LG SIGNATURE InstaView URETC1408N User manual

www.LGSIGNATURE.com
Read this owner’s manual thoroughly before operating the appliance and keep it handy for reference at
all times.
OWNER'S MANUAL
WINE CELLAR
Copyright © 2020 LG Electronics Inc. All Rights Reserved
EN ENGLISH
MFL71467804
Rev.00_012120

TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS ................................. 4
READ ALL INSTRUCTIONS BEFORE USE............................4
WARNING.............................................................................4
CAUTION ............................................................................10
CARING FOR THE ENVIRONMENT...................................12
INSTALLATION ............................................. 13
Before Installation ............................................................13
Levelling the Appliance ....................................................13
Turning on the Power ......................................................14
Moving the Appliance for Relocation .............................14
OPERATION .................................................. 15
Before Use .........................................................................15
Product Features...............................................................17
Control Panel.....................................................................20
Automatic Opening Door.................................................22
InstaView............................................................................22
Storing Wine ......................................................................23
Storage Racks....................................................................24
Door Basket .......................................................................26
Shelf....................................................................................26
Auto-lift Device ..................................................................26
SMART FUNCTIONS...................................... 30
LG ThinQ Application........................................................30
Using the Voice Assistant.................................................32
Smart Diagnosis................................................................33
MAINTENANCE ............................................. 34
Cleaning .............................................................................34

Air Filter..............................................................................34
TROUBLESHOOTING .................................... 36
Before Calling for Service ................................................36

4 SAFETY INSTRUCTIONS EN
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as
described below.
Safety Messages
WARNING
WARNING
• To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic
precautions, including the following:
Technical Safety
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
This symbol is displayed to indicate matters and operations
that can cause risk. Read the part with this symbol carefully
and follow the instructions in order to avoid risk.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the product.

5 SAFETY INSTRUCTIONS EN
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure
that they do not play with the appliance.
• Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• This appliance is intended to be used in household and similar
applications only. It should not be used for commercial, or catering
purposes, or in any mobile application such as a caravan or boat.
•
• This appliance contains a small amount of isobutane refrigerant
(R600a), but it is also combustible. When transporting and installing
the appliance, care should be taken to ensure that no parts of the
refrigerating circuit are damaged.
• The refrigerant and insulation blowing gas used in the appliance
require special disposal procedures. Consult with service agent or a
similarly qualified person before disposing of them.
• Do not damage the refrigerant circuit.
• If the power cord is damaged or the hole of the outlet socket is loose,
do not use the power cord and contact an authorized service centre.
• Do not locate multiple portable outlet sockets or portable power
supplies at the rear of the appliance.
• Securely plug the power plug in the outlet socket after completely
removing any moisture and dust.
• Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the outlet
socket.
This symbol alerts you to flammable materials that can
ignite and cause a fire if you do not take care.

6 SAFETY INSTRUCTIONS EN
• Keep ventilation openings, in the appliance enclosure or in the built-
in structure, clear of obstruction.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• Do not tilt the appliance to pull or push it when transporting.
• When positioning the appliance, ensure the supply cord is not
trapped or damaged.
• Do not use mechanical devices or other means to accelerate the
defrosting process.
• Do not use a hair drier to dry the inside of the appliance or place a
candle inside to remove the odours.
• Do not use electrical appliances inside the refrigerator.
• Make sure not to get a body part such as a hand or foot stuck while
moving the appliance.
• Disconnect the power cord before cleaning the appliance or
replacing the inside lamp (where fitted).
• Do not spray water or inflammable substances (toothpaste, alcohol,
thinner, benzene, flammable liquid, abrasive, etc.) over the interior or
exterior of the appliance to clean it.
• Do not clean the appliance with brushes, cloths or sponges with
rough surfaces or which are made of metallic material.
• Only qualified service personnel from LG Electronics service centre
should disassemble, repair, or modify the appliance. Contact an LG
Electronics customer information centre if you move and install the
appliance in a different location.
Risk of Fire and Flammable Materials
• If a leak is detected, avoid any naked flames or potential sources of
ignition and air the room in which the appliance is standing for
several minutes. In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the size of the
room in which the appliance is used should correspond to the
amount of refrigerant used. The room must be 1 m² in size for every
8 g of R600a refrigerant inside the appliance.

7 SAFETY INSTRUCTIONS EN
• Refrigerant leaking out of the pipes could ignite or cause an
explosion.
• The amount of refrigerant in your particular appliance is shown on
the identification plate inside the appliance.
Installation
• This appliance should only be transported by two or more people
holding the appliance securely.
• Install the appliance on a firm and level floor.
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• Do not place the appliance in direct sunlight or expose it to the heat
from heating appliances such as stoves or heaters.
• Be careful not to expose the rear of the appliance when installing.
• Install the appliance in a place where is easy to unplug the power
plug of the appliance.
• Be careful not to let the appliance door fall during assembly or
disassembly.
• Be careful not to pinch, crush, or damage the power cable during
assembly or disassembly of the appliance door.
• Be careful not to point the power plug up or let the appliance lean
against the power plug.
• Do not connect a plug adapter or other accessories to the power
plug.
• Do not modify or extend the power cable.
• Ensure that the outlet socket is properly grounded, and that the earth
pin on the power cord is not damaged or removed from the power
plug. For more details on grounding, inquire at an LG Electronics
customer information centre.
• This appliance is equipped with a power cord having an equipment-
grounding conductor and a grounding power plug. The power plug

8 SAFETY INSTRUCTIONS EN
must be plugged into an appropriate outlet socket that is installed
and grounded in accordance with all local codes and ordinances.
• Never start up an appliance showing any signs of damage. If in doubt,
consult your dealer.
• Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can cause
suffocation.
• Do not plug the appliance into a multi socket adapter which does not
have a power cable (mounted).
• The appliance should be connected to a dedicated power line which
is separately fused.
• Do not use a multi socket outlet which is not properly grounded
(portable). In case of using a properly-grounded multi socket outlet
(portable), use the multi socket outlet with the current capacity of the
power cord rating or higher and use the multi socket outlet only for
the appliance.
Operation
• Do not use the appliance for any purpose (storage of medical or
experimental materials or shipping) other than any domestic
household food storage use.
• If water penetrates electrical parts of the appliance, disconnect
power plug and contact an LG Electronics customer information
centre.
• Unplug the power plug during a severe thunderstorm or lightening
or when not in use for a long period of time.
• Do not touch the power plug or the appliance controls with wet
hands.
• Do not bend the power cable excessively or place a heavy object on it.
• Immediately unplug the power plug and contact an LG Electronics
customer information centre if you detect a strange sound, odour, or
smoke coming from the appliance.
• Do not place hands or metallic objects inside the area emitting the
cold air, cover or heat releasing grille on the back.

9 SAFETY INSTRUCTIONS EN
• Do not apply excessive force or impact to the back cover of the
appliance.
• Be careful of nearby children when you open or close the appliance
door. The door may bump the child and cause injury.
• Avoid the danger of children getting trapped inside the appliance. A
child trapped inside the appliance can cause suffocation.
• Do not put animals, such as pets into the appliance.
• Do not place heavy or fragile objects, containers filled with liquid,
combustible substances, flammable objects (such as candles, lamps,
etc.), or heating devices (such as stoves, heaters, etc.) on the
appliance.
• Do not place any electronic appliance (such as heater and mobile
phone) inside the appliance.
• If there is a gas leakage (isobutane, propane, natural gas, etc.), do not
touch the appliance or power plug and ventilate the area
immediately. This appliance uses a refrigerant gas (isobutane,
R600a). Although it uses a small amount of the gas, it is still
combustible gas. Gas leakage during appliance transport, installation
or operation can cause fire, explosion or injury if sparks are caused.
• Do not use or store flammable or combustible substances (ether,
benzene, alcohol, chemical, LPG, combustible spray, insecticide, air
freshener, cosmetics, etc.) near the appliance.
Auto-lift Feature
• The auto-lift drawer function can be used by children aged 8 years
and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning its use in a safe way and
understand the hazards involved. The function can be turned off in
the control panel, if desired.
• Do not allow children to play with or climb inside the drawer’s inner
compartment.
• Do not use the auto-lift function while folding the rear drawer back
cover.

10 SAFETY INSTRUCTIONS EN
• Do not put your hand in the open areas at the sides or back of the
drawer when open.
• Keep feet away from the bottom drawer when using the auto-open
feature.
• Turn off the appliance before cleaning the bottom drawer
compartment.
• The auto-lift device is heavy, so remove it with both hands.
• Do not unlock the locking knob of auto-lift device. The device could be
activated, unfold, and be damaged.
Disposal
• When discarding the appliance, remove the door gasket while leaving
the shelves and baskets in place and keep children away from the
appliance.
CAUTION
CAUTION
• To reduce the risk of minor injury to persons, malfunction, or damage
to the product or property when using this product, follow basic
precautions, including the following:
Operation
• Do not touch frozen food or the metal parts in the freezer
compartment with wet or damp hands. It may cause frostbite.
• Do not place glass containers, bottles or cans (especially those
containing carbonated drinks) in the freezer compartment, shelves or
ice bin that will be exposed to temperatures below freezing.
• The tempered glass on the front side of the appliance door or the
shelves can be damaged by an impact. If it is broken, do not touch it
with hands.
• Do not hang from the appliance doors, storage room, shelf or climb
up into it.

11 SAFETY INSTRUCTIONS EN
• Do not store an excessive amount of water bottles or containers for
side dishes on the door baskets.
• Do not open or close the appliance door with excessive force.
• If the hinge of the appliance door is damaged or operates
improperly, stop using the appliance and contact an authorized
service centre.
• Prevent animals from nibbling on the power cable or water hose.
• Never eat frozen foods immediately after they have been taken out in
the freezer compartment.
• Do not use a thin crystal cup or chinaware when dispensing.
• Make sure not to get a hand or foot stuck upon opening or closing the
appliance door or door in door.
Wine Storage
• Pull wine racks open gently. Jerking the racks out may cause bottles
to fall.
• Store only wine bottles in the wine storage compartment. The
temperature of the compartment is too high to safely preserve
refrigerated foods.
Maintenance
• Do not clean glass shelves or covers with warm water when they are
cold. They may shatter if exposed to sudden temperature changes.
• Do not insert the shelves upside down. The shelves may fall.
• To remove frost from the appliance, contact an LG Electronics
customer information centre.
• Dispose of the ice inside the ice bin in the freezer compartment
during an extended power outage.

12 SAFETY INSTRUCTIONS EN
CARING FOR THE ENVIRONMENT
Disposal of Your Old Appliance
• This crossed-out wheeled bin symbol indicates that waste
electrical and electronic products (WEEE) should be
disposed of separately from the municipal waste stream.
• Old electrical products can contain hazardous
substances so correct disposal of your old appliance will
help prevent potential negative consequences for the
environment and human health. Your old appliance may
contain reusable parts that could be used to repair other
products, and other valuable materials that can be
recycled to conserve limited resources.
• You can take your appliance either to the shop where you
purchased the product, or contact your local government
waste office for details of your nearest authorised WEEE
collection point. For the most up to date information for
your country please see www.lg.com/global/recycling.

13 INSTALLATION EN
INSTALLATION
Before Installation
Dimensions and Clearances
Too small of a distance from adjacent items may
result in the degradation of freezing capability and
increased electricity costs. Allow over 50 mm of
clearance between the back of the appliance and
the wall when installing the appliance.
NOTE
• You can determine what type of appliance it is by
looking at the label inside the appliance.
Ambient Temperature
• The appliance is designed to operate within a
limited range of ambient temperatures,
depending on the climate zone.
• The internal temperatures could be affected by
the location of the appliance, the ambient
temperature, the frequency of door opening and
so on.
• The climate class can be found on the rating
label.
* Australia, India, Kenya
** Argentina, Ecuador
NOTE
• The appliances rated from SN to T are intended
to be used at an ambient temperature between
10 ºC and 43 ºC.
Levelling the Appliance
Adjusting the Levelling Leg
If the appliance seems unsteady, or the doors do
not close easily, adjust the appliance’s tilt using the
instructions below.
Type Dimensions
A 695 mm
B 1 753 mm
C 1 793 mm
D 735 mm
E 23 mm
F 711 mm
G 1 300 mm
H 1 020 mm
I 700 mm
A
D
GF
BC
E
H
I
Climate Class Ambient Temperature
Range ºC
SN (Extended
Temperate)
+10 - +32
N (Temperate) +16 - +32
ST (Subtropical) +16 - +38 / +18 - +38**
T (Tropical) +10 - +43* / +16 - +43 /
+18 - +43**

14 INSTALLATION EN
1 Open the bottom drawer and remove the cover
from the appliance.
2 Turn the levelling leg to the left to raise that
side of the appliance or to the right to lower it.
It may take several turns of the levelling leg to
adjust the tilt of the appliance.
3 Open the door and the drawers and check to
make sure that they close easily. If they do not
close easily, tilt the appliance slightly more to
the rear by turning both levelling legs to the
left. It may take several more turns, and be
sure to turn both levelling legs the same
amount.
4 When the appliance is level, open the bottom
drawer and reassemble the cover.
Turning on the Power
Connecting the Appliance
After installing the appliance, connect the power
plug into the outlet socket.
NOTE
• After connecting the power supply cord (or plug)
to the outlet, wait 3 or 4 hours before you put
food into the appliance. If you add food before
the appliance has cooled completely, your food
may spoil.
Moving the Appliance for
Relocation
Preparing for Relocation
1 Remove all food from inside the appliance.
2 Pull the power plug out, insert and fix it into the
power plug hook at the rear or on top of the
appliance.
3 Tape parts such as shelves and the door handle
to prevent from falling off while moving the
appliance.
4 Move the appliance with more than two people
carefully. When transporting the appliance
over a long distance, keep the appliance
upright.
5 After installing the appliance, connect the
power plug into a mains outlet socket and
switch it on.

15 OPERATION EN
OPERATION
Before Use
Notes for Operation
• Users should keep in mind that frost can form if
the door is not closed completely or if the
humidity is high during the summer.
• Ensure there is sufficient space between food
stored on the shelf or door basket to allow the
door to close completely.
• Opening the door for long periods can cause a
significant increase of the temperature in the
compartments of the appliance.
• If the refrigerating appliance is left empty for
long periods, switch off, defrost, clean, dry, and
leave the door open to prevent mould
developing within the appliance.
Door Open Alarm
The alarm sounds 3 times in 30 second intervals if
the door is left open or not completely closed for 1
minute.
NOTE
• Contact the LG Electronics customer information
centre if the alarm sound continues even after
closing all doors.
Failure Detection
The appliance can automatically detect problems
during the operation.
NOTE
• If a problem is detected, the appliance may not
operate and an error code is displayed even
when any button is pressed.
• If an error code is indicated on the display, do
not turn off the power. Immediately contact the
LG Electronics customer information centre and
report the error code. If you turn off the power,
the repair technician from the our information
centre may have difficulty finding the problem.
Suggestion for Energy Saving
• Ensure there is sufficient space between stored
foods. This allows cold air to be circulated evenly
and lowers electricity bills.
• Store hot food only after it has cooled in order to
prevent dew or frost.
• When storing food in the freezer compartment,
set the freezer temperature lower than the
temperature indicated on the food.
• Do not set the temperature of the appliance
lower than needed.
• Do not put food near the temperature sensor of
the fridge compartment. Keep a distance of at
least 3 cm from the sensor.
• Note that a temperature rise after defrosting has
a permissible range in the appliance
specifications. If you wish to minimise the impact
on the food storage due to a temperature rise,
seal or wrap the stored food in several layers.
• The automatic defrosting system in the
appliance ensures that the compartment
remains free of ice buildup under normal
operating conditions.
Storing Foods Effectively
• Store frozen food or refrigerated food inside
sealed containers.
• Check the expiration date and label (storage
instructions) before storing food in the
appliance.
• Do not store food for a long period of time (more
than 4 weeks) if it spoils easily at a low
temperature.
• Place the refrigerated food or frozen food in
each fridge or freezer compartment
immediately after purchasing.

16 OPERATION EN
• Store raw meat and fish in suitable containers in
the refrigerator, so that it is not in contact with or
drip onto other food.
• Refrigerated foods and other food items can be
stored on top of the vegetable drawer.
• Avoid refreezing any food which has been
completely thawed. Freezing any food which has
been completely thawed again will lower its taste
and nutrition.
• Cool hot food before storing. If too much hot
food is placed inside, the internal temperature of
the appliance can increase and negatively affect
other foods stored in the appliance.
• Do not overfill the appliance. Cold air can not
circulate properly if the appliance is overfilled.
• If you set an excessively low temperature for
food, it may become frozen. Do not set a
temperature lower than the required
temperature for the food to be stored correctly.
• If there are chill compartments in the appliance,
do not store vegetables and fruits with higher
moisture content in the chill compartments as
they may freeze due to the lower temperature.
• In the event of a blackout, call the electricity
company and ask how long it is going to last.
- You should avoid door openings while the
power is off.
- When the power supply gets back to normal,
check the condition of the food.
Freezing the Maximum Amount
of Food
If large quantities of food are to be stored, the
inner container and auto-lift device should be
taken out of the bottom drawer.
CAUTION
• To remove the drawers, first remove the food
from drawers and then pull out the drawers
carefully. Not doing so could cause injury or
damage to the drawers.

17 OPERATION EN
Product Features
The appearance or components of the appliance may differ from model to model.
Exterior
a Voice Assistant Device
A voice assistant device is built into the door.
b InstaView Door
The sleek tinted glass panel illuminates with two quick knocks, allowing you to see inside the easy
access compartment without ever opening the door.
c Control Panel
Displays the wine, fridge, and freezer temperature controls.
d Bottom Pullout Drawer Button
When the button is pressed, the bottom drawer opens automatically and the inner compartment rises
up for convenient access.
e Automatic Door Opening Sensors
Stand close enough to the front of the appliance and DOOR OPEN appears on the floor. Pass your foot
over the words on the floor to open the wine storage door automatically.

18 OPERATION EN
Interior
a Fresh Filter
This reduces odours inside the wine compartment.
b Upper Zone
Stores bottles of red wine.
c Storage Rack
Stores wine bottles on their sides for best long-term storage.
d Zone Divider
Helps maintain separate temperature zones.
e Lower Zone
Stores bottles of white wine and champagne.
f Champagne Drawer
Stores champagne bottles. Before storing champagne, turn on the champagne function in the control
panel.
g Durabase Divider
Provides storage for large food items.
h Quick Freezing Zone
When you set the middle and bottom drawer to the freezer mode, the quick freezing zone will reach the
set temperature most quickly.
i Middle / Bottom Drawer
The 2 drawers can be set to either Fridge or Freezer mode. Both drawers must use the same mode.
• To store fresh food, press the
Fridge Drawer button for at least 1 second.

19 OPERATION EN
• To store frozen food, press the Freezer Drawer button for at least 1 second.
CAUTION
• Empty out both drawers before changing the mode from freezer to fridge or vice versa.
• If the mode is changed while food is in the drawer, the food could spoil.
j Inner Container
This is where fruits and vegetables are stored to help maintain freshness by adjusting the humidity
controller.

20 OPERATION EN
Control Panel
The actual control panel may differ from model to model.
Control Panel and Functions
a Voice Assistant
Changes voice assistant settings. This button allows you to activate/deactivate the Voice Assistant. To
use the voice assistant feature, the appliance must be connected to the
LG ThinQ application. For more
information on connecting the appliance, refer to the
SMART FUNCTIONS .
b Wi-Fi
This button allows the appliance to connect to a home Wi-Fi network. Refer to SMART FUNCTIONS for
information on the initial setup of the
LG ThinQ application.
c Auto Door
The door opens automatically if you place a foot near the motion sensor at the bottom of the door. This
is convenient when you have both hands full and need to open the door.
To set the automatic opening door function, press the button repeatedly to toggle between the ON,
Sound Off, and OFF settings.
d Wine Upper
Indicates the set temperature of the upper zone in Celsius (°C). The default temperature is 13 °C .
Press the
Wine Upper button repeatedly to select a new set temperature from 11 °C to 18 °C .
e Wine Lower
Indicates the set temperature of the lower zone in Celsius (°C). The default temperature is 8 °C .
Press the
Wine Lower button repeatedly to select a new set temperature from 5 °C to 11 °C .
f Champagne
Press the Champagne button repeatedly to turn on and off this function. The default condition is
turned off.
NOTE
• If you turn off this function, the temperature inside the champagne drawer remains the same as the
temperature of the lower wine compartment.
g Lock
The lock function disables every other button on the display.
• When power is initially connected to the appliance, the lock function is off.
