LG LDT7797 Series User manual

DISHWASHER
SERVICE MANUAL
NOTE
For Authorized Service Technicians
CONFIDENTIAL
MODEL : LUDP8997SN / LDT7797** / LDP6797** /
LDP5676** / LDT5665** / LDF5545** / LSDF9897** /
LDT7808** / LSDT9908** / LDT5678** / LDF5678** /
LDP7708** / SKSDW24*** / LDB4548** / LDT6809** /
LDP6809** / LDPS6844** / LDP7808**


Any reproduction or duplication (including by way of email, facsimile or other electronic means),
publication, modification, copying or transmission of this Service Manual is STRICTLY PROHIBITED unless you
have obtained the prior written consent of the LG Electronics entity from which you received this Service
Manual. The material covered by prohibition includes, without limitation, any text, graphics or logos in this
Service Manual.
Copyright ⓒ 2017 - 18 LG Electronics Inc. All rights
reserved. Only for training and service purposes.

For Authorized Service Technicians
- 3 -
CONTENTS


















For Authorized Service Technicians
- 4 -
- 4-
DISCONNECT POWER SUPPLY LINE BEFORE SERVICING
RECONNECT ALL GROUNDING DEVICES
IMPORTANT SAFETY NOTICE
This service information is intended for individuals
possessing adequate backgrounds of electrical,
electronic and mechanical experience.
Any attempt to repair this appliance may result in
personal injury and property damage.
The manufacturer or seller cannot be responsible
for the interpretation of this information, nor can it
assume any liability in connection with its use.
CAUTION

For Authorized Service TechniciansFor Authorized Service Technicians
- 5 -
2. SPECIFICATIONS
ITEM SPECIFICATION
 
 
 
 
 
 
 
 
 
 
 
 
 
 




 
 
 
 
 
 
 
 

For Authorized Service Technicians
- 6 -
3. FEATURES AND OPERATION
PRODUCT FEATURES
QuadWash™ System
Multi-motion lower spray arm shoots water in various directions and at optimized intensities to reach every area of the tub.
This system provides more powerful and complete cleaning coverage.
Inverter Direct Drive Motor
LG's experience in motor technology results in extraordinary functionality, with advanced features like the Dual Zone option,
The simple design and high build quality of the motor make it so reliable that it's covered for 10 years under the warranty.
EasyRack Plus
various shapes and sizes.
Hybrid Drying System
and gentle care for dishes.
Smart ThinQ™
Download the new LG smart phone app to set options, self-diagnose and troubleshoot problems with the appliance, and
other useful features. Some of these functions use Wi-Fi or NFC (Near Field Communication) technology and require an
NFC-equipped smart phone.

For Authorized Service TechniciansFor Authorized Service Technicians
- 7 -

Control Panel
12
4
3
1
Power
•Press the Power button to turn power on and
off.
•After the cycle is complete, the power
automatically turns off for purposes of safety and
economy.
•If there is a power surge, power outage, or
disruption of any kind, power is automatically
turned off for safety.
•When power is connected again, it will turn on
automatically and resume the cycle.
2
Display
•: Rinse Aid Icon
- This icon illuminates when the rinse aid level is
low. The LED automatically shuts off when the
- Refer to the Rinse Aid Dispenser Adjustment
section.
•: Digital Display
- The digital display on the control panel shows
the ESTIMATED cycle time. When the cycle
and options are selected, the display shows
the total estimated time to complete those
selections. During operation, the display shows
the remaining estimated operating time.
NOTE
•The estimated time shown on the display does
not include delay times for heating water, etc.
•If Delay Start is selected, the display shows the
delay time in hours.
•Cycle time may vary depending on the soil level
of your load.
•, : Control Lock
- The Control Lock feature helps prevent
settings from being changed during a cycle.
Selecting this feature locks all of the buttons,
except for the Power button, on the control
panel. This feature does not lock the door.
- While a cycle is running, press and hold Half
Load and Energy Saver simultaneously for
three seconds to activate or deactivate Control
Lock.
- To start a new cycle, deactivate Control Lock.
•: Wi-Fi
- When the appliance is connected to the
internet through a home Wi-Fi network, this
icon illuminates.
- Press and hold Delay Start for approximately
three seconds to connect to the network.
3
Cancel
•The drain pump activates and the cycle cancels.
power turns off.
•Press and hold Start for three seconds to
activate.
4
Start
•To operate the machine, either press Start and
close the door within four seconds or close the
door and press Start.
•If Start button is not pressed to start the cycle,
an alert will sound.
Chime On/Off
•To activate or deactivate the button sounds,
press and hold Dual Zone and Energy Saver
simultaneously for three seconds. The error alert
sound cannot be turned off.

For Authorized Service Technicians
- 8 -

Control Panel
12
4
3
1
Power
•Press the Power button to turn power on and
off.
•After the cycle is complete, the power
automatically turns off for purposes of safety and
economy.
•If there is a power surge, power outage, or
disruption of any kind, power is automatically
turned off for safety.
•When power is connected again, it will turn on
automatically and resume the cycle.
2
Display
•: Rinse Aid Icon
- This icon illuminates when the rinse aid level is
low. The LED automatically shuts off when the
- Refer to the Rinse Aid Dispenser Adjustment
section.
•: Digital Display
- The digital display on the control panel shows
the ESTIMATED cycle time. When the cycle
and options are selected, the display shows
the total estimated time to complete those
selections. During operation, the display shows
the remaining estimated operating time.
NOTE
•The estimated time shown on the display does
not include delay times for heating water, etc.
•If Delay Start is selected, the display shows the
delay time in hours.
•Cycle time may vary depending on the soil level
of your load.
•, : Control Lock
- The Control Lock feature helps prevent
settings from being changed during a cycle.
Selecting this feature locks all of the buttons,
except for the Power button, on the control
panel. This feature does not lock the door.
- While a cycle is running, press and hold
Dual Zone for three seconds to activate or
deactivate Control Lock.
- To start a new cycle, deactivate Control Lock.
3
Cancel
•The drain pump activates and the cycle cancels.
power turns off.
•Press and hold Start for three seconds to
activate.
4
Start
•To operate the machine, either press Start and
close the door within four seconds or close the
door and press Start.
•If Start button is not pressed to start the cycle,
an alert will sound.
Chime On/Off
•To activate or deactivate the button sounds,
press the Half Load button for three seconds.
The error alert sound cannot be turned off.

For Authorized Service TechniciansFor Authorized Service Technicians
- 9 -
Control Panel
12
4
3
1
Power
•Press the Power button to turn power on and
off.
•After the cycle is complete, the power
automatically turns off for purposes of safety and
economy.
•If there is a power surge, power outage, or
disruption of any kind, power is automatically
turned off for safety.
•When power is connected again, it will turn on
automatically and resume the cycle.
2
Display
•: Rinse Aid Icon
- This icon illuminates when the rinse aid level is
low. The LED automatically shuts off when the
- Refer to the Rinse Aid Dispenser Adjustment
section.
•: Digital Display
- The digital display on the control panel shows
the ESTIMATED cycle time. When the cycle
and options are selected, the display shows
the total estimated time to complete those
selections. During operation, the display shows
the remaining estimated operating time.
NOTE
•The estimated time shown on the display does
not include delay times for heating water, etc.
•If Delay Start is selected, the display shows the
delay time in hours.
•Cycle time may vary depending on the soil level
of your load.
•, : Control Lock
- The Control Lock feature helps prevent
settings from being changed during a cycle.
Selecting this feature locks all of the buttons,
except for the Power button, on the control
panel. This feature does not lock the door.
- While a cycle is running, press and hold Half
Load and Energy Saver simultaneously for
three seconds to activate or deactivate Control
Lock.
- To start a new cycle, deactivate Control Lock.
3
Cancel
•The drain pump activates and the cycle cancels.
power turns off.
•Press and hold Start for three seconds to
activate.
4
Start
•To operate the machine, either press Start and
close the door within four seconds or close the
door and press Start.
•If Start button is not pressed to start the cycle,
an alert will sound.
Chime On/Off
•To activate or deactivate the button sounds,
press and hold Dual Zone and Energy Saver
simultaneously for three seconds. The error alert
sound cannot be turned off.


For Authorized Service Technicians
- 10 -
Cycles
Select your desired cycle.
Auto
This cycle senses the soil amount and soil toughness
and is optimized to achieve the best cleaning.
•For steam models, this cycle has the added power
of steam.
Heavy
This cycle is for heavily soiled dishes and dishes with
hardened on soil. The Heavy cycle defaults to the
strongest spray intensity and uses it to wash heavily
soiled dishes.
•For steam models, this cycle has the added power
of steam.
Delicate
china and stemware.
•For steam models, this cycle has the added power
of steam.
Refresh (Steam Models)
This cycle freshens up and warms dishes that have
been unused for a long time.
•Do not use detergent when using this cycle.
Normal
This cycle is for moderately soiled, everyday loads.
Select the Night Dry option if leaving dishes
overnight. Press and hold Extra Dry for three
seconds to activate Night Dry.
Turbo
This cycle will clean heavily soiled dishes in an hour
using slightly more energy and water. Select the
Extra Dry options for better drying.
Download Cycle
Use a dedicated cycle downloadable via Wi-Fi or
NFC.
Machine Clean
This cycle is for cleaning the inside of the dishwasher.
Use the cycle without dishes in the machine. It
eliminates residual soils, odor, white spots, and other
dirt. Add citric acid or another cleaning agent for more
effective results.
•Press and hold Heavy for three seconds to activate.
NOTE
•The Machine Clean
cycles. To activate or deactivate the icon, press the
Delicate button for three seconds.
Rinse
This cycle is a quick rinse for dishes that will not be
washed immediately. The cycle rinses dishes that
have excess soil to soften dried on residue. Rinsing
the dishes helps prevent odors in the dishwasher. No
detergent should be used.
•Press and hold Normal for three seconds to
activate.
Express
This cycle will quickly clean lightly soiled dishes.
(Time : 33 minutes) Select the Extra Dry option or
another cycle for better drying.
•Press and hold Turbo for three seconds to activate.
NOTE
•Rinse, Turbo, and Express cycles do not have
drying or have a shortened dry time. For better
drying performance, open the door after these
cycles or select a different cycle.

For Authorized Service TechniciansFor Authorized Service Technicians
- 11 -
Options
Select the desired cycle button and then select the
options for that cycle.
Dual Zone
This option automatically sets the spray intensity to
soft for the upper spray arm and strong for the lower
spray arm. Place heavily soiled dishes like plates and
bowls in the lower rack and lightly soiled dishes like
cups and small plates in the upper rack to get the
best results.
Half Load
This option washes intensively by selecting the upper
or lower racks. For small loads, use just the upper
or lower rack to save energy and time. By pressing
the Half Load button, the settings , and the
cancellation of the Half Load option are available.
Energy Saver
This option saves energy by reducing the wash
and rinse temperatures. Wash time is increased to
maintain wash performance. Do not use this cycle
with heavily soiled dishes.
Pre-Steam (Steam Models)
This option adds steam at the start of the cycle to
improve wash performance.
High Temp
Raises the main wash temperature to improve
cleaning.
Extra Dry
Select the Extra Dry option for better drying
performance. This option adds 20 minutes of extra
drying time to the cycle and raises the heated rinse
temperature.
Night Dry
Dishes are often left in the dishwasher overnight after
the cycle ends. This can result in the steam inside
the tub condensing on dishes, leaving them wet. The
Night Dry option runs the ventilation fan periodically
to help vent the steam from the tub.
•Press and hold Extra Dry for three seconds to
activate.
Delay Start
The Delay Start feature delays the start of a selected
cycle. Each time the Delay Start button is pressed,
the delay time increases by an hour. The delay
time can be set from 1 to 12 hours, in one-hour
increments.

For Authorized Service Technicians
- 12 -
Control Panel
2
1
4
3
1
Power
For Steam Models(LSDF9897**, LDT7808**, LSDT9908**, LDP7708**, SKSDW24***,
LDT6809**, LDP6809**, LDPS6844**, LDP7808**)
•Press the Power button to turn power on and
off.
•After the cycle is complete, the power
automatically turns off for purposes of safety and
economy.
•If there is a power surge, power outage, or
disruption of any kind, power is automatically
turned off for safety.
•When power is connected again, it will turn on
automatically and resume the cycle.
2
Display
•: Digital Display
- The digital display on the control panel shows
the ESTIMATED cycle time. When the cycle
and options are selected, the display shows
the total estimated time to complete those
selections. During operation, the display shows
the remaining estimated operating time.
NOTE
•The estimated time shown on the display does
not include delay times for heating water, etc.
•If Delay Start is selected, the display shows the
delay time in hours.
•Cycle time may vary depending on the soil level
of your load.
•: Control Lock
- The Control Lock feature helps prevent
settings from being changed during a cycle.
Selecting this feature locks all of the buttons,
except for the Power button, on the control
panel. This feature does not lock the door.
- While a cycle is running, press and hold Half
Load and Energy Saver simultaneously for
three seconds to activate or deactivate Control
Lock.
•To start a new cycle, deactivate Control Lock.
•: Rinse Aid Icon
- This icon illuminates when the rinse aid level is
low. The LED automatically shuts off when the
•Refer to the Rinse Aid Dispenser Adjustment
section.
•:Machine Clean
- This cycle is for cleaning the inside of the
dishwasher. Use the cycle without dishes in
the machine. It eliminates residual soils, odor,
white spots, and other dirt. Add citric acid
or another cleaning agent for more effective
results.
•Press and hold Heavy for three seconds to
activate.
NOTE
•The Machine Clean
cycles. To activate or deactivate the icon, press
the Delicate button for three seconds.
•: Wi-Fi
- When the appliance is connected to the
internet through a home Wi-Fi network, this
icon illuminates.
- Press and hold Delay Start for approximately
three seconds to connect to the network.

For Authorized Service TechniciansFor Authorized Service Technicians
- 13 -
3
Cancel
•The drain pump activates and the cycle cancels.
power turns off.
•Press and hold Start for three seconds to
activate.
4
Start
•To operate the machine, either press Start and
close the door within four seconds or close the
door and press Start.
•If Start button is not pressed to start the cycle,
an alert will sound.
Chime On/Off
•To activate or deactivate the button sounds,
press and hold Dual Zone and Energy Saver
simultaneously for three seconds. The error alert
sound cannot be turned off.

For Authorized Service Technicians
- 14 -
Cycles
Select your desired cycle.
Auto
This cycle senses the soil amount and soil toughness
and is optimized to achieve the best cleaning.
Heavy
This cycle is for heavily soiled dishes and dishes with
hardened on soil. The Heavy cycle defaults to the
strongest spray intensity and uses it to wash heavily
soiled dishes.
•This cycle has the added power of steam.
Delicate
china and stemware.
•This cycle has the added power of steam.
Refresh
This cycle freshens up and warms dishes that have
been unused for a long time.
•Do not use detergent when using this cycle.
Normal
This cycle is for moderately soiled, everyday loads.
Select the Night Dry option if leaving dishes
overnight. Press and hold Extra Dry for three
seconds to activate Night Dry.
•After the cycle ends, the fan runs for an hour to help
vent the warm, moist air in the tub. You can stop the
fan by opening the door after the cycle ends.
Turbo
This cycle will clean heavily soiled dishes in an hour
using slightly more energy and water.
•This cycle does not have drying. Select the Extra
Dry and Night Dry option or another cycle for better
drying.
Download Cycle
Use a dedicated cycle downloadable via Wi-Fi or
NFC.
NOTE
•Only the cycle code for the current Download cycle
appears on the appliance. See the smartphone app
for cycle codes, names, and more information about
the available cycles.
- Default Cycle : P1. Pots & Pans
Rinse
This cycle is a quick rinse for dishes that will not be
washed immediately. The cycle rinses dishes that
have excess soil to soften dried on residue. Rinsing
the dishes helps prevent odors in the dishwasher. No
detergent should be used.
•This cycle does not have drying.
•Press and hold Normal for three seconds to
activate.
Express
This cycle will quickly clean lightly soiled dishes.
(Time : 33 minutes)
•This cycle does not have drying. Select the Extra
Dry and Night Dry option or another cycle for better
drying.
•Press and hold Turbo for three seconds to activate.

For Authorized Service TechniciansFor Authorized Service Technicians
- 15 -
Options
Select the desired cycle button and then select the
options for that cycle.
Dual Zone
This option automatically sets the spray intensity to
soft for the upper spray arm and strong for the lower
spray arm. Place heavily soiled dishes like plates and
bowls in the lower rack and lightly soiled dishes like
cups and small plates in the upper rack to get the
best results.
Half Load
This option washes intensively by selecting the upper
or lower racks. For small loads, use just the upper
or lower rack to save energy and time. By pressing
the Half Load button, the settings , and the
cancellation of the Half Load option are available.
Energy Saver
This option saves energy by reducing the wash
and rinse temperatures. Wash time is increased to
maintain wash performance. Do not use this cycle
with heavily soiled dishes.
Steam
This option adds steam at the start of the cycle to
improve wash performance.
High Temp
Raises the main wash temperature to improve
cleaning.
Extra Dry
Select the Extra Dry option for better drying
performance. This option adds extra drying time to
the cycle and raises the heated rinse temperature.
•When the rinse aid is empty, the Extra Dry option is
selected automatically.
Night Dry
Dishes are often left in the dishwasher overnight after
the cycle ends. This can result in the steam inside
the tub condensing on dishes, leaving them wet. The
Night Dry option runs the ventilation fan periodically
to help vent the steam from the tub.
•Press and hold Extra Dry for three seconds to
activate.
•The Night Dry option is selected by default on all
cycles for which it is available, except the Normal
cycle.
•To add the Night Dry option to the Normal cycle,
press and hold Extra Dry for 3 seconds
Delay Start
The Delay Start feature delays the start of a selected
cycle. Each time the Delay Start button is pressed,
the delay time increases by an hour. The delay
time can be set from 1 to 12 hours, in one-hour
increments.

For Authorized Service Technicians
- 16 -
3-3. TEST MODE
BUTTON
Times
button is
pushed
Top
Display
Load and Checking points Door
open/
closed
Remark
Load LED
lighting
POWER
+START 1 TIME
n35/U00/
D00
(version)
All LEDs are
lit Either
"nC" will be
displayed when
NFC or Wi
Module fails.
POWER
+AUTO
+START
LDF5678**
,LDT5678**
1 TIME
n**/U**/
D**
(version)
All LEDs are
lit Either
"nC" will be
displayed when
NFC or Wi
Module fails.
Start
1 TIME Sump
Temp(˚C) Dispenser
Power
Button is lit
Rinse aid
Rell LED
ashes
(if rinse
aid needs
relling)
other LED
are turned
O
Closed
"EE" will be
displayed when
EEPROM is fails.
2 TIME N02
Drying Fan
Motor
Drying
Actuator
Closed
3 TIME Soil Level Soil Sensor Closed
4 TIME Drain Motor
RPM Drain Motor Either
5 TIME Frequency Inlet Valve Closed
6 TIME Washing
Motor RPM Washing Motor Closed
7 TIME Washing
Position
Washing Heater
Vario Valve Closed
Un : Detecting
Washing Position
Lo : Detecting
Complete
"nE" will be
displayed when
Vario Valve fails.
8 TIME - Power O All LEDs are
turned O Either
CHECK PROGRAM

For Authorized Service TechniciansFor Authorized Service Technicians
- 17 -
4. PARTS
Exterior Parts
2
3
7
1
4
8
6
5
1
Control Panel & Door Handle
2
Front Cover
3
Lower Cover
4
Shipping Brace
5
Safety Cover
6
SignaLight™ (some models)
7
Base
8
Leveling Feet
3
4
8
1
5
9
27
6
1
Control Panel
2
Door Handle
3
Front Cover
4
Lower Cover
5
Shipping Brace
6
Safety Cover
7
SignaLight™ (some models)
8
Base
9
Leveling Feet
Interior Parts
10
6
11
12
5
9
28
1
3
4
7
1
Top Wash Impeller
2
Upper Spray Arm
3
Lower Spray Arm
4
Filtration System
5
Detergent and Rinse Aid Dispenser
6
Drying Vent Cover
7
Tub Light (some models)
8
Cutlery Rack (some models)
9
Upper Rack
10
Silverware Bask et
11
Lower Rack (appearance may vary)
12
Steam nozzle OGP

For Authorized Service Technicians
- 18 -
5. PROGRAM CHARTS (SCHEMATIC DIAGRAMS)
Program Chart
C1 C2
C3
C4
C5
C6
C7
C8 C9 C10
C11
C12
C13
C14
C15
C16 C 17
C18
C19
C20
C21 C22 C 23 C24 C 25 C26 C 27
C28
C29 C 30 C 31 C32 C 33 C34 C 35 C36 C37
C38
C39
C40
C41
C42
C43
C44
C45
C46
C47
C48
C49
C50
C51
C52
C53
C54
C55
C56
C57
C58
C59
C60
C61
C62
C63
C64
C65
C66
C67
C68
C69 C70 C71 C 72 C73 C 74 C75 C 76 C77 C 78 C79 C 80 C81 C82
C83
C84
C85
C86
C87
C88
C89
C90
C91
C92
C93
C94
C95
C96
C97
C98
C99
C100
C101
C102
C103
C104
C105
C106
C107
C108
C109
C110
C111
C112
C113
C114 C115 C116 C 117 C118 C 119 C120 C 121 C122 C 123 C124 C 125
R1 LargeClass
Was h
R2 M e di u m C l a s s Pr e Was h 1 Pr e Was h 2 Pr e Was h 3
Pr e Was h 4
R3 Small Class Dr ai n
Water Supply
TurbidityPure
TempWash TurbidityPure
Cold Wate r Heating
Pr e Wa s h 1-1
TurbidityDirty
Cloggin g Sensing
De-clogging 1 Pr e Wa s h 1-2 Drai n
Water Supply
TempWash Pr e Was h 2 De-clogging 2 Drain
Water Supply
TempWash Pr e Wa s h 3-1 De-clogging 2
Pr e Wa s h 3-2 Drain
R4 Operatin g Conditon T e mp
≤ 28℃
R5 Unit(Basic)
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Soil
Sen
sing
St
op
Was h
St
op
Was h
St
op
Was h
St
op
Soil
Sen
sing
Was h
St
op
Soil
Sen
sing
St
op
Heati n g
Was h
Heati n g
Was h
Was h
St
op
Soil
Sen
sing
Was h Was h Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h Heatin g
Was h
Heati n g
Was h
Was h Was h Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h Heatin g
Was h
Was h Was h Was h
R6 Complete Conditon
( Bl a n k =T i me )
No
Wate r
Supply
C o mp
T e mp Time & Temp Ti me T i me Ti me No
Wate r
Supply
C o mp
Time & Temp Time & Temp T i me T i me No
Wate r
Supply
C o mp
Time & Temp T i me T i me T i me
R7 Target (Water / Temp) Wate r 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ Te mp 0 ℃
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ Wate r 0 ℃ 0 ℃ T e mp 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ Wat er 0 ℃ 0 ℃ Te mp 0 ℃ 0 ℃ 0 ℃
R8 T ime (가 : Du mmy T ime ) 125(가 ) 1(가) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 90 3120 20 272 10 210 272 10 210 272 10 210 210 210 215 215(가 ) 1(가) 10 5 5 20 20 272 10 210 272 10 210 272 10 210 210 210 215 215(가 ) 1(가) 10 5 5 20
R9 Load Control I nformation Freq L( 1500) L( 1500) L( 1700) L( 1700) L( 1700)
Vario
Term RPM
Vario
Term RPM
L( 1800)
Vario
Term RPM
Vario
Term RPM L ( 2100) L(2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) L( 2400) L( 2400) Freq L ( 1500)
L( 1500)
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM L ( 2100) L(2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) L( 2400) L( 2400) Freq
L( 1500)
4
L( 1500)
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term
R10 Auto S trong
R11 T e mp Ti me T i me Ti me Time & Temp Ti me Ti me T i me T i me
R12 2.80 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ 0 ℃ 0 ℃ 42 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃
R13 125( 가 ) 150(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 240 30 3390 60 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 157( 가 ) 10 5 5 20 420 120 60 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 162(가 ) 10 5 5 20 360 60 90
R14 390 회 L ( 1500) L( 1500) L( 1600) L( 1600) L( 1700) L 3 1700 A6.5 2200 L( 1600) L( 1600) L( 1600) L( 1600) L(1600) L( 1600) L( 1600) L( 1600) 445 회 L ( 1500)
L( 1500)
T 1 2600 A 1 2400 L( 1600) L( 1600) L( 1600) L( 1600) L(1600) L( 1600) L ( 1600) L( 1600) 487 회 L( 1500) L( 1500) L 2 3000 A 1 2400
R15 L 5 2300 U 1 2900
R16 T 1 2200 T 1 2200 U 1 2200 T 2 2600 T1.5
R17 Auto Str ong
R18 (Uppe r) T e mp T i me Ti me T i me Time & Temp Ti me T i me T i me T i me
R19 2.80 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ 0 ℃ 0 ℃ 42 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃
R20 125( 가 ) 150(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 150 30 3390 60 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 157( 가 ) 10 5 5 20 270 120 60 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 162(가 ) 10 5 5 20 240 60 90
R21 390 회 L ( 1500) L( 1500) L( 1600) L( 1600) L( 1700) L1.5 1700 A6.5 2200 L( 1600) L( 1600) L(1600) L( 1600) L(1600) L ( 1600) L( 1600) L( 1600) 445 회 L( 1500)
L( 1500)
T 1 2600 A 1 2400 L( 1600) L( 1600) L( 1600) L( 1600) L(1600) L( 1600) L ( 1600) L( 1600) 487 회 L( 1500) L( 1500) L 1 3000 A 1 2400
R22 L2.5 2300 U 1 2900
R23 T 1 2200 T 1 2200 U 1 2200 T 2 2600 T1.5
R24 Auto Str ong
R25 (L owe r) T e mp T i me T i me T i me Time & Temp T i me T i me T i me Ti me
R26 2.80 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ 0 ℃ 0 ℃ 42 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃
R27 125( 가 ) 150(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 210 30 3390 30 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 157( 가 ) 10 5 5 20 360 60 60 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 162(가 ) 10 5 5 20 300 60 45
R28 390 회 L ( 1500) L( 1500) L( 1600) L( 1600) L( 1700) L 3 1700 A6.5 2200 L( 1600) L( 1600) L( 1600) L( 1600) L(1600) L( 1600) L( 1600) L( 1600) 445 회 L ( 1500)
L( 1500)
T0.5 2600 A 1 2400 L ( 1600) L ( 1600) L(1600) L( 1600) L(1600) L ( 1600) L( 1600) L( 1600) 487 회 L( 1500) L ( 1500) L 2 3000 A 1 2400
R29 L 5 2300 U0. 5 2900
R30 T0.5 2200 T0.5 2200 U0.5 2200 T 1 2600 T0.75
R31 Auto So ft
R32 T e mp Ti me
R33 2.80 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R34 125( 가 ) 150(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 240 30 3
R35 390 회 L ( 1500) L( 1500) L( 1600) L( 1600) L( 1700) L 3 1700
R36
R37 T 1 2200
R38 Auto So ft
R39 (Uppe r) T e mp T i me
R40 2.80 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R41 125( 가 ) 150(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 150 30 3
R42 390 회 L ( 1500) L( 1500) L( 1600) L( 1600) L( 1700) L1.5 1700
R43
R44 T 1 2200
R45 Auto So ft
R46 (L owe r) T e mp T i me
R47 2.80 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R48 125( 가 ) 150(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 210 30 3
R49 390 회 L ( 1500) L( 1500) L( 1600) L( 1600) L( 1700) L 3 1700
R50
R51 T0.5 2200
R52 Heav y
R53 T i me Ti me Ti me
R54 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃
R55 125( 가 ) 157(가 ) 10 5 5 20 180 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 120 20 272 10 272 10 272 10 215 215( 가 ) 159(가 ) 10 5 5 20 120
R56 445 회 L ( 1500) L( 1500) L 2 2000 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500) L ( 1500) L 1 2400 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500) L ( 1500) L 1 2400
R57 U 1 2200 U 1 2400 U 1 2400
R58
R59 Heav y
R60 (Uppe r) T i me T i me T i me
R61 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃
R62 125( 가 ) 157(가 ) 10 5 5 20 120 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 90 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 90
R63 445 회 L ( 1500) L( 1500) L 1 2000 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500) L ( 1500) L0.5 2400 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500) L( 1500) L0.5 2400
R64 U 1 2200 U 1 2400 U 1 2400
R65
R66 Heav y
R67 (L owe r) T i me T i me T i me
R68 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃
R69 125( 가 ) 157(가 ) 10 5 5 20 150 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 90 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 90
R70 445 회 L ( 1500) L( 1500) L 2 2000 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500) L ( 1500) L 1 2400 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500) L ( 1500) L 1 2400
R71 U0.5 2200 U0.5 2400 U0.5 2400
R72
R73 Deli cate
R74 T i me Ti me T i me T i me
R75 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 75 ℃
R76 125( 가 ) 157(가 ) 10 5 5 20 150 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 120 30 20 272 10 272 10 272 10 215 215( 가 ) 159(가 ) 10 5 5 20 180
R77 445 회 L ( 1500) L( 1500) L 2 2000 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500)
L( 1500)
L 1 2600 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500)
L( 1500)
LT 12800
R78 U0.5 2200 U 1 2700 U 2 2600
R79 T0.5 2600
R80 Deli cate
R81 (Uppe r) T i me T i me T i me Ti me
R82 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 75 ℃
R83 125( 가 ) 157(가 ) 10 5 5 20 90 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 90 30 20 272 10 272 10 272 10 215 215( 가 ) 159(가 ) 10 5 5 20 150
R84 445 회 L ( 1500) L( 1500) L 1 2000 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500)
L( 1500)
L0.5 2600 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500)
L( 1500)
LT 0.5 2800
R85 U0.5 2200 U 1 2700 U 2 2600
R86 T0.5 2600
R87 Deli cate
R88 (L owe r) T i me T i me Ti me T i me
R89 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 75 ℃
R90 125( 가 ) 157(가 ) 10 5 5 20 135 20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 90 30 20 272 10 272 10 272 10 215 215( 가 ) 159(가 ) 10 5 5 20 120
R91 445 회 L ( 1500) L( 1500) L 2 2000 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500)
L( 1500)
L 1 2600 L( 2100) L( 2400) L( 2400) L( 2400) 459 회 L(1500)
L( 1500)
LT 12800
R92 U0.25 2200 U0.5 2700 U 1 2600
R93 T0.5 2600
R94 Normal Stron g
R95 T e mp Ti me Ti me T i me
R96 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃
R97 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 360 90 3 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 10 215 215( 가 ) 153( 가 ) 10 5 5 20 180 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215( 가 ) 159( 가 ) 10 5 5 20 600
R98 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 4 2000 L( 2400) L( 2400) L(2400) L ( 2400) L ( 2400) L ( 2400) L ( 2400) L ( 2400) 417 회 L ( 1500) L( 1500) L 2 2100 L(2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) L( 2400) L( 2400) 459 회 L( 1500) L( 1500) L 2 2600
R99 U 2 2200 U 1 2200 U 2 2700
R100 T 1 2600
R101 Normal Stron g
R102 (Uppe r) T e mp T i me Ti me T i me
R103 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃
R104 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 240 90 3 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 10 215 215( 가 ) 153( 가 ) 10 5 5 20 120 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215( 가 ) 159( 가 ) 10 5 5 20 480
R105 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 2 2000 L( 2400) L( 2400) L(2400) L ( 2400) L ( 2400) L ( 2400) L ( 2400) L ( 2400) 417 회 L ( 1500) L( 1500) L 1 2100 L(2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) L( 2400) L( 2400) 459 회 L( 1500) L( 1500) L 1 2600
R106 U 2 2200 U 1 2200 U 2 2700
R107 T 1 2600
R108 Normal Stron g
R109 (L owe r) T e mp T i me Ti me Ti me
R110 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃
R111 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 300 90 3 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 10 215 215( 가 ) 153( 가 ) 10 5 5 20 150 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215( 가 ) 159( 가 ) 10 5 5 20 420
R112 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 5 2000 L( 2400) L( 2400) L(2400) L ( 2400) L ( 2400) L ( 2400) L ( 2400) L ( 2400) 417 회 L ( 1500) L( 1500) L 2 2100 L(2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) L( 2400) L( 2400) 459 회 L( 1500) L( 1500) L 2 2600
R113 U0.5 2200 U 1 2700
R114 T0.5 2600
R115 Normal Me dium
R116 T e mp Ti me
R117 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R118 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 360 90 3
R119 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 4 2000
R120 U 2 2200
R121
R122 Normal Me dium
R123 (Uppe r) T e mp T i me
R124 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R125 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 240 90 3
R126 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 2 2000
R127 U 2 2200
R128
R129 Normal Me dium
R130 (L owe r) T e mp T i me
R131 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R132 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 300 90 3
R133 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 5 2000
R134
R135
R136 Normal Soft
R137 T e mp Ti me
R138 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R139 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 360 90 3
R140 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 4 2000
R141 U 2 2200
R142
R143 Normal Soft
R144 (Uppe r) T e mp T i me
R145 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R146 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 240 90 3
R147 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 2 2000
R148 U 2 2200
R149
R150 Normal Soft
R151 (L owe r) T e mp T i me
R152 3.20 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 35 ℃ 0 ℃
R153 125( 가 ) 157(가 ) 3 3 10 5 5 20 110 3 3 30 3 3 1 600 300 90 3
R154 445 회 L ( 1500) L( 1500) L( 1700) L( 1700) L( 1700) L 5 2000
R155
R156
R157 Tur bo
R158 T i me Ti me T i me T i me T i me
R159 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃
R160 125( 가 ) 159(가 ) 10 5 5 20 90 215 215(가 ) 162(가 ) 10 5 5 20 120 30 215 215(가 ) 162(가 ) 10 5 5 20 180 30
R161 459 회 L ( 1500) L( 1500) L 1 2500 487 회 L(1500)
L( 1500)
L 2 3000 487 회 L(1500)
L( 1500)
L 2 3000
R162 U0.5 2600 U0.5 3100 U 1 3100 U0.5 3100
R163
R164 Expr ess
R165 T i me T i me
R166 3.40 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃
R167 125( 가 ) 161(가 ) 10 5 5 20 90 30
R168 473 회 L ( 1500) L( 1500) L1. 5 2900
R169 U0.5 2800
R170
R171 Rin se
R172
R173
R174 125( 가 )
R175
R176
R177
R178 Mach ine C lean
R179 T i me
R180 3.30 ℓ 0 ℃ 0 ℃ 0 ℃
R181 125( 가 ) 159(가 ) 10 5 5 20 420
R182 459 회 L ( 1500) L( 1500) L 4 2000
R183 U 2 2200
R184 T 1 2600
R185 Spee d Mode
R186 for Rel iabi li ty Ti me T i me
R187 3.30 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃
R188 125( 가 ) 159(가 ) 10 5 5 20 120 60
R189 459 회 L ( 1500) L( 1500) L 1 2000
R190 U 1 3100
R191 T 1 2600
R192 Motor ( Washi ng)
R193 Motor ( Drain )
R194 Motor ( Vario)
R195 Motor ( Blower Fan)
R196 Heater (Sump)
R197 SolenoidValve (Inlet)
R198 Sole noid (Dis penser)
R199 Actu ator ( Bl ow er )
R200 Optical S ensor (Soil )
R201 Auto Res tart 시작 시 점
Same to Auto Strong
Same to Normal Strong
Same to Normal Strong

For Authorized Service TechniciansFor Authorized Service Technicians
- 19 -
C126 C 127
C128
C129
C130
C131
C132
C133
C134
C135
C136
C137
C138
C139
C140
C141
C142
C143
C144
C145
C146
C147
C148
C149 C150 C151 C 152 C153 C 154 C155 C156
C157
C158
C159
C160
C161
C162
C163
C164
C165
C166
C167
C168
C169
C170
C171
C172
C173
C174
C175
C176
C177
C178 C179 C180 C 181 C182 C 183 C184 C185
C186
C187
C188
C189
C190
C191
C192
C193
C194
C195
C196
C197
C198
C199
C200
C201
C202
C203
C204
C205
C206
C207
C208
C209
C210
C211 C 212 C213
C214
C215
C216
C217
C218
C219
C220
C221
C222
C223 C224 C225 C226 C 227 C228 C229 C230 C 231 C232 C 233 C234 C 235 C236 C 237 C238 C 239 C240 C 241 C242 C 243 C244 C 245 C246 C 247 C248 C249 C250 C 251 C252 C 253 C254 C 255
Was h
SumofUnit Time
Pr e Was h 3
Pr e Was h 4 Pr e Was h 5 Main Wash
Pr e Wa s h 3-2
Drai n
Water Supply
TempWash Pre Wash 4 Dr ai n
Water Supply
TempWash Pre Wash 5 Drai n Water Suppl y Filter Cleaning Drain
Water Supply
TempWash Main Wash 1
Bubble Detect
Main Wash 2 Main Wash 3
Bubble Detect
Main Wash 4 Main Wash 5
Defau l t Defau l t High
T e mp Energy Saver
Was h
Was h
St
op
Dra
in
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h Heatin g
Was h
Was h Was h
St
op
Dra
in
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h Heatin g
Was h
Was h Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h He ati ng
Was h
Bubble
Detect
Heati n g
Was h
Heati n g
Was h
Heati n g
Was h
Heati n g
Was h
Bubble
Detect
Was h He ati ng
Was h
Ti me
No
Wate r
Supply
C o mp
Time & Temp T i me No
Wate r
Supply
C o mp
Time & Temp T i me No
Wate r
Supply
C o mp
Ti me No
Wate r
Supply
C o mp
Time &Temp Time & Temp Time & Temp Sameto Default Same toDefault Ti me Ti me & Temp
0 ℃
0 ℃ 0 ℃ 0 ℃ 0 ℃ Wat er 0 ℃ 0 ℃ Te mp 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ Wa te r 0 ℃ 0 ℃ T e mp 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ Wa te r 0 ℃ Wa te r 0 ℃ 0 ℃ T e mp T e mp T e mp Default + 5℃ (Max 75℃) 43 ℃ 0 ℃ Te mp
20 272 10 272 10 272 10 215 215(가 ) 1(가) 10 5 5 20 20 272 10 272 10 272 10 215 215(가 ) 1(가) 10 5 5 20 20 272 10 210 272 10 210 272 10 210 215 215(가 ) 1(가) 1 2 10 215(가 ) 1(가) 10 5 5 20 5( 가 ) Same to Default S ame to Default Same to Default Same toDefault 5( 가 )
RPM L( 2100) L( 2400) L(2400) L(2400) Freq L ( 1500)
L( 1500)
Vario
Term RPM
Vario
Term RPM L ( 2100) L(2400) L(2400) L(2400) Freq L ( 1500)
L( 1500)
Vario
Term RPM
Vario
Term RPM L ( 2100) L(2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) Freq
Vario
Term RPM Freq L ( 1500)
L( 1500)
Vario
Term RPM T( 2700)
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM T( 2700)
Vario
Term RPM
Vario
Term RPM
Ti me
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.70 ℓ 0 ℃ 0 ℃ 47 ℃ 47 ℃ 50 ℃ 43 ℃
90
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 166(가 ) 10 5 5 20 960 5( 가 ) 420 960 420 420
L( 1600) L( 1600) L(1600) L ( 1600) L(1600) L( 1600) 515 회 L( 1500)
L( 1500)
L 5 3200 T( 2700) LT 3.5 2800 LT 52800 LT 3.5 2800 LT 3.5 2800
U 3 3100 U3.5 3100 U 3 3100 U3.5 3100 U3.5 3100
2800
Ti me
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.70 ℓ 0 ℃ 0 ℃ 47 ℃ 47 ℃ 50 ℃ 43 ℃
90
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 166(가 ) 10 5 5 20 660 5( 가 ) 315 660 315 315
L( 1600) L( 1600) L(1600) L ( 1600) L(1600) L( 1600) 515 회 L( 1500)
L( 1500)
L2.5 3200 T ( 2700) LT 1. 75 2800 LT 2. 5 2800 LT 1.75 2800 LT 1.75 2800
U 3 3100 U3.5 3100 U 3 3100 U3.5 3100 U3.5 3100
2800
Ti me
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.70 ℓ 0 ℃ 0 ℃ 47 ℃ 47 ℃ 50 ℃ 43 ℃
45
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 166(가 ) 10 5 5 20 780 5( 가 ) 315 780 315 315
L( 1600) L( 1600) L(1600) L ( 1600) L(1600) L( 1600) 515 회 L( 1500)
L( 1500)
L 5 3200 T( 2700) LT 3.5 2800 LT 52800 LT 3.5 2800 LT 3.5 2800
U1.5 3100 U1.75 3100 U1.5 3100 U1.75 3100 U1.75 3100
2800
Ti me Ti me T i me T i me
0 ℃ 3.60 ℓ 0 ℃ 0 ℃ 50 ℃ 50 ℃ 55 ℃ 43 ℃
272 10 215 215(가 ) 164(가 ) 10 5 5 20 840 5( 가 ) 1260 1260 1260
L( 2400) 501 회 L ( 1500)
L( 1500)
L 3 2300 T( 2700) L 3 2300 L 3 2300 L 3 2300
U 3 2200 U 3 2200 U 3 2200 U 3 2200
T 1 2500 T 1 2500 T 1 2500 T 1 2500
Ti me Ti me T i me T i me
0 ℃ 3.60 ℓ 0 ℃ 0 ℃ 50 ℃ 50 ℃ 55 ℃ 43 ℃
272 10 215 215(가 ) 164(가 ) 10 5 5 20 660 5( 가 ) 990 990 990
L( 2400) 501 회 L ( 1500)
L( 1500)
L1.5 2300 T ( 2700) L1.5 2300 L1.5 2300 L1.5 2300
U 3 2200 U 3 2200 U 3 2200 U 3 2200
T 1 2500 T 1 2500 T 1 2500 T 1 2500
Ti me Ti me T i me T i me
0 ℃ 3.60 ℓ 0 ℃ 0 ℃ 50 ℃ 50 ℃ 55 ℃ 43 ℃
272 10 215 215(가 ) 164(가 ) 10 5 5 20 600 5( 가 ) 900 900 900
L( 2400) 501 회 L ( 1500)
L( 1500)
L 3 2300 T( 2700) L 3 2300 L 3 2300 L 3 2300
U1.5 2200 U1.5 2200 U1.5 2200 U1. 5 2200
T0.5 2500 T0.5 2500 T0.5 2500 T0. 5 2500
Ti me T i me Time & Temp Ti me Ti me Ti me T i me Ti me & Temp
0 ℃ 000 3.30 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 45 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0.30 ℓ 0 ℃ 3. 60 ℓ 0 ℃ 0 ℃ 50 ℃ 62 ℃ 67 ℃ 68 ℃
20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 270 60 20 272 10 272 10 272 10 215 215( 가 ) 159( 가 ) 10 5 5 20 420 20 272 10 272 10 272 10 215 215(가) 16( 가 ) 24 210 215(가 ) 164(가 ) 10 5 5 20 900 5( 가 ) 900 900 1800
L( 2100) L(2400) L( 2400) L(2400) 459 회 L(1500)
L( 1500)
L3.5 2600 L( 2100) L( 2400) L(2400) L(2400) 459 회 L( 1500)
L( 1500)
LT 32700 L( 2100) L ( 2400) L( 2400) L( 2400) 42 회 L0. 4 2400 501 회 L(1500)
L( 1500)
L 5 2600 T( 2700) L 5 2600 L 5 2600 L 5 2600
U 1 2700 U 4 2800 U 2 3100 U 2 3100 U 2 3100 U 2 3100
T 1 2600 T0.5 2600 T0.5 2600 T0. 5 2600 T0.5 2600
Ti me T i me Time & Temp Ti me Ti me Ti me T i me Ti me & Temp
0 ℃ 000 3.30 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 45 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0.30 ℓ 0 ℃ 3. 60 ℓ 0 ℃ 0 ℃ 50 ℃ 62 ℃ 67 ℃ 68 ℃
20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 165 60 20 272 10 272 10 272 10 215 215( 가 ) 159( 가 ) 10 5 5 20 330 20 272 10 272 10 272 10 215 215(가) 16( 가 ) 24 210 215(가 ) 164(가 ) 10 5 5 20 600 5( 가 ) 600 600 1200
L( 2100) L(2400) L( 2400) L(2400) 459 회 L(1500)
L( 1500)
L1.75 2600 L( 2100) L(2400) L( 2400) L(2400) 459 회 L(1500)
L( 1500)
LT 1.5 2700 L( 2100) L( 2400) L( 2400) L( 2400) 42 회 L0.4 2400 501 회 L ( 1500)
L( 1500)
L2.5 2600 T ( 2700) L2.5 2600 L2.5 2600 L2.5 2600
U 1 2700 U 4 2800 U 2 3100 U 2 3100 U 2 3100 U 2 3100
T 1 2600 T0.5 2600 T0.5 2600 T0. 5 2600 T0.5 2600
Ti me T i me Time & Temp Ti me Ti me Ti me T i me Ti me & Temp
0 ℃ 000 3.30 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 45 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0.30 ℓ 0 ℃ 3. 60 ℓ 0 ℃ 0 ℃ 50 ℃ 62 ℃ 67 ℃ 68 ℃
20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 240 60 20 272 10 272 10 272 10 215 215( 가 ) 159( 가 ) 10 5 5 20 300 20 272 10 272 10 272 10 215 215(가) 16( 가 ) 24 210 215(가 ) 164(가 ) 10 5 5 20 750 5( 가 ) 750 750 1500
L( 2100) L(2400) L( 2400) L(2400) 459 회 L(1500)
L( 1500)
L3.5 2600 L( 2100) L( 2400) L(2400) L(2400) 459 회 L( 1500)
L( 1500)
LT 32700 L ( 2100) L( 2400) L( 2400) L( 2400) 42 회 L0.4 2400 501 회 L ( 1500)
L( 1500)
L 5 2600 T( 2700) L 5 2600 L 5 2600 L 5 2600
U0.5 2700 U 2 2800 U 1 3100 U 1 3100 U 1 3100 U 1 3100
T 1 2600 T0.25 2600 T0.25 2600 T0. 25 2600 T0.25 2600
Ti me Time& Te mp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 50 ℃ 50 ℃ 43 ℃
20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 660 5( 가 ) 960 960
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L( 1500)
L( 1500)
LT 22800 T( 2700)
U 7 2600 U 7 2600 U 7 2600
LT 22800 LT 22800
Ti me Time& Te mp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 50 ℃ 50 ℃ 43 ℃
20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 540 5( 가 ) 900 900
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L( 1500)
L( 1500)
LT 12800 T( 2700)
U 7 2600 U 7 2600 U 7 2600
LT 12800 LT 12800
Ti me Time& Te mp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 50 ℃ 50 ℃ 43 ℃
20 272 10 272 10 272 10 215 215(가 ) 159(가 ) 10 5 5 20 660 5( 가 ) 330 330
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L( 1500)
L( 1500)
LT 22800 T( 2700) LT 22800 LT 22800
U3.5 2600 U3.5 2600 U3.5 2600
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 60 ℃ 60 ℃ 65 ℃ 43 ℃
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 161(가 ) 10 5 5 20 840 5( 가 ) 1680 1680 1680
L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 473 회 L( 1500)
L( 1500)
LT 32800 T( 2700) LT 32800 LT 32800 LT 32800
U 4 2900 U 4 2900 U 4 2900 U 4 2900
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 60 ℃ 60 ℃ 65 ℃ 43 ℃
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 161(가 ) 10 5 5 20 660 5( 가 ) 1320 1320 1320
L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 473 회 L( 1500)
L( 1500)
LT 1.5 2800 T ( 2700) LT 1. 5 2800 LT 1. 5 2800 LT 1. 5 2800
U 4 2900 U 4 2900 U 4 2900 U 4 2900
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 60 ℃ 60 ℃ 65 ℃ 43 ℃
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 161(가 ) 10 5 5 20 600 5( 가 ) 1200 1200 1200
L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 473 회 L( 1500)
L( 1500)
LT 32800 T( 2700) LT 32800 LT 32800 LT 32800
U 2 2900 U 2 2900 U 2 2900 U 2 2900
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 35 ℃ 35 ℃ 40 ℃ 35 ℃
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 161(가 ) 10 5 5 20 840 5( 가 ) 1260 1260 1260
L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 473 회 L( 1500)
L( 1500)
LT 32800 T( 2700) LT 32800 LT 32800 LT 32800
U 4 2900 U 4 2900 U 4 2900 U 4 2900
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 35 ℃ 35 ℃ 40 ℃ 35 ℃
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 161(가 ) 10 5 5 20 660 5( 가 ) 990 990 990
L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 473 회 L( 1500)
L( 1500)
LT 1.5 2800 T ( 2700) LT 1. 5 2800 LT 1. 5 2800 LT 1. 5 2800
U 4 2900 U 4 2900 U 4 2900 U 4 2900
Ti me Time& Te mp Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 35 ℃ 35 ℃ 40 ℃ 35 ℃
2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 161(가 ) 10 5 5 20 600 5( 가 ) 900 900 900
L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 473 회 L( 1500)
L( 1500)
LT 32800 T( 2700) LT 32800 LT 32800 LT 32800
U 2 2900 U 2 2900 U 2 2900 U 2 2900
Ti me Time & Temp Time & Temp Time & Temp
33 ℃ 33 ℃ 38 ℃ 33 ℃
840 5(가 ) 1680 720 1680 720 1680 720
L 2 2000 T( 2700) L 2 2000 L 2 2000 L 2 2000 L 2 2000 L 2 2000 L 2 2000
U 4 2200 U 4 2000 U 4 2000 U 4 2000 U 4 2000 U 4 2000 U 4 2000
T 1 2300 T 1 2300 T 1 2300 T 1 2300
Ti me Time & Temp Time & Temp Time & Temp
33 ℃ 33 ℃ 38 ℃ 33 ℃
720 5(가 ) 1440 600 1440 600 1440 600
L 1 2000 T( 2700) L 1 2000 L 1 2000 L 1 2000 L 1 2000 L 1 2000 L 1 2000
U 4 2200 U 4 2000 U 4 2000 U 4 2000 U 4 2000 U 4 2000 U 4 2000
T 1 2300 T 1 2300 T 1 2300 T 1 2300
Ti me Time & Temp Time & Temp Time & Temp
33 ℃ 33 ℃ 38 ℃ 33 ℃
540 5(가 ) 1080 480 1080 480 1080 480
L 2 2000 T( 2700) L 2 2000 L 2 2000 L 2 2000 L 2 2000 L 2 2000 L 2 2000
U 2 2200 U 2 2000 U 2 2000 U 2 2000 U 2 2000 U 2 2000 U 2 2000
T0.5 2300 T0.5 2300 T0.5 2300 T0. 5 2300
Ti me T i me Ti me T i me Ti me
3.50 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 75 ℃ 75 ℃ 0 ℃
215 215(가 ) 162(가 ) 10 5 5 20 30 30 215 215(가 ) 162(가 ) 10 5 5 20 570 570 5(가) 30
487 회 L ( 1500)
L( 1500)
L0.5 3000 487 회 L ( 1500) L( 1500) LT 33100 LT 33100 T( 2700)
U0.5 3100 U 2 3200 U 2 3200 U0.5 3200
Ti me T i me Ti me
3.40 ℓ 0 ℃ 0 ℃ 75 ℃ 75 ℃ 0 ℃
215 215(가 ) 161(가 ) 10 5 5 20 330 330 5(가) 30
473 회 L ( 1500) L( 1500) LT 1.5 3200 LT 1.5 3200 T(2700)
U1.5 3200 U1.5 3200 U0.5 3200
Time & Temp Ti me
0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 50 ℃ 0 ℃
272 10 215 215(가 ) 153(가 ) 10 5 5 20 840 5(가 ) 60
L( 2400) 417 회 L ( 1500) L( 1500) L 4 2000 T(2700)
U 2 2200
T 1 2600 T 1 2600
Time & Temp Ti me
0 ℃ 3.60 ℓ 0 ℃ 0 ℃ 50 ℃ 0 ℃
272 10 215 215(가 ) 164(가 ) 10 5 5 20 360 5(가 ) 60
L( 2400) 501 회 L ( 1500) L( 1500) L 1 2800 T(2700)
U 1 3200
T 1 2600 T 1 2600
2초 2초 2초

For Authorized Service Technicians
- 20 -
C256 C 257 C258 C259 C260 C261
C262
C263
C264
C265
C266
C267
C268
C269
C270
C271
C272
C273
C274
C275
C276
C277
C278
C279
C280
C281
C282
C283
C284
C285
C286
C287
C288
C289 C290 C291 C 292 C293 C 294 C295 C 296 C297 C 298 C299 C 300 C301 C 302 C303 C 304 C305 C 306 C307
C308
C309
C310
C311
C312
C313
C314
C315
C316
C317 C318 C319 C 320 C321 C 322 C323 C 324 C325 C 326 C327 C 328 C329
C330
C331
C332
C333
C334
C335
C336
C337
C338
C339 C340 C341 C 342 C343 C 344 C345 C 346 C347 C 348 C349 C 350 C351 C 352
C353
C354
C355
C356
C357
C358
C359
C360
C361
C362
C363
C364
C365
C366
C367
C368
C369
C370
C371
C372
C373
C374
C375
C376
C377
SumofUnit Time Rinse
Rinse 1 Rinse 2 Rinse 3
HeatingRins e
Drai n
Water Supply
TempWash Rinse 1 Drai n
Water Supply
TempWash Rinse 2 Drai n
Water Supply
TempWash Rinse 3 Drai n
Water Supply
TempWash
Defau l t Hi g h T e mp Extra Dry Energy Saver Extra Dry
& Hi g h T e mp Defaul t Ener gy Saver Defa ul t Energy Saver Defau l t Energy Saver
ti me ti me t i me ti me t i me Wash
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h Hea ti ng
Was h
Was h Was h He ati ng
Was h
Was h Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h Hea ti ng
Was h
Was h He ati ng
Was h
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
Was h
St
op
Was h He ati ng
Was h
Was h He ati ng
Was h
Was h Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Was h
St
op
Was h
St
op
Dra
in
St
op
Drai n
Com
plete
St
op
Wate r
Supply
St
op
No
Wate r
Supply
C o mp
Time & Temp T i me T i me Same to Default Same to Default Same to Default No
Wate r
Supply
C o mp
Time & Temp T i me Same to Default Sameto Default No
Wate r
Supply
C o mp
Time & Temp T i me Same to Default Sameto Default No
Wate r
Supply
C o mp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ Wa te r 0 ℃ 0 ℃ Te mp 0 ℃ 0 ℃ Same to Default Same to Default Sameto Default Wat er 0 ℃ 0 ℃ T e mp 0 ℃ Same to Default Same to Default Wa te r 0 ℃ 0 ℃ T e mp 0 ℃ Same to Default Same to Default 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ Wat er
20 272 10 210 272 10 210 272 10 210 215 215(가 ) 1(가) 10 5 5 20 De faul t x 2 De fault x 2 De fault x 2 215 215( 가 ) 1(가) 10 5 5 20 De fault x 2 De fault x 2 215 215( 가 ) 1(가) 10 5 5 20 De fault x 2 De fault x 2 20 272 10 210 272 10 210 272 10 210 215 215(가 ) 1(가) 10
RPM
L( 2100) L(2400) L ( 2400) L(2400) L( 2400) L(2400) L( 2400) Freq L ( 1500)
L( 1500)
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM Freq L ( 1500)
L( 1500)
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM Freq L ( 1500)
L( 1500)
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM
Vario
Term RPM L ( 2100) L(2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) Freq
L( 1500)
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.70 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ
4084 5044 4084 4084 5044 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 166(가 ) 10 5 5 20 600 60 1200 120 215 215(가 ) 157(가 ) 10
L( 1600) L( 1600) L( 1600) L( 1600) L(1600) L( 1600) 515 회 L( 1500) L( 1500) LT 1. 5 2800 LT 1.5 2800 445 회
L( 1500)
U 1 3200 U 1 3200 U 1 3200 U 1 3200
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.70 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ
3319 3979 3319 3319 3979 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 166(가 ) 10 5 5 20 420 60 840 120 215 215(가 ) 157(가 ) 10
L( 1600) L( 1600) L( 1600) L( 1600) L(1600) L( 1600) 515 회 L( 1500) L( 1500) LT 0. 75 2800 LT 0.75 2800 445 회
L( 1500)
U 1 3200 U 1 3200 U 1 3200 U 1 3200
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.70 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ
3514 4294 3514 3514 4294 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 166(가 ) 10 5 5 20 480 30 960 60 215 215(가 ) 157(가 ) 10
L( 1600) L( 1600) L( 1600) L( 1600) L(1600) L( 1600) 515 회 L( 1500) L( 1500) LT 1. 5 2800 LT 1.5 2800 445 회
L( 1500)
U0.5 3200 U0. 5 3200 U0.5 3200 U0.5 3200
Ti me Ti me
0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ
2715 2715 2715 2715 2715 272 10 215 215(가 ) 162(가 ) 10 5 5 20 240 480 215 215(가 ) 157(가 ) 10
L( 2400) 487 회 L(1500) L( 1500) L 1 2300 L 1 2300 445 회
L( 1500)
U 2 2200 U 2 2200
T 1 2500 T 1 2500
Ti me Ti me
0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ
2175 2175 2175 2175 2175 272 10 215 215(가 ) 162(가 ) 10 5 5 20 210 420 215 215(가 ) 157(가 ) 10
L( 2400) 487 회 L(1500) L( 1500) L0.5 2300 L0.5 2300 445 회
L( 1500)
U 2 2200 U 2 2200
T 1 2500 T 1 2500
Ti me Ti me
0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ
2085 2085 2085 2085 2085 272 10 215 215(가 ) 162(가 ) 10 5 5 20 150 300 215 215(가 ) 157(가 ) 10
L( 2400) 487 회 L(1500) L( 1500) L 1 2300 L 1 2300 445 회
L( 1500)
U 1 2200 U 1 2200
T0.5 2500 T0.5 2500
Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3. 30 ℓ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
6049 6049 6049 6049 20 272 10 272 10 272 10 215 215(가 ) 159( 가 ) 10 5 5 20 720 215 215(가 ) 159(가 ) 10
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L(1500) L( 1500) LT 32800 459 회
L( 1500)
U 3 2900
Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3. 30 ℓ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
4534 4534 4534 4534 20 272 10 272 10 272 10 215 215(가 ) 159( 가 ) 10 5 5 20 540 215 215(가 ) 159(가 ) 10
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L(1500) L( 1500) LT 1.5 2800 459 회
L( 1500)
U 3 2900
Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3. 30 ℓ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
5209 5209 5209 5209 20 272 10 272 10 272 10 215 215(가 ) 159( 가 ) 10 5 5 20 540 215 215(가 ) 159(가 ) 10
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L(1500) L( 1500) LT 32800 459 회
L( 1500)
U1.5 2900
Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3. 30 ℓ 0 ℃ 0 ℃ 55 ℃ 55 ℃ 3.30 ℓ
2880 2880 2880 20 272 10 272 10 272 10 215 215(가 ) 159( 가 ) 10 5 5 20 360 720 215 215(가 ) 159(가 ) 10
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L(1500)
L( 1500)
LT 32800 LT 32800 459 회
L( 1500)
U 3 2600 U 3 2600
Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3. 30 ℓ 0 ℃ 0 ℃ 55 ℃ 55 ℃ 3.30 ℓ
2580 2580 2580 20 272 10 272 10 272 10 215 215(가 ) 159( 가 ) 10 5 5 20 270 540 215 215(가 ) 159(가 ) 10
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L(1500)
L( 1500)
LT 1.5 2800 LT 1.5 2800 459 회
L( 1500)
U 3 2600 U 3 2600
Time & Temp Time & Temp
0 ℃ 0 ℃ 0 ℃ 0 ℃ 3. 30 ℓ 0 ℃ 0 ℃ 55 ℃ 55 ℃ 3.30 ℓ
2145 2145 2145 20 272 10 272 10 272 10 215 215(가 ) 159( 가 ) 10 5 5 20 270 540 215 215(가 ) 159(가 ) 10
L( 2100) L( 2400) L ( 2400) L ( 2400) 459 회 L(1500)
L( 1500)
LT 32800 LT 32800 459 회
L( 1500)
U1.5 2600 U1.5 2600
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
4622 4622 4622 4622 4622 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 159(가 ) 10 5 5 20 720 1440 215 215(가) 159(가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 459 회 L( 1500) L( 1500) LT 32800 LT 32800 459 회
L( 1500)
U 3 2900 U 3 2900
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
3782 3782 3782 3782 3782 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 159(가 ) 10 5 5 20 540 1080 215 215(가) 159(가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 459 회 L( 1500) L( 1500) LT 1. 5 2800 LT 1.5 2800 459 회
L( 1500)
U 3 2900 U 3 2900
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
3632 3632 3632 3632 3632 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 159(가 ) 10 5 5 20 540 1080 215 215(가) 159(가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 459 회 L( 1500) L( 1500) LT 32800 LT 32800 459 회
L( 1500)
U1.5 2900 U1.5 2900
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
2959 2959 2959 2959 2959 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 159(가 ) 10 5 5 20 360 720 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 159( 가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 459 회 L( 1500) L( 1500) LT 32800 LT 32800 L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 459 회
L( 1500)
U 3 2900 U 3 2900
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
2389 2389 2389 2389 2389 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 159(가 ) 10 5 5 20 270 540 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 159( 가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 459 회 L( 1500) L( 1500) LT 1. 5 2800 LT 1.5 2800 L( 2400) L( 2400) L(2400) L( 2400) L( 2400) L( 2400) 459 회
L( 1500)
U 3 2900 U 3 2900
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.30 ℓ
2299 2299 2299 2299 2299 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 159(가 ) 10 5 5 20 270 540 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 159( 가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 459 회 L( 1500) L( 1500) LT 32800 LT 32800 L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 459 회
L( 1500)
U1.5 2900 U1.5 2900
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ
3882 3882 3882 3882 3882 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 153(가 ) 10 5 5 20 720 1440 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 153( 가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 417 회 L( 1500) L( 1500) L 2 2000 L 2 2000 L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 417 회
L( 1500)
U 3 2100 U 3 2100
T 1 2300 T 1 2300
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ
3282 3282 3282 3282 3282 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 153(가 ) 10 5 5 20 600 1200 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 153( 가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 417 회 L( 1500) L( 1500) L 1 2000 L 1 2000 L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 417 회
L( 1500)
U 3 2100 U 3 2100
T 1 2300 T 1 2300
Ti me Ti me
0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ
2682 2682 2682 2682 2682 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가 ) 153(가 ) 10 5 5 20 480 960 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 7 2 15 215(가) 153( 가 ) 10
L( 2400) L( 2400) L( 2400) L( 2400) L(2400) L( 2400) 417 회 L( 1500) L( 1500) L 2 2000 L 2 2000 L( 2400) L( 2400) L(2400) L ( 2400) L(2400) L( 2400) 417 회
L( 1500)
U1.5 2100 U1.5 2100
T0.5 2300 T0.5 2300
Ti me T i me Ti me T i me
3.40 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3.40 ℓ
1789 1789 1789 1789 215 215(가 ) 161(가 ) 10 5 5 20 120 30 215 215(가 ) 161(가 ) 10 5 5 20 330 30 215 215( 가 ) 161(가 ) 10
473 회 L ( 1500)
L( 1500)
LT 0.5 3100 473 회 L ( 1500)
L( 1500)
LT 0.5 3100 473 회
L( 1500)
U1.5 3200 U0. 5 3200 U2.5 3200 U0. 5 3200
Ti me T i me Ti me T i me T i me T i me
3.40 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3.40 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3. 40 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3.40 ℓ
749 749 749 749 215 215( 가 ) 161(가 ) 10 5 5 20 90 30 215 215(가 ) 161(가 ) 10 5 5 20 90 30 215 215(가 ) 161(가 ) 10 5 5 20 90 30 215 215(가 ) 161(가 ) 10
473 회 L ( 1500)
L( 1500)
LT 1.5 3200 473 회 L ( 1500)
L( 1500)
LT 1.5 3200 473 회 L( 1500)
L( 1500)
LT 13200 473 회
L( 1500)
U0.5 3200 U0.5 3200 U0. 5 3200 U0. 5 3200
Ti me Ti me
3.60 ℓ 0 ℃ 0 ℃ 0 ℃ 3.20 ℓ 0 ℃ 0 ℃ 0 ℃
26 164(가 ) 10 5 5 20 180 215 215(가) 157(가 ) 10 5 5 20 180
501 회 L ( 1500) L( 1500) L1.5 2300 445 회 L ( 1500) L( 1500) L1.5 2300
U 1 2100 U 1 2200
T0.5 2600 T0.5 2900
Ti me
0 ℃ 3.00 ℓ 0 ℃ 0 ℃ 0 ℃ 3.00 ℓ
1600 272 10 215 215(가 ) 153(가 ) 10 5 5 20 420 215 215(가) 153( 가 ) 10
L( 2400) 417 회 L(1500) L( 1500) L 4 2000 417 회
L( 1500)
U 2 2200
T 1 2600
Ti me T i me
0 ℃ 3.50 ℓ 0 ℃ 0 ℃ 75 ℃ 0 ℃ 3.50 ℓ
891 272 10 215 215(가 ) 162(가 ) 10 5 5 20 120 60 215 215(가 ) 162(가 ) 10
L( 2400) 487 회 L(1500)
L( 1500)
L 1 2800 487 회
L( 1500)
U 1 3200
T 1 2600
