LG 27MP68VQ User manual

www.lg.com
LED LCD Monitor (LED Monitor) Model List
Please read this manual carefully before operating
your set and retain it for future reference.
Owner's Manual
LED LCD MONITOR
(LED MONITOR*)
*LG LED Monitors are LCD Monitors with LED Backlighting.
22MP68VQ
23MP68VQ
24MP68VQ
27MP68VQ

ENGLISH
2
CONTENTS
LICENSE ---------------------------- 3
ASSEMBLING AND PREPARING - 4
- Unpacking-------------------------------------- 4
- Supported Drivers and Software -------------- 5
- Parts and buttons ----------------------------- 6
- Moving and Lifting the Monitor --------------- 8
- Setting up the Monitor set ------------------- 9
USING THE MONITOR SET------ 14
- Connecting to a PC ---------------------------14
- Connecting to AV Devices -------------------- 15
- Connecting to External Devices -------------- 16
CUSTOMIZING SETTINGS ------ 17
- Customizing settings -------------------------18
Menu Settings
-Quick Settings
-Picture
-General
-Auto Configuration
-Reset
TROUBLESHOOTING ------------ 25
SPECIFICATIONS ---------------- 27
- Preset Modes (Resolution) -------------------31
- Indicator---------------------------------------31

3
ENG
ENGLISH
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing Ad-
ministrator, Inc.
The following content is only applied to the monitor which is sold in Europe market and which needs to
meet the ErP Directive:
* This monitor is set to be turned off automatically in 4 hours after you turned on display if there is no
adjustment to display.
* To make this setting be disabled, change the option to ‘Off’ in OSD menu of “Automatic Standby”.

4
ENG
ENGLISH
27MP67VQ24MP67VQ22MP67VQ 23MP67VQ
22MP67HQ 23MP67HQ 24MP67HQ 27MP67HQ
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual product
and accessories.
yDo not use any unapproved accessories to ensure the safety and product life span.
yAny damages or injuries by using unapproved accessories are not covered by the warranty.
yThe accessories supplied with your product may vary depending on the model.
yProduct specifications or contents in this manual may be changed without prior notice due to upgrade
of product functions.
CAUTION
NOTE
CD / Card
( Depending on the country ) ( Depending on the country )
Power Cord AC-DC Adapter
AC-DC Adapter
or
D-SUB Cable
( This cable is not included in all
countries. )
DVI-D Cable
( This cable is not included in all
countries. )
27MP67VQ24MP67VQ22MP67VQ 23MP67VQ
22MP67HQ 23MP67HQ 24MP67HQ 27MP67HQ
Stand Body Stand Base
HDMI Cable
( This cable is not
included in all countries. )
Cable Holder

5
ENG
ENGLISH
Supported Drivers and Software
You can download and install the latest version from the LGE website (www.lg.com).
Drivers and Software Installation Priority 22MP68VQ , 23MP68VQ
24MP68VQ , 27MP68VQ
Monitor Driver Recommended O
OnScreen Control Recommended O

6
ENG
ENGLISH
Parts and buttons
Joystick Button/
Power Indicator
yOn : power is on
yOff : power is off
yThe joystick button is located at the bottom of the monitor.
NOTE
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with
your finger.
Basic Functions
Power on Press the joystick button once with your finger to turn on the
monitor.
Power off Press and hold the joystick button once with your finger to turn off
the monitor.
◄/►Volume
Control You can control the volume by moving the joystick button left/right.

7
ENG
ENGLISH
Parts and buttons
Input Connector

8
ENG
ENGLISH
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these
instructions to prevent the monitor from being
scratched or damaged and to ensure safe trans-
portation regardless of its shape or size.
yAs far as possible, avoid touching the moni-
tor screen. This may result in damage to the
screen or some of the pixels used to create
images.
yIt is advisable to place the monitor in the
original box or packing material before at-
tempting to move it.
yBefore moving or lifting the monitor, discon-
nect the power cord and all cables.
yHold the top and bottom of the monitor frame
firmly. Do not hold the panel itself.
yWhen holding the monitor, the screen should
face away from you to prevent it being
scratched.
yWhen moving the monitor, avoid any strong
shock or vibrations to the product.
yWhen moving the monitor, keep it upright,
never turn the monitor on its side or tilt it
sideways.
CAUTION
yIf you use the monitor panel without the
stand base, its joystick button may cause
the monitor to become unstable and fall,
resulting in damage to the monitor or human
injury. In addition, this may cause the joystick
button to malfunction.

9
ENG
ENGLISH
Setting up the Monitor set
Attaching the Stand Base Detaching the Stand Base
2
1
3
3
2
1
3
3
Stand Body
Stand Base
Stand Body
Stand Base
Stand Body
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
11
* If it is difficult to remove, you can push the
Latch with a small flat-head screw driver or a
flat-headed tool and disassemble as shown
below.

2
1
3
3
Stand Base

10
ENG
ENGLISH
yIllustrations in this document represent typical
procedures, so they may look different from
the actual product.
yDo not carry the monitor upside down by just
holding the stand base. This may cause the
monitor to fall off the stand and could result in
personal injury.
yWhen lifting or moving the monitor, do not
touch the monitor screen. The force applied
to the monitor screen may cause damage to
it.
yIf you use the monitor panel without the stand
base, its joystick button may cause the moni-
tor to become unstable and fall, resulting in
damage to the monitor or human injury. In
addition, this may cause the joystick button to
malfunction.
Mounting on a table
1Lift and tilt the Monitor set into its upright
position on a table.
Leave a 100 mm (3.94 inches) space from the
wall for proper ventilation.
2Connect the AC-DC Adapter and Power Cord
to a wall outlet.
or
CAUTION
100 mm
(3.94 inches) 100 mm
(3.94 inches)
100 mm
(3.94 inches)
100 mm
(3.94 inches)
