LG 42LV355B User manual

Digital Signage Function with Free S/W
Public Display Settings - Cloning
Capable
EcoSmart™
Energy Saving Levels
ENERGY STAR 5.3 &
Ro S COMPLIANT
Auto Sensing Remote Jack Pack
(RJP) Compatible*
Pro:Centric™ ST
DYNAMIC CONTRAST RATIO
2,000,000:1
NATIVE DISPLAY RESOLUTION
1920 x 1080 full D 1080p
BUILT-IN ATSC/NTSC/QAM
CLEAR TUNER
INVISIBLE SPEAKER SYSTEM
idden speaker grilles
LG'S EXCLUSIVE XD ENGINE®
Multi Remote IR Code
USB 2.0 Media ost for photos and
music
USB CLONING
CLEAR VOICE II
REAL CINEMA™
2 DMI™ INPUTS WIT DCP
V.1.3 with deep color
2 year Limited Warranty
(parts and labor)
LCD TV
LGsolutions.com
55LV355B
47LV355B
42LV355B
The estimated annual energy cost determined in accordance with 16 CFR Part 305.5
or models 55LV355B, 47LV355B and 42LV355B are $14, $12 and $13, respectively.
“Your energy cost depends on your utility rates and use. The estimated cost is based on
11 cents per kWh and 5 hours o use per day. For more in ormation, visit
www. tc.gov/energy.”1
1FTC Television labeling rule (18 CFR Part 305, as added by 76 Fed. Reg. 1038 (Jan 6, 2011)).
The Bes Award winner from he
Commercial In egra or magazine for
digi al signage hardware, he LG EzSign
TV is an innova ion in digi al signage ha
can en er ain while maximizing he
impac of your message. Crea e your
own signage con en by using your PC
and he free EzSign sof ware. Transfer
ha con en by using a USB drive and
plug i in o he EzSign TV o run con en
in he form of a billboard - no addi ional
hardware is needed. Adver isemen ,
informa ion, and a live elevision
broadcas can be arranged on he same
screen o a rac a en ion and deliver
specific messaging o your cus omers.
FEAT RES
LED Commercial Widescreen The LG EzSign TV

•EcoSmart
Energy Saving Levels - Manually select your choice for the brightness
level for the television.
•RoHS Compliant - Meets directive on restriction of hazardous
substances.
• Energy Star 5.3 Qualified - Meets current reduction requirements of
energy consumption.
LIFE’S GOOD...
W EN IT’s GREEN.
LG is committed to improving product
development, manufacturing and usage to
meet the demand for environmentally
friendlier products. Our LV355B televisions
have technologies to reduce power
consumption and in return increase cost
savings per room. We’ve also placed limits
in the amounts of harmful materials used in
these televisions.
VARIETY - Pick and choose from a broad range of template designs
The LG EzSign TV gives you the power to choose and change according
to your needs.
LG EZSIGN SOFTWARE - Simple 4 step procedure
Manually select your choice for the brightness level for the television. By
selecting Minimum, Medium, or Maximum, the power consumption will
be reduced and an increase in energy savings can be achieved. (Note:
Selecting minimum level may slightly increase power consumption on some models)
Enter
Move
▼
Aspect Ratio:16:9
Picture Wizard
Energy Saving :Off
Picture Mode:Standard
• Backlight 70
•Contrast90
• Brightness50
• Sharpness70
Off
Minimum
Medium
Maximum
Screen off
ENERGY SAVING LEVELS
CONNECTIVITY
As a versatile addition to the TV viewing experience, LG's optional auto-
sensing Remote Jack Packs (RJP)*, can serve as a multimedia hub that
can be installed conveniently on a table or in a wall. Connect portable
devices such as a laptop, mp3 player, or a digital camera to display
images, play video or music from the set.
FAST AND EASY - Edit content quickly and easily
Select one of the pre-installed content templates.
Apply images and add texts on it. It’s that simple.
CUSTOMIZED TO YOUR NEEDS - Signage content can
be specific to your business
The LG EzSign TV allows you to create your own signage
content and make revisions on the fly.
COST EFFECTIVE
No need to buy a media player - Create your own signage content by
using your PC and the free EzSign software. Transfer that content by
using a USB flash drive and plug it in to the EzSign TV to run it
COST EFFECTIVE. SIMPLE. HIGHLY EFFECTIVE.
STEP1 Choose a Template
STEP3 Edit the TextSTEP2 Add Photos STEP4 Export to USB
LG’S SIGNAGE TECHNOLOGY MEETS THE TELEVISION
LG EZSIGN TV

55LV355B
42L
V355B
STAND BODY
COVER BASE
4-Screws
(provided)
MOUNTING HOLES ON STAND
LAN
ANTENNA /
CABLE IN
RS-232C IN (CONTROL & SERVICE)
RGB IN (PC)
OPTICAL
DIGITAL
AUDIO OUT
/ DVI IN
1
SPEAKER
OUT
AUDIO IN
(RGB/DVI)
RJP
INTERFACE
VIDEOAUDIO
COMPONENT IN
Y
P
B
P
R
R
L
VIDEO
AUDIO
R
AV IN 1
L/MONO
50.6”
30.6”
33.3”
13.3”
400mm
400mm
21.6”
1.2”
REAR SIDE
AVIN2
L/MONO
R
AUDIO
VIDEO
USBIN
39.3”
24.2”
26.9”
10.1”
400mm
400mm
20.1”
1.2”
SOUND IS HEARD, NOT SEEN
Enjoy a combination of smart technology
and stylish design with the invisible speaker
system custom tuned by audio expert Mr.
Mark Levinson. This unique system
provides a clean, polished look and an
enhanced auditory experience by
increasing the sweet spot and providing a
wider sound field.
PUBLIC DISPLAY SETTINGS
When used in public areas, these DTVs
can be easily programmed by the installer
to have the TV turn on at a specified
channel/volume level, set the minimum/
maximum volume, lock out the control
panel/remote, set the aspect ratio, and
return to a factory reset. By using Power
Management, these displays can be
programmed to turn off if there has been
no activity (remote or control panel
buttons) for a preset time (1-7) hours.
Public Display Mode No
Start Channel No
Ch. Type TV
Major 2
Minor 0
Minimum Volume 0
Maximum Volume 100
Start Volume No
Level 20
Power Management No
Setting 1
Key Management 0
Factory Reset 0
Aspect Ratio 0
PDM Plus
Public Display Setting
USB CLONING
USB cloning will allow for easy transfer of
Public Display Settings from the “Master TV”
to an unlimited number of same type
televisions.
IN 3
USB IN
USB IN
IN 2
AV IN 2
AUDIO / VIDEO
47LV355B
43.6”
26.6”
29.4”
10.1”
400mm
400mm
20.7”
1.2”

All screen images are simulated. Dimensions and weights are approximate. Design,
features and specifications subject to change without notice.
© Copyright 2012 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp. XD Engine is a registered trademark of LG Electronics,
Inc. ealthView and EcoSmart are trademarks of LG Corp.
ENERGY STAR is a registered
trademark of the U.S. Environmental Protection Agency.Dolby and the double-D symbol
are registered trademarks of Dolby Laboratories. SRS and the SRS symbol, TruSurround
XT and WOW are trademarks or registered trademarks of SRS Labs, Inc.
VESA is a
trademark of Video Electronics Standards Association. All other product and brand
names are trademarks or registered trademarks of their respective companies.
Printed in the USA. April 2012
XT
®
SPECIFICATIONS
LGsolutions.com
LCD TV
LCD SPECIFICATION
LED Backlighting Edge lit
Screen Size 55” class (54.6” measured diagonally)
47” class (46.9” measured diagonally)
42” class (42.0” measured diagonally)
Native Display Resolution 1920 x 1080
Brightness 400cd/m2(55”), 360cd/m2(47”, 42”)
Dynamic Contrast Ratio 2,000,000:1
Viewing Angle 178°/178°
Response Time (GTG) 5ms (55”), 6ms (47”, 42”)
Frame Rate 120 z (55”), 60 z (47”, 42”)
Life span 30,000hrs
BROADCASTING SYSTEM
Analog (NTSC) Y
es
ATSC/NTSC/Clear QAM Yes
MPEG4 Yes
VIDEO
XD Engine Yes
Aspect Ratio Correction 6 Modes (16:9/Just scan/set by program/
4:3/Zoom/Cinema Zoom)
Color Temperature Control 3 Modes (Cool, Medium, Warm)
Picture Status Mode 8 modes (Intelligent Sensor, Vivid, Standard,
Cinema, Sport, Game, isf Expert1, isf Expert2)
Just Scan 0% over scan
DMI/Component/RF 1080i/1080p/720p
24p Real Cinema (24p 5:5/2:2 Pull down) Yes
Film Mode (3:2 Pull down) Yes
Eye Care (Anti Dazzling) Yes
Fresh White (Clear white) Yes
Expert Mode/ ISF Ready Yes
Picture Wizard Yes
AV Mode 3 Modes (Cinema, Sport, Game)
xvyCC Yes
A DIO
Audio Output Power 10W + 10W
Speaker System 1 Way 2 Speakers
Dolby Digital Decoder Yes
Surround System Infinite Sound
Invisible Speaker Yes
Sound Mode 5 Modes (Standard, Music, Cinema, Sport, Game)
Clear Voice II Yes
SB 2.0
System Upgrade Yes
File Type JPG/MP3/DivX
SPECIAL FEAT RES
Smart Energy Saving Yes (Backlight Control+Intelligent Sensor)
Intelligent Sensor Yes
Pro:Centric (EPG) Yes
1080p Source Input
DMI 60p/50p/30p/24p
Component 60p/50p
A/V Input Navigation Yes
Input Labeling Yes
SIMPLINK™ ( DMI/CEC) Yes
Parental Control Yes
Key Lock Yes
Subtitle (Caption) Yes
Quick View (Flashback) Yes
e-streamer Yes
OSD Language 4 (English, French, Spanish, Korean)
Quick Menu (Round Type- 8 menus selectable) Yes
CHANNEL
Auto Programming Yes
Program Add/Del Yes
Favorite Channel Yes
TIME/CLOCK
Clock Yes
Auto Off/Auto Sleep (When no video is present)Yes
Sleep Timer
COMMERCIAL FEAT RES
USB Link Loader (USB Cloning) Yes
Multi IR Code Yes
Power On Splash Image (Welcome Screen) Yes
Video Mute Yes
Installation Menu (PDM, otel Mode) Yes (PDM2.6)
Pro:Centric Yes (1 Tuner)
TVLink Tuner/TVLink Loader Yes
IR Out/IR Pass Through Yes
RJP Interface
RJ45 Yes
RS232C Yes
CEC Yes (Guestlink)
CONVENIENCE FEAT RES
Language 4 (English/Spanish/French/Korean)
Auto Programming Yes
Channel Add/Delete Yes
Favorite Channel Programming Yes
A DIO/VIDEO INP TS/O TP TS
DMI In 1 (side)
USB 2.0 Input 1 (side)
RF In 1 (rear)
AV In 1 (rear)
Component Video In (Y, Pb, Pr) + L/R Audio 2 (rear)
Digital Audio Out (Optical) 1 (rear)
DMI/ DCP Input 1 (rear)
RGB In (D-Sub 15pin) - PC 1 (rear)
PC Audio Input 1 (rear)
RS-232c In (Control & Service Only) 1 (rear)
RJP (RJ45) 1 (rear)
External Speaker Out 1 (rear)
CABINET/ACCESSORIES
Cabinet Color Glossy Black
Swivel Stand (degrees) + 20°/-20°
VESA®Standard Mount Compatible (Wx ) 400mm x 400mm
Owner’s Manual (CD/Simple Book) Yes
Remote Control Yes
Power Cord Yes
TORX Security Screws (2 each) Yes
Kensington Lock Yes
Credenza/Security Screw ole Yes
Top Side Mounting Screw Yes
POWER
Voltage, z 100V - 240V, 50/60 z
Stand-by Mode (Max) Under 1W
Dynamic/Static Power Savings Yes
Power Consumption Max 145W (55”), 128W (47”), 110W (42”)
(with Power Saving Modes Disabled) Typical 145W (55”) , 128W (47”), 87W (42”)
REQ IRED LISTING (CERTIFICATION)
Required Approvals UL, cUL, NOM
Lead Free Yes
Mercury Free Yes
Ro S Compliant Yes
ENERGY STAR 5.3 Qualified Yes
DIMENSIONS & WEIGHT
TV without stand (Wx xD) 50.6" x 30.6" x 1.2" (55”)
43.6" x 26.6" x 1.2" (47”)
39.3" x 24.2" x 1.2" (42”)
TV with stand (Wx xD) 50.6" x 33.3" x 13.3" (55”)
43.6" x 29.4" x 10.1" (47”)
39.3" x 26.9" x 10.1" (42”)
Shipping Dimensions (Wx xD) 62.8" x 34.6" x 7.4" (55”)
52.4" x 31.9" x 5.6" (47”)
47.1" x 30.3" x 5.0" (42”)
Unit Weight with Stand without Stand
56.2 lbs (55”) 47.2 lbs (55”)
46.1 lbs (47”) 41.2 lbs (47”)
33.5 lbs (42”) 28.7 Ibs (42”)
Shipping Weight 68.6 lbs (55”)
53.1 lbs (47”)
41.4 lbs (42”)
SERVICE/LIMITED WARRANTY 2 Years (Parts/Labor)
PC CODE
55LV355B 7 19192 90374 6
47LV355B 7 19192 90376 0
42LV355B 7 19192 90373 9
LG Electronics U.S.A., Inc.
E BEB Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative
Channel: 800.897.8871
Hospitality: 800.228.1236
E-mail: [e-mail]
SPEC_LV355B_041230_PR
55" class (54.6” measured diagonally)
47" class (46.9” measured diagonally)
42" class (42.0” measured diagonally)
Required PC spec for installation: Pentium M or 4 CPU, 512MB RAM,
Windows XP sp2, 200MB DD
55LV355B
47LV355B
42LV355B
