CONTENTS
CONTENTS
3 INSTALLATIONPREPARATION
3 Accessories
4 MountingHoles
5 PortraitLayout
6 StorageMethodforPanelProtection
6 - CorrectMethod
6 - IncorrectMethod
7 PRODUCTINSTALLATION
7 InstallinganLVDSCable
8 LightingInstallation
9 InstallationinEnclosure
10 Precaution
10 - CorrectMethod
10 - IncorrectMethod
11 TROUBLESHOOTING
12 SPECIFICATIONS
14 LVDSPINMAPGUIDE
 Thewarrantywillnotcoveranydamagescausedbyusingtheproductinanexcessivelydusty
environment.
NOTE

3
ENG
ENGLISH
INSTALLATIONPREPARATION
INSTALLATIONPREPARATION
Accessories
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
 Donotuseanyunapprovedorcounterfeitpartsoraccessoriestoensurethesafetyandproductlife
span.
 Anydamagesorinjuriesbyusingunapproveditemsarenotcoveredbythewarranty.
 Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
 Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
 LVDScableisoptionalandnotprovidedwiththeproduct. PleaserefertoLVDSPinMapGuideon
pages14to15fortheLVDScableassembly.
CD(Owner'sManual)/
EasySetupGuide
CAUTION
NOTE

4
ENG
ENGLISH
INSTALLATIONPREPARATION
Frontoftheproduct
Rearoftheproduct
 Thisproducthasthefrontandbacksides.Makesuretheproductisinstalledwiththefrontsidefacing
forward.
 Imageisdisplayedreverselyonthebackside.
CAUTION
MountingHoles
UseM3screwstomountthemonitor.Thereare20positionsforscrewsontherearsideoftheproduct.

5
ENG
ENGLISH
INSTALLATIONPREPARATION
PortraitLayout
Toinstallinportraitmode,rotatethesetclockwise90degreeswhenlookingatfromthefront.
Theportraitmodeisonlyavailableonthescalerboard.(Thescalerboardshouldsupportportraitmode.)
 Thescalerboardisoptionalanditisnotpartoftheproduct.
CAUTION

6
ENG
ENGLISH
INSTALLATIONPREPARATION
CorrectMethod IncorrectMethod
StorageMethodforPanelProtection
Panel
Cushion
Whenlayingtheproductonaflatfloor,pititface
downonacushionorblankettopreventscratch-
inganddamage.
Ifthereisnoacushionorasoftclothavailable,
ensurethefloorisclean.Thenlaytheproduct
downcarefullywiththepanelfacingeitherupward
ordownward.Atthistime,makesurethatno
objectfallsonthepanel.
Panel
Panel
Panel
Iftheproductistiltedontothebezel,thebottomof
thepanelmaybedamaged.
Iftheproductistiltedontotheedgeofthepanel,
thepanelmaybedamaged.


7
ENG
ENGLISH
PRODUCTINSTALLATION
PRODUCTINSTALLATION
InstallinganLVDSCable
542.25mm
45mm
30mm
LVDSCable
TheLVDScableportislocatedasshowninthefigurebelow.
Wheninstallingtheproduct,makesurethereisenoughspacetoinstalltheLVDScable.

8
ENG
ENGLISH
PRODUCTINSTALLATION
LightingInstallation
Thisproductmustbeinstalledwithbacklighting.
Lightingmustbeinstalledbehindtheproductsothatthedisplaycanbeseenclearly.
Ifsomethingobstructsthebacklighting,additionallightingmayberequired.
Lighting
Lighting
Additionallighting
Additionallighting
Object
600luxormore
(WhentheFullScreen
isWhite.)
600luxormore
(WhentheFullScreen
isWhite.)

9
ENG
ENGLISH
PRODUCTINSTALLATION
 Thisproductcanbeinstalledinvarious
locationsbesidestheenclosure.
Exampleoftheproductintheenclosure
Exampleofthelightinginstallation
Lightingmustbeinstalledintheenclosure.
InstallationinEnclosure
Installtheproductintheenclosure.Wearworking
gloveswheninstallingtheproduct.Donotuse
barehands.Otherwise,itmaycausepersonal
injury.
1 Placetheproductintheenclosure.
2 Attachtheproductusingthepreparedscrew
holesandanadditionalenclosureguideframe.
NOTE
 Thepanelofthisproductissothinthatitcan
beeasilybrokenwhenitisexposedtothe
outside.Useaclearprotectivecovertokeep
theproductfromexposuretotheelements.
CAUTION
