LF Engineering SPL-2/75 AM-BC User manual

Model SPL-2/75 AM-BC
Two-Way Splitter/Combiner
The SPL-2/75 AM-BC Two-Way Splitter/Combiner provides an
impedance matched 75 ohm coaxial connection for two receivers
when feeding signal from a single source. Typically used for distrib-
uted cabling systems requiring impedance matched taps for multiple
receivers, or when combining two antennas for diversity reception.
The splitter consists of a low loss toroid matching network designed to
maintain a low impedance signal split with high isolation between ports.
Proper impedance matching is necessary for optimum performance
especially when running feeder cable over long distances within a
building.
Specifications - SPL-2/75
SPL-2 Size 2.4”L x 1.4”W x 0.75H”
Bandwidth 20 kHz to 30 MHz
Input Impedance 75 ohms
Output Impedance 75 ohms
Insertion Loss < 1 dB above 6 dB splitter loss
Port Isolation > 40 dB typical
Shorted Port Loss < 1 dB
Maximum Power 500 mW
Connections RCA
SPL-2/75 Two-Way Splitter/Combiner
Product Warranty
LF Engineering Co. warrants that, at the time of shipment the
products manufactured are free from defects in material and
workmanship. LF Engineering obligation under this warranty
is limited to replacement or repair of the product within 1 year
from the date of shipment.
860-526-4759 • www.lfengineering.com
Copyright LF Engineering Co.
All rights reserved.
Printed in U.S.A.
LF Engineering Co.
17 Jeffery Road
East Haven, CT 06513

Rx1 Rx2
Ant
SPL-2/75
75 Ω
75 Ω
75 Ω
Coupler
M-601C
AM-BC
Active Antenna
Receiver 1 Receiver 2
Configuration for Receivers
with 75 Ohm Input
Cable Sheild
to Ground
220 Ω
(center)
Antenna
220 Ω
(center)
22 Ω
Antenna
Configuration for Receivers
with Low Impedance
Loop Input
Configuration for Receivers
with 300 Ohm input
Rx1 Rx2
Ant
Rx1 Rx2
Ant
Receiver 1 Receiver 2
Receiver 1 Receiver 2
SPL-2/75
SPL-2/75 220 Ω
(center)
Cable Sheild
to Ground
220 Ω
(center)
22 Ω
Ant1 Ant2
Rx
SPL-2/75
Coupler
OR
Ant1 Ant2
Rx
RCVR
Broadcast)
75 Ω
Antenna Tuner
Tuned
Long Wire
M-601C
Antenna
Coupler
M-601C
Antenna
Coupler
H-800 MF/HF
Antenna
SPL-2/75
75 ΩRCVR
Broadcast/HF)
In splitter configuration, two receivers may be fed from one
antenna. Shown below are four antenna configurations typically
used with the SPL-2/75. Use coaxial extensions in lengths up to 100
feet using 75 ohm 1/4 inch coaxial cable.
The cumulative system loss is the total loss (in dB) of all feeder and
extension cables, and the splitter loss for the SPL-2/75 itself.
In combiner configuration, two different antennas may be used
to feed one broadband receiver. Shown below are two suggested
antenna configurations that may be used with the SPL-2/75.
The cumulative system loss is the total loss (in dB) of all feeder and
extension cables, and the splitter loss for the SPL-2/75 itself.
