LG 501C Quick Start Guide
•Depending on the software installed or your service provider or
country, some of the descriptions in this guide may not match your
phone exactly.
•Depending on your country, your phone and accessories may appear
different from the picture in this guide.
Bluetooth QD ID: B015489 P/N: MMBB0390801(1.0) H
Printed in Korea
Installing the Battery
Toinstall the battery, align the battery contacts with the terminals in
the battery compartment. Press the battery down until it clicks into
place. Then replace the battery cover on the back of your phone.
Removing the Battery
1. With your phone turned off, slide the battery cover towards the bottom
of the phone (1) and lift off to remove it (2).
2. Lift the battery up (1) and away (2) from the phone, as shown below.
Reinstalling the Battery
1.To reinstall the battery, align the battery contacts (1) with the
terminals in the battery compartment. Press the battery down until it
clicks into place (2).
2.With the battery in position in the phone, replace the battery cover
on the back of your phone.
Charging the Battery
Your phone is powered by a rechargeable Li-ion battery. Use the wall charger
to charge the battery. Please remember to use only LG approved batteries
and chargers.
Note: You must fully charge the battery before using your phone for the first time.
1. Open the cover of the accessory port on the bottom part of the phone
and plug the wall charger connector into the jack. Be sure to orient the
connector as shown in the image below to avoid damaging your phone.
2. Plug the charger into a standard AC wall outlet.
3. When the phone is completely charged( ), unplug the charger from
the wall outlet.
4. Remove the charger from the phone by gently pulling out the connector.
Replace the plastic cover over the open jack.
Important: Do not remove the battery from the phone while charging and make sure the
wall charger is disconnected from the phone before removing the battery.
Please make sure that the 'B' side of the connector is
facing up before inserting the charger or a USB cable
into your phone's Charger/Accessory Port.
Phone layout and key functions
Phone features include:
• Large, easy-to-read, LCD screen with status icons.
• Messaging, voice mail, and caller ID.
• 24-key keypad.
• Speakerphone feature.
•Menu-driven interface with promptsfor easyoperation and configuration.
• Any key answer, auto answer, auto retry, one-touch and speed dialing with
99memory locations.
•Bilingual (English and Spanish) capabilities.
• Internal Antenna.
Earpiece
2.5 mm HeadsetJack
Navigation Keys
CLR Keys
Volume Keys
END/PWR Key
OK Key
Left Soft Key
Camera Key
SEND Key
Alphanumeric
Keypad
LCD Screen
Right Soft Key
Voice Command
Key
Microphone
Speakerphone
Key
Your phone is in standby
mode when you arenoton
acall or using a menu. You
must be in standby mode
toenter a phone number
to dial.
Display
Status icons
Main displayarea
Soft key options
Your phone displays the following status icons on the top of the screen:
Signal Strength
Airplane Mode
Battery Strength
In Call State
No Service
New Text
Message
New Picture
Message
New Voicemail
Message &
Voicemail
Web Message
Ring
Ring & Speaker
Silence All
Silence All &
Speaker
Vibrate Only
Vibrate
&Speaker
One Beep
One Beep &
Speaker
Alarm Only
Alarm Only &
Speaker
Alarm
Calendar
Alarm & Calendar
Roaming
Digital
SSL
TTY
Location On
E911Only
Active Data
Dormant Data
Announce
Announce Ring
Bluetooth On
Device
Connected
Shown to All
I
I
c
c
o
o
n
n
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Turning the Phone On or Off
1. To turn on, install a charged battery.
2. Then press and hold until the LCD screen lights up.
3. To turn off, press and hold until the display turns off.
Changing the display language
Allows you to use the bilingual feature according to your preference.
Choose between English and Spanish.
1. In standby mode, press the Left Soft Key Menu to access the
Main menu.
2. Press gg.
3. Use to highlight English or Español, then press .
Making Calls
1. Make sure the phone is turned on.
2. Enter the phone number (include the area code if needed) using the
alphanumeric keypad.
3. Press to dial.
4. Press to end the call.
Recent Calls
The Recent Calls menu displays a list of the last phone numbers or
Contacts entries for calls missed, received, or dialed. It is continually
updated as new numbers are added to the beginning of the list and the
oldest entries are removed from the bottom of the list.
Note: To view a quick list of all your recent calls, press the key while in standby mode.
1. Missed Calls : Allows you to view the list of the most recent missed
calls; up to 40 entries.
Press the Left Soft Key , , gUse to highlight an
entry.
2. Received Calls : Allows you to view the list of the most recent received
calls; up to 40 entries.
Press the Left Soft Key , , gUse to highlight an
entry.
3. Dialed Calls : Allows you to view the list of the most recent dialed
calls; up to 40 entries.
Press the Left Soft Key , , gUse to highlight an
entry.
4. All Calls : Allows you to view the list of the most recent missed,
received and dialed calls; up to 120 entries.
Press the Left Soft Key , ,
5. Call Timer : Allows you to view the duration of the calls, by type.
Press the Left Soft Key , , gUse to highlight one of
the call types (below).
Last Call/ Home Calls/ Roam Calls/ All Calls
Sound
Options to customize your phone's sounds:
Ringers
1. Press the Left Soft Key Menu, Settings, Sound, and then
Ringtones.
2. Select All Calls/ Caller ID/ No Caller ID/ Buy Ringtones.
3. Select My Sounds/ Default/ Buy Ringtones*.
4. Use to highlight the ringtone.
5. Press Play to play the ringtone or Set to set the ringtone to
your phone.
*Selecting Buy Ringtones will direct you to the ringtones download site.
Volume
1. Press the Left Soft Key Menu, Settings, Sound, and
then Volume.
2. Select
Master Volume/ Keypad/ Earpiece/ Speaker.
3. Use to adjust the volume of the function, then press to
save the setting.
Using the menus
To navigate, or select, the menus or features:
1. Press the Left Soft Key
Menu to access the Main menu.
2. Use the Navigation Keys to reach a desired menu and then press
.
3. If the menu contains any submenus, locate the one you want by using
the Navigation Keys . Press to enter the submenu.
If the selected menu contains additional submenus, repeat this step.
*Many of the features and services described are network dependent and may require
additional subscription and/or usage charges. Not all features are available for purchase or
use in all areas. Other conditions and restrictions may apply. See carrier for more
information.
© 2010 LG Electronics, Inc.
Charger/ Accessory
Port

Entering text
In a text input field to switch between ABC,Abc and abc modes, press
the key. To access Symbols, press the Left Soft Key and select
Symbols.
Using T9Word mode
1. Press each key once for one letter. The word you are entering appears on the
display. Options may change with each keypress.
For example: To enter “Hello” in T9Word mode, press , , and
scroll down and select Hello.
2. Press to insert a space and enter the next word.
Using ABC mode
Press the keys labeled with the letter you want.
Using 123 mode
Press the keys that correspond with the digits you want to enter.
Using Symbols mode
Press the keys that correspond with the symbol you want.
You can press the Left Soft Key Prev or the Right Soft Key
Next to display more symbols.
Tips for entering text
• To move the cursor, press the .
•To delete characters one by one, press . To delete all of the characters
at once, press and hold .
•To insert a space between characters, press .
Sending an SMS message
Allows you to send text and e-mail messages.
1. Press the Left Soft Key Menu, Messages, and New Text
Message.
2. Enter the recipient's address.
3. Press to access the text field.
4. Type your message.
5. Press Send.
A confirmation message is displayed.
Quick feature reference
This section provides instructions on how to access the different features
on your phone.
Menu Description
Menu Description Menu Description
, , Drafts allows you to view the saved (message) Drafts.
, , Voicemail allows you to view how many new voicemails you have
and to access your voicemail box.
, , Templates allows you to display, edit, and add text templates.
These text templates allow you to reduce manual text input into
messages.
, , Settings allows you to configure settings for Messaging.
, , Delete All allows you to erase the messages stored in your
Inbox, Outbox, or Drafts message folders. You can also erase all
messages at the same time.
, , Missed Calls allows you to view the list of the most recent
missed calls; up to 40 entries.
, , Received Calls allows you to view the list of the most recent
received calls; up to 40 entries.
, , Dialed Calls allows you to view the list of the most recent dialed
calls; up to 40 entries.
, , All Calls allows you to view the list of the most recent missed,
received and dialed calls; up to 120 entries.
, , Call Timer allows you to view the duration of calls by call type.
, , Data Counter
, , Buy Games
, , Chequered Flag
, , WordAttack
, Start Browser starts the Web Browser and allows you to view
Internet content.
, , Take Photo allows you to take a picture.
, , Record Voice allows you to record short voice messages.
, , Images allows you to view your saved images, some of which can
be set as your phone's Main Screen or Front Screen wallpaper
or as a Picture ID.
, , Sounds allows you to access saved audio clips and record new
ones.
, , Start Command allows you to access the Voice Command
menu. Voice Command allows you to access several features
using voice prompts. This menu can useful for those who are
driving or who may be blind.
, , Command Mode
, , Announce Alert
, , Train Word
, , Best Match
, , Alarm Clock allows you to set up to five alarms. At the alarm
time, any set alarm will sound (depending on your Master
Volume settings) the tone of your choice and an alarm message
will be displayed on the LCD screen.
, , Calendar allows you to access your Calendar appointments.
Simply enter your appointments in the Calendar and your
phone can alert you with a reminder.
, , Notepad allows you to add, read, edit, and erase notes.
Menu Description
, Bluetooth menu allows you to configure and use the Bluetooth®
functionality on your phone.
*.1 Paired Devices *.2 Power
*.3 My Visibility*.4 My Bluetooth Info
, , Calculator allows you to perform simple mathematical
calculations.
, , Ez Tip Calculator allows you to quickly and easily estimate the
tip and total amount of a bill by inputting the bill amount before
tip, the tip percentage, and dividing it by the number of people
paying.
, , World Clock allows you to determine the current time in
another time zone or city.
, , Stopwatch allows you to use your phone as a stopwatch.
, , Unit Converter allows you to convert units of Area, Length,
Temperature, Mass, Volume and Velocity.
, , Sound allows you to customize the sounds for the options
below:
1.1 Ringtones 1.2 Volume
1.3 Message Alerts 1.4 Alert Type
1.5 Service Alerts 1.6 Power On/Off Tone
, , Display allows you to customize the display for the options
below:
2.1 Wallpaper 2.2 Backlight
2.3 Auto KeyGuard 2.4 Menu Style
2.5 Languages (Idiomas) 2.6 Clocks & Calendar
2.7 Font Settings 2.8 Word Prediction
Menu Description
, , The Security menu allows you to secure the phone. To access
this menu, you will need the Lock Code. Usually, it is the last 4
digits of your phone number.
3.1 Lock Phone 3.2 Camera Restriction
3.3 Change Lock Code 3.4 Reset Default
, , The Call Settings menu allows you to designate how the phone
handles both incoming and outgoing calls.
4.1 Answer Options 4.2 Auto Retry
4.3 One Touch Dial 4.4 Airplane Mode
4.5 TTY Mode
, , The System menu allows you to designate specific system
network settings.
5.1 Network
5.1.1 System Select 5.1.2 Serving System
5.2 Location
, , The Memory menu allows you to check out the memory status
of your phone.
6.1 Reserved Memory 6.2 Multimedia
, , The Phone Info menu provides you with specific information
pertaining to your phone model.
7. 1 My Number 7.2 ESN/MEID
7. 3 Icon Glossary 7.4 Version
, For more information about the Prepaid menu, please refer to
the Quick Activation Guide.
1.1 Add Airtime 1.2 Buy Airtime
1.3 My Phone Number 1.4 Airtime Info
1.5 Airtime Display 1.6 Serial Number
1.7 Code Entry Mode
, , New Contact allows you to add a new contact to your Contact List.
, , Contact List you to view your saved contacts.
, ,
Groups allows you to view your grouped Contacts, add a new
group, change the name of a group, or delete a whole group.
, , My vCard
, , Speed Dials allows you to view your Speed Dials list, designate
new Speed Dials, or remove Speed Dial designations entered in
your Contacts.
, , New Text Message allows you to send text and e-mail messages.
, , New Picture Message allows you to send multimedia messages.
, , Inbox allows you to view your received messages.
, , Outbox allows you to view your sent messages. Up to 100 (50
SMS + 50 MMS) sent messages can be stored in the Sent
folder. Access the Sent folder to view contents of sent messages
and verify whether the transmission was successful or not.
TIA Safety Information Consumer Information on SAR
The following is the complete TIA Safety Information for wireless handheld phones.
Antenna Care
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and may violate FCC
regulations.
Phone Operation
NORMAL POSITION: Hold the phone as you would any other telephone with the
antenna pointed up and over your shoulder.
Tips on Efficient Operation
For your phone to operate most efficiently:
Don’t touch the antenna unnecessarily when the phone is in use. Contact with the
antenna affects call quality and may cause the phone to operate at a higher power
level than otherwise needed.
Driving
Check the laws and regulations on the use of wireless phones in the areas where you
drive and always obey them. Also, if using your phone while driving, please observe the
following:
●
Give full attention to driving -- driving safely is your first responsibility;
●
Use hands-free operation, if available;
●
Pull off the road and park before making or answering a call if driving conditions or
the law require it.
Electronic Devices
Most modern electronic equipment is shielded from RF signals. However, certain
electronic equipment may not be shielded against the RF signals from your wireless
phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a minimum
separation of six (6) inches be maintained between a handheld wireless phone and a
pacemaker to avoid potential interference with the pacemaker. These
recommendations are consistent with the independent research by and
recommendations of Wireless Technology Research.
Persons with pacemakers:
●
Should ALWAYS keep the phone more than six (6) inches from their pacemaker when
the phone is turned ON;
●
Should not carry the phone in a breast pocket;
●
Should use the ear opposite the pacemaker to minimize the potential for
interference;
●
Should turn the phone OFF immediately if there is any reason to suspect that
interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event of such
interference, you may want to consult your service provider (or call the customer
service line to discuss alternatives).
This phone model meets the government’s requirements for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured
not to exceed the emission limits for exposure to Radio Frequency (RF) energy set by
the Federal Communications Commission of the U.S. Government. These limits are part
of comprehensive guidelines and establish permitted levels of RF energy for the general
population. The guidelines are based on standards that were developed by independent
scientific organizations through periodic and thorough evaluation of scientific studies.
The standards include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6
W/kg. Tests for SAR are conducted using standard operating positions specified by the
FCC with the phone transmitting at its highest certified power level in all tested
frequency bands. Although SAR is determined at the highest certified power level, the
actual SAR level of the phone while operating can be well below the maximum value.
Because the phone is designed to operate at multiple power levels to use only the
power required to reach the network, in general, the closer you are to a wireless base
station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certified
to the FCC that it does not exceed the limit established by the government-adopted
requirement for safe exposure. The tests are performed in positions and locations (e.g.,
at the ear and worn on the body) as required by the FCC for each model.
The highest SAR value for this model phone when tested for use at the ear is 1.20
W/kg and when worn on the body, as described in this user guide, is 0.41 W/kg (body-
worn measurements differ among phone models, depending upon available accessories
and FCC requirements). While there may be differences between SAR levels of various
phones and at various positions, they all meet the government requirement for safe
exposure.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF emission guidelines.
SAR information on this model phone is on file with the FCC and can be found under
the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID
BEJLG231C. Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications Industry Association (CTIA) website at
http://www.ctia.org.
* In the United States and Canada, the SAR limit for mobile phones used by the public
is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a
substantial margin of safety to give additional protection for the public and to account
for any variations in measurements.
Menu map
1. Prepaid
1.1 Add Airtime
1.2 Buy Airtime
1.3 My Phone Number
1.4 Airtime Info
1.5 Airtime Display
1.6 Serial Number
1.7 Code Entry Mode
2. Contacts
2.1 New Contact
2.2 Contact List
2.3 Groups
2.4 My vCard
2.5 Speed Dials
3. Messages
3.1 New Text Message
3.2 New Picture Message
3.3 Inbox
3.4 Outbox
3.5 Drafts
3.6 Voicemail
3.7 Templates
3.8 Settings
3.9 Delete All
4. Recent Calls
4.1 Missed Calls
4.2 Received Calls
4.3 Dialed Calls
4.4 All Calls
4.5 Call Timer
4.6 Data Counter
5. Games
5.1 Buy Games
5.2 Chequered Flag
5.3 WordAttack
6. Browser
6.1 Start Browser
7. Multimedia
7. 1 Take Photo
7.2 Record Voice
7. 3 Images
7.4 Sounds
8. Voice Command
8.1 Start Command
8.2 Command Mode
8.3 Announce Alert
8.4 Train Word
8.5 Best Match
9. My Schedule
9.1 Alarm Clock
9.2 Calendar
9.3 Notepad
*. Bluetooth
*.1 Paired Devices
*.2 Power
*.3 My Visibility
*.4 My Bluetooth Info
0. Tools
0.1 Calculator
0.2 Ez Tip Calculator
0.3 World Clock
0.4 Stopwatch
0.5 Unit Converter
#. Settings
#.1 Sound
#.2 Display
#.3 Security
#.4 Call Settings
#.5 System
#.6 Memory
#.7 Phone Info
