Based on the critically acclaimed line of Lexicon preamp/ processors and
power amplifiers, the RV-8 was designed from the ground up with the
enthusiast in mind. The massive power amplifier section outputs an
impressive 140 watts on each of its seven channels across the entire audi-
ble spectrum with all seven channels driven simultaneously. And it does
so while retaining exceptional transparency, wide dynamic range and sonic
neutrality. The RV-8 delivers real power that makes stand-alone multi-
channel power amplifiers blush. Mated with an exceptional preamp/
processor utilizing the latest algorithms, including LOGIC 7 and an intu-
itive user interface, the RV-8 can be viewed as “separates” that happen to
share the same chassis.
The RV-8 Receiver is an 8-channel audio and video control center with
independent zone monitoring that provides control of audio and video
source selection in three zones at the same time.The RV-8 includes a host
of inputs: abuilt-in tuner, eight digital audio, eight analog audio, phono, five
>Eight channels
>Eight configurable inputs
>Three independent zones
>Integrated 7-channel amplifier with massive toroidal transformer and
thermal/DC protection
>AM/FM tuner with 40 presets
>Low noise MM phono input
>Two 5.1-channel analog audio inputs
>Analog bypass option for 5.1-channel and stereo audio inputs
>Auto switching between digital and analog audio input connectors
>Headphone output with available LOGIC 7 processing
>Two 32-bit DSP engines
>Separate DSP engine for decoding compressed digital audio sources
>Four S/PDIF coaxial and four S/PDIF optical digital audio inputs
>One S/PDIF coaxial and one S/PDIF optical digital audio output
connector
>24-bit/192kHz digital-to-analog converters (DACs) for all audio
channels
>Two sets of analog A/V Zone 2 outputs; one fixed, one variable
>One set of analog audio Zone 3 outputs, variable level
>Broadcast-quality video switching
>Video conversion from S-video or composite video to component video
>Three component video inputs with full high-definition television
compatibility
>Five composite video inputs
>Five S-video inputs
>One component video output
>Four S-video outputs
>Five composite video outputs
>LOGIC 7 processing
>Dolby Digital Surround EX, Dolby Pro Logic II and Dolby Pro Logic
decoding
>DTS 96/24, DTS-ES (discrete and matrix) and DTS Neo:6 decoding
>THX Ultra2 and THX Surround EX decoding
>THX Ultra2 certification
>Flash memory software upgrade capability
>Two internal expansion slots
>Rear panel access plate
>RS-232 control
>Rear-panel IR input connector
>Two trigger output connectors
>Powerful preprogrammed and learning IR remote control with LCD
>Optional rack mount kit

Receiver
composite video, five S-video and three component
video input connectors.These can be assigned to any
of the eight software configurable inputs.The analog
input connectors can also be configured to accom-
modate up to two 5.1-channel analog sources such
as DVD-A and SACD.The RV-8 features an integrat-
ed 7-channel power amplifier that is designed to
achieve high levels of power and performance.
Equipped with a massivetoroidal power transformer,
the amplifier also provides thermal and DC protec-
tion. A built-in AM/FM tuner allows for automatic or
manual storing of up to 40 preset stations.
More than just an audio and video control center, the
RV-8 offers the latest version of Lexicon’s critically
acclaimed LOGIC 7 processing, which creates a 7.1-
channel output signal from stereo, 5.1- and 6.1-channel
sources. Unlike other decoders, LOGIC 7 processing is
compatible with all input sources and requires no special
encoding. Because the improvement it provides is clear-
lyaudible,LOGIC 7 is widely regarded as the finest sur-
round process currently available.
ALOGIC 7 downmix of multichannel source material is
available when using the Headphone listening modes. If a
stereo source is present, the dedicated HEADPHONE L7 listening mode
utilizes Head Related Transfer Functions that introduce a subtle sense of
surround sound, while preserving the original stereo image.
In addition to LOGIC 7, the RV-8 offers Dolby Digital Surround EX, Dolby
Pro Logic II, Dolby Pro Logic, DTS 96/24, DTS Neo:6, DTS-ES,THX Ultra2
and THX Surround EX decoding.THX Ultra2 certification guarantees that
the RV-8 meets the most stringent THX specifications.
With twofloating-point Hammerhead™Digital Signal Processing (DSP)
engines, the RV-8 boasts enormous processing power. These powerful
processors perform custom Lexicon processing such as LOGIC 7 decod-
ing, bass enhancement, dialog enhancement, auto azimuth, 5-speaker
enhancement, bass management, high-precision digital crossovers and
audio controls.These features are available at sample rates up to 96kHz,
with 24-bit resolution to retain top performance from all sources. In addi-
tion, athirdDSP engine is dedicated to decoding multi-channel com-
pressed audio sources.
The RV-8 is one of the most advanced audio and video control centers
available.High-precision 24-bit/96kHz analog-to-digital converters can be
used to convert stereo analog audio input signals to digital signals, allow-
ing the RV-8 to provide the benefits of precise digital signal processing
without sacrificing signal integrity.24-bit/192kHz DACs converters are uti-
lized for all output channels. Alternatively, 5.1-channel and stereo analog
Receiver

inputs can be set up individually to bypass analog-to-digital conversion and
internal processing altogether, following a pure analog signal path directly
to the outputs. Digital audio input signals are processed through a two-
stage phase lock loop for extremely low intrinsic jitter and high jitter
rejection.
Lexicon’sproprietaryauto azimuth technologycorrects timing and level
imbalances in stereo sources, ensuring exceptionally accurate playback of
surround-encoded sources.A digital audio pass-through output is available
for recording digital signals with a CD recorder or a similar component.
Complementing its audio performance, the RV-8 features broadcast-quali-
ty video switchers.A wide-bandwidth component video switcher accepts
analog component or
RGB video signals, while a composite and S-video
switcher accepts high-quality
NTSC , PAL or SECAM video signals.
Composite and S-video sources can be converted to component video.
The component video switcher can pass high-definition television signals,
as well as standard-definition TV signals.The switcher is designed to pass
video signals without alteration or degradation.
Built to professional standards, the RV-8 is designed to serve as the con-
trol center in anyhigh-quality home theater. Even the most demanding
enthusiast will be impressed with its unique combination of power, per-
formance and flexibility. Add to this a powerful learning remote control
that makes your entire system easier to use and you start to understand
why the RV-8 is the ultimate receiver.

Audio Inputs and Outputs
Analog Audio Inputs Eight stereo (RCA) or five stereo and one 5.1-channel or two
stereo and two 5.1-channel connectors
Digital Audio Inputs Four S/PDIF coaxial (RCA) and four S/PDIF optical (TosLink)
connectors;coaxial and optical input connectors conform to
IEC-958, S/PDIF standards
Sample Rates: 44.1, 48, 88.2, 96kHz
Accepts: 16-24 bits PCM audio, Dolby Digital, DTS, DTS-ES and DTS-
96k discrete data formats
Main Audio Outputs Eight Unbalanced (RCA) connectors for Front L/R, Center, Sub,
Side L/R and Rear L/R
Zone 2 Audio Outputs One Unbalanced (RCA, variable output level) stereo connector,
One Unbalanced (RCA, fixed output level) stereo connector,
One S/PDIF coaxial (RCA) connector and one optical (Toslink) con-
nector
Zone 3 Audio Outputs One Stereo (RCA, variable output level) connector
Headphone One Stereo (1/4-inch phone) connector
Amplifier Seven Channels, two channels assignable to Zone 2 or Zone 3
Performance (Main Zone)
Analog-to-Digital Conversion 24-bit, 44.1 to 192kHz, multi-bit ∆∑ architecture
Digital-to-Analog Conversion 24-bit, 44.1 to 192kHz, multi-bit ∆∑ architecture
Frequency Response* 20Hz to 20kHz, +0.1dB/-0.2dB, -0.5dB at 10Hz,
-0.5dB at 40kHz, reference 1kHz
THD + Noise* Below 0.02%, 20Hz to 20kHz, 140Wrms all channels driven
Dynamic Range* 105dB minimum, 22kHz bandwidth, “A” weighted
102dB minimum, 22kHz bandwidth, unweighted
Signal-to-Noise Ratio* 105dB minimum, 22kHz bandwidth, “A” weighted
102dB minimum, 22kHz bandwidth, unweighted
Input Sensitivity 200mVrms (2Vrms for maximum output level) at 0dB input gain
Input Impedance 100kΩin parallel with 150pF
Preamp Output Level 150mVrms typical, 3.5Vrms maximum (RCA connectors)
Maximum value with full-scale input signal and volume at +12dB
Preamp Output Impedance 500Ωin parallel with 150pF (RCA connectors)
Performance (Zone 2 and Zone 3)
Analog-to-Digital Conversion 24-bit, 44.1 to 192kHz, multi-bit ∆∑architecture (Zone 2 only)
Digital-to-Analog Conversion 24-bit, 44.1 to 192kHz, multi-bit ∆∑ architecture
Frequency Response 10Hz to 20kHz, +0.1dB/-0.25dB, -0.75dB at 40kHz, reference 1kHz
THD + Noise Below 0.005% at 1kHz, (1Vrms output level)
Dynamic Range 102dB minimum, 22kHz bandwidth
Signal-to-Noise Ratio 102dB minimum, 22kHz bandwidth
Input Sensitivity 200mVrms (4Vrms for maximum output level)
Input Impedance 100kΩin parallel with 150pF
Preamp Output Level 200mVrms typical, 4Vrms maximum; maximum value with
full-scale input signal and volume at 0dB
Preamp Output Impedance 300Ωin parallel with 150pF
Video Inputs and Outputs
Video Inputs Composite (RCA), five S-video and three component video (RCA)
Video Outputs Five Composite (RCA), (two monitor, two Zone2, one Zone3),
Four S-video (two monitor, two Zone2) and one component (RCA)
Performance (Composite & S-video)
Compatibility NTSC, PAL and SECAM
Switching Active
Output Level 1.0V peak-to-peak
Impedance 75Ω
Input Return Loss >40dB
Differential Gain <0.5%
Differential Phase <0.5°
Bandwidth >25MHz
KFactor <0.3%
Gain ±0.15dB
Signal-to-Noise Ratio >65dB
Frequency Response 10Hz to 10MHz + 0.1/-0.3dB
Performance (Component Video)
Compatibility 3-Channel (Y/Pb/Pr), format-independent
Switching Passive
Impedance 75Ω
Bandwidth >150MHz
Insertion Loss <3dB
Video Converter NTSC, PAL, SECAM to Y/Pb/Pr
Specifications
RV-8Specifications

Other
Trigger Outputs One Power on/off and one programmable connector on
detachable screw terminals (+12 VDC, 0.5 amps each)
RS-232 Serial Input/Output Two 9-pin D-sub connectors
Power Requirements 120/230 VAC, 50-60Hz, 1300W (universal line input),
detachable power cord
Dimensions & Weight
Height (with feet) 7.76 inches (197.1mm)
Width 17.3 inches (440mm)
Depth 21.2 inches (538.48mm)
Weight 65lb (29.48kg)
Rack Mounting Optional brackets are available for installation in a standard
19-inch equipment rack (four rack units required)
Environment Operating Temp: 0° to 35°C (32° to 95°F)
Storage Temp: -30° to 75°C (-22° to 167°F)
Relative Humidity: 95% maximum without condensation
Remote Control Hand-held, backlit infrared remote control unit,
preprogrammed & learning
Batteries: Requires four AAA batteries (alkaline batteries recommend-
ed)
Performance (FM Tuner)
Tuning Range 64MHz to 108MHz
Usable Sensitivity <4uV, 1.6uV typical
Selectivity >87dbmV, 93dbmV typical
Frequency Response 50Hz to 16kHz, +0.5dB/-2.0dB
THD + Noise Below 0.4% at 1 kHz (stereo)
Signal-to-Noise Ratio 50dB minimum at 60dBmV (stereo, A-Wtg)
Image Rejection >50dB, >60dB typical
AM Suppression >45dB, >55dB typical
Performance (AM Tuner)
Tuning Range 520 to 1720kHz
Usable Sensitivity <8uV, typ. 4uV
THD + Noise <0.56%, 0.32% typical (1kHz, 60dBmV, 30% mod)
Wideband AGC >80dBmV
Compatible Amplifier Connectors
Banana Plugs Standard0.75-inch plugs
Space Connectors Size 10-12 gauge
Bare Wire Up to 10 gauge bare wire
Specifications subject to change without notice.
