Service Manual
LG-D618
Date: March, 2014 / Issue 1.0
- 2 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Table Of Contents
1. INTRODUCTION..................................................................... 3
1.1 Purpose ........................................................................................................3
1.2 Regulatory Information.........................................................................3
2. PERFORMANCE...................................................................... 5
2.1 Product Name............................................................................................5
2.2 Supporting Standard..............................................................................5
2.3 Main Parts : GSM Solution.....................................................................6
2.4 HW Features ...............................................................................................6
2.5 SW Features................................................................................................8
2.6 HW SPEC. ................................................................................................. 12
3. TROUBLE SHOOTING .......................................................... 20
3.1 RF Component ....................................................................................... 20
3.2 SIGNAL PATH........................................................................................... 22
3.3 Checking XO Block................................................................................ 25
3.4 Checking FEMID (GSM, W B1/B2/B8) Block................................. 27
3.5 Checking WCDMA Block .................................................................... 30
3.6 Checking GSM Block............................................................................ 65
3.7 GPS Trouble Shooting ......................................................................... 72
3.8 WIFI/BT Trouble Shooting.................................................................. 77
3.9 Audio Trouble ......................................................................................... 81
3.10 Camera.................................................................................................... 94
3.11 Main LCDTrouble Shooting ........................................................... 99
3.12 Touch troubleshooting...................................................................102
3.13 Vibrator Trouble Shooting.............................................................105
3.14 Compass / AccelTrouble Shooting............................................107
3.15 Proximity Sensor on/o Trouble Shooting.............................109
3.16 Power ON Troubleshooting..........................................................111
3.17 FM Trouble Shooting.......................................................................115
3.18 USBTrouble Shooting.....................................................................120
4. DOWNLOAD.......................................................................124
5. BLOCK DIAGRAM...............................................................141
6. CIRCUIT DIAGRAM ............................................................148
7. BGA PIN MAP ....................................................................164
8. PCB LAYOUT.......................................................................171
9. CALIBRATION.....................................................................177
10. HIDDEN MENU.................................................................196
11. DISASSEMBLE GUIDE......................................................203
12. EXPLODED VIEW & REPLACEMENT PART LIST .............208
12.1 Exploded View ...................................................................................208
12.2 Replacement Parts ...........................................................................209
12.3 Accessory .............................................................................................241
- 3 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
1.1 Purpose
This manual provides the information necessary to repair, calibration, description and download the features of
this model.
1.2 Regulatory Information
A. Security
Toll fraud, the unauthorized use of telecommunications system by an unauthorized part (for example, persons
other than your company’s employees, agents, subcontractors, or person working on your company’s behalf)
can result in substantial additional charges for your telecommunications services.
System users are responsible for the security of own system. There are may be risks of toll fraud associated with
your telecommunications system. System users are responsible for programming and configuring the
equipment to prevent unauthorized use. The manufacturer does not warrant that this product is immune from
the above case but will prevent unauthorized use of common carrier telecommunication service of facilities
accessed through or connected to it. The manufacturer will not be responsible for any charges that result from
such unauthorized use.
B. Incidence of Harm
If a telephone company determines that the equipment provided to customer is faulty and possibly causing
harm or interruption in service to the telephone network, it should disconnect telephone service until repair can
be done. A telephone company may temporarily disconnect service as long as repair is not done.
C. Changes in Service
A local telephone company may make changes in its communications facilities or procedure. If these changes
could reasonably be expected to affect the use of the phones or compatibility with the net work, the telephone
company is required to give advanced written notice to the user, allowing the user to take appropriate steps to
maintain telephone service.
D. Maintenance Limitations
Maintenance limitations on the phones must be performed only by the manufacturer or its authorized agent.
The user may not make any changes and/or repairs expect as specifically noted in this manual. Therefore, note
that unauthorized alternations or repair may affect the regulatory status of the system and may void any
remaining warranty.
1. INTRODUCTION
- 4 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
1. INTRODUCTION
LGE Internal Use Only
E. Notice of Radiated Emissions
This model complies with rules regarding radiation and radio frequency emission as defined by local regulatory
agencies. In accordance with these agencies, you may be required to provide information such as the following
to the end user.
F. Pictures
The pictures in this manual are for illustrative purposes only; your actual hardware may look slightly different.
G. Interference and Attenuation
A phone may interfere with sensitive laboratory equipment, medical equipment, etc. Interference from
unsuppressed engines or electric motors may cause problems.
H. Electrostatic Sensitive Devices
ATTENTION
Boards, which contain Electrostatic Sensitive Device (ESD), are indicated by the sign.
Following information is ESD handling:
• Service personnel should ground themselves by using a wrist strap when exchange system boards. • When
repairs are made to a system board, they should spread the floor with anti-static mat which is also grounded.
• Use a suitable, grounded soldering iron. • Keep sensitive parts in these protective packages until these are used.
• When returning system boards or parts like EEPROM to the factory, use the protective package as described.
2. PERFORMANCE
- 5 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
2. PERFORMANCE
LGE Internal Use Only
2.1 Product Name
LG- D618 WCDMA(FDD1/2/5/8) +EGSM/GSM850/DCS/PCS with seamless handover Phase 2+(include AMR)
2.2 Supporting Standard
Item Feature Comment
Supporting Standard WCDMA(FDD1/2/5/8)
+EGSM/GSM850/DCS/PCS
with seamless handover
Phase 2+(include AMR)
(HSDPA Cat. 14 / HSUPA Cat.6 / GPRS Multislot
class 12/EDGE Rx only)
Frequency Range WCDMA(FDD1) TX : 1920 – 1980 MHz
WCDMA(FDD1) RX : 2110 – 2170 MHz
WCDMA(FDD2) TX: 1850 – 1910 MHz
WCDMA(FDD2) RX: 1930 – 1990 MHz
WCDMA(FDD5) TX : 824 – 849 MHz
WCDMA(FDD5) RX : 869 – 894 MHz
WCDMA(FDD8) TX : 880 – 915 MHz
WCDMA(FDD8) RX : 925 – 960 MHz
EGSM TX : 880 – 915 MHz
EGSM RX : 925 – 960 MHz
GSM850 TX : 824 – 849 MHz
GSM850 RX : 869 – 894 MHz
DCS1800 TX : 1710 – 1785 MHz
DCS1800 RX : 1805 – 1880 MHz
PCS1900 TX : 1850 – 1910 MHz
PCS1900 RX : 1930 – 1990 MHz
Application Standard WAP 2.0
2.1 Product Name
LG- D618 : WCDMA(FDD1/2/5/8) +EGSM/GSM850/DCS/PCS with seamless handover Phase 2+(include AMR)
2.2 Supporting Standard
2. PERFORMANCE
- 6 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM8226: Qualcomm
Analog Baseband MSM8226 : Qualcomm
RF Chip WTR2605 : Qualcomm
2.4HW Features
Item Part Name Comment
Form Factor DOP type
Battery
1) Capacity
Standard : Li-Ion, 2440mAh
2) Packing Type : Changeable
Size Standard : 129.6 x 66 x 9.9mm
Weight 120 g (TBD) With Battery
Volume 80.65cc With Battery
PCB 10Any Layers , 0.8t
Charging time 4.3hrs @ Power Off / 2440mAh
RX sensitivity
WCDMA(FDD1) : -106.7 dBm
WCDMA(FDD2) : -104.7 dBm
WCDMA(FDD5) : -104.7 dBm
WCDMA(FDD8) : -103.7 dBm
EGSM : -105 dBm
GSM850 : -105 dBm
DCS 1800 : -105 dBm
PCS 1900 : -105 dBm
TX
output
power
WCDMA/
GSM/
GPRS
WCDMA : 24dBm/3.84MHz,+1/-3dBm
EGSM : 33.0 dBm
GSM850 : 33.0 dBm
DCS1800 : 30.5 dBm
PCS 1900 : 29.5 dBm
Class3(WCDMA)
Class4 (EGSM)
Class4 (GSM850)
Class1 (PCS)
Class1 (DCS)
EDGE
2.4 HW Features
2.3 Main Parts : GSM Solution
LGE Internal Use Only
2.3 Main Parts : GSM Solution
Item Part Name Comment
Digital Baseband MSM8226: Qualcomm
Analog Baseband MSM8226 : Qualcomm
RF Chip WTR2605 : Qualcomm
2.4HW Features
Item Part Name Comment
Form Factor DOP type
Battery
1) Capacity
Standard : Li-Ion, 2440mAh
2) Packing Type : Changeable
Size Standard : 129.6 x 66 x 9.9mm
Weight 120 g (TBD) With Battery
Volume 80.65cc With Battery
PCB 10Any Layers , 0.8t
Charging time 4.3hrs @ Power Off / 2440mAh
RX sensitivity
WCDMA(FDD1) : -106.7 dBm
WCDMA(FDD2) : -104.7 dBm
WCDMA(FDD5) : -104.7 dBm
WCDMA(FDD8) : -103.7 dBm
EGSM : -105 dBm
GSM850 : -105 dBm
DCS 1800 : -105 dBm
PCS 1900 : -105 dBm
TX
output
power
WCDMA/
GSM/
GPRS
WCDMA : 24dBm/3.84MHz,+1/-3dBm
EGSM : 33.0 dBm
GSM850 : 33.0 dBm
DCS1800 : 30.5 dBm
PCS 1900 : 29.5 dBm
Class3(WCDMA)
Class4 (EGSM)
Class4 (GSM850)
Class1 (PCS)
Class1 (DCS)
EDGE
2. PERFORMANCE
- 7 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
GPRS compatibility GPRS Class 12
EDGE compatibility EDGE Rx only
SIM card type Micro SIM(3FF) 3V /1.8V
Display Main LCD : TFT LCD
(4.7”, qHD, 960X540 pixels, 16M Colors)
Built-in Camera 8M BSI - AF Camera with FHD
Status Indicator N/A
Keypad Full Touch Screen
Back-Key : 3
Back Key : Power On
Volume up/down
ANT Main : Internal Fixed Type
System connector 5 Pin u-USB micro USB
Ear Phone Jack 3.5Phi, 4 Pole, Stereo
PC synchronization Yes
Memory 8GB eMMC
1Gb LPDDR2
Speech coding FR, EFR, HR,AMR
Data & Fax Built in Data & Fax support
Vibrator Built in Vibrator
BlueTooth Bluetooth 4.0 + BLE
MIDI(for Buzzer
Function) SW Decoded 72Poly
Music Player MP3/WMA/AAC/MIDI/EAAC+/HEAAC/OGG
Video Player MPEG4, H.264
Camcorder MPEG4 or H.263
Voice Recording Yes
Speaker Phone mode
Support Yes
Travel Adapter Yes In-box item
CDROM No
Stereo Headset Yes
Data Cable Yes In-box item
T-Flash(External
Memory)
Yes
2. PERFORMANCE
- 8 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Specification
GSM WCDMA
Stand by current
(Sleep & Idle Avg.)
885 hours over
(PP = 5)
797 hours over
(DRX = 7)
Talk current 23 hours over
(TX Level = 10)
22 Hours over
(TX = 10dBm)
2.5 SW Features
Item Feature Comment
RSSI 0 ~ 5 Levels
Battery Charging 0 ~ 20 Levels
Key Volume 0 ~ 7 Level
Audio Volume 1 ~ 15 Level
Time / Date Display Yes
Multi-Language depending on build language
Quick Access Mode No
PC Sync Yes
Speed Dial Yes
Profile Yes not same with feature phone setting
CLIP / CLIR Yes
Phone Book
Name / Number / Email / Groups /
Postal addresses / Organizations / IM
/ Note / Nickname / Website / Event /
There is no limitation on the number
of items.
It depends on available memory
amount.
Last Dial Number Yes
Last ReceivedNumber Yes
Last Missed Number Yes
LGE Internal Use Only
Specification
GSM WCDMA
Stand by current
(Sleep & Idle Avg.)
885 hours over
(PP = 5)
797 hours over
(DRX = 7)
Talk current 23 hours over
(TX Level = 10)
22 Hours over
(TX = 10dBm)
2.5 SW Features
Item Feature Comment
RSSI 0 ~ 5 Levels
Battery Charging 0 ~ 20 Levels
Key Volume 0 ~ 7 Level
Audio Volume 1 ~ 15 Level
Time / Date Display Yes
Multi-Language depending on build language
Quick Access Mode No
PC Sync Yes
Speed Dial Yes
Profile Yes not same with feature phone setting
CLIP / CLIR Yes
Phone Book
Name / Number / Email / Groups /
Postal addresses / Organizations / IM
/ Note / Nickname / Website / Event /
There is no limitation on the number
of items.
It depends on available memory
amount.
Last Dial Number Yes
Last ReceivedNumber Yes
Last Missed Number Yes
2.5 SW Features
2. PERFORMANCE
- 9 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Search by
Number/Name Yes
Group Yes
There is no limitation on the number
of items.
It depends on available memory
amount.
Fixed Dial Number Yes
Service Dial Number No
Own Number Yes My Profile (add/edit/delete are
supported)
Voice Memo Yes Support voice recorder
Call Reminder No
Network Selection Automatic
Mute Yes
Call Divert Yes
Call Barring Yes
Call Charge (AoC) No
Call Duration Yes
SMS (EMS)
There is no limitation on the number
of items.
It depends on available memory
amount.
EMS does not support.
SMS Over GPRS Yes
EMS Melody / Picture
Send / Receive / Save No
MMS MPEG4
Send /Receive / Save Yes
Long Message MAX 2000 characters The standard of Open vender
Cell Broadcast Yes
Download Over the Web
2. PERFORMANCE
- 10 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
Game No
Calendar Yes
Memo Yes
There is no limitation on the number
of items.
It depends on available memory
amount.
World Clock Yes
Unit Convert No
Stop Watch Yes
Wall Paper Yes
WAP Browser No
Support only web browser based on
webkit. WAP stack and wml are not
supported.
Download Melody /
Wallpaper Yes Over web browser
SIM Lock YES
SIM Toolkit YES
MMS Yes Google MMS Client
EONS Yes
CPHS Yes V4.2
ENS No
Camera Yes 8M AF /
Digital Zoom : x4
JAVA No
Voice Dial No US English only
IrDa Yes
Bluetooth Yes
Ver. 4.0 [HSP, HFP, A2DP, AVRCP, PBAP,
FTP(Server only), OPP, MAP, HID,
PAN]
2. PERFORMANCE
- 11 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
FM radio Yes
GPRS Yes Class 12
EDGE Yes EDGE Rx only
Hold / Retrieve Yes
Conference Call Yes
DTMF Yes
Memo pad No
TTY No
AMR Yes
SyncML DS No
DM Yes
IM Yes Google Talk
Email Yes
Item Feature Comment
2. PERFORMANCE
- 12 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2.6 HW SPEC.
1) GSM transceiverspecification
Item Specification
Phase Error Rms : 5°/ Peak : 20 °
Frequency Error GSM : 0.1 ppm
DCS/PCS : 0.1 ppm
EMC(Radiated Spurious Emission
Disturbance) GSM/DCS : < -28dBm
Transmitter Output power and Burst
Timing
GSM : 5dBm – 33dBm ± 2dB
DCS/PCS : 0dBm – 30dBm ± 2dB
Burst Timing <3.69us
Spectrum due to modulation out to
less than 1800kHz offset
200kHz : -36dBm
600kHz : -51dBm/-56dBm
Spectrum due to modulation out to
larger than 1800kHz offset to the
edge of the transmit band
GSM :
1800-3000kHz :< -63dBc(-46dBm)
3000kHz-6000kHz : <-65dBc(-46dBm)
6000kHz < : < -71dBc(-46dBm)
DCS :
1800-3000kHz :< -65dBc(-51dBm)
6000kHz < : < -73dBc(-51dBm)
Spectrum due to switching transient 400kHz : -19dBm/-22dBm(5/0),
600kHz : -21dBm/-24dBm(5/0),
Reference Sensitivity – TCH/FS Class II(RBER) : -105dBm(2.439%)
Usable receiver input level range 0.012(-15 - -40dBm)
Intermodulation rejection – Speech
channels
± 800kHz, ± 1600kHz
: -98dBm/-96dBm (2.439%)
AM Suppression
-GSM : -31dBm
- DCS : -29dBm
-98dBm/-96dBm (2.439%)
Timing Advance ± 0.5T
2.6 HW SPEC.
1) GSM transceiverspecication
2. PERFORMANCE
- 13 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
2) WCDMA transmitter specification
Item Specification
Transmit Frequency Band1 : 1920 – 1980 MHz
Band2 : 1850 – 1910 MHz
Band5 : 824 – 849 MHz
Band8 : 880 – 915 MHz
Maximum Output Power +24dBm / 3.84 MHz, +1 / -3 dB
Frequency Error within ±0.1 PPM
Open Loop Power Control Normal Conditions : within ±9 dB,
Extreme Conditions : within ±12 dB
Minimum Transmit Power < -50 dBm /3.84 MHz
Occupied Bandwidth < 5 MHz at 3.84 Mcps (99% of power)
Adjacent Channel Leakage
Power Ratio (ACLR)
> 33 dB @ ±5 MHz,
> 43 dB @ ±10 MHz
Spurious Emissions
|f-fc| > 12.5 MHz
< -36 dBm / 1 kHz RW @ 9 kHz ≤f < 150 kHz
< -36 dBm / 10 kHz RW @ 150 KHz ≤f < 30 MHz
< -36 dBm / 100 kHz RW @ 30 MHz ≤f < 1 GHz
< -30 dBm / 1 MHz RW @ 1 GHz ≤f < 12.75 GHz
< -60 dBm / 3.84 MHz RW @ 869 MHz ≤f ≤894 MHz
< -60 dBm / 3.84 MHz RW @ 1930 MHz ≤f ≤1900 MHz
< -60 dBm / 3.84 MHz RW @ 2110 MHz ≤f ≤2155 MHz
< -67 dBm / 100 kHz RW @ 925 MHz ≤f ≤935 MHz
< -79 dBm / 100 kHz RW @ 935 MHz < f ≤960 GHz
< -71 dBm / 100 kHz RW @ 1805 MHz ≤f ≤1880 MHz
< -41 dBm / 300 kHz RW @ 1884.5 MHz < f < 1919.6 MHz
Transmit Intermodulation < -31 dBc @ 5 MHz &< -41 dBc @ 10 MHz
when Interference CW Signal Level = -40 dBc
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm
Peak Code Domain Error < -15 dB at Pout -20 dBm
2) WCDMA transmitter specication
2. PERFORMANCE
- 14 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
3) WCDMA receiver specification
Item Specification
Receive Frequency
Band1 : 2110 – 2170 MHz
Band2 : 1930 – 1990 MHz
Band5 : 869 – 894 MHz
Band8 : 925 – 960 MHz
Reference Sensitivity Level
Band1 : BER < 0.001 when Îor = -106.7 dBm / 3.84 MHz
Band2 : BER < 0.001 when Îor = -104.7 dBm / 3.84 MHz
Band5 : BER < 0.001 when Îor = -104.7 dBm / 3.84 MHz
Band8 : BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
Maximum Input Level BER < 0.001 when Îor = -25 dBm / 3.84 MHz
Adjacent Channel Selectivity
(ACS)
ACS > 33 dB where BER < 0.001 when
Îor = -92.7 dBm / 3.84 MHz
&Ioac = –52 dBm / 3.84 MHz @ ±5 MHz
Blocking Characteristic
BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
&Iblocking = -56 dBm / 3.84 MHz @ Fuw(offset) = ±10 MHz
orIblocking = -44 dBm / 3.84 MHz @ Fuw(offset) = ±15 MHz
Spurious Response BER < 0.001 when Îor = -103.7 dBm / 3.84 MHz
&Iblocking = -44 dBm
Intermodulation
BER < 0.001 when Îor= -103.7 dBm / 3.84 MHz
& Iouw1 = -46 dBm @ Fuw1(offset) = ±10 MHz
& Iouw2 = -46 dBm / 3.84 MHz @ Fuw2(offset) = ±20 MHz
Spurious Emissions < -57 dBm / 100 kHz BW @ 9 kHz ≤ f < 1 GHz
< -47 dBm / 1 MHz BW @ 1 GHz ≤ f ≤ 12.75 GHz
Inner Loop Power Control
In Uplink
Adjust output(TPC command)
cmd 1dB 2dB 3dB
+1 +0.5/1.5 +1/3 +1.5/4
0 -0.5/+0.5 -0.5/+0.5 -0.5/+0.5
-1 -0.5/-1.5 -1/-3 -1.5/-4
group(10equal command group)
+1 +8/+12 +16/+24
3) WCDMA receiver specication
2. PERFORMANCE
- 15 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
4) HSDPA transmitter specication
LGE Internal Use Only
4) HSDPA transmitter specification
Item Specification
Transmit Frequency
Band1 : 1920 – 1980 MHz
Band2 : 1850 – 1910 MHz
Band5 : 824 – 849 MHz
Band8 : 880 – 915 MHz
Maximum Output Power
Sub-Test
1=1/15, 2=12/15 21~25dBm / 3.84 MHz
3=13/15 4=15/8 20~25dBm / 3.84 MHz
5=15/7 6=15/0 19~25dBm / 3.84 MHz
HS-DPCCH
Sub-
test in
table
C.10.1.4
Power
step
Power step
slot boundary
Power
step
size, P
[dB]
Transmitter power
step tolerance [dB]
5
1 Start of
Ack/Nack 6 +/- 2.3
2 Start of CQI 1 +/- 0.6
3 Middle of CQI 0 +/- 0.6
4 End of CQI 5 +/- 2.3
Spectrum Emission Mask
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
Frequency offset
from carrier ᇞf Minimum requirement Measurement
Bandwidth
2.5 ~ 3.5 MHz -35-15×(ᇞf-2.5)dBc 30 kHz
3.5 ~ 7.5 MHz -35-1×(ᇞf-3.5)dBc 1 MHz
7.5 ~ 8.5 MHz -35-10×(ᇞf-7.5)dBc 1 MHz
8.5 ~ 12.5 MHz -49dBc 1 MHz
Adjacent Channel
Leakage
Power Ratio (ACLR)
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
> 33 dB @ ±5 MHz
> 43 dB @ ±10 MHz
Error Vector Magnitude < 17.5 %, when Pout ≥ -20 dBm
2. PERFORMANCE
- 16 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
5) HSDPA receiver specication
LGE Internal Use Only
5) HSDPA receiver specification
Item Specification
Receive Frequency
Band1 : 2110 – 2170 MHz
Band2 : 1930 – 1990 MHz
Band5 : 869 – 894 MHz
Band8 : 925 – 960 MHz
Maximum Input Level
(BLER or R), 16QAM Only
Sub-Test : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
BLER < 10% or R >= 700kbps
6) WLAN 802.11b transceiver specification
Item Specification
T
ransmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
T
x Power Level ≤ 20dBm under
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy
(Peak EVM) ≤ 35%
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -85dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
LGE Internal Use Only
5) HSDPA receiver specification
Item Specification
Receive Frequency
Band1 : 2110 – 2170 MHz
Band2 : 1930 – 1990 MHz
Band5 : 869 – 894 MHz
Band8 : 925 – 960 MHz
Maximum Input Level
(BLER or R), 16QAM Only
Sub-
T
est : 1=1/15, 2=12/15, 3=13/15, 4=15/8, 5=15/7, 6=15/0
BLER < 10% or R >= 700kbps
6) WLAN 802.11b transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm under
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask ≤ -30 @ fc-22MHz< f <fc-11MHz and fc+11MHz< f <fc+22MHz
≤ -50 @ f < fc-22MHz and f > fc+22MHz
Power ramp on/off time ≤ 2us
Carrier Suppression ≤ -15dB
Modulation Accuracy
(Peak EVM) ≤ 35%
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity ≤ -85dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Max input Sensitivity ≥ -10dBm(1Mbps,2Mbps,5.5Mbps,11Mbps) @ FER ≤ 8%
Rx Adjacent Channel
Rejection
≥ 35dB @FER ≤ 8%,
interference input signal -70dBm@fc±25MHz(11Mbps)
6) WLAN 802.11b transceiver specication
2. PERFORMANCE
- 17 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
7) WLAN 802.11g transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask
≤ -22 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -30 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -42 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM)
≤-5dB@6Mbps, ≤-8dB@9Mbps, ≤-10dB@12Mbps,
≤-13dB@15Mbps, ≤-16dB@24Mbps, ≤-19dB@36Mbps,
≤-22dB@45Mbps, ≤-25dB@54Mbps
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
-82dBm@6Mbps, -81dBm@9Mbps, -79dBm@12Mbps
-77dBm@18Mbps, -74dBm@24Mbps, -70dBm@36Mbps
-66dBm@48Mbps, -65dBm@54Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 16dB@6Mbps, ACR ≥ 15dB@9Mbps,
ACR ≥ 13dB@12Mbps, ACR ≥ 11dB@18Mbps,
ACR ≥ 8dB@24Mbps, ACR ≥ 4dB@36Mbps
ACR ≥ 0dB@48Mbps, ACR ≥ -1dB@54Mbps
※ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity
7) WLAN 802.11g transceiver specication
2. PERFORMANCE
- 18 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
LGE Internal Use Only
8) WLAN 802.11n transceiver specification
Item Specification
Transmit Frequency 2400 MHz ~ 2483.5 MHz ( CH1~CH13 )
Tx Power Level ≤ 20dBm under (Europe), ≤ 30dBm under (USA)
Frequency Tolerance within ±25 PPM
Chip clock Frequency
Tolerance within ±25 PPM
Spectrum Mask
≤ -20 @ ±11MHz offset (9Mhz ~ 11MHz)
≤ -28 @ ±20MHz offset (11MHz ~ 20Mhz)
≤ -45 @ ±30MHz offset (20MHz ~ 30Mhz)
Transmitter constellation error
(rms EVM)
≤ -16dB@26Mbps, ≤ -19dB@39Mbps, ≤ -22dB@52Mbps,
Spurious Emissions
< -36 dBm @ 30MHz ~ 1GHz
< -30 dBm above @ 1GHz ~ 12.75GHz
< -47 dBm @ 1.8GHz ~ 1.9GHz
< -47 dBm @ 5.15GHz ~ 5.3GHz
Rx Min input Sensitivity
PER ≤ 10%
-74dBm@26Mbps, -70dBm@39Mbps, -66dBm@52Mbps
Rx Max input Sensitivity ≥ -20dBm(6,9,12,18,24,36,48,54Mbps) @ PER ≤ 10%
Rx Adjacent Channel
Rejection
PER ≤ 10%,
ACR ≥ 4dB@39Mbps, ACR ≥ 0dB@52Mbps
※ACR shall be measured by setting the desired signal's strength
3 dB above the rate-dependent
sensitivity specified in min input sensitivity
8) WLAN 802.11n transceiver specication
2. PERFORMANCE
- 19 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
9) GPS receiver specication
10) Signal Bar
LGE Internal Use Only
9) GPS receiver specification
Item Specification
Receive Frequency
GPS : 1574.42 MHz ~ 1576.42 MHz
GLONASS : 1598 MHz ~ 1606 MHz
Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding
10) Signal Bar
Antenna BAR
Specification(dBm)
Comment
WCDMA(RSSI) GSM
54-86±2 -91±2
1. Call
Connected &
CPIPH
Level=-3.3
43-93±2 -96±2
32-99±2 -99±2
21-103±2 -103±2
10-109±2 -105±2
LGE Internal Use Only
9) GPS receiver specification
Item Specification
Receive Frequency
GPS : 1574.42 MHz ~ 1576.42 MHz
GLONASS : 1598 MHz ~ 1606 MHz
Minimum Sensitivity 1 satellite ≥-142dBm, 7 satellites ≥ -147dBm at coarse time aiding
10) Signal Bar
Antenna BAR
Specification(dBm)
Comment
WCDMA(RSSI) GSM
54-86±2 -91±2
1. Call
Connected &
CPIPH
Level=-3.3
43-93±2 -96±2
32-99±2 -99±2
21-103±2 -103±2
10-109±2 -105±2
3. TROUBLE SHOOTING
- 20 - Copyright © 2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
3. TROUBLE SHOOTING
3.1 RF Component
<Main Top>
U1100
U1500
U1601
FL1603
FL1601
U1600
FL1604
FL1602
FL1100
Other manuals for LG-D618
2
Table of contents
Other LG Cell Phone manuals
