Leyton POW-6M1 User manual

Motorised Pop-Up Socket
POW-6M1 / P0W-6M1-B
KEY FEATURES CONT.
•Anti pinch function: If the unit is obstructed during a closing
operation, the anti pinch function will reverse the direction of
travel momentarily, and then pause all movement. The
operation LED will flash red to indicate that the anti pinch
function has been activated. When the button at the top of the
unit is pressed again, the unit will fully raise and return to
normal operation.
•Anti-collision function: If the unit encounters an obstruction
during a raise operation, the anti collision function will activate
and the unit will pause. To indicate that the anti obstruction
function has activated, the indicator LED will flash yellow.
Once the obstruction has been cleared, the unit can be
returned to normal operation by pressing the button on the top
of the unit once again.
•One key design: This item has been designed with
simplicity and ease of use in mind. For this reason, all
operations are controlled using a single button on the top
of the unit.
•Water resistant design: In a closed state, this product is
designed to prevent water ingress by preventing spillages
from entering the product body and potentially leaking into
the mains sockets.
•USB charging: This unit is equipped with 1 x USB charging socket &
1 x Type C charging socket. This allows portable devices to be
charged from the convenience of your worktop.
WIRELESS CHARGER FUNCTION:
•The mobile phone needs to support the wireless charging function.
•When the product is powered on, the mobile phone is placed on the
top cover of the product and will be automatically charged.
20/12/21 –Version 1

UNPACKING
Remove contents from the packaging and lay out on cardboard or
other protective surface to avoid damage. Check the contents are
correct andfree from damage before proceeding. If any parts are
missing or damaged,please contact your supplier.
SAFETYINFORMATION
Install and use this product with care. Please read this instruction
booklet thoroughly before installation and carefully follow all
instructions. Do not use this product for any purpose or in any
configuration not explicitly specified in this instruction manual. We
hereby disclaim any and all liability for injury or damage arising
from incorrect assembly, mounting or usage of this product.
CAUTION
This motorized pop-up socket must be securely installed on a
solid horizontal surface.
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTIONS
1. Use a suitable hole cutter to make a 95mm hole in the
worktop(3).
2. Fix the Silicone pad(2) onto the Product body(1).
3. Insert the product body (1) into the 95mm hole in the
worktop(3). Rotate locking ring securing tightly to the
top.
4. Connect the supplied power lead to the connector on the
base of the product body (1).
KEY FEATURES
•Accidental Operation Protection: This product is fitted with an
automatic delay timer to prevent accidental operation. Press
the button on the top of the unit for 2 seconds to enable the
motorized raise/lower function. This function works to protect
both children and animals.
•Light design:
Dim Green (static): The unit is in a lowered position and is
ready to be used.
Bright Blue (flashing): A raise operation is currently in
progress.
Dim Blue (flashing): The unit has been paused during a
raise operation. Dim Blue (static): The unit is fully raised
and ready for use.
Bright Green (flashing): A lowering operation is currently in
progress.
Dim Green (flashing): The unit has been paused during a
lowering operation.
Yellow (flashing): The anti collision function has activated
during a raise operation.
Red (flashing): The anti pinch function has activated during
a lowering operation.
Dimensions: 490mm x 112mm
Hole Cut Out Diameter: 95mm
Rated Voltage Range: AC95V-250V
Rated Frequency: 50Hz / 60Hz
Rated Current: 13A
USB Supply: 2.1A
Type C Supply: 3A
KEY
1. Product Body 2.Silicone pad
3. Worktop 4. Locking Ring
