Lexicon MC-12 V1.1 - S REV 1 Instruction Manual

MC-12 Software Version 1.1
Release & Errata Notes

DOCUMENTATION CONVENTIONS
This document is a supplement to the MC-12 User Guide (Rev 1). It contains release notes that provide information about the new and
enhanced features of Software Version 1.1. It also includes errata notes for the MC-12 User Guide (Rev 1). Refer to the user guide for
general safety, installation, and operating instructions.
The following symbols are used in this document:
Calls attention to a procedure, practice, condition, or the like that, if not correctly performed or adhered to, could
result in damage or destruction to part or all of the product.
Note: Calls attention to information that is essential to highlight.
Represents a menu path. The selections in grey boxes must be made to reach the menu or parameter in the black
box. In the example above, the SETUP, INPUTS, DVD1, and NAME selections must be made to reach the DVD1
INPUT NAME menu. DVD1 is used as an example throughout these release notes. Whenever it appears in a menu
path, any other input (e.g. DVD2) may be substituted.
Manufactured under license from Dolby Laboratories. “Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby laboratories.
Lucasfilm and THX are trademarks or registered trademarks of Lucasfilm, Ltd.
© Lucasfilm, Ltd. & TM. Surround EX is a jointly developed technology of THX and Dolby Laboratories, Inc. and is a trademark of Dolby Laboratories, Inc. All rights
reserved. Used under authorization.
Manufactured under license from Digital Theater Systems, Inc. U.S. Pat. No. 5,451,942; 5,956,674; 5,974,380; 5,978,762 and other world-wide patents issued and
pending. “DTS”, “DTS-ES Extended Surround” and “Neo:6” are trademarks of Digital Theater Systems, Inc. © 1996, 2000 Digital Theater Systems, Inc. All rights
reserved.
Lexicon, LOGIC7, and the LOGIC7 symbol are registered trademarks of Lexicon, Inc., a Harman International
Company.© 2002 Lexicon, Inc. All rights reserved.
This document should not be construed as a commitment on the part of Lexicon, Inc. The information it contains is subject to change without notice. Lexicon, Inc.
assumes no responsibility for errors that may appear within this document.
SETUP INPUTS DVD1 NAME
Lexicon, Inc.
3 Oak Park
Bedford, MA 01730-1441 USA
Tel [phone]
Fax [phone]
www.lexicon.com
Customer Support
Tel [phone]
Fax [phone] (Sales)
Fax [phone] (Service)
Lexicon Part No. 070-14710 | Rev 1 | 04/02
DVD1 INPUT NAME
CAUTION

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
3
Revised INPUT SETUP Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5.1a. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ZONE2 IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
RECORD IN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
New Listening Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
dts NEO:6 FILM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
dts NEO:6 MUSIC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.1a L7 FILM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.1a L7 MUSIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.1a THX SurEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.1a STANDARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.1a 2-CHANNEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Revised Listening Mode STATUS Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
New Listening Mode Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Errata Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Revised Menu Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Revised Installation Worksheet (1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Revised Installation Worksheet (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Software Version 1.1 Release & Errata Notes Lexicon
4
ZONE2 IN (ANLG, DIGITAL, DMIX)
The ZONE2 IN parameter replaces the INPUT SELECT parameter
that was available on the ZONE 2 ADV menu. (The ZONE 2 ADV
menu is no longer available.) It can be used to select the input
source for the ZONE 2 AUDIO OUTPUTS.
When set to ANLG . . .
• The ANALOG IN connector specified in the INPUT SETUP menu
is sent to the ZONE 2 AUDIO OUTPUTS.
• The 5.1 analog input is not compatible with the ZONE 2
AUDIO OUTPUTS.
• Audio will not be available in Zone 2 when the 5.1 analog
input is selected for the Main Zone. However, audio will be
available in Zone 2 when the 5.1a BYPASS listening mode is
selected for the Main Zone.
REVISED INPUT SETUP MENUS
The INPUT SETUP menus (such as the DVD1 INPUT SETUP menu
pictured above) now include 5.1a, ZONE2 IN, and RECORD IN
parameters.
5.1a
Selecting 5.1a accesses the 5.1a MODE menu (pictured above),
which can be used to select a preferred listening mode for 5.1
analog input sources. Descriptions of the new 5.1a listening modes
begin on page 8.
SETUP INPUTS DVD1 5.1a
SETUP INPUTS DVD1 ZONE2 IN
DVD1 INPUT SETUP
NAME DVD1
DIGITAL IN COAX-1
ANALOG IN NONE
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-1
COMPONENT IN 1
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN DIGITAL
RECORD IN DIGITAL
RECORD ADVANCED
INPUT SETUP
DVD1
DVD2
LD
TV
SAT
VCR
CD
PVR
GAME
TAPE
TUNER
AUX
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
The DVD1 INPUT SETUP menu is used here as an example,
and will continue to be used as an example throughout this
document. The parameters on the left side of the on-screen
display are identical regardless of which input is selected. The
values on the right side are adjustable.
Likewise, whenever “DVD1” appears in a menu path, any
other input may be substituted.
DVD1 5.1a MODE
5.1a FILM
5.1a MUSIC
5.1a SurEX
5.1a STANDARD
5.1a 2-CHANNEL
USE LAST

DVD1 INPUT SETUP
NAME DVD1
DIGITAL IN COAX-1
ANALOG IN NONE
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-1
COMPONENT IN 1
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN
DIGITAL
RECORD ADVANCED
Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
5
INPUT SETUP
DVD1
DVD2
LD
TV
SAT
VCR
CD
PVR
GAME
TAPE
TUNER
AUX
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
The DVD1 INPUT SETUP menu is used here as an example,
and will continue to be used as an example throughout this
document. The parameters on the left side of the on-screen
display are identical regardless of which input is selected. The
values on the right side are adjustable.
Likewise, whenever “DVD1” appears in a menu path, any
other input may be substituted.
When set to DIGITAL . . .
• The DIGITAL IN connector specified in the INPUT SETUP menu
is sent to the ZONE 2 AUDIO OUTPUTS.
• Only PCM digital input sources are compatible with the ZONE
2 AUDIO OUTPUTS.
• Audio will not be available in Zone 2 when a Dolby Digital,
dts(-ES), or unknown digital input source is present.
When set to DMIX . . .
• A 2-channel downmixed version of Main Zone audio is sent to
the ZONE 2 AUDIO OUTPUTS. Downmixes can be generated
for Dolby Digital, dts(-ES), and 5.1 analog input sources. To
generate a downmix, the input that is selected in Zone 2 must
also be selected in the Main Zone (e.g. DVD1). Otherwise, the
ZONE 2 AUDIO OUTPUTS will mute. Downmixes cannot be
generated when the 5.1a BYPASS listening mode is selected in
the Main Zone.
• It is recommended to set the ZONE2 IN parameter to DMIX
when recording from a DVD player without built-in Dolby
Digital or dts(-ES) decoding to a VCR or PVR (i.e. Tivo® or
Replay TV®).
Note:
For Dolby Digital input sources, it is recommended to
set the ZONE2 IN parameter to analog. For dts(-ES)
input sources, it is recommended to set the ZONE2 IN
parameter to DMIX. When set to DIGITAL, the unit
recognizes dts-encoded CDs as audio signals (not
data signals) and outputs loud digital noise from the
ZONE 2 AUDIO OUTPUTS .
Note:
If the INPUT SELECT parameter on the
ZONE 2 ADV menu is set to AUTO in
Software Version 1.0, the ZONE2 IN
parameter will be set to DMIX when
Software Version 1.1 is installed. In
Software Version 1.0, the INPUT SELECT
parameter defaults to the AUTO setting
for the LD, TV, SAT, PVR, GAME, and TAPE
inputs. If the default setting has not been
changed, the ZONE2 IN parameter will
automatically be set to DMIX for these
inputs when the new software is installed.

DVD1 INPUT SETUP
NAME DVD1
DIGITAL IN COAX-1
ANALOG IN NONE
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-1
COMPONENT IN 1
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN
RECORD IN
DIGITAL
Software Version 1.1 Release & Errata Notes Lexicon
6
• Analog input sources are sent to the analog-to-digital
converter, then the RECORD AUDIO OUTPUT labelled S/PDIF.
When set to DIGITAL . . .
• The DIGITAL IN connector specified in the INPUT SETUP menu
is sent to the RECORD AUDIO OUTPUTS.
• Only PCM digital input sources are compatible with the
RECORD AUDIO OUTPUTS.
• Audio will not be available in the Record Zone when a Dolby
Digital, dts(-ES), or unknown digital input source is present.
When set to DMIX . . .
• A 2-channel downmixed version of Main Zone audio is sent to
the RECORD AUDIO OUTPUTS. Downmixes can be generated
for Dolby Digital, dts(-ES), and 5.1 analog input sources. To
generate a downmix, the input that is selected in the Record
Zone must also be selected in the Main Zone (e.g. DVD1).
RECORD IN (ANLG, DIGITAL, DMIX)
The RECORD IN parameter replaces the INPUT SELECT parameter
that was available on the RECORD ADV menu. (Other RECORD
ADV menu parameters are still available.) It can be used to select
the input source for the RECORD AUDIO OUTPUTS.
When set to ANLG . . .
• The ANALOG IN connector specified in the INPUT SETUP menu
is sent to the RECORD AUDIO OUTPUTS.
• The 5.1 analog input is not compatible with the RECORD
AUDIO OUTPUTS. Audio will not be available in the Record
Zone when the 5.1 analog input is selected for the Main Zone.
• The RECORD AUDIO OUTPUTS are not available if a 5.1a
listening mode is selected in the Main Zone. However, audio
will be available in the Record Zone when the 5.1a BYPASS
listening mode is selected for the Main Zone.
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
The DVD1 INPUT SETUP menu is used here as an example,
and will continue to be used as an example throughout this
document. The parameters on the left side of the on-screen
display are identical regardless of which input is selected. The
values on the right side are adjustable.
Likewise, whenever “DVD1” appears ºin a menu path, any
other input may be substituted.
INPUT SETUP
DVD1
DVD2
LD
TV
SAT
VCR
CD
PVR
GAME
TAPE
TUNER
AUX
SETUP INPUTS DVD1 RECORD IN
Note:
If the INPUT SELECT parameter on the
RECORD ADV menu is set to AUTO in
Software Version 1.0, the RECORD IN
parameter will be set to DMIX when
Software Version 1.1 is installed. In
Software Version 1.0, the INPUT SELECT
parameter defaults to the AUTO setting
for the LD, TV, SAT, PVR, GAME, and TAPE
inputs. If the default setting has not been
changed, the RECORD IN parameter will
automatically be set to DMIX for these
inputs when the new software is installed.

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
7
Otherwise, the RECORD AUDIO OUTPUTS will mute.
Downmixes cannot be generated when the 5.1a BYPASS
listening mode is selected in the Main Zone.
• It is recommended to set the RECORD IN parameter to DMIX
when recording from a DVD player without built-in Dolby
Digital or dts(-ES) decoding to a VCR or PVR (i.e. Tivo® or
Replay TV®).
Note:
For Dolby Digital input sources, it is recommended to
set the RECORD IN parameter to analog. For dts(-ES)
input sources, it is recommended to set the RECORD
IN parameter to DMIX. When set to DIGITAL, the
unit recognizes dts-encoded CDs as audio signals
(not data signals) and outputs loud digital noise from
the RECORD AUDIO OUTPUTS .
NEW LISTENING MODES
New listening modes are available for PCM and 5.1 analog input
sources. The 5.1 analog listening modes are only available when
using the 5.1 analog input with analog-to-digital conversion and
internal processing. Descriptions of these listening modes begin in
the next column. An alphabetical glossary of listening mode
parameters begins on page 11 of this document and on page 5-20
of the MC-12 User Guide (Rev 1).
Note:
The 5.1 BYPASS listening mode is now called the 5.1a
BYPASS listening mode.
dts NEO:6 FILM
• Designed for playback of matrix-encoded PCM digital stereo
film sources.
• Systems that include side and rear channels will derive six
separate channels (rear channels will be in parallel) and
systems with only side or rear channels will derive five separate
channels. The .1 subwoofer channel is generated through bass
management in the unit.
Parameter
OUTPUT LEVELS See page 5-17 for more information*
CUSTOM See page 5-17 for more information*
* Refers to the MC-12 User Guide (Rev 1).
An alphabetical glossary of listening mode parameters begins on
page 11 of this document and on page 5-20 of the MC-12 User Guide
(Rev 1).
Note:
dts NEO:6 FILM is not included on the 2-CH MODE
menu. This listening mode is available with 44.1kHz
and 48kHz PCM digital input sources. It is not
available with analog input sources.
MODE ADJUST FILM
R

Software Version 1.1 Release & Errata Notes Lexicon
8
5.1a L7 FILM
• A proprietary Lexicon listening mode.
• Designed for playback of 5.1 analog film sources.
• Converts the 5.1 analog input into digital audio for internal
LOGIC7 decoding.
• Derives seven channels from the 5.1 analog input.
• Allows the 5.1 analog input to utilize bass management, audio
controls, crossovers, and speaker distance calibration.
Default
Parameter Value Values
VOCAL ENHANCE +0.0dB +0.0dB, +3.0dB, +6.0dB
5 SPKR ENHANCE ON ON, OFF
BASS ENHANCE OFF ON, OFF
RE-EQUALIZER ON ON, OFF
REAR DLY OFFSET 15ms OFF, 0 to 30ms
LFE MIX +0.0dB -10.0 to +0.0dB
OUTPUT LEVELS See page 5-17 for more information*
CUSTOM See page 5-17 for more information*
* Refers to the MC-12 User Guide (Rev 1).
An alphabetical glossary of listening mode parameters begins on
page 11 of this document and on page 5-20 of the MC-12 User Guide
(Rev 1).
dts NEO:6 MUSIC
• Designed for playback of non-matrix-encoded PCM digital
stereo music sources.
• Systems that include side and rear channels will derive six
separate channels (rear channels will be in parallel) and
systems with only side or rear channels will derive five separate
channels. The .1 subwoofer channel is generated through bass
management in the unit.
Parameter
OUTPUT LEVELS See page 5-17 for more information*
CUSTOM See page 5-17 for more information*
* Refers to the MC-12 User Guide (Rev 1).
An alphabetical glossary of listening mode parameters begins on
page 11 of this document and on page 5-20 of the MC-12 User Guide
(Rev 1).
Note:
dts NEO:6 MUSIC is not included on the 2-CH MODE
menu. This listening mode is available with 44.1kHz
and 48kHz PCM digital input sources. It is not
available with analog input sources.
MODE ADJUST MUSIC
R
MODE ADJUST 5.1a FILM

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
9
5.1a L7 MUSIC
• A proprietary Lexicon listening mode.
• Designed for playback of 5.1 analog music sources.
• Converts the 5.1 analog input into digital audio for
internal LOGIC7 decoding.
• Derives seven channels from the 5.1 analog input.
• Allows the 5.1 analog input to utilize bass management, audio
controls, crossovers, and speaker distance calibration.
Default
Parameter Value Values
VOCAL ENHANCE +0.0dB +0.0dB, +3.0dB, +6.0dB
5 SPKR ENHANCE ON ON, OFF
BASS ENHANCE OFF ON, OFF
RE-EQUALIZER OFF ON, OFF
REAR DLY OFFSET 15ms 0 to 30ms, OFF
LFE MIX +0.0dB -10.0 to +0.0dB
OUTPUT LEVELS See page 5-17 for more information*
CUSTOM See page 5-17 for more information*
* Refers to the MC-12 User Guide (Rev 1).
An alphabetical glossary of listening mode parameters begins on
page 11 of this document and on page 5-20 of the MC-12 User Guide
(Rev 1).
5.1a THX SurEX
• Designed for playback of 5.1 analog film sources.
• Converts the 5.1 analog input into digital audio for
internal THX processing, allowing the 5.1 analog input to utilize
Surround EX decoding, re-equalization, bass management,
audio controls, crossovers, and speaker distance calibration.
Default
Parameter Value Values
RE-EQUALIZER ON ON, OFF
SURROUND EX ON AUTO, ON, OFF
LFE MIX +0.0dB -10.0 to +0.0dB
OUTPUT LEVELS See page 5-17 for more information*
CUSTOM See page 5-17 for more information*
* Refers to the MC-12 User Guide (Rev 1).
An alphabetical glossary of listening mode parameters begins on
page 11 of this document and on page 5-20 of the MC-12 User Guide
(Rev 1).
MODE ADJUST 5.1a MUSIC MODE ADJUST 5.1a SurEX

Software Version 1.1 Release & Errata Notes Lexicon
10
5.1a 2-CHANNEL
• Designed for recording 5.1 analog sources to stereo recording
devices.
• Converts the 5.1 analog input into digital audio, using a
LOGIC7-encoding process to downmix it to two channels. This
is recommended for recording from a DVD-A or multi-channel
SACD player to a CD-R.
Default
Parameter Value Values
CENTER MIX +0dB -25 to +5dB
SURROUND MIX +0dB -5 to +5dB
CNTR DLY SAMPLES +0 -127 to +127
MASTER LEVEL +0dB -5 to +5dB
LFE MIX +0.0dB -10.0 to +0.0dB
SUB L/R LVL +0dB OFF, -30 to +12dB
CUSTOM See page 5-17 for more information*
* Refers to the MC-12 User Guide (Rev 1).
An alphabetical glossary of listening mode parameters begins on
page 11 of this document and on page 5-20 of the MC-12 User Guide
(Rev 1).
5.1a STANDARD
• Designed for playback of 5.1 analog sources.
• Converts the 5.1 analog input into digital audio for
internal processing. This allows the 5.1 analog input to utilize
bass management, audio controls, crossovers, and speaker
distance calibration. When these features are not utilized, this
listening mode is similar to the 5.1a BYPASS listening mode.
• Sends identical signals (with appropriate time delay) to the
SIDE L and REAR L outputs, as well as the SIDE R and REAR R
outputs.
Default
Parameter Value Values
OUTPUT LEVELS See page 5-17 for more information*
CUSTOM See page 5-17 for more information*
* Refers to the MC-12 User Guide (Rev 1).
An alphabetical glossary of listening mode parameters begins on
page 11 of this document and on page 5-20 of the MC-12 User Guide
(Rev 1).
MODE ADJUST 5.1a STANDARD MODE ADJUST 5.1a 2-CHANNEL

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
11
REVISED LISTENING MODE STATUS MENUS
A second page has been added to the DOLBY D and dts(-ES)
STATUS menus to accommodate the addition of several new
parameters. STATUS menus can still be accessed with the remote
control. Press the SHIFT button, then the STAT button to access the
first page of the STATUS menu for the active listening mode. Press
the STAT button a second time to access the second page of the
menu. Press the STAT button a third time to exit the menu. (If the
STATUS menu does not include a second page, pressing the STAT
button a second time will exit the menu.)
The 5.1 BYPASS listening mode is now called the 5.1a BYPASS
listening mode. Likewise, the 5.1 BYPASS STATUS menu is now
called the 5.1a BYPASS STATUS menu. Level meters are no longer
available on the 5.1a BYPASS STATUS and 2CH BYPASS STATUS
menus.
An alphabetical glossary of listening mode parameters begins in
the next column and on page 5-20 of the MC-12 User Guide in the
next column. An alphabetical glossary of all listening mode
parameters begins on page 5-20 of the MC-12 User Guide (Rev 1).
Note:
Remote control MENU arrows can be used to scroll
listening mode STATUS menu parameters when the
MAIN command bank is active. STATUS menu
parameters are not adjustable.
NEW LISTENING MODE PARAMETERS
This glossary contains additions and revisions to the listening mode
parameter descriptions that appear on page 5-20 of the MC-12
User Guide (Rev 1).
2.0 ENCODING (MATRIX, NONE)
The 2.0 ENCODING parameter has been added to the
DOLBY D STATUS menu. When the parameter value is MATRIX,
matrix-encoding is present in the input signal. When the parameter
value is NONE, no matrix-encoding is present in the input signal.
BIT RATE (32 to 3072kbps)
The BIT RATE parameter has been added to the DOLBY D and
dts(-ES) STATUS menus. It indicates the rate at which the input
signal is encoded. A higher bit rate indicates that less compression
was used during the encoding process.
CENTER MIX LVL (-3.0dB, -4.5dB, -6.0dB)
The CENTER MIX LVL parameter has been added to the DOLBY D
STATUS menu. It indicates the relative level of the center channel
that was used during the mixing process.
DIALOG OFFSET (-31 to 0dB)
The DIALOG OFFSET parameter has been added to the DOLBY D
STATUS menu. It indicates the dialog normalization value applied
to the input signal. Dolby Digital input sources reproduce dialog
at 31 decibels below full-scale (-31dBFS). When the dialog
normalization value of the incoming signal is higher or lower, the
DIALOG OFFSET parameter indicates the amount of adjustment
the unit makes to normalize dialog to -31dBFS.
. . . New Listening Mode Parameters continues on page 12
STAT
SHIFT
then

Software Version 1.1 Release & Errata Notes Lexicon
12
MIX ROOM (SMALL, LARGE)
The MIX ROOM parameter has been added to the DOLBY D
STATUS menu. It indicates the size of the mixing room that was
used. When the parameter value is LARGE, it is recommended to
set the RE-EQUALIZATION parameter for the selected listening
mode to ON (if available).
SURR ROLLOFF (500Hz to 20kHz)
When the SURR ROLLOFF (Surround Rolloff) parameter is set
within its 500Hz to 20kHz range, the unit applies a high-
frequency rolloff to the SIDE L/R and REAR L/R outputs. This rolloff
is only applied to output signals generated by the unit. Signals
above the rolloff that are part of the source recording are passed
through without filtering.
SURROUND EX (AUTO, ON, OFF)
The SURROUND EX parameter provides control of the Surround EX
decoding feature. When set to AUTO, the unit engages Surround
EX decoding for flagged Surround EX input sources. When set to
ON, the unit forces Surround EX decoding for all input sources.
When set to OFF, the unit does not engage Surround EX decoding
for any input sources.
SURROUND MIX LVL (+0.0dB, -3.0dB, -6.0dB)
The SURROUND MIX LVL parameter has been added to the DOLBY
D STATUS menu. It indicates the relative level of surround channels
that were used during the mixing process.
WORD LENGTH (16bits, 20bits, 24bits)
The WORD LENGTH parameter has been added to the dts(-ES)
STATUS menu. It indicates the word length of the audio data
present in the input signal.
New Listening Mode Parameters (continued from page 11)
ES DECODING (AUTO, ON, OFF)
The ES DECODING parameter has been added to the dts(-ES) L7
FILM, dts(-ES) L7 MUSIC, dts(-ES) THX, dts(-ES), and dts(-ES)
2-CHAN listening mode menus. It provides control of the ES
decoding feature. When set to AUTO, the unit engages ES
decoding for flagged dts-ES input sources. When set to ON, the
unit forces ES decoding for all dts input sources. When set to OFF,
the unit does not engage ES decoding for any dts input sources.
Note:
When the ES DECODING parameter is set to ON for
dts 5.1-channel input sources, the SB level meter will
appear on the dts(-ES) STATUS menu.
ES ENCODING (DISCRETE, MATRIX, NONE)
The ES DECODE parameter on the dts(-ES) STATUS menu is now
called the ES ENCODING parameter. When the parameter value is
DISCRETE, a discrete 6.1-channel input source is present. When the
parameter value is MATRIX, a matrix 6.1-channel input source is
present. When the parameter value is NONE, a standard dts input
source with no ES encoding is present.
EX ENCODED (YES, NO)
The EX ENCODED parameter has been added to the DOLBY D
STATUS menu. When the parameter value is YES, the input source
is flagged for Dolby Digital EX encoding. When the parameter
value is NO, the input source is not flagged for Dolby Digital EX
encoding. Dolby Digital EX-encoded input sources that have not
been properly flagged cannot be automatically detected.

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
13
ERRATA NOTES
The errata notes listed below reflect additions and modifications to
the MC-12 User Guide (Rev 1) based on Software Version 1.1.
These errata notes replace the MC-12/MC-12 Balanced Errata
Notes (Rev 0).
1. When switching audio formats, the unit will mute momentarily
under certain conditions until the new audio format is
recognized.
2. When switching audio formats, some DVD players will produce
audio artifacts.
3. The unit does not decode MPEG-encoded input signals. When
an MPEG input source is present:
• The unit will not switch to the ANALOG IN connector
when the INPUT SELECT parameter on the MAIN ADV
menu is set to AUTO.
• The ZONE 2 AUDIO OUTPUTS will mute when the ZONE2
IN parameter on the INPUT SETUP menu is set to DIGITAL
or DMIX.
• The RECORD AUDIO OUTPUTS will mute when the
RECORD IN parameter on the INPUT SETUP menu is set to
DIGITAL or DMIX.
4. When a Dolby Digital input source is sent to
the RECORD AUDIO OUTPUTS, toggling the
setting of the DIGITAL BYPASS parameter on
the RECORD ADV menu will cause a loud burst
of digital noise. It is recommended to stop the
Dolby Digital input source before toggling the
parameter setting.
5. To accommodate THX level requirements, the MAIN AUDIO
OUTPUTS labeled FRONT L/R are about 2dB lower than the
ZONE 2 and RECORD AUDIO OUTPUTS when an analog input
source is present and about 8dB lower than the ZONE 2 and
RECORD AUDIO OUTPUTS when a digital input source is
present. The ZONE 2 and RECORD AUDIO OUTPUTS are the
same as the input signal.
6. When the 5.1 analog input is selected, speaker setup menu
parameters set to NONE on the CUSTOM SETUP or THX SETUP
menu will not be redirected to other channels. It is
recommended that DVD-A and SACD players are set up with
the same speaker configuration as the MC-12/MC-12
Balanced.
7. When the INTERNAL NOISE TEST is in process, it is possible
to manually select a speaker just as the unit is about to
automatically scroll to that speaker. This might cause the unit
to send the noise signal to both outputs. If this occurs, reselect
the desired speaker.
8. Toggling the setting of the SURROUND EX parameter produces
low-level clicks in the front speakers.
9. When the DIG OUT RATE parameter setting is adjusted,
the RECORD AUDIO OUTPUT labelled S/PDIF will mute
momentarily – even if the DIGITAL BYPASS parameter is set to
ON. The DIG OUT RATE and DIGITAL BYPASS parameters are
located on the RECORD ADV menu.
. . . Errata Notes continue on page 14
CAUTION

Software Version 1.1 Release & Errata Notes Lexicon
14
15. The level meters on the ANLG IN LVL menu might not indicate
accurate input levels when a 5.1 analog input source is present
and the ANALOG BYPASS parameter on the MAIN ADV menu
is set to ON.
16. The level meters on the ANLG IN LVL menu and the listening
mode STATUS menus appear in combinations of green, yellow,
and red when the on-screen display has a blue-screen
background. Green indicates low input levels, yellow indicates
normal input levels, and red indicates the onset of overload.
17. References to the INPUT GAIN parameter on page 3-7 of the
MC-12 User Guide (Rev 1) refer to the AUTO GAIN parameter
on the ANLG IN LVL menu.
18. The factory-default setting of the COMPONENT OSD
parameter on the MAIN ADV menu is OFF. When set to ON,
the component on-screen display appears on a full blue-screen
background. See page 3-14 of the MC-12 User Guide (Rev 1).
19. When the REAR L/R parameter on the CUSTOM SETUP menu is
set to NONE, the unit redirects rear channel signals to the SIDE
L/R outputs. See page 3-21 of the MC-12 User Guide (Rev 1).
20. The SUB LIMITERS menu has been renamed the BASS PEAK
LIMITERS menu. The menu and its parameters still function as
described on pages 3-28 and 3-29 of the MC-12 User Guide
(Rev 1).
21. The MONO listening mode menu has been updated to include
a SUB L/R LVL parameter and a CUSTOM menu option. This
menu is shown on page 21 of this document.
Errata Notes (continued from page 13)
10. When the MAIN command bank is selected, pressing the 7/5
button on the remote control will not toggle between 7 and
5-channel playback if the REAR L/R or SIDE L/R parameters on
the CUSTOM SETUP menu are set to NONE. The message,
"FEATURE UNAVAILABLE DUE TO CONFIGURATION" will
appear on the on-screen and front panel displays.
11. When the SHIFT command bank is selected, pressing the THX
button on the remote control selects the appropriate THX
listening mode for the current input. Pressing the THX button
again adjusts the SURROUND EX parameter, cycling through
the AUTO, ON, and OFF settings.
12. When the SHIFT command bank is selected, pressing the dts
button on the remote control selects the appropriate dts(-ES)
listening mode for the current input. Pressing the dts button
again adjusts the ES DECODING parameter, cycling through
the AUTO, ON, and OFF settings.
13. The ANLG IN LVL parameter on the RECORD ADV menu affects
the digital RECORD AUDIO OUTPUT labelled S/PDIF. This
parameter prevents the internal analog-to-digital converter
from overloading. It can be adjusted while listening to an input
source.
14. The level meters on the ANLG IN LVL menu indicate signal
levels for the selected input, whether an analog or digital input
source is present. For example, the level meters will indicate
digital input signal levels when a digital input source is present.

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
15
21. The 5.1 MONO, 5.1 MONO LOGIC, and 5.1 MONO SURR
listening modes are designed for playback of Dolby Digital
mono input sources. When a Dolby Digital 1.0 input source is
present, the unit will automatically select the 5.1 MONO
LOGIC listening mode. The unit will not automatically select
5.1 MONO LOGIC for other Dolby Digital mono input sources.
22. The rear panel TRIGGER OUTPUTS will be deactivated when
the unit is placed into standby. However, when the TRIGGER
parameters on the TRIGGER SETUP menu are set to REMOTE
ONLY, the corresponding TRIGGER OUTPUT will not be
activated when the unit is powered on. Instead, this TRIGGER
OUTPUT must be activated using the remote control
commands described on page 2-12 of the MC-12 User Guide
(Rev 1).
23. The Mute button LED lights whenever mute is activated, either
automatically or manually. For example, the unit will briefly
activate mute when switching input sources or listening
modes.
24. When the preferred listening mode selection parameters on
the INPUT SETUP menu are set to USE LAST, the unit will revert
to the previously-selected listening mode when the current
input is deselected, then reselected. However, when the
2-CHANNEL listening mode is selected with the 2CH button on
the remote control, the unit will revert to the listening mode
that was selected prior to the 2-CHANNEL listening mode.

Software Version 1.1 Release & Errata Notes Lexicon
16
REVISED MENU TREE
The menu tree that begins below replaces the menu tree that begins on page A-5 of the MC-12 User Guide (Rev 1).
MAIN MENU
MODE ADJUST
AUDIO CONTROLS
SETUP
SETUP
INPUTS
SPEAKERS
REAR PANEL CONFIG
DISPLAYS
VOLUME CONTROLS
TRIGGERS
LOCK OPTIONS
AUDIO CONTROLS
BASS +0.0dB
TREBLE +0.0dB
TILT EQ +0.0dB
LOUDNESS OFF
BALANCE <|>
FADER <|>
ZONE2 BALANCE <|>
RECORD BALANCE <|>
SPEAKER SETUP
CUSTOM SETUP
THX SETUP
SPEAKER DISTANCES
LEVELS CALIBRATION
INPUT SETUP
DVD1
DVD2
LD
TV
SAT
VCR
CD
PVR
GAME
TAPE
TUNER
AUX
REAR PANEL CONFIG
8 STEREO INPUTS
OR
5 STEREO & 5.1 ANLG
DISPLAY SETUP
ON-SCREEN DISPLAY
FRONT PANEL DISPLAY
A/V SYNC DELAY OFF
CUSTOM NAME OFF
EDIT CUSTOM NAME
VOLUME CONTROL SETUP
MAIN PWR ON -30dB
MUTE LEVEL -30dB
ZONE PWR ON -30dB
REC PWR ON -30dB
TRIGGER SETUP
TRIGGER 1 REMOTE
TRIGGER 2 REMOTE
LOCK OPTIONS
MODES UNLOCKED
AUDIO CNTRL UNLOCKED
SETUP UNLOCKED
Continued on page 17
Continued on page 20
Continued on page 21
Continued on page 19
Continued on page 20
MODE ADJUST
FILM
TV
MUSIC
PL II
PRO LOGIC II
PL II MUSIC
PRO LOGIC
FILM
MUSIC
2-CH SURROUND
2-CHANNEL
MONO LOGIC
MONO SURROUND
MONO
5.1 FILM
5.1 TV
5.1 MUSIC
5.1 SurEX
DIGITAL
5.1 2-CHANNEL
5.1 MONO LOGIC
5.1 MONO SURR
5.1 MONO
FILM
MUSIC
2-CHAN
5.1a FILM
5.1a MUSIC
5.1a SurEX
5.1a STANDARD
5.1a 2-CHANNEL
5.1a BYPASS
2CH BYPASS
R
R
40Hz 40Hz
40Hz 60Hz 60Hz
60Hz 60Hz
60Hz
L
M
SUB
R
C
SL
SR
RL
RR

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
17
INPUT SETUP
DVD1
DVD2
LD
TV
SAT
VCR
CD
PVR
GAME
TAPE
TUNER
AUX
The menu pictured at the left prompts the selection of the desired input for configuration. Selecting an input
accesses the corresponding INPUT SETUP menu pictured below. The parameters on the left side of this menu are
identical regardless of which input is selected. The values on the right side of this menu can be adjusted. Selecting a
parameter for adjustment accesses the corresponding menu on the next page.
CD INPUT SETUP
NAME CD
DIGITAL IN COAX-4
ANALOG IN NONE
ANLG IN LVL AUTO
VIDEO IN COMPOSITE-1
COMPONENT IN 1
2-CH MUSIC
D 5.1 MUSIC
MUSIC
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN DIGITAL
RECORD IN DIGITAL
RECORD ADVANCED
PVR INPUT SETUP
NAME PVR
DIGITAL IN OPTICAL-3
ANALOG IN ANALOG-5
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-7
COMPONENT IN 1
2-CH TV
D 5.1 TV
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN DIGITAL
RECORD IN DIGITAL
RECORD ADVANCED
GAME INPUT SETUP
NAME GAME
DIGITAL IN OPTICAL-4
ANALOG IN ANALOG-6
ANLG IN LVL AUTO
VIDEO IN COMPOSITE-2
COMPONENT IN 1
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN DIGITAL
RECORD IN DIGITAL
RECORD ADVANCED
TAPE INPUT SETUP
NAME TAPE
DIGITAL IN OPTICAL-5
ANALOG IN ANALOG-7
ANLG IN LVL AUTO
VIDEO IN NONE
COMPONENT IN 1
2-CH MUSIC
D 5.1 MUSIC
MUSIC
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN ANLG
RECORD IN ANLG
RECORD ADVANCED
TUNER INPUT SETUP
NAME TUNER
DIGITAL IN NONE
ANALOG IN ANALOG-8
ANLG IN LVL AUTO
VIDEO IN NONE
COMPONENT IN 1
2-CH MUSIC
D 5.1 MUSIC
MUSIC
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN ANLG
RECORD IN ANLG
RECORD ADVANCED
AUX INPUT SETUP
NAME AUX
DIGITAL IN OPTICAL-6
ANALOG IN NONE
ANLG IN LVL AUTO
VIDEO IN COMPOSITE-3
COMPONENT IN 1
2-CH MUSIC
D 5.1 MUSIC
MUSIC
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN DIGITAL
RECORD IN DIGITAL
RECORD ADVANCED
DVD1 INPUT SETUP
NAME DVD1
DIGITAL IN COAX-1
ANALOG IN NONE
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-1
COMPONENT IN 1
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN DIGITAL
RECORD IN DIGITAL
RECORD ADVANCED
DVD2 INPUT SETUP
NAME DVD2
DIGITAL IN COAX-2
ANALOG IN NONE
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-2
COMPONENT IN 2
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN DIGITAL
RECORD IN DIGITAL
RECORD ADVANCED
LD INPUT SETUP
NAME LD
DIGITAL IN COAX-3
ANALOG IN ANALOG-1
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-3
COMPONENT IN 1
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN ANLG
RECORD IN ANLG
RECORD ADVANCED
TV INPUT SETUP
NAME TV
DIGITAL IN OPTICAL-1
ANALOG IN ANALOG-2
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-4
COMPONENT IN 3
2-CH TV
D 5.1 TV
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN ANLG
RECORD IN ANLG
RECORD ADVANCED
SAT INPUT SETUP
NAME SAT
DIGITAL IN OPTICAL-2
ANALOG IN ANALOG-3
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-5
COMPONENT IN 4
2-CH TV
D 5.1 TV
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN ANLG
RECORD IN ANLG
RECORD ADVANCED
VCR INPUT SETUP
NAME VCR
DIGITAL IN NONE
ANALOG IN ANALOG-4
ANLG IN LVL AUTO
VIDEO IN S-VIDEO-6
COMPONENT IN 1
2-CH FILM
D 5.1 FILM
FILM
5.1a 5.1a FILM
MAIN ADVANCED
ZONE2 IN ANLG
RECORD IN ANLG
RECORD ADVANCED
Continued from page 16

Software Version 1.1 Release & Errata Notes Lexicon
18
DVD1 5.1a MODE
5.1a FILM
5.1a MUSIC
5.1a SurEX
5.1a STANDARD
5.1a 2-CHANNEL
USE LAST
DVD1 DIGITAL IN
COAX-1
COAX-2
COAX-3
COAX-4
COAX-5
COAX-6
OPTICAL-1
OPTICAL-2
OPTICAL-3
OPTICAL-4
OPTICAL-5
OPTICAL-6
AES/EBU
NONE
DVD1 ANALOG IN
ANALOG-1
ANALOG-2
ANALOG-3
ANALOG-4
ANALOG-5
ANALOG-6*
ANALOG-7*
ANALOG-8*
NONE
DVD1 VIDEO IN
COMPOSITE-1
COMPOSITE-2
COMPOSITE-3
COMPOSITE-4
COMPOSITE-5
S-VIDEO-1
S-VIDEO-2
S-VIDEO-3
S-VIDEO-4
S-VIDEO-5
S-VIDEO-6
S-VIDEO-7
S-VIDEO-8
NONE
DVD1 COMPONENT
COMPONENT 1
COMPONENT 2
COMPONENT 3
COMPONENT 4
DVD1 2-CH MODE
FILM
TV
MUSIC
PL II
PRO LOGIC II
PL II MUSIC
PRO LOGIC
2-CH SURROUND
2-CHANNEL
MONO LOGIC
MONO SURROUND
MONO
USE LAST
DVD1 D MODE
5.1 FILM
5.1 TV
5.1 MUSIC
5.1 SurEX
DIGITAL
5.1 2-CHANNEL
5.1 MONO LOGIC
5.1 MONO SURR
5.1 MONO
USE LAST
DVD1 MODE
FILM
MUSIC
2-CHAN
USE LAST
DVD1 RECORD ADV
ANLG IN LVL +0dB
DIGITAL BYPASS OFF
DIG OUT RATE 44.1kHz
RECORD ENABLED
DVD1 INPUT NAME
EDIT INPUT NAME
RESTORE DEFAULT NAME
DVD1 MAIN ADV
INPUT SELECT DIGITAL
ANALOG BYPASS OFF
S-VIDEO 16:9 AUTO
S-VIDEO OSD 4:3 ON
COMPONENT OSD OFF
* When REAR PANEL CONFIG is set to 5 STEREO & 5.1 ANLG, 5.1 ANALOG will appear in place of these menu selections.
DVD1 ANLG IN LVL
AUTO ON
MANUAL +0dB
AUTO GAIN +0.0dB
dB L CR SL SR LFE
0
-6
-15 XXXXX X
-30
-45
Menu Tree (continued)
Selecting parameters on the INPUT SETUP menus pictured on page 17 accesses the corresponding menu pictured below. The menus pictured
below are identical regardless of which input is selected (e.g. DVD1, DVD2, and so on).
Default parameter settings
vary from input to input
Default parameter settings
vary from input to input

Software Version 1.1 Release & Errata Notes
MC-12/MC-12 Balanced
19
* When the SUB L/R parameter is set to STEREO or NONE, the SUB (MONO) parameter becomes the SUB LEFT parameter.
FRONT L/R SPEAKERS
FULL
30Hz
40Hz
50Hz
60Hz
70Hz
80Hz
THX 80Hz
90Hz
100Hz
110Hz
120Hz
CUSTOM SETUP
FRONT L/R 40Hz
CENTER 60Hz
SIDE L/R 60Hz
REAR L/R 60Hz
SUB L/R MONO
SUB XOVER 40Hz
LFE OFF
SPEAKER DISTANCES
FRONT LEFT 0.0 ft
CENTER 0.0 ft
FRONT RIGHT 0.0 ft
SIDE RIGHT 0.0 ft
REAR RIGHT 0.0 ft
REAR LEFT 0.0 ft
SIDE LEFT 0.0 ft
SUB (MONO)* 0.0 ft
SUB RIGHT N/A
LFE N/A
UNITS FEET
Continued on page 20
LEVELS CALIBRATION
INTERNAL NOISE TEST
EXTERNAL NOISE TEST
BASS PEAK LIMITERS
CENTER SPEAKER
FULL
30Hz
40Hz
50Hz
60Hz
70Hz
80Hz
THX 80Hz
90Hz
100Hz
110Hz
120Hz
NONE
SIDE L/R SPEAKERS
FULL
30Hz
40Hz
50Hz
60Hz
70Hz
80Hz
THX 80Hz
90Hz
100Hz
110Hz
120Hz
NONE
THX SETUP
FRONT L/R THX 80Hz
CENTER THX 80Hz
SIDE L/R THX 80Hz
REAR L/R THX 80Hz
SUB L/R MONO
SUB XOVER THX 80Hz
LFE OFF
REAR L/R SPEAKERS
FULL
30Hz
40Hz
50Hz
60Hz
70Hz
80Hz
THX 80Hz
90Hz
100Hz
110Hz
120Hz
NONE
SUBWOOFERS L/R
MONO
STEREO
NONE
SUB XOVER
FULL
30Hz
40Hz
50Hz
60Hz
70Hz
80Hz
THX 80Hz
90Hz
100Hz
110Hz
120Hz
THX SPEAKER SETUP
!CAUTION!
PRESSING THE RIGHT V
BUTTON WILL
AUTOMATICALLY CHANGE
THE OUTPUTS TO A THX
SPEAKER
CONFIGURATION
SPEAKER SETUP
CUSTOM SETUP
THX SETUP
SPEAKER DISTANCES
LEVELS CALIBRATION
Continued on page 19
40Hz 40Hz
40Hz 60Hz 60Hz
60Hz 60Hz
60Hz
L
M
SUB
R
C
SL
SR
RL
RR

Software Version 1.1 Release & Errata Notes Lexicon
20
* When the SUB L/R parameter is set to STEREO or NONE, the SUB (MONO) parameter becomes the SUB LEFT parameter.
FRONT PANEL DISPLAY
STATUS ALWAYS ON
BRIGHTNESS 100%
ON-SCREEN DISPLAY
STATUS 2 SECONDS
POSITION TOP
FORMAT NTSC
BACKGROUND ON
REMOTE STATE ON
DISPLAY SETUP
ON-SCREEN DISPLAY
FRONT PANEL DISPLAY
A/V SYNC DELAY OFF
CUSTOM NAME OFF
EDIT CUSTOM NAME
Continued from page 16
Continued from page 19
(External Noise Test)
LEVELS CALIBRATION
INTERNAL NOISE TEST
EXTERNAL NOISE TEST
BASS PEAK LIMITERS
BASS PEAK LIMITERS
CAL NOISE ON
L/R LIMITER ON
L/R LIMIT ADJ 100dB
LFE LIMITER ON
LFE LIMIT ADJ 100dB
!CAUTION!
HIGH AUDIO LEVELS
INTERNAL NOISE
!CAUTION!
HIGH AUDIO LEVELS
SPEAKER LEVEL ADJUST
FRONT LEFT +0.0dB
CENTER +0.0dB
FRONT RIGHT +0.0dB
SIDE RIGHT +0.0dB
REAR RIGHT +0.0dB
REAR LEFT +0.0dB
SIDE LEFT +0.0dB
SUB (MONO)* +0.0dB
SUB RIGHT N/A
LFE N/A
SPEAKER LEVEL ADJUST
FRONT LEFT +0.0dB
CENTER +0.0dB
FRONT RIGHT +0.0dB
SIDE RIGHT +0.0dB
REAR RIGHT +0.0dB
REAR LEFT +0.0dB
SIDE LEFT +0.0dB
SUB (MONO)* +0.0dB
SUB RIGHT N/A
LFE N/A
TRIGGER SETUP
TRIGGER 1 REMOTE
TRIGGER 2 REMOTE
Continued from page 16
TRIGGER (#) SETUP
REMOTE ONLY ON
DVD1 OFF
DVD2 OFF
LD OFF
TV OFF
SAT OFF
VCR OFF
CD OFF
PVR OFF
GAME OFF
TAPE OFF
TUNER OFF
AUX OFF
ZONE2 INPUTS OFF
RECORD INPUTS OFF
FILM OFF
TV OFF
MUSIC OFF
PL II OFF
PRO LOGIC II OFF
PL II MUSIC OFF
PRO LOGIC OFF
FILM OFF
MUSIC OFF
2-CH SURROUND
OFF
2-CHANNEL OFF
MONO LOGIC OFF
MONO SURROUND OFF
MONO OFF
5.1 FILM OFF
5.1 TV
OFF
5.1 MUSIC OFF
5.1 SurEX OFF
DIGITAL OFF
5.1 2-CHANNEL OFF
5.1 MONO LOGIC OFF
5.1 MONO SURR
OFF
5.1 MONO OFF
FILM OFF
MUSIC OFF
OFF
OFF
2-CHAN
OFF
5.1a FILM OFF
5.1a MUSIC OFF
5.1a SurEX OFF
5.1a STANDARD OFF
5.1a 2-CHANNEL OFF
5.1a BYPASS OFF
2CH BYPASS OFF
R
R
Menu Tree (continued)
