LG LB55 User manual

www.lg.com
Please read this manual carefully before operating your set
and retain it for future reference.
LB55**
LB56**
LB62**
P/NO : MFL68003805 (1402-REV00)
Printed in Korea
OWNER’S MANUAL
LED TV*
* LG LED TV applies LCD screen with LED backlights.
*MFL68003805*

A-2 TABLE OF CONTENTS
TABLE OF CONTENTS
COMMON
LANGUAGE
COMMON
A-3 SETTING UP THE TV
A-3 Attaching the stand
A-4 MAKING CONNECTIONS
A-4 Antenna connection
A-5 Satellite dish connection
A-6 Euro Scart connection
A-8 Other connections
LANGUAGE LIST
English
Svenska
Norsk
Dansk
Suomi
B-1 SPECIFICATIONS
B-6 REGULATORY

A-3
SETTING UP THE TV
SETTING UP THE TV
Image shown may differ from your TV.
Attaching the stand
(Only LB55**, LB56**-ZE / ZC, LB62**-ZA / ZB)
4EA
M4 x L14
(Only 32LB55**,
32LB56**-ZE / ZC,
32LB62**-ZA / ZB)
M4 x L20
1
1
2
4EA
M4 x L14
(Only 32LB56**-ZT / ZQ,
32LB62**-ZE)
M4 x L20
2
A Stand Base
B Stand Base
A Stand Base
B Stand Base
yWhen attaching the stand to the TV set, place
the screen facing down on a cushioned table or
flat surface to protect the screen from scratches.
CAUTION
(Only LB56**-ZT / ZQ, LB62**-ZE)

A-4 MAKING CONNECTIONS
MAKING CONNECTIONS
This section on MAKING CONNECTIONS
mainly uses diagrams for the 47LB561V models.
Antenna connection
ANTENNA /
CABLE IN
Wall Antenna
Socket
*Not Provided
English
Connect the TV to a wall antenna socket with an RF
cable (75 Ω).
yUse a signal splitter to use more than 2 TVs.
yIf the image quality is poor, install a signal
amplifier properly to improve the image quality.
yIf the image quality is poor with an antenna
connected, try to realign the antenna in the
correct direction.
yAn antenna cable and converter are not supplied.
ySupported DTV Audio: MPEG, Dolby Digital,
Dolby Digital Plus, HE-AAC
NOTE
Svenska
Anslut TV:n till ett antennuttag i väggen med en
RF-kabel (75 Ω).
yAnvänd en signalfördelare om du använder fler
än två TV-apparater.
yOm bildkvaliteten är dålig kan du installera en
signalförstärkare för att förbättra bildkvaliteten.
yOm bildkvaliteten är dålig när en antenn är
ansluten ska du rikta åt rätt håll.
yAntennkabel och omvandlare medföljer ej.
yDTV-ljud som stöds: MPEG, Dolby Digital, Dolby
Digital Plus, HE-AAC
Obs!
Norsk
Koble TV-en til en antennekontakt på veggen med en
RF-kabel (75 Ω).
yBruk en signalsplitter hvis du vil bruke mer enn to
TV-er.
yHvis bildekvaliteten er dårlig, installerer du en
signalforsterker for å forbedre bildekvaliteten.
yHvis bildekvaliteten er dårlig når en antenne er
koblet til, justerer du antennen i riktig retning.
yAntennekabel og -omformer følger ikke med.
yStøttet DTV-lyd: MPEG, Dolby Digital, Dolby
Digital Plus, HE-AAC
MERK
Dansk
Slut TV’et til et vægantennestik med et RF-kabel
(75 Ω).
yHvis der skal bruges to TV’er, skal du bruge en
signalfordeler.
yHvis billedkvaliteten er dårlig, kan du
forbedre billedkvaliteten ved at installere en
signalforstærker.
yHvis billedkvaliteten er dårlig med en tilsluttet
antenne, kan du prøve at flytte på antennen til
den peger i den korrekte retning.
yDer følger ikke antennekabel og omsætter med
apparatet.
yUnderstøttet DTV-lyd: MPEG, Dolby Digital,
Dolby Digital Plus, HE-AAC
BEMÆRK

A-5
MAKING CONNECTIONS
Suomi
Kytke TV antennipistorasiaan RF-kaapelilla (75 Ω).
yKäytä antennijakajaa, jos käytät useampaa kuin
kahta televisiota.
yJos kuvanlaatu on heikko, asenna
signaalinvahvistin oikein, jotta kuvanlaatu
paranee.
yJos kuvanlaatu on heikko, vaikka antenni on
kytketty, säädä antennin suuntaa.
yAntennikaapeli ja muunnin on hankittava
erikseen.
yTuettu DTV-ääni: MPEG, Dolby Digital, Dolby
Digital Plus, HE-AAC
HUOMAUTUS
Satellite dish connection
(Only satellite models)
LNB
Satellite IN
13/18V
700mA Max
Satellite
Dish
*Not Provided
English
Connect the TV to a satellite dish to a satellite socket
with a satellite RF cable (75 Ω).
Svenska
Anslut TV:n till ett parabolantennuttag med en
satellit-RF-kabel (75 Ω).
Norsk
Koble TV-en til en parabolantenne til en
satellittkontakt med RF-kabel for satellit (75 Ω).
Dansk
Slut TV’et til en parabol og til et satellitstik ved hjælp af
et satellit-RF-kabel (75 Ω).
Suomi
Kytke TV satelliittiantenniin ja satelliittiliitäntään
RF-kaapelilla (75 Ω).

A-6 MAKING CONNECTIONS
Euro Scart connection
AUDIO / VIDEO
*Not Provided
English
Transmits the video and audio signals from an
external device to the TV set. Connect the external
device and the TV set with the euro scart cable as
shown.
Output
Type
Current
input mode
AV1
(TV Out1)
Digital TV Digital TV
Analogue TV, AV
Analogue TV
Component
HDMI
1 TV Out: Outputs Analogue TV or Digital TV signals.
yAny Euro scart cable used must be signal
shielded.
yWhen watching digital TV in 3D imaging mode,
only 2D out signals can be output through the
SCART cable. (Only 3D models)
NOTE
Svenska
Sänder video- och ljudsignalerna från en extern enhet
till TV:n. Anslut den externa enheten till TV:n med Euro
Scart-kabeln så som visas på bilden nedan.
Typ av utgång
Aktuellt
insignalsläge
AV1
(TV-utgång1)
Digital-TV Digital-TV
Analog-TV, AV
Analog-TV
Komponent
HDMI
1 TV-utgång: Utdatasignaler för analog- eller digital-TV.
yOm du vill använda en scartkabel måste du
använda en signalavskärmade typ.
yNär du tittar på digital-TV i 3D-läget är det endast
2D-signalerna från utgången som kan gå via
SCART-kabeln. (Endast 3D-modeller)
Obs!
Norsk
Sender video- og lydsignalene fra en ekstern enhet til
TV-en. Koble den eksterne enheten til TV-en med Euro
Scart-kabelen, som vist i illustrasjonen nedenfor.
Utgangstype
Gjeldende
modus for innsignal
AV1
(TV-uttak1)
Digital-TV Digital-TV
Analog-TV, AV
Analog-TV
Komponent
HDMI
1 TV-uttak: Genererer analoge eller digitale
TV-signaler.
yEURO scart-kabelen som brukes, må være
signalskjermet.
yHvis du ser på digital-TV i 3D-modus, kan bare
ut-signaler i 2D sendes via SCART-kabelen.
(Bare 3D-modeller)
MERK

A-7
MAKING CONNECTIONS
Dansk
Overfører video- og lydsignalerne fra en ekstern enhed
til TV’et. Tilslut den eksterne enhed og TV’et med
Scart-kablet som vist i følgende illustration.
Udgangstype
Aktuel
indgangstilstand
AV1
(TV ud1)
Digitalt TV Digitalt TV
Analogt TV, AV
Analogt TV
Component
HDMI
1 TV ud: udsender analoge eller digitale TV-signaler.
yBrug et Scart-kabel, der er afskærmet.
yNår du ser digitalt TV i 3D-billedtilstand, kan kun
signaler fra 2D-udgangen udsendes gennem
SCART-kablet. (kun 3D-modeller)
BEMÆRK
Suomi
Siirtää video- ja äänisignaalin ulkoisesta laitteesta
televisioon. Kytke ulkoinen laite ja televisio
Euro Scart -kaapelilla seuraavan kuvan mukaisesti.
Lähdön tyyppi
Nykyinen
tulotila
AV1
(TV-lähtö1)
Digitaalinen TV Digitaalinen TV
Analoginen TV, AV
Analoginen televisio
Komponentti
HDMI
1 TV-lähtö: ulostulot analogisen television tai
digitaalisen television signaaleille.
yKaikkien käytettävien Euro scart -kaapelien on
oltava suojattuja.
yKatsottaessa digitelevisiota 3D-tilassa vain
2D-signaalia voidaan lähettää näytöstä SCART-
kaapelilla. (vain 3D-mallit)
HUOMAUTUS

A-8 MAKING CONNECTIONS
Other connections
Only LB56**, LB62** series
DVD/ Blu-Ray / HD Cable Box
DVD/ Blu-Ray / HD Cable Box / VCR
MONO
( )
YELLOW
RED
WHITE
YELLOW
RED
WHITE
GREEN
BLUE
RED RED
WHITE
GREEN
BLUE
RED
RED
WHITE
AUDIO VIDEO
VIDEO
IN
OPTICAL
DIGITAL
AUDIO OUT
LNB
Satellite IN
13/18V
700mA Max
ANTENNA /
CABLE IN
OPTICAL AUDIO IN
Digital Audio System
DVD/ Blu-Ray / HD Cable Box
/ HD STB / PC
HDMI
(Only LAN PORT models)
(Only Satellite models)
USB IN
USB / HDD
Mobile phone
PCMCIA card
H/P OUT
IN 2 (MHL)
HDMI 2 port position
varies by model.
Headphone

A-9
MAKING CONNECTIONS
English
Connect your TV to external devices. For the best
picture and audio quality, connect the external device
and the TV with the HDMI cable as shown. Some
separate cable is not provided.
Svenska
Anslut TV:n till externa enheter. För att få bästa bild-
och ljudkvalitet ska du ansluta den externa enheten
till TV:n med HDMI-kabeln som på bilden nedan.
Vissa separata kablar medföljer inte.
Norsk
Koble TV-en til eksterne enheter. Koble den eksterne
enheten til TV-en med HDMI-kabelen som vist her
for best mulig bilde- og lydkvalitet. Enkelte separate
kabler er ikke inkludert.
Dansk
Slut dit tv til eksterne enheder. For at få den bedste
billed- og lydkvalitet, skal du tilslutte den eksterne
enhed og tv’et med HDMI-kablet som vist. Nogle
særskilte kabler medfølger ikke.
Suomi
Ulkoisten laitteiden liittäminen televisioon: saat
laadukkaimman kuvan ja äänen, kun liität ulkoisen
laitteen televisioon HDMI-kaapelilla kuvan mukaisesti.
Tiettyjä erillisiä kaapeleita ei toimiteta mukana.
Only LB56**, LB62** series
DVD/ Blu-Ray / HD Cable Box
DVD/ Blu-Ray / HD Cable Box / VCR
MONO
( )
YELLOW
RED
WHITE
YELLOW
RED
WHITE
GREEN
BLUE
RED RED
WHITE
GREEN
BLUE
RED
RED
WHITE
AUDIO VIDEO
VIDEO
IN
OPTICAL
DIGITAL
AUDIO OUT
LNB
Satellite IN
13/18V
700mA Max
ANTENNA /
CABLE IN
OPTICAL AUDIO IN
Digital Audio System
DVD/ Blu-Ray / HD Cable Box
/ HD STB / PC
HDMI
(Only LAN PORT models)
(Only Satellite models)
USB IN
USB / HDD
Mobile phone
PCMCIA card
H/P OUT
IN 2 (MHL)
HDMI 2 port position
varies by model.
Headphone

A-10 MAKING CONNECTIONS
Svenska
Anslut olika externa enheter till TV: noch byt inställn-
ingsläge för att välja en extern enhet. Mer information
om anslutning av externa enheter nns i manualen för
varje enhet.
Tillgängliga externa enheter är:
HD-mottagare, DVD-spelare, videobandspelare,
ljudanläggningar, USB-lagringsenheter, datorer, spelen-
heter och andra externa enheter.
yAnslutningen för den externa enheten kan skilja
sig från modellen.
yExterna enheter kan anslutas till TV:n oberoende
av ordningen på TV:ns portar.
yFör att spela in ett TV-program på en DVD-
spelare eller videobandspelare måste du se till
att signalkabeln till TV:n går genom en DVD-
spelare eller videobandspelare. Mer information
om inspelning finns i manualen till den anslutna
enheten.
yAnvändningsinstruktioner hittar du i
användarhandboken för den externa enheten.
yOm du ansluter en spelenhet till TV:n ska du
använda den kabel som följer med spelenheten.
yI datorläge kan det uppstå störningar i
upplösning, vertikalt mönster, kontrast eller
ljusstyrka. Om det inträffar störningar, kan du
prova med att ändra datorutgången till en annan
upplösning, ändra uppdateringsfrekvensen till
en annan inställning eller justera ljusstyrka och
kontrast på menyn BILD tills bilden blir tydlig.
yI PC-läge kanske inte vissa
upplösningsinställningar fungerar som de ska
beroende på grafikkortet.
Obs!
English
Connect various external devices to the TV and switch
input modes to select an external device.
For more information of external device’s connection,
refer to the manual provided with each device.
Available external devices are:
HD receivers, DVD players, VCRs, audio systems,
USB storage devices, PC, gaming devices, and other
external devices.
yThe external device connection may differ from
the model.
yConnect external devices to the TV regardless of
the order of the TV port.
yIf you record a TV programme on a DVD recorder
or VCR, make sure to connect the TV signal
input cable to the TV through a DVD recorder or
VCR. For more information of recording, refer to
the manual provided with the connected device.
yRefer to the external equipment’s manual for
operating instructions.
yIf you connect a gaming device to the TV, use the
cable supplied with the gaming device.
yIn PC mode, there may be noise associated
with the resolution, vertical pattern, contrast or
brightness. If noise is present, change the PC
output to another resolution, change the refresh
rate to another rate or adjust the brightness and
contrast on the PICTURE menu until the picture
is clear.
yIn PC mode, some resolution settings may not
work properly depending on the graphics card.
NOTE

A-11
MAKING CONNECTIONS
Norsk
Koble ulike eksterne enheter til TV-en og bytt
innsignalsmodus for å velge en ekstern enhet.
Hvis du vil ha mer informasjon om tilkobling av eksterne
enheter, kan du se manualen som fulgte med enhetene.
De tilgjengelige eksterne enhetene er:
HD-mottakere, DVD-spillere, videospillere, lydsystemer,
USB-lagringsenheter, PC-er, spillenheter og andre
eksterne enheter.
yHvilke eksterne enheter som kan kobles til,
avhenger av modell.
yKoble eksterne enheter til TV-en uavhengig av
rekkefølgen på TV-portene.
yHvis du tar opp et TV-program på en DVD-spiller
eller en videospiller, må du koble innsignalkabe-
len for TV-signalet til TV-en via en DVD-spiller
eller videospiller. Hvis du vil ha mer informasjon
om opptak, kan du se manualen som fulgte med
den tilkoblede enheten.
yDu finner instruksjoner for bruk i brukerhåndbo-
ken for det eksterne utstyret.
yHvis du kobler en spillenhet til TV-en, må du
bruke kabelen som fulgte med spillenheten.
yDet kan forekomme støy i forbindelse med opp-
løsning, vertikalt mønster, kontrast eller lysstyrke
i PC-modus. Hvis det finnes støy, kan du endre
PC-modusen til en annen oppløsning, endre
oppdateringsfrekvensen eller juster lysstyrken
og kontrasten på menyen BILDE for å få et klart
bilde.
yI PC-modus er det ikke sikkert at alle
oppløsningsinnstillinger fungerer, avhengig av
skjermkortet.
MERK
Dansk
Slut forskellige eksterne enheder til TV’et, og skift
indgangstilstand for at vælge en ekstern tilstand.
Du nder ere oplysninger om tilslutning af eksterne
tilstande i manualen, der følger med hver enkelt enhed.
Tilgængelige eksterne enheder er følgende:
HD-modtagere, DVD-afspillere, videoafspillere,
lydsystemer, USB-lagerenheder, PC’er, spilleenheder
og andre eksterne enheder.
yTilslutningen af den eksterne enhed varierer,
afhængigt af modellen.
ySlut eksterne enheder til TV’et, uanset
rækkefølgen på TV-porten.
yHvis du optager et TV-program på en DVD-
eller videooptager, skal du sørge for at forbinde
indgangssignalkablet til TV’et via en dvd- eller
videooptager. Du finder flere oplysninger om
optagelse i den vejledning, der følger med den
tilsluttede enhed.
ySe vejledningen til det eksterne udstyr for at få
oplysninger om betjening.
yHvis du slutter en spilleenhed til TV’et, skal du
bruge kablet, der følger med spilleenheden.
yI PC-tilstand kan der opstå støj tilknyttet
opløsning, lodret mønster, kontrast eller lysstyrke.
Hvis der er støj til stede, skal PC’ens output
ændres til en anden opløsning, opdateringen
ændres til en anden hastighed eller lysstyrken
og kontrasten justeres i menuen BILLEDE, indtil
billedet bliver klart.
yI PC-tilstand kan visse indstillinger for opløsning
muligvis ikke fungere korrekt afhængigt af
grafikkortet.
BEMÆRK

A-12 MAKING CONNECTIONS
Suomi
Kytke ulkoisia laitteita televisioon ja valitse ulkoinen
laite vaihtamalla tulolähdettä.
Lisätietoja ulkoisen laitteen kytkemisestä on kyseisen
laitteen käyttöoppaassa.
Hyväksytyt ulkoiset laitteet:
HD-vastaanottimet, DVD-soittimet, videonauhurit,
äänijärjestelmät, USB-tallennuslaitteet, tietokoneet,
pelilaitteet ja muut ulkoiset laitteet.
yUlkoisen laitteen kytkentä voi vaihdella mallin
mukaan.
yKytke ulkoiset laitteet televisioon riippumatta TV-
portin järjestyksestä.
yJos tallennat TV-ohjelmaa DVD-tallentimella tai
videonauhurilla, muista kytkeä TV:n tulosignaa-
likaapeli DVD-tallentimeen tai videonauhuriin.
Lisätietoja tallentamisesta on ulkoisen laitteen
käyttöoppaassa.
yKatso lisätietoja ulkoisen laitteen käyttöoppaasta.
yJos kytket pelilaitteen televisioon, käytä pelilait-
teen mukana toimitettua kaapelia.
yPC-tilassa voi esiintyä tarkkuuteen, pystykuvioi-
hin, kontrastiin tai kirkkauteen liittyviä häiriöitä.
Jos häiriöitä esiintyy, muuta tietokoneen kuvan
resoluutiota ja virkistystaajuutta tai säädä KUVA-
valikon kirkkautta ja kontrastia, kunnes kuva on
selkeä.
yPC-tilassa jotkin tarkkuusasetukset eivät ehkä
toimi oikein joidenkin näytönohjainten kanssa.
HUOMAUTUS

www.lg.com
Please read this manual carefully before operating your set and
retain it for future reference.
OWNER’S MANUAL
LED TV*
* LG LED TV applies LCD screen with LED backlights.

2
ENG
ENGLISH
LICENSES / OPEN SOURCE SOFTWARE NOTICE
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an ofcial DivX Certied® device that has
passed rigorous testing to verify that it plays DivX video. Visit divx.com
for more information and software tools to convert your les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied® device must be
registered in order to play purchased DivX Video-on-Demand (VOD)
movies.
To obtain your registration code, locate the DivX VOD section in your device setup
menu. Go to vod.divx.com for more information on how to complete your
registration.
“DivX Certied® to play DivX® video up to HD 1080p, including premium content.”
“DivX®, DivX Certied® and associated logos are trademarks of
Rovi Corporation or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents :
7,295,673; 7,460,668; 7,515,710; 7,519,274”
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product,
please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for
download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing
such distribution (such as the cost of media, shipping and handling) upon email request to [email protected].
This offer is valid for three (3) years from the date on which you purchased the product.

3
ENGENGLISH
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Please read these safety precautions carefully before using the product.
WARNING
yDo not place the TV and/or remote control in the following environments:
-
- A location exposed to direct sunlight
-
- An area with high humidity such as a bathroom
-
- Near any heat source such as stoves and other devices that produce heat
-
- Near kitchen counters or humidifiers where they can easily be exposed to steam or
oil
-
- An area exposed to rain or wind
-
- Near containers of water such as vases
Otherwise, this may result in re, electric shock, malfunction or product deformation.
yDo not place the product where it might be exposed to dust.
This may cause a fire hazard.
yMains Plug is the TV connecting/disconnecting device to AC mains electric supply.This
plug must remain readily attached and operable when TV is in use.
yDo not touch the power plug with wet hands. Additionally, if the cord pin is wet or
covered with dust, dry the power plug completely or wipe dust off.
You may be electrocuted due to excess moisture.
yMake sure to connect Mains cable to compliant AC mains socket with Grounded earth
pin. (Except for devices which are not grounded on earth.) Otherwise possibility you
may be electrocuted or injured.
yInsert power cable plug completely into wall socket otherwise if not secured completely
into socket, fire ignition may break out.
yEnsure the power cord does not come into contact with hot objects such as a heater.
This may cause a fire or an electric shock hazard.
yDo not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in fire or electric shock.
yBend antenna cable between inside and outside building to prevent rain from flowing in.
This may cause water damaged inside the Product and could give an electric shock.

4
ENG
ENGLISH
SAFETY INSTRUCTIONS
yWhen mounting TV onto wall make sure to neatly install and isolate cabling from rear of
TV as to not create possibility of electric shock /fire hazard.
yDo not plug too many electrical devices into a single multiple electrical outlet.
Otherwise, this may result in fire due to over-heating.
yDo not drop the product or let it fall over when connecting external devices.
Otherwise, this may result in injury or damage to the product.
yKeep the anti-moisture packing material or vinyl packing out of the reach of children.
Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient
to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation.
Keep it out of the reach of children.
yDo not let your children climb or cling onto the TV.
Otherwise, the TV may fall over, which may cause serious injury.
yDispose of used batteries carefully to ensure that a small child does not consume them.
Please seek Doctor- Medical Attention immediately if child consumes batteries.
yDo not insert any metal objects/conductors (like a metal chopstick/cutlery/screwdriver)
between power cable plug and input Wall Socket while it is connected to the input
terminal on the wall. Additionally, do not touch the power cable right after plugging into
the wall input terminal. You may be electrocuted.
(Depending on model)
yDo not put or store inflammable substances near the product.
There is a danger of combustion/explosion or fire due to careless handling of the
inflammable substances.
yDo not drop metallic objects such as coins, hair pins, chopsticks or wire into the
product, or inflammable objects such as paper and matches. Children must pay
particular attention.
Electrical shock, fire or injury can occur. If a foreign object is dropped into the product,
unplug the power cord and contact the service centre.
yDo not spray water on the product or scrub with an inflammable substance (thinner or
benzene). Fire or electric shock accident can occur.
yDo not allow any impact, shock or any objects to fall into the unit, and do not drop
anything onto the screen.
You may be injured or the product can be damaged.

5
ENGENGLISH
SAFETY INSTRUCTIONS
yNever touch this product or antenna during a thunder or lighting storm.
You may be electrocuted.
yNever touch the wall outlet when there is leakage of gas, open the windows and
ventilate.
It may cause a fire or a burn by a spark.
yDo not disassemble, repair or modify the product at your own discretion.
Fire or electric shock accident can occur.
Contact the service centre for check, calibration or repair.
yIf any of the following occur, unplug the product immediately and contact your local
service centre.
-
- The product has been impacted by shock
-
- The product has been damaged
-
- Foreign objects have entered the product
-
- The product produced smoke or a strange smell
This may result in re or electric shock.
yUnplug the TV from AC mains wall socket if you do not intend to use the TV for a long
period of time.
Accumulated dust can cause re hazard and insulation deterioration can cause electric
leakage/shock/re.
yApparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
yDo not install this product on a wall if it could be exposed to oil or oil mist.
This may damage the product and cause it to fall.
CAUTION
yInstall the product where no radio wave occurs.
yThere should be enough distance between an outside antenna and power lines to keep
the former from touching the latter even when the antenna falls.
This may cause an electric shock.
yDo not install the product on places such as unstable shelves or inclined surfaces. Also
avoid places where there is vibration or where the product cannot be fully supported.
Otherwise, the product may fall or flip over, which may cause injury or damage to the
product.

6
ENG
ENGLISH
SAFETY INSTRUCTIONS
yIf you install the TV on a stand, you need to take actions to prevent the product from
overturning. Otherwise, the product may fall over, which may cause injury.
yIf you intend to mount the product to a wall, attach VESA standard mounting interface (optional parts) to the
back of the product. When you install the set to use the wall mounting bracket (optional parts), fix it carefully so
as not to drop.
yOnly use the attachments / accessories specified by the manufacturer.
yWhen installing the antenna, consult with a qualified service technician. If not installed
by a qualified technician, this may create a fire hazard or an electric shock hazard.
yWe recommend that you maintain a distance of at least 2 to 7 times the diagonal screen
size when watching TV.
If you watch TV for a long period of time, this may cause blurred vision.
yOnly use the specified type of battery.
This could cause damage to the remote control.
yDo not mix new batteries with old batteries.
This may cause the batteries to overheat and leak.
yBatteries should not be exposed to excessive heat. For example, keep away from direct Sunlight , open
fireplace and electric heaters .
yDo not place non-rechargeable batteries in charging device.
yMake sure there are no objects between the remote control and its sensor.
ySignal from Remote Control can be interrupted due to external/internal lighting eg
Sunlight, fluorescent lighting.
If this occurs turn off lighting or darken viewing area.
yWhen connecting external devices such as video game consoles, make sure the
connecting cables are long enough.
Otherwise, the product may fall over, which may cause injury or damage the product.
yDo not turn the product On/Off by plugging-in or unplugging the power plug to the wall
outlet. (Do not use the power plug for switch.)
It may cause mechanical failure or could give an electric shock.

7
ENGENGLISH
SAFETY INSTRUCTIONS
yPlease follow the installation instructions below to prevent the product from overheating.
-
- The distance between the product and the wall should be more than 10 cm.
-
- Do not install the product in a place with no ventilation (e.g., on a bookshelf or in a
cupboard).
-
- Do not install the product on a carpet or cushion.
-
- Make sure the air vent is not blocked by a tablecloth or curtain.
Otherwise, this may result in re.
yTake care not to touch the ventilation openings when watching the TV for long periods
as the ventilation openings may become hot. This does not affect the operation or
performance of the product.
yPeriodically examine the cord of your appliance, and if its appearance indicates damage or deterioration,
unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an
authorized servicer.
yPrevent dust collecting on the power plug pins or outlet.
This may cause a fire hazard.
yProtect the power cord from physical or mechanical abuse, such as being twisted,
kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall
outlets, and the point where the cord exits the appliance.
yDo not press strongly upon the panel with a hand or sharp object such as nail, pencil or
pen, or make a scratch on it, as it may cause damage to screen.
yAvoid touching the screen or holding your finger(s) against it for long periods of time.
Doing so may produce some temporary or permanent distortion/damage to screen.
yWhen cleaning the product and its components, unplug the power first and wipe it with
a soft cloth. Applying excessive force may cause scratches or discolouration. Do not
spray with water or wipe with a wet cloth. Never use glass cleaner, car or industrial
shiner, abrasives or wax, benzene, alcohol etc., which can damage the product and its
panel.
Otherwise, this may result in fire, electric shock or product damage (deformation,
corrosion or breakage).
yAs long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if
you turn off this unit by SWITCH.
yWhen unplugging the cable, grab the plug and unplug it, by pulling at the plug.
Don’t pull at the cord to unplug the power cord from the power board, as this could be
hazardous.
yWhen moving the product, make sure you turn the power off first. Then, unplug the
power cables, antenna cables and all connecting cables.
The TV set or power cord may be damaged, which may create a fire hazard or cause
electric shock.

8
ENG
ENGLISH
SAFETY INSTRUCTIONS
yWhen moving or unpacking the product, work in pairs because the product is heavy.
Otherwise, this may result in injury.
yContact the service centre once a year to clean the internal parts of the product.
Accumulated dust can cause mechanical failure.
yRefer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
yIf the product feels cold to the touch, there may be a small “flicker” when it is turned on.
This is normal, there is nothing wrong with product.
yThe panel is a high technology display product with resolution of two million to six million
pixels. You may see tiny black dots and/or brightly coloured dots (red, blue or green) at a
size of 1 ppm on the panel. This does not indicate a malfunction and does not affect the
performance and reliability of the product.
This phenomenon also occurs in third-party products and is not subject to exchange or
refund.
yYou may find different brightness and color of the panel depending on your viewing
position(left/right/top/down).
This phenomenon occurs due to the characteristic of the panel. It is not related with the
product performance, and it is not malfunction.
yDisplaying a still image (e.g., broadcasting channel logo, on-screen menu, scene from a video game) for a
prolonged time may cause damage to the screen, resulting in retention of the image, which is known as image
sticking. The warranty does not cover the product for image sticking.
Avoid displaying a fixed image on your television’s screen for a prolonged period (2 or more hours for LCD, 1
or more hours for Plasma).
Also, if you watch the TV at a ratio of 4:3 for a long time, image sticking may occur on the borders of the panel.
This phenomenon also occurs in third-party products and is not subject to exchange or refund.
yGenerated Sound
“Cracking” noise: A cracking noise that occurs when watching or turning off the TV is generated by plastic
thermal contraction due to tempera-ture and humidity. This noise is common for products where thermal
deformation is required. Electrical circuit humming/panel buzzing: A low level noise is generated from a high-
speed switching circuit, which supplies a large amount of current to operate a product. It varies depending on
the product.
This generated sound does not affect the performance and reliability of the product.
