LG LM95 Series User manual

P/NO : MFL67441717 (1209-REV02)
Printed in Korea www.lg.com
OWNER’S MANUAL
LED LCD TV
Please read this manual carefully before operating your set and retain it
for future reference.
LM96**
LM95**
LM86**

A-2 TABLE OF CONTENTS
TABLE OF CONTENTS
A3 SETTING UP THE TV
A-3 Attaching the stand
A-8 Tidying cables
B1 MAKING CONNECTIONS
B-1 Antenna connection
B-2 Satellite connection
B-2 HDMI connection
B-4 - ARC (Audio Return Channel)
B-4 DVI to HDMI connection
B-5 MHL connection
B-6 RGB-PC connection
B-7 Component connection
B-8 Composite connection
B-9 Euro scart connection
B-11 Audio connection
B-12 - Digital optical audio connection
B-13 USB connection
B-14 CI module connection
B-15 Headphone connection
B19 SPECIFICATIONS
LANGUAGE LIST
English
Русский
Қазақша
Українська
COMMON
LANGUAGE
COMMON

A-3
SETTING UP THE TV
SETTING UP THE TV
Image shown may differ from your TV.
Attaching the stand
3
41
Front
Top View
4 EA
M4 x 20
yWhen attaching the stand to the TV set,
place the screen facing down on a cushioned
table or flat surface to protect the screen
from scratches.
CAUTION
yMake sure that the screws are inserted
correctly and fastened securely. If they are
not fastened securely enough, the TV may
tilt forward after being installed.
yDo not use too much force and over tighten
the screws; otherwise screw may be
damaged and not tighten correctly.
CAUTION
4 EA
M4 x 20
yRemove the stand before installing the TV on
a wall mount by performing the stand
attachment in reverse.
NOTE
47/55LM96**
Stand base
Stand body
2
Stand rear cover

A-4 SETTING UP THE TV
41
yWhen attaching the stand to the TV set,
place the screen facing down on a cushioned
table or flat surface to protect the screen
from scratches.
CAUTION
2
4 EA
M4 x 20
yMake sure that the screws are inserted
correctly and fastened securely. If they are
not fastened securely enough, the TV may
tilt forward after being installed.
yDo not use too much force and over tighten
the screws; otherwise screw may be
damaged and not tighten correctly.
CAUTION
yRemove the stand before installing the TV on
a wall mount by performing the stand
attachment in reverse.
NOTE
84LM96**
Front
6 EA
M5 x 16
Front
Stand base
Stand body
3

A-5
SETTING UP THE TV
1
Front
Top View
4 EA
M4 x 20
3
42/47/55LM86**
Stand base
Stand body
2
Stand rear cover
4
yWhen attaching the stand to the TV set,
place the screen facing down on a cushioned
table or flat surface to protect the screen
from scratches.
CAUTION
Wrapping bag

A-6 SETTING UP THE TV
5
4 EA
M4 x 20
yRemove the stand before installing the TV on
a wall mount by performing the stand
attachment in reverse.
NOTE
6
Protection pad
yMake sure that the screws are inserted
correctly and fastened securely. If they are
not fastened securely enough, the TV may
tilt forward after being installed.
yDo not use too much force and over tighten
the screws; otherwise screw may be
damaged and not tighten correctly.
CAUTION

A-7
SETTING UP THE TV
3
41
Front
4 EA
M5 x 35
yWhen attaching the stand to the TV set,
place the screen facing down on a cushioned
table or flat surface to protect the screen
from scratches.
CAUTION
4 EA
M4 x 20
72LM95**
Stand base
Stand body
Stand rear cover
Top View
2
yMake sure that the screws are inserted
correctly and fastened securely. If they are
not fastened securely enough, the TV may
tilt forward after being installed.
yDo not use too much force and over tighten
the screws; otherwise screw may be
damaged and not tighten correctly.
CAUTION
yRemove the stand before installing the TV on
a wall mount by performing the stand
attachment in reverse.
NOTE

A-8 SETTING UP THE TV
Tidying cables
1Gather the cables with the stand rear cover.
47/55LM96**, 42/47/55LM86**
2Install the cable holder as shown.
Cable holder
3Gather and bind the cables with the cable
holder.
Stand rear cover
yDo not move the TV by holding the cable holder, as the cable holders may break, and injuries and
damage to the TV may occur.
CAUTION
84LM96**
1Gather and bind the cables with the cable
management.
2Install the cable holder as shown.
Cable holder
3Gather and bind the cables with the cable
holder.
Cable management

A-9
SETTING UP THE TV
1Install the cable holder as shown.
72LM95**
2Gather and bind the cables with the cable
holder.
3Pull the cable management on the stand rear
cover and organize cables. Then, put it back.
Cable holder
Cable management
yDo not move the TV by holding the cable
holder, as the cable holders may break, and
injuries and damage to the TV may occur.
CAUTION
