UP TO 25 PPM COLOR
UP TO 25 PPM BLACK
DUPLEX
NETWORK
Power up your workday with
Lexmark multifunction color!
PRINT
COPY
SCAN
FAX AVAILABLE
Lexmark X543dn
Lexmark X540 Series
Lexmark X544 models

The network-ready Lexmark X540 Series offers high-performance color and multifunction savings for cost-conscious small
workgroups. What’s more, you’re protected by Lexmark’s Lifetime Pricing Guarantee. Lexmark guarantees, for as long as you
own your MFP, not to increase the price* of toner cartridges for your Lexmark X540 MFP. Save even more when you enroll in
Lexmark Rewards!
Powerful scanning features!
Duplex color scanning Direct USBScan to e-mail Lexmark Scan Center
software
Multi-format support
Print Less. Save More.
Print less? This may seem like a surprising message for a company dedicated solely to printing. But when you consider that businesses spend, on
average, up to 6% of their revenue on printing and that active print management can cut office print costs by up to 30%1, it makes a lot of sense.
Lexmark products, solutions and services provide innovative ways to save you time, drive down costs and reduce your impact on the environment.
We are committed to helping you print less and save more.
(1) Source: InfoTrends/CapVentures, Network Document Solutions Forecast 2007-2012, Network Document Solutions Consulting Service, August 2008
Easy to use, easy to share
Surprisingly compact for such a fully functioned solution,
these devices are also incredibly quiet, easy to use and
integrate effortlessly into your existing office environment.
l
As quiet as 47 dBA while printing; reduce sound even more
with Quiet Mode
l
User-friendly operator panel for easy access to all functions
l
PCL 6 and PostScript 3 emulations ensure compatibility
with your application software
l
Fully network-ready for enhanced workgroup performance
l
Quick and convenient cartridge replacement
The power of multifunction
Built for serious office work, these new color MFPs equip you
with all the productivity functions you need to maximize your
business performance.
l
Move easily between hardcopy and digital documents with
advanced scanning, such as scan to desktop, scan to e-
mail or scan to shared server
l
Models available with duplex printing and duplex scanning
l
Duo Drawer combines a 100-sheet multipurpose feeder
and 550-sheet tray in one unique option
l
Lexmark X544 models add Super G3 fax capability
Eco-responsible printing
Printing responsibly means everyone wins – your business,
your budget and the environment! Lexmark’s new color
MFPs are eco-designed and come with a range of features
to help you print greener at every level.
l
Instant warm-up fuser saves energy while delivering first
page quickly
l
Lexmark Cartridge Collection Program for leading-edge
recycling
Saves time by scanning
both sides of your
document automatically
Eliminates the need for
paper copies; quickly
locates addresses stored in
your company directory
Front USB port for walk-up
printing and scanning to
memory device
Scan options and scan-to
destinations located on one
easy-to-use window
Save your documents in
common image formats
(PDF, JPG, TIF) for viewing,
sharing and use on the Web
* U.S. dollar price only listed on www.lexmark.com. Other currency prices listed subject to currency fluctuation based on the U.S. dollar. This guarantee does not apply to dealer and/or distributor pricing. Lexmark reserves the right to discontinue selling these
toner cartridges any time after it discontinues service support for this printer.
Color that makes a difference!
l
Rich, vibrant, true 1200 x 1200 dpi color printing
l
Includes new generation Lexmark toner
Outstanding color adds impact to your important
business documents. Lexmark puts its color expertise
to work for you and gives you the tools to control color
output effectively.
l
Consistent color balance with Pantone calibration
l
Color-control tools: coverage estimator and ColorSaver™
mode
l
Models with built-in duplex offer excellent value and paper
savings
l
Paper Saver lets you copy multiple pages per sheet
l
Eco-Mode reduces power consumption
l
Lexmark High Yield Toner Cartridges to keep printing
costs low

A small office partner
packed with features!
Get exactly the performance you need
Lexmark X543dn
Reliable 4-in-1 color MFP, loaded with high-performance features
l
Up to 25 ppm output in black and color
l
Includes fax and high-quality duplex scanning
l
Lexmark Extra High Yield Toner Cartridges available
l
Recommended monthly volume: 800 to 3,000 pages
Configurations available: Lexmark X544n, Lexmark X544dn, Lexmark X544dtn,
Lexmark X544dw
Lexmark X540 Series
Lexmark X544 models
Network-ready, 3-in-1 compact color laser with paper-saving
duplex printing
l
Up to 21 ppm output in black and color
l
High-quality printing, copying and scanning
l
Built-in paper-saving duplex printing
l
Ships with Lexmark High Yield Toner Cartridges
l
Recommended monthly volume: 500 to 1,500 pages
Lexmark Rewards
Green looks good
on you!
Purchase a Lexmark X540 Series
color laser MFP and you can save
up to 20 percent of the total cost
of supplies while you help save
the planet. It’s easy with Lexmark
Rewards.
Learn more
www.LexmarkRewards.com
Lexmark Rewards gives you
free high-yield toner cartridges
and imaging kits simply for using
genuine Lexmark toner and
returning your empty cartridges
to Lexmark for recycling – you’ll
earn two rewards points just
for signing up and an additional
point for each cartridge return.
For every 10 points earned
Lexmark will send you a free
high-yield toner cartridge, and
when it’s time to replace your
imaging kit we’ll send you one of
those free too.
l
Optional Duo Drawer expands input capacity and includes
a multipurpose feeder
l
Direct USB port for walk-up printing and scanning
to memory device

Product specifications Lexmark X540 Series
Lexmark X543dn Lexmark X544n
Maximum Monthly Duty Cycle
Recommended Monthly Page Volume
«Maximum Monthly Duty Cycle» is defined as the maximum number of pages a device could deliver in a month. This metric
provides a comparison of robustness in relation to other Lexmark printers and MFPs.
«Recommended Monthly Page Volume» is a range of pages that helps customers evaluate Lexmark’s product offerings based
on the average number of pages customers plan to print on the device each month. Lexmark recommends that the number of
pages per month be within the stated range for optimum device performance, based on factors including: supplies replacement
intervals, paper loading intervals, speed, and typical customer usage.
Trademarks
Lexmark and Lexmark with the diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other
countries. All other trademarks are the property of their respective owners. PCL is a registered trademark of Hewlett-Packard Company. AppleTalk,
Mac and Macintosh are trademarks of Apple Computer, Inc., registered in the United States and other countries. MarkNet and MarkVision are
trademarks of Lexmark International, Inc., registered in the United States and/or other countries. The USB-IF logos are trademarks of Universal
Serial Bus Implementers Forum, Inc. ENERGY STAR® is a U.S. registered mark. Microsoft, Windows, the Windows logo, Windows Vista, and
the Windows Vista logo are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Citrix,
MetaFrame and MetaFrame XP are registered trademarks or trademarks of Citrix Systems, Inc. in the U.S. and other countries. Information in this
document is subject to change without notice.
License/Agreement Terms
Printers are sold subject to certain license/agreement conditions. See www.lexmark.com/printerlicense for details.
Printing
Print Technology Color Laser
Print Speed (Letter, Black): Up to 21 ppm 25 ppm
Print Speed (Letter, Color): Up to 21 ppm 25 ppm
Print Resolution, Black 1200 x 1200 dpi, 4800 Color Quality (1200 x 600 dpi)
Print Resolution, Color 1200 x 1200 dpi, 4800 Color Quality (1200 x 600 dpi)
Memory, Standard 128 MB
Memory, Maximum 640 MB
Print Noise Level, Operating 47 dBA 48 dBA
Noise Level, Idle inaudible dBA
Maximum Monthly Duty Cycle: Up to 35000 pages per month 55000 pages per month
Recommended Monthly Page Volume 500 - 1500 pages 800 - 3000 pages
Supplies
Supplies Yield
(*Average continuous black or continuous composite CMY
declared cartridge yield up to this number of standard pages in
accordance with ISO/IEC 19798.)
1,000*-page Color Toner Cartridges (CMY), 2,000*-page Color High Yield
Toner Cartridges (CMY), 2,500*-page Black High Yield Toner Cartridge,
1,000*-page Black Toner Cartridge
1,000*-page Color Toner Cartridges (CMY), 2,000*-page Color High Yield
Toner Cartridges (CMY), 4,000*-page Color Extra High Yield Toner Cartridges
(CMY), 2,500*-page Black High Yield Toner Cartridge, 6,000*-page Black
Extra High Yield Toner Cartridge, 1,000*-page Black Toner Cartridge
Cartridge(s) Shipping with Product 2,500*-page Black Return Program Toner Cartridge, 2,000*-page Color (CMY) Return Program Toner Cartridges
Copying
Copy Speed (A4, Black): Up to 20 cpm 23 cpm
Copy Speed (Letter, Black): Up to 21 cpm 25 cpm
Copy Speed (Letter, Color): Up to 21 cpm 25 cpm
Scanning
ADF Scan Simplex RADF (reversing Duplex)
Scanning Resolution 600 X 600 dpi
Reduce / Enlarge Range 25 - 400 %
Faxing
Modem Speed 33.6 Kbps
Paper Handling
Paper Handling Standard 150-Sheet Output Bin, Integrated Duplex, Single Sheet Manual Feed, 250-
Sheet Input Tray
150-Sheet Output Bin, Single Sheet Manual Feed, 250-Sheet Input Tray
Paper Handling Optional 550-Sheet Duo Drawer with 100-Sheet Feeder
Paper Input Capacity, Standard 250+1 pages 20 lb or 75 gsm bond
Paper Input Capacity, Maximum 900 +1 pages 20 lb or 75 gsm bond
Paper Output Capacity, Standard 150 pages 20 lb or 75 gsm bond
Paper Output Capacity, Maximum 150 pages 20 lb or 75 gsm bond
ADF Paper Input Capacity : Up to 50 pages 20 lb or 75 gsm bond
Media Types Supported Card Stock, Paper Labels, Plain Paper, Transparencies, Refer to the Card Stock & Label Guide
Media Sizes Supported A4, A5, Executive, Folio, JIS-B5, Legal, Letter, Universal, Oficio
Compatibility
Network Protocol Support TCP/IP IPv4, AppleTalk™, TCP/IP IPv6, TCP, UDP
Printer Languages (Standard) PCL 5c Emulation, PCL 6 Emulation, Personal Printer Data Stream (PPDS),
PostScript 3 Emulation, PDF 1.6
PCL 5c Emulation, PCL 6 Emulation, Personal Printer Data Stream (PPDS),
PostScript 3 Emulation, PDF 1.6, Direct Image
Standard Ports Ethernet 10/100BaseTX (RJ-45), USB 2.0 Specification Hi-Speed Certified Ethernet 10/100BaseTX (RJ-45), USB 2.0 Specification Hi-Speed Certified,
PictBridge Certified Port, Front USB port Compatible with USB 2.0 Specifi-
cation (Type A)
Microsoft Windows Operating Systems Supported 2000, XP, Server 2003, XP x64, Server 2003 running Terminal Services, 2000 Server running Terminal Services, Server 2003 x64, Server 2003 x64 running
Terminal Services, Vista, Vista x64, Server 2008, Server 2008 x64, Server 2008 running Terminal Services, Server 2008 x64 running Terminal Services
Apple Macintosh Operating Systems Supported Mac OS X, Mac OS 9.x
General
Function Color Copying, Color Printing, Network Scanning Color Copying, Color Faxing, Color Printing, Color Scanning, Network
Scanning
Product Warranty 1-Year Onsite Service, Next Business Day
Product Certifications www.lexmark.com
Size (in. - H x W x D) 18.23 x 17.32 x 21.14 in.
Weight (lb.) 60 lb.
Specified Operating Environment Temperature: 16 to 32°C (60 to 90°F), Humidity: 8 to 80% Relative Humidity, Altitude: 0 - 3048 Meters (10,000 Feet)

Lexmark X544n: Network ready, Part #3044503
Lexmark X544dn: Network ready plus duplex, Part #3001389
Lexmark X544dtn: Network ready with duplex plus extra input drawer, Part #26C0300
Lexmark X544dw: Duplex with built-in wireless, Part #26C0400
Ordering information
In the box
In the box
Lexmark’s guarantee to you
At Lexmark, we’re always working hard to ensure you achieve maximum productivity and minimum downtime. For greater level of peace of mind, you can opt for one of our Lexmark service offerings detailled on www.lexmark.com/services.
Models available
Environmental commitment Cost-saving and environmental features
Lexmark believes that the environment is a critical component of responsible busi-
ness management and clearly demonstrates it by implementing the “4R” strategy:
Reduce, Recover, Reuse and Recycle. To learn more about these programs please
visit www.lexmark.com/recycle.
- Energy Star compliant
- Duplex printing, Print and Hold (verify print), multi-up printing and support for recycled paper help reduce paper consumption.
- Selectable toner-saving modes help reduce the amount of toner used on a page.
- Lexmark Cartridge Collection Program and end-of-life product recycling help reduce waste.
Lexmark X540 Series
Lexmark X543dn Multifunction Color Laser, up to 2,000*-page color High Yield Return Program Toner Cartridges (CMY), up to 2,500*-page black High Yield
Return Program Toner Cartridge, software and documentation CD, power cord(s), RJ-11 phone cable or adapter (country dependent), setup guides (network
and local attachment), Lexmark Rewards brochure, Lexmark Cartridge Collection Program information, Statement of Limited Waranty, operator panel language
overlays
Lexmark X544n Multifunction Color Laser, up to 2,000*-page color High Yield Return Program Toner Cartridges (CMY), up to 2,500*-page black High Yield
Return Program Toner Cartridge, software and documentation CD, power cord(s), RJ-11 phone cable or adapter (country dependent), setup guides (network
and local attachment), Lexmark Rewards brochure, Lexmark Cartridge Collection Program information, operator panel language overlays, Statement of Limited
Warranty
Part # Model
3044503 Lexmark X544n
Lexmark X544n Part # Laser Toner/Print Cartridge
C544X1KG Black Extra High Yield Return Program Toner Cartridge
C544X1CG Cyan Extra High Yield Return Program Toner Cartridge
C544X1MG Magenta Extra High Yield Return Program Toner
C544X1YG Yellow Extra High Yield Return Program Toner
C540H1KG Black High Yield Return Program Toner Cartridge
C540H1CG Cyan High Yield Return Program Toner Cartridge
C540H1MG Magenta High Yield Return Program Toner Cartridge
C540H1YG Yellow High Yield Return Program Toner Cartridge
C540A1KG Black Return Program Toner Cartridge
C540A1CG Cyan Return Program Toner Cartridge
C540A1MG Magenta Return Program Toner Cartridge
C540A1YG Yellow Return Program Toner Cartridge
C544X2KG Black Extra High Yield Toner Cartridge
C544X2CG Cyan Extra High Yield Toner Cartridge
C544X2MG Magenta Extra High Yield Toner Cartridge
C544X2YG Yellow Extra High Yield Toner Cartridge
C540H2KG Black High Yield Toner Cartridge
C540H2CG Cyan High Yield Toner Cartridge
C540H2MG Magenta High Yield Toner Cartridge
C540H2YG Yellow High Yield Toner Cartridge
C540X75G Waste Toner Bottle
C540X71G Black Imaging Kit
C540X74G Black and Color Imaging Kit
Part # Paper & Transparencies
12A5950 Glossy Laser Paper, Letter (200 sheets)
12A8240 Professional Color Laser Transparencies, Letter
Part # Paper Handling
3000551 550-Sheet Duo Drawer with 100-Sheet MPF
Part # Memory Options
1022298 128MB DDR1-DRAM
1022299 256MB DDR1-DRAM
1022301 512MB DDR1-DRAM
1021209 64MB Flash Card
30G0828 Japanese Font Card
30G0825 Korean Font Card
Part # Connectivity
1021294 USB (2 Meter) Cable
14T0145 Lexmark N4050e 802.11g Wireless Print Server
14T0220 MarkNet™ N7020e Gigabit Ethernet Print Server
Part # Extended Warranties
2350521 2-Years Total Onsite Service, Next Business Day
2350522 3-Years Total Onsite Service, Next Business Day
2350525 1-Year Onsite Service Renewal, Next Business Day
Part # User Replaceable Parts
40X5472 ADF Separator Pad
40X5535 X544 Scanner Cover Cushion
40X5470 ADF Paper Tray
40X5484 Output Bin Extension
40X5168 Pick Tire
150-Sheet Output Bin
250-Sheet Input Tray
Single Sheet Manual
Feed
550-Sheet Duo Drawer
with 100-Sheet MPF
Paper Handling Standard
Paper Handling Optional
Part # Model
3001385 Lexmark X543dn
Lexmark X543dn Part # Laser Toner/Print Cartridge
C540H1KG Black High Yield Return Program Toner Cartridge
C540H1CG Cyan High Yield Return Program Toner Cartridge
C540H1MG Magenta High Yield Return Program Toner Cartridge
C540H1YG Yellow High Yield Return Program Toner Cartridge
C540A1KG Black Return Program Toner Cartridge
C540A1CG Cyan Return Program Toner Cartridge
C540A1MG Magenta Return Program Toner Cartridge
C540A1YG Yellow Return Program Toner Cartridge
C540H2KG Black High Yield Toner Cartridge
C540H2CG Cyan High Yield Toner Cartridge
C540H2MG Magenta High Yield Toner Cartridge
C540H2YG Yellow High Yield Toner Cartridge
C540X75G Waste Toner Bottle
C540X71G Black Imaging Kit
C540X74G Black and Color Imaging Kit
Part # Paper & Transparencies
12A5950 Glossy Laser Paper, Letter (200 sheets)
12A8240 Professional Color Laser Transparencies, Letter
Part # Paper Handling
3000551 550-Sheet Duo Drawer with 100-Sheet MPF
Part # Memory Options
1022298 128MB DDR1-DRAM
1022299 256MB DDR1-DRAM
1022301 512MB DDR1-DRAM
1021209 64MB Flash Card
30G0828 Japanese Font Card
30G0825 Korean Font Card
Part # Connectivity
1021294 USB (2 Meter) Cable
14T0145 Lexmark N4050e 802.11g Wireless Print Server
14T0220 MarkNet™ N7020e Gigabit Ethernet Print Server
Part # Extended Warranties
2350503 2-Years Total Onsite Service, Next Business Day
2350504 3-Years Total Onsite Service, Next Business Day
2350507 1-Year Onsite Service Renewal, Next Business Day
Part # User Replaceable Parts
40X5472 ADF Separator Pad
40X5539 X543 Scanner Cover Cushion
40X5470 ADF Paper Tray
40X5484 Output Bin Extension
40X5168 Pick Tire
150-Sheet Output Bin
250-Sheet Input Tray
Integrated Duplex
Single Sheet Manual
Feed
550-Sheet Duo Drawer
with 100-Sheet MPF
Paper Handling Standard
Paper Handling Optional

www.lexmark.com
