LG OLED A3 Series User manual

1. Model Name: OLED A3*
2. Suffix: TR
3. Part No: MFL71833949
4. REV REV00
5. Number of pages 16
6. Folded/Unfolded 3 Folded
7. Trim size (W x H)_Unfolded (mm) 296 x 420 (+/- 5)
8. Trim size (W x H)_folded (mm) 148 x 105
9. Bindery -
10. Color (Cover) -
11. Paper (Cover) -
12. Weight (cover) (g/㎡) -
13. Color (inner) 4
14. Paper (inner) Wood free
15. Weight (inner) (g/㎡) 70 (+/-10)
16. Coating No
17. Thomson No
18. Sub-material No
[Country Name] (ENG/FRE)
Changes the Country name. LGERS / LGEMX :
Printed in[Country Name in English] LGEKR :
Imprimé en(au)[Country Name in French] LGEMA :
LGEND :
LGEIN :
Others :
[Restriction of Hazardous Substances ]
Hazardous substances on this product should be satisfied by substance regulation of Level A-I, A-II, SVHC according to LG(52)B―5011 standard.
(1) Hazardous substances test report should be submitted when part certification test and first mass production.
(2) Especially, Don’t use or contain lead (Pb) and cadmium (Cd) in ink.
INK REQUIREMENT FOR EU
(1) The amount of MOAH/MOSH must be less than 0.1% of the weight of the INK used.
*MOAH(Mineral Oil Aromatic Hydrocarbons) : Consisting of 1 to 7 aromatic cycles
*MOSH(Mineral Oil Saturated Hydrocarbons) : Consisting of 16 to 35 carbon atoms
(2) From 01 January 2025 : Ban on the use of MOAH in INK up to a limit of one part per million(1ppm) for compounds of 3 to 7 aromatic cycles
REV07
REV06
REV05
REV04
REV03
REV02
REV01
Checked Nitin.H
Approved Santosh.C
Rev. Number Date ECO Number Owner Aditya.K
COVER
INNER
2. Origin Notification
ENG (1)
19. Languages
Each Country name.
NOTE
Especially, Part should be followed and controlled the following specification.
Printed in Mexico
Imprimé au Mexique
Printed in Korea
Imprimé en Corée
Printed in Poland
Imprimé en Pologne
Printed in China
Imprimé en Chine
Printed in Indonesia
Imprimé en Indonésie
Printing Specification
1. Specification 1.1 Folding / Cover
Models
SIZE
3. History
Description
REV00 2023-04-06
1
2
3
Barcode
Front Back
Folded Step
Folded
Front

OLED48A3*
OLED55/65A3* 21 43
21 3
!
*M F L 7 1 8 3 3 9 4 9 2 3 0 4 R E V 0 0*
Quick Start Guide
OLED A3*
Unpacking
Check your product box for the following items. If there are
any missing accessories, contact the local dealer where you
purchased your product. The illustrations in this manual may
differ from the actual product and item.
Images shown in manual may vary depending on model
www.lg.com

Do not look into the optical
output ports, looking at the
laser beam may damage
your vision
Audio with ACP (Audio Copy
Protection)function may
block digital audio output.
Some USB Hubs may not
work, if a USB device con-
nected using a USB Hub is
not detected, connect it to
the USB port on the TV
directly
Connect the external power
source if your USB is needed.
An external audio device that
supports SIMPLINK and ARC
must be connected using
HDMI IN eARC/ARC port
When connected with a
high-speed HDMI cable, the
external audio device that
supports ARC outputs SPDIF
audio without additional audio
cable and supports the
SIMPLINK function
ARC (Audio Return Channel)
Kg
A B C x D(mm) E
Wallmount
Bracket OLED48/55/65A3* 300x200 M6
B
A
C
D
E
90°
D
B
C
A
AB C D
(mm) (kg)
OLED48A3PSA 1070 620 45.9 11.5
OLED55A3PSA 1228 708 45.9 14.3
OLED65A3PSA 1449 832 45.9 17.1
