LG 65TR3DJ-E User manual

BA
C
LG Digital Signage
(MONITOR SIGNAGE)
Afchage dynamique numérique LG
(AFFICHAGE SUR MONITEUR)
Señalización digital LG
(MONITOR DE SEÑALIZACIÓN)
ENGLISH Installation Guide
Please read this manual carefully before operating your set and retain it for future reference.
FRANÇAIS Guide d’installation
Veuillez lire ce manuel attentivement avant d’utiliser l’appareil et conservez-le pour pouvoir vous y reporter
ultérieurement.
ESPAÑOL Guía de instalación
Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
Printed in Korea
65TR3DJ-E 65TR3DJ-B 65TR3DJ-I
75TR3DJ-E 75TR3DJ-B 75TR3DJ-I
86TR3DJ-E 86TR3DJ-B 86TR3DJ-I

ʣwww.lg.com/id-manual

Kg
ENGLISH
Dimensions
(Width x Height x
Depth) / Weight
65TR3DJ-B
65TR3DJ-I
65TR3DJ-E
1,489 mm x 897 mm x 87 mm / 38.75 kg
(58.6 inches x 35.3 inches x 3.4 inches / 85.4 lbs)
75TR3DJ-B
75TR3DJ-I
75TR3DJ-E
1,710 mm x 1,020 mm x 87 mm / 53.1 kg
(67.3 inches x 40.1 inches x 3.4 inches / 117.0 lbs)
86TR3DJ-B
86TR3DJ-I
86TR3DJ-E
1,957 mm x 1,160 mm x 87 mm / 67.45 kg
(77.0 inches x 45.6 inches x 3.4 inches / 148.7 lbs)
FRANÇAIS
Dimensions
(largeur x hauteur
x profondeur) / Poids
65TR3DJ-B
65TR3DJ-I
65TR3DJ-E
1 489 mm x 897 mm x 87 mm / 38,75 kg
(58,6 po x 35,3 po x 3,4 po / 85,4 lb)
75TR3DJ-B
75TR3DJ-I
75TR3DJ-E
1 710 mm x 1 020 mm x 87 mm / 53,1 kg
(67,3 po x 40,1 po x 3,4 po / 117,0 lb)
86TR3DJ-B
86TR3DJ-I
86TR3DJ-E
1 957 mm x 1 160 mm x 87 mm / 67,45 kg
(77,0 po x 45,6 po x 3,4 po / 148,7 lb)
ESPAÑOL
Dimensiones
(ancho x alto x
profundidad) / Peso
65TR3DJ-B
65TR3DJ-I
65TR3DJ-E
1 489 mm x 897 mm x 87 mm / 38,75 kg
75TR3DJ-B
75TR3DJ-I
75TR3DJ-E
1 710 mm x 1 020 mm x 87 mm / 53,1 kg
86TR3DJ-B
86TR3DJ-I
86TR3DJ-E
1 957 mm x 1 160 mm x 87 mm / 67,45 kg
Alimentación
65TR3DJ-B
65TR3DJ-I
65TR3DJ-E
CA 100-240 V ~ 50/60Hz, 3,0A
75TR3DJ-B
75TR3DJ-I
75TR3DJ-E
CA 100-240 V ~ 50/60Hz, 3,5A
86TR3DJ-B
86TR3DJ-I
86TR3DJ-E
CA 100-240 V ~ 50/60Hz, 5,5A

AUDIO IN AUDIO OUT
SPDIF
VGA OUT
VGA OUT
VGA
VGA
AUDIO IN AUDIO OUT
SPDIF
VGA OUT
VGA OUT
VGA
VGA
AUDIO IN AUDIO OUT
SPDIF
VGA OUT
VGA OUT
VGA
VGA
A
A

AUDIO IN AUDIO OUT
SPDIF
VGA OUT
VGA OUT
VGA
VGA
B

C
