LG LAT240DT1 User manual

Please read this manual carefully before operating your set and retain it
for future reference.
LAT240DT1
LAT240DT1Q
LAT240DT1S
LAT240DT2
LAT240DT2Q
LAT240DT2S
LAT240DT3
LAT240DT3Q
LAT240DT3S
ACC-LATB2
ACC-LATB3
ACC-LATB4
LCLG012U
OWNER’S MANUAL
LG Digital
Signage
(LED SIGNAGE)
www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.

2
ENGLISH_index
TABLE OF CONTENTS
SAFETY PRECAUTIONS .............3
- Precautions In Installing the Product ............... 3
- Precautions to the AC Adapter and Electrical
Power................................................................................. 5
- Precautions In Moving the Product................... 7
- Precautions In Using the Product ...................... 8
- Mounting on a Wall ................................................... 9
ASSEMBLING AND
PREPARING ............................. 10
- Remote Control Receiver.....................................11
- Optional Accessories.............................................. 12
- Parts................................................................................ 13
- Installing on a Wall.................................................. 15
TROUBLESHOOTING............... 16
PRODUCT SPECIFICATIONS... 17

3
ENGLISH_index
WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may
cause radio interference.
SAFETY PRECAUTIONS
Please read these safety precautions carefully before using the product.
WARNING
If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.
CAUTION
If you ignore the caution message, you may be slightly injured or the product may be damaged.
WARNING
• Indoor Use Only.
NOTE
• Some features described in the User Manual may not be supported in certain models and countries.
Precautions In Installing the Product
WARNING
• Keep away from heat sources like electrical heaters.
- Electrical shock, fire, malfunction, or deformation may occur.
• Keep the packing anti-moisture material or vinyl packing out of the reach of children.
- Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to vomit and visit the
nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it out of the reach of children.
• Do not put heavy objects on the product or sit upon it.
- If the product collapses or is dropped, you may be injured. Children must pay particular attention.
• Do not leave the power or signal cable unattended on the pathway.
- The passerby can trip or fall, which can cause electrical shock, fire, product breakdown, or injury.
• Install the product in a neat and dry place.
- Dust or moisture can cause electrical shock, fire or product damage.
• If you dropped the product or the case is broken, turn off the product and unplug the power cord.
- If you continue to use without taking proper measures, electrical shock or fire can occur. Contact the service center.

4
ENGLISH_index
• Do not drop an object on or apply pressure to the product. Do not throw any toys or objects on the product screen.
- It can cause injury to human, problem to product and damage the display.
• Do not let the product fall or drop when connecting it with an external device.
- This may cause injury and/or damage to the product.
• Do not install this product on a wall where there is high risk of exposure to oil fumes or mist.
- This may damage product and cause it to fall.
• Install the product firmly fixed on a floor, wall, etc. to prepare against external impact such as wind and earthquake.
- You must refer to the installation guide.
• Safely install the product in a place that can hold the weight of the product.
- A lack of strength may cause the product to fall.
CAUTION
• Make sure the product ventilation holes are not blocked. Install the product in a suitably wide place (more than
100mmfromthewall).
- If you install the product too close to the wall, it may be deformed or fire can break out due to internal heat.
• When installing the product on a shelf or cabinet, make sure that the bottom end of the product is not protruding
forward.
- The product may fall due to unbalanced centre of gravity, which may cause personal injury or damage to the product.
Be sure to use cabinets or shelves that fit your product.
• Do not block the ventilation hole of the product with a tablecloth or curtain.
- The product can be deformed or fire can break out due to overheating inside the product.
• Install the product on a flat and stable place that has no risk of dropping the product.
- If the product is dropped, you may be injured or the product may be broken.
• Install the product where no EMI occurs.
• Keep the product away from direct sunlight.
- The product can be damaged.
• If you install the product in a place that does not meet the recommended conditions, this may cause serious damage
to the product’s picture quality, life cycle, and appearance. Please check with LG or a qualified installer before installing.
This caution applies to a place where there is an abundance of fine dust or oil mist, chemical substances are used, the
temperature is very high or low, the humidity is very high, or the product is likely to remain turned on for a long period
of time (airport and train station). failure to do so will invalidate the warranty.
• Do not install the product in an area with poor ventilation (e.g. on a bookshelf, in a closet) or outside and avoid placing
on cushions or carpets.
• In addition, do not install it where there are heating objects such as lighting equipment.

5
ENGLISH_index
Precautions to the AC Adapter and Electrical Power
WARNING
• If water or any foreign substance goes inside the product (TV, monitor, power cord, or AC adapter), disconnect the
power cord immediately and contact the service center.
- Otherwise, this may cause a fire or electric shock due to damage to the product.
• Do not touch the power plug or AC adapter with wet hands. If the pins of the plug are wet or dusty, wipe and dry them
before use.
- Otherwise, this may cause a fire or electric shock.
• Make sure to completely insert the power cord into the AC adapter.
- If loosely connected, the poor connection may cause a fire or electric shock.
• Be sure to use power cords and AC adapters provided or approved by LG Electronics, Inc.
- The use of non-approved products may cause a fire or electric shock.
• When unplugging the power cord, always pull it by the plug. Do not bend the power cord with excessive force.
- The power line can be damaged, which may cause electric shock or fire.
• Be careful not to step or place heavy objects (electronic appliances, clothing, etc.) on the power cord or AC adapter. Be
careful not to damage the power cord or AC adapter with sharp objects.
- Damaged power cords may cause a fire or electric shock.
• Never disassemble, repair or modify the power cord or AC adapter.
- This may cause a fire or electric shock.
• Make sure to connect the power cable to the grounded current.
- You may be electrocuted or injured.
• Use the rated voltage only.
- The product can be damaged, or you may be electrocuted.
• In the presence of thunder and lightning, never touch the power cord and signal cable because it can be very
dangerous.
- It can cause electric shock.
• Do not connect several extension cords, electrical appliances, or electrical heaters to a single outlet. Use a power strip
with a grounding terminal designed for exclusive use with the computer.
- A fire can break out due to overheating.
• Do not touch the power plug with wet hands. Additionally, if the cord pin is wet or covered with dust, dry the power
plug completely or wipe dust off.
- You may be electrocuted due to excess moisture.

6
ENGLISH_index
• If you don’t intend to use the product for a long time, unplug the power cable from the product.
- Covering dust can cause a fire, or insulation deterioration can cause electric leakage, electric shock or fire.
• Fix the power cable completely.
- If the power cable is not fixed completely, a fire can break out.
• Do not insert a conductor (like a metal chopstick) into one end of the power cable while the other end is connected
to the input terminal on the wall. Additionally, do not touch the power cable right after plugging into the wall input
terminal.
- You may be electrocuted.
• The appliance coupler is used as the disconnect device.
• Please make sure the device is installed near the wall outlet to which it is connected and that the outlet is easily
accessible.
• As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if the unit
is turned off.
CAUTION
• Be sure to keep the outlet, AC adapter, and pins of the power plug clean from dust and etc.
- This may cause a fire.
• Do not unplug the power cord while the product is in use.
- Electrical shock can damage the product.
• Use only the power cord supplied with the unit. If you use another power cord, make sure that it is certified by the
applicable national standards when not provided by the supplier. If the power cable is faulty in any way, please contact
the manufacturer or the nearest authorized repair service provider for a replacement.
• Ensure the power cord does not come into contact with hot objects such as a heater.
- This may cause a fire or an electric shock hazard.

7
ENGLISH_index
Precautions In Moving the Product
WARNING
• Make sure to turn off the product.
- You may be electrocuted or the product can be damaged.
• Make sure to remove all cables before moving the product.
- You may be electrocuted or the product can be damaged.
• Make sure the panel faces forward and hold it with both hands to move. If you drop the product, the damaged product
can cause electric shock or fire. Contact an authorized the service center for repair.
• Make sure the product is turned off, unplugged, and all cables have been removed. It may take 2 or more people to
carry larger apparatus. Do not press against or put stress on the front panel of the apparatus.
CAUTION
• Do not shock the product when moving it.
- You may be electrocuted or the product can be damaged.
• Do not dispose the product-packing box. Use it when you move.

8
ENGLISH_index
Precautions In Using the Product
WARNING
• Do not disassemble, repair or modify the product at your own discretion.
- Fire or electric shock accident can occur.
- Contact the service center for check, calibration or repair.
• When the display is to be left unattended for an extended period of time, unplug it from the wall outlet.
• Do not shock or scratch the front and sides of the screen with metallic objects.
- Otherwise, it may cause damage to the screen.
• Never touch the wall outlet when there is leakage of gas, open the windows and ventilate.
- It may cause a fire or a burn by a spark.
• Keep the product away from water.
- Fire or electric shock accident can occur.
• If you can smell smoke or other odors or hear a strange sound unplug the power cord and contact the service center.
- Fire or electric shock accident can occur.
• Do not touch the surface to overheat.
• Avoid high temperatures and humidity.
• Do not use high voltage electrical goods near the product(e.g. electric swatter).
- This may result in product malfunction.
CAUTION
• All the power sources must be disconnected by removing the power cables to remove all power from the unit.
• Do not put or store inflammable substances near the product.
- There is a danger of explosion or fire due to careless handling of the inflammable substances.
• When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching. Do not
clean with a wet cloth or spray water or other liquids directly onto the product. An electric shock may occur. (Do not
use chemicals such as benzene, paint thinners, or alcohol.)
• Take a rest from time to time to protect your vision.
• Keep the product clean at all times.
• Take a comfortable and natural position when working with a product to relax the muscles.
• Take a regular break when working with a product for a long time.
• Do not press strongly upon the panel with a hand or sharp object such as nail, pencil, or pen, or make a scratch on it.

9
ENGLISH_index
• Keep the proper distance from the product.
- Your vision may be impaired if you look at the product too closely.
• Leaving a fixed image on the screen for a long time may cause damage to the screen and cause image retention.
- Image retention and related problems are not covered by the warranty on this product.
• Set the appropriate resolution and clock by referring to the User’s Guide.
- Your vision can be impaired.
• Use authorized detergent only when cleaning the product. (Do not use benzene, thinner, or alcohol.)
- Product can be deformed.
• Do not expose to dripping or splashing and do not place objects filled with liquids, such as vases, cups, etc. on or over
the apparatus (e.g. on shelves above the unit).
• Batteries should not be exposed to excessive heat. For example, keep away from direct sunlight, open fireplace, and
electric heaters.
• Do not place non-rechargeable batteries in charging device.
• Since the LED Signage uses a high technology to produce a screen comprised of millions of LED packages, a few pixel
spots (red, green, white, and black) may occasionally appear on the screen during use.
- This is a phenomenon that can occur due to the unique properties of the LED Signage and does not indicate any
performance issues or malfunction.
• To clean the product, use an air gun to lightly remove dust from the front frame and the screen. If there are foreign
substances in between the LEDs on the screen, it may cause a defect in the screen.
- Do not physically come in contact with the screen of the LED Package. This may cause damage to the product.
Mounting on a Wall
• Do not install this product by yourself as you may injure yourself or cause damage to product. Please contact service
personnel authorised by manufacturer.

10
ENGLISH_index
ASSEMBLING AND PREPARING
CAUTION
• Always use genuine components to ensure safety and product performance.
- The product warranty will not cover damage or injury caused by the use of counterfeit components.
• Connect the power cord to the product before you plug it into a wall outlet.
- Plugging the power cord into a wall outlet first may cause an electric shock, which can damage the product.
• When installing or using this product, be cautious of damaging the product or safety accident due to negligence.
• If you do not fully understand the instructions in this manual, do not install the product and contact the service centre.
• Check the accessories provided with the model before installation.
- We will not be responsible for missing or damaged accessories after the internal packaging is damaged.
• Keep out of reach of children, as various safety accidents such as suffocation can occur if an infant or child swallows
the accessories provided with the product.
• Make sure that the screws are completely tightened.
- Tightening the screws with excessive force may damage the wall, degrade the performance and solidity of the
product, or damage the product.
• Do not install display products that are heavier than the designated weight and make sure that external force is not
applied.
• Be cautious of safety accidents when handling tools for installing the product.
• Before installation, remove accessories (watch, bracelet, etc.) that can damage the coloured, transparent film.
• Applying excessive force may damage the product.
• There is no problem if fine bubbles are not visible to the naked eye at a distance of 1 m from the light-emitting surface
of the product.
NOTE
• The accessories provided with your product may vary depending on the model.
• Product specifications or contents in this manual may be changed without prior notice due to upgrade of product
functions.
• The warranty will not cover any damage caused by using the product in an excessively dusty environment.
• Up to 4 films are supported per 210 W adapter.
• Up to 18 1st bezel kits can be connected to a LAN port.
• Up to 26 common bezel kits can be supported by a 1st bezel kit.
• For adapter cable extension, use an approved standard cable.

11
ENGLISH_index
WARNING
• The warranty will not cover any component damage caused by electrostatic discharge at the time of installation. When
installing this product, you must wear anti-electrostatic discharge (ESD) gear.
• There should be no oil, water, dust and foreign substance on the glass surface where the coloured, transparent LED
film will be installed.
• Do not use surfactant-containing products for cleaning. It compromises the film’s adhesive strength.
• It is recommended that you use dedicated tools (for film attachment) when installing the film.
• Workers should wear masks and antistatic gloves and be careful not to allow foreign objects to adhere to the product
or the glass surface.
• The coloured, transparent LED film should not be folded or wrinkled, and once attached, should not be separated from
the glass.
• Be cautious when handling the coloured, transparent LED film because it is vulnerable to static electricity and foreign
substances.
• After opening the product, install it immediately or within 1 month at the latest.
• Applying strong physical impact on the installed film surface may damage the product.
Required Items for Installation
Oil-based marker, mask, antistatic gloves, the Phillips-head screwdriver, wool putty knife, (steel) ruler
Installation Preparation
• Leave 1-2 mm of the gap between the aluminium bars when attaching them to the glass surface.
- A pressure of 5 to 7 kgf is needed when attaching to the glass surface.
Remote Control Receiver
Because the product is the embedded-type, the remote control should be used only during installation and the use of
remote control by user is not recommended.

12
ENGLISH_index
Optional Accessories
Without prior notice, optional accessories are subject to change to improve the performance of the product, and new
accessories may be added. The illustrations in this manual may differ from the actual product and optional accessories.
LCLG002
ACC-LATP1
NOTE
• Optional accessories are only available for some models. If necessary, please purchase them separately.

13
ENGLISH_index
Parts
The illustrations may differ depending on the model.
LAT240DT1* LAT240DT2* LAT240DT3*
ACC-LATB2
ACC-LATB3
ACC-LATB4

14
ENGLISH_index
LCLG012U

15
ENGLISH_index
Installing on a Wall
Fix the assembled set on a desired place.
LCLG012U
283 mm
139 mm

16
ENGLISH_index
TROUBLESHOOTING
No image is displayed or the screen image looks abnormal.
Problem Solution
Is the power cord connected to the
product?
• Check if the power cord is correctly plugged into the power outlet.
Check if the cable is properly connected. • Problems may occur if the user connects cables arbitrarily. Contact a
system integrator or the service centre for cable connection change.
The display colour is abnormal.
Problem Solution
Screen colour is unstable or mono-
coloured.
• Problems may occur if the user connects cables arbitrarily. Contact a
system integrator or the service centre for cable connection change.

17
ENGLISH_index
PRODUCT SPECIFICATIONS
Without prior notice, all product information and specifications contained in this manual are subject to change to
improve the performance of the product.
The symbol means alternating current, and the symbol means direct current.
Film Panel Screen Type Film Panel
Usage Condition Daily Usage Time 24 hours (video)
Video Signal Synchronization Digital
Input/Output Ports LCLG012U
ACC-LATB2
Embedded Battery Not applicable.
Environmental
Conditions
Operating
Temperature
0 °C to 45 °C
Operating Humidity 10 % to 70 %
Storage Temperature -20 °C to 60 °C
Storage Humidity 5 % to 85 %

18
ENGLISH_index
LAT240DT1*, LAT240DT2*, LAT240DT3*
Film Panel Pixel pitch 24 mm (H) x 24 mm (V)
Power Power
Consumption
LAT240DT1* On Mode: 37 W (Typ.)
LAT240DT2*
LAT240DT3* On Mode: 9 W (Typ.)
Dimensions (Width x Height x Depth)
/ Weight
LAT240DT1* Film 668x480x1.8(mm)/0.73(kg)
Module 672x480x1.8(mm)/0.73(kg)
LAT240DT2* Film 476x480x1.8(mm)/0.53(kg)
Module 480x480x1.8(mm)/0.53(kg)
LAT240DT3* Film 668x120x1.8(mm)/0.18(kg)
Module 672x120x1.8(mm)/0.18(kg)
- The installation is only available for glass with a radius of more than 1,100 mm.
ACC-LATB*
Power Power Rating ACC-LATB2
19.5 V 7.0 A
ACC-LATB3
ACC-LATB4 19.5 V 3.0 A
Power Consumption ACC-LATB2
OnMode(including2x2Film):150W(Typ.)
ACC-LATB3
ACC-LATB4 OnMode(including2x2Film):40W(Typ.)
Dimensions (Width x Height x Depth)
/ Weight
ACC-LATB2 547.3x63x24(mm)/0.45(kg)
ACC-LATB3 479.5x28.1x24(mm)/0.26(kg)
ACC-LATB4 444.3x55.9x24(mm)/0.48(kg)
LCLG012U
Power Power Rating AC 100-240 V ~ 50/60 Hz 0.5 A
Power Consumption On Mode: 20 W (Typ.)
Dimensions (Width x Height x Depth)
/ Weight
293x188.7x37(mm)/1.5(kg)

19
ENGLISH_index
[Unit: mm]
LAT240DT1* 1.8
480
668
LAT240DT2*
1.8
480
476
LAT240DT3* 1.8
120
668

20
ENGLISH_index
[Unit: mm]
188.7
293
LCLG012U 37
ACC-LATB2
ACC-LATB3
ACC-LATB4
547.3
63
55.9
444.3
24
28.1
479.5
