LG 42PM4M User manual

Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote
this information to your dealer
when you require service.
OWNER’S MANUAL
PLASMA
MONITOR
MODELS:50PM4M
P/NO: MFL36274107 (0708-REV00)
Printed in Korea

1
WARNING / CAUTION
WARNING / CAUTION
To prevent ire or shock hazards, do not expose
this product to rain or moisture.
FCC NOTICE
Class B digital device
This equipment has been tested and found to comply
ith the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance ith the
instructions, may cause harmful interference to radio
communications. Ho ever, there is no guarantee that
interference ill not occur in a particular installation.
If this equipment does cause harmful interference to
radio or television reception, hich can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by one
or more of the follo ing measures:
- Reorient or relocate the receiving antenna.
- Increase the separation bet een the equipment and
receiver.
- Connect the equipment to an outlet on a circuit
different from that to hich the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
A y cha ges or modificatio s ot expressly approved
by the party respo sible for complia ce could void
the user’s authority to operate the equipme t.
CAUTION
Do not attempt to modify this product in any ay
ithout ritten authorization from LG Electronics.
Unauthorized modification could void the user’s
authority to operate this product
The lightning flash ith arro head
symbol, ithin an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” ithin the
product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point ithin an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the litera-
ture accompanying the appliance.
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
WARNING/CAUTION
TO REDUCE THE RISK OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the National
Electric Code (U.S.A.). The code provides guidelines for
proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system
of the building, as close to the point of the cable entry
as practical.

2Plasma Monitor
Safety Instructions
WARNING/CAUTION
TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
Do not place the set in direct sunlight or near heat sources such as heat registers, stove and so on.
-This may cause a fire.
Do not use the set in damp place such as a bathroom or any place where it is likely to get wet.
- This may cause a fire or could give an electric shock.
Bend antenna cable between inside and outside building to prevent rain from flowing in.
-This may cause water damaged inside the set and could give an electric shock.
Earth wire should be connected.
- If the earth wire is not connected, there is possible a danger of electric shock caused by the current leakage.
- If grounding methods are not possible, a separate circuit breaker should be employed and installed by a qualified electrician.
- Do not connect ground to telephone wires, lightning rods or gas pipe.
Do not place anything containing liquid on top of the set.
- This may cause a fire or could give an electric shock.
Do not insert any object into the exhaust vent.
- This may cause a fire or could give an electric shock.
Do not place heavy objects on the set.
- This may cause serious injury to a child or adult.
Do not use water while cleaning the set.
- This may cause damaged the set or could give an electric shock.
In case of smoke or strange smell from the set, switch it off ,unplug it from the wall outlet and contact your dealer
or service center.
- This may cause a fire or could give an electric shock.
Do not attempt to service the set yourself. Contact your dealer or service center.
- This may cause damaged the set or could give an electric shock.
During a lightning thunder, unplug the set from the wall outlet and don’t touch an antenna cable.
- This may cause damaged the set or could give an electric shock.
WARNING
Safety Instructions
Safety Instructions

Owner’s Manual 3
ENGLISH
Safety Instructions
Never touch the power plug with a wet hand.
- This may cause an electric shock.
Disconnect from the mains and remove all connections before moving.
Do not place the set in a built-in installation such as a bookcase or rack.
- Ventilation required.
When installing the set on a table, be careful not to place the edge of its stand.
- This may cause the set to fall, causing serious injury to a child or adult, and serious damage to the set.
Do not place an outside antenna in the vicinity of overhead power lines or other electric light or power circuits.
- This may cause an electric shock.
There should be enough distance between an outside antenna and power lines to keep the former from touching the
latter even when the antenna falls.
- This may cause an electric shock.
Do not pull the cord but the plug when unplugging.
- This may cause a fire.
Ensure the power cord doesn’t trail across any hot objects like a heater.
- This may cause a fire or an electric shock.
Do not plug when the power cord or the plug is damaged or the connecting part of the power outlet is loose.
- This may cause a fire or an electric shock.
Dispose of used batteries carefully to protect a child from eating them.
- In case that it eats them, take it to see a doctor immediately.
When moving the set assembled with speakers do not carry holding the speakers.
- This may cause the set to fall, causing serious injury to a child or adult, and serious damage to the Monitor.
Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
- This may cause damaged the set or could give an electric shock.
Contact the service center once a year to clean the internal part of the set.
- Accumulated dust can cause mechanical failure.
The distance between eyes and the screen should be about 5 ~ 7 times as long as diagonal length of the screen.
- If not, eyes will strain.
Unplug the set from the wall outlet when it is left unattended and unused for long periods of time.
- Accumulated dust may cause a fire or an electric shock from
deterioration or electric leakage.
NOTES
*Safety instructions have two kinds of information, and each meaning of it is as below.
Take care of danger that may happen under specific condition.
The violation of this instruction may cause serious injuries and even death.
The violation of this instruction may cause light injuries or damage of the
product.
WARNING
NOTES

4Plasma Monitor
Safety Instructions
Safety Instructions continued
Safety Instructions continued
CAUTION concerning the Power Cord :
-Most appliances recommend they be connected to a dedicated circuit; that is,
a single outlet circuit which powers only that appliance and has no additional
outlets or branch circuits.
- This may cause a fire or an electric shock.
-Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords,
or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire.
Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, discon-
tinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer.
-Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance.
-Use a dedicated power cord. Do not modify or extend the power cord.
- Do not install, remove, or reinstall the unit by yourself (customer).
For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized Service Center. For installation, always
contact the dealer or an Authorized Service Center.
- Do not use if the power cord or plug is damaged, or socket is loose. Use a dedicated outlet for this appliance.
-Do not over bend the power cord and do not place anything on the power cord. Do not install the monitor near any sharp
edge to avoid wire damage.
Outdoor Use Marking :
- WARNING - To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This Appliance To Rain Or Moisture.
Wet Location Marking :
-Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on
the apparatus.

Owner’s Manual 5
ENGLISH
Contents
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2~4
Introduction
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Controls and Connection Options . . . . . . . . . .8~9
Remote Control Key Functions . . . . . . . . . . . . .10
Installation
Installation Instructions . . . . . . . . . . . . . . . . . . . . .11
External Equipment Connections . . . . . . . . . .12~16
VCR Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Cable TV Setup . . . . . . . . . . . . . . . . . . . . . . . .12
External A/V Source Setup . . . . . . . . . . . . . . . .13
DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
DTV Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
PC Setup . . . . . . . . . . . . . . . . . . . . . . . . . .15~16
Operation
Turning on the Monitor . . . . . . . . . . . . . . . . . . . . .17
Menu Language Selection . . . . . . . . . . . . . . . . . .17
Picture Menu Options
PSM (Picture Status Memory) . . . . . . . . . . . . . .18
Manual Picture Control (Off option) . . . . . . . . . .18
CSM (Colour Status Memory) . . . . . . . . . . . . . .18
Manual Color Temperature Control . . . . . . . . . .19
XD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Advanced - Cinema . . . . . . . . . . . . . . . . . . . . .20
Advanced - Black level . . . . . . . . . . . . . . . . . . .20
Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Sound Menu Options
SSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
AVL (Auto Volume Leveler) . . . . . . . . . . . . . . . .22
Balanec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Speacker . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Timer Menu Options
Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . .24
On/Off Timer Setup . . . . . . . . . . . . . . . . . . . . .24
Auto Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Special Menu Options
Child Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ISM (Image Sticking Minimization) Method . . . .26
Tile mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Low Power . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
XD DEMO . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Screen Menu Options
Auto Configure . . . . . . . . . . . . . . . . . . . . . . . . .29
Manual Configure (RGB-PC mode only) . . . . . .29
Selecting Wide XGA mode . . . . . . . . . . . . . . . .30
Setting the Picture Format . . . . . . . . . . . . . . . .30
Initializing (Reset to original factory settings) . . .31
External Control Device Setup . . . . . . . . . . . . .32~37
IR Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38~39
Programming the remote . . . . . . . . . . . . . . . . . . . . .40
Programming Codes . . . . . . . . . . . . . . . . . . . . . .41~42
Troubleshooting Checklist . . . . . . . . . . . . . . . . . . .43
Product Specifications . . . . . . . . . . . . . . . . . . . . . . .44
Contents
Contents
After reading this manual, keep it handy for future reference.

6Plasma Monitor
Introduction
Introduction
Introduction
What is a Plasma Display Panel?
If voltage is applied to gas within glass panels, ultraviolet rays are produced and fused with a fluorescent substance. At that
instant, light is emitted. A Plasma Display is a next generation flat Display using this phenomenon.
160° - Wide angle range of vision
Your flat panel plasma screen offers an exceptionally broad viewing angle -- over 160 degrees. This means that the display is
clear and visible to viewers anywhere in the room.
Wide Screen
The screen of the Plasma Display is 42 or 50" so wide that your viewing experience is as if you are in a theater.
Versatile
The light weight and thin size makes it easy to install your plasma display in a variety of locations where conventional TVs would
not fit.
The Plasma Monitor Manufacturing Process: Why minute colored dots may be present on the Plasma
Monitor screen
The Plasma Display Panel which is the display device of this product is composed of 0.9 to 2.2 million cells. A few cell defects will
normally occur in the Plasma Monitor manufacturing process. Several minute colored dots visible on the screen should be accept-
able. This also occurs in other Plasma Monitor manufacturers' products and the tiny dots appearing does not mean that this
Plasma Monitor is defective. Thus a few cell defects are not sufficient cause for the Plasma Monitor to be exchanged or returned.
Our production technology is designed to minimize cell defects during the manufacture and operation of this product.
Cooling Fan Noise
In the same way that a fan is used in a PC computer to keep the CPU (Central Processing Unit) cool, the Plasma Monitor is
equipped with cooling fans to cool the Monitor and improve its reliability. Therefore, a certain level of noise could occur while the
fans are operating and cooling the Plasma Monitor.
The fan noise doesn't have any negative effect on the Plasma Monitor's efficiency or reliability. The noise from these fans is nor-
mal during the operation of this product. We hope you understand that a certain level of noise from the cooling fans is acceptable
and is not sufficient cause for the Plasma Monitor to be exchanged or returned.
WARNING
TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.

Ensure that the following accessories are included with your plasma display. If an accessory is missing, please contact the dealer
where you purchased the product.
Video cables Audio cables
-Optional extras can be changed or modified for quality improvement without any notification new optional extras can be added.
- Contract your dealer for buying these items.
Option Extras
Option Extras
Desktop stand speaker
Owner’s Manual 7
Introduction
ENGLISH
Accessories
Accessories
Use the ferrite core with the speaker cables
The ferrite core given as a bundled accessory can be used to reduce the electromagnetic
waves in the connection to the speakers.
Wind the speaker cable on the ferrite core twice, and then plug the cables into the monitor
and the speakers as shown in the following picture:
Owner’s Manual
1.5V
1.5V
Batteries Power Cord
AV
SLEEP PSM ARC AUTO
MENU EXIT
MUTE
*
POWER
1 2 3
4 5 6
7 8 9
0
INPUT
SET
Remote Control
D-sub 15 pin Cable
Tilt wall mounting bracket

8Plasma Monitor
Introduction
Controls
Controls
Front Panel Controls
Front Panel Controls
-Here shown may be somewhat different from your set.
1.Power Standby Indicator
Illuminates red in standby mode, Illuminates green when the
Set is turned on.
2. Remote Control Sensor
3. VOLUME (FF,GG) Buttons
4. EE, DDButtons
5. MENU Button
6. INPUT SELECT Button
7. Main Power Button
Switches the set on from standby or off to standby.
2
1
3
4
5
6
7

Owner’s Manual 9
Introduction
ENGLISH
Connection Options
Connection Options
Back Connection Panel
Back Connection Panel
-Here shown may be somewhat different from your set.
REMOTE
CONTROL IN
AUDIO
(RGB/DVI)
HDMI/DVI IN
RL
RS-232C
(CONTROL/SERVICE)
OUT
IN
RGB
OUT
IN
COMPONENT IN
VIDEO
2
1
L-AUDIO-R
L-AUDIO-R S-VIDEO
AV IN
VIDEO
AV
OUT
EXTERNAL SPEAKER
15
2 3 78
9
1. REMOTE CONTROL IN
2. RS-232C INPUT(CONTROL/SERVICE) PORT
Connect to the RS-232C port on a PC.
3. HDMI/DVI IN
Connect a HDMI signal to this jack. Or connect a DVI(Video)
signal.
4. RGB INPUT
Connect the set output connector from a PC to the
appropriate input port.
RGB OUTPUT
You can watch the RGB signal on another set, connect RGB
OUTPUT to another set’s PC input port.
5. AUDIO (RGB/DVI)
Connect the monitor output from a PC to the appropriate
input port.
6. COMPONENT INPUT 1-2
Connect a component video/audio device to these jacks.
7. AV IN
S-VIDEO/AUDIO IN SOCKETS
Connect the S-VIDEO out socket of an VCR to the S-VIDEO
socket.
Connect the audio out sockets of the VCR to the audio sock-
ets as in AV.
8. EXTERNAL SPEAKER (8 ohm output)
Connect to optional external speaker(s).
* For further information, refer to ‘Speaker & Speaker
Stand’ manual.
9. POWER CORD SOCKET
This set operates on anAC power. The voltage is indicated on
the Specifications page. Never attempt to operate the set on
DC power.
46

10 Plasma Monitor
Introduction
- When using the remote control, aim it at the remote control sensor on the monitor.
- Under certain conditions such as if the remote IR signal is interrupted, the remote control may not function. Press
the key again as necessary.
Remote Control Key Functions
Remote Control Key Functions
Installing Batteries
• Open the battery compartment cover on the back side and install the bat-
teries matching correct polarity (+ with +, - with -).
• Install two 1.5V AAA batteries. Don’t mix old or used batteries with new
ones. Replace cover.
AV
SLEEP PSM ARC AUTO
MENU EXIT
MUTE
*
POWER
1 2 3
4 5 6
7 8 9
0
INPUT
SET
POWER
switches the set on from standby or off to
standby.
INPUT
Selects the TV, AV, Component, RGB or
HDMI modes.
switches the set on from standby.
EXIT
Clears all on-screen displays and returns
to TV viewing from any menu.
There is not a function which is supported.
SET
accepts your selection or displays the
current mode.
FF/ GG
Volume Up/Down
DD/ EE
Adjusts menu settings.
Selects menu item.
*: No function
AUTO
Automatic adjustment function.
(Operational for the analog signal only)
ARC
Changes the picture format.
NUMBER buttons
There is not a function which is supported.
MENU
Displays on screen menus one by
one.
Exits the current menu.
Memorizes menu changes.
MUTE
Switches the sound on or off.
SLEEP
Sets the sleep timer.
PSM
Adjusts the factory preset picture
according to the room.
AV buttons
Each time you press the lnput
button it will change to
AV1 Component1
Component2 RGB HDMI/DVI.

4 inches
4 inches
4 inches4 inches
4 inches
W
Wall Mount Installation all Mount Installation
For proper ventilation, allow a clearance of 4” on each
side and 4” from the wall. Detailed installation instruc-
tions are available from your dealer, see the optional
Wall Mounting Bracket Installation and Setup Guide.
•Install this monitor only in a location where adequate ventilation is available.
GROUNDING
Ensure that you connect the grounding / earth wire to prevent possible
electric shock. If grounding methods are not possible, have a qualified
electrician install a separate circuit breaker. Do not try to ground the
unit by connecting it to telephone wires, lightening rods, or gas pipes.
Power
Supply
Short-circuit
Breaker
4 inches 4 inches
4 inches
4 inches
Desktop Pedestal Installation
Desktop Pedestal Installation
For proper ventilation, allow a clearance of 4” on each
side and the top and 4” from the wall. Detailed installa-
tion instructions are included in the optional Desktop
Stand Installation and Setup Guide available from your
dealer.
Installation
Installation
Installation Instructions
Installation Instructions
Owner’s Manual 11
Installation
ENGLISH

12 Plasma Monitor
Installation
External Equipment Connections
External Equipment Connections
NOTE: Not all cables shown are included with the plasma display.
1. First of all, see if the computer, product and the peripherals are turned off.
Then, connect the signal input cable.
2. Connect the Audio cable.
a. When connecting with the D-Sub signal input cable.
When Connecting to your PC
When Connecting to your PC
RGB
OUT
IN
Rear side of the product.
PC
PC
MAC
b. When connecting with the HDMI to DVI signal input cable (not included).
HDMI/DVI IN
Rear side of the product.
PC
AUDIO
(RGB/DVI)
Rear side of the product.
3. Connect the power cord.
(not included)
PC/MAC
Macintosh Adapter (not included)
Use the standard Macintosh adapter since an incompatible
adapter is available in the market. (Different signaling system)

Owner’s Manual 13
Installation
ENGLISH
4. Turn on power by pressing the power button on the product.
Turn on the PC.
Use this function when displaying ANALOG RGB inputs of a PC to the other product.
• To use different products connected to each other Connect one end of the signal input cable(15-pin
D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN
connector of other products.
5. Select an input signal.
Press the INPUT button on the remote control to select the input
signal.
INPUT DD/ EESET
Or, press the SOURCE button on the back of the product.
SOURCE DD/ EEAUTO/SET
a. When connecting with a D-Sub signal input cable.
• Select RGB : 15-pin D-Sub analog signal.
b. When connecting with a HDMI to DVI signal input cable.
• Select HDMI/DVI : HDMI to DVI Digital signal.
Input Input
AV
Component1
Component2
RGB
HDMI/DVIA
AV
Component1
Component2
RGB
HDMI/DVI
NOTES: • How to connect to two computers.
Connect the signal cables (HDMI to DVI and D-Sub) to each computer.
Press the INPUT button on the remote control to select the computer to use.
• Directly connect to a grounded power outlet on the wall or a power bar with a ground wire.
NOTES: • When multi-connecting in/out cascade format, cables to be less damaged are recommended.
We recommend that you should use cable distributor.
W
Watching RGB Outputs atching RGB Outputs
RGB
OUT
IN
RGB
OUT
IN
RGB
OUT
IN
RGB
OUT
IN
15-pin D-Sub Signal Cable
PC Product 1 Product 2 Product 3 Product 4

14 Plasma Monitor
Installation
1. Connect the video cable as shown in the below figure and then connect the power cord.
2. Select an input signal.
Press the INPUT button on the remote control to select the input signal.
INPUT DD/ EESET
Or, press the SOURCE button on the back of the product.
SOURCE DD/ EEAUTO/SET
a. When connecting with an BNC cable.
• Select AV.
b. When connecting with an S-Video cable.
• Select AV.
NOTES: • When the BNC cable is connected simultaneously with S-Video cable, S-Video cable is first.
When watching VCR / DVD
When watching VCR / DVD
a. When connecting with a BNC cable.
• Connect the input terminal with a proper color match.
L-AUDIO-R S-VIDEO
AV IN
VIDEO
AV
OUT
Product
BNC Cable
(not included)
VCR/DVD Receiver
Audio Cable
(not included)
b. When connecting with a S-Video cable.
• Connect to the S-Video input terminal to watch high
image quality movies.
L-AUDIO-R S-VIDEO
AV IN
VIDEO
AV
OUT
Product
Audio Cable
(not included)
VCR/DVD Receiver
S-Video Cable
(not included)
Input
AV
Component1
Component2
RGB
HDMI/DVIA

Owner’s Manual 15
Installation
ENGLISH
When watching HDTV/DVD(480p/576p/720p/1080i/480i/576i)
When watching HDTV/DVD(480p/576p/720p/1080i/480i/576i)
1. Connect the video/audio cable as shown in the below figure and then, connect the power cord.
• Connect the input terminal with a proper color match.
When watching HDMI/DVI/RGB from the VCR/DVD/Set-top Box (480p/576p/720p/1080i)
When watching HDMI/DVI/RGB from the VCR/DVD/Set-top Box (480p/576p/720p/1080i)
1. Connect the video/audio cable as shown in the below figure and then connect thepower cord.
COMPONENT IN
VIDEO
2
1
L-AUDIO-R
Product
Product
VCR/DVD/Set-top Box VCR/DVD/Set-top Box VCR/DVD/Set-top Box
Product Product
BNC Cable
(not included)
HDTV Receiver
Audio Cable
(not included)
COMPONENT IN
VIDEO
2
1
L-AUDIO-R
Product
BNC Cable
(not included)
HDTV Receiver
Audio Cable
(not included)
2. Select an input signal.
Press the INPUT button on the remote control to select the input signal.
INPUT DD/ EESET
Or, press the SOURCE button on the back of the product.
SOURCE DD/ EEAUTO/SET
a. • Select Component 1
b. • Select Component 2
Input
AV
Component1
Component2
RGB
HDMI/DVIA
Input
AV
Component1
Component2
RGB
HDMI/DVIA
2. Select an input signal.
Press the INPUT button on the remote control to select the input signal.
INPUT DD/ EESET
Or, press the SOURCE button on the back of the product.
SOURCE DD/ EEAUTO/SET
a. When connecting with a HDMI to DVI signal input cable.
When connecting with a HDMI signal input cable.
• Select HDMI/DVI
b. When connecting with a D-Sub signal input cable.
• Select RGB
a. b.
a. b.
AUDIO
(RGB/DVI)
HDMI/DVI IN
RGB
OUT
IN
AUDIO
(RGB/DVI)
HDMI/DVI IN
RGB
OUT
IN
AUDIO
(RGB/DVI)
HDMI/DVI IN
RGB
OUT
IN
HDMI to
DVI Signal
Cable (not
included)
HDMI Signal
Cable (not
included)
(not includ-
ed) Cable RCA-PC Audio
Cable
RCA-PC
Audio Cable
Input Input
AV
Component1
Component2
RGB
HDMI/DVIA
AV
Component1
Component2
RGB
HDMI/DVI

16 Plasma Monitor
Installation
• When you set the input signal of the main screen as 'AV (CVBS)', you can transmit the signal that you're watching
to the AV output terminal.
W
Watching atching A AV Outputs V Outputs
L-AUDIO-R S-VIDEO
AV IN
VIDEO
AV
OUT
Video/TV
Video/TV
BNC Cable
(not included)
BNC Cable
(not included)
Audio Cable
(not included)
Audio Cable
(not included)
Product
NOTES: • When multi-connecting in/out cascade format, cables to be less damaged are recommended.
We recommend that you should use cable distributor.
PC Mode – Preset Mode
Resolution Horizontal
Frequency(kHz)
31.469
31.468
31.469
37.500
43.269
37.879
46.875
53.674
49.725
48.363
60.123
68.68
44.772
47
47.72
47
63.981
79.98
75.00
VGA 640 x 350
VGA 720 x 400
VGA 640 x 480
VESA 640 x 480
VESA 640 x 480
VESA 800 x 600
VESA 800 x 600
VESA 800 x 600
MAC 832 x 624
VESA1024 x 768
VESA1024 x 768
VESA1024 x 768
VESA1280 x 720
VESA1280 x 768
VESA1360 x 768
VESA1366 x 768
VESA1280 x 1024
VESA1280 x 1024
VESA1600 x 1200
70
70
60
75
85
60
75
85
75
60
75
85
60
60
60
60
60
75
60
Vertical
Frequency(Hz)
DTV Mode
Component 1/2
O
O
O
O
O
O
RGB
X
X
O
O
O
O
HDMI
X
X
O
O
O
O
RGB : Mode 1 ~ Mode 19
HDMI/DVI : Mode 1 ~ Mode 17
Signal
480i
570i
480p
576p
720p
1080i

Owner’s Manual 17
Operation
ENGLISH
17 Plasma Monitor
Operation
Operation
Menu Language Selection
Menu Language Selection
T
Turning on the Monitor urning on the Monitor
Turning on the Monitor just after installation
1. Connect power cord correctly. At this moment, the Monitor is switched to standby mode.
2. Press the INPUT or button on the Monitor or press the POWER, INPUT button on the remote
control and then the Monitor will switch on.
-The menus can be shown on the screen in the selected language. First select your language.
1. Press the MENU button and then use DD/ EEbutton to select the SPECIAL menu.
2. Press the GGbutton and then use DD/ EEbutton to select Language.
3. Press the GGbutton and then use DD/ EEbutton to select your desired language.
From this point on, the on-screen menus will be shown in the language of your choice.
4. Press the EXIT button to save.
• Press the MENU button to return to the previous menu.

18 Plasma Monitor
Operation
PSM (Picture Status Memory)
PSM (Picture Status Memory)
CSM (Colour Status Memory)
CSM (Colour Status Memory)
- Readjust Picture menu settings for each following input source as preferred.
Picture Menu Options
Picture Menu Options
1. Press the PSM button
- This function adjusts the set to the best picture appearance.
- When adjusting picture options (contrast, brightness, colour, sharpness and tint (NTSC input only)) manually, PSM
is automatically changed to User .
• Each press of the PSM button changes the screen display as shown below.
• You can also select
Dynamic , Standard , Mild or User1/2 in the PICTURE menu.
• Picture options Dynamic , Standard and Mild are preset and programmed for good picture quality at
the factory and cannot be changed.
• When the Intelligent eye function is on, the most suitable picture is automatically adjusted according to
the surrounding conditions.
Dynamic Standard Mild User1 User2
- To initialize values (reset to default settings), select the Normal option.
1. Press the MENU button and then use DD/ EEbutton to select the PICTURE menu.
2. Press the GGbutton and then use DD/ EEbutton to select
CSM .
3. Press the GGbutton and then use DD/ EEbutton to select the desired colour temperature.
4.
Press the EXIT button to return to normal TV viewing.
• Each press of DD/ EEbutton changes the screen display as shown below.
Cool Normal Warm User
SOUND
TIMER
SPECIAL
SCREEN
Prev.
Menu
PSM
CSM
Advancde
Reset
SOUND
TIMER
SPECIAL
SCREEN
Prev.
Menu
PSM
CSM GG
Advancde
Reset
Cool
Normal
Warm
User
SOUND
TIMER
SPECIAL
SCREEN
Prev.
Menu
PSM
CSM
Advancde
Reset
SOUND
TIMER
SPECIAL
SCREEN
Prev.
Menu
PSM GG
CSM
Advancde
Reset
Dynamic
Standard
Mild
User1
User2
1. Press the MENU button and then use DD/ EEbutton to select the PICTURE menu.
2. Press the GGbutton and then use DD/ EEbutton to select
PSM .
2. Press the GGbutton and then use DD/ EEbutton to select
User1 .
2. Press the GGbutton and then use DD/ EEbutton to select the desired picture option (Contrast,Brightness,
Color,Sharpness or Tint).
3. Press the GGbutton and then use FF/ GGbutton to make appropriate adjustments.
4. Press the
EXIT button to save the new settings.
- You can adjust picture contrast, brightness, color, sharpness, and tint to the levels you prefer.
Manual Picture Control (
Manual Picture Control (Off option) option)

Owner’s Manual 19
Operation
ENGLISH
XD
XD
Manual Color
Manual Color T Temperature Control ( emperature Control (A ACC CC set to set to Off Off option) option)
- You can adjust red, green, or blue to any color temperature you prefer.
1. Press the MENU button and then use DD/ EEbutton to select the PICTURE menu.
2. Press the GGbutton and then use DD/ EEbutton to select CSM .
3. Press the GGbutton and then use DD/ EEbutton to select User.
4. Press the GGbutton and then use DD/ EEbutton to select Red, Green or Blue.
5. Use the FF/ GGbutton to make appropriate adjustments.
• The adjustment range of Red, Green and Blue is -10 ~ +10.
6. Press the
EXIT button to save the new settings.
SOUND
TIMER
SPECIAL
SCREEN
Prev.
Menu
PSM
CSM
Advancde
Reset
SOUND
TIMER
SPECIAL
SCREEN
Prev.
Menu
PSM
CSM
Advancde
Reset
Auto
Manual
XD Contrast
XD Colour
XD NR
MPEG NR
GG
On
On
0
Off
1. Press the MENU button and then use DD/ EEbutton to select the PICTURE menu.
2. Press the GGbutton and then use DD/ EEbutton to select
XD .
3. Press the GGbutton and then use DD/ EEbutton to select
Auto or Manual .
4.
Press the EXIT button to return to normal TV viewing.
* Selecting the Manual
This menu is activated after selecting the User1 or User2 of Picture Mode.
1. Press the GGbutton and then DD/ EEbutton to select XD Contrast,XD Colour,XD NR or MPEG NR.
2. Press the GGbutton and then DD/ EEbutton to select On or Off.
3. Press the EXIT button to return to normal TV viewing.
•XD Contrast : Optimizing the contrast automatically according to the brightness of the reflection.
•XD Colour :Adjusting the colors of the reflection automatically to reproduce as closely as possible to the natural colors.
•XD NR : Removing the noise up to the point where it does not damage the original picture.
•MPEG NR : To reduce the picture noise which may appear on the screen during watching the TV.
-XD is LG electronic's unique picture improving technology to display a real HD source through an
advanced digital signal processing algorithm.
- It’s not available to use this function in PC[RGB/HDMI] mode.
