LG 42LG50DC User manual

lcd tv
Full 1080p HDTVLCD Widescreen
w w w. LG c o m m e r c i a l . c o m
NATIVE DISPLAY RESOLUTION
1920 x 1080 (1080p Full D resolution)
BACKLIGHT DIMMING CONTROL
Provides Power Savings
DYNAMIC CONTRAST RATIO
15,000:1
BUILT-IN TUNER
ATSC/NTSC/Clear QAM
PUBLIC DISPLAY SETTINGS
Cloning capable
LG’S E CLUSIVE D ENGINE®
REAL CINEMA™
CLEAR VOICE™
INTELLIGENT SENSOR
2 HDMI™ WITH HDCP
USB INPUT FOR PHOTOS AND MUSIC
USB CLONING
42” only
RoHS COMPLIANT
INVISIBLE SPEAKER SYSTEM
CUSTOMIZABLE CLOSED CAPTIONS
CABINET COLOR
igh-gloss black
NEW! 2-YEAR LIMITED WARRANTY
(parts/labor)
AVAILABLE USING OPTIONAL HCS5610 PAY-PER-VIEW BO
Auto-Sensing Remote Jack Pack (RJP) capable
Pro:Idiom®capable
52" class (52.0" d agonal
47" class (46.9" d agonal)
42" class (42.0" d agonal)
52LG50DC
47LG50DC
42LG50DC

SHARPER
BRIGHTER
CLEARER
Dramatization Dramatization
BALANCED SO ND TO EMPHASIZE DIALOG E
Designed to automatically enhance and amplify the sounds of the human
voice frequency range, Clear Voice Technology helps keep dialogue audible
when background noises swell.
SO ND IS HEARD, NOT SEEN
Breaking through the fixed idea that speaker grills must be exposed, the
Invisible Speaker design provides a “full sweet spot” and more realistic sound.
Personally tuned by Mr. Mark Levinson, world-renowned audio authority, this
unique design has rich and lively sound that can be enjoyed from any angle.
P BLIC DISPLAY SETTINGS
CLONING CAPABLE
When used in public areas, these DTVs can be easily programmed by
the installer to have the TV turn on at a specified channel/volume level,
set the minimum/ maximum volume, lock out the control panel/remote,
set the aspect ratio, and return to a factory reset. By using Power
Management, these displays can be programmed to turn off if there has
been no activity (remote or control panel buttons) for a preset time
(1-7) hours.
Public Display Mode No
Start Channel No
Ch. Type TV
Major 2
Minor 0
Minimum Volume 0
Maximum Volume 100
Start Volume No
Level 20
Power Management No
Setting 1
Key Management 0
Factory Reset 0
Aspect Ratio 0
Public Display Settings+
52LG50DC in Vivid Mode 47LG50DC in Vivid Mode
BACKLIGHT
SETTING VAL E BRIGHTNESS (cd /m2)
*POWER
CONS MPTION
(Watts)
Level 100 349 cd/m2350 Watts
90 95%** 94%**
80 90% 90%
70 78% 80%
60 68% 72%
50 60% 66%
40 52% 60%
30 46% 55%
20 38% 49%
10 34% 45%
1 30% 43%
BACKLIGHT
SETTING VAL E BRIGHTNESS
(cd /m2)
*POWER
CONS MPTION
(Watts)
Level 100 382 cd/m2304 Watts
90 98%** 95%**
80 94% 91%
70 71% 73%
60 55% 60%
50 46% 53%
40 38% 46%
30 29% 40%
20 22% 34%
10 13% 27%
1 5% 20%
BACKLIGHT DIMMING CONTROL
By selecting lower levels of backlight settings, a reduction in
power consumption is achieved resulting in energy savings
and lower costs. This feature is disabled when Intelligent
Sensor is selected.
Power consumption was measured using IEC62087 dynamic broadcast - content video signal
*
All percentages listed are percentages based off of level 100
**
42LG50DC in Vivid Mode
BACKLIGHT
SETTING VAL E BRIGHTNESS (cd /m2)
*POWER
CONS MPTION
(Watts)
Level 100 289 cd/m2214.8 Watts
90 98%** 97%**
80 96% 93%
70 80% 80%
60 70% 73%
50 61% 65%
40 52% 59%
30 42% 53%
20 36% 47%
10 30% 42%
1 26% 38%
Enter
Move
Aspect Ratio : 16:9
Picture Mode : Standard
• Backlight 80
• Contrast90
• Brightness50
• Sharpness60
• Color60
• Tint0
RG
Intelligent Sensor
Vivid
Standard
Cinema
Sport
Game
Expert1
Expert2
Enter
Move
6
RG
Aspect Ratio : 16:9
Picture Mode : Standard
• Backlight 80
• Contrast90
• Brightness50
• Sharpness60
• Color60
• Tint0
6
PICT RE MODE
Adjust the picture appearance to suit you preference and viewing situations.

Dramatization Dramatization Dramatization
TLL-1100A
TVLink-Loader
27.5”
50.9”
13.5”
4.54”
45.5”
25.7”
32.2”
35.1”
800mm
400mm
9.0”
7
.4”
19.0”
5.48”
47LG50DC
52LG50DC
R E M O T E C O N T R O L
SIDE
AV IN 2
L/MONO
RR
AUDIO
VIDEO
USB IN
RGB IN
COMPONENT IN
AUDIO
(RGB/DVI)
RGB(PC)
REMOTE
CONTROL IN
ANTENNA/
CABLE IN
1
2
RS-232C IN
(CONTROL & SERVICE)
VIDEO
AUDIO
OPTICAL COAXIAL
DIGITAL AUDIO OUT
AUDIO OUT
AV IN 1
HDMI/DVI IN
2
1
VIDEO
MONO
(())
AUDIO
S-VIDEO
REAR JACK PACK PANEL
27.5
45.5”
13.5
4.06”
41.1”
23.2”
29.1
32.0
200mm
200mm
10.0”
11.1”
19.0”
4.96”
By using the handheld,
rechargeable TVLink-
Loader, the installer can
“clone” the Public Display
Settings from one TV and
then transfer this infor-
mation quickly to many
other TVs that have this
feature.
AVIN2
L/MONO
R
AUDIO
VIDEO
USBIN
U S B
C L O N I N G
42”
200mm
200mm
8.0”
10.2”
16.3”
11.6”
3.58”
40.7”
37.0”
21.0”
26.1”
29.9”
23.0”
3.62”
42LG50DC
SIDE

LG Electronics U.S.A., Inc.
Commercial Products Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
Contact your LG Regional Sales Representative:
Hospitality: 800.228.1236
Enterprise: 800.897.8788
Channel: 800.897.8871
E-mail: L[email protected]
SPEC_LG50DC_110805_PR
All screen images are simulated. Dimensions and weights are approximate. Design,
features and specifications subject to change without notice.
© Copyright 2009 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is
a registered trademark of LG Corp. XD Engine is a registered trademark of LG
Electronics USA, Inc. Pro:Idiom and MPI are trademarks of Zenith Electronics Corp.
VESA is a trademark of Video Electronics Standards Association. DMI, the DMI
Logo and igh-Definition Multimedia Interface are trademarks or registered trademarks
of DMI Licensing LLC. Dolby and the double-D symbol are registered trademarks of
Dolby Laboratories. SRS and the SRS symbol are registered trademarks of SRS Labs,
Inc. in the U.S. and selected foreign countries. All other product and brand names are
trademarks or registered trademarks of their respective companies.
Printed in the USA. January 2009
spec f cat ons
www.LGcommercial.com
lcd tv
PANEL
LCD Panel Type 52" (52LG50DC)
47" (47LG50DC)
42" (47LG50DC)
Display Area 52.0" diagonal (52LG50DC)
46.9" diagonal (47LG50DC)
42.0" diagonal (42LG50DC)
Native Display Resolution 1920 x 1080
Brightness 450 cd/m
2
(52”)
500 cd/m
2
(47”, 42”)
Dynamic Contrast Ratio 15,000:1
Contrast Ratio 1,500:1 (52”, 47”) 1,400:1 (42”)
Viewing Angle (xV) 178°x178°
Response Time (G to G) 5ms
Pure Black Level Yes
True Wide View Yes
Life Span (approx. hr) 60,000 (Module 50,000)
BROADCASTING SYSTEM
Analog/Digitial ATSC/NTSC/Clear QAM 1 tuner
VIDEO
XD Engine Yes
Aspect Ratio 16:9
Aspect Ratio Correction 6 mode (16:9, Just scan, 4:3, Set by program,
Zoom1, Zoom2)
Just Scan (0% overscan) -DMI (1080i/1080p/720p)
when "Just Scan Mode" selected Component (1080i/1080p/720p)
RF(1080i/720p)
Enhanced Line Doubler Yes
Enhanced Noise Reduction Yes (3D & MPEG)
Digital Comb Filter Yes (3D)
DLTI (Digital Luminance Transient Improver) Yes
DCTI (Color Transient Improver) Yes
Color Temperature Control Cool, Medium, Warm
Black Stretcher Yes
Cinema 3:2 , 2:2 Pulldown 3:2 (TV/S-Video/Composite - 480i,
Component 480i/576i/1080i)
Picture Status Mode 8 modes
XD color (Active Color Management) Yes
DTV Signal Strength (Digital) Yes
A DIO
Mono/Stereo/Dual (MTS/SAP) Yes
Audio Output (Watts - T D 10%) 10W + 10W
Invisible Speaker System Yes
Speaker System Details 2 Way 4 Speakers
Dolby Digital
®
Decoder Yes
Surround System SRS TruSurround XT ™
Bass/Treble/Balance Yes
AVL (Auto Volume Leveler) Yes
Sound Status Mode 5 modes
(Standard, Music, Cinema, Sports, Game)
Mute Yes
SPECIAL FEAT RES
Intelligent Sensor Yes
Real Cinema Yes
Public Display Settings Yes
EPG (Brief Info) Yes
1080p Source Input DMI (60/30/24p) /Component (60/30/24p)
RGB (60p)
AV Input Navigation Yes
Auto Navigation Yes
Input Labeling Cable Box/VCR/DVD/Set Top Box/PC/Game
Quick View (Flash Back) Yes
Clear Voice (On/Off) Yes
Quick Set-up Guide Yes
Parental Control w/ V-Chip Yes
Key Lock Yes
Closed Captions (Customizable) Yes
SimpleLink (DMI CEC) Yes
Auto/Manual Clock Yes
On/Off Time, Sleep, Auto off Yes
EZ OSD (Menu System) Yes
Menu Languages Yes (English, Spanish, French)
USB Input for Photos and Music Yes
Universal Remote Yes
COMPATIBILITIES
Pro:Idiom Yes (using optional CS5610 pay-per-view box)
Optional Auto-Sensing Remote Jack Packs Yes (using optional CS5610 pay-per-view box)
JACK PACK
Side
AV In 1
USB 2.0 1
(Photos, Music, Service - all) ,USB cloning (42” only)
DMI In 1
Rear RF In (Antenna/Cable) 1
AV In 1
S-Video In 1
Component in (Y,Pb,Pr) + Audio 2
Digital Audio Out 1 Optical/1 Coaxial
Analog Audio Out (L/R) 1
DMI/ DCP Input 2 (1.3 Version)
RGB In (D-sub 15pin) -PC 1
PC Audio Input 1
S-232C (Control / SVC) 1
Remote Control In port 1
CABINET
Unit Dimensions with Stand (Wx xD) 50.9" x 35.1" x 13.5" (52”)
45.5" x 32.0" x 13.5" (47”)
40.7" x 29.9" x 11.6" (42”)
Unit Dimensions without Stand (Wx xD)50.9" x 32.2" x 4.54" (5.48)* (52”)
45.5" x 29.1" x 4.06" (4.96)* (47”)
40.7" x 26.1" x 3.58” (3.62)* (42”)
Unit Weight with Stand without Stand
87.1 lbs
(52”) 80.0 lbs (52”)
65.1 lbs (47”) 54.2 lbs (47”)
54.0 lbs (42”) 48.5 Ibs (42”)
Carton Dimensions (Wx xD) 54.6" x 16.2" x 35.4" (52”)
49.8” x 18.1” x 34.9” (47”)
52.4” x 9.8” x 29.4” (42”)
Shipping Weight 110.3 lbs (52”)
80.7 lbs (47”)
64.1 lbs (42”)
Cabinet Color igh-Gloss Black
Cable Management Clip Yes
Swivel (stand) Included/Detachable +/- 20 °
Ro S Compliant Yes
UL Standard Listed
VESA ™ Compatible Yes (800mm x 400mm, M4) (52”)
Yes (200mm x 200mm, M6) (47”, 42”)
POWER
Backlight Dimming Control Yes
Voltage, z 100 ~240V, 50/60 z
Power Consumption (Max/Typ.) 375W/340W (52”)
with power saving modes disabled 330W/300W (47”)
238W/224W (42”)
Power Consumption (Stand-by) Under 1W
PC
52LG50DC 7 19192 17434 4
47LG50DC 7 19192 17433 7
42LG50DC 7 19192 17465 8
LIMITED WARRANTY 2 Years (parts/labor)
*Depth of monitor including stand adapter plate.
