LG CP50 User manual

• Please pay attention to handling Electrostatic Sensitive Devices, you may use anti-static
products such as wrist straps, heel straps, mats to protect your body from electrostatic.
• Make sure you have a personal computer with one or two open USB ports before connecting the
drive to your computer.
• Power for all other devices should be turn off before attaching the cables.
Connect the drive to the computer as shown in figure.
1Connect the USB 2.0 (Y type) cable to the drive.
2Connect the other end of the USB 2.0 cable to your computer.
3The drive may get its power from the PC USB power. All systems may not meet USB
power requirements and full performance may not be achieved. In this case, connect to
the USB power cable.
When the computer is ready, confirm that the drive is detected. And then, insert the supplied
software CD into the drive and install the software.
• Please do not connect the USB cables by any means other than specified above.
Using the wrong type of cable with this drive can cause it to malfunction.
• The appliance is not intended for use by young children or infirm persons without supervision.
Young Children should be supervised to ensure that they do not play with appliance.
• If the appliance is supplied from a cord extension set or an electrical portable outlet device, the cord
extension set on electrical portable outlet device must be positioned so that it is not subject to
splashing or ingress of moisture.
Installation
NOTES
NOTES
Connecting to computer or A/V Device.
Hardware Installation
1
2
3
The drive supports both Windows and Mac®. To use it properly, please follow directions below.
How to Eject Disc from the drive
• When using with Mac
- Click the eject button located on Mac OS menu or toolbar.
• When using with Windows
- Press the eject button in the front of the product.
* Software CD (for Windows only)
- The Software CD includes DVD software for usage for Windows.
• An application included in the Mac OS must be used to play data records or DVD video discs
through Mac OS.
- When recording data: Finder Burn, iTunes must be used.
- When playing a DVD movie disc: A DVD Player must be used.
• The Mac OS & Windows OS do not include an application that can play Blu-ray movie titles.
Separate playback software for Mac OS must be used to play Blu-ray movie titles through Mac OS.
• DVD/Blu-ray movie titles cannot be recorded because of the copyright protection.
NOTES
USB Power cable

1. Disc Tray
2. Drive activity indicator
The LED is used to indicate the operation of drive.
3. Eject Button
4. Emergency Eject Hole
1. USB Connector (mini)
This connector is used to connect to the USB
2.0 cable.
Location and function of controls
This following is the general figure of the design of the drive.
The drive’s appearance and specifications may change without prior notice.
Front
Rear
• Normal operation is not guaranteed if you use a USB hub or unspecified USB extension cables. TV connectivity functions support with files under 4GB.
• Due to compatibility issue of some AV devices and disc, may not work.
• DVD/Blu-ray movie titles and album titles cannot be played when using TV connectivity.
• TV connectivity function may not be available in BD-R/RE DL or XL disc.
NOTES
What is TV Connectivity?
TV Connectivity is a function that allows you to enjoy videos, pictures
and music by connecting this product to a compatible A/V device (e.g.
DIGITAL TV, DIGITAL PHOTO FRAME, PC) that supports USB
connectivity.
How to Use TV Connectivity
* This product is defaulted to ODD mode when it is powered on.
11With the tray open, press and hold the ‘Eject’ button for 2 seconds.
(The LED indicator will turn on, switching to TV mode. Press and hold the button again for 2 seconds with the tray open to return to ODD mode).
22Insert your supported media into the drive.
The disc file system will be converted to FAT32 and will be recognized as USB flash memory.
33Select and play the files from your A/V device to enjoy videos, pictures and music.
Refer to your A/V device owner’s manual for more information.
1 2 3 4
1

Features
• Universal Serial Bus (USB) 2.0 interface for high-speed data transfer.
• Ultra Slim Portable BD-ROM/DVD Writer
• Buffer Under Run error protection technology
• Emergency eject support
• Combination of CD-R/RW, DVD-R/RW, DVD+R/RW, DVD+R DL, DVD-R DL, DVD-RAM, M-Disc
(DVD+R SL), BD-R (SL/DL,LTH)/RE (SL/DL) and BD-R/RE XL (3 Layer) drive functions into one drive.
• CD Family, DVD-ROM, BD-ROM, BDXL (BD-R TL/QL, BD-RE TL) read compatible.
• Supports BD 3D Movie Play.
• PC USB powered, no AC adapter needed.
System meeting the following requirements is needed in order to use USB 2.0 operation with this drive.
• Computer that is equipped with a USB 2.0 – compliant USB connector or PCI adapter card, and on
which the USB 2.0 EHCI (Enhanced Host Controller Interface) driver software 1) has been installed.
1) The USB 2.0 EHCI driver software is supplied with currently available PCI adapter cards that
conform to USB 2.0. Further, Microsoft has released the USB 2.0 EHCI driver software for
Windows XP, therefore it is also possible to use this driver software with Windows XP SP3.
If you want to know in detail, please contact your USB 2.0 adapter dealer or consult your PC
manufacturer, or consult the Microsoft Corporation Web site.
System Environment
Computer
This unit can be operated in the system environment explained here.
* Compatibility problem in write/read function may occur with some media depending on the media manufacturing quality.
* To achieve maximum Record & Write speed your system may require data to be copied first to the computer’s hard
drive rather than directly from another source disc or drive.
Blu-ray Disc movie playback
CPU: Following CPU recommended for playing Blu-ray Disc
-Intel: E6400 or higher
3D title playback: Intel Core 2 Duo E6750 (266GHz), AMD Phenom 9450 (2.1GHz) or higher.
Graphic Card: card with following GPU (Graphic Processing Unit) recommended.
-nVidia: GeForce 7600GT or higher/ GeForce 8400 or higher -ATI: ATI Radeon HD 2400 or higher
Graphic Card Driver shall meet AACS compliance criteria. Please consult your graphic card vendor for proper driver
solution. BD movies can be played only with HDMI or DVI Connection.
Specifications
• CPU : Pentium 2.4 GHz or higher
• O/S : Windows 8.1, 8 / 7 / Vista (32 bit, 64 bit), XP (SP3),
Mac OS X v.10.7.5 or higher
• RAM : 1 GB or more
• HDD : 30 GB or more of available space (60 GB for Blu-ray Disc)
USB 2.0 (3.0 Compatible)
DVD-R : Mitsubishi Kagaku Media, Verbatim
DVD-RW : JVC, Mitsubishi Kagaku Media
DVD+R : Mitsubishi Kagaku Media, Verbatim
DVD+RW : Mitsubishi Kagaku Media, Verbatim
DVD±R DL : Mitsubishi Kagaku Media, Verbatim
DVD-RAM : Maxell, Panasonic
M-Disc (DVD+R SL) : Millenniata
CD-R : Mitsubishi Kagaku Media, Verbatim, Taiyo Yuden
CD-RW : LG, Mitsubishi Kagaku Media, Verbatim
System
requirements
Interface
Recommended
media manufacturer
SVC CODE: CP50NS20
- For the sake of periodic improvements, the drive’s specifications and appearance are
subject to change without prior notice.
- The maximum data transfer rate varies according to the performance capabilities of
the PC.
- We have taken all possible measures to assure the quality of our products, but we
cannot be responsible for the consequences if defect occurs.
Software
Install the appropriate CD Recording Authoring Software before using this unit.
* Please uninstall any previous CD burning software you may have loaded on your PC in order to
prevent possible compatibility issues.
Once you have installed the application software, you may (if you wish) begin to reinstall
previous software, taking note for errors. We recommend using the drive with the latest software
as some problems encountered when using the drive can be solved by updating the software.
We recommend to use USBFast Software in Software Installation disc for better performance.
Worldwide support site : http://www.LGservice.com
Worldwide corporate site : http://www.LG.com
Supported Discs BD-ROM ( Single/Dual), BD-R ( Single/Dual, LTH), BD-RE
(Single/Dual),
BD-R/RE XL (3 Layer), DVD-ROM (Single/ Dual),
DVD-RW, DVD-R, DVD+RW, DVD+R, DVD+R Double layer,
DVD-R Dual layer, DVD- RAM, M-Disc (DVD+R SL), CD-DA,
CD-Extra, CD-ROM, CD-ROM XA, CD-TEXT, CD-R, CD-RW,
Photo-CD (Single & Multi-Session), Video CD, DVD-VIDEO, BD-MV
Dimensions (WxHxD) 144 mm x 14.6 mm x 156 mm (5.7” x 0.6” x 6.1”)
Weight About 270 g (0.6 Ibs)
Interface USB 2.0 (3.0 Compatible)
Read/Write Speed
Write : DVD-R (SL/DL): 2x, 4x, 8x/2x, 4x, 6x
DVD+R (SL/DL): 2.4x, 4x, 8x/2.4x, 6x
DVD+RW: 2.4x, 3.3x, 4x, 6x, 8x
DVD-RW: 2x, 3x, 4x, 6x DVD-RAM: 2x, 3x, 5x
CD-R: 10x, 16x, 24x CD-RW: 4x, 10x, 16x
Read : BD-ROM (SL/DL): 6x max.
BD-R (SL/DL/TL/QL/SL LTH): 6x max.
BD-RE (SL/DL/TL): 6x/6x/4x max.
BDMV
(AACS Compliant Disc) (SL/DL) : 6x max.
DVD-ROM (SL/DL) : 8x max. DVD-R (SL/DL) : 8x max.
DVD+R (SL/DL) : 8x max. DVD-RW : 8x max.
DVD+RW : 8x max.
DVD-Video
(CSS Compliant Disc) (SL/DL) : 8x max.
CD-R/RW/ROM: 24x max. CD-DA : 24x max.
Average Access BD-ROM : 250 ms typ.
Time (
1/3Stroke
) DVD-ROM : 200 ms typ.
CD-ROM : 200 ms typ.
Buffer capacity 4 MB
MTBF 60,000 Power On Hours (Duty Cycle 10 %)
Power Requirement 5 V DC
Operating Environment
Temperature 5 °C to 45 °C
Humidity 15 % to 85 %
Storage Environment
Temperature -40 °C to 60 °C
Humidity 5 % to 90 % RH
Quick Set-up Guide
Slim Portable
BD-ROM/DVD Writer
CP50
To install of your product, please read this guide manual carefully and completely.
Cautions

Safety Instructions
CLASS 1 LASER PRODUCT
LASER KLASSE 1 PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
CLASE 1 PRODUCTO LÁSER
CLASSE 1 PRODOTTO LASER
CAUTION : CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCKS DEFEATED.AVOID EXPOSURE TO THE BEAM.
ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING I ÅBEN TILSTAND OG VED
AFBRUDT LÅSEFUNKTION. UNDGÅ AT BLIVE RAMT AF LASERSTRÅLEN.
VARO! : LUOKKA 3B AVATTAESSA JA KUMOTTAESSA LUKITUS NÄKYVÄÄ JA NÄKYMÄTÖNTÄ
LASERSÄTEILYÄ. VÄLTÄ LASERSÄTEILLE ALTISTUMISTA.
ATTENTION : CLASSE 3B RAYONNEMENT LASER VISIBLE ET INVISIBLE EN CAS D’OUVERTURE
ET ENCLENCHEMENTS DEFECTUEUX, EVITER L'EXPOSITION AU FAISCEAU.
VORSICHT : SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B WENN
ABDECKUNG GEÖFFNET UND SICHERHEITSVERRIEGELUNG ÜBERBRÜCKT VERMEIDEN SIE
ES, SICH DEM STRAHL AUSZUSETZEN.
ADVARSEL : KLASSE 3B SYNLIG OG USYNLIG LASERSTRÅLING NÅR ÅPNES OG LÅS BRYTES.
UNNGÅ EKSPONERING FOR STRÅLEN.
VARNING : KLASS 3B SYNLIG OCH OSYNLIG LASERSTRÅLNING FÖREKOMMER NÄR OCH
MELLANLÅSET FÖRSTÖRS. UNDVIK EXPONERING UNDER STRÅLEN.
■Microsoft®and Windows®are trademarks registered in the United States and other
countries by the Microsoft Corporation.
■The company names and product names written in this manual are trademarks or
registered trademarks of the respective companies.
FCC COMPLIANCE STATEMENT
Note : This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an Authorized Service Center for help.
• FCC WARNING
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• This product is for use only with UL listed personal computers that have installation
instructions detailing user-installation of card cage accessory.
CAUTION: The laser used in the writer can damage your eyes. Do not attempt to open the cover.
To reduce the risk of electric shock, do not remove the cover (or back). There are no user-service-
able parts inside. Refer servicing to qualified service personnel. Use of controls or performance of
procedures other than those specified herein may result in hazardous radiation exposure.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or
moisture.
VORSICHT : Der in diesem Laufwerk benutzte Laser kann Ihre Augen schädigen. Versuchen Sie
keinesfalls, die Abdeckung zu öffnen. Um die Gefahr eines elektrischen Schocks zu reduzieren,
sollten Sie die Abdeckung (oder Rückseite) keinesfalls entfernen. Im Inneren des Geräts befinden
sich keine Teile, die vom Benutzer selbst gewartet werden können. Überlassen Sie die Wartung
qualifizierten Kundendiensttechnikern. Beachten Sie bei der Benutzung von Bedienelementen
und der Durchführung von Prozeduren unbedingt die Anweisungen dieses Handbuchs, da
andernfalls gefährliche Strahlung freigesetzt werden kann.
WARNUNG : Setzen Sie das Laufwerk keinesfalls Regen oder Feuchtigkeit aus, um die Gefahr
eines Brandes oder elektrischen Schocks zu reduzieren.
ATTENTION: l'exposition au laser utilisé dans le graveur présente un danger pour les yeux.
N'essayez pas d'ouvrir le capot. Afin de réduire les risques de chocs électriques, ne retirez pas le
capot (ni l'arrière du dispositif). Aucune pièce interne ne peut être remplacée par l'utilisateur. Pour
la maintenance de l'appareil, adressez-vous au personnel qualifié du service de maintenance.
L'utilisation de commandes ou de procédures différentes de celles spécifiées ci-après peut
entraîner une exposition à des rayons dangereux.
AVERTISSEMENT :Ne pas exposer ce matériel à la pluie ou à l’humidité (risques d’incendie et
d’électrocution).
PERICOLO : Il dispositivo di lettura e scrittura utilizzato in questo masterizzatore utilizza un
raggio laser che, se osservato da vicino, può danneggiare la vista. Evitare di smontare il
coperchio dell’apparecchio. Al fine di prevenire eventuali folgorazioni, evitare di smontare
l’apparecchio. All’interno dell’apparecchio non sono presenti parti che richiedono manutenzione
da parte dell’utente. In caso di difetti o guasti, rivolgersi ad un Centro di Assistenza Tecnica.
L’esecuzione di procedure diverse da quella espressamente indicate in questo manuale può
provocare pericolose esposizioni alle radiazioni laser.
ATTENZIONE: Al fine di evitare cortocircuiti o principi di incendio, evitare di esporre questo
apparecchio alla pioggia o ad una eccessiva umidità ambientale.
PRECAUCION: El láser utilizado en la unidad puede dañar sus ojos. No intente abrir la tapa.
Para reducir el riesgo de descarga eléctrica, no quite la tapa (ni la parte posterior). No hay
piezas internas que deba mantener el usuario. El servicio de mantenimiento debe efectuarlo
personal técnico cualificado. El uso de controles o la ejecución de procedimientos distintos de
los especificados en este manual pueden ser causa de exposición a radiación peligrosa.
ADVERTENCIA: Para reducir el riesgo de fuego o descarga eléctrica, no exponga este aparato
a la lluvia ni a la humedad.
CUIDADO: O laser utilizado na unidade pode causar lesões oculares. Não tente abrir a tampa.
Para reduzir o risco de choques eléctricos, não retire a tampa (quer frontal quer superior).
A unidade não contém peças que possam ser reparadas pelo utilizador. Deixe a manutenção
para um técnico da assistência qualificado. A utilização de controlos ou a execução de
procedimentos que não sejam os especificados neste manual podem causar a exposição a
radiações perigosas.
AVISO: Para reduzir o risco de incêndio ou choque elétrico não exponha este aparelho á chuva
ou humidade.
EU Conformity Notice
LG Electronics hereby declares that this/these product(s) is/are in compliance
with the essential requirements and other relevant provisions of Directive
2004/108/EC, 2006/95/EC, 2009/125/EC and 2011/65/EU.
European representative :
LG Electronics Inc. - EU Representative
Krijgsman 1, 1186 DM Amstelveen
The Netherlands
