LG 32LE75 User manual

OWNER’S MANUAL
LED LCD TV
Please read this manual carefully before operating
your set and retain it for future reference.
LED LCD TV MODELS
www.lg.com
ENGLISH
32LE75
42LE75
47LE75
55LE75
32LE55
37LE55
42LE55
47LE55
55LE55

HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or regis-
tered trademarks of HDMI Licensing LLC.
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer for buying these items.
Wall Mounting Bracket
Wireless LAN for
Broadband/
DLNA Adaptor
Separate purchase
roB002WSL
LSW200BG
(32LE5***,
32LE7***)
(37/42/47LE5***,
42/47LE7***)
(55LE5***,
55LE7***)
roB001WSL
LSW100BG
roB004WSL
LSW400BG
Wireless Media Box
OUT
WIRELESS
CONTROL
AV1 AV2 COM HDMI1 HDMI2 HDMI3 HDMI4
RGB WIRELESS

I
CONTENTS
CONTENTS
Picture/Sound test.............................................42
Diagnostics........................................................43
Product/service information...............................44
Network Test.......................................................44
Simple Manual ..................................................46
Selecting the Programme List...........................47
Input List............................................................49
Input Label ........................................................50
SIMPLINK..........................................................51
AV Mode............................................................55
Initializing(Reset to original factory settings) ....56
TO USE THE BLUETOOTH
Bluetooth? ........................................................63
Setting the Bluetooth.........................................64
My Bluetooth Information ..................................65
Bluetooth Headset ............................................ 66
Remove the Bluetooth Device ..........................70
Receiving photos from external Bluetooth device
...........................................................................71
Listening to the Musics from external Bluetooth
device ................................................................72
TO USE A USB DEVICE
When connecting a USB device .......................73
DLNA.................................................................75
Movie list ...........................................................81
Photo list............................................................ .92
Music list..........................................................102
DivX Registration Code...................................111
Deactivation.....................................................112
Game...............................................................113
PREPARATION
Front Panel Control
Back Panel Information
Stand Installation
Swivel Stand.....................................................A-5
Back Cover for Wire Arrangement
..........................................A-2
.............................................A-4
...................A-5
Kensington Security-System
............................A-6
Careful installation advice ...............................A-6
Desktop Pedestal Installation...........................A-7
Wall Mount:Horizontal Installation....................A-7
Remote Control Key Function..........................A-8
...................................A-3
EXTERNAL EQUIPMENT SETUP
Antenna Connection............................................1
Connecting with a Component cable..................2
Connecting with an HDMI cable .........................3
Connecting with an HDMI to DVI cable ..............4
Usb setup ............................................................5
Connecting with a RF Cable...............................5
Connecting with a RCA cable .............................6
Connecting with a D-sub 15 pin cable................7
Headphone Setup ...............................................8
Digital audio out Setup.................................... ..9
External Equipment WIreless Connection ........10
Supported Display Resolution...........................11
Screen Setup for PC mode...............................13
network setup....................................................17
ACCESSORIES
LED LCD TV Models : 32/37/42/47/55LE5***,
32 /42/47/55LE7***...........................................A-1
WATCHING TV / PROGRAMME CON-
TROL
Turning on the TV .............................................27
Initializing Setup ...............................................27
Programme Selection........................................27
Volume Adjustment ...........................................27
Quick Menu .......................................................28
On Screen Menus Selection and adjustment ...29
Auto programme tuning ...................................31
Manual programme Tuning...............................32
Programme Edit ...............................................35
Booster ..............................................................39
Software Update...............................................40
NETCAST
Legal Notice ......................................................57
Netcast Menu ....................................................58
YOUTUBE.........................................................59
AccuWeather.....................................................61
picasa ................................................................62

II
CONTENTS
CONTENTS
EPG(ELECTRONIC PROGRAMME
GUIDE)(IN DIGITAL MODE)
Switch on/off EPG ...........................................115
Select a programme........................................115
Button Function in NOW/NEXT Guide Mode .115
Button Function in 8 Day Guide Mode ...........116
Button Function in Date Change Mode ..........117
Button Function in Extended Description Box 118
Button Function in Record/Remind Setting Mode
.........................................................................119
Button Function in Schedule List Mode..........120
PICTURE CONTROL
Picture Size (Aspect Ratio) Control ................121
Picture Wizard.................................................123
Energy Saving.................................................124
Preset Picture Settings ...................................125
Manual Picture Adjustment .............................126
Picture Improvement Technology....................127
Expert Picture Control.....................................128
Picture Reset...................................................131
Trumotion ........................................................132
LED LOCAL DIMMING ...................................133
Power Indicator ...............................................134
Mode Setting ...................................................135
Demo Mode.....................................................136
SOUND & LANGUAGE CONTROL
Auto Volume Leveler.......................................137
Clear Voice II...................................................138
Preset Sound Settings-Sound Mode ..............139
Sound Setting Adjustment -User Mode ..........140
Infinite Sound ..................................................140
Balance ...........................................................141
TV Speakers On/ Off Setup ............................142
DTV Audio Setting (in digital mode only)........143
Selecting Digital Audio out ..............................144
Audio Reset.....................................................145
Stereo/Dual Reception
(In Analogue Mode Only) ................................146
NICAM Reception (In Analogue Mode Only)..147
Speaker Sound Output Selection ...................147
On-Screen Menu Language /
Country Selection............................................148
Language Selection (In digital mode only) .....149
TIME SETTING
Clock Setup.....................................................151
Auto on/off time setting ...................................152
Sleep Timer setting .........................................153
PARENTAL CONTROL / RATINGS
Set Password & Lock System.........................154
Block Programme............................................155
External Input Blocking ...................................156
Key Lock..........................................................157
TELETEXT
Switch on/off ...................................................158
SIMPLE Text....................................................158
TOP Text..........................................................159
FASTEXT ........................................................159
Special Teletext Functions ..............................160
DIGITAL TELETEXT
Teletext within Digital Service .........................161
Teletext in Digital Service................................161
APPENDIX
Troubleshooting...............................................162
Maintenance....................................................164
Product Specifications.....................................165
IR Codes .........................................................166
External Control Device Setup........................167
Open Source Software notice ........................174

A-1
PREPARATION
PREPARATION
LED LCD TV MODELS
ACCESSORIES
Ensure that the following accessories are included with your TV. If an accessory is missing, please
contact the dealer where you purchased the TV.
■Image shown may differ from your TV.
Owner’s Manual Batteries
(AAA)
Remote Control
Polishing Cloth
Polishing cloth for
use on the screen.
This item is not included for all models.
* Lightly wipe any stains or
fingerprints on the surface
of the TV with the polish-
ing cloth.
Do not use excessive
force. This may cause
scratching or discoloura-
tion.
Ferrite Core
(
This item is not included
for all models.
)
Install the power plug closely.
Use of ferrite core (This feature is not available for all models.)
Ferrite core can be used to reduce the electromagnetic
wave when connecting the power cord.
The closer the location of the ferrite core to the power
plug, the better it is.
Nero MediaHome
4 Essentials CD
Cable Holder
1-screw for stand fixing
(Only 32LE55**)
Component gender cable,
AV gender cable
x 2
(Only 32/37/42/47LE5*** ,(Only 55LE5***
,
32/37/42/47LE7*** )55LE7***
)
x 8 x 4 x 4
(M4 x 16) (M4 x 24) (M4 x 16)
Bolts for stand assembly
AVMODE INPUT
TV/
RAD
ENERGY
1 2 ABC 3 DEF
4 GHI 5 JKL 6 MNO
7 PQRS 8 TUV
0
9
WXYZ
BACK EXIT
OK
LIST
Q.VIEW
MENU Q.MENU
GUIDE
T.OPT
P
A
G
E
MARK
RATIO
MUTE
FAV
DELETE
CHAR/NUM
P
SAVING
INFO
TEXT

A-2
PREPARATION
PREPARATION
FRONT PANEL CONTROLS
NOTE
►
►
TV can be placed in standby mode in order to reduce the power consumption.
The energy consumed during use can be significantly reduced if the level of
brightness of the picture is reduced, and this will reduce the overall running cost.
■Image shown may differ from your TV.
Intelligent Sensor
Adjusts picture according to
the surrounding conditions.
Remote Control Sensor
SPEAKER
Touch Button
You can use the desired button function by touching.
OK INPUT
Power/Standby Indicator
PROGRAMMEVOLUMEMENU POWER
(Can be adjusted using the Power
Indicator in the OPTION menu.)
CAUTION
►Do not drag the TV. The floor or the product may be damaged.

A-3
PREPARATION
HDMI/DVI IN
L/MONO
R
AUDIO
VIDEO
AV IN 1
USB IN 2
H/P
USB IN 1
HDMI
IN 4
1
2
HDMI/DVI IN
L/MONO
R
AUDIO
VIDEO
AV IN 1
1
2
3
HDMI/DVI IN
WIRELESS
CONTROL
L/MONO
R
AUDIO
VIDEO
AV IN 1
LAN
1
2
BACK PANEL INFORMATION
■Image shown may differ from your TV.
RS-232C IN (CONTROL & SERVICE) PORT
Connect to the RS-232C port on a PC.
This port is used for Service or Hotel mode.
WIRELESS Control
Connect the Wireless Dongle to the TV to
control the external input devices connected
to Media Box wirelessly.
Audio/Video Input
Connect audio/video output from an external
device to these jacks.
Antenna Input
Connect antenna to this jack.
Cable Input
Connect cable signals to this jack.
USB Input
Connect USB storage device to this jack.
Headphone Socket
Plug the headphone into the headphone
socket.
7RGB IN Input
Connect the output from a PC.
432 5
78 9 10
6
13
ANTENNA
IN
CABLE
IN
11 12
5
10
6
14
1
8
9
10
11
12
13
14
2LAN
Also used for photo and music files on local
network.
3OPTICAL DIGITAL AUDIO OUT
Connect digital audio to various types of
equipment.
Connect to a Digital Audio Component.
Use an Optical audio cable.
4RGB/DVI Audio Input
Connect the audio from a PC .
5Component Input
Connect a component video/audio device to
these jacks.
6HDMI/DVI IN Input
Connect an HDMI signal to HDMI IN. Or DVI
(VIDEO) signal to HDMI/DVI port with DVI to
HDMI cable.
Power Cord Socket
This TV operates on an AC power. The volt-
age is indicated on the Specifications page.
(► p.165) Never attempt to operate the TV
on DC power.
1
Network connection for Accu Weather,
YouTube,Picasa, etc.

A-4
PREPARATION
PREPARATION
STAND INSTALLATION
■Image shown may differ from your TV.
When assembling the desk type stand, check whether the bolt is fully tightened. (If not tightened fully,
the product can tilt forward after the product installation.) If you tighten the bolt with excessive force,
the bolt can deviate from abrasion of the tightening part of the bolt.
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
Assemble the TV as shown.
3
Assemble the parts of the stand body with
the stand base of the TV.
2
1
Assemble the parts of the Stand Rear
Cover with the TV.
4
Stand Rear
Cover
5 Fix the 4 bolts securely using the holes in
the back of the TV.
M4 X 16
(Only
32/37/42/47/55LE5***,
32/37/42/47/55LE7***)
Stand Body
Stand Base
M4 X 16
(Only 32/37/42/47LE5***
32/37/42/47LE7***)
M4 X 24
(Only 55LE5
55LE7***)

A-5
PREPARATION
SWIVEL STAND
■Image shown may differ from your TV.
After installing the TV, you can adjust the TV set
manually to the left or right direction by 20
degrees to suit your viewing position.
ATTACHING THE TV TO A
DESK
Desk
Stand
■Image shown may differ from your TV.
The TV must be attached to desk so it cannot be
pulled in a forward/backward direction, potentially
causing injury or damaging the product. Use only
an attached screw.
WARNING
►To prevent TV from falling over, the TV
should be securely attached to the floor/wall
per installation instructions. Tipping, shaking,
or rocking the machine may cause injury.
(Only 32LE55**)
1-Screw (provided as parts of the product)
BACK COVER FOR
WIRE ARRANGEMENT
■Image shown may differ from your TV.
Secure the power cord with the Cable
Holder on the TV back cover.
It will help prevent the power cable from
being removed by accident.
Cable Holder
After connecting the cables as necessary,
install Cable Holder as shown and bundle
the cables.
Cable Holder
1
2

A-6
PREPARATION
PREPARATION
■This feature is not available for all models.
■Image shown may differ from your TV.
KENSINGTON SECURITY
SYSTEM
CAREFUL INSTALLATION
ADVICE
■You should purchase necessary components
to fix the TV safety and secure to the wall on
the market.
■Position the TV close to the wall to avoid the
possibility of it falling when pushed.
■The instructions shown below are a safer way
to set up the TV, by fixing it to the wall, avoid-
ing the possibility of it falling forwards if pulled.
This will prevent the TV from falling forward
and causing injury. This will also prevent the
TV from damage. Ensure that children do not
climb or hang from the TV.
3
Use the eye-bolts or TV brackets/bolts to fix the
product to the wall as shown in the picture.
(If your TV has bolts in the eyebolts, loosen then
bolts.)
* Insert the eye-bolts or TV brackets/bolts and
tighten them securely in the upper holes.
Secure the wall brackets with the bolts on the
wall. Match the height of the bracket that is
mounted on the wall.
Use a sturdy rope to tie the product for align-
ment. It is safer to tie the rope so it becomes
horizontal between the wall and the product.
2 2
11
The TV is equipped with a Kensington Security
System connector on the back panel. Connect
the Kensington Security System cable as shown
below.
For the detailed installation and use of the
Kensington Security System, refer to the user’s
guide provided with the Kensington Security
System.
For further information, contact http://www.kens-
ington.com, the internet homepage of the
Kensington
company. Kensington sells security systems for
expensive electronic equipment such as note-
book PCs and LCD projectors.
1
2
3
NOTE
►When moving the TV undo the cords first.
►Use a platform or cabinet strong and large
enough to support the size and weight of the TV.
►To use the TV safely make sure that the height of
the bracket on the wall and on the TV is the
same.
NOTE
►The Kensington Security System is an optional
accessory.
►If the TV feels cold to the touch, there may be a
small “flicker” when it is turned on.
This is normal
, there is nothing wrong with TV.
►Some minute dot defects may be visible on the
screen, appearing as tiny red, green, or blue
spots. However, they have no adverse effect on
the monitor's performance.
►Avoid touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary distortio
n
effects on the screen.
