LG 29UM67-P User manual

www.lg.com
29UM67
29UB67
34UM67
34UB67
Please read the safety information carefully before using the
product.
IPS LED Monitor (LED Monitor) Model List
Owner's Manual
IPS LED MONITOR
(LED MONITOR*)
*LG LED Monitors are LCD Monitors with LED Backlighting.

2
ENG
ENGLISH
Contents
CONTENTS
34 Customizing settings
34 - Menu Settings
34 - -Quick Settings
35 - -PBP
36 - -Picture
38 - -Sound
39 - -General
40 - -Reset
41 - -Picture mode
42 - -Game mode
44 TROUBLESHOOTING
46 SPECIFICATIONS
46 29UM67
47 29UB67
48 34UM67
49 34UB67
50 Factory support mode
(DVI-D/ HDMI/ DisplayPort)
50 HDMI Timing (Video)
50 Indicator
51 PROPER POSTURE
51 Proper Posture for Using the Monitor
3LICENSE
4ASSEMBLING AND
PREPARING
4Product Components
5Component and Button Description
8- How to Use the Joystick Button
9Moving and Lifting the Monitor
10 Installing the Monitor
10 - Assembling the stand base
13 - Using the cable holder
14 - Installing onto a table
15 - Adjusting the stand height
16 - Adjusting the angle
17 - Pivot feature
18 - Using the Kensington lock
18 - Installing the wall mount plate
19 - Installing to a wall
20 USING THE MONITOR
20 Connecting to a PC
20 - DVI connection
21 - DisplayPort connection
21 - HDMI connection
22 Connecting to AV Devices
22 - HDMI connection
23 Connecting to External Devices
23 - USB Cable connection - PC
23 - Connecting Headphones
24 INSTALLING THE LG
MONITOR SOFTWARE
33 USER SETTINGS

3
ENG
ENGLISH
LICENSE
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing Ad-
ministrator, Inc. in the United States and other countries.
VESA, VESA logo, Display Port Compliance Logo and Display Port
Compliance Logo for dual-mode source are all registered trademarks of the
Video Electronics Standards Association.
The following content is only applied to the monitor which is sold in Europe market and which needs to meet
the ErP Directive:
* This monitor is set to be turned off automatically in 4 hours after you turned on display if there is no
adjustment to display.
* To make this setting be disabled, change the option to ‘Off’ in OSD menu of “Automatic Standby”.

4
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Product Components
Please check whether all the components are included in the box before using the product. If there are
missing components, contact the retail store where you purchased the product. Note that the product and
components may look different from those shown here.
yAlways use genuine components to ensure safety and product performance.
yThe product warranty will not cover damage or injury caused by the use of counterfeit components.
yNote that the components may look different from those shown here.
yWithout prior notice, all information and specifications in this manual are subject to change to im-
prove the performance of the product.
yTo purchase optional accessories, visit an electronics store or online shopping site or contact the
retail store where you purchased the product.
yThe DisplayPort cable may not be available in some areas.
CAUTION
NOTE
CD(Owner's Manual) /
Card
OPTIONAL ACCESSORIES
The DisplayPort cable may not be
available in some areas.
Display Port Cable
Stand Base Stand Body
Screws
HDMI Cable
( This cable is not in-
cluded in all countries. )
( Depending on the country ) ( Depending on
the country )
Power Cord AC-DC Adapter AC-DC Adapter
or
DVI-D Dual Cable
( This cable is not included in
all countries. )
USB Cable
( This cable is not included
in all countries. )
Power Cord
Stand Base Stand Body
Stand Base
Screws Screws Cable HolderCable Holder
Clear sheet

5
ENG
ENGLISH
ASSEMBLING AND PREPARING
Component and Button Description
Power Indicator
yOn: power is on
yOff: power is off
Joystick Button
Input Connector

6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Joystick Button /
Power LED
yOn: power is on
yOff: power is off
Ports
Input Connector

7
ENG
ENGLISH
ASSEMBLING AND PREPARING
Power Indicator
yOn: power is on
yOff: power is off
Ports
Joystick Button
Input Connector

8
ENG
ENGLISH
ASSEMBLING AND PREPARING
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with
your finger.
Basic Functions
Power on Press the joystick button once with your finger to turn on the
monitor.
Power off Press and hold the joystick button once with your finger to turn off
the monitor.
◄/►Volume
Control You can control the volume by moving the joystick button left/right.
yThe joystick button is located at the bottom of the monitor.
NOTE

9
ENG
ENGLISH
ASSEMBLING AND PREPARING
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these
instructions to prevent the monitor from being
scratched or damaged and to ensure safe trans-
portation regardless of its shape or size.
yAs far as possible, avoid touching the moni-
tor screen. This may result in damage to the
screen or some of the pixels used to create
images.
yIt is advisable to place the monitor in the
original box or packing material before at-
tempting to move it.
yBefore moving or lifting the monitor, discon-
nect the power cord and all cables.
yHold the top and bottom of the monitor frame
firmly. Do not hold the panel itself.
yWhen holding the monitor, the screen should
face away from you to prevent it being
scratched.
yWhen moving the monitor, avoid any strong
shock or vibrations to the product.
yWhen moving the monitor, keep it upright,
never turn the monitor on its side or tilt it
sideways.
CAUTION
yIf you use the monitor panel without the
stand base, its joystick button may cause
the monitor to become unstable and fall,
resulting in damage to the monitor or human
injury. In addition, this may cause the joystick
button to malfunction.

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
Applying excessive force when tightening
the screws may cause damage to the moni-
tor. Damage caused in this way will not be
covered by the product warranty.
CAUTION
It may hurt your foot off the stand, so be
careful.
CAUTION
Installing the Monitor
Assembling the stand base
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
2First, please insert Stand Body to Stand Base,
Then tighten two screws into the back of the
stand base.
1Place the screen face down.
29UM67
4Tighten two screws into the back of the stand
body .
3Check the direction of the stand body
(front, back) and then mount the stand
body onto the stand hinge.
Stand Body
Stand Body
Stand Base
(Silver)
(Black)
or
120 mm
100 mm
(Black)
Stand Hinge yYou can disassemble the stand in the
reverse order of the assembly.
NOTE

11
ENG
ENGLISH
ASSEMBLING AND PREPARING
1 Place the screen face down.
Stand Hinge
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
2 Mount the stand base onto the stand hinge as
shown in the illustration. Fix two screws into
the back of the stand base and close the screw
cover.
Stand Base
120 mm
Screw Cover
or
100 mm
yThe stand height is adjustable by 20 mm
yWhen tightening the screws after mounting
the stand base onto the stand hinge, be sure
to hold the stand base with your hand. Other-
wise, the product may fall, causing personal
injury or damage to the product.
yBe careful not to hurt your hand on the edges
of the screw covers.
yApplying excessive force when tightening
screws may cause damage to the monitor.
Damage caused in this way will not be cov-
ered by the product warranty.
yIf you use the monitor panel without the
stand base, its joystick button may cause the
monitor to become unstable and fall, result-
ing in damage to the monitor or human injury.
In addition, this may cause the joystick button
to malfunction.
CAUTION
34UM67
yYou can disassemble the stand in the
reverse order of the assembly.
NOTE

12
ENG
ENGLISH
ASSEMBLING AND PREPARING
yTo protect the screen from scratches, cover
the surface with a soft cloth.
CAUTION
2
1Place the screen face down.
29UB67 34UB67
1
2
3
Remove a tape on the surface of stand body.
Use a tool to attach the stand body as shown
in the figure.
Check the position (at the front and rear) of
the stand body, then mount the stand base on
the stand body as shown in the figure.
Tighten the screw to the right.
It may hurt your foot off the stand, so be
careful.
CAUTION
Stand Body
Stand Body
Stand Base
Stand Base
Tape
yYou can disassemble the stand in the
reverse order of the assembly.
NOTE

13
ENG
ENGLISH
ASSEMBLING AND PREPARING
Using the cable holder
yIllustrations in this document represent typi-
cal procedures, so they may look different
from the actual product.
yApplying excessive force when tightening
screws may cause damage to the monitor.
Damage caused in this way will not be cov-
ered by the product warranty.
yBe careful not to hurt your hand on the edges
of the screw covers.
yDo not carry the monitor upside down by just
holding the base. This may cause the moni-
tor to fall off the stand and could result in
personal injury.
yWhen lifting or moving the monitor, do not
touch the monitor screen. The force applied
to the monitor screen may cause damage to
it.
CAUTION
29UM67
1First, as shown in the illustration,push the
cable holder on the stand body, Second ,Fix
the cable holder to stand body.
2Put the cables into the cable holder.
Stand Body
Tidy up cables using the cable holder on the stand
base as shown in the illustration.
34UM67
yCables can get caught in the hinge area as
shown in the illustration, so be careful when
organizing cables.
NOTE

14
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing onto a table
1Lift the monitor and place it on the table in an
upright position.
Place at least 100 mm away from the wall to
ensure sufficient ventilation.
2Connect the power adapter to the monitor and
then plug the power cord into the wall outlet.
29UB67:Press the knob in “ ” state.
(“ ” Open the power).
or
or
yUnplug the power cord prior to moving or
installing the monitor. There is risk of electric
shock.
CAUTION
3Press the joystick button on the bottom of the
monitor to turn on the monitor.
100 mm
100 mm
100 mm
100 mm
100 mm
100 mm
100 mm
100 mm

15
ENG
ENGLISH
ASSEMBLING AND PREPARING
yOnce the pin is removed, it is not necessary
to re-insert it to adjust the height.
Adjusting the stand height
2Remove the tape attached to the bottom
back of the stand body and then pull out the
locking pin while pressing the head down-
ward.
3The height can be adjusted up to 130.0 mm.
yDo not put your fingers or
hand between the screen
and the base (chassis) when
adjusting the screen's height.
Tape
Locking Pin
Stand Body
CAUTION
WARNING
1Stand the monitor assembled with the stand
base in an upright position
34UB67
130.0 mm
29UB67
Locking Pin
Locking Pin
Head
Head
130.0 mm

16
ENG
ENGLISH
ASSEMBLING AND PREPARING
Adjusting the angle
1Place the monitor in an upright position, mount-
ed on the stand base.
2Adjust the angle of the screen. The angle of the
screen can be adjusted forwards or backwards
for a comfortable viewing experience.
Front Side
Rear Side
Front Side
Rear Side
Front Side
Rear Side
yTo avoid injury to the fingers when adjusting
the screen, do not hold the lower part of the
monitor's frame as illustrated below.
WARNING
yBe careful not to touch or press the screen
area when adjusting the angle of the monitor.

17
ENG
ENGLISH
ASSEMBLING AND PREPARING
yTo avoid scratching the stand base, make
sure that when rotating the monitor using
the pivot feature, the stand does not make
contact with the monitor.
WARNING
Pivot feature
The pivot feature allows the monitor to rotate 90
clockwise.
29UB67
1Raise the monitor up to the maximum height.
2Adjust the angle of the monitor in the direction
of the arrow as shown in the figure.
3Rotate the monitor clockwise as shown in the
figure.
4Complete the installation by rotating the
monitor 90° as shown below.
yTake care when rotating the monitor if the
cable is connected.
WARNING
yAn image displayed on the monitor's screen
does not rotate according to the screen
orientation.
NOTE
Head
Stand
WARNING
yTo avoid injury to the fingers when adjusting
the screen, do not hold the lower part of the
monitor's frame as illustrated below.

18
ENG
ENGLISH
ASSEMBLING AND PREPARING
Installing the wall mount plate
This monitor supports the specification of the stan-
dard wall mount plate or compatible device.
1Place the screen face down. To protect the
screen from scratches, cover the surface with a
soft cloth.
2Attach the clear sheet to the back of the
monitor and align it with the screw holes.
(34UM67/34UB67)
3Place the wall mount plate onto the monitor
and align it with the screw holes.
4Tighten the four screws to fix the plate to the
monitor using a screwdriver.
yThe wall mount plate is sold separately.
yFor more information on installation, refer to
the wall mount plate's installation guide.
yBe careful not to use excessive force when
mounting the wall mount plate, as this can
damage the monitor's screen.
NOTE
yUse of the Kensington lock is optional.
The accessories can be purchased at
your local electronics store.
NOTE
Using the Kensington lock
The Kensington security system connector is locat-
ed at the back of the Monitor set.
For more information on installation and usage,
refer to the Kensington lock user manual or visit
the website at http://www.kensington.com.
Connect the Kensington security system cable
between the Monitor set and a table.
Clear sheet
(PET sheet)

19
ENG
ENGLISH
ASSEMBLING AND PREPARING
To install the monitor to a wall, attach a wall mount-
ing bracket (optional) to the back of the monitor.
Make sure that the wall mounting bracket is securely
fixed to the monitor and to the wall.
1If you use screw longer than standard, the moni-
tor might be damaged internally.
2If you use improper screw, the product might be
damaged and drop from mounted position.
In this case, LG Electronics is not responsible
for it.
Installing to a wall
Install the monitor at least 100 mm away from the
wall and leave about 100 mm of space at each
side of the monitor to ensure sufficient ventilation.
Detailed installation instructions can be obtained
from your local retail store. Please refer to the
manual to install and set up a tilting wall mounting
bracket.
yUnplug the power cord before moving or in-
stalling the monitor to avoid electric shocks.
yInstalling the monitor on the ceiling or on a
slanted wall may result in the monitor falling
off, which could lead to injury. Please use
the genuine LG wall mounting bracket. For
more information, contact your local retail
store or a qualified installer.
yApplying excessive force when fastening
screws may cause damage to the moni-
tor. Damage caused in this way will not be
covered by the product warranty.
yUse the wall mounting bracket and screws
that conform to the VESA standard. Dam-
age caused by the use or misuse of inap-
propriate components will not be covered
by the product warranty.
yScrew length from outer surface of back
cover should be under 8mm.
yUse the screws specified by the VESA stan-
dard.
yThe wall mount kit includes the installation
guide and all necessary parts.
yThe wall mounting bracket is optional. The
accessories can be purchased at your local
retail store.
yThe length of the screw may differ for each
wall mounting bracket. Ensure the correct
length screw is used.
yFor more information, please refer to the
user manual for the wall mounting bracket.
CAUTION
NOTE
Wall mount Pad
Wall mount Pad
Back Cover
Back Cover
Standard screw
Max.8mm
yWall Mount (A x B)
A
B
Model
Wall Mount
(A x B)
75 x 75 100 x 100 200 x 100
Standard
screw M4 x L10 M4 x L10
Number of
screws 4 4
Wall Mount
Plate
(Optional)
RW120 LSW140
29UM67 29UB67
34UM67
34UB67
100 mm
100 mm
100 mm
100 mm

20
ENG
ENGLISH
USING THE MONITOR
USING THE MONITOR
Connecting to a PC
yThis monitor supports the *Plug and Play
feature.
*Plug and Play: A feature that allows you to
add a device to your computer without having
to reconfigure anything or install any manual
drivers.
DVI connection
Transmits digital video signals to the monitor. Con-
nect the monitor using the DVI cable as illustrated
below.
Press the menu button and then select the input
option from the input menu.
To hear the sound in DVI input mode, connect the
PC's AUDIO OUT port to the monitor's AUDIO IN
(PC) port using the audio cable that came with the
product.
yConnect the input signal cable and
turn in the direction of the arrow.
To prevent disconnection secure
the cable tightly.
yDo not press on the screen for a
prolonged period of time. This may cause
image distortion.
yDo not display a still image on the screen
for a prolonged period of time. This may
cause image retention. If possible, use the
screen saver.
CAUTION
yWhen connecting the power cord to the out-
let, use a grounded (3-hole) multi-socket or a
grounded power outlet.
yThe monitor may flicker when turned on in an
area of low temperature. This is normal.
ySometimes red, green, or blue spots may ap-
pear on the screen. This is normal.
yUsing a DVI to HDMI cable may cause com-
patibility issues.
NOTE
(sold separately)
