OMEGA STUDIO BUNDLE COMPLETE DESKTOP RECORDING SOLUTION
Microphone Inputs (2) Female XLR Pin 2 Hot
Input Impedance 600Ωbalanced
Phantom Power +48 Volt DC
Gain +50dB
EIN (150Ωsource) –120dB A-weighted @ 50dB gain
Maximum Input Level +18dBu
Frequency Response +0, –0.2dB 20 Hz - 20kHz, ref. 1kHz
THD+N <.005%, 20Hz - 20kHz
Insert Inputs (2) 1
/
4" TRS
Send Level (tip) +19dBu maximum
Max Return Level (ring) +19dBu maximum
Line Inputs (4) 1
/
4" TRS balanced or unbalanced
Input Impedance 20kΩbalanced, 10kΩunbalanced
Maximum Input Level +22dBu
Frequency Response +0, –0.2dB 20 Hz - 20kHz, ref. 1kHz
THD+N <.009% A/D, 20Hz - 20kHz
Instrument Input (1) 1
/
4" mono jack
Input Impedance 1 MΩunbalanced
Maximum Input Level +19dBu
Frequency Response +0, –0.25 dB 20 Hz - 20kHz, ref. 1kHz
THD+N <.0125% A/D
Crosstalk <–74dB any input or output to any
recording channel, 20Hz-20kHz
<–95dB at 1kHz typical
Line Outputs (2) 1
/
4" TRS balanced or unbalanced
Level +19dBu maximum
Impedance 110Ω
Headphone Output (1) 1
/
4” stereo jack
100 mW per channel at 50Ω
MIDI Interface MIDI IN/MIDI OUT - 5 pin DIN
Digital Audio Input Coaxial RCA (S/PDIF format)
Digital Audio Output Coaxial RCA (S/PDIF format)
always transmits the audio data
from the USB stream
D/A- A/D Sample Rate 44.1 kHz or 48 kHz (determined
by computer application)
Dynamic Range, 20Hz-20kHz:
A/D (24 Bit) 104dB typical, A-weighted
D/A (24 Bit) 105dB typical, A-weighted
A/D/A (24 Bit) 103dB typical, A-weighted
Analog Path 118dB typical, A-weighted
USB Type B Socket Version 1.1, Version 1.1 hubs are
not supported
Power Requirements PS0913-B 9VAC adapter supplied
requires 18W at 120V
Dimensions 4.625” W x 7.25” H x 7.75” D
(118mm x 184mm x 197mm)
Weight 2 .65 lbs. (1.2 kg)
www.lexiconpro.com
VST Reverb Plug-In
35 factory presets•
6 reverb types•
16 editable parameters•
per reverb type
Mono & stereo operation•
Advanced, yet easy-to-use•
interface
Efficient CPU utilization•
16 and 24-bit compatible•
48 audio and 64 MIDI tracks•
Professional audio editing - cut,•
paste, copy and loop song tracks
A wealth of built-in signal pro-•
cessing features like Chorus,
Gating and EQ
Full automation of volume, pan, mute and effects for•
professional-sounding mixdown
MIDI score editor and advanced quantization and logical presets•
Supports up to 8 VST instruments•
2 insert and 4 effect sends per channel•
VST system link and ReWire 2 compatible•
Multi-Track Recording Software
®
D 88 S Microphone
Polar Pattern supercardioid
Sensitivity 25 mV/Pa (-52 dbV)
Impedance 300Ω
Finish Zinc/alloy diecast
Weight 0.57 lbs (260 g)
®
