LG DLEY1201 User manual

L A UNDR Y
DLEY1201
Ultra Large Capacity Steam Dryer
with Front Control Design
DLEY1201
Performance
• 7.3 cu.ft. Ultra Large Capacity with
Alluminized Alloy Steel Drum
Technology Benefits
• LoDecibel Quiet Operation
™
Style and Design
• Front Electronic Control Panel
with LED Display
• Chrome Edged Diamond Glass Door
ELECTRIC DRYERS
Graphite Steel
Intelligent Fabric Care
• Sensor Dry System for Intelligent Fabric Care
and Energy Efficiency
• FlowSense Duct Clogging Indicator
™
• 12 Drying Programs
• 4 Temperature Settings
• 3 Minute Installation Check
• Wrinkle Care Option
• Delicates Cycle
• Custom Program
• Anti-Bacterial Cycle
• Damp Dry Signal
• SmartDiagnosis™
• Steam Technology
• WrinkleFree Cycle
™
• SteamFresh Cycle
™

Call, Connect, Resolve
SmartDiagnosis uses self-diagnosing technology that
can communicate 24/7 with LG customer service over
the telephone providing you with comfort and reliability.
™
Dry Big Loads
Accurately dry big and bulky loads with 7.3 cu.ft.
ultra large capacity. Less time in laundry room, more
time for life.
Accurate Drying
Our Sensor Dry system measures the moisture levels
during the cycle and automatically adjusts the drying
time, assuring you get dry laundry every time.
Keep it Quiet
There’s no need for laundry to be noisy. Thanks to
LG's LoDecibel operation, chances are you’ll never
even notice it.
™
Pressed For Time
With the wrinkle care cycle just pop your dry clothes
in for a tumble on the wrinkle care cycle to reduce
creases.
The Refreshing Power of Steam
Save time, and effort by using the power of steam to
remove wrinkles, odours, and static in just minutes.
LG ELECTRONICS CANADA INC.
20 Norelco Drive, North York, Ontario, M9L 2X6
Customer Service & Parts
Tel: [phone] LG.com
1-888-542-2623
ELECTRIC DRYERS
DLEY1201
TYPE
Front Loader
Design Look Front Control
Front Electronic Control Panel with LED Display
DRYING PROGRAMS
12 Programs Sensor Dry: Cotton/Normal, Perm. Press/Casual,
Heavy Duty, Bulky Bedding, Delicates,
Anti-bacterial, Towels, Small Load,
SteamFresh , WrinkleFree
Manual Dry: Speed Dry, Air Dry
™™
FABRIC CARE FEATURES
Sensor Dry
™
SteamFresh Cycle
7 Options More Time, Less Time, Custom Program,
Damp Dry Signal, Wrinkle Care,
Child Lock, End of Cycle Signal
High, Medium High, Medium, Low4 Temperature Settings
Very Dry, More Dry, Normal Dry,
Less Dry, Damp Dry
5 Drying Levels
Dry Times 60 min., 50 min., 40 min., 30 min.,
20 min., More Time/Less Time
.tf.uc3.7Capacity
gk1.01>Dry Linen Capacity
CONVENIENCE FEATURES
SmartDiagnosis™
FlowSense Duct Clogging Indicator
™
End of Cycle Signal
Child Lock
Remaining Time Display/Status Indicator(s)
Wrinkle Care Option
Anti-Bacterial Cycle
Drum Light
3 Minute Installation Check
Reversible Door
Venting Option
Leveling Legs 4 Adjustable Legs
LoDecibel™Quiet Operation
POWER SOURCE
MATERIALS AND FINISHES
Aluminized Alloy Steel Drum
Painted SteelCabinet
PlasticControl Panel
PlasticTop Plate
Transparent Glass Door
Door Rim
Graphite Steel (V)Available Colours
Chrome
4 Way Venting
DIMENSIONS
27" x 40 3/16" x 28 15/16"Product (WxHxD) (50 1/4" D with door open)
29 1/2" x 43" x 31 1/4"Carton (WxHxD)
121.7 lbs/139.6 lbsWeight (Product/Carton)
UPC CODES
WARRANTY
Design, features and specifications are subject to change without notice.
Non-metric weights and measurements are approximate.
All trademarks are property of their respective owners.
1 year parts and labour
908060454277DLEY1201V
Ratings / Electrical Requirements UL Listed / 240V, 30 Amps
ElectricType
Printed in January 2013
Take Control of Your Laundry
The first of its kind. The controls are located up front
for convenient easy access.
WrinkleFree Cycle
™
