Lexicon I-ONIX U22 User manual

Don’t Sacrifice Your Music or Your Desktop
You care intensely about your music. It’s more than a pastime – it’s a passion.
Lexicon understands your passion and it inspires us to innovate. Brilliantly designed,
I·ONIX fits where it makes the most sense, between your keyboard and monitor. With all
the controls at your fingertips, you’ll wonder why no one ever thought of it before.
The innovation doesn’t stop on the outside. Lexicon partnered with dbx®to
design a new 60V high-voltage, ultra-low noise mic preamp into every input to provide
professional recordings that keep your music sounding its best. The preamps run on
a 60V supply to guarantee headroom and deliver a superior recording across a wide
dynamic range. Ultra high-definition converters ensure pristine 24-bit/96kHz audio to
capture every subtle nuance of your performance. In fact the inputs are so clear and
transparent, your recordings will have deeper lows , smoother highs, and an overall
fuller sound.
The Lexicon name is synonymous with “the world’s best reverb.” The
Pantheon™II VST/AU reverb plug-in features 6 reverbs types with 16 adjustable
parameters, and 35 factory presets that range from Vocal to Live Sound and Special
Effects. It’s easy to complete your mix and add depth and dimension to any track
with Lexicon’s exquisitely rich, full reverbs.
No compromise performance – ergonomic brilliance. Pure genius.
USB DESKTOP RECORDING STUDIOS
™
U22 / U42S / U82S KEY FEATURES
0USB 2.0 connection to DAW – up to 480Mbps
044.1 to 96kHz sample rates, 24-bit resolution
0Analog ¼” and XLR combi-jack inputs on
the rear panel for mic/line inputs
0dbx®60V high-voltage, ultra-low noise mic
preamp’s on all analog mic/line inputs
0+48V phantom power for each input pair
0Hi-Z instrument input(s)
0Input signal metering via 8 LED’s per channel
0Analog ¼” TRS (Stereo Main) outputs
0High-power ¼” headphone output(s)
0Patent-pending ergonomic design
0Signal mixing and stereo bus signal metering
0Zero latency monitoring
0Low latency ASIO drivers
0Lexicon Pantheon II VST/AU reverb plug-in
0Software suite includes Steinberg®’s Cubase®
LE4, and Toontrack®EZdrummer®Lite
0Supports Windows®Vista/XP and Mac®
I•ONIX DESKTOP RECORDING STUDIOS U22 /U42S /U82S
lexiconpro.com
©2009 All Rights Reserved, Harman International Industries Inc. Specifications are subject to change. Part Number: 18-0675
MICROPHONE INPUTS: Female XLR Pin 2 Hot
INPUT IMPEDANCE: 3kΩbalanced
PHANTOM POWER: +48 Volts
MAXIMUM GAIN: +58 dB
E.I.N. (AT MAX GAIN): −125 dBu @ 58dB gain typical (150Ωsource)
−128 dBu @ 58dB gain typical A-weighted
(150Ωsource)
MAXIMUM INPUT LEVEL: +20 dBu at minimum input gain
FREQUENCY RESPONSE: +0/−1.0 dB, 20Hz - 20kHz
THD+N: <0.01% 20Hz - 20kHz, +4 dBu input level, +4 dBu output
(mic input to main output)
<0.008% 1kHz, +4 dBu input level, +4 dBu output,
(mic input to main output)
LINE INPUTS: 1/4” TRS balanced or unbalanced
INPUT IMPEDANCE: 20kΩbalanced, 13kΩunbalanced
MAXIMUM INPUT LEVEL: +32 dBu
FREQUENCY RESPONSE: +0/−1.0 dB, 20Hz - 20kHz
THD+N: <0.015%, 20Hz - 20kHz, +4 dBu input level,
+4 dBu output (line input to main output)
<0.005%, 1 kHz, +4 dBu input level, +4 dBu output
INSTRUMENT INPUT: 1/4” TS unbalanced
INPUT IMPEDANCE: 1MΩ
MAXIMUM INPUT LEVEL: +13 dBu
FREQUENCY RESPONSE: +0/−1.0 dB, 20Hz - 20kHz
THD+N: <0.05%, 20Hz - 20kHz, +4 dBu input level,
+4 dBu output, (instrument input to main output)
<0.007%, 1 kHz, +4 dBu input level, +4 dBu output
LINE OUTPUTS: 1/4” TRS balanced or unbalanced
LEVEL: >+18 dBu maximum
IMPEDANCE: 32ΩBalanced, 16ΩUnbalanced
HEADPHONE OUTPUT: 1/4” stereo jack 350mW per channel at 50Ω
MIDI INTERFACE: 5 pin DIN connectors for MIDI in and MIDI out
SAMPLE RATE: 44.1, 48, 88.2, or 96 kHz (determined by computer
application)
DYNAMIC RANGE: A/D (24 Bit) 102 dB typical, A-weighted, 20Hz - 20kHz
D/A (24 Bit) 106 dB typical, A-weighted, 20Hz - 20kHz
A/D/A (24 Bit) 101 dB typical, A-weighted, 20Hz - 20kHz
POWER REQUIREMENTS: Power adaptors available for
100 – 240 VAC, 50/60 Hz,12 Watts (U22)
100 – 240 VAC, 50/60 Hz,18 Watts (U42S)
100 – 240 VAC, 50/60 Hz, 24 Watts (U82S)
SPECIfICaTIONS
Combi-Jack Analog Inputs 2 4 8
Simult. Recording Sources 2 6 10
dbx 60V Mic Preamps 2 4 8
Hi-Z Instrument Inputs 1 2 2
High-Power Headphone Outputs 1 2 2
1/4” TRS Analog Outputs 2 2 2
44.1 kHz to 96 kHz/24-bit QQQ
Stereo S/PDIF QQ
MIDI I/O QQQ
Pantheon II VST/AU QQQ
Reverb Plug-In
Cubase LE4 QQQ
ToonTrack EZdrummer Lite QQQ
U22 /U42S /U82S I•ONIX DESKTOP RECORDING STUDIOS
