GENERAL INFORMATION
SIMPLWINDOWS NAME: Lexicon RV-5 Receiver V1.0
CATEGORY: Receiver/Processor
VERSION: 1.0
SUMMARY: Controls all standard functions on Lexicon RV-5 Receiver system. Provides true
feedback.
GENERAL NOTES:
This module will control a Lexicon RV-5 Receiver.
Pulse one of the *_Direct_Setting_Enable radio group to enable commands such as
Main Volume, Zone 2 Volume, Bass, Treble, HQ Shelf, Surround Trims, etc.
Note: At least 1 of these signals must be enabled for any direct commands to work.
Auto status feedback is enabled by selecting Auto_Feedback_On. You may also
switch Auto Feedback off by using Auto_Feedback_Off.
You may also hold Poll_Enable high to poll for device status every ½ second. This is
typically done on demand (when visiting control pages for this device).
Note that all inputs to this module should be momentary, as if coming from a button
on a touch panel.
CRESTRON HARDWARE REQUIRED: CNXCOM, ST-COM, C2COM
SETUP OF CRESTRON HARDWARE:
RS232
Baud: 38,400
Parity: N
Data Bits: 8
Stop Bits: 1
VENDOR FIRMWARE: Software Version: RV-5 V2.51
VENDOR SETUP: N/A
CABLE DIAGRAM: CNSP-121

Partner: Lexicon
Model: RV-5 Receiver
Device Type: Receiver/Processor
CONTROL:
Power_On/Off/Toggle D Pulse to turn the unit on or off.
Power_Off_Zone_1 D Pulse to power off Main Zone.
Power_Off_Zone_2 D Pulse to power off Zone 2.
Input_*_Zone_1 D Pulse to pick a source input for Zone 1 (Main).
Volume_Up/Down_Zone_1 D Press and hold to adjust volume for Zone 1 (Main).
Volume_Mute_On/Off/Toggle_Zone_1 D Pulse to set or toggle mute state to on/off Main Zone.
Mode_Up/Down D Pulse to cycle through surround modes based on parent surround mode
(see Mode_* below).
Video_Status_Toggle D Pulse for video status toggle command.
Audio_Status_Toggle D Pulse for audio status toggle command.
Menu_Select D Pulse for menu selection.
Arrow_Up/Down/Left/Right D Pulse to navigate onscreen menu system.
Menu_Select_2 D Pulse for menu select 2 (enter).
Menu_Exit D Pulse for menu exit.
Front_Panel_LCD_Display_Toggle D Pulse for front panel display brightness toggle.

Partner: Lexicon
Model: RV-5 Receiver
Device Type: Receiver/Processor
Mode_* D Pulse for surround mode command.
Analog/Digital_In_Toggle D Pulse to switch between analog and digital in.
Tone_On/Off_Toggle D Pulse to toggle tone on/off.
EQ_On/Off_Toggle D Pulse to set or toggle EQ on/off.
EQ_Preset_1/2/3 D Pulse to set EQ preset.
Treble_+1/-1_dB D Pulse to increment/decrement treble level by 1 dB.
Tuner_Preset_+/- D Pulse to increment/decrement tuner presets.
Tuner_Tune_+/- D Pulse to increment/decrement tuner frequencies.
Tuner_Auto/Man_Toggle D Pulse to toggle between tuner auto and manual settings.
Tuner_Save D Pulse to save current frequency into a preset. System will prompt for a
preset location.
Tuner_Stereo/Mono_Toggle D Pulse to toggle between tuner stereo and monaural settings.
Tuner_AM/FM_Toggle D Pulse to toggle between tuner am and fm settings.
iPOD+/- D Pulse to increment/decrement iPod songs/files.
iPOD_CounterClockWise_Click D Pulse to emulate iPod jog wheel in counterclockwise direction.
iPod_ClockWise_Click D Pulse to emulate iPod jog wheel in clockwise direction.
iPOD_Menu D Pulse for iPod menu.
iPOD_Select D Pulse for iPod menu select.
iPOD_Play/Pause D Pulse for iPod play/pause select.
PC_+/- D Pulse to increment/decrement PC songs/files.
PC_Pause D Pulse for pause PC.
Volume_Up/Down_Zone_2 D Press and hold to adjust volume for Zone 2.
Volume_Mute_On/Off/Toggle_Zone_2 D Pulse to set or toggle mute state to on/off Zone 2.

Partner: Lexicon
Model: RV-5 Receiver
Device Type: Receiver/Processor
Input_*_Zone_2 D Pulse to pick a source input for Zone 2 (Main).
Auto_EQ_On/Off D Pulse for Auto EQ.
Tone_On/Off D Pulse for tone.
Analog_In D Pulse to set analog in.
Digital_In D Pulse to set digital in.
Two_Line_OSD_Toggle D Pulse to set two line OSD state.
V-Process_Toggle D Pulse to set Video process state.
EQ_HF_Shelf_+/-dB D Pulse to increment/decrement EQ HF in 1 dB increments.
FM/AM_Band D Pulse to set tuner band state to either FM or AM.
Tuner_Stereo/Mono D Pulse to set tuner state to either stereo or monaural.
Tuner_Tune_Auto/Manual D Pulse to set tuner state to either auto or manual.
*_Direct_Setting_Enable D
Pulse one of these inputs to enable commands such as Main Volume,
Zone 2 Volume, Bass, Treble, HQ Shelf, FL Trim, etc. After a Direct
Setting function is selected, the Key_* functions are used to set proposed
level. Press Key_Enter to send command.
Key_* D Press to adjust direct setting selected. Key_Clear/Up/Down/Enter.
Two_Line_OSD_Off D Pulse to change two lines of OSD display to off.
Auto_Feedback_On/Off D Set Auto_Feedback_On high to enable auto feedback.
Two_Line_OSD_*_Sec D Pulse to change two lines of OSD display to various durations in seconds.
Front_Panel_LCD_Display_Bright_Full/Half/Off D Pulse to change brightness level of FRONT_PANEL_LCD_DISPLAY.
Video_Process_Conversion_On/Faroudja/Bypass D Pulse to set video process conversion mode.
Bass_+1/-1_dB D Pulse to increment/decrement bass level by 1 dB.
Poll_Enable D Hold high to enable polling of unit for it’s settings every .5 seconds. Hold low to disable polling when not visiting pages directly related to control of
the receiver/processor.
From_Device$ S Serial signal to be routed from a 2-way RS232 port or TCP/IP Client.

Partner: Lexicon
Model: RV-5 Receiver
Device Type: Receiver/Processor
FEEDBACK:
Power_On/Off_Fb D True feedback indicating the power state.
Mute_On/Off_Zone_1_Fb D True feedback indicating mute status for main zone.
Input_*_Zone_1_Fb D True feedback indicating input status for main zone.
Main_Volume_Bar A Analog value representing actual volume for main zone. Should be routed to a bar
graph on a touch panel.
Digital_On_Fb D True feedback indicating digital in is selected.
Tone_On_Fb D True feedback indicating tone on is selected.
Tuner_Tune_Auto_Fb D True feedback indicating tuner auto tune on is selected.
Stereo_Fb D True feedback indicating tuner stereo is selected.
Tuner_FM_Fb D True feedback indicating tuner FM is selected.
Zone_2_Volume_Bar A Analog value representing actual volume for main zone. Should be routed to a bar
graph on a touch panel.
Mute_On/Off_Zone_2_Fb D True feedback indicating mute status for zone 2.
Input_*_Zone_2_Fb D True feedback indicating input status for zone 2.
Auto_EQ_On/Off_Fb D True feedback indicating Auto EQ selected.
Mono_Fb D True feedback indicating tuner monaural is selected.
Tuner_Tune_Auto/Manual_Fb D True feedback indicating tuner auto/manual is selected.
*_Direct_Setting_Enable_Fb D Feedback to show one of this radio group to enable shared keyboard for direct entry commands such as Main Volume, Zone 2 Volume, Bass, Treble, HQ Shelf,
FM, AM, Preset, FL Trim, etc.
Direct_Command_Value A Analog value representing raw data sent to unit for processing a direct command. This value is useful as a visual indicator for keypad data entry. Numeric values are
different for this field depending on what command is being processed.
Auto_Feedback_On/Off_Fb D Feedback for Auto Feedback, high to enable auto feedback.

Partner: Lexicon
Model: RV-5 Receiver
Device Type: Receiver/Processor
Display_Status_Line1$ S Serial signal representing line 1 of LCD to be routed to a touch panel indirect text
field.
Display_Status_Line2$ S Serial signal representing line 2 of LCD to be routed to a touch panel indirect text
field.
To_Device$ S Serial signal to be routed to a 2 way RS232 port or TCP/IP Client.
TESTING:
OPS USED FOR TESTING: PRO2 Cntrl Eng {v3.155.1240 (Release)}
SIMPL WINDOWS USED FOR TESTING: 2.08.41
CRES DB USED FOR TESTING: 18.8.8
SYMBOL LIBRARY USED FOR TESTING: 487
SAMPLE PROGRAM: Lexicon RV-5 V1.0 Demo
REVISION HISTORY: V. 1.0
