LG 49LV341H User manual
2
ENGLISH
Warning! Safety instructions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION :TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence of
uninsulated“dangerous voltage”within the product’s
enclosure that may be of sucient magnitude to constitute a risk
of electric shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING : TO REDUCETHE RISK OF FIRE AND ELECTRIC SHOCK,
DO NOT EXPOSETHIS PRODUCT TO RAIN OR MOISTURE.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR
OTHER ITMESWITH OPEN FLAMES AWAY FROM THIS
PRODUCT AT ALL TIMES.
• Do not place the TV and/or remote control in the following
environments:
- A location exposed to direct sunlight
- An area with high humidity such as a bathroom
- Near any heat source such as stoves and other devices that
produce heat
- Near kitchen counters or humidiers where they can easily be
exposed to steam or oil
- An area exposed to rain or wind
- Near containers of water such as vases
Otherwise, this may result in re, electric shock, malfunction or
product deformation.
• Do not place the product where it might be exposed to dust. This
may cause a re hazard.
• Mains Plug is the TV connecting/disconnecting device to AC
mains electric supply.This plug must remain readily attached and
operable when TV is in use.
• Do not touch the power plug with wet hands. Additionally, if the
cord pin is wet or covered with dust, dry the power plug completely
or wipe dust o. You may be electrocuted due to excess moisture.
• Make sure to connect Mains cable to compliant AC mains socket
with Grounded earth pin. (Except for devices which are not
grounded on earth.) Otherwise possibility you may be electrocuted
or injured.
• Insert power cable plug completely into wall socket otherwise if
not secured completely into socket, re ignition may break out.
• Ensure the power cord does not come into contact with hot objects
such as a heater. This may cause a re or an electric shock hazard.
• Do not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in re or electric shock.
• Bend antenna cable between inside and outside building to
prevent rain from owing in.This may cause water damaged inside
the Product and could give an electric shock.
• When mountingTV onto wall make sure to neatly install and
isolate cabling from rear of TV as to not create possibility of electric
shock /re hazard.
• Do not plug too many electrical devices into a single multiple
electrical outlet. Otherwise, this may result in re due to over-
heating.
• Do not drop the product or let it fall over when connecting external
devices. Otherwise, this may result in injury or damage to the
product.
• Keep the anti-moisture packing material or vinyl packing out of the
reach of children. Anti-moisture material is harmful if swallowed.
If swallowed by mistake, force the patient to vomit and visit the
nearest hospital. Additionally, vinyl packing can cause suocation.
Keep it out of the reach of children.
• Do not let your children climb or cling onto the TV.
Otherwise, theTV may fall over, which may cause serious injury.
• Dispose of used batteries carefully to ensure that a small child
does not consume them. Please seek Doctor- Medical Attention
immediately if child consumes batteries.
• Do not insert any metal objects/conductors (like a metal chopstick/
cutlery/screwdriver) into the end of power cable while the power
plug is plugged into wall socket. Additionally, do not touch the
power plug right after unplugging from the wall socket. You may
be electrocuted.
• Do not put or store inammable substances near the product.
There is a danger of combustion/explosion or re due to careless
handling of the inammable substances.
3
ENGLISH
• Do not drop metallic objects such as coins, hair pins, chopsticks
or wire into the product, or inammable objects such as paper
and matches. Children must pay particular attention. Electrical
shock, re or injury can occur. If a foreign object is dropped into the
product, unplug the power cord and contact the service centre.
• Do not spray water on the product or scrub with an inammable
substance (thinner or benzene). Fire or electric shock accident can
occur.
• Do not allow any impact, shock or any objects to fall into the unit,
and do not drop anything onto the screen.You may be injured or
the product can be damaged.
• Never touch this product or antenna during a thunder or lighting
storm.
You may be electrocuted.
• Never touch the wall outlet when there is leakage of gas, open the
windows and ventilate. It may cause a re or a burn by a spark.
• Do not disassemble, repair or modify the product at your own
discretion. Fire or electric shock accident can occur.
Contact the service centre for check, calibration or repair.
• If any of the following occur, unplug the product immediately and
contact your local service centre.
- The product has been damaged
- Foreign objects have entered the product
- The product produced smoke or a strange smell
This may result in re or electric shock.
• Unplug the TV from AC mains wall socket if you do not intend to
use the TV for a long period of time. Accumulated dust can cause
re hazard and insulation deterioration can cause electric leakage/
shock/re.
• Apparatus shall not be exposed to dripping or splashing and no
objects lled with liquids, such as vases, shall be placed on the
apparatus.
• Do not install this product on a wall if it could be exposed to oil or
oil mist.This may damage the product and cause it to fall.
• If water enters or comes into contact withTV, AC adapter or power
cord please disconnect the power cord and contact service centre
immediately. Otherwise, this may result in electric shock or re.
• Only use an authorized AC adapter and power cord approved by
LG Electronics. Otherwise, this may result in re, electric shock,
malfunction or product deformation.
• Never Disassemble the AC adapter or power cord.This may result in
re or electric shock.
• Be careful in handling the adapter to prevent any external shocks
to it. An external shock may cause damage to the adapter.
• Make sure the power cord is connected securely to the power plug
on the TV.
• Install the product where no radio wave occurs.
• There should be enough distance between an outside antenna and
power lines to keep the former from touching the latter even when
the antenna falls.This may cause an electric shock.
• Do not install the product on places such as unstable shelves or
inclined surfaces. Also avoid places where there is vibration or
where the product cannot be fully supported. Otherwise, the
product may fall or ip over, which may cause injury or damage to
the product.
• If you install theTV on a stand, you need to take actions to prevent
the product from overturning. Otherwise, the product may fall
over, which may cause injury.
• If you intend to mount the product to a wall, attach VESA standard
mounting interface (optional parts) to the back of the product.
When you install the set to use the wall mounting bracket
(optional parts), x it carefully so as not to drop.
• Only use the attachments / accessories specied by the
manufacturer.
• When installing the antenna, consult with a qualied service
technician. If not installed by a qualied technician, this may create
a re hazard or an electric shock hazard.
• We recommend that you maintain a distance of at least 2 to 7
times the diagonal screen size when watchingTV. If you watchTV
for a long period of time, this may cause blurred vision.
• Only use the specied type of battery.This could cause damage to
the remote control.
• Do not mix new batteries with old batteries. This may cause the
batteries to overheat and leak.
• Batteries should not be exposed to excessive heat. For example,
keep away from direct Sunlight, open replace and electric heaters.
• Signal from Remote Control can be interrupted due to external/
internal lighting eg Sunlight, uorescent lighting. If this occurs turn
o lighting or darken viewing area.
• When connecting external devices such as video game consoles,
make sure the connecting cables are long enough. Otherwise,
the product may fall over, which may cause injury or damage the
product.
• Do not turn the product On/O by plugging-in or unplugging
the power plug to the wall outlet. (Do not use the power plug for
switch.) It may cause mechanical failure or could give an electric
shock.
4
ENGLISH
• Please follow the installation instructions below to prevent the
product from overheating.
- The distance between the product and the wall should be more
than 10cm.
- Do not install the product in a place with no ventilation (e.g., on
a bookshelf or in a cupboard).
- Do not install the product on a carpet or cushion.
- Make sure the air vent is not blocked by a tablecloth or curtain.
This may result in re.
• Take care not to touch the ventilation openings when watching the
TV for long periods as the ventilation openings may become hot.
This does not aect the operation or performance of the product.
• Periodically examine the cord of your appliance, and if its
appearance indicates damage or deterioration, unplug it,
discontinue use of the appliance, and have the cord replaced with
an exact replacement part by an authorized servicer.
• Prevent dust collecting on the power plug pins or outlet.This may
cause a re hazard.
• Protect the power cord from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a door, or walked upon.
Pay particular attention to plugs, wall outlets, and the point where
the cord exits the appliance.
• Do not press strongly upon the panel with a hand or sharp object
such as nail, pencil or pen, or make a scratch on it, as it may
causedamage to screen.
• Avoid touching the screen or holding your nger(s) against it for
long periods of time. Doing so may produce some temporary or
permanent distortion/damage to screen.
• As long as this unit is connected to the AC wall outlet, it is not
disconnected from the AC power source even if you turn o this
unit by SWITCH.
• When unplugging the cable, grab the plug and unplug it, by
pulling at the plug. Don’t pull at the cord to unplug the power cord
from the power board, as this could be hazardous.
• When moving the product, make sure you turn the power o rst.
Then, unplug the power cables, antenna cables and all connecting
cables.
TheTV set or power cord may be damaged, which may create a re
hazard or cause electric shock.
• When moving or unpacking the product, work in pairs because the
product is heavy. Otherwise, this may result in injury.
• Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
• Do not use high voltage electrical goods near the TV (e.g. electric
mosquito-swatter).This may result in product malfunction.
• When cleaning the product and its components, unplug the power
rst and wipe it with a soft cloth. Applying excessive force may
cause scratches or discolouration. Do not spray with water or wipe
with a wet cloth on the panel. Do not clean yourTV with chemicals
including glass cleaner, any type of air freshener, insecticide,
lubricants, wax (car, industrial), abrasive, thinner, benzene,
alcohol etc., which can damage the product and/ or its panel.
Otherwise, this may result in re, electric shock or product damage
(deformation, corrosion or breakage).
Preparing
• Image shown may dier from your TV.
• Your TV’s OSD (On Screen Display) may dier slightly from that
shown in this manual.
• The available menus and options may dier from the input source
or product model that you are using.
• New features may be added to this TV in the future.
• The items supplied with your product may vary depending on the
model.
• Product specications or contents of this manual may be changed
without prior notice due to upgrade of product functions.
• For an optimal connection, HDMI cables and USB devices should
have bezels less than 10 mm thick and 18 mm width. Use an
extension cable that supports USB if the USB cable or USB
memory stick does not t into your TV’s USB port.
A
B
A
B
*A
<
=
10 mm
*B
<
=
18 mm
• Use a certied cable with the HDMI logo attached.
• If you do not use a certied HDMI cable, the screen may not display
or a connection error may occur. (Recommended HDMI CableTypes)
- High-Speed HDMI®/™ cable (3 m or less)
- High-Speed HDMI®/™ cable with Ethernet (3 m or less)
5
ENGLISH
• Antenna isolator installation guide (Depending on model)
- Use this to installTV in a place where there is a voltage
dierence betweenTV Set and GND of antenna signal.
»If there is a voltage dierence betweenTV Set and GND of
antenna signal, the antenna contact might be heated and
excessive heat might cause an accident.
- You can improve the safety when watching TV by eciently
removing power voltage fromTV antenna. It is recommended
to mount the isolator to the wall. If it cannot be mounted to
the wall, mount it on theTV. Avoid disconnecting the antenna
Isolator after installation.
- Before starting, be sure that theTV antenna is connected.
ANTENNA/
CABLE IN
Cable /
Antenna
Wall
Isolator
or
1. Connect toTV.
2. Connect to Set-Top box.
- Connect one end of the isolator to cable/antenna jack and the
other toTV set or set-top box.
“Equipment connected to the protective earthing of the building
installation through the mains connection or through other
equipment with a connection to protective earthing - and to
a cable distribution system using coaxial cable, may in some
circumstances create a re hazard. Connection to a cable
distribution system has therefore to be provided through a
device providing electrical isolation below a certain frequency
range (galvanic isolator, see EN 60728-11)”
- When applying the RF Isolator, a slight loss of signal sensitivity
can occur.
• Do not use any unapproved items to ensure the safety
and product life span.
• Any damage or injuries caused by using unapproved
items are not covered by the warranty.
• When attaching the stand to theTV set, place the
screen facing down on a cushioned table or at
surface to protect the screen from scratches.
• Make sure that the screws are fastened completely. (If
they are not fastened securely enough, the TV may tilt
forward after being installed.) Do not use too much
force and over tighten the screws; otherwise screw
may be damaged and not tighten correctly.
Separate purchase
Separate purchase items can be changed or modied for quality
improvement without any notication. Contact your dealer to buy
these items.These devices only work with certain models. The model
name or design may be changed depending on the upgrade of product
functions, manufacturer’s circumstances or policies.
(Depending on model)
LED Clock
LEC-005
This manual suits for next models
5
Table of contents
Other LG LED TV manuals
