LG 32LB561V User manual

www.lg.com
Please read this manual carefully before operating your set
and retain it for future reference.
LB55**
LB56**
LB62**
P/NO : MFL68003809 (1407-REV02)
Printed in Korea
OWNER’S MANUAL
LED TV*
* LG LED TVs are LCD TVs with LED backlighting.
*MFL68003809*

2
ENG
ENGLISH
LICENSES / OPEN SOURCE SOFTWARE NOTICE
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
7KHWHUPV+'0,DQG+'0,+LJK'H¿QLWLRQ0XOWLPHGLD,QWHUIDFHDQGWKH+'0,
logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
ABOUT DIVX VIDEO: DivX®is a digital video format created by DivX, LLC, a
VXEVLGLDU\RI5RYL&RUSRUDWLRQ7KLVLVDQRI¿FLDO'LY;&HUWL¿HG®device that has
passed rigorous testing to verify that it plays DivX video. Visit divx.com
IRUPRUHLQIRUPDWLRQDQGVRIWZDUHWRROVWRFRQYHUW\RXU¿OHVLQWR'LY;YLGHRV
$%287',9;9,'(221'(0$1'7KLV'LY;&HUWL¿HG®device must be
registered in order to play purchased DivX Video-on-Demand (VOD)
movies.
To obtain your registration code, locate the DivX VOD section in your device setup
menu. Go to vod.divx.com for more information on how to complete your
registration.
³'LY;&HUWL¿HG®to play DivX®video up to HD 1080p, including premium content.”
“DivX®'LY;&HUWL¿HG®and associated logos are trademarks of
Rovi Corporation or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents :
7,295,673; 7,460,668; 7,515,710; 7,519,274”
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product,
please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for
download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing
such distribution (such as the cost of media, shipping and handling) upon email request to [email protected].
This offer is valid for three (3) years from the date on which you purchased the product.

3
ENGENGLISH
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Please read these safety precautions carefully before using the product.
WARNING
yDo not place the TV and/or remote control in the following environments:
-A location exposed to direct sunlight
-An area with high humidity such as a bathroom
-Near any heat source such as stoves and other devices that produce heat
-Near kitchen counters or humidifiers where they can easily be exposed to steam or
oil
-An area exposed to rain or wind
-Near containers of water such as vases
2WKHUZLVHWKLVPD\UHVXOWLQ¿UHHOHFWULFVKRFNPDOIXQFWLRQRUSURGXFWGHIRUPDWLRQ
yDo not place the product where it might be exposed to dust.
This may cause a fire hazard.
yMains Plug is the TV connecting/disconnecting device to AC mains electric supply.This
plug must remain readily attached and operable when TV is in use.
yDo not touch the power plug with wet hands. Additionally, if the cord pin is wet or
covered with dust, dry the power plug completely or wipe dust off.
You may be electrocuted due to excess moisture.
yMake sure to connect Mains cable to compliant AC mains socket with Grounded earth
pin. (Except for devices which are not grounded on earth.) Otherwise possibility you
may be electrocuted or injured.
yInsert power cable plug completely into wall socket otherwise if not secured completely
into socket, fire ignition may break out.
yEnsure the power cord does not come into contact with hot objects such as a heater.
This may cause a fire or an electric shock hazard.
yDo not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in fire or electric shock.
yBend antenna cable between inside and outside building to prevent rain from flowing in.
This may cause water damaged inside the Product and could give an electric shock.

4
ENG
ENGLISH
SAFETY INSTRUCTIONS
yWhen mounting TV onto wall make sure to neatly install and isolate cabling from rear of
TV as to not create possibility of electric shock /fire hazard.
yDo not plug too many electrical devices into a single multiple electrical outlet.
Otherwise, this may result in fire due to over-heating.
yDo not drop the product or let it fall over when connecting external devices.
Otherwise, this may result in injury or damage to the product.
yKeep the anti-moisture packing material or vinyl packing out of the reach of children.
Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient
to vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation.
Keep it out of the reach of children.
yDo not let your children climb or cling onto the TV.
Otherwise, the TV may fall over, which may cause serious injury.
yDispose of used batteries carefully to ensure that a small child does not consume them.
Please seek Doctor- Medical Attention immediately if child consumes batteries.
yDo not insert any metal objects/conductors (like a metal chopstick/cutlery/screwdriver)
between power cable plug and input Wall Socket while it is connected to the input
terminal on the wall. Additionally, do not touch the power cable right after plugging into
the wall input terminal. You may be electrocuted.
(Depending on model)
yDo not put or store inflammable substances near the product.
There is a danger of combustion/explosion or fire due to careless handling of the
inflammable substances.
yDo not drop metallic objects such as coins, hair pins, chopsticks or wire into the
product, or inflammable objects such as paper and matches. Children must pay
particular attention.
Electrical shock, fire or injury can occur. If a foreign object is dropped into the product,
unplug the power cord and contact the service centre.
yDo not spray water on the product or scrub with an inflammable substance (thinner or
benzene). Fire or electric shock accident can occur.
yDo not allow any impact, shock or any objects to fall into the unit, and do not drop
anything onto the screen.
You may be injured or the product can be damaged.

5
ENGENGLISH
SAFETY INSTRUCTIONS
yNever touch this product or antenna during a thunder or lighting storm.
You may be electrocuted.
yNever touch the wall outlet when there is leakage of gas, open the windows and
ventilate.
It may cause a fire or a burn by a spark.
yDo not disassemble, repair or modify the product at your own discretion.
Fire or electric shock accident can occur.
Contact the service centre for check, calibration or repair.
yIf any of the following occur, unplug the product immediately and contact your local
service centre.
-The product has been impacted by shock
-The product has been damaged
-Foreign objects have entered the product
-The product produced smoke or a strange smell
7KLVPD\UHVXOWLQ¿UHRUHOHFWULFVKRFN
yUnplug the TV from AC mains wall socket if you do not intend to use the TV for a long
period of time.
$FFXPXODWHGGXVWFDQFDXVH¿UHKD]DUGDQGLQVXODWLRQGHWHULRUDWLRQFDQFDXVHHOHFWULF
OHDNDJHVKRFN¿UH
yApparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
yDo not install this product on a wall if it could be exposed to oil or oil mist.
This may damage the product and cause it to fall.
CAUTION
yInstall the product where no radio wave occurs.
yThere should be enough distance between an outside antenna and power lines to keep
the former from touching the latter even when the antenna falls.
This may cause an electric shock.
yDo not install the product on places such as unstable shelves or inclined surfaces. Also
avoid places where there is vibration or where the product cannot be fully supported.
Otherwise, the product may fall or flip over, which may cause injury or damage to the
product.

6
ENG
ENGLISH
SAFETY INSTRUCTIONS
yIf you install the TV on a stand, you need to take actions to prevent the product from
overturning. Otherwise, the product may fall over, which may cause injury.
yIf you intend to mount the product to a wall, attach VESA standard mounting interface (optional parts) to the
back of the product. When you install the set to use the wall mounting bracket (optional parts), fix it carefully so
as not to drop.
yOnly use the attachments / accessories specified by the manufacturer.
yWhen installing the antenna, consult with a qualified service technician. If not installed
by a qualified technician, this may create a fire hazard or an electric shock hazard.
yWe recommend that you maintain a distance of at least 2 to 7 times the diagonal screen
size when watching TV.
If you watch TV for a long period of time, this may cause blurred vision.
yOnly use the specified type of battery.
This could cause damage to the remote control.
yDo not mix new batteries with old batteries.
This may cause the batteries to overheat and leak.
yBatteries should not be exposed to excessive heat. For example, keep away from direct Sunlight , open
fireplace and electric heaters .
yDo not place non-rechargeable batteries in charging device.
yMake sure there are no objects between the remote control and its sensor.
ySignal from Remote Control can be interrupted due to external/internal lighting eg
Sunlight, fluorescent lighting.
If this occurs turn off lighting or darken viewing area.
yWhen connecting external devices such as video game consoles, make sure the
connecting cables are long enough.
Otherwise, the product may fall over, which may cause injury or damage the product.
yDo not turn the product On/Off by plugging-in or unplugging the power plug to the wall
outlet. (Do not use the power plug for switch.)
It may cause mechanical failure or could give an electric shock.

7
ENGENGLISH
SAFETY INSTRUCTIONS
yPlease follow the installation instructions below to prevent the product from overheating.
-The distance between the product and the wall should be more than 10 cm.
-Do not install the product in a place with no ventilation (e.g., on a bookshelf or in a
cupboard).
-Do not install the product on a carpet or cushion.
-Make sure the air vent is not blocked by a tablecloth or curtain.
2WKHUZLVHWKLVPD\UHVXOWLQ¿UH
yTake care not to touch the ventilation openings when watching the TV for long periods
as the ventilation openings may become hot. This does not affect the operation or
performance of the product.
yPeriodically examine the cord of your appliance, and if its appearance indicates damage or deterioration,
unplug it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an
authorized servicer.
yPrevent dust collecting on the power plug pins or outlet.
This may cause a fire hazard.
yProtect the power cord from physical or mechanical abuse, such as being twisted,
kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall
outlets, and the point where the cord exits the appliance.
yDo not press strongly upon the panel with a hand or sharp object such as nail, pencil or
pen, or make a scratch on it, as it may cause damage to screen.
yAvoid touching the screen or holding your finger(s) against it for long periods of time.
Doing so may produce some temporary or permanent distortion/damage to screen.
yWhen cleaning the product and its components, unplug the power first and wipe it with
a soft cloth. Applying excessive force may cause scratches or discolouration. Do not
spray with water or wipe with a wet cloth. Never use glass cleaner, car or industrial
shiner, abrasives or wax, benzene, alcohol etc., which can damage the product and its
panel.
Otherwise, this may result in fire, electric shock or product damage (deformation,
corrosion or breakage).
yAs long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if
you turn off this unit by SWITCH.
yWhen unplugging the cable, grab the plug and unplug it, by pulling at the plug.
Don’t pull at the cord to unplug the power cord from the power board, as this could be
hazardous.
yWhen moving the product, make sure you turn the power off first. Then, unplug the
power cables, antenna cables and all connecting cables.
The TV set or power cord may be damaged, which may create a fire hazard or cause
electric shock.

8
ENG
ENGLISH
SAFETY INSTRUCTIONS
yWhen moving or unpacking the product, work in pairs because the product is heavy.
Otherwise, this may result in injury.
yContact the service centre once a year to clean the internal parts of the product.
Accumulated dust can cause mechanical failure.
yRefer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
yIf the product feels cold to the touch, there may be a small “flicker” when it is turned on.
This is normal, there is nothing wrong with product.
yThe panel is a high technology display product with resolution of two million to six million
pixels. You may see tiny black dots and/or brightly coloured dots (red, blue or green) at a
size of 1 ppm on the panel. This does not indicate a malfunction and does not affect the
performance and reliability of the product.
This phenomenon also occurs in third-party products and is not subject to exchange or
refund.
yYou may find different brightness and color of the panel depending on your viewing
position(left/right/top/down).
This phenomenon occurs due to the characteristic of the panel. It is not related with the
product performance, and it is not malfunction.
yDisplaying a still image (e.g., broadcasting channel logo, on-screen menu, scene from a video game) for a
prolonged time may cause damage to the screen, resulting in retention of the image, which is known as image
sticking. The warranty does not cover the product for image sticking.
Avoid displaying a fixed image on your television’s screen for a prolonged period (2 or more hours for LCD, 1
or more hours for Plasma).
Also, if you watch the TV at a ratio of 4:3 for a long time, image sticking may occur on the borders of the panel.
This phenomenon also occurs in third-party products and is not subject to exchange or refund.
yGenerated Sound
“Cracking” noise: A cracking noise that occurs when watching or turning off the TV is generated by plastic
thermal contraction due to tempera-ture and humidity. This noise is common for products where thermal
deformation is required. Electrical circuit humming/panel buzzing: A low level noise is generated from a high-
speed switching circuit, which supplies a large amount of current to operate a product. It varies depending on
the product.
This generated sound does not affect the performance and reliability of the product.

9
ENGENGLISH
SAFETY INSTRUCTIONS
Viewing 3D Imaging
(Only 3D models)
WARNING
Viewing Environment
yViewing Time
-When watching 3D contents, take 5 - 15 minute
breaks every hour. Viewing 3D contents for
a long period of time may cause headache,
dizziness, fatigue or eye strain.
Those that have a photosensitive seizure or
chronic illness
ySome users may experience a seizure or other
abnormal symptoms when they are exposed to a
flashing light or particular pattern from 3D contents.
yDo not watch 3D videos if you feel nausea, are
pregnant and/ or have a chronic illness such
as epilepsy, cardiac disorder, or blood pressure
disease, etc.
y3D Contents are not recommended to those who
suffer from stereo blindness or stereo anomaly.
Double images or discomfort in viewing may be
experienced.
yIf you have strabismus (cross-eyed), amblyopia
(weak eyesight) or astigmatism, you may have
trouble sensing depth and easily feel fatigue due to
double images. It is advised to take frequent breaks
than the average adult.
yIf your eyesight varies between your right and left
eye, revise your eyesight prior to watching 3D
contents.
Symptoms which require discontinuation or
refraining from watching 3D contents
yDo not watch 3D contents when you feel fatigue
from lack of sleep, overwork or drinking.
yWhen these symptoms are experienced, stop using/
watching 3D contents and get enough rest until the
symptom subsides.
-Consult your doctor when the symptoms
persist. Symptoms may include headache,
eyeball pain, dizziness, nausea, palpitation,
blurriness, discomfort, double image, visual
inconvenience or fatigue.
CAUTION
Viewing Environment
yViewing Distance
- Maintain a distance of at least twice the screen
diagonal length when watching 3D contents.
If you feel discomfort in viewing 3D contents,
move further away from the TV.
Viewing Age
yInfants/Children
-Usage/ Viewing 3D contents for children under
the age of 6 are prohibited.
-Children under the age of 10 may overreact
and become overly excited because their vision
is in development (for example: trying to touch
the screen or trying to jump into it. Special
monitoring and extra attention is required for
children watching 3D contents.
-Children have greater binocular disparity of 3D
presentations than adults because the distance
between the eyes is shorter than one of adults.
Therefore they will perceive more stereoscopic
depth compared to adults for the same 3D
image.
yTeenagers
-Teenagers under the age of 19 may react with
sensitivity due to stimulation from light in 3D
contents. Advise them to refrain from watching
3D contens for a long time when they are tired.
yElderly
-The elderly may perceive less 3D effect
compared to the youth. Do not sit closer to the
TV than the recommended distance.
Cautions when using the 3D glasses
yMake sure to use LG 3D glasses. Otherwise, you
may not be able to view 3D videos properly.
yDo not use 3D glasses instead of your normal
glasses, sunglasses or protective goggles.
yUsing modified 3D glasses may cause eye strain or
image distortion.
yDo not keep your 3D glasses in extremely high or
low temperatures. It will cause deformation.
yThe 3D glasses are fragile and are easily scratched.
Always use a soft, clean piece of cloth when wiping
the lenses. Do not scratch the lenses of the 3D
glasses with sharp objects or clean/wipe them with
chemicals.

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
yImage shown may differ from your TV.
yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
yThe available menus and options may differ from the input source or product model that you are using.
yNew features may be added to this TV in the future.
yThe TV can be placed in standby mode in order to reduce the power consumption. And the TV should be
turned off if it will not be watched for some time, as this will reduce energy consumption.
yThe energy consumed during use can be significantly reduced if the level of brightness of the picture is
reduced, and this will reduce the overall running cost.
NOTE
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local dealer where
you purchased your product. The illustrations in this manual may differ from the actual product and item.
yDo not use any unapproved items to ensure the safety and product life span.
yAny damages or injuries by using unapproved items are not covered by the warranty.
ySome models have a thin film attached on to the screen and this must not be removed.
CAUTION
yThe items supplied with your product may vary depending on the model.
yProduct specifications or contents of this manual may be changed without prior notice due to upgrade of
product functions.
yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick and 18
mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit
into your TV’s USB port.
A
B
A
B
*A
<
=
10 mm
*B
<
=
18 mm
NOTE

11
ENGENGLISH
ASSEMBLING AND PREPARING
Remote control,
batteries (AAA)
Owner’s manual Power Cord
Stand Bases
(Only LB55**, LB56**-ZE / ZC,
LB62**-ZA / ZB / ZD)
Stand Bases
(Only LB56**-ZT / ZQ, LB62**-ZE)
Stand Screws
4EA, M4 x L14
(Only 42/49LB55**,
39/42/47/50/55/60LB56**,
42/49/55LB62**)
Stand Screws
4EA, M4 x L20
(Only 32LB55**, 32LB56**,
32LB62**)
Wall Mount Spacers
2EA
(Only 42LB55**, 42LB56**,
42LB62**)
Cable Managements
2EA
(Only LB55**, LB56**-ZE / ZC /
ZT / ZQ, LB62**-ZA / ZB / ZD / ZE)
Cable holder
(Depending on model)
Cinema 3D Glasses
The number of 3D glasses may
differ depending on the model or
country.
(Only LB62**)
Stand Body / Stand Base
(Only LB56**-ZX, LB62**-ZM)
Stand Screws
4EA, M4 x L20
(Only LB56**-ZX, LB62**-ZM)
Rubbers
2EA
(Only LB56**-ZX, LB62**-ZM)

12
ENG
ENGLISH
ASSEMBLING AND PREPARING
Separate purchase
2SWLRQDOH[WUDVFDQEHFKDQJHGRUPRGL¿HGIRUTXDOLW\LPSURYHPHQWZLWKRXWDQ\QRWL¿FDWLRQ
Contact your dealer for buying these items.
These devices only work with certain models.
LG Audio Device AG-F***
Cinema 3D Glasses
AG-F***DP
Dual play glasses
Compatibility LB56** / LB55** LB62**
LG Audio device  
AG-F***
Cinema 3D Glasses 
AG-F***DP
Dual play glasses 
The model name or design may be changed depending on the upgrade of product functions,
manufacturer’s circumstances or policies.

13
ENGENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
A type : LB55**, LB56**-ZE / ZC, LB62**-ZA / ZB / ZD
Screen
Remote control sensor
Power Indicator
Speakers
Joystick Button
(* This button is located
below the TV screen.)
B type : LB56**-ZT / ZQ, LB62**-ZE
Screen
Remote control sensor
Power Indicator
Speakers
Joystick Button
(* This button is located
below the TV screen.)
yYou can set the power indicator light to on or off by selecting OPTION in the main menus.
NOTE
C type : LB56**-ZX, LB62**-ZM
Screen
Remote control sensor
Power Indicator
Speakers
Joystick Button
(* This button is located
below the TV screen.)

14
ENG
ENGLISH
ASSEMBLING AND PREPARING
Using the Joystick button
You can simply operate the TV functions, pressing or moving the joystick button up, down, left or right.
Basic Functions
Power On :KHQWKH79LVWXUQHGRIISODFH\RXU¿QJHURQWKHMR\VWLFNEXWWRQ
and press it once and release it.
Power Off
:KHQWKH79LVWXUQHGRQSODFH\RXU¿QJHURQWKHMR\VWLFNEXWWRQ
and press it once for a few seconds and release it.
(However, if the Menu button is on the screen, pressing and holding
the joystick button will let you exit the Menu.)
Volume Control ,I\RXSODFH\RXU¿QJHURYHUWKHMR\VWLFNEXWWRQDQGPRYHLWOHIWRU
right, you can adjust the volume level you want.
Programmes
Control
,I\RXSODFH\RXU¿QJHURYHUWKHMR\VWLFNEXWWRQDQGPRYHLWXSRU
down, you can scrolls through the saved programmes you want.
yWhen your finger over the joystick button and push it to the up, down, left or right, be careful not to
press the joystick button. If you press the joystick button first, you may not be able to adjust the volume level
and saved programmes.
NOTE
Adjusting the Menu
When the TV is turned on, press the joystick button one time.
You can adjust the Menu items( , , , ) moving the joystick button up, down, left or right.
TV off Turns the power off.
Settings Accesses the main menu.
Close Clears on-screen displays and returns to TV viewing.
Input List Changes the input source.

15
ENGENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the TV
Please note the following advice to prevent the TV from
being scratched or damaged and for safe transportation
regardless of its type and size.
yAvoid touching the screen at all times, as this
may result in damage to the screen.
CAUTION
yIt is recommended to move the TV in the box or
packing material that the TV originally came in.
yBefore moving or lifting the TV, disconnect the
power cord and all cables.
yWhen holding the TV, the screen should face away
from you to avoid damage.
yHold the top and bottom of the TV frame firmly.
Make sure not to hold the transparent part, speaker,
or speaker grill area.
yWhen transporting a large TV, there should be at
least 2 people.
yWhen transporting the TV by hand, hold the TV as
shown in the following illustration.
yWhen transporting the TV, do not expose the TV to
jolts or excessive vibration.
yWhen transporting the TV, keep the TV upright,
never turn the TV on its side or tilt towards the left
or right.
yDo not apply excessive pressure to cause flexing /
bending of frame chassis as it may damage screen.

16
ENG
ENGLISH
ASSEMBLING AND PREPARING
1
4EA
M4 x L14
(Only 32LB56**-ZT / ZQ,
32LB62**-ZE)
M4 x L20
2
A Stand Base
B Stand Base
1
2
yWhen attaching the stand to the TV set, place
the screen facing down on a cushioned table or
flat surface to protect the screen from scratches.
CAUTION
(Only LB56**-ZT / ZQ, LB62**-ZE)
Setting up the TV
Image shown may differ from your TV.
Attaching the stand
(Only LB55**, LB56**-ZE / ZC, LB62**-ZA / ZB / ZD)
4EA
M4 x L14
(Only 32LB55**,
32LB56**-ZE / ZC,
32LB62**-ZA / ZB)
M4 x L20
1
2
A Stand Base
B Stand Base
1
2

17
ENGENGLISH
ASSEMBLING AND PREPARING
(Only LB56**-ZX, LB62**-ZM)
1
1
Stand Body
Stand Base
4EA
M4 x L20
2
3
4EA
M4 x L14
yWhen attaching the stand to the TV set, place
the screen facing down on a cushioned table or
flat surface to protect the screen from scratches.
CAUTION
yThe Rubber will protect the opening from
accumulating dust and dirt. When installing the
wall mounting bracket, use the Rubber. (Only
LB56**-ZX, LB62**-ZM)
Rubber
2EA
NOTE

18
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1 Lift and tilt the TV into its upright position on a table.
-Leave a 10 cm (minimum) space from the wall
for proper ventilation.
10 cm
10 cm
10 cm
10 cm
2 Connect the power cord to a wall outlet.
yDo not place the TV near or on sources of heat,
as this may result in fire or other damage.
CAUTION
Securing the TV to a wall
(This feature is not available for all models.)
1 Insert and tighten the eye-bolts, or TV brackets and
bolts on the back of the TV.
-If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2 Mount the wall brackets with the bolts to the wall.
Match the location of the wall bracket and the eye-
bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly with
a sturdy rope.
Make sure to keep the rope horizontal with the flat
surface.
yMake sure that children do not climb on or hang
on the TV.
CAUTION
yUse a platform or cabinet that is strong and large
enough to support the TV securely.
yBrackets, bolts and ropes are not provided. You
can obtain additional accessories from your local
dealer.
NOTE

19
ENGENGLISH
ASSEMBLING AND PREPARING
Mounting on a wall
Attach an optional wall mount bracket at the rear of the
TV carefully and install the wall mount bracket on a
VROLGZDOOSHUSHQGLFXODUWRWKHÀRRU:KHQ\RXDWWDFK
the TV to other building materials,
SOHDVHFRQWDFWTXDOL¿HGSHUVRQQHO
LG recommends that wall mounting be performed by a
TXDOL¿HGSURIHVVLRQDOLQVWDOOHU
We recommend the use of LG’s wall mount bracket.
When you do not use LG’s wall mount bracket, please
use a wall mount bracket where the device is ad-
equately secured to the wall with enough space to allow
connectivity to external devices.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mount bracket that
meet the VESA standard. Standard dimensions for the
wall mount kits are described in the following table.
Separate purchase(Wall Mounting Bracket)
Model
32/39LB56**
32LB55**
32LB62**
42/47/50/55LB56**
42/49LB55**
42/49/55LB62**
VESA (A x B) 200 x 200 400 x 400
Standard screw M6 M6
Number of screws 4 4
Wall mount
bracket
LSW240B
MSW240
LSW440B
MSW240
Model 60LB56**
VESA (A x B) 400 x 400
Standard screw M6
Number of screws 4
Wall mount
bracket
LSW440B
A
B
yDisconnect the power first, and then move or
install the TV. Otherwise electric shock may
occur.
yIf you install the TV on a ceiling or slanted wall, it
may fall and result in severe injury.
Use an authorized LG wall mount and contact
the local dealer or qualified personnel.
yDo not over tighten the screws as this may cause
damage to the TV and void your warranty.
yUse the screws and wall mounts that meet the
VESA standard. Any damages or injuries by
misuse or using an improper accessory are not
covered by the warranty.
CAUTION
yUse the screws that are listed on the VESA
standard screw specifications.
yThe wall mount kit includes an installation manual
and necessary parts.
yThe wall mount bracket is not provided. You can
obtain additional accessories from your local
dealer.
yThe length of screws may differ depending on the
wall mount. Make sure to use the proper length.
yFor more information, refer to the manual
supplied with the wall mount.
yWhen attaching a wall mounting bracket to the
TV, insert the wall mount spacers into the TV wall
mount holes to adjust the vertical angle of the TV.
(Only 42LB55**, 42LB56**, 42LB62**)
Wall Mount Spacers
NOTE

20
ENG
ENGLISH
MAKING CONNECTIONS
MAKING CONNECTIONS
This section on MAKING CONNECTIONS
mainly uses diagrams for the 47LB561V models.
Connect various external devices to the TV and switch
input modes to select an external device.
For more information of external device’s connection,
refer to the manual provided with each device.
Available external devices are:
HD receivers, DVD players, VCRs, audio systems,
USB storage devices, PC, gaming devices, and other
external devices.
yThe external device connection may differ from
the model.
yConnect external devices to the TV regardless of
the order of the TV port.
yIf you record a TV programme on a DVD recorder
or VCR, make sure to connect the TV signal
input cable to the TV through a DVD recorder or
VCR. For more information of recording, refer to
the manual provided with the connected device.
yRefer to the external equipment’s manual for
operating instructions.
yIf you connect a gaming device to the TV, use the
cable supplied with the gaming device.
yIn PC mode, there may be noise associated
with the resolution, vertical pattern, contrast or
brightness. If noise is present, change the PC
output to another resolution, change the refresh
rate to another rate or adjust the brightness and
contrast on the PICTURE menu until the picture
is clear.
yIn PC mode, some resolution settings may not
work properly depending on the graphics card.
NOTE
Antenna connection
ANTENNA /
CABLE IN
Wall Antenna
Socket
*Not Provided
Connect the TV to a wall antenna socket with an RF
FDEOH
yUse a signal splitter to use more than 2 TVs.
yIf the image quality is poor, install a signal
amplifier properly to improve the image quality.
yIf the image quality is poor with an antenna
connected, try to realign the antenna in the
correct direction.
yAn antenna cable and converter are not supplied.
ySupported DTV Audio: MPEG, Dolby Digital,
Dolby Digital Plus, HE-AAC
NOTE
Satellite dish connection
(Only satellite models)
LNB
Satellite IN
13/18V
700mA Max
Satellite
Dish
*Not Provided
Connect the TV to a satellite dish to a satellite socket
ZLWKDVDWHOOLWH5)FDEOH
