPERATION
Use the hand crank
to open the awning
fully then close it
completely to test for
proper operation.
Use the hand crank
and open the awning
to desired extension.
NOTE: The arms are
not designed to be
completely straight in the
fully extended position.
CAUTION: To keep the
fabric taut, alway reserve
a small protion of the
awning fabric in the roller
tube.
Position yourself
under the awning.
Remove the safety
restraints from the
arms, with scissors,
one at a time. Do not
use a knife or blade
to cut the restraints.
Before removing the
safety restraints, make
sure no persons or
objects are in front of the
awning. Failure to do so
could result in personal
injury.
READY YOUR
AWNING
OPERATE YOUR
AWNING
1
2
www.advaning.com Toll Free (US): [phone]
Fig 17
Fig 18
1
1
1
2

11
MAINTENANCE
Allow the awning fabric to fully dry before retracting. Doing so will help prevent
mildew from growing and prolong the life of the fabric.
If you must retract the awning while wet, open the awning as soon as the weather
permits to allow the fabric to fully dry and remove any dirt deposits to preserve
the fabric.
Cleaning the awning regularly with mild soap and water will extend the life of the
fabric and prevent the formation of mildew. It is necessary to prevent stains from
becoming embedded into the fabric.
Remove the dust from the dry awning fabric by gently beating or brushing the
fabric.
Your awning contains powder-coating steel or aluminum and can last for many
years. It is important to inspect the fasteners, connections and the condition of
the metal components.
The retractable awning is designed to provide protection from the sun and is not
intended for rain, snow or extreme wind. Retract the awning to prevent damage
from accumulated water, snow or from strong gusts of wind.
The fabric is water repellent and is not intended to protect against the water
elements.
PREPARING
YOUR AWNING
FOR INCLEMENT
WEATHER
PROTECTING THE
FABRIC FROM
MILDEW
CLEANING THE
FABRIC
PROTECTING THE
FRAME
www.advaning.com Toll Free (US): [phone]

12
Toll Free (US): [phone] www.advaning.com
LIMITED WARRANTY AND CUSTOMER SERVICE
LIMITED WARRANTY COVERS
Advaning warrants all Advaning original products, sold and installed within the 50 states of the United States,
to be free of defects of materials and workmanship. This warranty only applies to the original owner or
purchaseroftheproductandisonlyeffectiveonabasisforsixty(60)monthsorve(5)yearsfromthedate
of purchase. Any defects or issues presented to Advaning within the warranty period will be handled by
Advaning Customer Service within a reasonable time.
Entire awning framework, including extruded and die cast component parts, springs and cables are covered
under the limited warranty. Should the purchaser notify Advaning within the twelve (12) months or one (1)
year period from the date of the original purchase, defective component will be replaced in full or repaired
by Advaning at no charge. All claims submitted after twelve (12) months or one (1) year but within sixty (60)
monthsorve(5)yearsfromthedateoftheoriginalpurchase,thedefectivecomponentwillbereplaced
upon the purchaser’s payment of 1/60th of the full retail cost of the component for each month of use prior to
theclaim.PowdercoatednishesandpaintednishesareexcludedandareNOTcoveredunderthislimited
warranty.
ANY MODIFICATIONS OR ALTERATIONS TO THE PRODUCT WILL VOID THIS WARRANTY.
ADVANING, INCLUDING ITS SUBSIDIARIES AND AFFILIATES SHALL NOT BE RESPONSIBLE IN ANY MANNER
WHATSOEVER FOR INJURY, DEATH OR DAMAGE TO PROPERTY AS A RESULT OF THE INTENTIONAL OR
ACCIDENTAL MISUSED FOR PURPOSES FOR WHICH THE PRODUCT WAS NOT DESIGNED FOR.
WARRANTY LIMITATION AND EXCLUSION
The warranty will be in effect once the awning is fully paid for.
Advaningisnotresponsiblefordamagesduetofaultymodications,installation,orre-installation.
Advaning assumes no liability for damage to the structure to which the awning is attached, or to the property
located underneath the awning. This limited warranty does not cover damage from ice, snow, hail, high winds,
vandalism, neglect, improper use, or any natural disasters. This limited warranty does not cover degradation
due to salt corrosion, oxidation, and chipping or peeling of the paint.
Problems and Warranty Claims
If you experience a problem with your Advaning product, please contact Advaning Customer Service over the
phone Monday through Friday 8:00AM – 4:00PM Pacic Standard Time at 1-855-574-0158 or email us at
service@advaning. com.
• Prior to contacting Advaning via phone or email for warranty claims, please have your model name/
number,serial/lotnumber,originalproofofpurchase,andadescriptionofdifcultyexperiencereadyfor
our Customer Service team. Most issues can be resolved over the telephone by our trained Customer
Service representatives. If any issues arise that cannot be solved over the phone or email, Advaning will
issue a Return Merchandise Authorization (“RMA”) number, and arrange replacement parts for you.
For more information on returning a RMA product, please see Advaning Return Policy or contact Advaning
Customer Service Department at [phone].
• All Work will be carried out by Advaning or its authorized agents and will not extend the warranty
coverage period beyond the sixty (60) months from the original date of purchase. Any work done by a
third party or non-authorized Advaning agent will void this warranty.

13
LIMITED WARRANTY AND CUSTOMER SERVICE
THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED. NO IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
ARE GIVEN, ANY AND ALL LIABILITY FOR BREACH OF ANY IMPLIED WARRANTY OR WARRANTY CREATED
BY LAW IS DISCLAIMED.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not
apply to you.
UNDER NO CIRCUMSTANCES SHALL ADVANING, INCLUDING ITS SUBSIDIARIES AND AFFILIATES BE
LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES WITH RESPECT TO ECONOMIC LOSS, INJURY,
DEATH OR PROPERTY DAMAGE, WHETHER AS A RESULT OF BREACH OF THIS WARRANTY, NEGLIGENCE
OR OTHERWISE.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation or exclusion may not apply to you in
wholeorinpart.Thiswarrantygivesyouspeciclegalrights.Youmayalso
have other rights that vary from state to state.
What is Not Covered by the Advaning Limited Warranty
This warranty is non-transferable and does not cover product purchases from the initial buyer to a third party.
This warranty does not cover incidental damages, such as loss of time, loss of use, or installation costs of
defective, repaired or replaced product. This warranty does not cover product that has been damaged or
rendered defective as a result of:
(a) Neglect, abuse or misuse.
(b) Modicationoftheoriginalproduct.
(c) Improper use or installation using products not manufactured by Advaning.
(d) Service provided by anybody other than Advaning.
(e) Abnormal mechanical or environmental conditions.
(f) Unusualphysicalorelectricalstress-includingfailureoructuationofelectrical power, lighting, static
electricity,re,tornadoes,orothernaturaldisasters.
Shipping Damage Claim:
On the occasion of a damage claim, the end user must contact Advaning and the delivering freight carrier
within 3 days of signing for the delivery in order to make a claim. Failure to report freight damage and missing
parts in a timely manner and in accordance to the carrier’s guidelines may result in you incurring all costs.
Likewise, there are 7 days to report missing parts to Advaning.
Formoreinformation,pleasecontactthecorporateofce.
Advaning Customer Service Center
Toll Free (US): [phone]
Email: [email protected]
MondaythroughFriday8:00amto4:00pm(PacicStandardTime)
www.advaning.com Toll Free (US): [phone]

CONTACT
INFORMATION
Service Questions: [email protected]
Toll Free (US): 855–574-0158
Fax: [phone]
12282 Knott Street, Garden Grove, CA 92841
www.advaning.com
OM_FS Series_V03_R01_2018.08.12
