LG Therma V 5BPM5-01B Product guide

Air-to-Water Heat Pump / Monobloc
R32 / 50Hz
5BPM5-01B(Replaces 5BPM5-01A)
P/No. : MFL66101126

THERMA V
Monobloc Type
General Information
Product Data
Design and installation

General Information
THERMA V
Monobloc Type
1.Model Line Up
2.Nomenclature

2
THERMA V Monobloc Type General Information
1. Model line up
Model line up
External appearance
Category Capacity (kW) Chassis Model Name
1 Phase Model
1 Ø, 220-240 V, 50 Hz
5.5
UN36A
ZHBW056A1 [HM051MR U44]
7.0 ZHBW076A1 [HM071MR U44]
9.0 ZHBW096A1 [HM091MR U44]
12.0
UN60A
ZHBW126A1 [HM121MR U34]
14.0 ZHBW146A1 [HM141MR U34]
16.0 ZHBW166A1 [HM161MR U34]
3 Phase Model
3 Ø, 380-415 V, 50 Hz
12.0 ZHBW128A1 [HM123MR U34]
14.0 ZHBW148A1 [HM143MR U34]
16.0 ZHBW168A1 [HM163MR U34]
UN36A UN60A

3
THERMA V Monobloc Type General Information
2. Nomenclature
■Factory Model Name
Model
Name ZH B W 12 6 A 1
No.1234567
No. Signification
1ZH : Air-to-Water Heat Pump for R32
2Classification
B : Monobloc
3Model Type
W : Inverter Heat Pump
4Heating Capacity (kW)
Ex) 5 kW : ‘05’, 16 kW : '16'
5
Electrical ratings
6 : 1 Ø, 220-240 V, 50 Hz
8 : 3 Ø, 380-415 V, 50 Hz
6Function
A : General Heating Heat pump
7Series

THERMA V Monobloc Type
2. Nomenclature
4
General Information
■Buyer Model Name
Model
Name HM121MRU34
No.12345678
No. Signification
1H : Air-to-Water Heat Pump
2Classification
M : Monobloc type
3Heating Capacity (kW)
Ex) 5 kW : ‘05’, 16 kW : '16'
4
Electrical ratings
1 : 1 Ø, 220-240 V, 50 Hz
3 : 3 Ø, 380-415 V, 50 Hz
5Leaving Water Combination
M : Mid Temperature
6
Type of refrigerant
A : R410A
R : R32
7
Platform (Chassis code)
U3 : UN60A Chassis
U4 : UN36A Chassis
8Series

Product Data
THERMA V
Monobloc Type
1.List of Functions
2.Specification
3.Dimensions
4.Piping Diagrams
5.Wiring Diagrams
6.Performance Data
7.Electric Characteristics
8.Operation Range
9.Sound levels
10.Hydraulic Performance

2
THERMA V Monobloc Type Product Data
1. List of Functions
■Basic functions of Unit
Water Side
Note
1. O : Applied, X : Not applied
Accessory : Ordered and purchased separately the accessory package referring to the model name provided and install at field.
Accessory line-ups varies by region, so check your local catalogue or local sales material.
2. * : This function requires the 3rd party accessory, PT-1000 sensor. (field supply)
Category Functions
ZHBW056A1 [HM051MR U44] ZHBW076A1 [HM071MR U44]
ZHBW096A1 [HM091MR U44] ZHBW126A1 [HM121MR U34]
ZHBW146A1 [HM141MR U34] ZHBW166A1 [HM161MR U34]
ZHBW128A1 [HM123MR U34] ZHBW148A1 [HM143MR U34]
ZHBW168A1 [HM163MR U34]
Installation Backup heater (Install kit) O (Accessory)
Reliability Self diagnosis O
Convenience
Auto Restart O
Child lock O
Sleep mode O
Timer (on/off) O
Timer (weekly) O
Two thermistor control X
Network function Network solution(LGAP) O
Modbus connectivity (without gateway) O
Air to Water Heat
Pump Functions
Anti-condensation on floor (cooling) O
Digital output for external pump O
Current flow rate monitoring O
Thermostat interface (230V AC) O
Thermostat interface (24V AC) X
Solar thermal system* O (Accessory)
DHW(Domestic Hot Water) tank installation
kit O (Accessory)
PHEX anti-freezing control O
Water pump anti-stuck function O
Weather compensation for heating and
cooling (Auto mode) O
Low noise operation O
Anti-overheating of water pipe O
Emergency operation O
Weather Dependent Operation with
Thermostat O
Scheduler (DHW Tank Heater) O
Timer (Domestic Hot Water Tank Heater) O
Quick Domestic Hot Water Tank Heating O
Screed Drying Mode O
Sump Heater O
Base Pan Heater O
Integrated Dry Contact (CN-EXT) O
Water flow control O
Water pressure monitoring O
Digital input for energy saving (ESS) O
Energy Monitoring O
DHW Recirculation O

1. List of Functions
3
THERMA V Monobloc Type Product Data
Refrigerant Side
Note
1. O : Applied, X : Not applied
Accessory : Ordered and purchased separately the accessory package referring to the model name provided and install at field.
Accessory line-ups varies by region, so check your local catalogue or local sales material.
2. * : This function requires the 3rd party accessory, PT-1000 sensor. (field supply)
Category Functions
ZHBW056A1 [HM051MR U44]
ZHBW076A1 [HM071MR U44]
ZHBW096A1 [HM091MR U44]
ZHBW126A1 [HM121MR U34]
ZHBW146A1 [HM141MR U34]
ZHBW166A1 [HM161MR U34]
ZHBW128A1 [HM123MR U34]
ZHBW148A1 [HM143MR U34]
ZHBW168A1 [HM163MR U34]
Reliability
Defrost / Deicing O O
High pressure switch O O
Low pressure switch X X
Phase protection X O
Restart delay (3-minutes) O O
Self diagnosis O O
Soft start X X
Convenience
Test function X X
Low Noise Operation O O
Wiring Error Check X X
Peak Control O O
Mode Lock O O
Forced Cooling Operation (Outdoor Unit) X X
Base Pan Heater O O
SLC(Smart Load Control) X X
Network function Network solution(LGAP) O O

THERMA V Monobloc Type
1. List of Functions
4
Product Data
■Accessory Compatibility List
Category Product Remark
ZHBW056A1 [HM051MR U44]
ZHBW076A1 [HM071MR U44]
ZHBW096A1 [HM091MR U44]
ZHBW126A1 [HM121MR U34]
ZHBW146A1 [HM141MR U34]
ZHBW166A1 [HM161MR U34]
ZHBW128A1 [HM123MR U34]
ZHBW148A1 [HM143MR U34]
ZHBW168A1 [HM163MR U34]
Wired
Remote
Controller
Standard PREMTW101 New standard (White) O
Dry Contact
Simple Contact PDRYCB000 Simple Dry Contact O
Communication Type
PDRYCB400 2 Points Dry Contact (For Setback) X
PDRYCB320 For 3rd party Thermostat O
PDRYCB500 Dry Contact for Modbus X
ETC
Remote temperature
sensor PQRSTA0 - O
Group control wire PZCWRCG3 0.25 m X
2-Remo Control Wire PZCWRC2 0.25 m O
Extension wire PZCWRC1 10 m O
Wi-Fi controller * PWFMDD200 USB Cable : 0.6 m Extension cable :
0.5 m O
Meter Interface*** PENKTH000 Interface between IDU and Meter O
2 Zone Valve
Controller PZNVVB200 - X
Accessory
Kit for
AWHP
DHW tanks (Single
coil)
OSHW-200F 200 L O
OSHW-300F 300 L O
OSHW-500F 500 L O
DHW tanks (Double
coil) OSHW-300FD 300 L O
DHW tank kit
PHLTA For Split 1Φ X
PHLTB For Monobloc O
PHLTC For Split 3Φ X
DHW sensor PHRSTA0 included in DHW Tank kit O
Thermostatic mixing
valve
OSHA-MV 3/4" DN20 O
OSHA-MV1 1" DN25 O
Backup heater
AHEH036A [HA031M E1] 220-240 V, 1Φ (For Monobloc) O
AHEH066A [HA061M E1] 220-240 V, 1Φ (For Monobloc) O
AHEH068A [HA063M E1] 380-415 V, 3Φ (For Monobloc) O
AHEH066B [HA061B E1] 220-240 V, 1Φ (For Hydrosplit
HN1600MB NK0) X
AHEH068B [HA063B E1] 380-415 V, 3Φ (For Hydrosplit
HN1600MB NK0) X
AHEH066C [HA061C E1] 220-240 V, 1Φ (For Hydrosplit
HN1600MC NK1) X
AHEH068C [HA063C E1] 380-415 V, 3Φ (For Hydrosplit
HN1600MC NK1) X
3way valve OSHA-3V - O
Solar thermal kit PHLLA - X
2nd Circuit or
E/Heater Thermistor PRSTAT5K10 - O
Drain pan PHDPB - X
PHDPC - X
Cover plate PDC-HK10 For K1 Chassis only X
Buffer Tank (40ℓ)OSHB-40KT For IWT(integrable) X
DHW expansion
vessel (8ℓ)OSHE-12KT For IWT(integrable) X
Note
1. O: Possible, X: Impossible, - : Not applicable
2. * : Some advanced functions controlled by individual controller cannot be operated.
3. ** : ACP or AC Smart is needed.
4. *** Meter interface cannot be connected at the same time with 3rd-party controller.
5. If you need more detail, please refer to the manual of product.
(http://partner.lge.com/global : Home> Doc.Library> Product > Control(BECON))

1. List of Functions
5
THERMA V Monobloc Type Product Data
Central
Controller
AC EZ PQCSZ250S0 AC EZ X
AC Ez Touch PACEZA000 AC Ez Touch O
AC Smart PACS4B000 AC Smart IV O
PACS5A000 AC Smart 5 O
ACP PACP4B000 ACP IV O
PACP5A000 ACP 5 O
AC Manager ** PACM4B000 AC Manager IV O
PACM5A000 AC Manager 5 O
Gateway
IDU PI485 PHNFP14A0 Without case X
PSNFP14A0 With case X
ODU PI485 PMNFP14A1 PI 485 Gateway O
BACnet PQNFB17C0 ACP BACnet O
Lonworks PLNWKB000 ACP Lonworks O
Modbus PMBUSB00A - O
ETC PDI PPWRDB000 PDI Standard O PQNUD1S40 PDI Premium O
ACS IO Module PEXPMB000 - X
Category Product Remark
ZHBW056A1 [HM051MR U44]
ZHBW076A1 [HM071MR U44]
ZHBW096A1 [HM091MR U44]
ZHBW126A1 [HM121MR U34]
ZHBW146A1 [HM141MR U34]
ZHBW166A1 [HM161MR U34]
ZHBW128A1 [HM123MR U34]
ZHBW148A1 [HM143MR U34]
ZHBW168A1 [HM163MR U34]
Note
1. O: Possible, X: Impossible, - : Not applicable
2. * : Some advanced functions controlled by individual controller cannot be operated.
3. ** : ACP or AC Smart is needed.
4. *** Meter interface cannot be connected at the same time with 3rd-party controller.
5. If you need more detail, please refer to the manual of product.
(http://partner.lge.com/global : Home> Doc.Library> Product > Control(BECON))

6
THERMA V Monobloc Type Product Data
2. Specification
■1 phase Inverter (5.5 ~ 9 kW)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound power level is measured on the rated condition in the accordance with ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
Rated sound power level is according to the EN12102-1 under conditions of the EN14825
4. Performances are accordance with EN14511 and reflect ErP testing conditions. Above gives the declared values at rated conditions acc. ErP regulation.
For max. capacities, refer to Performance Data.
• Rated running current : Outdoor Temp. 7°CDB / 6°CWB, LWT 35℃
5. This product contains Fluorinated greenhouse gases.
* : This values are accordance with EN14825.
Nominal Capacity and Nominal Input
ZHBW056A1
[HM051MR U44]
ZHBW076A1
[HM071MR U44]
ZHBW096A1
[HM091MR U44]
--
Outdoor
Temp. (°C)
DB / WB
Leaving Water
Temp. (°C) -
Capacity
Cooling 35 / 24 18 kW 5.50 7.00 9.00
7 kW 5.50 7.00 9.00
Heating 7 / 6 35 kW 5.50 7.00 9.00 55 kW 5.50 5.50 5.50
2 / 1 35 kW 4.40 5.60 6.80
Power Input
Cooling 35 / 24 18 kW 1.17 1.56 2.14
7 kW 1.67 2.19 2.90
Heating 7 / 6 35 kW 1.17 1.49 1.96
55 kW 2.04 2.04 2.04
2 / 1 35 kW 1.22 1.58 1.94
EER Cooling 35 / 24 18 W/W 4.70 4.50 4.20
7 W/W 3.30 3.20 3.10
COP Heating 7 / 6 35 W/W 4.70 4.70 4.60 55 W/W 2.70 2.70 2.70
2 / 1 35 W/W 3.60 3.55 3.50
SCOP (Low temp. Average Climate)* 4.46 4.48 4.55
SCOP (Medium temp. Average Climate)* 3.20 3.20 3.20
Rated Water Flow Rate (at LWT 35 ºC) LPM 15.8 20.1 25.9
Electrical Specifications ZHBW056A1
[HM051MR U44]
ZHBW076A1
[HM071MR U44]
ZHBW096A1
[HM091MR U44]
Power Supply V, Ø, Hz 220-240, 1, 50 220-240, 1, 50 220-240, 1, 50
Peak Control Running Current A 13.0 14.0 15.0
Rated Running Current Cooling A 5.2 6.9 9.5
Heating A 5.2 6.6 8.7
Circuit breaker A 16 20 25
Wiring Connections Power Supply Cable
(included Earth, H07RN-F)
mm² x
cores 4.0 x 3C 4.0 x 3C 4.0 x 3C
Technical Specifications ZHBW056A1
[HM051MR U44]
ZHBW076A1
[HM071MR U44]
ZHBW096A1
[HM091MR U44]
Sound Power Level Heating
Day Max. dB(A) 63 64 64
Rated dB(A) 57 57 57
Low noise dB(A) 54 55 55
Dimensions Unit W × H × D mm 1,239 × 834 × 330 1,239 × 834 × 330 1,239 × 834 × 330
Packed Unit W × H × D mm 1,364 × 985 × 461 1,364 × 985 × 461 1,364 × 985 × 461
Weight Unit kg 89.0 89.0 89.0
Packed Unit kg 100.0 100.0 100.0
Exterior Color - Warm Gray Warm Gray Warm Gray
RAL Code - RAL 7044 RAL 7044 RAL 7044

2. Specification
7
THERMA V Monobloc Type Product Data
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound power level is measured on the rated condition in the accordance with ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
Rated sound power level is according to the EN12102-1 under conditions of the EN14825
4. Performances are accordance with EN14511 and reflect ErP testing conditions. Above gives the declared values at rated conditions acc. ErP regulation.
For max. capacities, refer to Performance Data.
• Rated running current : Outdoor Temp. 7°CDB / 6°CWB, LWT 35℃
5. This product contains Fluorinated greenhouse gases.
* DHW 58~80℃ Operating is available only when the booster heater is operating.
Technical Specifications (Water side) ZHBW056A1
[HM051MR U44]]
ZHBW076A1
[HM071MR U44]
ZHBW096A1
[HM091MR U44]
Operation Range
(Leaving Water Temp.)
Cooling Min. ~ Max. °C 5 ~ 27 5 ~ 27 5 ~ 27
Heating Min. ~ Max. °C 15 ~ 65 15 ~ 65 15 ~ 65
DHW * Min. ~ Max. °C 15 ~ 80 15 ~ 80 15 ~ 80
Water Pump
Type - Canned type for hot water circulation
Model - UPM3K 20-75 CHBL
Motor Type - BLDC
Steps of Pumping Performance - Variable speed 10% to 100%
Power input Min. / Rated W 3 / 60 3 / 60 3 / 60
Water Flow Rate Min. / Rated ℓ/min 2.3 / 25.9 2.3 / 25.9 2.3 / 25.9
Heat Exchanger
Type - Brazed Plate HEX
Quantity - 1 1 1
Number of Plate EA 52 52 52
Water Volume ℓ0.7 0.7 0.7
Water Flow Rate Min. / Rated ℓ/min 13 ~ 70 13 ~ 70 13 ~ 70
Expansion Vessel
Volume Max. ℓ888
Water pressure Max. bar 3 3 3
Pre-charged bar 1 1 1
Flow Sensor
Model SIKA VVXC9SNBUC00252P
Measuring range Min. ~ Max. ℓ/min 5~80 5~80 5~80
Flow (Trigger
point) Min. ℓ/min 777
Water Pressure sensor Model Sensata OFM(2HMP)
Measuring range Min. ~ Max. bar(G) 0~20 0~20 0~20
Piping Connections Inlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Outlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Strainer
Mesh size - 30 mesh 30 mesh 30 mesh
Max. particle size mm 0.6 0.6 0.6
Material - Stainless Steel
Relief Valve Pressure Limit Upper Limit bar 3.0 3.0 3.0
Devices for Water Circuit
- Relief valve / Flow Sensor
-Drain hose
- Pressure Sensor / Air vent
Technical Specifications (Refrigerant side) ZHBW056A1
[HM051MR U44]
ZHBW076A1
[HM071MR U44]
ZHBW096A1
[HM091MR U44]
Operation Range
(Outdoor Temp.)
Cooling Min. ~ Max. °C DB 5 ~ 48 5 ~ 48 5 ~ 48
Heating Min. ~ Max. °C DB -25 ~ 35 -25 ~ 35 -25 ~ 35
Compressor
Type - Hermetic Sealed Scroll
Model Model × No. RJB036MAA × 1
Motor Type - BLDC
Displacement cm³/Rev. 31.6 31.6 31.6
Refrigerant
Type - R32 R32 R32
GWP
(Global Warming Potential) - 675.0 675.0 675.0
Precharged Amount g 1,400 1,400 1,400
t-CO2 eq. - 0.945 0.945 0.945
Control - Electronic Expansion Valve
Refrigerant Oil Type - FW68D
Charged Volume cc × No. 1,100 1,100 1,100
Heat Exchanger
Type Fin & Tube Fin & Tube Fin & Tube
Quantity 1 1 1
Specification
Row EA 38 38 38
Column EA 2 2 2
FPI EA 18 18 18
Fan Type - Propeller
Air Flow Rate Rated m³/min × No. 60.0 × 1 60.0 × 1 60.0 × 1
Fan Motor Type - BLDC
Output W × No. 124 × 1 124 × 1 124 × 1

THERMA V Monobloc Type
2. Specification
8
Product Data
■1 phase Inverter (12 ~ 16 kW)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound power level is measured on the rated condition in the accordance with ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
Rated sound power level is according to the EN12102-1 under conditions of the EN14825
4. Performances are accordance with EN14511 and reflect ErP testing conditions. Above gives the declared values at rated conditions acc. ErP regulation.
For max. capacities, refer to Performance Data.
• Rated running current : Outdoor Temp. 7°CDB / 6°CWB, LWT 35℃
5. This product contains Fluorinated greenhouse gases.
* : This values are accordance with EN14825.
Nominal Capacity and Nominal Input
ZHBW126A1
[HM121MR U34]
ZHBW146A1
[HM141MR U34]
ZHBW166A1
[HM161MR U34]
--
Outdoor
Temp. (°C)
DB / WB
Leaving Water
Temp. (°C) -
Capacity
Cooling 35 / 24 18 kW 12.00 14.00 16.00
7 kW 12.00 14.00 16.00
Heating 7 / 6 35 kW 12.00 14.00 16.00 55 kW 11.00 11.50 12.00
2 / 1 35 kW 11.00 12.00 13.80
Power Input
Cooling 35 / 24 18 kW 2.53 3.26 4.00
7 kW 3.64 4.24 5.16
Heating 7 / 6 35 kW 2.45 2.92 3.40 55 kW 3.79 4.04 4.29
2 / 1 35 kW 3.01 3.31 3.83
EER Cooling 35 / 24 18 W/W 4.75 4.30 4.00
7 W/W 3.30 3.30 3.10
COP Heating 7 / 6 35 W/W 4.90 4.80 4.70 55 W/W 2.90 2.85 2.80
2 / 1 35 W/W 3.65 3.63 3.60
SCOP (Low temp. Average Climate)* 4.67 4.62 4.53
SCOP ((Medium temp. Average Climate)* 3.47 3.46 3.45
Rated Water Flow Rate (at LWT 35 ºC) LPM 34.5 40.3 46.0
Electrical Specifications ZHBW126A1
[HM121MR U34]
ZHBW146A1
[HM141MR U34]
ZHBW166A1
[HM161MR U34]
Power Supply V, Ø, Hz 220-240, 1, 50 220-240, 1, 50 220-240, 1, 50
Peak Control Running Current A 23.0 24.0 25.0
Rated Running Current Cooling A 11.2 14.4 17.7
Heating A 10.9 12.9 15.1
Circuit breaker A 40 40 40
Wiring Connections Power Supply Cable
(included Earth, H07RN-F)
mm² x
cores 6.0 x 3C 6.0 x 3C 6.0 x 3C
Technical Specifications ZHBW126A1
[HM121MR U34]
ZHBW146A1
[HM141MR U34]
ZHBW166A1
[HM161MR U34]
Sound Power Level Heating
Day Max. dB(A) 65 66 66
Rated dB(A) 60 61 61
Low noise dB(A) 56 57 57
Dimensions Unit W × H × D mm 1,239 × 1,380 × 330 1,239 × 1,380 × 330 1,239 × 1,380 × 330
Packed Unit W × H × D mm 1,364 × 1,532 × 461 1,364 × 1,532 × 461 1,364 × 1,532 × 461
Weight Unit kg 118.6 118.6 118.6
Packed Unit kg 133.6 133.6 133.6
Exterior Color - Warm Gray Warm Gray Warm Gray
RAL Code - RAL 7044 RAL 7044 RAL 7044

2. Specification
9
THERMA V Monobloc Type Product Data
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound power level is measured on the rated condition in the accordance with ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
Rated sound power level is according to the EN12102-1 under conditions of the EN14825
4. Performances are accordance with EN14511 and reflect ErP testing conditions. Above gives the declared values at rated conditions acc. ErP regulation.
For max. capacities, refer to Performance Data.
• Rated running current : Outdoor Temp. 7°CDB / 6°CWB, LWT 35℃
5. This product contains Fluorinated greenhouse gases.
* DHW 58~80℃ Operating is available only when the booster heater is operating.
Technical Specifications (Water side) ZHBW126A1
[HM121MR U34]
ZHBW146A1
[HM141MR U34]
ZHBW166A1
[HM161MR U34]
Operation Range
(Leaving Water Temp.)
Cooling Min. ~ Max. °C 5 ~ 27 5 ~ 27 5 ~ 27
Heating Min. ~ Max. °C 15 ~ 65 15 ~ 65 15 ~ 65
DHW * Min. ~ Max. °C 15 ~ 80 15 ~ 80 15 ~ 80
Water Pump
Type - Canned type for hot water circulation
Model - UPML 20-105 CHBL
Motor Type - BLDC
Steps of Pumping Performance - Variable speed 10% to 100%
Power input Min. / Rated W 3.5 / 140 3.5 / 140 3.5 / 140
Water Flow Rate Min. / Rated ℓ/min 5.0 / 46.0 5.0 / 46.0 5.0 / 46.0
Heat Exchanger
Type - Brazed Plate HEX
Quantity - 1 1 1
Number of Plate EA 76 76 76
Water Volume ℓ1.0 1.0 1.0
Water Flow Rate Min. / Rated ℓ/min 13 ~ 70 13 ~ 70 13 ~ 70
Expansion Vessel
Volume Max. ℓ888
Water pressure Max. bar 3 3 3
Pre-charged bar 1 1 1
Flow Sensor
Model SIKA VVXC9SNBUC00252P
Measuring range Min. ~ Max. ℓ/min 5~80 5~80 5~80
Flow (Trigger
point) Min. ℓ/min 15 15 15
Water Pressure sensor Model Sensata OFM(2HMP)
Measuring range Min. ~ Max. bar(G) 0~20 0~20 0~20
Piping Connections Inlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Outlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Strainer
Mesh size - 30 mesh 30 mesh 30 mesh
Max. particle size mm 0.6 0.6 0.6
Material - Stainless Steel
Relief Valve Pressure Limit Upper Limit bar 3.0 3.0 3.0
Devices for Water Circuit
- Relief valve / Flow Sensor
-Drain hose
- Pressure Sensor / Air vent
Technical Specifications (Refrigerant side) ZHBW126A1
[HM121MR U34]
ZHBW146A1
[HM141MR U34]
ZHBW166A1
[HM161MR U34]
Operation Range
(Outdoor Temp.)
Cooling Min. ~ Max. °C DB 5 ~ 48 5 ~ 48 5 ~ 48
Heating Min. ~ Max. °C DB -25 ~ 35 -25 ~ 35 -25 ~ 35
Compressor
Type - Hermetic Sealed Scroll
Model Model × No. RJB036MAA × 1
Motor Type - BLDC
Displacement cm³/Rev. 31.6 31.6 31.6
Refrigerant
Type - R32 R32 R32
GWP
(Global Warming Potential) - 675.0 675.0 675.0
Precharged Amount g 2,000 2,000 2,000
t-CO2 eq. - 1.350 1.350 1.350
Control - Electronic Expansion Valve
Refrigerant Oil Type - FW68D
Charged Volume cc × No. 1,100 1,100 1,100
Heat Exchanger
Type Fin & Tube Fin & Tube Fin & Tube
Quantity 2 2 2
Specification
Row EA 32 32 32
Column EA 2 2 2
FPI EA 18 18 18
Fan Type - Propeller
Air Flow Rate Rated m³/min × No. 60.0 × 2 60.0 × 2 60.0 × 2
Fan Motor Type - BLDC BLDC BLDC
Output W × No. 124 × 2 124 × 2 124 × 2

THERMA V Monobloc Type
2. Specification
10
Product Data
■3 phase Inverter (12 ~ 16 kW)
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound power level is measured on the rated condition in the accordance with ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
Rated sound power level is according to the EN12102-1 under conditions of the EN14825
4. Performances are accordance with EN14511 and reflect ErP testing conditions. Above gives the declared values at rated conditions acc. ErP regulation.
For max. capacities, refer to Performance Data.
• Rated running current : Outdoor Temp. 7°CDB / 6°CWB, LWT 35℃
5. This product contains Fluorinated greenhouse gases.
* : This values are accordance with EN14825.
Nominal Capacity and Nominal Input
ZHBW128A1
[HM123MR U34]
ZHBW148A1
[HM143MR U34]
ZHBW168A1
[HM163MR U34]
--
Outdoor
Temp (°C)
DB / WB
Leaving Water
Temp (°C) -
Capacity
Cooling 35 / 24 18 kW 12.00 14.00 16.00
7 kW 12.00 14.00 16.00
Heating 7 / 6 35 kW 12.00 14.00 16.00 55 kW 11.00 11.50 12.00
2 / 1 35 kW 11.00 12.00 13.80
Power Input
Cooling 35 / 24 18 kW 2.53 3.26 4.00
7 kW 3.64 4.24 5.16
Heating 7 / 6 35 kW 2.45 2.92 3.40 55 kW 3.79 4.04 4.29
2 / 1 35 kW 3.01 3.31 3.83
EER Cooling 35 / 24 18 W/W 4.75 4.30 4.00
7 W/W 3.30 3.30 3.10
COP Heating 7 / 6 35 W/W 4.90 4.80 4.70 55 W/W 2.90 2.85 2.80
2 / 1 35 W/W 3.65 3.63 3.60
SCOP (Low temp. Average Climate)* 4.67 4.62 4.53
SCOP ((Medium temp. Average Climate)* 3.47 3.46 3.45
Rated Water Flow Rate (at LWT 35 ºC) LPM 34.5 40.3 46.0
Electrical Specifications ZHBW128A1
[HM123MR U34]
ZHBW148A1
[HM143MR U34]
ZHBW168A1
[HM163MR U34]
Power Supply V, Ø, Hz 380-415, 3, 50 380-415, 3, 50 380-415, 3, 50
Peak Control Running Current A 8.0 9.0 10.0
Rated Running Current Cooling A 3.7 4.8 5.9
Heating A 3.6 4.3 5.0
Circuit breaker A 16 16 16
Wiring Connections Power Supply Cable
(included Earth, H07RN-F)
mm² x
cores 4.0 x 5C 4.0 x 5C 4.0 x 5C
Technical Specifications ZHBW128A1
[HM123MR U34]
ZHBW148A1
[HM143MR U34]
ZHBW168A1
[HM163MR U34]
Sound Power Level Heating
Day Max. dB(A) 65 66 66
Rated dB(A) 60 61 61
Low noise dB(A) 56 57 57
Dimensions Unit W × H × D mm 1,239 × 1,380 × 330 1,239 × 1,380 × 330 1,239 × 1,380 × 330
Packed Unit W × H × D mm 1,364 × 1,532 × 461 1,364 × 1,532 × 461 1,364 × 1,532 × 461
Weight Unit kg 118.6 118.6 118.6
Packed Unit kg 133.6 133.6 133.6
Exterior Color - Warm Gray Warm Gray Warm Gray
RAL Code - RAL 7044 RAL 7044 RAL 7044

2. Specification
11
THERMA V Monobloc Type Product Data
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
3. Sound power level is measured on the rated condition in the accordance with ISO 9614 standard.
Therefore, these values can be increased owing to ambient conditions during operation.
Rated sound power level is according to the EN12102-1 under conditions of the EN14825
4. Performances are accordance with EN14511 and reflect ErP testing conditions. Above gives the declared values at rated conditions acc. ErP regulation.
For max. capacities, refer to Performance Data.
• Rated running current : Outdoor Temp. 7°CDB / 6°CWB, LWT 35℃
5. This product contains Fluorinated greenhouse gases.
* DHW 58~80℃ Operating is available only when the booster heater is operating.
Technical Specifications (Water side) ZHBW128A1
[HM123MR U34]
ZHBW148A1
[HM143MR U34]
ZHBW168A1
[HM163MR U34]
Operation Range
(Leaving Water Temp.)
Cooling Min. ~ Max. °C 5 ~ 27 5 ~ 27 5 ~ 27
Heating Min. ~ Max. °C 15 ~ 65 15 ~ 65 15 ~ 65
DHW * Min. ~ Max. °C 15 ~ 80 15 ~ 80 15 ~ 80
Water Pump
Type - Canned type for hot water circulation
Model - UPML 20-105 CHBL
Motor Type - BLDC
Steps of Pumping Performance - Variable speed 10% to 100%
Power input Min. / Rated W 3.5 / 140 3.5 / 140 3.5 / 140
Water Flow Rate Min. / Rated ℓ/min 5.0 / 46.0 5.0 / 46.0 5.0 / 46.0
Heat Exchanger
Type - Brazed Plate HEX
Quantity - 1 1 1
Number of Plate EA 76 76 76
Water Volume ℓ1.0 1.0 1.0
Water Flow Rate Min. / Rated ℓ/min 13 ~ 70 13 ~ 70 13 ~ 70
Expansion Vessel
Volume Max. ℓ888
Water pressure Max. bar 3 3 3
Pre-charged bar 1 1 1
Flow Sensor
Model SIKA VVXC9SNBUC00252P
Measuring range Min. ~ Max. ℓ/min 5~80 5~80 5~80
Flow (Trigger
point) Min. ℓ/min 15 15 15
Water Pressure sensor Model Sensata OFM(2HMP)
Measuring range Min. ~ Max. bar(G) 0~20 0~20 0~20
Piping Connections Inlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Outlet inch Male PT 1" according to ISO 7-1 (tapered pipe threads)
Strainer
Mesh size - 30 mesh 30 mesh 30 mesh
Max. particle size mm 0.6 0.6 0.6
Material - Stainless Steel
Relief Valve Pressure Limit Upper Limit bar 3.0 3.0 3.0
Devices for Water Circuit
- Relief valve / Flow Sensor
-Drain hose
- Pressure Sensor / Air vent
Technical Specifications (Refrigerant side) ZHBW128A1
[HM123MR U34]
ZHBW148A1
[HM143MR U34]
ZHBW168A1
[HM163MR U34]
Operation Range
(Outdoor Temp.)
Cooling Min. ~ Max. °C DB 5 ~ 48 5 ~ 48 5 ~ 48
Heating Min. ~ Max. °C DB -25 ~ 35 -25 ~ 35 -25 ~ 35
Compressor
Type - Hermetic Sealed Scroll
Model Model × No. RJB036MAA × 1
Motor Type - BLDC
Displacement cm³/Rev. 31.6 31.6 31.6
Refrigerant
Type - R32 R32 R32
GWP
(Global Warming Potential) - 675.0 675.0 675.0
Precharged Amount g 2,000 2,000 2,000
t-CO2 eq. - 1.350 1.350 1.350
Control - Electronic Expansion Valve
Refrigerant Oil Type - FW68D
Charged Volume cc × No. 1,100 1,100 1,100
Heat Exchanger
Type Fin & Tube Fin & Tube Fin & Tube
Quantity 2 2 2
Specification
Row EA 32 32 32
Column EA 2 2 2
FPI EA 18 18 18
Fan Type - Propeller
Air Flow Rate Rated m³/min × No. 60.0 × 2 60.0 × 2 60.0 × 2
Fan Motor Type - BLDC
Output W × No. 124 × 2 124 × 2 124 × 2

THERMA V Monobloc Type
2. Specification
12
Product Data
■Backup Heater
Note
1. Due to our policy of innovation some specifications may be changed without notification.
2. Wiring cable size must comply with the applicable local and national codes. And “Electric characteristics” chapter should be considered for electrical
work and design. Especially the power cable and circuit breaker should be selected in accordance with that.
Electrical Specification AHEH036A
[HA031M E1]
AHEH066A
[HA061M E1]
AHEH068A [HA063M
E1]
Backup Heater
Type - Sheath Sheath Sheath
Number of Heating Coil EA 1 2 3
Capacity Combination kW 3.0 3.0 + 3.0 2.0 + 2.0 + 2.0
Operation - Automatic Automatic Automatic
Heating Steps Step 1 2 1
Power Supply V, Ø, Hz 220-240, 1, 50 220-240, 1, 50 380-415, 3, 50
Rated Running Current A 12.5 25 8.7
Circuit Breaker A 25 40 25
Wiring
Connections
Power Cable (Included Earth,
H07RN-F) mm² x cores 1.5 x 3C 4.0 x 3C 2.5 x 4C
Communication Cable
(H07RN-F) mm² x cores 0.75 x 4C 0.75 x 4C 0.75 x 2C

13
THERMA V Monobloc Type Product Data
3. Dimensions
■Product
ZHBW056A1 [HM051MR U44] / ZHBW076A1 [HM071MR U44] / ZHBW096A1 [HM091MR U44]

THERMA V Monobloc Type
3. Dimensions
14
Product Data
ZHBW126A1 [HM121MR U34] / ZHBW146A1 [HM141MR U34] / ZHBW166A1 [HM161MR U34]
ZHBW128A1 [HM123MR U34] / ZHBW148A1 [HM143MR U34] / ZHBW168A1 [HM163MR U34]
Note
If you need more drains, remove them.
