LG-Nortel iPECS ES-3024G User manual

U SER G UIDE
Installation Manual
ES-3024G Managed GE Switch
ES-3024GP Managed GE POE Switch

I NSTALLATION M ANUAL
ES-3024G/3024GP
ES-3024G MANAGED 24-PORT GE SWITCH
Layer 2 Managed Switch
with 24 10/100/1000BASE-T (RJ-45) Ports,
and 4 shared Gigabit Combination Ports (SFP)
ES-3024GP MANAGED 24-PORT GE POE SWITCH
Layer 2 Managed Switch
with 24 10/100/1000BASE-T (RJ-45) PoE Ports,
and 4 shared Gigabit Combination Ports (SFP)
ES-3024G
ES-3024GP
E122009-DT-R01
150200000055A

ES-3024G/3024GP
– 3 –
COMPLIANCES AND SAFETY STATEMENTS
FCC CLASS A
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.
You are cautioned that changes or modifications not expressly approved by
the party responsible for compliance could void your authority to operate
the equipment.
You may use unshielded twisted-pair (UTP) for RJ-45 connections -
Category 3 or better for 10 Mbps connections, Category 5 or better for 100
Mbps connections, Category 5, 5e, or 6 for 1000 Mbps connections. For
fiber optic connections, you may use 50/125 or 62.5/125 micron
multimode fiber or 9/125 micron single-mode fiber.
INDUSTRY CANADA - CLASS A
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus as set out in the interference-causing
equipment standard entitled “Digital Apparatus,” ICES-003 of the
Department of Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques
applicables aux appareils numériques de Classe A prescrites dans la norme
sur le matériel brouilleur: “Appareils Numériques,” NMB-003 édictée par le
ministère des Communications.

C OMPLIANCES
– 4 –
ES-3024G/3024GP
CE MARK DECLARATION OF CONFORMANCE FOR EMI AND SAFETY (EEC)
This information technology equipment complies with the requirements of
the Council Directive 2004/108/EC on the Approximation of the laws of the
Member States relating to Electromagnetic Compatibility and 2006/95/EC
for electrical equipment used within certain voltage limits and the
Amendment Directive 93/68/EEC. For the evaluation of the compliance
with these Directives, the following standards were applied:
RFI EMISSION: ◆Limit class A according to EN 55022:1998
◆Limit class A for harmonic current emission
according to EN 61000-3-2/2006
◆Limitation of voltage fluctuation and flicker in
low-voltage supply system according to
EN 61000-3-3/1995+A2:2005
IMMUNITY: ◆Product family standard according to
EN 55024:1998+A2:2003
◆Electrostatic Discharge according to EN 61000-
4-2:1995+A2:2001 (Contact Discharge: ±4 kV,
Air Discharge: ±8 kV)
◆Radio-frequency electromagnetic field according
to EN 61000-4-3:2006
(80 - 1000 MHz with 1 kHz AM 80% Modulation:
3 V/m)
◆Electrical fast transient/burst according to
EN 61000-4-4:2004
(AC/DC power supply: ±1 kV, Data/Signal lines:
±0.5 kV)
◆Surge immunity test according to EN 61000-4-
5:2006
(AC/DC Line to Line: ±1 kV, AC/DC Line to
Earth: ±2 kV)
◆Immunity to conducted disturbances, Induced
by radio-frequency fields: EN 61000-4-6:2007
(0.15 - 80 MHz with 1 kHz AM 80% Modulation:
3 V/m)
◆Voltage dips, short interruptions and voltage
variations immunity test according to EN 61000-
4-11:2004 (>95% Reduction @10 ms, 30%
Reduction @500 ms, >95% Reduction @5000
ms)
LVD: ◆EN 60950-1:2001

C OMPLIANCES
– 5 –
ES-3024G/3024GP
SAFETY COMPLIANCE
Warning: Fiber Optic Port Safety:
Avertissment: Ports pour fibres optiques - sécurité sur le plan optique:
Warnhinweis: Faseroptikanschlüsse - Optische Sicherheit:
POWER CORD SAFETY
Please read the following safety information carefully before installing the
switch:
WARNING: Installation and removal of the unit must be carried out by
qualified personnel only.
◆The unit must be connected to an earthed (grounded) outlet to comply
with international safety standards.
◆Do not connect the unit to an A.C. outlet (power supply) without an
earth (ground) connection.
◆The appliance coupler (the connector to the unit and not the wall plug)
must have a configuration for mating with an EN 60320/IEC 320
appliance inlet.
◆The socket outlet must be near to the unit and easily accessible. You
can only remove power from the unit by disconnecting the power cord
from the outlet.
◆This unit operates under SELV (Safety Extra Low Voltage) conditions
according to IEC 60950. The conditions are only maintained if the
equipment to which it is connected also operates under SELV
conditions.
France and Peru only
This unit cannot be powered from IT† supplies. If your supplies are of IT
type, this unit must be powered by 230 V (2P+T) via an isolation
transformer ratio 1:1, with the secondary connection point labelled
Neutral, connected directly to earth (ground).
† Impédance à la terre
When using a fiber optic port, never look at the transmit laser while it is
powered on. Also, never look directly at the fiber TX port and fiber cable
ends when they are powered on.
Ne regardez jamais le laser tant qu'il est sous tension. Ne regardez jamais
directement le port TX (Transmission) à fibres optiques et les embouts de
câbles à fibres optiques tant qu'ils sont sous tension.
Niemals ein Übertragungslaser betrachten, während dieses eingeschaltet
ist. Niemals direkt auf den Faser-TX-Anschluß und auf die Faserkabelenden
schauen, während diese eingeschaltet sind.
CLASS I
LASER DEVICE
DISPOSITIF LASER
DE CLASSE I
LASERGER
DER KLASSE I
ÄT

C OMPLIANCES
– 6 –
ES-3024G/3024GP
Important! Before making connections, make sure you have the correct
cord set. Check it (read the label on the cable) against the following:
Veuillez lire à fond l'information de la sécurité suivante avant d'installer le
Switch:
AVERTISSEMENT: L’installation et la dépose de ce groupe doivent être
confiés à un personnel qualifié.
◆Ne branchez pas votre appareil sur une prise secteur (alimentation
électrique) lorsqu'il n'y a pas de connexion de mise à la terre (mise à la
masse).
◆Vous devez raccorder ce groupe à une sortie mise à la terre (mise à la
masse) afin de respecter les normes internationales de sécurité.
◆Le coupleur d’appareil (le connecteur du groupe et non pas la prise
murale) doit respecter une configuration qui permet un branchement
sur une entrée d’appareil EN 60320/IEC 320.
◆La prise secteur doit se trouver à proximité de l’appareil et son accès
doit être facile. Vous ne pouvez mettre l’appareil hors circuit qu’en
débranchant son cordon électrique au niveau de cette prise.
◆L’appareil fonctionne à une tension extrêmement basse de sécurité qui
est conforme à la norme IEC 60950. Ces conditions ne sont maintenues
que si l’équipement auquel il est raccordé fonctionne dans les mêmes
conditions.
Power Cord Set
U.S.A. and Canada The cord set must be UL-approved and CSA certified.
The minimum specifications for the flexible cord are:
- No. 18 AWG - not longer than 2 meters, or 16 AWG.
- Type SV or SJ
- 3-conductor
The cord set must have a rated current capacity of at least 10 A
The attachment plug must be an earth-grounding type with NEMA 5-
15P (15 A, 125 V) configuration.
Denmark The supply plug must comply with Section 107-2-D1, Standard DK2-
1a or DK2-5a.
Switzerland The supply plug must comply with SEV/ASE 1011.
U.K. The supply plug must comply with BS1363 (3-pin 13 A) and be fitted
with a 5 A fuse which complies with BS1362.
The mains cord must be <HAR> or <BASEC> marked and be of type
HO3VVF3GO.75 (minimum).
Europe The supply plug must comply with CEE7/7 (“SCHUKO”).
The mains cord must be <HAR> or <BASEC> marked and be of type
HO3VVF3GO.75 (minimum).
IEC-320 receptacle.

C OMPLIANCES
– 7 –
ES-3024G/3024GP
France et Pérou uniquement:
Ce groupe ne peut pas être alimenté par un dispositif à impédance à la
terre. Si vos alimentations sont du type impédance à la terre, ce groupe
doit être alimenté par une tension de 230 V (2 P+T) par le biais d’un
transformateur d’isolement à rapport 1:1, avec un point secondaire de
connexion portant l’appellation Neutre et avec raccordement direct à la
terre (masse).
Bitte unbedingt vor dem Einbauen des Switches die folgenden
Sicherheitsanweisungen durchlesen:
WARNUNG: Die Installation und der Ausbau des Geräts darf nur durch
Fachpersonal erfolgen.
◆Das Gerät sollte nicht an eine ungeerdete Wechselstromsteckdose
angeschlossen werden.
◆Das Gerät muß an eine geerdete Steckdose angeschlossen werden,
welche die internationalen Sicherheitsnormen erfüllt.
◆Der Gerätestecker (der Anschluß an das Gerät, nicht der
Wandsteckdosenstecker) muß einen gemäß EN 60320/IEC 320
konfigurierten Geräteeingang haben.
◆Die Netzsteckdose muß in der Nähe des Geräts und leicht zugänglich
sein. Die Stromversorgung des Geräts kann nur durch Herausziehen
des Gerätenetzkabels aus der Netzsteckdose unterbrochen werden.
◆Der Betrieb dieses Geräts erfolgt unter den SELV-Bedingungen
(Sicherheitskleinstspannung) gemäß IEC 60950. Diese Bedingungen
sind nur gegeben, wenn auch die an das Gerät angeschlossenen Geräte
unter SELV-Bedingungen betrieben werden.
Cordon électrique - Il doit être agréé dans le pays d’utilisation
Etats-Unis et Canada: Le cordon doit avoir reçu l’homologation des UL et un certificat de
la CSA.
Les spécifications minimales pour un cable flexible sont AWG No.
18, ouAWG No. 16 pour un cable de longueur inférieure à 2 mètres.
- type SV ou SJ
- 3 conducteurs
Le cordon doit être en mesure d’acheminer un courant nominal
d’au moins 10 A.
La prise femelle de branchement doit être du type à mise à la terre
(mise à la masse) et respecter la configuration NEMA 5-15P (15 A,
125 V).
Danemark: La prise mâle d’alimentation doit respecter la section 107-2 D1 de
la norme DK2 1a ou DK2 5a.
Suisse: La prise mâle d’alimentation doit respecter la norme SEV/ASE
1011.
Europe La prise secteur doit être conforme aux normes CEE 7/7
(“SCHUKO”)
LE cordon secteur doit porter la mention <HAR> ou <BASEC> et
doit être de type HO3VVF3GO.75 (minimum).

C OMPLIANCES
– 8 –
ES-3024G/3024GP
WARNINGS AND CAUTIONARY MESSAGES
W ARNING : This product does not contain any serviceable user parts.
W ARNING : Installation and removal of the unit must be carried out by
qualified personnel only.
W ARNING : When connecting this device to a power outlet, connect the field
ground lead on the tri-pole power plug to a valid earth ground line to
prevent electrical hazards.
W ARNING : This switch uses lasers to transmit signals over fiber optic cable.
The lasers are compliant with the requirements of a Class 1 Laser Product
and are inherently eye safe in normal operation. However, you should
never look directly at a transmit port when it is powered on.
C AUTION : Wear an anti-static wrist strap or take other suitable measures to
prevent electrostatic discharge when handling this equipment.
C AUTION : Do not plug a phone jack connector in the RJ-45 port. This may
damage this device.
C AUTION : Use only twisted-pair cables with RJ-45 connectors that conform
to FCC standards.
ENVIRONMENTAL STATEMENTS
The manufacturer of this product endeavours to sustain an
environmentally-friendly policy throughout the entire production process.
This is achieved though the following means:
◆Adherence to national legislation and regulations on environmental
production standards.
◆Conservation of operational resources.
◆Waste reduction and safe disposal of all harmful un-recyclable by-
products.
◆Recycling of all reusable waste content.
◆Design of products to maximize recyclables at the end of the product’s
life span.
◆Continual monitoring of safety standards.
Stromkabel. Dies muss von dem Land, in dem es benutzt wird geprüft werden:
Schweiz Dieser Stromstecker muß die SEV/ASE 1011Bestimmungen einhalten.
Europe Das Netzkabel muß vom Typ HO3VVF3GO.75 (Mindestanforderung) sein
und die Aufschrift <HAR> oder <BASEC> tragen.
Der Netzstecker muß die Norm CEE 7/7 erfüllen (”SCHUKO”).

C OMPLIANCES
– 9 –
ES-3024G/3024GP
END OF PRODUCT LIFE SPAN
This product is manufactured in such a way as to allow for the recovery and
disposal of all included electrical components once the product has reached
the end of its life.
MANUFACTURING MATERIALS
There are no hazardous nor ozone-depleting materials in this product.
DOCUMENTATION
All printed documentation for this product uses biodegradable paper that
originates from sustained and managed forests. The inks used in the
printing process are non-toxic.

– 10 –
ES-3024G/3024GP
ABOUT THIS GUIDE
PURPOSE This guide details the hardware features of the switches, including the
physical and performance-related characteristics, and how to install the
switches.
AUDIENCE The guide is intended for use by network administrators who are
responsible for installing and setting up network equipment; consequently,
it assumes a basic working knowledge of LANs (Local Area Networks).
CONVENTIONS The following conventions are used throughout this guide to show
information:
N OTE : Emphasizes important information or calls your attention to related
features or instructions.
C AUTION : Alerts you to a potential hazard that could cause loss of data, or
damage the system or equipment.
W ARNING : Alerts you to a potential hazard that could cause personal injury.
RELATED PUBLICATIONS The following publication gives specific information on how to operate and
use the management functions of the switch:
The User Manual
Also, as part of the switch’s software, there is an online web-based help
that describes all management related features.
REVISION HISTORY This section summarizes the changes in each revision of this guide.
SEPTEMBER 7TH 2009 REVISION
This is the first revision of this guide. It is valid for the initial release for the
standard version.

– 11 –
ES-3024G/3024GP
CONTENTS
COMPLIANCES AND SAFETY STATEMENTS 3
ABOUT THIS GUIDE 10
CONTENTS 11
FIGURES 14
TABLES 15
1I
NTRODUCTION 16
Overview 16
Switch Architecture 17
Network Management Options 17
Power-over-Ethernet 17
Description of Hardware 18
10/100/1000BASE-T Ports 18
SFP Transceiver Slots 18
Port and System Status LEDs 19
Mode Button 20
Power Supply Inlet 20
Grounding Point 20
Reset Button 21
Console Port 21
2NETWORK PLANNING 22
Introduction To Switching 22
Application Examples 22
Collapsed Backbone 22
PoE Connections 23
Network Aggregation Plan 24
Remote Connections with Fiber Cable 24
Making VLAN Connections 25
Application Notes 26

C ONTENTS
– 12 –
ES-3024G/3024GP
3INSTALLING THE SWITCH 27
Selecting a Site 27
Ethernet Cabling 27
Equipment Checklist 28
Optional Rack-Mounting Equipment 29
Mounting 29
Rack Mounting 29
Desktop or Shelf Mounting 32
Installing an Optional SFP Transceiver 32
Connecting to a Power Source 33
Connecting to the Console Port 34
Wiring Map for Serial Cable 34
4MAKING NETWORK CONNECTIONS 36
Connecting Network Devices 36
Twisted-Pair Devices 36
Power-over-Ethernet Connections 36
Cabling Guidelines 37
Connecting to PCs, Servers, Hubs, and Switches 37
Network Wiring Connections 38
Fiber Optic SFP Devices 39
Connectivity Rules 41
1000BASE-T Cable Requirements 41
1000 Mbps Gigabit Ethernet Collision Domain 41
100 Mbps Fast Ethernet Collision Domain 42
10 Mbps Ethernet Collision Domain 42
Cable Labeling and Connection Records 42
ATROUBLESHOOTING 44
Diagnosing LED Indicators 44
Power and Cooling Problems 44
Installation 44
In-Band Access 45
BCABLES AND PINOUTS 46
Twisted-Pair Cable Assignments 46
10/100BASE-TX Pin Assignments 46
Straight-Through Wiring 47

C ONTENTS
– 13 –
ES-3024G/3024GP
Crossover Wiring 48
1000BASE-T Pin Assignments 48
Fiber Standards 50
CHARDWARE SPECIFICATIONS 51
Physical Characteristics 51
Switch Features 52
Management Features 53
Standards 53
Compliances 53
GLOSSARY 55
INDEX 58

– 14 –
ES-3024G/3024GP
FIGURES
Figure 1: Front and Rear Panels 16
Figure 2: Port and System LEDs 19
Figure 3: Power Supply Inlet 20
Figure 4: Reset Button 21
Figure 5: Console Port 21
Figure 6: Collapsed Backbone 23
Figure 7: Supplying PoE Power 24
Figure 8: Network Aggregation Plan 24
Figure 9: Remote Connections with Fiber Cable 25
Figure 10: Making VLAN Connections 25
Figure 11: RJ-45 Connections 28
Figure 12: Grounding 29
Figure 13: Attaching the Brackets 30
Figure 14: Installing the Switches in a Rack 31
Figure 15: Attaching the Adhesive Feet 32
Figure 16: Installing an Optional SFP Transceiver into a Slot 32
Figure 17: Power Inlet 33
Figure 18: Console Cable 34
Figure 19: Making-Twisted-Pair Connections 37
Figure 20: Network Wiring Connections 39
Figure 21: Making Fiber Port Connections 40
Figure 22: RJ-45 Connector 46
Figure 23: Straight Through Wiring 47
Figure 24: Crossover Wiring 48

– 15 –
ES-3024G/3024GP
TABLES
Table 1: Supported SFP Transceivers 18
Table 2: Port Status LEDs 19
Table 3: System Status LEDs 20
Table 4: Serial Cable Wiring 34
Table 5: Maximum 1000BASE-T Gigabit Ethernet Cable Length 41
Table 6: Maximum 1000BASE-SX Gigabit Ethernet Cable Lengths 41
Table 7: Maximum 1000BASE-LX Gigabit Ethernet Cable Length 41
Table 8: Maximum 1000BASE-LH Gigabit Ethernet Cable Length 42
Table 9: Maximum 100BASE-FX Cable Length 42
Table 10: Maximum Fast Ethernet Cable Length 42
Table 11: Maximum Ethernet Cable Length 42
Table 12: LED Indicators 44
Table 13: 10/100BASE-TX MDI and MDI-X Port Pinouts 47
Table 14: 1000BASE-T MDI and MDI-X Port Pinouts 49
Table 15: Fiber Standards 50

– 16 –
ES-3024G/3024GP
1INTRODUCTION
OVERVIEW
The ES-3024G and ES-3024GP are Gigabit Ethernet Layer 2 switches with
24 10/100/1000-BASE-T ports, and four Small Form Factor Pluggable (SFP)
transceiver slots that operate in combination with ports 21~24 (see
Figure 1 on page 16, Ports 21-24). The ES-3024GP also provides PoE
power to connected devices. The switches also include an SNMP-based
management agent, which provides both in-band and out-of-band access
for managing the switch.
Both switches provide a broad range of powerful features for Layer 2
switching, delivering reliability and consistent performance for your
network traffic. They bring order to poorly performing networks by
segregating them into separate broadcast domains with IEEE 802.1Q
compliant VLANs, and empowers multimedia applications with multicast
switching and CoS services.
Figure 1: Front and Rear Panels
AC 100-240V, 50-60Hz, 3A
ES-3024G
ES-3024GP
Port Status Indicators System Indicators
10/100 Mbps RJ-45 Ports 1000BASE SFP Ports
Reset Button Grounding Point
Power Inlet
Console Port
Mode Button

C HAPTER 1 | Introduction
Switch Architecture
– 17 –
ES-3024G/3024GP
SWITCH ARCHITECTURE
The switch employs a wire-speed, non-blocking switching fabric. This
permits simultaneous wire-speed transport of multiple packets at low
latency on all ports. The switch also features full-duplex capability on all
ports, which effectively doubles the bandwidth of each connection.
This switch uses store-and-forward switching to ensure maximum data
integrity. With store-and-forward switching, the entire packet must be
received into a buffer and checked for validity before being forwarded. This
prevents errors from being propagated throughout the network.
NETWORK MANAGEMENT OPTIONS
With a comprehensive array of LEDs, the switch provides “at a glance”
monitoring of network and port status. The switch can be managed over
the network with a web browser or Telnet application, or via a direct
connection to the console port. The switch includes a built-in network
management agent that allows it to be managed in-band using SNMP or
RMON (Groups 1, 2, 3, 9) protocols. It also has an RJ-45 serial port (DB-9
connector) for out-of-band management. A PC may be connected to this
port for configuration and monitoring out-of-band via the supplied RJ-45 to
RS232 (DB-9 connector) serial cable.
For a detailed description of the management features, refer to the User
Manual.
POWER-OVER-ETHERNET
The first six ports (ports 1~6) of the ES-3024GP's 24 10/100/1000 Mbps
ports support the IEEE802.3at Draft standard version that enables DC
power to be supplied to attached devices using wires in the connecting
Ethernet cable. The rest of the ES-3024GP's 24 10/100/1000 Mbps ports
(ports 7~24) support the normal PoE (802.3af). The total PoE power
delivered by all ports cannot exceed 185W power budget.
Any PoE-compliant device attached to a port can directly draw power from
the switch over the Ethernet cable without requiring its own separate
power source. This capability gives network administrators centralized
power control for devices such as IP phones and wireless access points,
which translates into greater network availability.
For each attached PoE-compliant device, the switch automatically senses
the load and dynamically supplies the required power. The switch delivers
power to a device using the wire pairs in UTP or STP cable. The first six
ports on the switch can provide up to 30 W of power, while the remaining
ports (ports 7~24) can provide 15.4W of power.

C HAPTER 1 | Introduction
Description of Hardware
– 18 –
ES-3024G/3024GP
DESCRIPTION OF HARDWARE
10/100/1000BASE-T
PORTS
The switch contains 24 Gigabit RJ-45 ports that operate at 10 Mbps or 100
Mbps, half or full duplex, or at 1000 Mbps, full duplex. Because these ports
support automatic MDI/MDI-X operation, you can use straight-through
cables for all network connections to PCs or servers, or to other switches or
hubs.
Each of these ports supports auto-negotiation, so the optimum
transmission mode (half or full duplex), and data rate (10, 100 or 1000
Mbps) can be selected automatically. If a device connected to one of these
ports does not support auto-negotiation, the communication mode of that
port can be configured manually.
Each port also supports IEEE 802.3x auto-negotiation of flow control, so
the switch can automatically prevent port buffers from becoming
saturated.
SFP TRANSCEIVER
SLOTS
The Small Form Factor Pluggable (SFP) transceiver slots are shared with
RJ-45 ports 21~24. In the default configuration, if an SFP transceiver
(purchased separately) is installed in a slot and has a valid link on the port,
the associated RJ-45 port is disabled. The switch can also be configured to
force the use of an RJ-45 port or SFP slot, as required.
The following table shows a list of transceiver types which have been
tested with the switch. For an updated list of vendors supplying these
transceivers, contact your local dealer. For information on the
recommended standards for fiber optic cabling, see “Fiber Standards” on
page 50.
Table 1: Supported SFP Transceivers
Media Standard Fiber Diameter (microns) Wavelength (nm) Maximum Distancea
a. Maximum distance may vary for different SFP vendors.
1000BASE-SX 50/125 850 700 m
62.5/125 850 400 m
1000BASE-LX 50/125 1300 550 m
62.5/125 1300 550 m
9/125 1300 10 km
1000BASE-LH 9/125 1310 35 km
1550 80 km
100BASE-FX 50/125 or 62.5/125 1300 2 km
9/125 1300 20 km
1000BASE-T 100 m

C HAPTER 1 | Introduction
Description of Hardware
– 19 –
ES-3024G/3024GP
PORT AND SYSTEM
STATUS LEDS
The switch includes a display panel for key system and port indications that
simplify installation and network troubleshooting. The LEDs, which are
located on the front panel for easy viewing, are shown below and described
in the following tables.
Figure 2: Port and System LEDs
Table 2: Port Status LEDs
LED Condition Status
Gigabit Ethernet Ports (Ports 1-24)
Link/Activity/
Speed
(Mode button
not depressed)
On/Flashing Amber Port has established a valid 10/100 Mbps network
connection. Flashing indicates activity.
On/Flashing Green Port has established a valid 1000 Mbps network
connection. Flashing indicates activity.
Off There is no valid link on the port.
PoE Status
(Mode button is
depressed)
On Amber A PoE device is connected.
Off No PoE device is connected.
SFP Gigabit Ethernet Ports (Ports 21-24)
(SFP Inserted) On Green A valid SFP transceiver is installed in the slot.
Off No SFP transceiver is installed in the slot.
Port LEDs System LEDs

C HAPTER 1 | Introduction
Description of Hardware
– 20 –
ES-3024G/3024GP
MODE BUTTON When the Mode button is depressed, the port LEDs display PoE information.
When the Mode button is not depressed, the port LEDs display link and
activity information.
POWER SUPPLY INLET There is one power inlet on the rear panel of the switch. The standard
power inlet is for the AC power cord.
Figure 3: Power Supply Inlet
GROUNDING POINT To prevent accidental electrical shock or damage to your switch, it is
recommended that you ground the switch to an earth point by attaching a
grounding wire (not supplied) to the grounding point located next to the
power inlet, with a metal screw. If located in a tall building, grounding
points include metal drain pipes, and other electrostatic conductive devices
that lead to the ground, or if located on the first floor of a building, the
ground outside itself.
Table 3: System Status LEDs
LED Condition Status
PWR On Green The unit’s internal power supply is operating
normally.
Off The unit has no power connected.
Diag/PoE
(Mode button
not depressed)
On Green The system diagnostic test has completed
successfully.
Flashing Green The system boot up is in progress.
On Amber The system diagnostic test is in progress.
Flashing Amber The system diagnostic test has detected a fault.
Diag/PoE
(Mode button
depressed)
On Amber Port LEDs display PoE status.
Flashing Amber Supplied PoE power has reached 95% or more of
the total system power budget.
AC 100-240V, 50-60Hz, 3A
