LG DLEC733W User manual

COMBO TRAINING
DLEC733W
Condensing Dryer
DLEC733W

Introduction
DLEC733W p5

Specifications
DLEC733W p5

Accessories
DLEC733W p6

Installation
DLEC733W p7

Installation
DLEC733W p7

Installation
DLEC733W p8

Installation
DLEC733W p8

Installation
DLEC733W p8

Wiring Diagram
DLEC733W p14

To enter the QC Test Mode, press the Power button while holding the
Buzzer and Wrinkle Care buttons. After entering the QC Test Mode, step
through the tests below by pressing the Start/Pause button.
End QC Test mode9
No ELB (Earth Leakage Breaker)
Motor off, Buzzer on8
Moisture data (Normal: 221) by
semiconductor moisture sensor.
Motor off7
Moisture data (Normal: 230-245).
(For moisture sensor check on production
line by opening door with door switch
pressed.)
Motor on (CW)6
Moisture data (Normal: 230-245)Pump on, Motor off5
Temperature at high temp
thermistor located in heater
Motor on (CW)
both heating coils on
4
Temperature at the low temp
thermistor under the door
Motor on (CW)
1750W heater on
3
Moisture data (Normal: 230-245)
Motor on (CW), Humidity data2
Moisture data (Normal: 230-245)
Motor on (CCW), Humidity data1
Programming checksumLEDs0
DisplayCheckpoint
Start/Pause
___ times
Note: This information was verified on an early production dryer. The sequence of operations may
vary on the particular dryer being serviced.
Test Mode
DLEC733W p13

Operation Programming
DLEC733W p11

Operation Programming
DLEC733W p11
/ Anti-Crease

Operation Programming
DLEC733W p11

Operation Programming
DLEC733W p12

Dryer Drum
Cool
F
I
L
T
E
R
H
E
A
T
E
R
COND
MTR
Drying Cycle
DLEC733W

Clean Lint Filter
A clean lint filter reduces drying, reduces energy
consumption, and lengthens the dryer’s life.
The filter can be cleaned by vacuuming or by rinsing with
water.
Note: If the Clean Filter indicator flashes during operation,
clean the filter promptly. (Allow the dryer to cool for a few
minutes to prevent injury from burning.)
Empty Water Container
If the dryer has not been installed with the optional drain
kit attached, the condensed water container should be
emptied after every use.
If the Empty Water warning lights and a buzzer sounds
while the dryer is operating, the container is full and must
be emptied within one hour.
Owner’s Maintenance
DLEC733W

Condenser
The condenser plays a very important role in the dryer’s
efficient operation. It is recommended that it be cleaned
three or four times a year.
Open the condenser's cover by depressing the latching
tab with a coin, a key, or a screwdriver.
Turn the locking levers and remove the sealing cover.
Turn two more locking levers and remove the condenser
by pulling the finger hole tab on the front of the
condenser.
Clean the condenser thoroughly by running water
through the openings, from front to back and from side
to side.
Owner’s Maintenance
DLEC733W

Front Ventilation Grille
The dryer uses room temperature air to condense
moisture from the warmer air in the dryer. It is
important that dust does not accumulate around the
vents in the front grille to restrict the air flow.
Vacuum the front grille three or four times a year to
prevent dust accumulation.
Moisture Sensor
Two strips of metal just below the door, inside the
dryer, sense the moisture content of the laundry.
These can develop a coating from minerals in the
customer’s water supply, from dryer sheets (which
are not recommended for use), or simply from
oxidation over an extended period of time. Any
coating on the strips will affect the sensor’s ability to
accurately sense the moisture within the laundry. The
sensor strips should be wiped clean frequently.
Owner’s Maintenance
DLEC733W

Wiring Diagram
DLEC733W p14
