Lg 42lk450 User manual

LCD TV

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE CHASSIS,

READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

CHASSIS : LA01U

MODEL : 42LK450 42LK450-UB

North/Latin America http://aic.lgservice.com

Europe/Africa http://eic.lgservice.com

Asia/Oceania http://biz.lgservice.com

Internal Use Only

Printed in KoreaP/NO : MFL67021006 (1102-REV00)

Only for training and service purposes - 2 -

CONTENTS

CONTENTS .............................................................................................. 2

SAFETY PRECAUTIONS ......................................................................... 3

SPECIFICATION....................................................................................... 6

ADJUSTMENT INSTRUCTION .............................................................. 10

EXPLODED VIEW .................................................................................. 17

SVC. SHEET ...............................................................................................

Only for training and service purposes - 3 -

SAFETY PRECAUTIONS

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the

Schematic Diagram and Exploded View.

It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent

Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

General Guidance

An isolation Transformer should always be used during the

servicing of a receiver whose chassis is not isolated from the AC

power line. Use a transformer of adequate power rating as this

protects the technician from accidents resulting in personal injury

from electrical shocks.

It will also protect the receiver and it's components from being

damaged by accidental shorts of the circuitry that may be

inadvertently introduced during the service operation.

If any fuse (or Fusible Resistor) in this TV receiver is blown,

replace it with the specified.

When replacing a high wattage resistor (Oxide Metal Film Resistor,

over 1W), keep the resistor 10mm away from PCB.

Keep wires away from high voltage or high temperature parts.

Before returning the receiver to the customer,

always perform an AC leakage current check on the exposed

metallic parts of the cabinet, such as antennas, terminals, etc., to

be sure the set is safe to operate without damage of electrical

shock.

Leakage Current Cold Check(Antenna Cold Check)

With the instrument AC plug removed from AC source, connect an

electrical jumper across the two AC plug prongs. Place the AC

switch in the on position, connect one lead of ohm-meter to the AC

plug prongs tied together and touch other ohm-meter lead in turn to

each exposed metallic parts such as antenna terminals, phone

jacks, etc.

If the exposed metallic part has a return path to the chassis, the

measured resistance should be between 1MΩand 5.2MΩ.

When the exposed metal has no return path to the chassis the

reading must be infinite.

An other abnormality exists that must be corrected before the

receiver is returned to the customer.

Leakage Current Hot Check (See below Figure)

Plug the AC cord directly into the AC outlet.

Do not use a line Isolation Transformer during this check.

Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor

between a known good earth ground (Water Pipe, Conduit, etc.)

and the exposed metallic parts.

Measure the AC voltage across the resistor using AC voltmeter

with 1000 ohms/volt or more sensitivity.

Reverse plug the AC cord into the AC outlet and repeat AC voltage

measurements for each exposed metallic part. Any voltage

measured must not exceed 0.75 volt RMS which is corresponds to

0.5mA.

In case any measurement is out of the limits specified, there is

possibility of shock hazard and the set must be checked and

repaired before it is returned to the customer.

Leakage Current Hot Check circuit

1.5 Kohm/10W

To Instrument's

exposed

METALLIC PARTS

Good Earth Ground

such as WATER PIPE,

CONDUIT etc.

AC Volt-meter

IMPORTANT SAFETY NOTICE

0.15uF

Only for training and service purposes - 4 -

CAUTION: Before servicing receivers covered by this service

manual and its supplements and addenda, read and follow the

SAFETY PRECAUTIONS on page 3 of this publication.

NOTE: If unforeseen circumstances create conflict between the

following servicing precautions and any of the safety precautions on

page 3 of this publication, always follow the safety precautions.

Remember: Safety First.

General Servicing Precautions

1. Always unplug the receiver AC power cord from the AC power

source before;

a. Removing or reinstalling any component, circuit board

module or any other receiver assembly.

b. Disconnecting or reconnecting any receiver electrical plug or

other electrical connection.

c. Connecting a test substitute in parallel with an electrolytic

capacitor in the receiver.

CAUTION: A wrong part substitution or incorrect polarity

installation of electrolytic capacitors may result in an

explosion hazard.

2. Test high voltage only by measuring it with an appropriate high

voltage meter or other voltage measuring device (DVM,

FETVOM, etc) equipped with a suitable high voltage probe.

Do not test high voltage by "drawing an arc".

3. Do not spray chemicals on or near this receiver or any of its

assemblies.

4. Unless specified otherwise in this service manual, clean

electrical contacts only by applying the following mixture to the

contacts with a pipe cleaner, cotton-tipped stick or comparable

non-abrasive applicator; 10% (by volume) Acetone and 90% (by

volume) isopropyl alcohol (90%-99% strength)

CAUTION: This is a flammable mixture.

Unless specified otherwise in this service manual, lubrication of

contacts in not required.

5. Do not defeat any plug/socket B+ voltage interlocks with which

receivers covered by this service manual might be equipped.

6. Do not apply AC power to this instrument and/or any of its

electrical assemblies unless all solid-state device heat sinks are

correctly installed.

7. Always connect the test receiver ground lead to the receiver

chassis ground before connecting the test receiver positive

lead.

Always remove the test receiver ground lead last.

8. Use with this receiver only the test fixtures specified in this

service manual.

CAUTION: Do not connect the test fixture ground strap to any

heat sink in this receiver.

Electrostatically Sensitive (ES) Devices

Some semiconductor (solid-state) devices can be damaged easily

by static electricity. Such components commonly are called

Electrostatically Sensitive (ES) Devices. Examples of typical ES

devices are integrated circuits and some field-effect transistors and

semiconductor "chip" components. The following techniques

should be used to help reduce the incidence of component

damage caused by static by static electricity.

1. Immediately before handling any semiconductor component or

semiconductor-equipped assembly, drain off any electrostatic

charge on your body by touching a known earth ground.

Alternatively, obtain and wear a commercially available

discharging wrist strap device, which should be removed to

prevent potential shock reasons prior to applying power to the

unit under test.

2. After removing an electrical assembly equipped with ES

devices, place the assembly on a conductive surface such as

aluminum foil, to prevent electrostatic charge buildup or

exposure of the assembly.

3. Use only a grounded-tip soldering iron to solder or unsolder ES

devices.

4. Use only an anti-static type solder removal device. Some solder

removal devices not classified as "anti-static" can generate

electrical charges sufficient to damage ES devices.

5. Do not use freon-propelled chemicals. These can generate

electrical charges sufficient to damage ES devices.

6. Do not remove a replacement ES device from its protective

package until immediately before you are ready to install it.

(Most replacement ES devices are packaged with leads

electrically shorted together by conductive foam, aluminum foil

or comparable conductive material).

7. Immediately before removing the protective material from the

leads of a replacement ES device, touch the protective material

to the chassis or circuit assembly into which the device will be

installed.

CAUTION: Be sure no power is applied to the chassis or circuit,

and observe all other safety precautions.

8. Minimize bodily motions when handling unpackaged

replacement ES devices. (Otherwise harmless motion such as

the brushing together of your clothes fabric or the lifting of your

foot from a carpeted floor can generate static electricity

sufficient to damage an ES device.)

General Soldering Guidelines

1. Use a grounded-tip, low-wattage soldering iron and appropriate

tip size and shape that will maintain tip temperature within the

range or 500°F to 600°F.

2. Use an appropriate gauge of RMA resin-core solder composed

of 60 parts tin/40 parts lead.

3. Keep the soldering iron tip clean and well tinned.

4. Thoroughly clean the surfaces to be soldered. Use a mall wire-

bristle (0.5 inch, or 1.25cm) brush with a metal handle.

Do not use freon-propelled spray-on cleaners.

5. Use the following unsoldering technique

a. Allow the soldering iron tip to reach normal temperature.

(500°F to 600°F)

b. Heat the component lead until the solder melts.

c. Quickly draw the melted solder with an anti-static, suction-

type solder removal device or with solder braid.

CAUTION: Work quickly to avoid overheating the circuit

board printed foil.

6. Use the following soldering technique.

a. Allow the soldering iron tip to reach a normal temperature

(500°F to 600°F)

b. First, hold the soldering iron tip and solder the strand against

the component lead until the solder melts.

c. Quickly move the soldering iron tip to the junction of the

component lead and the printed circuit foil, and hold it there

only until the solder flows onto and around both the

component lead and the foil.

CAUTION: Work quickly to avoid overheating the circuit

board printed foil.

d. Closely inspect the solder area and remove any excess or

splashed solder with a small wire-bristle brush.

SERVICING PRECAUTIONS

Only for training and service purposes - 5 -

IC Remove/Replacement

Some chassis circuit boards have slotted holes (oblong) through

which the IC leads are inserted and then bent flat against the

circuit foil. When holes are the slotted type, the following technique

should be used to remove and replace the IC. When working with

boards using the familiar round hole, use the standard technique

as outlined in paragraphs 5 and 6 above.

Removal

1. Desolder and straighten each IC lead in one operation by gently

prying up on the lead with the soldering iron tip as the solder

melts.

2. Draw away the melted solder with an anti-static suction-type

solder removal device (or with solder braid) before removing the

IC.

Replacement

1. Carefully insert the replacement IC in the circuit board.

2. Carefully bend each IC lead against the circuit foil pad and

solder it.

3. Clean the soldered areas with a small wire-bristle brush.

(It is not necessary to reapply acrylic coating to the areas).

"Small-Signal" Discrete Transistor

Removal/Replacement

1. Remove the defective transistor by clipping its leads as close as

possible to the component body.

2. Bend into a "U" shape the end of each of three leads remaining

on the circuit board.

3. Bend into a "U" shape the replacement transistor leads.

4. Connect the replacement transistor leads to the corresponding

leads extending from the circuit board and crimp the "U" with

long nose pliers to insure metal to metal contact then solder

each connection.

Power Output, Transistor Device

Removal/Replacement

1. Heat and remove all solder from around the transistor leads.

2. Remove the heat sink mounting screw (if so equipped).

3. Carefully remove the transistor from the heat sink of the circuit

board.

4. Insert new transistor in the circuit board.

5. Solder each transistor lead, and clip off excess lead.

6. Replace heat sink.

Diode Removal/Replacement

1. Remove defective diode by clipping its leads as close as

possible to diode body.

2. Bend the two remaining leads perpendicular y to the circuit

board.

3. Observing diode polarity, wrap each lead of the new diode

around the corresponding lead on the circuit board.

4. Securely crimp each connection and solder it.

5. Inspect (on the circuit board copper side) the solder joints of

the two "original" leads. If they are not shiny, reheat them and if

necessary, apply additional solder.

Fuse and Conventional Resistor

Removal/Replacement

1. Clip each fuse or resistor lead at top of the circuit board hollow

stake.

2. Securely crimp the leads of replacement component around

notch at stake top.

3. Solder the connections.

CAUTION: Maintain original spacing between the replaced

component and adjacent components and the circuit board to

prevent excessive component temperatures.

Circuit Board Foil Repair

Excessive heat applied to the copper foil of any printed circuit

board will weaken the adhesive that bonds the foil to the circuit

board causing the foil to separate from or "lift-off" the board. The

following guidelines and procedures should be followed whenever

this condition is encountered.

At IC Connections

To repair a defective copper pattern at IC connections use the

following procedure to install a jumper wire on the copper pattern

side of the circuit board. (Use this technique only on IC

connections).

1. Carefully remove the damaged copper pattern with a sharp

knife. (Remove only as much copper as absolutely necessary).

2. carefully scratch away the solder resist and acrylic coating (if

used) from the end of the remaining copper pattern.

3. Bend a small "U" in one end of a small gauge jumper wire and

carefully crimp it around the IC pin. Solder the IC connection.

4. Route the jumper wire along the path of the out-away copper

pattern and let it overlap the previously scraped end of the good

copper pattern. Solder the overlapped area and clip off any

excess jumper wire.

At Other Connections

Use the following technique to repair the defective copper pattern

at connections other than IC Pins. This technique involves the

installation of a jumper wire on the component side of the circuit

board.

1. Remove the defective copper pattern with a sharp knife.

Remove at least 1/4 inch of copper, to ensure that a hazardous

condition will not exist if the jumper wire opens.

2. Trace along the copper pattern from both sides of the pattern

break and locate the nearest component that is directly

connected to the affected copper pattern.

3. Connect insulated 20-gauge jumper wire from the lead of the

nearest component on one side of the pattern break to the lead

of the nearest component on the other side.

Carefully crimp and solder the connections.

CAUTION: Be sure the insulated jumper wire is dressed so the

it does not touch components or sharp edges.

Only for training and service purposes

1. Application range

This spec sheet is applied LCD TV with 32”, 37”, 42”, 47”, 55”

LA01U chassis.

2. Requirement for Test

Each part is tested as below without special appointment.

1) Temperature: 25 ºC ± 5 ºC

2) Relative Humidity: 65 ± 10 %

3) Power Voltage : Standard input voltage(100-240V~, 50/60Hz)

* Standard Voltage of each product is marked by models

4) Specification and performance of each parts are followed

each drawing and specification by part number in

accordance with BOM.

5) The receiver must be operated for about 5 minutes prior to

the adjustment.

3. Test method

1) Performance: LGE TV test method followed

2) Demanded other specification

- Safety : UL, CSA, IEC specification

- EMC: FCC, ICES, IEC specification

- 6 -

SPECIFICATION

NOTE : Specifications and others are subject to change without notice for improvement.

4. General Specification(TV)

No Item Specification Remark

1 Receivable System 1) ATSC / NTSC-M

2 Available Channel 1) VHF : 02 ~ 13

2) UHF : 14 ~ 69

3) DTV : 02 ~ 69

4) CATV : 01 ~ 135

5) CADTV : 01 ~ 135

3 Input Voltage 1) AC 100 - 240V~ 50/60Hz Mark : 110V, 60Hz (N.Ame

4 Market North America

5 Screen Size 32 inch Wide (1920x1080) FHD + 60Hz 32LK450-UB

37 inch Wide (1920x1080) FHD + 60Hz 37LK450-UB

42 inch Wide (1920x1080) FHD + 60Hz 42LK450-UB

47 inch Wide (1920x1080) FHD + 60Hz 47LK450-UB

6 Aspect Ratio 16:9

7 Tuning System FS

8 LCD Module T315HW04-V9 AUO 32LK450-UB

LC370WUE-SCA1 LGD 37LK450-UB

T370HW03-VN AUO 37LK450-UB

LC420WUE-SCA2 LGD 42LK450-UB

T420HW09-V0 AUO 42LK450-UB

LC470WUE-SCA2 LGD 47LK450-UB

9 Operating Environment Temp : 0 ~ 40 deg

Humidity : ~ 80 %

10 Storage Environment Temp : -20 ~ 60 deg

Humidity : -85 %

Only for training and service purposes

5. Chrominance & Luminance

No. Item Min Typ Max Unit Remarks

1 Max Luminance 320 400 cd/m232/37/42LK450-UB(AUO)

(Center 1-point / Full White Pattern) 360 500 37/42/47LK450-UB(LGD)

2 Luminance uniformity

3 Color coordinate RED X Typ. 0.64 Typ. 32LK450-UB(AUO)

(Default) Y -0.03 0.33 +0.03

GREEN X 0.29

Y 0.60

BLUE X 0.15

Y 0.06

WHITE X 0.28

Y 0.29

RED X Typ. 0.639 Typ. 37LK450-UB(LGD)

Y -0.03 0.334 +0.03

GREEN X 0.289

Y 0.606

BLUE X 0.145

Y 0.065

WHITE X 0.279

Y 0.292

RED X Typ. 0.640 Typ. 37LK450-UB(AUO)

Y -0.03 0.330 +0.03

GREEN X 0.281

Y 0.590

BLUE X 0.144

Y 0.060

WHITE X 0.280

Y 0.290

RED X Typ. 0.636 Typ. 42LK450-UB(LGD)

Y -0.03 0.335 +0.03

GREEN X 0.291

Y 0.603

BLUE X 0.146

Y 0.061

WHITE X 0.279

Y 0.292

RED X Typ. 0.640 Typ. 42LK450-UB(AUO)

Y -0.03 0.330 +0.03

GREEN X 0.281

Y 0.590

BLUE X 0.144

Y 0.060

WHITE X 0.280

Y 0.290

Only for training and service purposes

RED X Typ. 0.639 Typ. 47LK450-UB(LGD)

Y -0.03 0.334 +0.03

GREEN X 0.290

Y 0.606

BLUE X 0.146

Y 0.058

WHITE X 0.279

Y 0.292

4 Contrast ratio Module 3200 4000 32/37/42LK450(AUO)

1100 1450 42/47LK450-UB(LGD)

1100 1500 37LK450-UB

DCR 90,000:1 100,000:1 32/37/42/47LK450-UB(LGD)

30,000:1 40,000:1 32/37/42LK450-UB(AUO)

5 Color Temperature Cool 0.254 0.269 0.284

13000K The W/B Tolerance is ±0.015

0.258 0.273 0.288

for picture quality by DQA

Medium 0.270 0.285 0.300

9300K

0.278 0.293 0.308

Warm 0.298 0.313 0.324

6500K

0.314 0.329 0.344

Only for training and service purposes

6. Component Video Input (Y, CB/PB, CR/PR)

No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed

1. 720*480 15.73 60 13.5135 SDTV ,DVD 480I

2. 720*480 15.73 59.94 13.5 SDTV ,DVD 480I

3. 720*480 31.50 60 27.027 SDTV 480P

4. 720*480 31.47 59.94 27.0 SDTV 480P

5. 1280*720 45.00 60.00 74.25 HDTV 720P

6. 1280*720 44.96 59.94 74.176 HDTV 720P

7. 1920*1080 33.75 60.00 74.25 HDTV 1080I

8. 1920*1080 33.72 59.94 74.176 HDTV 1080I

9. 1920*1080 67.500 60 148.50 HDTV 1080P

10. 1920*1080 67.432 59.94 148.352 HDTV 1080P

11. 1920*1080 27.000 24.000 74.25 HDTV 1080P

12. 1920*1080 26.97 23.976 74.176 HDTV 1080P

13. 1920*1080 33.75 30.000 74.25 HDTV 1080P

14. 1920*1080 33.71 29.97 740176 HDTV 1080P

7. RGB Input (PC)

No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed

PC DDC

1. 640*350 31.468 70.09 25.17 EGA X

2. 720*400 31.469 70.08 28.32 DOS O

3. 640*480 31.469 59.94 25.17 VESA(VGA) O

4. 800*600 37.879 60.31 40.00 VESA(SVGA) O

5. 1024*768 48.363 60.00 65.00 VESA(XGA) O

6. 1280*768 47.776 59.870 79.5 CVT(WXGA) X

7. 1360*768 47.712 60.015 85.50 VESA(WXGA) X

8. 1280*1024 63.981 60.020 108.00 VESA(SXGA) O

9. 1920*1080 66.587 59.934 138.50 WUXGA O

Only for training and service purposes - 10 -

8. HDMI input (PC/DTV)

No Resolution H-freq(kHz) V-freq.(kHz) Pixel clock Proposed

PC DDC

1. 640*350 31.468 70.09 25.17 EGA X

2. 720*400 31.469 70.08 28.32 DOS O

3. 640*480 31.469 59.94 25.17 VESA(VGA) X

4. 800*600 37.879 60.31 40.00 VESA(SVGA) O

5. 1024*768 48.363 60.00 65.00 VESA(XGA) O

6. 1360*768 47.712 60.015 85.50 VESA (WXGA) O

7. 1280*1024 63.981 60.020 108.00 VESA (SXGA) O

8. 1920*1080 67.500 60.000 148.50 HDTV 1080P O

DTV

1 720*480 31.47 60 27.027 SDTV 480P O

2 720*480 31.47 59.94 27.00 SDTV 480P O

3 1280*720 45.00 60.00 74.25 HDTV 720P O

4 1280*720 44.96 59.94 74.176 HDTV 720P O

5 1920*1080 33.75 60.00 74.25 HDTV 1080I O

6 1920*1080 33.72 59.94 74.176 HDTV 1080I O

7 1920*1080 67.500 60 148.50 HDTV 1080P O

8 1920*1080 67.432 59.939 148.352 HDTV 1080P O

9 1920*1080 27.000 24.000 74.25 HDTV 1080P O

10 1920*1080 26.97 23.976 74.176 HDTV 1080P O

11 1920*1080 33.75 30.000 74.25 HDTV 1080P O

12 1920*1080 33.71 29.97 74.176 HDTV 1080P O

Only for training and service purposes - 11 -

ADJUSTMENT INSTRUCTION

1. Application range

This spec. sheet applies to LA01U Chassis applied LED LCD

TV all models manufactured in TV factory.

2. Specification

2.1 Because this is not a hot chassis, it is not necessary

to use an isolation transformer. However, the use of

isolation transformer will help protect test instrument.

2.2 Adjustment must be done in the correct order.

2.3 The adjustment must be performed in the

circumstance of 25±5°C of temperature and 65±10%

of relative humidity

2.4 The input voltage of the receiver must keep

100~240V~, 50/60Hz.

2.5 At first Worker must turn on the SET by using Power

Only key.

2.5 The receiver must be operated for about 5 minutes

prior to the adjustment when module is in the

circumstance of over 15.

In case of keeping module is in the circumstance of

0°C, it should be placed in the circumstance of above

15°C for 2 hours

In case of keeping module is in the circumstance of

below -20°C, it should be placed in the circumstance

of above 15°C for 3 hours.

• Caution

When a still image is displayed for 20 minutes or longer

(especially where W/B scale is strong. Digital pattern 13ch

and/or Cross hatch pattern 09ch), there can some

afterimage in the black level area.

3. Adjustment items

3.1 Board Level Adjustment

(1) Adjust 480i Comp1(ADC)

(2) EDID/DDC download

• Remark

- Above adjustment items can be also performed in Final

Assembly if needed. Adjustment items in both PCBA and

final assembly stages can be checked by using the

INSTART Menu 1.ADJUST CHECK.

3.2 Final Assembly adjustment

(1) White Balance adjustment

(2) RS-232C functionality check

(3) Factory Option setting per destination

(4) Shipment mode setting (IN-STOP)

3.3 Etc

(1) Ship-out mode

(2) Service Option Default

(3) USB Download(S/W Update, Option, Service only)

(4) ISP Download (Optional)

4. Board Level Adjustment

4.1. ADC Adjustment

4.1.1. Overview

• ADC adjustment is needed to find the optimum black level

and gain in Analog-to-Digital device and to compensate RGB

deviation.

4.1.2. Equipment & Condition

1) Jig (RS-232C protocol)

• Required equipment : Adjustment R/C

*Enter Service Mode by pushing “ADJ” key,

*Enter Internal ADC mode by pushing “G” key at “6. ADC

Calibration”

4.1.3. Adjustment

4.1.3.1 Adjustment method

• Using RS-232, adjust items listed in 3.1 in the other

shown in “4.1.3.3”

4.1.3.2 Adj. protocol

Ref.) ADC Adj. RS232C Protocol_Ver1.0

4.1.3.3. Adj. order

• aa 00 00 [Enter ADC adj. mode]

• xb 00 40 [Change input source to Component1(1080i)]

• ad 00 10 [Adjust 480i Comp1]

• xb 00 60 [Change input source to RGB(1024*768)]

• ad 00 10 [Adjust 1024*768 RGB]

• ad 00 90 End adj.

Ref) ADC adj. RS232C Protocol_Ver1.0

Protocol Command SetACK

Enter adj. mode aa 00 00 a 00 OK00x

Source change xb 00 40

xb 00 60 b 00 OK40x (Adjust 480i/1080p Comp1 )

b 00 OK60x (Adjust 1920*1080 RGB)

Begin adj. ad 00 10

Return adj. result OKx (Case of Success)

NGx (Case of Fail)

Read adj. data (main)

ad 00 20

(sub )

ad 00 21

(main)

000000000000000000000000007c007b006dx

(Sub)

000000070000000000000000007c00830077x

Confirm adj. ad 00 99 NG 03 00x (Fail)

NG 03 01x (Fail)

NG 03 02x (Fail)

OK 03 03x (Success)

End adj. aa 00 90 a 00 OK90x

Only for training and service purposes

4.2. EDID/DDC Download

4.2.1 Overview

•It is a VESA regulation. A PC or a MNT will display an

optimal resolution through information sharing without any

necessity of user input. It is a realization of “Plug and Play”.

4.2.2 Equipment

•Since embedded EDID data is used, EDID download JIG,

HDMI cable and D-sub cable are not need.

•Adjust remocon.

4.2.3 Download method

1) Press Adj. key on the Adj. R/C,

2) Select EDID D/L menu.

3) By pressing Enter key, EDID download will begin

4) If Download is successful, OK is display, but If Download is

failure, NG is displayed.

5) If Download is failure, Re-try downloads.

* Caution) When EDID Download, must remove RGB/HDMI

Cable.

4.2.4 EDID DATA

1) North America

# HDMI1-EDID (C/S : 03CC)

EDID Block 0

Block1

# HDMI2-EDID (C/S : 03BC)

Block0

Block1

# HDMI3-EDID (C/S : 03AC)

Block0

Block1

# RGB-EDID (C/S : 1C)

Block0

0 1 2 3 4 5 6 7 8 9 A B C D E F

_______________________________________________________

0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01

10 | 01 15 01 03 80 10 09 78 0A EE 91 A3 54 4C 99 26

20 | 0F 50 54 A1 08 00 81 80 61 40 45 40 31 40 01 01

30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C

40 | 45 00 A0 5A 00 00 00 1E 01 1D 00 72 51 D0 1E 20

50 | 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00 FD 00 39

60 | 3F 1F 52 10 00 0A 20 20 20 20 20 20 00 00 00 FC

70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 03

0 1 2 3 4 5 6 7 8 9 A B C D E F

_______________________________________________________

0 | 02 03 1C F1 47 10 22 20 05 84 03 02 23 09 07 07

10 | 67 03 0C 00 10 00 B8 2D E3 05 03 01 02 3A 80 18

20 | 71 38 2D 40 58 2C 04 05 A0 5A 00 00 00 1E 01 1D

30 | 80 18 71 1C 16 20 58 2C 25 00 A0 5A 00 00 00 9E

40 | 01 1D 00 72 51 D0 1E 20 6E 28 55 00 A0 5A 00 00

50 | 00 1E 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 A0 5A

60 | 00 00 00 18 26 36 80 A0 70 38 1F 40 30 20 25 00

70 | A0 5A 00 00 00 1A 00 00 00 00 00 00 00 00 00 CC

0 1 2 3 4 5 6 7 8 9 A B C D E F

______________________________________________________

0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01

10 | 01 15 01 03 80 10 09 78 0A EE 91 A3 54 4C 99 26

20 | 0F 50 54 A1 08 00 81 80 61 40 45 40 31 40 01 01

30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C

40 | 45 00 A0 5A 00 00 00 1E 01 1D 00 72 51 D0 1E 20

50 | 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00 FD 00 39

60 | 3F 1F 52 10 00 0A 20 20 20 20 20 20 00 00 00 FC

70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 03

0 1 2 3 4 5 6 7 8 9 A B C D E F

_______________________________________________________

0 | 02 03 1C F1 47 10 22 20 05 84 03 02 23 09 07 07

10 | 67 03 0C 00 20 00 B8 2D E3 05 03 01 02 3A 80 18

20 | 71 38 2D 40 58 2C 04 05 A0 5A 00 00 00 1E 01 1D

30 | 80 18 71 1C 16 20 58 2C 25 00 A0 5A 00 00 00 9E

40 | 01 1D 00 72 51 D0 1E 20 6E 28 55 00 A0 5A 00 00

50 | 00 1E 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 A0 5A

60 | 00 00 00 18 26 36 80 A0 70 38 1F 40 30 20 25 00

70 | A0 5A 00 00 00 1A 00 00 00 00 00 00 00 00 00 BC

0 1 2 3 4 5 6 7 8 9 A B C D E F

________________________________________________________

0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01

10 | 01 15 01 03 80 10 09 78 0A EE 91 A3 54 4C 99 26

20 | 0F 50 54 A1 08 00 81 80 61 40 45 40 31 40 01 01

30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C

40 | 45 00 A0 5A 00 00 00 1E 01 1D 00 72 51 D0 1E 20

50 | 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00 FD 00 39

60 | 3F 1F 52 10 00 0A 20 20 20 20 20 20 00 00 00 FC

70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 03

0 1 2 3 4 5 6 7 8 9 A B C D E F

_______________________________________________________

0 | 02 03 1C F1 47 10 22 20 05 84 03 02 23 09 07 07

10 | 67 03 0C 00 30 00 B8 2D E3 05 03 01 02 3A 80 18

20 | 71 38 2D 40 58 2C 04 05 A0 5A 00 00 00 1E 01 1D

30 | 80 18 71 1C 16 20 58 2C 25 00 A0 5A 00 00 00 9E

40 | 01 1D 00 72 51 D0 1E 20 6E 28 55 00 A0 5A 00 00

50 | 00 1E 8C 0A D0 8A 20 E0 2D 10 10 3E 96 00 A0 5A

60 | 00 00 00 18 26 36 80 A0 70 38 1F 40 30 20 25 00

70 | A0 5A 00 00 00 1A 00 00 00 00 00 00 00 00 00 AC

0 1 2 3 4 5 6 7 8 9 A B C D E F

_______________________________________________________

0 | 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01

10 | 01 15 01 03 68 10 09 78 0A EE 91 A3 54 4C 99 26

20 | 0F 50 54 A1 08 00 81 80 61 40 45 40 31 40 01 01

30 | 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C

40 | 45 00 A0 5A 00 00 00 1E 01 1D 00 72 51 D0 1E 20

50 | 6E 28 55 00 A0 5A 00 00 00 1E 00 00 00 FD 00 3A

60 | 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC

70 | 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 00 1C

Only for training and service purposes

5. Final Assembly Adjustment

5.1. White Balance Adjustment

5.1.1. Overview

5.1.1.1. W/B adj. Objective & How-it-works

(1) Objective: To reduce each Panel’s W/B deviation

(2) How-it-works: When R/G/B gain in the OSD is at 192, it

means the panel is at its Full Dynamic Range. In order to

prevent saturation of Full Dynamic range and data, one of

R/G/B is fixed at 192, and the other two is lowered to find

the desired value.

(3) Adj. condition: normal temperature

1) Surrounding Temperature: 25±5°C

2) Warm-up time: About 5 Min

3) Surrounding Humidity: 20% ~ 80%

5.1.2. Equipment

(1) Color Analyzer: CA-210 (NCG: CH 9 / WCG: CH12 / LED:

CH14)

(2) Adj. Computer (During auto adj., RS-232C protocol is

needed)

(3) Adjust Remocon

(4) Video Signal Generator MSPG-925F 720p/204-Gray

(Model: 217, Pattern: 49)

•Color Analyzer Matrix should be calibrated using CS-1000

5.1.3. Equipment connection

5.1.4. Adjustment Command (Protocol)

(1) RS-232C Command used during auto-adj.

Ex) wb 00 00 -> Begin white balance auto-adj.

wb 00 10 -> Gain adj.

ja 00 ff -> Adj. data

jb 00 c0

...

wb 00 1f -> Gain adj. complete

*(wb 00 20(start), wb 00 2f(end)) -> Off-set adj.

wb 00 ff ->End white balance auto adj.

(2) Adj. Map

Applied Model :

32/37/42/47LK450-UB, 32/42/47LK450-NA, 32/42/47LK451-

NB, 32/42/47LK452-NC,32LK330-UB, 32/42LK430-UA,

42/47/55LK520-UA, 32LK330-NB, 42LK430-NA,

42/47/55LK530-NA

5.1.5. Adjustment method

5.1.5.1 Auto WB calibration

1) Set TV in adj. mode using POWER ONLY (P-ONLY) key

2) Zero calibrate probe then place it on the center of the

Display

3) Connect Cable(RS-232C)

4) Select mode in adj. Program and begin adj.

5) When adj. is complete (OK Sing), check adj. status pre

mode (Cool, Medium, Warm)

6) Remove probe and RS-232C cable to complete adj.

•W/B Adj. must begin as start command “wb 00 00”, and

finish as end command “wb 00 ff”, and Adj. offset if need

5.1.5.2 Manual adj. method

1) Set TV in Adj. mode using POWER ON

2) Zero Calibrate the probe of Color Analyzer, then place it on

the center of LCD module within 10cm of the surface..

3) Press ADJ key -> EZ adjust using adj. R/C 6. White-

Balance then press the cursor to the right (KEYG). (When

KEY(G) is pressed 204 Gray(80IRE) internal pattern will be

displayed)

4) One of R Gain / G Gain / B Gain should be fixed at 192,

and the rest will be lowered to meet the desired value.

5) Adj. is performed in COOL, MEDIUM, WARM 3 modes of

color temperature.

•If internal pattern is not available, use RF input. In EZ Adj.

menu 6.White Balance, you can select one of 2 Test-pattern:

ON, OFF. Default is inner(ON). By selecting OFF, you can

adjust using RF signal in 204 Gray pattern.

Color Analyzer

Computer

Pattern Generator

RS-232C

Probe

Signal Source

* If TV internal pattern is used, not needed

Connection Diagram of Automatic Adjustment

RS-232C COMMAND

[CMD ID DATA] Explanation

Wb 00 00 Begin White Balance adj.

Wb 00 ff End White Balance adj. (internal pattern disappears )

Adj. item Command

(lower case ASCII) Data Range

(Hex.) Default

(Decimal)

CMD1 CMD2 MIN MAX

R Gain j g 00 C0 172

G Gain j h 00

i 00 C0 172

B Gain j C0 192

R Cut 64

G Cut 64

Cool

B Cut 64

Medium j a 00 C0 192

G Gain j b 00 C0 192

B Gain

R Gain

j c 00 C0 192

R Cut 64

G Cut 64

B Cut 64

R Gain j d 00 C0 192

G Gain j e 00 C0 192

B Gain j f 00 C0 172

R Cut 64

G Cut 64

Warm

B Cut 64

Only for training and service purposes

•Adj. condition and cautionary items

1) Lighting condition in surrounding area

Surrounding lighting should be lower 10 lux. Try to isolate

adj. area into dark surrounding.

2) Probe location : Color Analyzer (CA-210) probe should be

within 10cm and perpendicular of the module surface (80°~

100°)

3) Aging time

- After Aging Start, Keep the Power ON status during 5

Minutes.

- In case of LCD, Back-light on should be checked using no

signal or Full-white pattern.

5.1.6 Reference (White Balance Adj. coordinate and color

temperature)

(1) Luminance: 204 Gray, 80IRE

(2) Standard color coordinate and temperature using CS-1000

(over 26 inch)

•Standard color coordinate and temperature using CA-

210(CH 9)

5.2 HDCP (High-Bandwidth Digital

Contents Protection) SETTING

5.3 Option selection per country

5.3.1 Overview

•Option selection is only done for models in Non-USA North

America due to rating

•Applied model: LA01U Chassis applied None USA

model(CANADA, MEXICO)

5.3.2 Method

(1) Press ADJ key on the Adj. R/C, and then select Country

Group Menu

(2) Depending on destination, select KR or US, then on the

lower Country option, select US, CA, MX. Selection is

done using +, - KEY

5.4 Tool Option selection

•Method: Press Adj. key on the Adj. R/C, then select Tool

option.

5.5 Ship-out mode check (In-stop)

•After final inspection, press In-Stop key of the Adj. R/C and

check that the unit goes to Stand-by mode.

Mode Color Coordination Temp ∆UV

COOL 0.269 0.273 13000K 0.0000

MEDIUM 0.285 0.293 9300K 0.0000

WARM 0.313 0.329 6500K 0.0000

Mode Color Coordination Temp ∆UV

COOL 0.269±0.002 0.273±0.002 13000K 0.0000

MEDIUM 0.285±0.002 0.293±0.002 9300K 0.0000

WARM 0.313+0.002 0.329±0.002 6500K 0.0000

Model Tool 1 Tool 2 Tool 3 Tool 4 Tool 5 Menu

32LK450-UB 18056 19478 55308 2332 290 AUO

37LK450-UB 22152 19478 55306 2332 290 AUO

37LK450-UB 22144 19478 55307 2332 8450 LGD

42LK450-UB 26248 19478 55305 2332 290 AUO

42LK450-UB 26240 19478 55305 2332 8450 LGD

32LK430-UA 18024 19478 51209 2328 290 AUO

32LK430-UA 18016 19478 51209 2328 8482 LGD

42LK430-UA 26216 19478 51209 2328 290 AUO

42LK430-UA 26208 19478 51209 2328 8450 LGD

42LK430-NA 26208 19478 51209 2328 8194 LGD

26LK330-UB 13896 18966 51209 2328 290 AUO

26LK330-NB 18966 51209 2328 34 AUO

32LK330-UB 17992 18966 55307 2332 290 AUO

32LK330-UB 17984 18966 55305 2332 290 LGD

32LK330-NB 18966 51209 2328 34 LGD

32LK330-NB 18000 18966 51209 2328 34 IPS

42LK520-UA 26272 19478 55305 2332 8450 LGD

42LK530-NA 26304 19478 55305 2328 8194 LGD

47LK520-UA 34464 19478 55305 2332 8450 LGD

47LK530-NA 34496 19478 55305 2328 8194 LGD

55LK520-UA 46752 19478 55305 2332 8482 LGD

55LK530-NA 46784 19478 55305 2328 8226 LGD

32LK450-NA

32LK451-NB

32LK452-NC 18048 19478 55305 2328 8226 LGD

42LK450-NA

42LK451-NB

42LK452-NC 26240 19478 55305 2328 8194 LGD

47LK450-UB 34432 19478 55305 2332 8450 LGD

47LK450-NA

47LK451-NB

47LK452-NC 34432 19478 55305 2328 8194 LGD

13896

17984

Only for training and service purposes

6. GND and Hi-pot Test

6.1. Method

6.1.1. GND & HI-POT auto-check preparation

(1) Check the POWER CABLE and SIGNAL CABE

insertion condition

6.1.2. GND & HI-POT auto-check

(1) Pallet moves in the station. (POWER CORD / AV

CORD is tightly inserted)

(2) Connect the AV JACK Tester.

(3) Controller (GWS103-4) on.

(4) GND Test (Auto)

- If Test is failed, Buzzer operates.

- If Test is passed, execute next process (Hi-pot test).

(Remove A/V CORD from A/V JACK BOX)

(5) HI-POT test (Auto)

- If Test is failed, Buzzer operates.

- If Test is passed, GOOD Lamp on and move to next

process automatically.

6.2. Checkpoint

•TEST voltage

- GND: 1.5KV/min at 100mA

- SIGNAL: 3KV/min at 100mA

•TEST time: 1 second

•TEST POINT

- GND TEST = POWER CORD GND & SIGNAL CABLE

METAL GND

- Internal Pressure TEST = POWER CORD GND & LIVE &

NEUTRAL

•LEAKAGE CURRENT: At 0.5mArms

7. EYE-Q Check

Step 1) Turn on the TV.

Step 2) Press EYE button in adjust remote control.

Step 3) Stay 6 seconds with Eye Q sensor hidden located on

the front of the set.

Step 4) Check the “Sensor Data”on the screen and check

whether the value is lower thanafter 6 seconds, the

value does not go below 10, Eye Q sensor is not

working properly. Then, change the sensor.

Step 5) Remove hand from the Eye Q II sensor and stay for 6

seconds.

Step 6) Check whether the “Back Light (xxx)”value has risen

on the screen. If after 6 seconds and the value still

does not go high, the eye Q II sensor is not working

properly. Replace the sensor.

Only for training and service purposes

8.USB S/W Download (Option,

Service only)

1. Put the USB Stick to the USB socket

2. Automatically detecting update file in USB Stick

- If your downloaded program version in USB Stick is Low, it

didn’t work. But your downloaded version is High, USB data

is automatically detecting

3. Show the message “Copying files from memory”

4. Updating is starting.

5. Updating Completed, The TV will restart automatically

6. If your TV is turned on, check your updated version and

Tool option. (Explain the Tool option, next stage)

* If downloading version is more high than your TV have, TV

can lost all channel data. In this case, you have to channel

recover. if all channel data is cleared, you didn’t have a

DTV/ATV test on production line.

* After downloading, have to adjust TOOL OPTION again.

1. Push "IN-START" key in service remote controller.

2. Select "Tool Option 1" and Push “OK”button.

3. Punch in the number. (Each model has their number.)

Only for training and service purposes - 17 -

A21

A4 A10

900

300

200 800 400

540 521

530

810

910

120

511

510

* Set + Stand

* Stand Base + Body

LV1

EXPLODED VIEW

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These

parts are identified by in the Schematic Diagram and EXPLODED VIEW.

It is essential that these special safety parts should be replaced with the same components as

recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

IMPORTANT SAFETY NOTICE

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

CI_TS_DATA[1]

FE_TS_DATA[6]

PCM_A[0]

PCM_A[4]

PCM_D[6]

PCM_D[0]

PCM_A[12]

PCM_A[0]

PCM_A[13]

PCM_A[6]

PCM_A[7]

PCM_A[2]

PCM_A[4]

FE_TS_DATA[5]

PCM_A[1]

PCM_A[10]

CI_TS_DATA[5]

FE_TS_DATA[0]

PCM_A[5]

PCM_D[3]

PCM_A[3]

FE_TS_DATA[7]

PCM_A[3]

PCM_D[4]

FE_TS_DATA[3]

PCM_A[14]

CI_TS_DATA[7]

CI_TS_DATA[6]

FE_TS_DATA[1]

PCM_A[8]

FE_TS_DATA[2]

PCM_A[9]

PCM_A[6]

PCM_A[5]

PCM_A[7]

PCM_D[2]

PCM_D[7]

PCM_A[1]

PCM_A[11]

CI_TS_DATA[3]

FE_TS_DATA[4]

PCM_D[1]

PCM_D[5]

CI_TS_DATA[2]

CI_TS_DATA[0]

CI_TS_DATA[4]

NEC_SCL

/PF_WE

5V_DET_HDMI_2

/PCM_IRQA

R104

10K

OPT

/PF_WP

AUD_LRCH

AMP_SDA

R111 22

PWM2

R144

2.2K

RGB_DDC_SCL

PCM_D[0-7]

R143

3.3K

C106

8pF

OPT

R145

2.2K

/SPI_CS

FRC_PWM0

PWM0

R142

3.3K

AUD_SCK

FRC_SDA

DSUB_DET

/PF_CE0

AR102

IC104

M24M01-HRMN6TP

EEPROM_1MBIT_ST

VSS

5SDA

6SCL

7WP

8VCC

/PF_OE

CI_TS_DATA[0-7]

/PCM_OE

/F_RB

SCAN_BLK1/OPC_OUT

R125

OPT

R160

MODEL_OPT_2

/PF_WP

SIDEAV_DET

SCAN_BLK2

SPI_SDO

/F_RB

NEC_SDA

SC1/COMP1_DET

IC104-*1

AT24C1024BN-SH-T

EEPROM_1MBIT_ATMEL

GND

5SDA

6SCL

7WP

8VCC

I2C_SCL

TUNER_RESET

5V_DET_HDMI_4

SPI_SCK

R117

PCM_A[0-14]

PWM2

I2C_SDA

C102

10uF

R102

3.3K

SPI_SDI

DEMOD_RESET

USB1_CTL

+3.3V_Normal

R116

1K OPT

SC_RE1

C109

0.1uF

FE_TS_DATA[0-7]

RGB_DDC_SDA

CI_TS_VAL

R138 22

AR101

PF_ALE

CONTROL_ATTEN

IC102

NAND01GW3B2CN6E

NAND_FLASH_1G_NUMONYX

EAN60762401

26 NC_17

27 NC_18

28 NC_19

29 I/O0

30 I/O1

31 I/O2

32 I/O3

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VDD_2

38 NC_23

39 NC_24

40 NC_25

41 I/O4

42 I/O5

43 I/O6

44 I/O7

45 NC_26

46 NC_27

47 NC_28

48 NC_29

NC_3

NC_6

NC_10

NC_9

VSS_1

VDD_1

NC_8

NC_7

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

PCM_5V_CTL

S7_NEC_RXD

ERROR_OUT

R1081K

OPT

MODEL_OPT_1

R109 3.9K

R118

1K OPT

/PF_WE

IC102-*1

H27U1G8F2BTR-BC

NAND_FLASH_1G_HYNIX

EAN35669102

26 NC_17

27 NC_18

28 NC_19

29 I/O0

30 I/O1

31 I/O2

32 I/O3

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VCC_2

38 NC_23

39 NC_24

40 NC_25

41 I/O4

42 I/O5

43 I/O6

44 I/O7

45 NC_26

46 NC_27

47 NC_28

48 NC_29

ALE

NC_3

NC_6

CLE

NC_10

NC_9

VSS_1

VCC_1

NC_8

NC_7

R/B

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

I2C_SDA FE_TS_VAL_ERR

PWM1

R126

PWM1

R129 22

/PCM_REG

USB1_OCD

+5V_Normal

R105

OPT

FRC_RESET

C103

0.1uF

R121

PCM_A[0-7]

MODEL_OPT_3

C111

2.2uF

5V_DET_HDMI_1

R124

MODEL_OPT_0

/PCM_CE

R139 22

AUD_MASTER_CLK_0

+3.3V_Normal

/PCM_IORD

C105

0.1uF

/PF_CE1

P3904

12505WS-03A00

URSA_DEBUG

/PCM_WE

/PF_CE1

R158 100

OPT

R113

4.7K

C101

0.1uF

R14633

R123

OPT

+3.3V_Normal

SC_RE2

/PCM_CD

AR103

Q101

KRC103S

OPT

C107

0.1uF AMP_SCL

FRC_PWM1

R15133

FRC_SCL

R14733

CI_TS_CLK

R137 22

/PCM_WAIT

I2C_SDA

R132

10K

A_DIM

R157 100

R128 22

I2C_SCL

CI_TS_SYNC

I2C_SCL

/PF_CE0

R155

0OPT

R136 22

PWM_DIM

/PCM_IOWR

R133

10K

IC103

CAT24WC08W-T

VSS

5SDA

6SCL

7WP

8VCC

/PF_OE

PF_ALE

R107 1K

PCM_RST

S7_NEC_TXD

FE_TS_CLK

R159 100

OPT

MODEL_OPT_6

R106

AV_CVBS_DET

R140

R141

R135 22

C108

0.1uF

OPT

+3.3V_Normal

PWM0

/FLASH_WP

R156 10K

I2C_SDA

R134 22

AR104

FE_TS_SYNC

HP_DET

+3.3V_Normal

R127 4.7K

C104

8pF

OPT

PWM0

I2C_SCL

R115

R112 22

ET_RXER

/RST-PHY

AUD_MASTER_CLK R148

C112

100pF

50V

LGE101DC-R [S7R DIVX/MS10]

IC101-*4

S7R_DivX_MS10

NC_48

AE1

NC_78

AF16

NC_64

AF1

NC_50

AE3

NC_45

AD14

NC_34

AD3

NC_77

AF15

NC_65

AF2

NC_62

AE15

NC_33

AD2

NC_47

AD16

NC_46

AD15

NC_63

AE16

NC_66

AF3

NC_76

AF14

NC_32

AD1

NC_44

AD13

NC_61

AE14

NC_60

AE13

NC_51

AE4

NC_36

AD5

NC_67

AF4

NC_35

AD4

NC_49

AE2

NC_71

AF8

NC_40

AD9

NC_56

AE9

NC_72

AF9

NC_58

AE11

NC_69

AF6

NC_53

AE6

NC_74

AF11

NC_37

AD6

NC_43

AD12

NC_52

AE5

NC_75

AF12

NC_68

AF5

NC_59

AE12

NC_57

AE10

NC_70

AF7

NC_42

AD11

NC_38

AD7

NC_41

AD10

NC_54

AE7

NC_73

AF10

NC_39

AD8

NC_55

AE8

NC_12

Y11

GND_105

Y19

LVACLKP/LLV6P/BLUE[3] W26

LVACLKN/LLV6N/BLUE[2] W25

LVA0P/LLV3P/BLUE[9] U26

LVA0N/LLV3N/BLUE[8] U25

LVA1P/LLV4P/BLUE[7] U24

LVA1N/LLV4N/BLUE[6] V26

LVA2P/LLV5P/BLUE[5] V25

LVA2N/LLV5N/BLUE[4] V24

LVA3P/LLV7P/BLUE[1] W24

LVA3N/LLV7N/BLUE[0] Y26

LVA4P/LLV8P Y25

LVA4N/LLV8N Y24

LVBCLKP/LLV0P/GREEN[5] AC26

LVBCLKN/LLV0N/GREEN[4] AC25

LVB0P/RLV6P/RED[1] AA26

LVB0N/RLV6N/RED[0] AA25

LVB1P/RLV7P/GREEN[9] AA24

LVB1N/RLV7N/GREEN[8] AB26

LVB2P/RLV8P/GREEN[7] AB25

LVB2N/RLV8N/GREEN[6] AB24

LVB3P/LLV1P/GREEN[3] AC24

LVB3N/LLV1N/GREEN[2] AD26

LVB4P/LLV0P/GREEN[1] AD25

LVB4N/LLV0N/GREEN[0] AD24

RLV3P/RED[7] AD23

RLV3N/RED[6] AE23

RLV0P/LVSYNC AE26

RLV0N/LHSYNC AE25

RLV1N/LCK AF26

RLV2P/RED[9] AF25

RLV1P/LDE AE24

RLV2N/RED[8] AF24

RLV4P/RED[5] AF23

RLV4N/RED[4] AD22

RLV5P/RED[3] AE22

RLV5N/RED[2] AF22

TCON3/OE/GOE/GCLK2 AD19

TCON15/SCAN_BLK1 AE19

TCON18/CS7/GCLK5 AD21

TCON19/CS8/GCLK6 AE21

TCON11/CS5/HCON AF21

TCON10/CS4/OPT_N AD20

TCON9/CS3/OPT_P AE20

TCON16/WPWM AF20

TCON12/DPM AF19

TCON1/STV/GSP/VST AD18

TCON5/TP/SOE AE18

TCON14/SACN_BLK AF18

TCON21/CS10/VGH_ODD AB22

TCON20/CS9/VGH_EVEN AB23

TCON13/LEDON AC23

TCON17/CS6/GCLK4 AC22

NC_26 AB16

NC_19 AA14

NC_30 AC15

NC_15 Y16

NC_31 AC16

NC_29 AC14

NC_21 AA16

NC_20 AA15

NC_11 Y10

NC_17 AA11

NC_25 AB15

NC_24 AB14

LGE101C-R-1 [S7R BASIC]

IC101-*1

S7R_BASIC

NC_48

AE1

NC_78

AF16

NC_64

AF1

NC_50

AE3

NC_45

AD14

NC_34

AD3

NC_77

AF15

NC_65

AF2

NC_62

AE15

NC_33

AD2

NC_47

AD16

NC_46

AD15

NC_63

AE16

NC_66

AF3

NC_76

AF14

NC_32

AD1

NC_44

AD13

NC_61

AE14

NC_60

AE13

NC_51

AE4

NC_36

AD5

NC_67

AF4

NC_35

AD4

NC_49

AE2

NC_71

AF8

NC_40

AD9

NC_56

AE9

NC_72

AF9

NC_58

AE11

NC_69

AF6

NC_53

AE6

NC_74

AF11

NC_37

AD6

NC_43

AD12

NC_52

AE5

NC_75

AF12

NC_68

AF5

NC_59

AE12

NC_57

AE10

NC_70

AF7

NC_42

AD11

NC_38

AD7

NC_41

AD10

NC_54

AE7

NC_73

AF10

NC_39

AD8

NC_55

AE8

NC_12

Y11

GND_105

Y19

LVACLKP/LLV6P/BLUE[3] W26

LVACLKN/LLV6N/BLUE[2] W25

LVA0P/LLV3P/BLUE[9] U26

LVA0N/LLV3N/BLUE[8] U25

LVA1P/LLV4P/BLUE[7] U24

LVA1N/LLV4N/BLUE[6] V26

LVA2P/LLV5P/BLUE[5] V25

LVA2N/LLV5N/BLUE[4] V24

LVA3P/LLV7P/BLUE[1] W24

LVA3N/LLV7N/BLUE[0] Y26

LVA4P/LLV8P Y25

LVA4N/LLV8N Y24

LVBCLKP/LLV0P/GREEN[5] AC26

LVBCLKN/LLV0N/GREEN[4] AC25

LVB0P/RLV6P/RED[1] AA26

LVB0N/RLV6N/RED[0] AA25

LVB1P/RLV7P/GREEN[9] AA24

LVB1N/RLV7N/GREEN[8] AB26

LVB2P/RLV8P/GREEN[7] AB25

LVB2N/RLV8N/GREEN[6] AB24

LVB3P/LLV1P/GREEN[3] AC24

LVB3N/LLV1N/GREEN[2] AD26

LVB4P/LLV0P/GREEN[1] AD25

LVB4N/LLV0N/GREEN[0] AD24

RLV3P/RED[7] AD23

RLV3N/RED[6] AE23

RLV0P/LVSYNC AE26

RLV0N/LHSYNC AE25

RLV1N/LCK AF26

RLV2P/RED[9] AF25

RLV1P/LDE AE24

RLV2N/RED[8] AF24

RLV4P/RED[5] AF23

RLV4N/RED[4] AD22

RLV5P/RED[3] AE22

RLV5N/RED[2] AF22

TCON3/OE/GOE/GCLK2 AD19

TCON15/SCAN_BLK1 AE19

TCON18/CS7/GCLK5 AD21

TCON19/CS8/GCLK6 AE21

TCON11/CS5/HCON AF21

TCON10/CS4/OPT_N AD20

TCON9/CS3/OPT_P AE20

TCON16/WPWM AF20

TCON12/DPM AF19

TCON1/STV/GSP/VST AD18

TCON5/TP/SOE AE18

TCON14/SACN_BLK AF18

TCON21/CS10/VGH_ODD AB22

TCON20/CS9/VGH_EVEN AB23

TCON13/LEDON AC23

TCON17/CS6/GCLK4 AC22

NC_26 AB16

NC_19 AA14

NC_30 AC15

NC_15 Y16

NC_31 AC16

NC_29 AC14

NC_21 AA16

NC_20 AA15

NC_11 Y10

NC_17 AA11

NC_25 AB15

NC_24 AB14

LGE101C-R [S7R MS10]

IC101-*2

S7R_MS10

NC_48

AE1

NC_78

AF16

NC_64

AF1

NC_50

AE3

NC_45

AD14

NC_34

AD3

NC_77

AF15

NC_65

AF2

NC_62

AE15

NC_33

AD2

NC_47

AD16

NC_46

AD15

NC_63

AE16

NC_66

AF3

NC_76

AF14

NC_32

AD1

NC_44

AD13

NC_61

AE14

NC_60

AE13

NC_51

AE4

NC_36

AD5

NC_67

AF4

NC_35

AD4

NC_49

AE2

NC_71

AF8

NC_40

AD9

NC_56

AE9

NC_72

AF9

NC_58

AE11

NC_69

AF6

NC_53

AE6

NC_74

AF11

NC_37

AD6

NC_43

AD12

NC_52

AE5

NC_75

AF12

NC_68

AF5

NC_59

AE12

NC_57

AE10

NC_70

AF7

NC_42

AD11

NC_38

AD7

NC_41

AD10

NC_54

AE7

NC_73

AF10

NC_39

AD8

NC_55

AE8

NC_12

Y11

GND_105

Y19

LVACLKP/LLV6P/BLUE[3] W26

LVACLKN/LLV6N/BLUE[2] W25

LVA0P/LLV3P/BLUE[9] U26

LVA0N/LLV3N/BLUE[8] U25

LVA1P/LLV4P/BLUE[7] U24

LVA1N/LLV4N/BLUE[6] V26

LVA2P/LLV5P/BLUE[5] V25

LVA2N/LLV5N/BLUE[4] V24

LVA3P/LLV7P/BLUE[1] W24

LVA3N/LLV7N/BLUE[0] Y26

LVA4P/LLV8P Y25

LVA4N/LLV8N Y24

LVBCLKP/LLV0P/GREEN[5] AC26

LVBCLKN/LLV0N/GREEN[4] AC25

LVB0P/RLV6P/RED[1] AA26

LVB0N/RLV6N/RED[0] AA25

LVB1P/RLV7P/GREEN[9] AA24

LVB1N/RLV7N/GREEN[8] AB26

LVB2P/RLV8P/GREEN[7] AB25

LVB2N/RLV8N/GREEN[6] AB24

LVB3P/LLV1P/GREEN[3] AC24

LVB3N/LLV1N/GREEN[2] AD26

LVB4P/LLV0P/GREEN[1] AD25

LVB4N/LLV0N/GREEN[0] AD24

RLV3P/RED[7] AD23

RLV3N/RED[6] AE23

RLV0P/LVSYNC AE26

RLV0N/LHSYNC AE25

RLV1N/LCK AF26

RLV2P/RED[9] AF25

RLV1P/LDE AE24

RLV2N/RED[8] AF24

RLV4P/RED[5] AF23

RLV4N/RED[4] AD22

RLV5P/RED[3] AE22

RLV5N/RED[2] AF22

TCON3/OE/GOE/GCLK2 AD19

TCON15/SCAN_BLK1 AE19

TCON18/CS7/GCLK5 AD21

TCON19/CS8/GCLK6 AE21

TCON11/CS5/HCON AF21

TCON10/CS4/OPT_N AD20

TCON9/CS3/OPT_P AE20

TCON16/WPWM AF20

TCON12/DPM AF19

TCON1/STV/GSP/VST AD18

TCON5/TP/SOE AE18

TCON14/SACN_BLK AF18

TCON21/CS10/VGH_ODD AB22

TCON20/CS9/VGH_EVEN AB23

TCON13/LEDON AC23

TCON17/CS6/GCLK4 AC22

NC_26 AB16

NC_19 AA14

NC_30 AC15

NC_15 Y16

NC_31 AC16

NC_29 AC14

NC_21 AA16

NC_20 AA15

NC_11 Y10

NC_17 AA11

NC_25 AB15

NC_24 AB14

LGE101DC-R-1 [S7R DIVX]

IC101-*3

S7R_DivX

NC_48

AE1

NC_78

AF16

NC_64

AF1

NC_50

AE3

NC_45

AD14

NC_34

AD3

NC_77

AF15

NC_65

AF2

NC_62

AE15

NC_33

AD2

NC_47

AD16

NC_46

AD15

NC_63

AE16

NC_66

AF3

NC_76

AF14

NC_32

AD1

NC_44

AD13

NC_61

AE14

NC_60

AE13

NC_51

AE4

NC_36

AD5

NC_67

AF4

NC_35

AD4

NC_49

AE2

NC_71

AF8

NC_40

AD9

NC_56

AE9

NC_72

AF9

NC_58

AE11

NC_69

AF6

NC_53

AE6

NC_74

AF11

NC_37

AD6

NC_43

AD12

NC_52

AE5

NC_75

AF12

NC_68

AF5

NC_59

AE12

NC_57

AE10

NC_70

AF7

NC_42

AD11

NC_38

AD7

NC_41

AD10

NC_54

AE7

NC_73

AF10

NC_39

AD8

NC_55

AE8

NC_12

Y11

GND_105

Y19

LVACLKP/LLV6P/BLUE[3] W26

LVACLKN/LLV6N/BLUE[2] W25

LVA0P/LLV3P/BLUE[9] U26

LVA0N/LLV3N/BLUE[8] U25

LVA1P/LLV4P/BLUE[7] U24

LVA1N/LLV4N/BLUE[6] V26

LVA2P/LLV5P/BLUE[5] V25

LVA2N/LLV5N/BLUE[4] V24

LVA3P/LLV7P/BLUE[1] W24

LVA3N/LLV7N/BLUE[0] Y26

LVA4P/LLV8P Y25

LVA4N/LLV8N Y24

LVBCLKP/LLV0P/GREEN[5] AC26

LVBCLKN/LLV0N/GREEN[4] AC25

LVB0P/RLV6P/RED[1] AA26

LVB0N/RLV6N/RED[0] AA25

LVB1P/RLV7P/GREEN[9] AA24

LVB1N/RLV7N/GREEN[8] AB26

LVB2P/RLV8P/GREEN[7] AB25

LVB2N/RLV8N/GREEN[6] AB24

LVB3P/LLV1P/GREEN[3] AC24

LVB3N/LLV1N/GREEN[2] AD26

LVB4P/LLV0P/GREEN[1] AD25

LVB4N/LLV0N/GREEN[0] AD24

RLV3P/RED[7] AD23

RLV3N/RED[6] AE23

RLV0P/LVSYNC AE26

RLV0N/LHSYNC AE25

RLV1N/LCK AF26

RLV2P/RED[9] AF25

RLV1P/LDE AE24

RLV2N/RED[8] AF24

RLV4P/RED[5] AF23

RLV4N/RED[4] AD22

RLV5P/RED[3] AE22

RLV5N/RED[2] AF22

TCON3/OE/GOE/GCLK2 AD19

TCON15/SCAN_BLK1 AE19

TCON18/CS7/GCLK5 AD21

TCON19/CS8/GCLK6 AE21

TCON11/CS5/HCON AF21

TCON10/CS4/OPT_N AD20

TCON9/CS3/OPT_P AE20

TCON16/WPWM AF20

TCON12/DPM AF19

TCON1/STV/GSP/VST AD18

TCON5/TP/SOE AE18

TCON14/SACN_BLK AF18

TCON21/CS10/VGH_ODD AB22

TCON20/CS9/VGH_EVEN AB23

TCON13/LEDON AC23

TCON17/CS6/GCLK4 AC22

NC_26 AB16

NC_19 AA14

NC_30 AC15

NC_15 Y16

NC_31 AC16

NC_29 AC14

NC_21 AA16

NC_20 AA15

NC_11 Y10

NC_17 AA11

NC_25 AB15

NC_24 AB14

LGE101RC-R [S7R RM]

IC101-*5

S7R_RM

NC_48

AE1

NC_78

AF16

NC_64

AF1

NC_50

AE3

NC_45

AD14

NC_34

AD3

NC_77

AF15

NC_65

AF2

NC_62

AE15

NC_33

AD2

NC_47

AD16

NC_46

AD15

NC_63

AE16

NC_66

AF3

NC_76

AF14

NC_32

AD1

NC_44

AD13

NC_61

AE14

NC_60

AE13

NC_51

AE4

NC_36

AD5

NC_67

AF4

NC_35

AD4

NC_49

AE2

NC_71

AF8

NC_40

AD9

NC_56

AE9

NC_72

AF9

NC_58

AE11

NC_69

AF6

NC_53

AE6

NC_74

AF11

NC_37

AD6

NC_43

AD12

NC_52

AE5

NC_75

AF12

NC_68

AF5

NC_59

AE12

NC_57

AE10

NC_70

AF7

NC_42

AD11

NC_38

AD7

NC_41

AD10

NC_54

AE7

NC_73

AF10

NC_39

AD8

NC_55

AE8

NC_12

Y11

GND_105

Y19

LVACLKP/LLV6P/BLUE[3] W26

LVACLKN/LLV6N/BLUE[2] W25

LVA0P/LLV3P/BLUE[9] U26

LVA0N/LLV3N/BLUE[8] U25

LVA1P/LLV4P/BLUE[7] U24

LVA1N/LLV4N/BLUE[6] V26

LVA2P/LLV5P/BLUE[5] V25

LVA2N/LLV5N/BLUE[4] V24

LVA3P/LLV7P/BLUE[1] W24

LVA3N/LLV7N/BLUE[0] Y26

LVA4P/LLV8P Y25

LVA4N/LLV8N Y24

LVBCLKP/LLV0P/GREEN[5] AC26

LVBCLKN/LLV0N/GREEN[4] AC25

LVB0P/RLV6P/RED[1] AA26

LVB0N/RLV6N/RED[0] AA25

LVB1P/RLV7P/GREEN[9] AA24

LVB1N/RLV7N/GREEN[8] AB26

LVB2P/RLV8P/GREEN[7] AB25

LVB2N/RLV8N/GREEN[6] AB24

LVB3P/LLV1P/GREEN[3] AC24

LVB3N/LLV1N/GREEN[2] AD26

LVB4P/LLV0P/GREEN[1] AD25

LVB4N/LLV0N/GREEN[0] AD24

RLV3P/RED[7] AD23

RLV3N/RED[6] AE23

RLV0P/LVSYNC AE26

RLV0N/LHSYNC AE25

RLV1N/LCK AF26

RLV2P/RED[9] AF25

RLV1P/LDE AE24

RLV2N/RED[8] AF24

RLV4P/RED[5] AF23

RLV4N/RED[4] AD22

RLV5P/RED[3] AE22

RLV5N/RED[2] AF22

TCON3/OE/GOE/GCLK2 AD19

TCON15/SCAN_BLK1 AE19

TCON18/CS7/GCLK5 AD21

TCON19/CS8/GCLK6 AE21

TCON11/CS5/HCON AF21

TCON10/CS4/OPT_N AD20

TCON9/CS3/OPT_P AE20

TCON16/WPWM AF20

TCON12/DPM AF19

TCON1/STV/GSP/VST AD18

TCON5/TP/SOE AE18

TCON14/SACN_BLK AF18

TCON21/CS10/VGH_ODD AB22

TCON20/CS9/VGH_EVEN AB23

TCON13/LEDON AC23

TCON17/CS6/GCLK4 AC22

NC_26 AB16

NC_19 AA14

NC_30 AC15

NC_15 Y16

NC_31 AC16

NC_29 AC14

NC_21 AA16

NC_20 AA15

NC_11 Y10

NC_17 AA11

NC_25 AB15

NC_24 AB14

LGE107DC-R [S7MR DIVX/MS10]

IC101-*9

S7MR_DivX_MS10

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_REXT

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_GPIO0/UART_RX AB16

FRC_GPIO1 AA14

FRC_GPIO3 AC15

FRC_GPIO8 Y16

FRC_GPIO9/UART_TX AC16

FRC_GPIO10 AC14

FRC_I2CM_DA AA16

FRC_I2CM_CK AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107C-R-1 [S7MR BASIC]

IC101-*6

S7MR_BASIC

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_REXT

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_GPIO0/UART_RX AB16

FRC_GPIO1 AA14

FRC_GPIO3 AC15

FRC_GPIO8 Y16

FRC_GPIO9/UART_TX AC16

FRC_GPIO10 AC14

FRC_I2CM_DA AA16

FRC_I2CM_CK AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107C-R [S7MR MS10]

IC101-*7

S7MR_MS10

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_REXT

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_GPIO0/UART_RX AB16

FRC_GPIO1 AA14

FRC_GPIO3 AC15

FRC_GPIO8 Y16

FRC_GPIO9/UART_TX AC16

FRC_GPIO10 AC14

FRC_I2CM_DA AA16

FRC_I2CM_CK AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107DC-R-1 [S7MR DIVX]

IC101-*8

S7MR_DivX

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_REXT

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_GPIO0/UART_RX AB16

FRC_GPIO1 AA14

FRC_GPIO3 AC15

FRC_GPIO8 Y16

FRC_GPIO9/UART_TX AC16

FRC_GPIO10 AC14

FRC_I2CM_DA AA16

FRC_I2CM_CK AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107RC-R [S7MR RM]

IC101-*10

S7MR_RM

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_REXT

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_GPIO0/UART_RX AB16

FRC_GPIO1 AA14

FRC_GPIO3 AC15

FRC_GPIO8 Y16

FRC_GPIO9/UART_TX AC16

FRC_GPIO10 AC14

FRC_I2CM_DA AA16

FRC_I2CM_CK AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107DC-RP [S7M+ DIVX/MS10]

IC101

S7M-PLUS_DivX_MS10

PCM_D0

U22

PCM_D1

T21

PCM_D2

T22

PCM_D3

AB18

PCM_D4

AC18

PCM_D5

AC19

PCM_D6

AC20

PCM_D7

AC21

PCM_A0

U21

PCM_A1

V21

PCM_A2

Y22

PCM_A3

AA22

PCM_A4

R22

PCM_A5

R21

PCM_A6

T23

PCM_A7

T24

PCM_A8

AA23

PCM_A9

Y20

PCM_A10

AB17

PCM_A11

AA21

PCM_A12

U23

PCM_A13

Y23

PCM_A14

W23

PCM_REG_N

W22

PCM_OE_N

AA17

PCM_WE_N

V22

PCM_IORD_N

W21

PCM_IOWR_N

Y21

PCM_CE_N

AA20

PCM_IRQA_N

V23

PCM_CD_N

P23

PCM_WAIT_N

R23

PCM_RESET

P22

PCM_PF_CE0Z

AC17

PCM_PF_CE1Z

AB20

PCM_PF_OEZ

AA18

PCM_PF_WEZ

AB21

PCM_PF_ALE

AB19

PCM_PF_AD[15]

AD17

PCM_PF_RBZ

AA19

UART_TX2/GPIO65

M23

UART_RX2/GPIO64

N23

DDCR_DA/GPIO71

M22

DDCR_CK/GPIO72

N22

DDCA_DA/UART0_TX

DDCA_CK/UART0_RX

PWM0/GPIO66

K23

PWM1/GPIO67

K22

PWM2/GPIO68

G23

PWM3/GPIO69

G22

PWM4/GPIO70

G21

SAR0/GPIO31

SAR1/GPIO32

SAR2/GPIO33

SAR3/GPIO34

SAR4/GPIO35

GPIO143/TCON0 N21

GPIO145/TCON2 M21

GPIO147/TCON4 L22

GPIO149/TCON6 L21

GPIO151/TCON8 P21

GPIO36/UART3_RX K21

GPIO37/UART3_TX L23

GPIO38 K20

GPIO39 L20

GPIO40 M20

GPIO41 G20

GPIO42 G19

GPIO50/UART1_RX F20

GPIO51/UART1_TX F19

GPIO6/PM0/INT0 E7

GPIO7/PM1/PM_UART_TX D7

GPIO8/PM2 E11

GPIO9/PM3 G9

GPIO10/PM4 F9

GPIO11/PM5/PM_UART_RX/INT1 C5

PM_SPI_CS1/GPIO12/PM6 E8

PM_SPI_WP1/GPIO13/PM7 E9

PM_SPI_WP2/GPIO14/PM8/INT2 F7

GPIO15/PM9 F6

PM_SPI_CS2/GPIO16/PM10 D8

GPIO17/PM11/INT3 G12

GPIO18/PM12/INT4 F10

PM_SPI_CK/GPIO1 D9

GPIO0/PM_SPI_CZ D11

PM_SPI_DI/GPIO2 E10

PM_SPI_DO/GPIO3 D10

TS0_CLK AA9

TS0_VLD AA5

TS0_SYNC AA10

TS0_D0 AB5

TS0_D1 AC4

TS0_D2 Y6

TS0_D3 AA6

TS0_D4 W6

TS0_D5 AA7

TS0_D6 Y9

TS0_D7 AA8

TS1_CLK AC5

TS1_VLD AC6

TS1_SYNC AB6

TS1_D0 AC10

TS1_D1 AB10

TS1_D2 AC9

TS1_D3 AB9

TS1_D4 AC8

TS1_D5 AB8

TS1_D6 AC7

TS1_D7 AB7

MPIF_CLK D12

MPIF_CS_N D14

MPIF_BUSY E14

MPIF_D0 E12

MPIF_D1 F12

MPIF_D2 D13

MPIF_D3 E13

LGE107C-RP-1 [S7M+ BASIC]

IC101-*11

S7M-PLUS_BASIC

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_VSYNC_LIKE

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_SPI_CZ AB16

FRC_GPIO1 AA14

FRC_SPI1_CK AC15

FRC_GPIO8 Y16

FRC_SPI_DO AC16

FRC_SPI1_DI AC14

FRC_SPI_CK AA16

FRC_SPI_DI AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107C-RP [S7M+ MS10]

IC101-*12

S7M-PLUS_MS10

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_VSYNC_LIKE

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_SPI_CZ AB16

FRC_GPIO1 AA14

FRC_SPI1_CK AC15

FRC_GPIO8 Y16

FRC_SPI_DO AC16

FRC_SPI1_DI AC14

FRC_SPI_CK AA16

FRC_SPI_DI AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107DC-RP-1 [S7M+ DIVX]

IC101-*13

S7M-PLUS_DivX

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_VSYNC_LIKE

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_SPI_CZ AB16

FRC_GPIO1 AA14

FRC_SPI1_CK AC15

FRC_GPIO8 Y16

FRC_SPI_DO AC16

FRC_SPI1_DI AC14

FRC_SPI_CK AA16

FRC_SPI_DI AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

LGE107RC-RP [S7M+ RM]

IC101-*14

S7M-PLUS_RM

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_VSYNC_LIKE

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_SPI_CZ AB16

FRC_GPIO1 AA14

FRC_SPI1_CK AC15

FRC_GPIO8 Y16

FRC_SPI_DO AC16

FRC_SPI1_DI AC14

FRC_SPI_CK AA16

FRC_SPI_DI AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

IC102-*2

K9F1G08U0D-SCB0

NAND_FLASH_1G_SS

EAN61857001

26 NC_17

27 NC_18

28 NC_19

29 I/O0

30 I/O1

31 I/O2

32 I/O3

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VCC_2

38 NC_23

39 NC_24

40 NC_25

41 I/O4

42 I/O5

43 I/O6

44 I/O7

45 NC_26

46 NC_27

47 NC_28

48 NC_29

ALE

NC_3

NC_6

CLE

NC_10

NC_9

VSS_1

VCC_1

NC_8

NC_7

R/B

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

IC102-*3

TC58NVG0S3ETA0BBBH

NAND_FLASH_1G_TOSHIBA

EAN61508001

26 NC_17

27 NC_18

28 NC_19

29 I/O1

30 I/O2

31 I/O3

32 I/O4

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VCC_2

38 NC_23

39 NC_24

40 NC_25

41 I/O5

42 I/O6

43 I/O7

44 I/O8

45 NC_26

46 NC_27

47 NC_28

48 NC_29

ALE

NC_3

NC_6

CLE

NC_10

NC_9

VSS_1

VCC_1

NC_8

NC_7

RY/BY

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

GP3_Saturn7M Ver. 0.1

FLASH/EEPROM/GPIO

NAND FLASH MEMORY

/PF_CE0

H : Serial Flash

L : NAND Flash

/PF_CE1

H : 16 bit

L : 8 bit

from CI SLOT

Boot from SPI flash : 1’b0

Boot from NOR flash : 1’b1

TO SCART1

Addr:10101--

MIPS_no_EJ_NOR8 : 4’h3 (MIPS as host. No EJ PAD. Byte mode NAND flash.)

MIPS_EJ1_NOR8 : 4’h4 (MIPS as host. EJ use PAD1. Byte mode NAND flash.)

MIPS_EJ2_NOR8 : 4’h5 (MIPS as host. EJ use PAD2. Byte mode NAND flash.)

B51_Secure_no scramble : 4’hb (8051 as host. Internal SPI flash secure boot, no scramble)

B51_Sesure_scramble : 4’hc (8051 as host. Internal SPI flash secure boot with scarmble)

I2C

for SYSTEM/HDCP

EEPROM&URSA3

A0’h

(AUD_SCK, AUD_MASTER_CLK, PWM1, PWM0)

Internal demod out

/External demod in

$0.199

LD650 Scan

Delete Wireless

Delete /PIF_SPI_CS

DIMMING

HDCP EEPROM EEPROM

for SERIAL FLASH

S7R S7MR

S7MR-PLUS

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

R293 1K

OPT

TP202

R212 1K

PHM_OFF

C292 0.1uF

OPT

MVREF

10uFC4001

C204 0.047uF

TU_CVBS

D0+_HDMI1

C4044 0.1uF

OPT

C263

10uF

R4028 22 LED_DRIVER_D/L L207

BLM18PG121SN1D

SCART1_Lout

L226

BLM18SG700TN1D

C290

0.1uF

OPT

DSUB_R+

D1+_HDMI1

R213 100

OPT

D2+_HDMI1

VDD33_DVI

AVDD_DMPLL

AU33

AVDD_DDR0

C4056 0.1uF

C4060 2.2uF

10uFC276

R4029 22 LED_DRIVER_D/L

D1+_HDMI4

SIDE_USB_DM

DSUB_HSYNC

C4008

0.1uF

OPT

AU33

C4011 0.1uF

OPT

C285 0.1uF

D2-_HDMI2

AUD_LRCK

VDD_RSDS

C4004

0.1uF

OPT

C253

1uF

AVDD_DMPLL

L223

BLM18SG121TN1D

C210 1000pF VDD_RSDS

R4016 33

SC1_FB

L228

BLM18SG700TN1D

C4045 1uF

AU25

+1.26V_VDDC

D1-_HDMI4

D0-_HDMI4

C4042

0.1uF

OPT

HP_LOUT

CK+_HDMI4

C214 0.047uF

+2.5V_Normal

R4026

10K

C208 0.047uF

C4022

10uF

OPT

L227

BLM18PG121SN1D

L217

BLM18PG121SN1D

C4032

0.1uF

C245 2.2uF PC_R_IN

C231 0.047uF

AVDD25_PGA

R249 33

C286 0.1uF

OPT

R257 33

AVDD_DDR0

R236 0

NON_EU

C4026 0.1uF

D2+_HDMI2

C4028

0.1uF

VDD33_DVI

R201 100

OPT

TP209

D0-_HDMI1

C4019 0.1uF

OPT

AVDD_DMPLL

C4014 0.1uF

AUD_SCK

VDD33

HPD2

R288 100

TU_SCL

C242 2.2uF

C4061 10uF

FRC

C251 0.1uF

VDD33

C283 0.1uF

OPT

AVDD_DDR0

+3.3V_Normal

+2.5V_Normal

FRCVDDC

+1.5V_FRC_DDR

C291

0.1uF

FRC

COMP2_R_IN

VDD33

R231 68

RF_SWITCH_CTL

CEC_REMOTE_S7

+1.26V_VDDC

C238 2.2uF

MODEL_OPT_1

D1-_HDMI1

R292 22

FULL_NIM

AVDD2P5

R248 33

10uFC275

COMP2_Pb+

MODEL_OPT_4

C4043 0.1uF

R258 68

C279

10uF

FRC L210

BLM18PG121SN1D

FRC

AVDD2P5

MODEL_OPT_4

C223 0.047uF

SIDE_USB_DP

DDC_SDA_2

COMP2_DET

C4058 0.1uF

FRC

R226 1K

FRC

C4016 0.1uF

C209 0.047uF

+2.5V_Normal

+3.3V_Normal

R4019

R297 1K

50/60Hz LVDS

L206

BLM18PG121SN1D

C225 0.047uF

C221 0.047uF

C213 0.047uF

C4038

0.1uF

CK-_HDMI2

AV_R_IN

D2-_HDMI1

DSUB_B+

TP210

C222 0.047uF

C4046

0.1uF

SIDEAV_L_IN

SC1_R+/COMP1_Pr+

R242 68

L215

BLM18PG121SN1D

R202 100

BOOSTER_OPT

R210 100

OPT

R227 1K

NO_FRC

SC1_G+/COMP1_Y+

R211 1K

PHM_ON

R4014

1/16W

VDD33

C218 0.047uF

X201

24MHz

C4065

0.022uF

16V

C4062 0.1uF

D0-_HDMI2

C220 0.047uF

R4023

10K

TP201

C247 2.2uF OPT

R255 33

AU25

R250 33

MIU1VDDC

C240

0.1uF

FRC

R4018

FRC

MODEL_OPT_2

L204

BLM18PG121SN1D

AVDD_DDR0

D0+_HDMI4

+3.3V_Normal

+2.5V_Normal

SC1_SOG_IN

MODEL_OPT_5

C217 1000pF

SC1_B+/COMP1_Pb+

VDD33

L222

BLM18PG121SN1D

FRC

R4003 47

C4041 0.1uF

FRC

CK-_HDMI4

R4025 22

L203 5.6uH

CM2012F5R6KT

DDC_SDA_4

C288

0.1uF

R4020

10K

C4007 0.1uF

OPT

R215 1K

LCD

C4017

0.1uF

SCART1_Rout

AVDD2P5

R289 100

DDC_SDA_1

C4031 0.1uF

R207 1K

C239 2.2uF

C4005

0.1uF

LED_DRIVER_D/L_SDA

R291 22

FULL_NIM

R256 68 FRC_VDD33_DDR

TP203

R245 33

MIU0VDDC

AUD_LRCH

C4024 0.1uF

R237 33

HP_ROUT

R206 1K

FHD

C216 0.047uF

D1+_HDMI2

MODEL_OPT_5

C230 0.047uF

C244 2.2uF

C4003

0.1uF

+1.26V_VDDC

C4057 0.047uF

R239 33

C207 0.047uF

C4040 0.1uF

AVDD_DDR0

C289 10uF

C258 0.1uF

C4063 10uF

C298

0.1uF

OPT

R296 100

C234 2.2uF

OPT

C232 0.047uF

C295 0.1uF

IF_P_MSTAR

HPD4

MODEL_OPT_0IF_AGC_SEL

C227 0.047uF

C287

10uF

C262 27pF

D0+_HDMI2

TP211

C272

4.7uF

C4009

0.1uF

C294

0.1uF

C4020 0.1uF

OPT

D1-_HDMI2

AUD_MASTER_CLK_0

SPDIF_OUT

C211 0.047uF

+1.5V_DDR

C215 0.047uF

MODEL_OPT_6

TP205

SOC_RESET

C246 2.2uF OPT

TU_SIF

SC1/COMP1_R_IN

R287

FRC_AVDD

CK+_HDMI1

L219

BLM18PG121SN1D

C4066 10uF

AVDD_DDR0

AVDD2P5

10uFC293

OPT

AV_CVBS_IN

L221

BLM18PG121SN1D

FRC

DDC_SCL_4

LED_DRIVER_D/L_SCL

R4017

10K

OPT

R295 1K

DDC_SCL_2

HPD1

R233 68

C226 0.047uF

PC_L_IN

TP207

R4015

1/16W

R228 33

R246 33

IF_AGC_MAIN

C4012 0.1uF

R253 33

MODEL_OPT_3

AMP_SCL

D2-_HDMI4

FRCVDDC

AV_CVBS_IN2

VDD33

FRC_VDD33_DDR

D2+_HDMI4

AV_L_IN

C241

0.1uF

C4025 0.1uF

R294 1K

100/120Hz LVDS

C4027 0.1uF

R214 1K

OPT

DSUB_G+ C206 0.047uF

L213

BLM18PG121SN1D

OPT

R244 33

L212

BLM18PG121SN1D

NEC_SCL

+1.26V_VDDC

AVDD2P5

NEC_SDA

R240 68

DEMOD_SDA

IF_N_MSTAR

R229 68

FRC_LPLL

C233 0.047uF

SC1/COMP1_L_IN

+2.5V_Normal

R205

10K

FRC

L202

BLM18SG121TN1D

C212 0.047uF

R241 33

DTV/MNT_VOUT

L214

BLM18PG121SN1D

FRC

C219 0.047uF

C297

0.1uF

OPT

C281

10uF

OPT

TU_SDA

SC1_CVBS_IN

AVDD2P5

DEMOD_SCL

C4002

0.1uF

C4015

0.1uF

OPT

CK-_HDMI1 MIU0VDDC

TP208

C237 2.2uF

C257 0.1uF

AVDD_DDR_FRC

10uFC284

COMP2_L_IN

L205 5.6uH

CM2012F5R6KT

LNA2_CTL

AVDD_DDR_FRC

C229 0.047uF

R204 100

OPT

C282

10uF

FRC

+3.3V_Normal

+1.26V_VDDC

TP204

DDC_SCL_1

C205 0.047uF

R238 68

L209

BLM18PG121SN1D

R251 33

AVDD25_PGA

R4002 47

COMP2_Pr+

R203 100

RF_SW_OPT

COMP2_Y+

C236 2.2uF

10uFC228

R4006

10K

C4036

0.1uF

OPT

C4064

0.1uF

VDD33

SIDEAV_CVBS_IN

C4010

0.1uF

FRC

AMP_SDA

SIDEAV_R_IN

C243 2.2uF

FRC_RESET

R209 1K

CK+_HDMI2

C264

1000pF

OPT

C261 27pF

DSUB_VSYNC

C4023 0.1uF

R4024 22

AV_CVBS_IN2

R298 100

OPT

R254 68

C250 0.1uF

C224 1000pF

C203

1000pF

OPT

SC1_ID

C4059 2.2uF

FRC_AVDD

+3.3V_Normal

C249

4.7uF

MVREF

R230 33

C268

4.7uF

C4018

10uF

L225

BLM18SG700TN1D

FRC

C278

10uF

C256

0.1uF

FRC_LPLL

L211

BLM18PG121SN1D

C235 2.2uF

OPT

C296 0.1uF

TP206

MIU1VDDC

R232 33

R208 1K

R252 68

C280 0.1uF

ET_MDC

ET_TXD1

ET_CRS

ET_TXD0

ET_REF_CLK

ET_RXD1

ET_MDIO

ET_TX_EN

ET_RXD0

LGE107DC-RP [S7M+ DIVX/MS10]

IC101

S7M-PLUS_DivX_MS10

A_RXCP

A_RXCN

A_RX0P

A_RX0N

A_RX1P

A_RX1N

A_RX2P

A_RX2N

DDCDA_DA/GPIO24

DDCDA_CK/GPIO23

HOTPLUGA/GPIO19

B_RXCP

B_RXCN

B_RX0P

B_RX0N

B_RX1P

B_RX1N

B_RX2P

B_RX2N

DDCDB_DA/GPIO26

DDCDB_CK/GPIO25

HOTPLUGB/GPIO20

C_RXCP

AA2

C_RXCN

AA1

C_RX0P

AB1

C_RX0N

AA3

C_RX1P

AB3

C_RX1N

AB2

C_RX2P

AC2

C_RX2N

AC1

DDCDC_DA/GPIO28

AB4

DDCDC_CK/GPIO27

AA4

HOTPLUGC/GPIO21

AC3

D_RXCP

D_RXCN

D_RX0P

D_RX0N

D_RX1P

D_RX1N

D_RX2P

D_RX2N

DDCDD_DA/GPIO30

DDCDD_CK/GPIO29

HOTPLUGD/GPIO22

CEC/GPIO5

HSYNC0

VSYNC0

RIN0P

RIN0M

GIN0P

GIN0M

BIN0P

BIN0M

SOGIN0

HSYNC1

VSYNC1

RIN1P

RIN1M

GIN1P

GIN1M

BIN1P

BIN1M

SOGIN1

HSYNC2

RIN2P

RIN2M

GIN2P

GIN2M

BIN2P

BIN2M

SOGIN2

CVBS0P

CVBS1P

CVBS2P

CVBS3P

CVBS4P

CVBS5P

CVBS6P

CVBS7P

CVBS_OUT1

CVBS_OUT2

VCOM0

VIFP W2

VIFM W1

IP V2

IM V1

SSIF/SIFP Y2

SSIF/SIFM Y1

QP U3

QM V3

IFAGC Y5

RF_TAGC Y4

TGPIO0/UPGAIN U1

TGPIO1/DNGAIN U2

TGPIO2/I2C_CLK R3

TGPIO3/I2C_SDA T3

XTALIN T2

XTALOUT T1

SPDIF_IN/GPIO177 G14

SPDIF_OUT/GPIO178 G13

DM_P0 B7

DP_P0 A7

DM_P1 AF17

DP_P1 AE17

I2S_IN_BCK/GPIO175 F14

I2S_IN_SD/GPIO176 F13

I2S_IN_WS/GPIO174 F15

I2S_OUT_BCK/GPIO181 D20

I2S_OUT_MCK/GPIO179 E20

I2S_OUT_SD/GPIO182 D19

I2S_OUT_SD1/GPIO183 F18

I2S_OUT_SD2/GPIO184 E18

I2S_OUT_SD3/GPIO185 D18

I2S_OUT_WS/GPIO180 E19

LINE_IN_0L N1

LINE_IN_0R P3

LINE_IN_1L P1

LINE_IN_1R P2

LINE_IN_2L P4

LINE_IN_2R P5

LINE_IN_3L R6

LINE_IN_3R T6

LINE_IN_4L U5

LINE_IN_4R V5

LINE_IN_5L U6

LINE_IN_5R V6

LINE_OUT_0L U4

LINE_OUT_2L W3

LINE_OUT_3L W4

LINE_OUT_0R V4

LINE_OUT_2R Y3

LINE_OUT_3R W5

MIC_DET_IN R4

MICCM T5

MICIN R5

AUCOM T4

VRM P7

VAG R7

VRP P6

HP_OUT_1L R1

HP_OUT_1R R2

ET_RXD0 E21

ET_TXD0 E22

ET_RXD1 D21

ET_TXD1 F21

ET_REFCLK E23

ET_TX_EN D22

ET_MDC F22

ET_MDIO D23

ET_CRS F23

AVLINK F8

IRINT G8

TESTPIN K8

RESET A4

U3_RESET Y17

LGE107DC-RP [S7M+ DIVX/MS10]

IC101

S7M-PLUS_DivX_MS10

VDDC_1

H11

VDDC_2

H12

VDDC_3

H13

VDDC_4

H14

VDDC_5

H15

VDDC_6

J12

VDDC_7

J13

VDDC_8

J14

VDDC_9

J15

VDDC_10

J16

VDDC_11

L18

A_DVDD

H16

B_DVDD

K19

FRC_VDDC_0

L19

FRC_VDDC_1

M18

FRC_VDDC_2

M19

FRC_VDDC_3

N18

FRC_VDDC_4

N19

FRC_VDDC_5

N20

FRC_VDDC_6

P18

FRC_VDDC_7

P19

FRC_VDDC_8

P20

U3_DVDD_DDR

Y12

AVDD1P2

J11

DVDD_NODIE

AVDD2P5_ADC_1

AVDD2P5_ADC_2

AVDD25_REF

AVDD_AU25

PVDD_1

W15

PVDD_2

Y15

AVDD25_PGA

AVDD_NODIE

AVDD_DVI_1

AVDD_DVI_2

AVDD3P3_CVBS

AVDD_DMPLL

AVDD_AU33

AVDD_EAR33

AVDD33_T

VDDP_1

VDDP_2

VDDP_3

FRC_VD33_2_1

V20

FRC_VD33_2_2

W20

FRC_AVDD_RSDS_1

U19

FRC_AVDD_RSDS_2

U20

FRC_AVDD_RSDS_3

V19

FRC_AVDD

W19

FRC_AVDD_LPLL

U18

FRC_AVDD_MPLL

T20

FRC_VDD33_DDR

Y14

AVDD_MEMPLL

R19

FRC_AVDD_MEMPLL

W14

AVDD_DDR0_D_1

D15

AVDD_DDR0_D_2

D16

AVDD_DDR0_D_3

E15

AVDD_DDR0_D_4

E16

AVDD_DDR0_C

E17

AVDD_DDR1_D_1

F16

AVDD_DDR1_D_2

F17

AVDD_DDR1_D_3

G16

AVDD_DDR1_D_4

G17

AVDD_DDR1_C

H17

FRC_AVDD_DDR_D_1

AB11

FRC_AVDD_DDR_D_2

AB12

FRC_AVDD_DDR_D_3

AC11

FRC_AVDD_DDR_D_4

AC12

FRC_AVDD_DDR_C

AA12

MVREF

G15

NC_1

NC_2

GND_1 G18

GND_2 H9

GND_3 H10

GND_4 H18

GND_5 H19

GND_6 J10

GND_7 J17

GND_8 J18

GND_9 J19

GND_10 K9

GND_11 K10

GND_12 K11

GND_13 K12

GND_14 K13

GND_15 K14

GND_16 K15

GND_17 K16

GND_18 K17

GND_19 K18

GND_20 L9

GND_21 L10

GND_22 L11

GND_23 L12

GND_24 L13

GND_25 L14

GND_26 L15

GND_27 L16

GND_28 L17

GND_29 M9

GND_30 M10

GND_31 M11

GND_32 M12

GND_33 M13

GND_34 M14

GND_35 M15

GND_36 M16

GND_37 M17

GND_38 N10

GND_39 N11

GND_40 N12

GND_41 N13

GND_42 N14

GND_43 N15

GND_44 N16

GND_45 N17

GND_46 P10

GND_47 P11

GND_48 P12

GND_49 P13

GND_50 P14

GND_51 P15

GND_52 P16

GND_53 P17

GND_54 R10

GND_55 R11

GND_56 R12

GND_57 R13

GND_58 R14

GND_59 R15

GND_60 R16

GND_61 R17

GND_62 R18

GND_63 T10

GND_64 T11

GND_65 T12

GND_66 T13

GND_67 T14

GND_68 T15

GND_69 T16

GND_70 T17

GND_71 T18

GND_72 T19

GND_73 U10

GND_74 U11

GND_75 U12

GND_76 U13

GND_77 U14

GND_78 U15

GND_79 U16

GND_80 U17

GND_81 V7

GND_82 V8

GND_83 V9

GND_84 V10

GND_85 V11

GND_86 V12

GND_87 V13

GND_88 V14

GND_89 V15

GND_90 V16

GND_91 V17

GND_92 V18

GND_93 W7

GND_94 W8

GND_95 W9

GND_96 W10

GND_97 W11

GND_98 W12

GND_99 W13

GND_100 W16

GND_101 W17

GND_102 W18

GND_103 Y13

GND_104 Y18

GND_105 AA13

GND_106 AB13

GND_107 AC13

GND_FU J9

PGA_VCOM U9

GND_108 D17

GND_109 H23

GND_110 AF13

C277 0.1uF

C299 0.1uF

C4006 0.1uF

C4013 0.1uF

C248 0.047uF

D18

MODEL_OPT_3

reserved for FRC : LOW HIGH

FRC_AVDD:60mAAU33:31mA

TU/DEMOD_I2C

E18

AUDIO OUT

CVBS In/OUT

U5_EXTERNALBOOT :HIGH HIGH

MODEL_OPT_0

Close to MSTAR

FRC_MPLL:4mA

MODEL_OPT_5

AVDD_DDR1:55mA

AVDD_DMPLL/AVDD_NODIE:7.362mA

VDD33_T/VDDP/U3_VD33_2:47mA

100/120Hz LVDS

MODEL_OPT_6

DTV_IF

Normal Power 3.3V

LCD

AVDD_DDR_FRC:55mA

FRC_LPLL:13mA

MODEL OPTION

OLED

MODEL_OPT_2

Close to MSTAR

HDMI

B/T USB

Normal 2.5V

AVDD2P5/ADC2P5:162mA

RSDS Power OPT

DSUB

50/60Hz LVDS

PIN NAME

MODEL_OPT_1

I2S_I/F

VDD_RSDS:88mA

Close to MSTAR

NO FRC FRC

PIN NO.

DDR3 1.5V

AUDIO IN

U3_INTERNAL : HIGH LOW

VDDC 1.26V

LOW

H/P OUT

HIGH

AVDD_DDR0:55mA

Ready

VDDC : 2026mA

AVDD25_PGA:13mA

G19

MODEL_OPT_4

SCART1_RGB/COMP1

SIDE USB

FHD

default

MODEL OPTION

VDD33_DVI:163mA

FRC_VDD33_DDR:50mA

NO_FRC : LOW LOW

AVDD_MEMPLL:24mA

Delete CHB_CVBS_IN

Close to MSTAR

OPT_0

RSDS Power OPT

AU25:10mA

-->In case of GP2, This port was used for GIP/NON_GIP

ANALOG SIF

COMP2

PHM_ON

OPT_4

PHM_OFF --> This option is only applied in EU.

In case of NON_EU, default value set LOW.

GP2R

MAIN2, HW OPT 2

20101023

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

C-MDQU7

I2C_SDA

C-MDQU0

C-TMA12

FRC_MODEL_OPT_0

C-MA1

C-TMA0

RXA0-

C-MDQU7

C-TMDQL5

RXB0-

R338

OPT

VCC1.5V_U3_DDR

C-TMA6

C-MBA2

C-MA11

C317

0.1uF

L/DIM_SCLK

RXC0+

C-MDQU2

RXCCK+

RXACK-

RXA1+

C-TMA3

C-MDML

FRC_PWM1

C-MBA0

C-TMA0

R334 22

OPT

C-MDQL2

C-MA7

R307

RXA1-

RXD2+

C-TMCKB

C-TMDQU1

C306

0.1uF

C-TMCKE

R330

S7M-PLUS

C-TMA7

C-TMA12

R329

S7M-PLUS

C-MDQSU

RXD1+

R323

FRC

C-MA4

C304

1000pF

C-TMRESETB

R311

FRC_CONF0

+1.5V_FRC_DDR

R301

1K 1%

C-TMA4

C-MDQU5

RXD4+

C320

0.1uF

R325

S7M-R

RXA2-

FRC_SPI_SDI

C301

10uF

C-MDQU6

C-TMDQU5

RXCCK-

FRC_MODEL_OPT_2

R322

OPT

C-TMA5

+3.3V_Normal

C-TMDQU4

C-TMDQL0

C-TMDQU5

2D/3D_CTL

C-TMA11

C-MA5

VCC1.5V_U3_DDR

C-MODT

C-TMDMU

RXA2+

C-TMA10

AR308

AR309

C-MBA0

C-MDQSLB

C-MDQU2

RXB4-

FRC_SPI_SCK

C-MA2

C-MVREFDQ

C-TMDML

C-TMDQL6

C-MCK

C-MCKE

C-MDQL6

C-MCKB

C-TMCKB

R341

LVDS_S7M-PLUS

R316

RXB1-

C-TMA6

AR303

R317

820

S7M-R

C-TMDQU6

C-MA9

RXB1+

R321

S7M-PLUS

C-MA3

C305

0.1uF

C-TMDQL4

FRC_SPI_SDI

C-TMDQU6

C-MDQL4

C323

0.1uF

C-MA7

C-MDQL3

FRC_PWM1

R300 33

FRC_L/DIM

AR307

C-MDQSL

AR305

C-TMA9

C-TMDQU4

C-MDQSL

R314

RXA3+

C308

0.1uF

R327

S7M-PLUS

RXC4+

C322

0.1uF

R313

FRC_/SPI_CS

C-MRASB

C-TMDQL7

C-TMCKE

RXB4+

C-MDQL3

2D/3D_CTL

RXD3+

C-MA1

FRC_PWM0

RXDCK-

C-TMA3

RXD0+

C-TMRASB

RXC2-

C-TMDQU7

VCC1.5V_U3_DDR

C-TMDQU3

C-MDML

C316

0.1uF

RXB0+

C303

0.1uF

OPT

C-TMA8

C-TMA2

C-TMDQSL

C318

0.1uF

RXA3-

C310

0.1uF

C-TMDQL2

C-MA12

C-TMCK

R308

C-TMDQL1

C-TMA7

R340

LVDS_EXT_URSA5

FRC_MODEL_OPT_0

C-MDQU3

RXD4-

C314

1000pF

C-MA10

R343

OPT

FRC_CONF0

C-MDQU5

C-MVREFCA

C-TMBA0

R309

RXBCK-

C-TMDQL4

C-MBA1

RXA4+

C-MDQU6

C319

0.1uF

C-MWEB

C-TMCASB

C302

0.1uF

RXB2+

C-MDQU1

C-MA10

C-MBA2

C-MVREFCA

R310

C-MDQSLB

C321

0.1uF

C-TMDQL3

C-TMDQU0

VCC1.5V_U3_DDR

RXD1-

FRC_SDA

C-TMA10

C-MA4

R312

FRC_MODEL_OPT_1

C-MDQU4

RXC4-

C-TMBA2

FRC_CONF1

R306

150

OPT

C-MDMU

C-TMDQSUB

R303

240

R319

OPT

R335 22

OPT

C-TMODT

R305

1K 1%

C-TMDQSU

C-TMBA1

C-TMA9

C-MDQSU

C-TMDQSU

R328

S7M-PLUS

C-MDQU0

C-MCK

C-MCASB

C-TMBA1

C-MA12

C-MDQU4

C-MDQSUB C-TMDQU1

C-MA9

C313

0.1uF

C-TMDQU3

C-TMBA0

FRC_SPI_SDO

C-TMA1

C312

0.1uF

R336

L/DIM_EDGE_32/37

C-MRESETB

R318

FRC

RXC3-

C-TMDQSL

I2C_SCL

L301

C-TMDQL3

RXC1+

C-TMBA2

FRC_PWM0

RXA4-

C-MA6

C-MDQL7

FRC_/SPI_CS

R326 22 FRC

C-MA8

C-TMWEB

C-MDQL2

C-TMDQL2

C-TMDQU2

C-TMDQL7

C-TMA8

C311

0.1uF

C315

0.1uF

C-MCKB

C-MA11

C-MWEB

C-MA0

V_SYNC

AR301

R324

OPT

C-TMDML

C-MDQL0

C325

0.1uF

16V

FRC_SPI_SCK

C-MA5

C-MDQL1

C-MDQL6

C-TMCK

RXC1-

R349

10K

S7M-PLUS

RXC3+

RXACK+

C-MODT

RXB3+

RXD2-

R339

C-MDQSUB

RXBCK+

C-TMDQSLB

R331 22 FRC

R348 33

FRC_L/DIM

R304

1K 1%

R342

OPT

R337

L/DIM_EDGE_42/47/55

C-TMDQL1

C-TMA1

RXD3-

RXDCK+

C-TMRESETB

RXC2+

C-TMWEB

C-MRASB

C-MA3

L/DIM_MOSI

AR304

C-MA6

R332

FRC_L/DIM

RXD0-

C-TMA5

RXB3-

AR302

C307

0.1uF

+3.3V_Normal

C-TMA11

FRC_SPI_SDO

R320

FRC

C-TMDQL0

C309

0.1uF

R333

10K

C-TMDMU

C-TMCASB

C-MA8

C-TMA2

C-TMDQU7

C-MA2

C324

10uF

10V

C-TMA4

C-MCKE

C-MBA1

+3.3V_Normal

FRC_MODEL_OPT_2

C-MDQL0

C-TMDQL5

C-MDMU

VCC1.5V_U3_DDR

R350

4.7K

OPT

C-MVREFDQ

K4B1G1646E-HCH9000

IC301-*1

FRC_DDR_1333_SS

EAN60899001

A10/AP

A11

A12/BC

A13

NC_5

BA0

BA1

BA2

CKE

ODT

RAS

CAS

RESET

DQSL

DQSU

DML

DMU

DQL0

DQL1

DQL2

DQL3

DQL4

DQL5

DQL6

DQL7

DQU0

DQU1

DQU2

DQU3

DQU4

DQU5

DQU6

DQU7

VREFCA M8

VREFDQ H1

ZQ L8

VDD_1 B2

VDD_2 D9

VDD_3 G7

VDD_4 K2

VDD_5 K8

VDD_6 N1

VDD_7 N9

VDD_8 R1

VDD_9 R9

VDDQ_1 A1

VDDQ_2 A8

VDDQ_3 C1

VDDQ_4 C9

VDDQ_5 D2

VDDQ_6 E9

VDDQ_7 F1

VDDQ_8 H2

VDDQ_9 H9

NC_1 J1

NC_2 J9

NC_3 L1

NC_4 L9

NC_6 T7

VSS_1 A9

VSS_2 B3

VSS_3 E1

VSS_4 G8

VSS_5 J2

VSS_6 J8

VSS_7 M1

VSS_8 M9

VSS_9 P1

VSS_10 P9

VSS_11 T1

VSS_12 T9

VSSQ_1 B1

VSSQ_2 B9

VSSQ_3 D1

VSSQ_4 D8

VSSQ_5 E2

VSSQ_6 E8

VSSQ_7 F9

VSSQ_8 G1

VSSQ_9 G9

FRC_SCL

C-TMDQSUB

R302

1K 1%

+3.3V_Normal

AR306

C-MDQU3

C-MA0

R315

FRC_MODEL_OPT_1

C-MDQL5

RXA0+

C-TMDQSLB

C-MDQL7

C-TMDQL6

C-MDQL4

RXB2-

C-TMRASB

C-MRESETB

C-TMDQU0

C-MDQU1

FRC_CONF1

C-MDQL5

VCC1.5V_U3_DDR

C-TMODT

RXC0-

C-TMDQU2

C-MCASB

LGE107DC-RP [S7M+ DIVX/MS10]

IC101

S7M-PLUS_DivX_MS10

FRC_DDR3_A0/DDR2_NC

AE1

FRC_DDR3_A1/DDR2_A6

AF16

FRC_DDR3_A2/DDR2_A7

AF1

FRC_DDR3_A3/DDR2_A1

AE3

FRC_DDR3_A4/DDR2_CASZ

AD14

FRC_DDR3_A5/DDR2_A10

AD3

FRC_DDR3_A6/DDR2_A0

AF15

FRC_DDR3_A7/DDR2_A5

AF2

FRC_DDR3_A8/DDR2_A2

AE15

FRC_DDR3_A9/DDR2_A9

AD2

FRC_DDR3_A10/DDR2_A11

AD16

FRC_DDR3_A11/DDR2_A4

AD15

FRC_DDR3_A12/DDR2_A8

AE16

FRC_DDR3_BA0/DDR2_BA2

AF3

FRC_DDR3_BA1/DDR2_ODT

AF14

FRC_DDR3_BA2/DDR2_A12

AD1

FRC_DDR3_MCLK/DDR2_MCLK

AD13

FRC_DDR3_CKE/DDR2_RASZ

AE14

FRC_DDR3_MCLKZ/DDR2_MCLKZ

AE13

FRC_DDR3_ODT/DDR2_BA1

AE4

FRC_DDR3_RASZ/DDR2_WEZ

AD5

FRC_DDR3_CASZ/DDR2_CKE

AF4

FRC_DDR3_WEZ/DDR2_BA0

AD4

FRC_DDR3_RESETB/DDR2_A3

AE2

FRC_DDR3_DQSL/DDR2_DQS0

AF8

FRC_DDR3_DQSLB/DDR2_DQSB0

AD9

FRC_DDR3_DQSU/DDR2_DQS1

AE9

FRC_DDR3_DQSUB/DDR2_DQSB1

AF9

FRC_DDR3_DML/DDR2_DQ7

AE11

FRC_DDR3_DMU/DDR2_DQ11

AF6

FRC_DDR3_DQL0/DDR2_DQ6

AE6

FRC_DDR3_DQL1/DDR2_DQ0

AF11

FRC_DDR3_DQL2/DDR2_DQ1

AD6

FRC_DDR3_DQL3/DDR2_DQ2

AD12

FRC_DDR3_DQL4/DDR2_DQ4

AE5

FRC_DDR3_DQL5/DDR2_NC

AF12

FRC_DDR3_DQL6/DDR2_DQ3

AF5

FRC_DDR3_DQL7/DDR2_DQ5

AE12

FRC_DDR3_DQU0/DDR2_DQ8

AE10

FRC_DDR3_DQU1/DDR2_DQ14

AF7

FRC_DDR3_DQU2/DDR2_DQ13

AD11

FRC_DDR3_DQU3/DDR2_DQ12

AD7

FRC_DDR3_DQU4/DDR2_DQ15

AD10

FRC_DDR3_DQU5/DDR2_DQ9

AE7

FRC_DDR3_DQU6/DDR2_DQ10

AF10

FRC_DDR3_DQU7/DDR2_DQM1

AD8

FRC_DDR3_NC/DDR2_DQM0

AE8

FRC_VSYNC_LIKE

Y11

FRC_TESTPIN

Y19

ACKP/RLV3P/RED[3] W26

ACKM/RLV3N/RED[2] W25

A0P/RLV0P/RED[9] U26

A0M/RLV0N/RED[8] U25

A1P/RLV1P/RED[7] U24

A1M/RLV1N/RED[6] V26

A2P/RLV2P/RED[5] V25

A2M/RLV2N/RED[4] V24

A3P/RLV4P/RED[1] W24

A3M/RLV4N/RED[0] Y26

A4P/RLV5P/GREEN[9] Y25

A4M/RLV5N/GREEN[8] Y24

BCKP/TCON13/GREEN[1] AC26

BCKM/TCON12/GREEN[0] AC25

B0P/RLV6P/GREEN[7] AA26

B0M/RLV6N/GREEN[6] AA25

B1P/RLV7P/GREEN[5] AA24

B1M/RLV7N/GREEN[4] AB26

B2P/RLV8P/GREEN[3] AB25

B2M/RLV8N/GREEN[2] AB24

B3P/TCON11/BLUE[9] AC24

B3M/TCON10/BLUE[8] AD26

B4P/TCON9/BLUE[7] AD25

B4M/TCON8/BLUE[6] AD24

CCKP/LLV3P AD23

CCKM/LLV3N AE23

C0P/LLV0P/BLUE[5] AE26

C0M/LLV0N/BLUE[4] AE25

C1P/LLV1P/BLUE[3] AF26

C1M/LLV1N/BLUE[2] AF25

C2P/LLV2P/BLUE[1] AE24

C2M/LLV2N/BLUE[0] AF24

C3P/LLV4P AF23

C3M/LLV4N AD22

C4P/LLV5P AE22

C4M/LLV5N AF22

DCKP/TCON5 AD19

DCKM/TCON4 AE19

D0P/LLV6P AD21

D0M/LLV6N AE21

D1P/LLV7P AF21

D1M/LLV7N AD20

D2P/LLV8P AE20

D2M/LLV8N AF20

D3P/TCON3 AF19

D3M/TCON2 AD18

D4P/TCON1 AE18

D4M/TCON0 AF18

GPIO0/TCON15/HSYNC/VDD_ODD AB22

GPIO1/TCON14/VSYNC/VDD_EVEN AB23

GPIO2/TCON7/LDE/GCLK4 AC23

GPIO3/TCON6/LCK/GCLK2 AC22

FRC_SPI_CZ AB16

FRC_GPIO1 AA14

FRC_SPI1_CK AC15

FRC_GPIO8 Y16

FRC_SPI_DO AC16

FRC_SPI1_DI AC14

FRC_SPI_CK AA16

FRC_SPI_DI AA15

FRC_I2CS_DA Y10

FRC_I2CS_CK AA11

FRC_PWM0 AB15

FRC_PWM1 AB14

H5TQ1G63DFR-H9C

IC301

FRC_DDR_1333_HYNIX

EAN61828901

A0 N3

A1 P7

A2 P3

A3 N2

A4 P8

A5 P2

A6 R8

A7 R2

A8 T8

A9 R3

A10/AP L7

A11 R7

A12/BC N7

A13 T3

NC_5 M7

BA0 M2

BA1 N8

BA2 M3

CK J7

CK K7

CKE K9

CS L2

ODT K1

RAS J3

CAS K3

WE L3

RESET T2

DQSL F3

DQSL G3

DQSU C7

DQSU B7

DML E7

DMU D3

DQL0 E3

DQL1 F7

DQL2 F2

DQL3 F8

DQL4 H3

DQL5 H8

DQL6 G2

DQL7 H7

DQU0 D7

DQU1 C3

DQU2 C8

DQU3 C2

DQU4 A7

DQU5 A2

DQU6 B8

DQU7 A3

VREFCA

VREFDQ

VDD_1

VDD_2

VDD_3

VDD_4

VDD_5

VDD_6

VDD_7

VDD_8

VDD_9

VDDQ_1

VDDQ_2

VDDQ_3

VDDQ_4

VDDQ_5

VDDQ_6

VDDQ_7

VDDQ_8

VDDQ_9

NC_1

NC_2

NC_3

NC_4

NC_6

VSS_1

VSS_2

VSS_3

VSS_4

VSS_5

VSS_6

VSS_7

VSS_8

VSS_9

VSS_10

VSS_11

VSS_12

VSSQ_1

VSSQ_2

VSSQ_3

VSSQ_4

VSSQ_5

VSSQ_6

VSSQ_7

VSSQ_8

VSSQ_9

H5TQ1G63DFR-PBC

IC301-*2

FRC_DDR_1600_HYNIX

EAN61829001

A10/AP

A11

A12/BC

A13

A15

BA0

BA1

BA2

CKE

ODT

RAS

CAS

RESET

DQSL

DQSU

DML

DMU

DQL0

DQL1

DQL2

DQL3

DQL4

DQL5

DQL6

DQL7

DQU0

DQU1

DQU2

DQU3

DQU4

DQU5

DQU6

DQU7

VREFCA M8

VREFDQ H1

ZQ L8

VDD_1 B2

VDD_2 D9

VDD_3 G7

VDD_4 K2

VDD_5 K8

VDD_6 N1

VDD_7 N9

VDD_8 R1

VDD_9 R9

VDDQ_1 A1

VDDQ_2 A8

VDDQ_3 C1

VDDQ_4 C9

VDDQ_5 D2

VDDQ_6 E9

VDDQ_7 F1

VDDQ_8 H2

VDDQ_9 H9

NC_1 J1

NC_2 J9

NC_3 L1

NC_4 L9

NC_6 T7

VSS_1 A9

VSS_2 B3

VSS_3 E1

VSS_4 G8

VSS_5 J2

VSS_6 J8

VSS_7 M1

VSS_8 M9

VSS_9 P1

VSS_10 P9

VSS_11 T1

VSS_12 T9

VSSQ_1 B1

VSSQ_2 B9

VSSQ_3 D1

VSSQ_4 D8

VSSQ_5 E2

VSSQ_6 E8

VSSQ_7 F9

VSSQ_8 G1

VSSQ_9 G9

IC302

W25X20BVSNIG

S7M-PLUS_S_FLASH_2MBIT_WIN

GND

5DIO

6CLK

7HOLD

8VCC

R317-*1

4.7K

S7M-PLUS

K4B1G1646G-BCH9

IC301-*3

FRC_DDR_1333_SS_NEW

EAN61857101

A10/AP

A11

A12/BC

A13

NC_5

BA0

BA1

BA2

CKE

ODT

RAS

CAS

RESET

DQSL

DQSU

DML

DMU

DQL0

DQL1

DQL2

DQL3

DQL4

DQL5

DQL6

DQL7

DQU0

DQU1

DQU2

DQU3

DQU4

DQU5

DQU6

DQU7

VREFCA M8

VREFDQ H1

ZQ L8

VDD_1 B2

VDD_2 D9

VDD_3 G7

VDD_4 K2

VDD_5 K8

VDD_6 N1

VDD_7 N9

VDD_8 R1

VDD_9 R9

VDDQ_1 A1

VDDQ_2 A8

VDDQ_3 C1

VDDQ_4 C9

VDDQ_5 D2

VDDQ_6 E9

VDDQ_7 F1

VDDQ_8 H2

VDDQ_9 H9

NC_1 J1

NC_2 J9

NC_3 L1

NC_4 L9

NC_6 T7

VSS_1 A9

VSS_2 B3

VSS_3 E1

VSS_4 G8

VSS_5 J2

VSS_6 J8

VSS_7 M1

VSS_8 M9

VSS_9 P1

VSS_10 P9

VSS_11 T1

VSS_12 T9

VSSQ_1 B1

VSSQ_2 B9

VSSQ_3 D1

VSSQ_4 D8

VSSQ_5 E2

VSSQ_6 E8

VSSQ_7 F9

VSSQ_8 G1

VSSQ_9 G9

NT5CB64M16DP-CF

IC301-*4

FRC_DDR_1333_NANYA_NEW

EAN61857201

A10/AP

A11

A12

NC_6

NC_5

BA0

BA1

BA2

CKE

ODT

RAS

CAS

RESET

DQSL

DQSU

DML

DMU

DQL0

DQL1

DQL2

DQL3

DQL4

DQL5

DQL6

DQL7

DQU0

DQU1

DQU2

DQU3

DQU4

DQU5

DQU6

DQU7

VREFCA M8

VREFDQ H1

ZQ L8

VDD_1 B2

VDD_2 D9

VDD_3 G7

VDD_4 K2

VDD_5 K8

VDD_6 N1

VDD_7 N9

VDD_8 R1

VDD_9 R9

VDDQ_1 A1

VDDQ_2 A8

VDDQ_3 C1

VDDQ_4 C9

VDDQ_5 D2

VDDQ_6 E9

VDDQ_7 F1

VDDQ_8 H2

VDDQ_9 H9

NC_1 J1

NC_2 J9

NC_3 L1

NC_4 L9

NC_7 T7

VSS_1 A9

VSS_2 B3

VSS_3 E1

VSS_4 G8

VSS_5 J2

VSS_6 J8

VSS_7 M1

VSS_8 M9

VSS_9 P1

VSS_10 P9

VSS_11 T1

VSS_12 T9

VSSQ_1 B1

VSSQ_2 B9

VSSQ_3 D1

VSSQ_4 D8

VSSQ_5 E2

VSSQ_6 E8

VSSQ_7 F9

VSSQ_8 G1

VSSQ_9 G9

$ 0.17

CLose to Saturn7M IC

(FRC_CONF0)

Close to DDR Power Pin

CLose to DDR3

(FRC_CONF1,FRC_PWM1, FRC_PWM0)

DDR3 1.5V By CAP - Place these Caps near Memory

3’d5 : boot from internal SRAM

3’d6 : boot from EEPROM

3’d7 : boot form SPI flash

HIGH : I2C ADR = B8

LOW : I2C ADR = B4

GP2R

FRC_DDR

20101023

Other manuals for 42LK450

This manual suits for next models

Table of contents

Popular LCD TV manuals by other brands

Samsung

Samsung LN46M52BD Owner's instructions

Dell

Dell W2600 owner's manual

Haier

Haier LE40B650CF instruction manual

Insignia

Insignia NS-L55X-10A user guide

Panasonic

Panasonic Viera TC-L32C5 operating instructions

Coby

Coby TF-TV2608 Specifications

Sony

Sony BRAVIA KDL-26S2000 Service manual

August

August DA700B user manual

Philips

Philips 22PFL3415H/12 quick start

Philips

Philips 22PDL49X6H user manual

Vidao

Vidao 22A60 user manual

Sharp

Sharp LC-32SB220U Operation manual

Panasonic

Panasonic TH-L32C22T Service manual

Grundig

Grundig AMIRA 26 LXW 68-7515 manual

Samsung

Samsung UA32K5500 user manual

Philips

Philips 40PFL3008T/12 user manual

Samsung

Samsung LN-S4095D Owner's instructions

Magnasonic

Magnasonic 32612MHD instruction manual

LG 42LK450 User manual

Popular LCD TV manuals by other brands
