LG 34WP65CP User manual

* LG LED Monitor applies LCD screen with LED
backlights.
Please read this manual carefully before operating
your set and retain it for future reference.
OWNER’S MANUAL
LED LCD MONITOR
(LED Monitor*)
34WP65C
34WP65CP
34BP65C
www.lg.com
Copyright © 2021 LG Electronics Inc. All Rights Reserved.

2
ENGLISH
2
TABLE OF CONTENTS
LICENSE.......................................3
OPEN SOURCE SOFTWARE
NOTICE INFORMATION ..............4
ASSEMBLING AND PREPARING 4
- Supported Drivers and Software .........................4
- Product and Button Description...........................5
How to Use the Joystick Button
- Moving and Lifting the Monitor............................5
Installing on a Table
Adjusting the Stand Height
Adjusting the Angle
Using the Kensington Lock
Installing the Wall Mount Plate
Installing on the Wall
USING THE MONITOR.............. 10
- Connecting to a PC...................................................10
HDMI Connection
DisplayPort Connection
- Connecting AV Devices...........................................11
HDMI Connection
- Connecting Peripherals...........................................12
Connecting Headphones
USER SETTINGS ....................... 13
- Activating the Main Menu ....................................13
Main Menu Features
- User Settings ...............................................................15
Menu Settings
TROUBLESHOOTING................ 26
PRODUCT SPECIFICATION ...... 29
- Factory Support Mode (Preset Mode, PC)..31
- HDMI Timing (Video)................................................32
- Beep Guide ...................................................................33

3
ENGLISH
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.
MaxxAudio and additional MAXX trademarks are trademarks and/or registered trademarks of Waves Audio Ltd.

4
ENGLISH
OPEN SOURCE SOFTWARE
NOTICE INFORMATION
To obtain the source code under GPL, LGPL, MPL, and other open source licenses,
that is contained in this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and
copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge
covering the cost of performing such distribution (such as the cost of media,
shipping, and handling) upon email request to opensourc[email protected].
This offer is valid for a period of three years after our last shipment of this product.
This offer is valid to anyone in receipt of this information.
ASSEMBLING AND PREPARING
CAUTION
•Always use genuine LG components to ensure safety and product performance.
•The product warranty will not cover damage or injury caused by the use of
unauthorized components.
•It is recommended that use the supplied components.
•If you use generic cables not certified by LG, the screen may not display or there
may be image noises.
•Illustrations in this document represent typical procedures, so they may look
different from the actual product.
•Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when
assembling the product. (Doing so may damage the product.)
•Applying excessive force when tightening screws may cause damage to the
monitor. Damage caused in this way will not be covered by the product warranty.
•Do not carry the monitor upside down by just holding the base. This may cause the
monitor to fall off the stand and could result in personal injury.
•When lifting or moving the monitor, do not touch the monitor screen. The force
applied to the monitor screen may cause damage to it.
NOTE
•The components may look different from those illustrated here.
•Without prior notice, all product information and specifications contained in this
manual are subject to change to improve the performance of the product.
•To purchase optional accessories, visit an electronics store or an online shopping
site, or contact the retailer from which you purchased the product.
•The power cord provided may differ depending upon the region.
Supported Drivers and Software
You can download and install the latest version from the LGE website ( www.lg.com ).
Drivers and Software Installation Priority
Monitor Driver Recommended
OnScreen Control Recommended
Dual Controller Optional

5
ENGLISH
Product and Button Description
Joystick Button
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or
moving it left/right/up/down with your finger.
Basic Functions
Power on Press the joystick button once with
your finger to turn on the monitor.
Power off
Press and hold the joystick button
once more than 5 seconds with your
finger to turn off the monitor.
/ Volume control You can control the volume by
moving the joystick button left/right.
NOTE
•The joystick button is located at the bottom of the monitor.
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these instructions to prevent the monitor
from being scratched or damaged and to ensure safe transportation, regardless of
its shape or size.
•Place the monitor in the original box or packing material before attempting to move it.
•Before moving or lifting the monitor, disconnect the power cord and all other cables.
•Hold the bottom and side of the monitor frame firmly. Do not hold the panel itself.
•When holding the monitor, the screen should face away from you to prevent it
from being scratched.
•When transporting the monitor, do not expose the monitor to shock or excessive
vibration.
•When moving the monitor, keep it upright and never turn the monitor on its side or
tilt it sideways.
CAUTION
•Avoid touching the monitor screen as much as possible.
- This may result in damage to the screen or some of the pixels used to create
images.
•If you use the monitor panel without the stand base, its joystick button may cause
the monitor to become unstable and fall, resulting in damage to the monitor or
human injury. In addition, this may cause the joystick button to malfunction.

6
ENGLISH
Installing on a Table
•Lift the monitor and place it on the table in an upright position. Place the monitor
at least 100mm (3.94 inches) away from the wall to ensure sufficient ventilation.
100 mm
100 mm
100 mm
100 mm
CAUTION
•Unplug the power cord before moving or installing the monitor. There is risk of
electric shock.
•Make sure to use the power cord that is provided in the product package and
connect it to a grounded power outlet.
•If you need another power cord, please contact your local dealer or the nearest
retail store.
Adjusting the Stand Height
1 Place the monitor mounted on the stand base in an upright position.
2 Handle the monitor with both hands for safety.
Max. 110.0 mm
WARNING
•When adjusting the screen height, do not place your hand on the stand body to
avoid injury to your fingers.

7
ENGLISH
Using the Kensington Lock
The connector for the Kensington security system is located at the bottom of the
monitor.
For more information on installation and usage, refer to the Kensington lock owner’s
manual or visit the website at http://www.kensington.com.
Connect the monitor to a table using the Kensington security system cable.
NOTE
•The Kensington security system is optional. You can obtain optional accessories
from most electronics stores.
Adjusting the Angle
1 Place the monitor mounted on the stand base in an upright position.
2 Adjust the angle of the screen.
The angle of the screen can be adjusted forward or backward from -5° to 20° for a
comfortable viewing experience.
WARNING
•To avoid injury to the fingers when adjusting the screen, do not hold the lower part
of the monitor’s frame as illustrated below.
•Be careful not to touch or press the screen area when adjusting the angle of the
monitor.
NOTE
•The left or right side of the monitor head can be slightly rotated up or down (up to
3°). Adjust the horizontal level of the monitor head.
Monitor head

8
ENGLISH
Installing the Wall Mount Plate
This monitor meets the specifications for the wall mount plate or other compatible
devices.
NOTE
•The wall mount plate is sold separately.
•For more information on installation, refer to the wall mount plate’s installation
guide.
•Be careful not to apply too much force while mounting the wall mount plate as it
may cause damage to the screen.
•Remove the stand before installing the monitor on a wall mount by performing the
stand attachment in reverse.
Installing on the Wall
Install the monitor at least 100mm (3.94 inches) away from the wall and leave
about 100mm (3.94 inches) of space at each side of the monitor to ensure
sufficient ventilation. Detailed installation instructions can be obtained from your
local retail store. Alternatively, please refer to the manual for how to install and set
up a tilting wall mounting bracket.
100 mm
(3.94 inches)
100 mm
(3.94 inches)
100 mm
(3.94 inches) 100 mm
(3.94 inches)
To install the monitor to a wall, attach a wall mounting bracket (optional) to the back
of the monitor.
Make sure that the wall mounting bracket is securely fixed to the monitor and to the
wall.
1 If you use screws longer than the standard length, it may damage the inside of
the product.
2 A non-VESA standard screw may damage the product and cause the monitor
to fall. LG Electronics is not liable for any accidents relating to the use of non-
standard screws.
Wall Mount (mm) 100 x 100
Standard screw M4 x L10
Number of screws 4
Wall Mount Plate (Optional) LSW 149

9
ENGLISH
NOTE
•Use the screws specified by VESA standards.
•The wall mount kit includes the installation guide and all necessary parts.
•The wall mounting bracket is optional. You can obtain optional accessories from
your local dealer.
•The length of the screw may differ for each wall mounting bracket. Be sure to use
the proper length.
•For more information, please refer to the user manual for the wall mounting
bracket.
CAUTION
•Unplug the power cord before moving or installing the monitor to avoid electric
shock.
•Installing the monitor on the ceiling or on a slanted wall may result in the monitor
falling off, which could lead to injury. Use an authorized LG wall mount and contact
the local dealer or qualified personnel.
•Applying excessive force when tightening screws may cause damage to the
monitor. Damage caused in this way will not be covered by the product warranty.
•Use the wall mounting bracket and screws that conform to VESA standards.
Damage caused by the use or misuse of inappropriate components will not be
covered by the product warranty.
•When measured from the back of the monitor, the length of each installed screw
must be 8 mm (0.3 inches) or less.
Wall Mount Plate
Back of the Monitor
Screw
Dimensions
: M4 x L10
Wall Mount Plate
Back of the
Monitor
Max. 8 mm (0.3 inches)

10
ENGLISH
USING THE MONITOR
•Illustrations in this manual may differ from the actual product.
Press the joystick button, go to Settings →Input, and then select the input option.
CAUTION
•Do not press the screen for a prolonged time. This may cause image distortion.
•Do not display a still image on the screen for a prolonged time. This may cause
image retention. Use a screensaver if possible.
NOTE
•When connecting the power cord to the outlet, use a grounded (3-hole) power
strip or a grounded power outlet.
•The monitor may flicker when turned on in an area where the temperature is low.
This is normal.
•Sometimes red, green, or blue spots may appear on the screen. This is normal.
Connecting to a PC
•This monitor supports the *Plug and Play feature.
* Plug and Play: A feature that allows you to add a device to your computer without
having to reconfigure anything or install any manual drivers.
HDMI Connection
Transmits digital video and audio signals from your PC to the monitor.
CAUTION
•Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility
issues.
•Use a certified cable with the HDMI logo attached. If you do not use a certified
HDMI cable, the screen may not display or a connection error may occur.
•Recommended HDMI cable types
- High-Speed HDMI®/TM cable
- High-Speed HDMI®/TM cable with Ethernet

11
ENGLISH
DisplayPort Connection
Transmits digital video and audio signals from your PC to the monitor.
NOTE
•There may be no video or audio output depending on the DP (DisplayPort) version
of the PC.
•If you are using a Mini DisplayPort output graphics card, use a Mini DP to DP (Mini
DisplayPort to DisplayPort) cable or gender that supports DisplayPort1.4. (sold
separately)
Connecting AV Devices
HDMI Connection
HDMI transmits digital video and audio signals from your AV device to the monitor.
NOTE
•Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility
issues.
•Use a certified cable with the HDMI logo attached. If you do not use a certified
HDMI cable, the screen may not display or a connection error may occur.
•Recommended HDMI cable types
- High-Speed HDMI®/TM cable
- High-Speed HDMI®/TM cable with Ethernet

12
ENGLISH
Connecting Peripherals
Connecting Headphones
Connect peripherals to the monitor via the headphones port.
NOTE
•Peripheral devices are sold separately.
•If you use angled earphones, it may cause a problem with connecting another external
device to the monitor. Therefore, it is recommended to use straight earphones.
Angled Straight
(Recommend)
•Depending on the audio settings of the PC and external device, headphones and
speaker functions may be limited.

13
ENGLISH
USER SETTINGS
NOTE
•Your monitor’s OSD (On Screen Display) may differ
slightly from that shown in this manual.
•When Beep Guide is activated, pressing the joystick
button will take you to Settings right away.
Activating the Main Menu
1 Press the joystick button on the bottom of the
monitor.
2 Move the joystick up/down ( / ) and left/right
(/ ) to set the options.
3 Press the joystick button once more to exit the
main menu.
Joystick Button
Button Menu Status Description
Main menu disabled Enables the main menu.
Main menu enabled
Exits the main menu.
(Holding down the button to turn off the monitor. You can
turn off the monitor this way at any time, including when the
OSD is on.)
Main menu disabled Adjusts the monitor volume level.
Main menu enabled Enters the Input features.
Main menu disabled Adjusts the monitor volume level.
Main menu enabled Enters the Settings feature.
Main menu disabled Enters the Accessibility menu.
Main menu enabled Turns off the monitor.
Main menu disabled Enters the Accessibility menu.
Main menu enabled Enters the Game Mode feature.

14
ENGLISH
Main Menu Features
Main Menu Description
Input Sets input mode.
Power Off Turns off the monitor.
Settings Configures the screen settings.
Game Mode Sets the game mode for gaming.
Exit Exits the main menu.
Power Off
Input Settings
Game Mode
Exit

15
ENGLISH
User Settings
Menu Settings
1 To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Settings.
2 Configure the options by moving the joystick up/down/left/right.
3 To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
4 If you want to exit the OSD menu, move the joystick to until you exit.
Game Mode Game Adjust Picture Adjust Input General

16
ENGLISH
Game Mode on SDR(Non-HDR)signal.
Settings > Game Mode Description
Game Mode
Gamer 1 In this mode, users can customize elements including game-related options.
Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup
options.
Gamer 2
FPS This mode is optimized for FPS games.
RTS This mode is optimized for RTS Game.
Vivid Optimized the screen for vivid colors.
Reader Optimizes the screen for viewing documents. You can brighten the screen in the OSD menu.
HDR Effect Optimizes the screen for high dynamic range.

17
ENGLISH
Game Mode on HDR signal.
Settings > Game Mode Description
Game Mode
Gamer 1 In this mode, users can customize elements including game-related options.
Gamer 1 and Gamer 2 picture modes allow you to save two sets of customized display settings, including game-related setup
options.
Gamer 2
FPS This mode is optimized for FPS games.It is suitable for very dark FPS games.
RTS This mode is optimized for RTS Game.
Vivid Optimized the screen for vivid colors.
NOTE
•HDR content may not be operated properly depending on the Windows10 OS setting. Please check the HDR On / Off setting of Windows.
•When the HDR function is turned on, the characters or picture quality may be poor according to Graphic card performance.
•While the HDR function is on, screen flickering or cracking may occur when changing the monitor input or power on/off according to Graphic card
performance.

18
ENGLISH
Settings > Game Adjust Description
Game Adjust
1ms Motion Blur
Reduction
On
This mode minimizes motion blur in fast-moving videos. To take full advantage of this function, select 3440 x 1440
before enabling 1ms Motion Blur Reduction.
This function is available for the following vertical frequency. (HDMI 85Hz, DP 100,144,160Hz)
Off
Turns 1ms Motion Blur Reduction Mode off.
NOTE
•To reduce motion blur, brightness is reduced with backlight control.
•1ms Motion Blur Reduction and FreeSync feature can not used at the same time.
•This function is game-optimized.
•It is recommended to turn off when you are not using the gaming function.
•Flicker may occur during 1ms Motion Blur Reduction operation.

19
ENGLISH
Game Adjust
FreeSync Premium
Provides seamless and natural images by synchronizing the vertical frequency of the input signal with that of the output
signal.
CAUTION
•Supported Interface: DisplayPort.
•Supported Graphic Card : A graphic card that supports AMD’s FreeSync is necessary.
•Supported Version : Make sure to update the graphic card to the latest driver.
•For more information and requirement, refer to AMD website at http://www.amd.com/FreeSync
•FreeSync Premium and 1ms Motion Blur Reduction cannot be enabled simultaneously.
Extended Enable wider frequency range of FreeSync function than basic mode.
The screen may flicker during the game play.
Basic Enable basic frequency range of FreeSync function.
Off FreeSync function off.
Black Stabilizer
You can control the black contrast to have better visibility in dark scenes.
Increasing the Black Stabilizer value brightens the low gray level area on the screen. (You can easily distinguish objects on dark
game screens.)
Reducing the Black Stabilizer value darkens the low gray level area and increases the dynamic contrast on the screen.

20
ENGLISH
Game Adjust
Response Time
Sets a response time for displayed pictures based on the speed of the screen.
For a normal environment, it is recommended that you use Fast.
For a fast-moving picture, it is recommended that you use Faster.
Once Faster Mode is selected, Motion Blur may occur depending on the content.
Faster Sets the response time to Faster.
Fast Sets the response time to Fast.
Normal Sets the response time to Normal.
Off Does not use the response time improvement feature.
Crosshair Crosshair provides a mark on the center of the screen for First Person Shooter (FPS) games. Users can select the Crosshair that fits
their gaming environment among four different Crosshairs.
Game Reset
Do you want to reset your Game settings?
No Cancel the select.
Yes Returns to the default settings.
