OWNER’S MANUAL
LED TV*
* Disclaimer
LG LED TV applies LCD screen with LED backlights.
*MFL68003302*
ENG
http://opensource.lge.com
www.lg.com
ENG
ENG
ENG
ENG
ENG
ENG
ENG
ENG
A
B
A
B
<
=
<
=
11
ENGENGLISH
ASSEMBLING AND PREPARING
NOTE
yImage shown may differ from your TV.
yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
yThe available menus and options may differ from the input source or product model that you
are using.
yNew features may be added to this TV in the future.
yThe TV can be placed in standby mode in order to reduce the power consumption. And the
TV should be turned off if it will not be watched for some time, as this will reduce energy
consumption.
yThe energy consumed during use can be significantly reduced if the level of brightness of the
picture is reduced, and this will reduce the overall running cost.
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
CAUTION
yDo not use any unapproved items to ensure the safety and product life span.
yAny damages or injuries by using unapproved items are not covered by the manufacturer’s
warranty.
ySome models have a thin film attached on to the screen and this must not be removed.
NOTE
yThe items supplied with your product may vary depending on the model.
yProduct specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
thick and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB
memory stick does not fit into your TV’s USB port.
*A 10 mm
*B 18 mm
Remote control,
batteries (AAA)
Owner’s manual Cable Holder
1EA
Power Cord Stand Screws
4EA, M4 x L14
(Only 39/42/47/50/
55/60LB56**,
42/49/55LB55**,
42/49/55LB62**)
Stand Screws
4EA, M4 x L20
(Only 32LB56**, 32LB55**,
32LB62**)
Cable Managements
2EA
Wall mount spacers
2EA
(Only 42LB56**, 42LB55**,
42LB62**)
Stand Bases
(Only LB56**, LB55**,
LB62**-TA)
Stand Bases
(Only LB62**-TF/TE)
Cinema 3D Glasses
The number of 3D glasses
may differ depending on the
model or country.
(Only LB62**)
ENG
ENG
ENG
ENG
16
ENG
ENGLISH
ASSEMBLING AND PREPARING
Setting up the TV
Image shown may differ from your TV.
Attaching the stand
1
1
2
CAUTION
yWhen attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
4EA
M4 x L14
M4 x L20
(Only 32LB56**,
32LB55**,
32LB62**-TA)
2
4EA
M4 x L14
M4 x L20
(Only
32LB62**-TF/
TE)
(Only LB56**, LB55**, LB62**-TA)
(Only LB62**-TF/TE)
B stand base
A stand base
1
2
1
2
A stand base
B stand base
ENG
»
»
»
»
»
»
18
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a wall
Attach an optional wall mount bracket at the rear
of the TV carefully and install the wall mount
bracket on a solid wall perpendicular to the
floor. When you attach the TV to other building
materials, please contact qualified personnel.
LG recommends that wall mounting be
performed by a qualified professional installer.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mount
bracket that meet the VESA standard. Standard
dimensions for the wall mount kits are described
in the following table.
Separate purchase(Wall Mounting Bracket)
Model
32/39LB56**
32LB55**
32LB62**
42/47/50/55LB56**
42/49/55LB55**
42/49/55LB62**
VESA (A x B) 200 x 200 400 x 400
Standard
screw M6 M6
Number of
screws 44
Wall mount
bracket
LSW240B
MSW240
LSW440B
MSW240
Model 60LB56**
VESA (A x B) 400 x 400
Standard
screw M6
Number of
screws 4
Wall mount
bracket LSW440B
A
B
CAUTION
yDisconnect the power first, and then
move or install the TV. Otherwise electric
shock may occur.
yIf you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and
contact the local dealer or qualified
personnel.
yDo not over tighten the screws as this
may cause damage to the TV and void
your warranty.
yUse the screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an
improper accessory are not covered by
the manufacturer’s warranty.
NOTE
yUse the screws that are listed on the
VESA standard screw specifications.
yThe wall mount kit includes an installation
manual and necessary parts.
yThe wall mount bracket is not provided.
You can obtain additional accessories
from your local dealer.
yThe length of screws may differ
depending on the wall mount. Make sure
to use the proper length.
yFor more information, refer to the manual
supplied with the wall mount.
yWhen attaching a wall mounting bracket
to the TV, insert the wall mount spacers
into the TV wall mount holes to adjust the
vertical angle of the TV.
(Only 42LB56**, 42LB55**, 42LB62**)
Wall Mount
Spacers
ENG
ANTENNA/
CABLE IN
ENG
HDMI
OPTICAL
DIGITAL
AUDIO OUT
ANTENNA/
CABLE IN
1
IN
AUDIO
VIDEO
L R
OPTICAL
AUDIO IN
VIDEO
MONO
( )
AUDIOL R
IN
2 (MHL) HDD IN
USB IN
H/P OUT
