LG 26LC7D Series User manual

www.LGusa.com
LG SIMPLINK
Allows for convenient control of other LG SimpLink products using the existing HDMI
connection.
LG’S EXCLUSIVE XD ENGINE®
Six distinct processes contribute to picture improvement. LG’s XD Engine®takes the low
resolution of analog signals to near HD levels by improving brightness, contrast, detail and
enhancing color as well as reducing signal noise. This total solution results in cinema-like high
resolution images.
HIGH DEFINITION TV
Built-in ATSC tuner allows this TV to receive over-the-air digital broadcast signals and
unscrambled digital cable.
ADVANCED CONNECTIVITY
Includes inputs for the most advanced components which allows simultaneous PC interactivity
while watching your favorite TV programming.
• 1366 x 768p Resolution
• 1,200:1 Dynamic Contrast Ratio
• ATSC/NTSC/QAM Clear Tuner
• XD Engine®
• SRS TruSurround XT®
• LG SimpLink
• 2 HDMI with HDCP
26LC7D
26” LCD INTEGRATED HDTV
XT

www.LGusa.com
26LC7D
26” LCD INTEGRATED HDTV
LG Electronics U.S.A., Inc.
1000 Sylvan Avenue
Englewood Cliffs, NJ 07632
1-800-243-0000
www.LGusa.com
© 2007 LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. LG Design and Life’s Good are trademarks of LG Electronics, Inc.
All other trademarks are the property of their respective owners.
Design and specifications subject to change without notice. 03/28/07
REMOTE REAR AUDIO/VIDEO INPUTS/OUTPUTS SIDE
26.6”
18.8”
22.3”
8.7”
3.7” 7.9”
3.9”
17.2”
8.7”
HDMI IN
2
1
REMOTE
CONTROL IN
RS-232C IN
(CONTROL/SERVICE)
ANTENNA/
CABLE IN
VIDEO
L/MONO -AUDIO- R
S-VIDEO
AV IN 2
COMPONENT IN
VIDEO AUDIO
2
1
Y PBPRL R
RGB IN
(PC)
OPTICAL
S-VIDEO VIDEO L(MONO)-AUDIO-R
AV OUT AV IN 1
DIGITAL
AUDIO OUT
AUDIO
(RGB/DVI)
HDMI/DVI IN
SERVICE
TV
ATSC/NTSC/QAM Clear Tuner •
VIDEO
Native Display Resolution 1366 x 768p
Dynamic Contrast Ratio 1,200:1
Response Time (Grey to Grey) 8ms
Brightness (cd/m²) 500
XD Engine® •
True Wide View •
Viewing Angle (H x V) 160º x 140º
Digital Comb Filter 3D
Color Temperature Control 4 Modes
Aspect Ratio Adjustment 6 Modes
Enhanced Noise Reduction (Video Noise Filter) •
Enhanced Line Doubled •
3:2 Pull-Down Correction 3:2 (480i)
Picture Selection Mode 5 Modes
Black Stretcher (Black Level Enhancer) •
DTV Signal Strength Indicator •
ACM (Active Color Management) •
Pure Black Level •
Color Processor 10 Bit
1080p SOURCE INPUT
HDMI 30p/24p
Component 30p/24p
AUDIO
Mono/Stereo/Dual (MTS/SAP) •
AudioOutput Power(Watts- THD10%) 7W+ 7W
Speaker System Details 1 Way 2 System
Dolby Digital Decoder •
AUDIO (CONTINUED)
Surround System Type SRSTruSurroundXT™
Bass/Treble/Balance Controls •
AVL (Auto Volume Leveler) •
EZ Sound (Sound Status Mode) 5 Modes
Mute •
SPECIAL FEATURES
Auto Input Detect •
Custom Input Labels •
PC Mode Configuration •(Manual)
Back (Previous Channel) •
Parental Control w/V-Chip •
Closed Caption •
LG SimpLink (HDMI CEC) •
Trilingual Menus English, Spanish, French
EZ Menus (High Performance Interface) •
Auto Channel Programming •
Channel Add/Delete •
Favorite Channel •
Manual Clock •
On/Off Timer •
Sleep Timer •
Auto Off (When no Video is Present) •
REAR AUDIO/VIDEO INPUTS/OUTPUTS
RF In (Antenna/Cable) 1
L/R Audio/Composite Video In 1
L/R Audio Out 1
S-Video In 1
HD Component Video In (Y,Pb,Pr) + L/R Audio 2
Digital Audio Out 1 (Optical)
HDMI/HDCP Input 2
REAR AUDIO/VIDEO INPUTS/OUTPUTS (CONTINUED)
RGB In (D-Sub 15pin) - PC 1
PC Audio Input 1
RS-232c In (Control/Service) 1
Remote Control In (IR) 1
USB (Service Only) 1
SIDE AUDIO/VIDEO INPUTS/OUTPUTS
L/R Audio/Composite Video In 1
S-Video In 1
CABINET/ACCESSORIES
Cabinet Style Table Top
Cabinet Color Gloss Black
Remote Control Type Universal
VESA® Compatible (W x H) 200mmx 100mm
POWER
Consumption (Typical) 106 W
Stand-by Consumption (Cable Card Off) 1W
Energy Star Compliant •
SPECIFICATIONS
Dimensions w/Out Stand (W x H x D) 26,6" x 18.8" x 3.3"
Weight w/Out Stand 19.0 lbs.
Dimensions w/Stand (W x H x D) 26.6"x 20.9"x 8.7"
Weight w/Stand 21.2 lbs.
Dimensionsw/Packaging(Wx H xD) 34.7"x22.0"x8.3"
Weight In Package 22.7 lbs.
UPC 719192171350
Warranty 1YearParts/Labor
