LG 98UM3F User manual

A B C
D
(M4 x L22)
98UH5F
98UM3F
Depending upon country / Selon le pays / Según el país
ENGLISH Installation Guide
Please read this manual carefully before operating your set and retain it for future reference.
FRANÇAIS Guide d’installation
Veuillez lire ce manuel attentivement avant d’utiliser l’appareil et conservez-le pour pouvoir vous y reporter
ultérieurement.
ESPAÑOL Guía de instalación
Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
LG Digital Signage
(MONITOR SIGNAGE)
Afchage dynamique numérique LG
(AFFICHAGE SUR MONITEUR)
Señalización digital LG
(MONITOR DE SEÑALIZACIÓN)
Printed in Korea / Imprimé en Corée

ʣwww.lg.com/id-manual
ʣSuperSign : http://partner.lge.com

Kg
ENGLISH
Dimensions
(Width x Height x Depth) / Weight
2,191.8 mm x 1,246.8 mm x 83.8 mm / 81.1 kg
(86.2 inches x 49.0 inches x 3.2 inches / 178.7 lbs)
FRANÇAIS
Dimensions
(largeur x hauteur x profondeur) / Poids
2 191,8 mm x 1 246,8 mm x 83,8 mm / 81,1 kg
(86,2 po x 49,0 po x 3,2 po / 178,7 lb)
ESPAÑOL
Dimensiones
(ancho x alto x profundidad) / Peso 2 191,8 mm x 1 246,8 mm x 83,8 mm / 81,1 kg
Alimentación CA 100-240 V ~ 50/60Hz, 6,6A
