OWNER’S MANUAL
LED LCD TV / PLASMA
TV
Please read this manual carefully before operating the
set and retain it for future reference.
LED LCD TV MODELS
32LV5500
42LV5500
47LV5500
55LV5500
PLASMA TV MODELS
50PZ570B
60PZ570B
50PZ950B
60PZ950B
32LW5700
42LW5700
47LW5700
47LW9500
55LW9500
47LZ9600
55LZ9600
72LZ9700

LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is
an official DivX Certified® device that plays DivX video. Visit www.divx.com for
more information and software tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered
in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device setup menu. Go to
vod.divx.com for more information on how to complete your registration.
“DivX Certified® to play DivX® and DivX Plus ™ HD (H.264/MKV) video up to
1080p HD including premium content.”
“DivX®, DivX Certified® and associated logos are trademarks of DivX, Inc. and are
used under license.”
“Covered by one or more of the following U.S. patents :
7,295,673; 7,460,668; 7,515,710; 7,519,274”
NOTE

Plasma
: Plasma TV
LCD
: LED LCD TV, LCD TV
 Image shown may differ from your TV.
 Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
2
ENG
ENGLISH
LICENSES

IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance
of your product.
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING/CAUTION
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
 Do not use this apparatus near water.
 Clean only with a dry cloth.
 Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
 Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade
or the third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet (Can differ by country).
3
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS

 Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
 Only use attachments/accessories specified
by the manufacturer.
 Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
 Unplug this apparatus during lightning
storms or when unused for long periods of
time.
 Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
 Never touch this apparatus or antenna during
a thunder or lightning storm.
 When mounting a TV on the wall, make sure
not to install the TV by hanging the power
and signal cables on the back of the TV.
 Do not allow an impact shock or any objects
to fall into the product, and do not drop
anything onto the screen.
 CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord
to unplug the TV.
 Warning - To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.
4
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS

 Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
 Grounding
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Power Supply
Short-circuit Breaker
 DISCONNECTING DEVICE FROM THE MAIN
POWER
The power outlet must remain readily
accessed in the event the device needs to
be unplugged.
 As long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
 Do not attempt to modify this product in any
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this
product.
 ANTENNAS Outdoor antenna grounding
(Can differ by country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
NEC: National Electrical Code
Ground Clamp
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Electric Service
Equipment
Ground Clamp
 Cleaning
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals
such as alcohol, thinners or benzine.
 Moving
Make sure the product is turned off,
unplugged and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
 Ventilation
Install your TV where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials while
plugged. Do not install in excessively dusty
places.
 If you smell smoke or other odours coming
from the TV, unplug the power cord contact
an authorized service center.
 Do not press strongly upon the panel with
hand or sharp object such as nail, pencil or
pen, or make a scratch on it.
 Keep the product away from direct sunlight.
5
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS

 Dot Defect
The Plasma or LCD panel is a high
technology product with resolution of two
million to six million pixels. In a very few
cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots
are deactivated pixels and do not affect the
performance and reliability of the TV.
 Generated Sound
“Cracking” noise: A cracking noise that
occurs when watching or turning off the TV
is generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-
speed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending on the product.
This generated sound does not affect the
performance and reliability of the product.
 Take care not to touch the ventilation
openings. When watching the TV for a long
period, the ventilation openings may become
hot. This does not affect the performance of
the product or cause defects in the product.
 Viewing 3D Imaging (For 3D TV)
- If you watch the 3D imaging too closely or
for a long period of time, it may harm your
eyesight.
- Watching the TV or playing video games
that incorporate 3D imaging with the 3D
glasses for a long period of time can cause
drowsiness, headaches or fatigue to you
and/or your eyes. If you have a headache,
or otherwise feel fatigued or drowsy, stop
watching the TV and have a rest.
- Pregnant woman, seniors, persons with
heart problems or persons who experience
frequent drowsiness should refrain from
watching 3D TV.
- Some 3D imaging may cause you to duck
or dodge the image displayed in the video.
Therefore, it is best if you do not watch 3D
TV near fragile objects or near any objects
that can be knocked over easily.
- Please prevent children under the age of
5 from watching 3D TV. It may affect their
vision development.
- Warning for photosensitization seizure: Some
viewers may experience a seizure or epilepsy
when exposed to certain factors, including
flashing lights or images in TV or video
games. If you or anybody from your family
has a history of epilepsy or seizure, please
consult with your doctor before watching 3D
TV.
Also certain symptoms can occur in
unspecified conditions without any previous
history. If you experience any of the following
symptoms, immediately stop watching the
3D imaging and consult a doctor: dizziness or
light-headedness, visual transition or altered
vision, visual or facial instability, such as eye
or muscle twitching, unconscious action,
convulsion, loss of conscience, confusion
or disorientation, loss of directional sense,
cramps, or nausea. Parents should monitor
their children, including teenagers, for these
symptoms as they may be more sensitive to
the effects of watching 3D TV.
Risk of photosensitization seizure can be
reduced with the following actions.
- Take frequent breaks from watching 3D TV.
- For those who have vision that is different
in each eye, they should watch the TV after
taking vision correction measures.
- Watch the TV so that your eyes are on the
same level as the 3D screen and refrain from
sitting too closely to the TV.
- Do not watch the 3D imaging when tired or
sick, and avoid watching the 3D imaging for a
long period of time.
- Do not wear the 3D glasses for any other
purpose than viewing 3D imaging on a 3D TV.
- Some viewers may feel disoriented after
watching 3D TV. Therefore, after you watch
3D TV, take a moment to regain awareness
of your situation before moving.
6
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS


LCD
If the TV feels cold to the touch, there may
be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with TV.
Some minute dot defects may be visible on
the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse
effect on the TV’s performance. Avoid
touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary
distortion effects on the screen.
DISPOSAL (Hg lamp only used in LCD TVs)
The fluorescent lamp used in this product contains
a small amount of mercury. Do not dispose of this
product with general household waste. Disposal of
this product must be carried out in accordance to
the regulations of your local authority.
7
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS

TABLE OF CONTENTS
2 LICENSES
3 IMPORTANT SAFETY IN-
STRUCTIONS
8 TABLE OF CONTENTS
10 ASSEMBLING AND PREPARING
10 Unpacking
13 Optional Extras
14 Parts and buttons
20 Lifting and moving the TV
20 Setting up the TV
20 - Attaching the stand
26 - Mounting on a table
28 - Mounting on a wall
31 - Tidying cables
32 REMOTE CONTROL
36 Magic Motion Remote Control Functions
37 - Registering Magic Motion Remote
Control
37 - How to use Magic Motion Remote
Control
37 - Precautions to Take when Using the
Magic Motion Remote Control
38 WATCHING TV
38 Connecting to an antenna or cable
38 - Connecting an antenna or basic cable
39 Turning the TV on for the first time
40 Watching TV
41 Accessing Home Menu
42 Managing channels
42 - Setting up channels
43 - Using favorite channels
44 - Checking current program info
45 Using additional options
45 - Adjusting aspect ratio
46 - Changing AV modes
46 - Using the input list
47 Using the quick menu
48 ENTERTAINMENT
48 Network Connection
48 - Connecting to a wired network
49 - Connecting to a wireless network
50 - When a security code is already set
53 - Network Status
54 Premium Account Function
54 - Notice
56 LG Apps function
56 - Registration LG Apps
57 - Sign in with LG Apps account
58 - Using LG Apps
59 - Using My Apps
60 Smart Share Function
60 - Connecting USB storage devices
61 - Connecting DLNA DMP (Digital Living
Network Alliance, Digital Media Player)
64 - Connecting DLNA DMR (Digital Living
Network Alliance, Digital Media Render)
65 - Browsing files
66 - Viewing Videos
69 - DivX registration code
70 - Viewing Photos
72 - Listening to music
74 Time Machine Function
74 - Precautions when using the USB De-
vice
75 - TIME MACHINE (PAUSE & REPLAY OF
LIVE TV)
78 - RECORDING
79 - SCHEDULE
82 - RECORDED TV
8
ENG
ENGLISH
TABLE OF CONTENTS

85 EPG (Electronic Program Guide) Function
(In digital mode)
85 - Switch on/off EPG
85 - Select a program
85 - NOW/NEXT Guide Mode
85 - 8 Day Guide Mode
86 - Date Setting Mode
86 - Detailed Information Box
87 3D IMAGING (FOR 3D TV)
87 3D Technology
87 - When watching 3D imaging
87 - When using 3D Glasses
87 - 3D Imaging Viewing Range
88 Viewing 3D Imaging
88 - Setting 3D Imaging
90 CUSTOMIZING TV SETTINGS
90 The SETUP Menu
91 Customizing Settings
91 - CHANNEL Settings
92 - PICTURE Settings
97 - AUDIO Settings
99 - TIME Settings
100 - LOCK Settings
101 - OPTION Settings
104 - NETWORK Settings
105 - SUPPORT Settings
106 MAKING CONNECTIONS
107 Connection Overview
108 Connecting to a HD receiver, DVD, or
VCR player
108 - HDMI Connection
109 - DVI to HDMI Connection
110 - Component Connection
111 - Composite Connection
112 Connecting to a PC
112 - HDMI Connection
113 - DVI to HDMI Connection
114 - RGB Connection
115 Connecting to an Audio System
115 - Digital Optical Audio Connection
116 Connecting to a USB
116 Connecting to a Headphone (
LCD
)
117 Connecting the Wireless Media Box
118 SIMPLINK Connection
118 - Activating and Using the SIMPLINK
menus
119 MAINTENANCE
119 Updating the TV Firmware
120 Cleaning Your TV
120 - Screen and frame
120 - Cabinet and stand
120 - Power cord
120 Preventing “Image burn” or “Burn-in” on
your TV screen
121 TROUBLESHOOTING
123 SPECIFICATIONS
130 IR CODES
131 EXTERNAL CONTROL DEVICE
SETUP
139 OPEN SOURCE LICENSE
9
ENG
ENGLISH
TABLE OF CONTENTS

ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
Remote control,
Batteries (AAA)
Owner’s manual CD manual
Polishing cloth1
(Depending on model)
Cleansing Cloths (Mitt)2
(Depending on model)
Nero MediaHome 4 Essentials
CD
Magic Motion Remote Control3,
Strap,
Batteries (AA)
(Except LV5500, LW5700, PZ570B
series)
RF Adapter4
(Depending on model)
FREEZE
RATIO
L/R SELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
1 2 3
4 5 6
7 8
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AV MODE INPUT
1 Gently wipe the spots on the cabinet with the polishing cloth.
2 Wipe spots on the exterior only with the cleansing cloths.
Do not wipe roughly when removing stains. Excessive pressure
may cause scratches or discoloration.
For cleaning front frame, please slowly wipe in one direction
after spraying water 1-2 times on cleansing cloths. Please
remove excessive moisture after cleaning. Excessive moisture
may cause water stains on the frame.
3 Sold seperately for LV5500, LW5700, PZ570B series.
4 Connect it to the antenna wire after fixing in Antenna Input.
This adapter is for supplied in Argentina.
Water
10
ENG
ENGLISH
ASSEMBLING AND PREPARING

LV5500, LW5700, LW9500, LZ9700 series
Screw for assembly
(LV5500, LW5700 series)
Screw for assembly
(LW9500 series)
Screw for assembly
(LZ9700 series)
Power cord
(LZ9700 series)
Composite gender cable Component gender cable Cable holder
(Depending on model)
Screw for fixing
(32LW5700, 32LV5500)
3D Glasses
(AG-P110, AG-F110)
(LW5700 series)
3D Glasses
(AG-S250)
(LZ9700 series)
PZ570B, PZ950B series
Screw for assembly
(50PZ570B, 50PZ950B)
Screw for assembly
(60PZ570B)
Screw for assembly
(60PZ950B)
Cable holder Power cord holder Protection cover,
Tape
Power cord Wireless LAN for Broadband
/DLNA Adaptor
(AN-WF100)
(PZ950B series)
3D Glasses
(AG-S250)
M4 x 28
x 4
M5 x 24
x 3
x 4
M4 x 12
x 8
M5 x 35
x 4
M4 x 26
x 4
M4 x 16
x 8
M4 x 26
x 4
M5 x 14.5
x 3
M4 x 28
x 4
M5 x 14.5
x 4
11
ENG
ENGLISH
ASSEMBLING AND PREPARING

NOTE
 The items supplied with your product may vary depending on the model.
 Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
 (
LCD
) For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
thick and 18 mm width.
B
AA
B
*A 10 mm
*B 18 mm
CAUTION
 Do not use any unapproved items to ensure the safety and product life span.
 Any damages or injuries by using unapproved items are not covered by the warranty.
LZ9600 series
Screw for assembly Wall Anchor Screw
Composite gender cable Component gender cable Cable holder
Stand Base Stand Body Stand Rear Cover Display Link Cable Cover
Display Link Cable
(stand type and wall
mounting type)
Wall Mounting Bracket
(one for the set and one
for the wall)
Wall Mounting Bracket
Pushpin
TV Protection Bracket
M3 x 6
x 4
x 2
x 2
M4 x 7 M4 x 14
x 6 x 6
x 2 x 2
12
ENG
ENGLISH
ASSEMBLING AND PREPARING

Optional Extras
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer for buying these items.
These device only works with compatible LG LED LCD TV, LCD TV, or Plasma TV.
Wireless Media Box1
(AN-WL100W)
3D Glasses2
(AG-S230, AG-S250, AG-S270)
Wireless LAN for Broadband
/DLNA Adaptor3
(AN-WF100)
Magic Motion Remote
(AN-MR200)
3D Glasses4
(AG-P110, AG-F110)
1 Supports for LV5500, LW5700, LW9500, LZ9700, PZ570B, PZ950B series
2 Supports for LW9500, LZ9600, LZ9700, PZ570B, PZ950B series
3 Unnecessary for LW9500 series
4 Supports for LW5700 series
13
ENG
ENGLISH
ASSEMBLING AND PREPARING

Touch button2Description
/ ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the Home menu, or saves your input and exits the menus.
ENTER 󰭺Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
AUDIO
VIDEO
L/MONO
R
AV IN1
COMPON ENT IN
ANTENNA IN CABLE IN
VIDEO
AUDIO
Y
2
1
LP
B
P
R
R
RS-232C IN
(CONTROL&SERVICE)
OPTICAL
DIGITAL
AUDIO OUT
WIRELESS
CONTROL
RGB IN (PC)
LAN
AUDIO IN
(RGB/DVI)
Time
Machine
Ready
AUDIO
VIDEO
L/MONO
AV IN2
R
/DVI IN
1 (ARC) 2 3 4
USB IN 1
USB IN 2/USB Apps
Rear Connection
panel (See p.106)
Parts and buttons
PZ570B, PZ950B series
ENTER CH
VOL
HOME
INPUT
Speakers
Screen
Touch buttons2
Remote control and
intelligent1 sensors
Power indicator
14
ENG
ENGLISH
ASSEMBLING AND PREPARING

NOTE
 You can set the power indicator light to on or off by selecting OPTION in the Home menu - SETUP.
Touch button2Description
/ ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the Home menu, or saves your input and exits the menus.
ENTER 󰭺Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
LAN RGB IN (PC)
OPTICAL DIGITAL
AUDIO OUT
AUDIO IN
(RGB/DVI)
ANTENNA
IN CABLE IN
AV IN 2
AUDIO / VIDEO
COMPONENT IN 2
AUDIO / Y PB PR
H/P
WIRELESS
CONTROL
RS-232C IN (CONTROL&SERVICE)
COMPONENT
IN1
VIDEO
AUDIO
Y LP
B
P
R
R
AUDIO
VIDEO
L/MONO
R
AV IN1
ꔡ
IN 1 (ARC)
/DVI
IN 2
/DVI
IN 3
/DVI
IN 4
/DVI
Time Machine Ready USB IN 1 USB Apps
USB IN 2
LV5500 series
Rear Connection panel
(See p.106)
Remote control and
intelligent1 sensors
Power indicator
ENTER
CH VOL HOME
H
INPUT
Speakers
Screen
Touch buttons2
15
ENG
ENGLISH
ASSEMBLING AND PREPARING

NOTE
 You can set the power indicator light to on or off by selecting OPTION in the Home menu - SETUP.
Button Description
/ ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the Home menu, or saves your input and exits the menus.
ENTER 󰭺Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
LAN RGB IN (PC)
OPTICAL DIGITAL
AUDIO OUT
AUDIO IN
(RGB/DVI)
ANTENNA
IN CABLE IN
AV IN 2
AUDIO / VIDEO
COMPONENT IN 2
AUDIO / Y PB PR
H/P
WIRELESS
CONTROL
RS-232C IN (CONTROL&SERVICE)
COMPONENT
IN1
VIDEO
AUDIO
Y LP
B
P
R
R
AUDIO
VIDEO
L/MONO
R
AV IN1
ꔡ
IN 1 (ARC)
/DVI
IN 2
/DVI
IN 3
/DVI
IN 4
/DVI
Time Machine Ready USB IN 1 USB Apps
USB IN 2
LW5700 series
Rear Connection panel
(See p.106)
ENTER
CH
VOL
HOME
INPUT
H
Speakers
Screen
Buttons
Remote control and intelligent1 sensors,
Power indicator
16
ENG
ENGLISH
ASSEMBLING AND PREPARING

NOTE
 You can set the power indicator light to on or off by selecting OPTION in the Home menu - SETUP.
Touch button2Description
/ ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the Home menu, or saves your input and exits the menus.
ENTER 󰭺Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
LAN RGB IN (PC)
OPTICAL DIGITAL
AUDIO OUT
AUDIO IN
(RGB/DVI)
ANTENNA
IN CABLE IN
AV IN 2
AUDIO / VIDEO
COMPONENT IN 2
AUDIO / Y PB PR
H/P
WIRELESS
CONTROL
RS-232C IN (CONTROL&SERVICE)
COMPONENT
IN1
VIDEO
AUDIO
Y LP
B
P
R
R
AUDIO
VIDEO
L/MONO
R
AV IN1
ꔡ
IN 1 (ARC)
/DVI
IN 2
/DVI
IN 3
/DVI
IN 4
/DVI
Time Machine Ready USB IN 1 USB Apps
USB IN 2
LW9500 series
Rear Connection panel
(See p.106)
ENTER
CH VOL HOME
H
INPUT
Speakers
Screen
Touch buttons2
Remote control and
intelligent1 sensors
Power indicator
17
ENG
ENGLISH
ASSEMBLING AND PREPARING

NOTE
 You can set the power indicator light to on or off by selecting OPTION in the Home menu - SETUP.
Touch button2Description
/ ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the Home menu, or saves your input and exits the menus.
ENTER 󰭺Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
LZ9600 series
LAN
RGB IN (PC)
OPTICAL
DIGITAL
AUDIO OUT
DISPLAY LINK
AUDIO IN
(RGB/DVI)
ANTENNA IN CABLE IN
AV IN
VIDEO / AUDIO
RS-232C IN
(CONTROL&SERVICE)
/DVI IN
IN 3
/DVI
USB Apps
USB IN
1 2
1 (ARC)
2
Time Machine Ready
COMPONENT
IN Y PB PR / AUDIO
ENTER
CH VOL HOME
H
INPUT
Screen
Touch buttons1
Rear Connection panel
(See p.106)
Remote Control
Sensor
Speakers
18
ENG
ENGLISH
ASSEMBLING AND PREPARING

NOTE
 You can set the power indicator light to on or off by selecting OPTION in the Home menu - SETUP.
Touch button2Description
/ ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the Home menu, or saves your input and exits the menus.
ENTER 󰭺Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
LAN RGB IN (PC)
RS-232C IN
CONTROL&SERVICE
H/P
OPTICAL
DIGITAL
AUDIO OUT
ANTENNA
IN CABLE IN
IN 1
AV
VIDEO Y
PB
PR
AUDIO
COMPO
NENT
IN 2
AV
VIDEO Y
PB
PR
AUDIO
COMPO
NENT
AUDIO IN
(RGB/DVI)
1
ARC
2 3
1 2
4
USB IN
WIRELESS CONTROL
/DVI IN
USB Apps
Time Machine Ready
LZ9700 series
ENTER
CH VOL HOME
H
INPUT
Speakers
Screen
Touch buttons2
Rear Connection panel
(See p.106)
Remote control and
intelligent1 sensors
Power indicator
19
ENG
ENGLISH
ASSEMBLING AND PREPARING

Lifting and moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless of
its type and size.
CAUTION
 Avoid touching the screen at all times, as
this may result in damage to the screen.
 It is recommended to move the TV in the
box or packing material that the TV originally
came in.
 Before moving or lifting the TV, disconnect
the power cord and all cables.
 When holding the TV, the screen should face
away from you to avoid damage.
 Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
 When transporting a large TV, there should
be at least 2 people.
 When transporting the TV by hand, hold the
TV as shown in the following illustration.
 When transporting the TV, do not expose the
TV to jolts or excessive vibration.
 When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
Setting up the TV
Put your TV on a pedestal stand and mount the TV
on a table or wall.
Attaching the stand
If you are not mounting the TV to a wall, use the
following instructions to attach the stand.
PZ570B, PZ950B series
1 Lay the TV with the screen side down on a flat
surface.
CAUTION
 Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage. Make sure no objects press
against the screen.
2 Assemble the parts of the stand body with the
stand base of the TV.
Model Screw for
assembly
Number of
screws
50PZ570B
50PZ950B
M5 x 14.5 3
60PZ570B M5 x 24 3
60PZ950B M5 x 14.5 4
Stand Base
Stand Body
Stand Base
Stand Body
20
ENG
ENGLISH
ASSEMBLING AND PREPARING
