LG Innotek ETWBCLUL05 User manual

User Manual
PRODUCT NAME : Bluetooth Low Energy Module
MODEL NAME : ETWBCLUL05
(00)-0073
The information contained herein is the exclusive property of LG Innotek
and shall not be distributed, reproduced or disclosed in whole or no in part
without prior written permission of LG Innotek.
Designed Checked Approved
LG Innotek Co., Ltd.
H.S. Kim J.H. Chang S.D. Choi
Document No.
2021.04.27 2021.04.27 2021.04.27 Page 9

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
Index
No Description Page
1Features 2
2Block Diagram 2
3Absolute Maximum Ratings 3
4Recommendation operating conditions 4
5Standard test conditions 4
6RF specifications 5
7Pin description 6
8Application Schematic 7
9Mechanical Dimension 8
10 Outline Drawing 9
1

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
1. Features
ETWBCLUL05 is the ultra small size with antenna BT5.0 Low energy module.
ETWBCLUL05 is based on nRF52810 (Nordic) solution.
Supported data rates: 1Mbps, 2Mbps Bluetooth® low energy mode
-20 to +4dBm TX power, configurable in 4dB steps
ARM® Cortex®-M4 32-bit processor, 64MHz
Support LDO and DC/DC regulator system
Integrated 2.4GHz Antenna (Option)
192kB flash and 24kB RAM
12-bit, 200ksps, ADC-8 configurable channels with programmable gain
Support GPIO, PDM, PWM, SPI, I2C, UART, 64 level comparator
Size : 3.28 x 5.26 x 0.69mm
Application: Health care and medical, Wearable, Enterprise lighting, Remote controls,
Computer peripherals and I/O devices
2

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
3. Absolute maximum ratings
Parameter Min Max Unit
VBAT -+3.9 V
Storage Humidity (40℃) - 90 %
Storage Temperature -20 +85 ℃
MSL
(Moisture Sensitivity Level) 3Level
ESD HBM ±1-kV
Caution : Stresses exceeding the absolute maximum ratings in Table 1 may damage the
device. The device may not function or be operable above the recommended operating
conditions and stressing the parts to these levels is not recommended.
In addition, extended exposure to stresses above the recommended operating conditions
may affect device reliability. The absolute maximum ratings are stress ratings only.
※Other conditions
1) Do not use or store modules in the corrosive atmosphere, especially where chloride gas, sulfide gas, acid,
alkali, salt or the like are contained. Also, avoid exposure to moisture.
2) Store the modules where the temperature and relative humidity do not exceed 5 to 40℃and 20 to 60%.
3) Assemble the modules within 6 months. Check the soldering ability in case of 6 months over.
4) MSL Level 3 (Floor Life Time : 168Hrs. / Condition : ≤30℃, 60% RH), Standard : IPC / JEDEC J-STD-020C
< Table 1 >
3

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
Parameter Min Typ Max Unit
Ambient Temperature 0 - 60 ℃
Ambient Humidity (40℃) - - 85 %
Supply Voltage 1.9 3.0 3.6 Vdc
5. Standard test conditions
The Test for electrical specification shall be performed under the following condition.
Otherwise this following conditions, not guaranteed this performance.
Temperature 25 ±5℃
Humidity 65 ±5%
Input power Supply Voltage
VBAT 3.0V
5-1. Ambient condition
5-2. Power supply voltages
ESD Min. Max. Unit
Human Body Model (HBM) ±1kV
5-3. ESD Information
4. Recommendation operating conditions
4
MSL Level 3 (Floor Life Time : 168Hrs. / Condition : ≤30℃, 60% RH)
Standard : IPC / JEDEC J-STD-020C
5-4. MSL
Note 1) Discharge : Contact, Interval : 1sec, Count : 1 time
Condition : 100pF, 1500ohm, JEDC JESD22-A114

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
6. RF Specifications(Conducted Test)
5
PARAMETER TEST CONDITIONS MIN TYP MAX UNIT
Receiver
sensitivity
1 Mbps Packet length<=37 bytes, BER=0.1% - -94 -80
dBm
2 Mbps Packet length<=37 bytes, BER=0.1% - -91 -80
Maximum received
signal strength
Maximum received signal strength at
< 0.1% BER -10 5 - dBm
Maximum output power Conducted Test 0 4 - dBm
Modulation
Characteristics
1 Mbps
delta F1 average 225 -275 kHz
ratio(delta F2/delta F1 ) 80 - - %
2 Mbps
delta F1 average 450 -550 kHz
ratio(delta F2/delta F1 ) 80 - - %
Carrier frequency
offset
and drift
1 Mbps
| f[n] | - - 150 kHz
| f0 –fn |- - 50 kHz
Carrier frequency
offset
and drift
2 Mbps
| f[n] | - - 150 kHz
| f0 –fn |- - 50 kHz

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
7. Pin Description
6
Pin No. Pin Name Pin Description
1ANT Sub Line Antenna Sub Pattern
2NC NC
3NC NC
4NC NC
5ANT Feed Internal Antenna Feeding
6GND Ground
7RF Port RF In / Out Port
8GND Ground
9GPIO20 (P0.20) General purpose I/O pin
10 GPIO16 (P0.16) General purpose I/O pin
11 GPIO15 (P0.15) General purpose I/O pin
12 GPIO12 (P0.12) General purpose I/O pin
13 NC NC
14 AIN1 (P0.03) Analog input (General purpose I/O, COMP input, SAADC input)
15 GND Ground
16 XL2 (P0.01) General purpose I/O pin, Connection for 32.768kHz crystal
17 XL1 (P0.00) General purpose I/O pin, Connection for 32.768kHz crystal
18 NC NC
19 VBAT Power supply pin
20 GND Ground
21 DC DC IN DC DC Inductor connection
22 GND Ground
23 DC DC Out DC DC Inductor connection
24 GND Ground
25 GND Ground
26 ANT Sub Line Antenna Sub Pattern
27 Reset Reset (General purpose I/O pin)
28 SWDIO Serial wire debug I/O for debug and programming
29 SWDCLK Serial wire debug clock input for debug and programming
30 AIN2 (P0.04) Analog input (General purpose I/O, COMP input, SAADC input)
31 GPIO18 (P0.18) General purpose I/O pin
32 GPIO14 (P0.14) General purpose I/O pin
33 GND Ground
34 GPIO8 (P0.08) General purpose I/O pin
35 GPIO11 (P0.11) General purpose I/O pin

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
9. Mechanical Dimension (Top View)
Max.0.69mm
<ETWBCLUL05>
DIM mm DIM mm DIM mm
W3.28.0 ±0.2 L5.26 ±0.2 B4 0.265 ±0.05
A1 0.2 ±0.05 A7 0.53 ±0.05 B5 0.4 ±0.05
A2 0.2 ±0.05 A8 0.25 ±0.05 B6 0.14 ±0.05
A3 0.25±0.05 A9 0.2 ±0.05 B7 1.43 ±0.05
A4 0.5 ±0.05 B1 0.6 ±0.05 B8 0.6 ±0.05
A5 0.4 ±0.05 B2 0.25 ±0.05 B9 0.4 ±0.05
A6 0.14 ±0.05 B3 0.25 ±0.05 B10 0.35 ±0.05
8

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
10. Outline Drawing
9
K.S Lee
'21. 03. 17

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
FCC MODULAR APPROVAL INFORMATION EXAMPLES for Manual
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
OEM INTEGRATION INSTRUCTIONS:
This device is intended only for OEM integrators under the following conditions:
The module must be installed in the host equipment such that 20 cm is maintained between the antenna
and users, and the transmitter module may not be co-located with any other transmitter or antenna.
The module shall be only used with the internal on-board antenna that has been originally tested and certified
with this module. External antennas are not supported. As long as these 3 conditions above are met,
further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any additional compliance
requirements required with this module installed (for example, digital device emissions, PC peripheral
requirements, etc.). The end-product may need Verification testing, Declaration of Conformity testing,
a Permissive Class II Change or new Certification. Please involve a FCC certification specialist in order to
determine what will be exactly applicable for the end-product.
9

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
Validity of using the module certification:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location
with another transmitter), then the FCC authorization for this module in combination with the host
equipment is no longer considered valid and the FCC ID of the module cannot be used on the final product.
In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including
the transmitter) and obtaining a separate FCC authorization. In such cases, please involve a FCC
certification specialist in order to determine if a Permissive Class II Change or new Certification is required.
Upgrade Firmware:
The software provided for firmware upgrade will not be capable to affect any RF parameters as certified for
the FCC for this module, in order to prevent compliance issues.
End product labeling:
This transmitter module is authorized only for use in device where the antenna may be installed such that
20 cm may be maintained between the antenna and users. The final end product must be labeled in a
visible area with the following: “Contains FCC ID: YZP-ETWBCLUL05”.
Information that must be placed in the end user manual:
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user's manual of the end product which integrates this module. The end user
manual shall include all required regulatory information/warning as show in this manual.
WARNING
Changes or modifications not expressly approved by the manufacturer could void the user’s authority to
operate the equipment.
“CAUTION : Exposure to Radio Frequency Radiation.
Antenna shall be mounted in such a manner to minimize the potential for human contact during normal
operation. The antenna should not be contacted during operation to avoid the possibility of exceeding the
FCC radio frequency exposure limit.
IC Information
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of
the device.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). L'opération est
soumise aux deux conditions suivantes:
(1) cet appareil ne peut causer d'interférences, et
(2) cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais
fonctionnement de l'appareil.
The end product must be labeled to display the Industry Canada certification number of the module.
Contains transmitter module IC: 7414C-ETWBCLUL05
Le dispositif d'accueil doivent être étiquetés pour afficher le numéro de certification d'Industrie Canada du
module.
Contient module émetteur IC : 7414C-ETWBCLUL05
9

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
Information for OEM Integrator
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
End product labelling
The label for end product must include
“Contains FCC ID: YZP-ETWBCLUL05, Contains IC: 7414C-ETWBCLUL05”.
“CAUTION: Exposure to Radio Frequency Radiation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance of 20cm between the radiator and your
body. This transmitter module is authorized only for use in device where the antenna may be installed such
that 20 cm may be maintained between the antenna and users.”
9

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
Requirement per KDB996369 D03
2.2 List of applicable FCC rules
List the FCC rules that are applicable to the modular transmitter. These are the rules that specifically
establish the bands of operation, the power, spurious emissions, and operating fundamental frequencies.
DO NOT list compliance to unintentional-radiator rules (Part 15 Subpart B) since that is not a condition of a
module grant that is extended to a host manufacturer. See also Section 2.10 below concerning the need to
notify host manufacturers that further testing is required.3
Explanation: This module meets the requirements of FCC part 15C(15.247).
2.3 Summarize the specific operational use conditions
Describe use conditions that are applicable to the modular transmitter, including for example any limits on
antennas, etc. For example, if point-to-point antennas are used that require reduction in power or
compensation for cable loss, then this information must be in the instructions. If the use condition
limitations extend to professional users, then instructions must state that this information also extends to
the host manufacturer’s instruction manual. In addition, certain information may also be needed, such as
peak gain per frequency band and minimum gain, specifically for master devices in
5 GHz DFS bands.
Explanation: The EUT has a PCB Antenna, and the antenna use a permanently attached antenna which is
not replaceable.
2.4 Limited module procedures
If a modular transmitter is approved as a “limited module,”then the module manufacturer is responsible
for approving the host environment that the limited module is used with. The manufacturer of a limited
module must describe, both in the filing and in the installation instructions, the alternative means that the
limited module manufacturer uses to verify that the host meets the necessary requirements to satisfy the
module limiting conditions.
A limited module manufacturer has the flexibility to define its alternative method to address the conditions
that limit the initial approval, such as: shielding, minimum signaling amplitude, buffered modulation/data
inputs, or power supply regulation. The alternative method could include that the limited module
manufacturer reviews detailed test data or host designs prior to giving the host manufacturer approval.
This limited module procedure is also applicable for RF exposure evaluation when it is necessary to
demonstrate compliance in a specific host. The module manufacturer must state how control of the product
into which the modular transmitter will be installed will be maintained such that full compliance of the
product is always ensured. For additional hosts other than the specific host originally granted with a limited
module, a Class II permissive change is required on the module grant to register the additional host as a
specific host also approved with the module.
Explanation: The module is not a limited module.
9

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
2.5 Trace antenna designs
For a modular transmitter with trace antenna designs, see the guidance in Question 11 of KDB Publication
996369 D02 FAQ –Modules for Micro-Strip Antennas and traces. The integration information shall include
for the TCB review the integration instructions for the following aspects:
layout of trace design, parts list (BOM), antenna, connectors, and isolation requirements.
a) Information that includes permitted variances (e.g., trace boundary limits, thickness, length, width,
shape(s),
dielectric constant, and impedance as applicable for each type of antenna);
b) Each design shall be considered a different type (e.g., antenna length in multiple(s) of frequency,
the wavelength, and antenna shape (traces in phase) can affect antenna gain and must be considered);
c) The parameters shall be provided in a manner permitting host manufacturers to design the printed circuit
(PC) board layout;
d) Appropriate parts by manufacturer and specifications;
e) Test procedures for design verification; and
f) Production test procedures for ensuring compliance.
The module grantee shall provide a notice that any deviation(s) from the defined parameters of the antenna
trace, as described by the instructions, require that the host product manufacturer must notify the module
grantee that they wish to change the antenna trace design. In this case, a Class II permissive change
application is required to be filed by the grantee, or the host manufacturer can take responsibility through
the change in FCC ID (new application) procedure followed by a Class II permissive change application.
Explanation: Yes, The module with trace antenna designs, and This manual has been shown the layout
of trace design, antenna, connectors, and isolation requirements.
2.6 RF exposure considerations
It is essential for module grantees to clearly and explicitly state the RF exposure conditions that permit a
host product manufacturer to use the module. Two types of instructions are required for RF exposure
information: (1) to the host product manufacturer, to define the application conditions (mobile, portable –xx
cm from a person’s body); and (2) additional text needed for the host product manufacturer to provide to
end users in their end-product manuals. If RF exposure statements and use conditions are not provided,
then the host product manufacturer is required to take responsibility of the module through a change in
FCC ID (new application).
Explanation: This module complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment, This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body." This module is designed to comply with the FCC
statement, FCC ID is: YZP-ETWBCLUL05
9

Copyrightⓒ. 2019. All Rights Reserved.
Reg. Date : 2021.04.27 User Manual
MODEL NAME : ETWBCLUL05
Rev. No : 1.0
Rev. Date : 2021.04.27 Page : / 9
DOCUMENT No :
LG Innotek Confidential : This document is protected by security policies and laws.
[Restricted]
2.7 Antennas
A list of antennas included in the application for certification must be provided in the instructions. For
modular transmitters approved as limited modules, all applicable professional installer instructions must be
included as part of the information to the host product manufacturer. The antenna list shall also identify the
antenna types (monopole, PIFA, dipole, etc. (note that for example an “omni-directional antenna”is not
considered to be a specific “antenna type”)).
For situations where the host product manufacturer is responsible for an external connector, for example
with an RF pin and antenna trace design, the integration instructions shall inform the installer that unique
antenna connector must be used on the Part 15 authorized transmitters used in the host product. The
module manufacturers shall provide a list of acceptable unique connectors.
Explanation: Explanation: The EUT support external PCB antenna according. Antenna Gain is 0.08 dBi.
2.8 Label and compliance information
Grantees are responsible for the continued compliance of their modules to the FCC rules. This includes
advising host product manufacturers that they need to provide a physical or e-label stating “Contains FCC
ID”with their finished product. See Guidelines for Labeling and User Information for RF Devices –KDB
Publication 784748.
Explanation: The host system using this module, should have label in a visible area indicated the
following texts: "Contains FCC ID: YZP-ETWBCLUL05.
2.9 Information on test modes and additional testing requirements5
Additional guidance for testing host products is given in KDB Publication 996369 D04 Module Integration
Guide. Test modes should take into consideration different operational conditions for a stand-alone
modular transmitter in a host, as well as for multiple simultaneously transmitting modules or other
transmitters in a host product.
The grantee should provide information on how to configure test modes for host product evaluation for
different operational conditions for a stand-alone modular transmitter in a host, versus with multiple,
simultaneously transmitting modules or other transmitters in a host.
Grantees can increase the utility of their modular transmitters by providing special means, modes, or
instructions that simulates or characterizes a connection by enabling a transmitter. This can greatly simplify
a host manufacturer’s determination that a module as installed in a host complies with FCC
requirements.
Explanation: Top band can increase the utility of our modular transmitters by providing instructions
that simulates or characterizes a connection by enabling a transmitter.
2.10 Additional testing, Part 15 Subpart B disclaimer
The grantee should include a statement that the modular transmitter is only FCC authorized for the specific
rule parts (i.e., FCC transmitter rules) listed on the grant, and that the host product manufacturer is
responsible for compliance to any other FCC rules that apply to the host not covered by the modular
transmitter grant of certification. If the grantee markets their product as being Part 15 Subpart B compliant
(when it also contains unintentional-radiator digital circuity), then the grantee shall provide a notice stating
that the final host product still requires Part 15 Subpart B compliance testing with the modular transmitter
installed.
Explanation: The module without unintentional-radiator digital circuity, so the module does not
require an evaluation by FCC Part 15 Subpart B. The host shoule be evaluated by the FCC Subpart B.
9
